Edifier EDF30 Bluetooth Headphones User Manual
Edifier International Limited Bluetooth Headphones
Edifier >
user manual
Operating instructions
安全指摘事項!
安全のために、このヘッドフオン-スメ-カ-の近く(10cm
以内) で使用または保管することは避けてください。
差し込プラグをコンセントに差し込まないようにして
ください。
お子様が使用になる場合は、 必ず大人が付き添えって
ください。本製品は玩具ではありません。
大きな音量のベッドフオンの使用は、特に長時間使用
する場合において聴覚障害の原因となる恐れがありま
す。
HiFi機器の切り替え時、あるいは機器にへっドフオンを
接続する際に、音量が大きい場合にはガリガリという
騒音が発生し、聴覚に悪影響を与える恐れがあります。
HiFi機器で各ソ-ス（ラジオ、レコードプレーヤ、CDプ
レーヤ. . .）を選ぶ際、あるいはヘッドフオンを接続す
る際には、音量のっまみを常に最少にしてください。
安全なドライブ、そして他の運転手の安全のためにも、
お車を運転する場合、あるいは自転車に乗る場合には
ヘッドヘオンは絶対に使用しないでください。
安全注意事项：
为保证您的人身安全，请勿将该耳机佩戴或放置在离心脏
起搏器过近的位置(小于10CM)。
请勿将插头插入电源插座。
儿童应在成人监督下使用本设备，本产品并非玩具。
在高音量下使用耳机——特别是长时间使用——可能会对
您的听力造成损伤。
操作高保真音响开关或插入耳机时可能会发出尖利的声音，
其在高音量设置下可能会影响您的听力。因此，在切换各
种音源或插入耳机前，请将音量控制设置为最低。
为交通安全起见，驾驶时或骑自行车时请勿使用耳机。
Products of Edifier will be customized for different
applications. Pictures and illustrations shown on this
manual may be slightly different from actual product.
If any difference is found, the actual product prevails.
NOTICE:
For the need of technical improvement and system
upgrade, information contained herein may be subject
to change from time to time without prior notice.
Printed in China
www.edifier.com
www.edifier-international.com
2015 Edifier International Limited. All rights reserved.
Manual Edition 1.0, Oct. 2015
IB-200-W00570-00
경고!
안전상의 이유로,이 헤드폰은 심장박동 조절장치 근처
(10cm 이내)에 두어서는 안됩니다.
잭 플러그를 전류가 흐르는 소켓에 삼입하지 마십시오.
어린이가 헤드폰을 사용할 때는 보호자의 주의 깊은 관찰
이 필요합니다.이 제품은 장난감이 아닙니다.
헤드폰을 높은 볼륨상태에서 특히 장기간 사용할 경우 청
각에 해가 될수 있습니다.
하이파이 오디오 시스템상에서 스위치를 바꾸거나 헤드
폰을 하이파이 오디오 시스템에 연결할 경우,높은 볼륨상
태에서는 청각에 해를 줄수 있는 클릭소리가 날수 있습니
다.그러므로 하이파이 오디오 시스템상의 한 소스기기에
서 다른 소스기기(라디오,레코드 플레이어,CD-플레이어...)
를 선택하거나 헤드폰을 연결시킬 경우에는 항상 볼륨을
초저상태로 조정해 놓으십시오.
여러분의 운정상태와 다른 운전자들의 안전을 보호하기
위해 운정 중이거나 자전거를 타고 이동할 시에는 헤드폰
착용을 삼가 해 주십시오.
War ning!
To guarantee your personal safety, please do not
wear or keep headphones in the vicinity (closer
than 10cm) of a pacemaker.
Do not insert plug into electric sockets.
Supervise children when using the equipment, the
product is not a toy.
Headphone listening at high volume levels –
particularly, over extended periods of time – may
damage your hearing.
The operation of switches on your hi-fi system or
plugging in the headphones may cause clicks which
at high volume setting may affect your hearing.
Therefore, always set the volume control to
minimum before switching between different
sources (tuner, turntable, CD player, etc.) or
plugging in the headphones.
