Edifier EDF17 Multimedia speaker User Manual e10BT ENGLISH
Edifier International Limited Multimedia speaker e10BT ENGLISH
Edifier >
User Manual
Exclaim Connect - e10BT Multimedia Speaker
User Manual
Page1 Important safety instructions
WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
Thank you for purchasing this Edifier product. For generations, Edifier tries to provide powered speaker products to
satisfy the need of our end customers, even the most demanding ones. This product can add to your home
entertainment, personal computer, and mini home theater great sound performance. Please read this manual
carefully to obtain the best of this system.
1. Read these instructions. 2. Keep these instructions.
3. Heed all warnings. 4. Follow all instructions.
5. Do not use this apparatus near water. 6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one
wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third
prong is provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Unplug this apparatus during lightning storms or when unused for long periods of time.
13. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in
any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
14. The MAINS plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain
readily operable.
FCC Caution:
"Changes or modifications not expressly approved by the part responsible for compliance could void the user's
authority to operate the equipment."
FCC statement:
"This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation."
The lightning flash with arrowhead inside
the triangle, is intended to alert the user
to the presence of un-insulated dangerous
voltage within the product's enclosure
that may be of a sufficient magnitude to
constitute a risk of electric shock to persons.
To prevent the risk of electric shock, do not
remove cover (or back). No user-serviceable
Parts inside. Refer servicing to qualified
Service personnel only.
The exclamation point inside the triangle
is intended to alert the user to the presence
of important operating and maintenance
(servicing) instructions in the literature
accompanying the product.
Page 2 Important safety instructions
"This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15
of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help."
IC statement:
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two
conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired operation of the device.
This Class【B】digital apparatus complies with Canadian ICES-003.
Cet appareil s’accorde avec Industrie Canada licence-exempte RSS standard.
(1) cet appareil ne peut pas causer l’intervention, et
(2) cet appareil doit accepter de l’intervention, y compris l’intervention qui peut causer l’opération non désirée de.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from
tip-over.
Correct Disposal of this product. This marking indicates that this product should not be disposed with other
household wastes throughout the EU. To prevent possible harm to the environment or human health from
uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To return
your used device, please use the return and collection systems or contact the retailer where the product was
purchased. They can take this product for environmental safe recycling.
This equipment is a Class II or double insulated electrical appliance. It has been designed in such a way that
it does not require a safety connection to electrical earth.
Page 3 Unpack the box & Connectivity
Box contents
Active speaker Passive speaker
Connectivity
Page 3 Illustrations
Rear view Side view of active speaker
Power adapter
Speaker connecting cable
3.5mm-3.5mm audio connecting cable
User
Manual
User manual
n
o
pq
t
s
r
Power
indicator
1. Connect the speakers
Connect the active and passive speaker with the speaker
connecting cable.
2. Connect the audio source (like a PC sound card, MP3
player, CD player or external audio source) to the AUX input
port on the back panel of the active speaker with the
3.5mm~3.5mm audio connecting cable.
3. Plug & Play
Please connect the A.C. power plug to the correct A.C. voltage
outlet. Adjust the master volume to the desired listening level
on your device.
Page 4 Operational guide
Power on
nConnect the power adapter to the speaker and then connect to the wall socket.
o The indicator light on the front panel is now lit, the system is on. Press & hold the button for
approximately 3 seconds to put the system into standby mode. Press the button to turn the system back on.
AUX input
n Connect the AUX input cable to your PC sound card, MP3 player or external audio source using the
3.5mm to 3.5mm audio connecting cable.
o Play the selected audio on the connected device.
p Adjust the volume to the desired level.
X Set your device (mobile phone, tablet device, MP3/MP4 player etc.,) to search and select “EDIFIER Exclaim BT”.
Y Pair your device with “EDIFIER Exclaim BT”.
Z Play the audio on your device and adjust the volume to a desired level.
Note: 1. Bluetooth connectivity and compatibility may be different between different source devices, depending on
the software versions of source devices.
2. To enjoy the full Bluetooth functions of this product, please ensure your mobile device has A2DP profile.
3. PIN code for connection is “0000” if needed.
Page 5 Specifications
Power output: RMS 8W × 2 + 10W × 2 (DRC on)
Signal to noise ratio: ≥85dBA
Frequency response: 56Hz~17KHz (±6dB)
n Connect to the active speaker o Connect to the passive speaker
p AUX input port q Connect to the power adapter
rVolume increase s Volume decrease t Standb
y
/ON
Input type: AUX
Input sensitivity: R/L: 700 mV±50mV
SW: 350 mV±50mV
Adjustment: Buttons on active speaker
Bass unit: 3 inch (82mm), magnetically shielded, 6ohm
Treble unit: 1½ inch(40mm), magnetically shielded, 8ohm
Dimension: 105(W) × 310(H) ×180(D) mm
Net Weight: Approx. 2.4kg
Gross Weight: Approx. 3.0kg
Page 9 Troubleshooting
●Switch the EDIFIER e10BT off then on and reconnect to the audio source.
● Ensure Bluetooth function is enabled compatible on your Bluetooth devices.
●Move the devices closer and retry the connection.
●Try another Bluetooth device for connection.
●Please check if power is connected, and if the wall outlet is switched on.
●Please switch the system off then on and reconnect to the audio source.
●Please check if the system is in STBY.
●Please check if the master volume is turned to minimum.
●Please check if the audio input cable is connected correctly.
●Please check if there is signal from audio source.
If you have any further questions or concerns regarding EDIFIER Products…
Asia, Europe, Oceania:
Please visit our website at: www.edifier.com, or email EDIFIER Support for further assistance at:
main@edifier.com,
Î Dear Customer, thank you for purchasing this EDIFIER product. For the EDIFIER warranty applicable for this
product, we refer you to the Edifier website www.edifier-international.com/warranty-terms.
Canada/USA/Mexico: www.edifier.ca, Email: service@edifier.ca
If you prefer, you may contact us by phone, Toll Free: 1-877-EDIFIER (334-3437) in Canada, 1-800-688-7406 in
US.
South America: Please visit www.edifier.com (English) or www.edifierla.com (Spanish/Portuguese) for detailed local
contact information.
