User manual



1/7



Thewirelesstransceiver

ModuleInstruction

Client：Ecovacs

Item:2.4Greceivingandreceivingmodule

PO:JWTRF2411A

Edition:V1.2

Page:1/45

Date:2017/12/04

Manufacturer:jiangsujingweite



directory

Productcharacteristics..............................................................................................................3

Applicationcircuit.....................................................................................................................4

Useinstructionsforpins...........................................................................................................4

approve：audit：make：

customersignback：approve：audit：



2/7



Installationconsiderations........................................................................................................5

Manufacturerrelatedinformation............................................................................................7





3/7



Productcharacteristics

The2.4GmoduleadoptstheJD0069chip,andtheJD0069chipisasingleintegratedwireless

transceiverchipthatworksinthe2.4GHzworldgeneralISMfrequencyband.Thechipis

integratedwithradiofrequencyreceiver,radiofrequencytransmitter,frequencysynthesizer,

GFSKmodulator,GFSKdemodulatorandotherfunctionalmodules.ThroughtheSPIinterfacecan

beoutputpower,channelselectionandprotocolforflexibleconfiguration,andbuilt‐inCRC,FEC,

automaticresponseandautomaticretransmissionmechanism,cangreatlysimplifysystemdesign

andoptimizationperformance.

Thismoduleadoptsthewayofcompletecircuitdesign,needverylittleconnectionof

peripheraldevices,inthesimplestcase,theusersimplyconnectthepowersupply,ground,MOSI,

MISO,CS,CLKthissixlinecanbeused,usingthestampholedesign,hastheadvantagesofsmall

volume,lowpowerconsumptionandhighsensitivitytosendandreceive,applypatchbatch

production.

Lowpowerconsumption

Thecurrentconsumptionis14mAwhentheworkisinlaunchmode(thetransmittingpower

is0dBm);

Thecurrentconsumptionis16mAwhentheworkisinreceivingmode;

Currentconsumptionislowerthan1uAwhenworkinginhibernationmode.

Lowcost

Low‐costsystemsolutions;

Theperipheralcomponentsarelessthan5pcs;

Internalintegratedpowerresetandsoftwareresetfunction,peripheralcontrolissimple;

DoublelayerPCBcanbeusedforplateantenna;

highperformance

Workfrequency:2437MHz;



4/7



Maximumdatarateof1Mbps;

Thesensitivitycanbeupto‐89dBm

Applicationcircuit

Theinputpower：3.3V



Useinstructionsforpins



PinnumberappellationtypeFunctionaldescription

1GNDpowerland

2VCCPWR3.3Vpowerinput

3MOSIDISPIDataentrypin

4CLKDISPIclockentrypin

5MISODISPIDataoutputpin

6RSTDIChipresetfeet,lowleveleffective,resetafter

7PKTDOLaunchreceivestatusflag

8CSDIMakethesignal,lowandeffective,pulllowcan

makethechipexitsleepmode

图1

图2



5/7



form1

Installationconsiderations

1.Beforeinstallation,checkwhethertheshieldshapeisintactandthelogoiscomplete

2.Themoduleadoptsthehalf‐holeweldingmode,anditisnecessarytoensurethatthe

semi‐holeweldingpositionofthemainplateiscoincidentwiththehalfholeofthemoduleto

avoidweldingshortcircuit

3.Theweldingpositionofthemainplateandhalfholeshalloverlapwiththehalfholeofthe

moduletoavoidweldingshortcircuit

4.TheMCUisusedtodrivesoftware,whichcancommunicatewithothermodules

Warning:afterallequipmenthasbeeninstalled,switchonpower



6/7



FCCStatement:

ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassB

digitaldevice,pursuanttoPart15oftheFCCRules.Theselimitsaredesignedto

providereasonableprotectionagainstharmfulinterferenceinaresidential

installation.Thisequipmentgeneratesusesandcanradiateradiofrequencyenergy

and,ifnotinstalledandusedinaccordancewiththeinstructions,maycauseharmful

interferencetoradiocommunications.However,thereisnoguaranteethat

interferencewillnotoccurinaparticularinstallation.Ifthisequipmentdoescause

harmfulinterferencetoradioortelevisionreception,whichcanbedeterminedby

turningtheequipmentoffandon,theuserisencouragedtotrytocorrectthe

interferencebyoneormoreofthefollowingmeasures:

‐‐Reorientorrelocatethereceivingantenna.

‐‐Increasetheseparationbetweentheequipmentandreceiver.

‐‐Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthe

receiverisconnected.

‐‐Consultthedealeroranexperiencedradio/TVtechnicianforhelp.



Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothe

followingtwoconditions:

(1)Thisdevicemaynotcauseharmfulinterference,and(2)thisdevicemustaccept

anyinterferencereceived,includinginterferencethatmaycauseundesired

operation.



Changesormodificationsnotexpresslyapprovedbythepartyresponsiblefor

compliancecouldvoidtheuser'sauthoritytooperatetheequipment.



MPORTANTNOTES

FCCRadiationExposureStatement:

ThisequipmentcomplieswithFCCradiationexposurelimitssetforthforan

uncontrolledenvironment.

Co‐locationwarning:

Thistransmittermustnotbeco‐locatedoroperatinginconjunctionwithanyother

antennaortransmitter.

LimitedChannelsfixedforuseintheUS:

Thisdeviceispre‐settoonlytransmitinFCCapprovedchannelsfrom2437MHz.This

cannotbechanged.



7/7



ICStatement:

ThisdevicecomplieswithIndustryCanada’slicence‐exemptRSSs.Operationis

subjecttothefollowingtwoconditions:

(1)Thisdevicemaynotcauseinterference;and

(2)Thisdevicemustacceptanyinterference,includinginterferencethatmay

causeundesiredoperationofthedevice.



LeprésentappareilestconformeauxCNRd'IndustrieCanadaapplicablesaux

appareilsradioexemptsdelicence.L'exploitationestautoriséeauxdeuxconditions

suivantes:(1)l'appareilnedoitpasproduiredebrouillage,et(2)l'utilisateurde

l'appareildoitacceptertoutbrouillageradioélectriquesubi,mêmesilebrouillageest

susceptibled'encompromettrelefonctionnement.



Manufacturerrelatedinformation

Company:EcovacsRoboticsCo.,Ltd.

Address:No.18YouXiangRoad,WuzhongDistrict,SuzhouCity,JiangsuProvince,P. R . C h i n a 

Contactnumber:0512‐68566030

Website：http://www.js‐jwt.com