For traffic safety, do not use headphones while
driving or cycling.
Attenzione!
Al fine di garantire la sicurezza personale, fare
attenzione che queste cuffie non siano posizionate
in prossimità del proprio eventuale pace maker
(con una distanza inferiore a 10 cm).
Non introdurre la spina jack in una presa sotto
tensione.
Sorvegliare i bambini quando utilizzano il dispositivo.
Questo apparecchio non è un giocattolo.
L'utilizzo delle cuffie ad alto volume, soprattutto se
prolungato, può danneggiare l'udito.
Maneggiare le manopole del Vostro sistema hi-fi o
inserire le cuffie quando il volume è troppo alto,
potrebbe produrre dei rumori che potrebbero
danneggiare l'udito, soprattutto se il volume è alto.
Si consiglia pertanto di regolare il volume al minimo
prima di passare da una fonte all'altra (radio,
giradischi, lettore CD, ecc.) o prima di collegare le
cuffie.
Per la sicurezza nel traffico, si prega di non usare
mai le cuffie mentre si guida o si va in bicicletta.
Conseils de Sécurité!
Pour votre sécurité, ne portez pas et ne posez pas
ce casque à proximité immédiate (moins de 10 cm)
d'un pacemaker.
Ne pas introduire la fiche à jack dans des prises de
courant.
Surveillez vos enfants s'ils utilisent l'appareil. Ce
produit n'est pas un jouet.
Un casque d'écoute utilisé à un volume élevé risque
de provoquer de troubles de l'audition, en particulier
s'il est porté de façon prolongée.
Lorsque vous procédez à un réglage sur votre
installation hi-fi ou que vous branchez le casque
sur l'installation, des bruits dangereux pour l'oreille
peuvent se produire si le son est réglé sur un
volume élevé. Pour cette raison, il faut toujours
mettre le son au minimum avant de passer d'une
source à l'autre (radio, platine, lecteur de CD ...)
ou de brancher le casque.
Pour ne pas mettre en danger votre sécurité au
volant ni celle des autres usagers de la route,
n'utilisez jamais le casque lorsque vous conduisez
ou que vous roulez à vélo.
¡Atención!
Por su propia seguridad, procure no llevar ni
guardar estos auriculares muy cerca de su
marcapasos (a menos de 10cm).
No introducir el conector Jack en los casquillos
conductores de corriente.
Vigile a sus hijos al utilizar el equipo. Este producto
no es un juguete.
La utilización de auriculares a un volumen muy
alto – sobre todo al utilizarlos durante largos
períodos – puede conducir al deterioro del oído.
Al operar los interruptores de su sistema HiFi o al
conectar los auriculares al sistema puede hacer clic,
lo que a un volumen muy alto puede deteriorar el
oído. Por lo tanto disminuya el nivel de volumen
al mínimo al seleccionar entre diferentes fuentes
(radio, tocadiscos, reproductor de CD ...) en su
sistema HiFi o al conectar los auriculares.
Para no poner en peligro ni su capacidad de
conducir, ni la seguridad de otros usuarios de la
vía pública, no utilice en ningún caso sus
auriculares al conducir un vehículo o al andar en
bicicleta.
Sicherheitshinweis!
Um lhre persönliche Sicherheit zu garantieren,
achten Sie bitte darauf, dass dieser Kopfhörer nicht
in nächster Nähe (näher als 10cm) zu lhrem
Herzschrittmacher getragen oder auf-bewahrt wird.
Klinkenstecker nicht in stromführende Buchsen
einführen.
Beaufsichtigen Sie ihre Kinder bei der Benutzung
des Geräts. Das Produkt ist kein Spielzeug.
Die Verwendung von Kopfhörern kann bei großer
Lautstärke – vor allem im Dauerbetrieb – zur
Schädigung des Gehörs führen.
