Edco Electronics MP390B Bluetooth MP4 User Manual GL3966 Design Spec
Edco Electronics Inc. Bluetooth MP4 GL3966 Design Spec
User manual
User’s Manual
Bluetooth MP4 player
Model Number: MP390B
*ANY PROBLEM OR QUESTIONS, CALL SUPPORT DESK 0900-3437623 (NL)
*VRAGEN OF PROBLEMEN, BEL ONZE SUPPORT DESK 0900-3437623 (NL)
*BEI FRAGEN ODER PROBLEMEN WENDEN SIE SICH BITTE AN UNSEREN
SERVICE: 00-31-348 409 371 (DU)
*VRAGEN OF PROBLEMEN, BEL ONZE SUPPORT DESK +32 380-80793 (BE)
*SI VOUS AVEZ DES QUESTIONS SOIR DES PROBLEMES, CONTACTEZ-NOUS AU
NUMERO DE SAV SUIVANTE: +32 380-80793 (BE)
Preparation before use
Exterior view
M key: refers to the Menu key. The menu will pop up after pressing this key, and then enter
the next interface after confirming (Enter or Exit). Hold the key to go back to the main
interface.
1、 key: choose the previous option or file.
2、 key: choose the next option or file.
3、 key: refers to the Play/Stop key, playing the role of confirmation also.
4、 V key: quick press to ‘Return’, press and hold it to enter Volume adjustment mode,
Switch on/off
Push and hold the Power button ‘ ’ on top of the player for 3 seconds to turn on, press
and hold this button again to turn off.
When the idle time of the system reaches the off time customized by the user, the player
will automatically be turned off.
Note: When the player is connected to a PC or being charged, this function is
invalid.
Low battery
When the battery power is low, the prompt screen will appear and then the player will
automatically shut down into the sleep mode. It should then be charged instead of
restarting it.
Note: When charging the player, be sure to switch the Power switch to
the ON position, or charging will not occur.
Bluetooth
Select Bluetooth on the main interface, and press key to enter the Bluetooth
submenu.
Select ‘BT Control’ and press key to enter the next submenu,
Select ‘Turn BT On’ and press key to activate the Bluetooth function,
Press V button and return to previous Bluetooth submenu, then select ‘Search Device’
and press key to search all Bluetooth devices available,
Select the Bluetooth device from the ‘Device List’ and press key to pair it,
Press V button and return to previous Bluetooth submenu, select ‘All Music’ and press
key to enter the music list,
Select a song, press to start playing it via the Bluetooth device,
Press and hold the V button to enter the Volume adjustment mode, and then press
and to adjust the sound volume, ranging from 0-24.
Music
Select Music on the main interface, and press key to enter the music play interface.
Press key to switch modes between Play and Pause. Press and keys to
choose the previous file or next file. Hold and key to Fast Forward or Fast
Reverse.
Press and hold the VOL key to enter the Volume adjustment mode, and then press
and to adjust the sound volume, ranging from level 0-24.
Notice：At full volume, prolonged listening to the portable audio device may
damage the user’s hearing.
DIFRNCE device is with ‘max volume limit’ function (level 14), because
listening music with high volume may harm your hearing; you can press the ‘M’
button to cancel this volume limit in case you may really need to.
Movie
1. Select the video play function on the main interface, and press to enter.
2. Use to select the video to play. Press to start playback.
3. Supported resume play from the last breakpoint.
4. Under the halted state, press M to enter the menu options, including Local folder,
Delete file, Delete all, Repeat mode, and Exit. The functions and operation methods are
the same as that of music application.
Recording
Select Record on the main interface and press . Press again to start/pause/restart
and continue the recording. Press V key and it will remind you to save the current
recording content or not, and be ready for new recording.
If the low-power signal appears in the process of pause mode, the system will
automatically save the recording content and go back to the recording function interface.
Press to select the other submenu options, including Recording Library (to play the
recorded files), Record Format, Record Settings..
Images
Press the key on the main interface to enter the picture browsing.
Press to select the picture to view.
Press to view the picture browsed, and press it again to enter slideshow mode.
Press / to browse pictures back and forth.
Press M key to enter the submenu, including Brightness, Backlight timer, Slideshow
settings, Delete picture, Create Playlist.
Press V key to exit.
Play setting
Manual play: in case you need to manually play each picture, press or to view
the previous or next picture.
Auto play: after the entry, press M key and select ‘Slideshow settings’, adjust the time
interval (2-30s) for automatic play and press to confirm, press V to return to Playlist
and press to start browsing, then press again to start auto play. .
E-book
Press key on the main interface to enter the e-book,
Use to select the text file and press to start reading.
Press or for last page or next page,
Press M key to enter the submenu, including Play settings, Delete ebook, Bookmark
settings and etc.
Press V key to exit.
System settings
1. System time: press Volume control to switch among the options of Second, Minute,
Hour, Day, Month and Year, press or to adjust the value, and press M to save the
settings.
2. LCD (Screen) settings:
Dark (black screen) mode: The backlight will be turned off in case of no key operation.
Setting range is from 0 ~ 50 seconds. Setting step size: 5 seconds. The setting of Dark
mode is invalid on the following five interfaces: picture display interface, video player
interface, e-book reading interface, USB on-line equipment interface, and lyrics play
interface.
3. Language selection: Supports many languages such as: Simplified Chinese,
Traditional Chinese, English, Japanese, Korean, French, German, Italian, Dutch,
Portuguese, Spanish, Swedish, Czech, Danish, Polish Russian, Turkish, Hungarian,
Romanian, Arabic, Hebrew, Thai, Indonesian, and Greek.
4. Power off setting:
Power-saving mode: The system shall be automatically turned off in case of no key
operation. Setting range is from 0 ~ 200 seconds. Setting step size: 10 seconds. This
mode is invalid in the modes such as USB, audio and video playback, recording, FM
listening, auto-play of pictures and e-books.
Sleep time: Set the sleep and shutdown time in case of no operation, with the range of
0-120 min, and the step interval of 10 min. The sleep mode shall be valid under all other
modes than the USB mode.
5. Memory info: Displays the total capacity and the used space percentage of master
disc or SD card of player. To switch between the information stored in two discs use
or
6. Format device: Formats the master disc and the disc where cards can plug in.
CAUTION: Use of this operation will delete whatever is on the master disc.
7. Firmware version: displays the current firmware version information.
8.Firmware upgrade
The player can upgrade or repair the player's firmware through the firmware upgrade tool.
9. Keypad tone: Set the volume level of keypad tone, with a range from 0－24. If the step
length is 1.0, it indicates the keypad tone shall be closed.
10. Exit: back to the main interface of system setting.
Troubleshooting
Media player does not work or LCD does not display contents.
- Check the battery power.
Power key does not work.
- The battery is depleted.
Unable to download files
- Check the connection between computer's USB port and USB cables.
- Format the media player.
FCC Statement
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause
undesired operation.
2. Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two
conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference that may cause undesired operation of the
device.
Cet appareil est conforme aux CNR exemptes de licence d'Industrie Canada . Son fonctionnement est soumis aux
deux conditions suivantes :
( 1 ) Ce dispositif ne peut causer d'interférences ; et
( 2 ) Ce dispositif doit accepter toute interférence , y compris les interférences qui peuvent causer un mauvais
fonctionnement de l'appareil.