Bei Umschaltvorgängen an lhrer HiFi-Anlage oder
bei Anschluss des Kopfhörers an die Anlage können
Knackgeräusche auftreten, die bei hoher Lautstärke
das Gehör beeinträchtigen.Drehen Sie daher den
Lautstärkeregler immer auf Minimum, wenn Sie an
lhrer HiFi-Anlage zwischen verschiedenen Quellen
(Radio, Plattenspieler, CD-Player …) wählen oder
den Kopfhörer anschließen.
Um lhre Fahrtüchtigkeit und die Sicherheit anderer
Verkehrsteilnehmer nicht zu gefährden, verwenden
Sie Kopfhörer keinesfalls beim Lenken eines Kfz
oder beim Radfahren.
ﺮﻳﺬﺤﺗ!
ﻭﺃ ﺱﺃﺮﻟﺍ ﺕﺎﻋﺎﻤﺳ ءﺍﺪﺗﺭﺍ ﻡﺪﻋ ﻰﺟﺮﻳ ،ﺔﻴﺼﺨﺸﻟﺍ ﻚﺘﻣﻼﺳ ﻥﺎﻤﻀﻟ
ﻦﻣ ﺏﺮﻘﻟﺎﺑ ﺎﻬﺑ ﻅﺎﻔﺘﺣﻻﺍ) ﻦﻣ ﺏﺮﻗﺃ10ﻢﺳ ( ﻢﻴﻈﻨﺗ ﺯﺎﻬﺟ
ﺐﻠﻘﻟﺍ ﺕﺎﺑﺮﺿ.
ﺔﻴﺋﺎﺑﺮﻬﺁ ﺬﺧﺂﻣ ﻲﻓ ﺲﺑﺎﻘﻟﺍ ﺗُﺪﺧﻞ ﻻ.
،ﺯﺎﻬﺠﻟﺍ ﻡﺍﺪﺨﺘﺳﺍ ﺪﻨﻋ ﻝﺎﻔﻃﻷﺍ ﻰﻠﻋ ﻑﺍﺮﺷﻹﺍ ﻰﻠﻋ ﺹﺮﺣﺍ
ﺔﺒﻌﻟ ﺲﻴﻟ ﺞﺘﻨﻤﻟﺎﻓ.
ﺫﻷﺍ ﺕﺎﻋﺎﻤﺳ ﻝﻼﺧ ﻦﻣ ﻉﺎﻤﺘﺳﻻﺍ ،ﺔﻴﻟﺎﻌﻟﺍ ﺕﻮﺼﻟﺍ ﺕﺎﻳﻮﺘﺴﻣ ﺪﻨﻋ ﻥ
ﻚﻌﻤﺴﺑ ﺮﻀﻳ ﺪﻗ ،ﺔﻠﻳﻮﻃ ﺕﺍﺮﺘﻓ ﻯﺪﻣ ﻰﻠﻋ ﺔﺻﺎﺧ.
ﺕﺎﻋﺎﻤﺳ ﻝﺎﺧﺩﺇ ﻭﺃ ﻚﺑ ﺹﺎﺨﻟﺍ ﻱﺎﻓ ﻱﺍﻭ ﻡﺎﻈﻧ ﻲﻓ ﺢﻴﺗﺎﻔﻤﻟﺍ ﻞﻴﻐﺸﺗ
ﺕﺎﻳﻮﺘﺴﻣ ﻲﻓ ﻚﻌﻤﺳ ﻰﻠﻋ ﺮﺛﺆﺗ ﺪﻗ ﻲﺘﻟﺍﻭ ﺕﺍﺮﻘﻧ ﺐﺒﺴﻳ ﺪﻗ ﺱﺃﺮﻟﺍ
ﺔﻴﻟﺎﻌﻟﺍ ﺕﻮﺼﻟﺍ.
ﺪﺤﻟﺍ ﻰﻠﻋ ﺕﻮﺼﻟﺍ ﻯﻮﺘﺴﻣ ﻲﻓ ﻢﻜﺤﺘﻟﺍ ﺭﺯ ﻂﺒﻀﺑ ﺎﻤﺋﺍﺩ ﻢﻗ ،ﻚﻟﺬﻟ
ﻰﻧﺩﻷﺍ ﺔﻔﻠﺘﺨﻤﻟﺍ ﺭﺩﺎﺼﻤﻟﺍ ﻦﻴﺑ ﻞﻳﺪﺒﺘﻟﺍ ﻞﺒﻗ) ،ﺭﺍﻭﺩ ﺹﺮﻗ ،ﻒﻟﺍﻮﻣ
ﺦﻟﺍ ،ﺔﺠﻣﺪﻣ ﺹﺍﺮﻗﺃ ﻞﻐﺸﻣ (ﺱﺃﺮﻟﺍ ﺕﺎﻋﺎﻤﺳ ﻞﻴﺻﻮﺗ ﺪﻨﻋ ﻭﺃ.
ءﺎﻨﺛﺃ ﺱﺃﺮﻟﺍ ﺕﺎﻋﺎﻤﺳ ﻡﺪﺨﺘﺴﺗ ﻻ ،ﺔﻳﺭﻭﺮﻤﻟﺍ ﺔﻣﻼﺴﻟﺍ ﻞﺟﺃ ﻦﻣ
ﺕﺎﺟﺍﺭﺪﻟﺍ ﺏﻮﺁﺭ ﻭﺃ ﺓﺩﺎﻴﻘﻟﺍ.
Untuk menjamin keselamatan diri Anda, jangan
memakai atau menyimpan headphone di sekitar
(dekat dari 10 cm) alat pacu jantung.
Jangan masukkan steker ke stopkontak listrik.
Awasi anak-anak saat menggunakan peralatan,
produk ini bukan mainan.
Mendengarkan headphone pada tingkat volume
tinggi – khususnya, selama waktu yang
lama – dapat merusak pendengaran Anda.
Penggunaan sakelar pada sistem hi-fi Anda, atau
penyumbatan pada headphone dapat menimbulkan
klik yang pada pengaturan volume tinggi dapat
memengaruhi pendengaran Anda.
Karena itu, selalu mengatur kontrol volume paling
rendah sebelum beralih di antara berbagai sumber
(penala, pemutar piringan hitam, pemutar CD, dll)
atau penyumbatan pada headphone.
Untuk keselamatan lalu lintas, jangan gunakan
headphone selama mengemudi atau berkendara.
Peringatan!
Product Introduction
Please read this manual carefully in order to use
the unit safety and to bring out its maximum
performance. Please be sure to keep this manual
for future.
Features
High performance Neodymium drivers with an ultra
diaphragm produce strong bass and a full audio
experience.
Bluetooth V4.0 makes high-performance audio
processing, and low latency.
10 hours of play back, and works within 10 meter of
distance.
Build-in high sensitivity Omni-directional Microphone
for pickup 360-degree sound source.
Soft leather and lightweight for long comfort use.
Easy to use function keys.
①
②
③
④
⑤
Illustration
① LED indicator
Red light on: Charging, Light off: Fully charged
Blue light blinks quickly: search Bluetooth/incoming call
Blue light blinks slowly: connected to Bluetooth/answering
Red light blinks: low battery level
② Multifunction key
③ Microphone
④ Charging port
⑤ Volume control key
Keys function：
Skip to next track：press and hold“+”key
Return to previous track：press and hold“-”key
Increase volume：press“+”key
Decrease volume：press“-”key
Answer the call：press” ”key once when the phone rings
Hangup the call：press“ ”key once during answering
Reject the call：press and hold“ ”key for approx.2 seconds
Pause music/video：press“ ”to pause playing, press again to
resume playing
1. Press and hold button for approximately 5 seconds, the
headphone is power on. And it's into pairing mode until blue
light continuously blinks;
2. Open headphone's Bluetooth to search Bluetooth device.
Select“W570BT" to pair and connect. After successfully
connected, there's a prompt tone from headphone and blue
light blinks once per 4 seconds.
Note
: After opening Bluetooth pairing,if no connection with
headphone within 3 minutes it will automatically turn off.
EDIFIER W570BT
Operational guide
Check if the volume is minimum.
Ensure the audio source is available.
Ensure your Bluetooth device is available and correctly
connected.
In Bluetooth mode, if the audio playback is interrupted,
move the devices closer and retry the connection.
When connect via Bluetooth®, it’s best to turn the
volume of your device up.
Try another Bluetooth device for connection.
Ensure Bluetooth function is enabled compatible on
your Bluetooth devices.
Ensure EDIFIER W570BT is fully charged.
Switch EDIFIER W570BT off then on and reconnect to
the audio source.
If you have any further questions or concerns
regarding EDIFIER Products, please contact us by
dialing the technology support/service telephone
number (refer to the After-service card).
Troubleshooting
No sound…
Specifications
Note: The design and specifications may be
changed without prior notice in order
to make improvements.
Product type Enclosed，moving coil
Driver unit 30mm
Impedance
Sound Pressure
Level (SPL)
Frequency
Response
32Ohm
106dB
20Hz~20KHz
Bluetooth profile HSP/HFP/A2DP/AVRCP
Bluetooth distance Approx. 10m
Accessory micro-USB cable*1pcs
В целях гарантии вашей безопасности просим
не надевать и не держать наушники вблизи
(ближе 10 см) кардиостимулятора.
Запрещается вставлять штекер в электрические
розетки.
При использовании прибора присматривайте за
детьми, так как это оборудование не является
игрушкой.
Прослушивание музыки через наушники на
высокой громкости, особенно длительное время,
может навредить вашему слуховому аппарату.
Включение и выключение переключателей на
высококачественной системе воспроизведения
или подключение наушников может привести к
возникновению щелчков, которые на высокой
громкости могут нанести вред вашему
слуховому аппарату.
Таким образом, всегда устанавливайте
громкость на минимальный уровень, прежде чем
производить переключение между различными
источниками (тюнер, диск проигрывателя,
CD-проигрыватель и т.д.) или подключать
наушники в систему.
Для безопасности дорожного движения не
используйте наушники во время езды на
велосипеде и вождения автомобиля.
Предупреждение!
Headphone
W570BT
EDIFIER International Limited
IC Caution
FCC Statement
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful interference, and
(2)
this device must accept any interference received, including interference
that may cause undesired operation.
Any Changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
The device meets the exemption from the routine evaluation limits in
section 2.5 of RSS 102 and compliance with RSS-102 RF exposure,
users can obtain Canadian information on RF exposure and compliance.
This device complies with Industry Canada licence-exempt RSS standard
(s). Operation is subject to the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including interference that
may cause undesired operation of the device.
This equipment should be installed and operated with a minumum
distance of 20 cm between the radiator and your body.
Le dispositif rencontre l'exemption des limites courantes d'évaluation
dans la section 2.5 de RSS102 et la conformité à l'exposition de
RSS-102 rf, utilisateurs peut obtenir l'information canadienne sur
l'exposition et la conformité de rf. Le present appareil est conforme aux
CNR d'Industrie Canada applicables aux appareils radio exempts de
licence. L'exploitation estautorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et.
(2) l'utilisateur de l'appareildoit accepter tout brouillageradioélectrique
subi, mêmesi le brouillage est susceptible d'en compromettre le
fonctionnement.
Cet équipement doit être installé et utilisé à une distance minimale de
20 cm entre le radiateur et votre corps.
Note: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated
with minimum distance 20cm between the radiator & your body.
This device complies with Industry Canada licence-exempt RSS
standard(s). Operation is subject to the following two conditions:
(1)this device may not cause interference, and(2) this device must
accept any interference, includinginterference that may cause
undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada
applicables auxappareils radio exempts de licence. L'exploitation
est autorisée aux deux conditions suivantes :(1) l'appareil ne doit
pas produire de brouillage, et(2) l'utilisateur de l'appareil doit
accepter tout brouillage radioélectrique subi, même si le brouillage
est susceptible d'en compromettre lefonctionnement.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment. This device complies with Part
15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
