Edifier EDF50 Bluetooth Stereo Headphones, Headphones, Earphones, Earbuds User Manual W293BT
Edifier International Limited Bluetooth Stereo Headphones, Headphones, Earphones, Earbuds W293BT
Edifier >
User Manual
9HU
Bluetooth Stereo Headphones
W293BT
ᲗFeatures
Გ
Designed like an oxygen tank, the W293BT is machined into
shell form by a precision based metal powder process geared
for optimum performance
Გ
Supported by strong low-frequency output, this earphones is
highly recommended for dynamic audio performance
Გ
CSR chip with Bluetooth V4.1 supports AAC and Qualcomm®
aptX™ audio decoding
Გ
Dual batteries support up to 8 hours of continuous play
Გ
I IPX4 rating ensures water resistance at all times
Გ
Connects up to 10m in distance
Გ
Tilted in- ear design match multi-size earrings, silicone ear tips
for comfortable wear
Გ
Wired controller easily enables voice calls, volume adjustment
and song changes
Bluetooth version: Bluetooth V4.1
Bluetooth protocol: HFP᱃HSP᱃A2DP᱃AVRCP
Audio decoding: Qualcomm® aptX™ audio decoding
Connecting distance: 10m
Working time: 8h
Charging time: 1.5h
Standby time: About 300h
Input: DC 5.0V 500mA
Frequency response range: 20Hz-20KHz
Sound pressure level᷉SPL᷊: 105dB
,PSHGDQFH
Thank you for using the stereo Bluetooth headphone W293bt.
Please carefully read this manual before using the product.
ᲗSpecification
ᲗFunction operational
ᲗBox contents:
micro USB charging
cable*1pcs
Headphone*1pcs Storage bag*1pcs
Ear holder* 3 pairs
Wire clip*1pcs
User manual*1pcs
Warranty card*1pcs
Silicon ear tips*3 pairs
Volume increase/next track
Multi-function key
Volume decrease/previous track
ᲗOperation
Fully Charged low battery level
᱃Charging
Before the first use or the battery is in low level, please complete
charging firstly.
1. Plug the USB charging cable into a PC’s USB port.
2. Connect the charging cable to the headphone’s micro USB
charging port.
Red light on = Charging Red light off = fully charge
Charging time: It takes about 1.5 hours to do a fully charge.
Tips:
1. When Blue light quickly flashes thrice and headphone emit
prompt per 3 minutes, it shows the battery is in low level, and just
can supports 30 minute use.
2. In order to avoid shortening the battery life, please charge the
headphone at least per 3 months when the headphone is un-use
for a long time.
Warning: The rechargeable batteries of the headphone must be
properly disposed for recycling. Never dispose of batteries in fire to
avoid explosion.
2᱃ON/OFF
3. Pairing
Indicator
Blue light flashes quickly
Red light flashes quickly
Function
ON
OFF
Operation
Press and hold multi-function
button for about 3 seconds
Press and hold multi-function
button for about 3 seconds
Indicator
Red/blue light
flash alternately
Function
Enter into pairing
mode
Operation
Press and hold multi-function
key for about 5 seconds
Tips
1. Under pairing status, the headphone will return to standby dormant status after 2
minutes without connecting successfully, you can press any key to start the
operation under standby status.
2. The headphone will automatically turn off after 15 minute without any operation.
3. When the headphone disconnect due to over the effective distance, it will
automatically re-connect if the headphone enter the connecting distance in 5
minutes, and will automatically turn off over 15 minutes.
4. When the headphone is in low battery level, it will automatically enter dormant
state, and it will automatically be awaked and re-connect the near and paire
mobile phones after starting to charge.
1. Make the headphone enter into pairing mode according to the follow operation
2. Keep your mobile and the headphone within 1 meter distance. The closer, the better.
3. Enable Bluetooth function on your mobile and search for Bluetooth devices.
4. Select “EDIFIER W293BT’” to pair up and connect. When successfully connected, the
blue light of the headphone flashes slowly.
Tips:
When under pairing process, please input “0000” when it needs pairing password.
After complete pairing, the headphone will automatically connect the last connected
device in the next time use.
Functions
Answer call
Reject call
Connecting with two devices
1. Pair the headphone with the first device.
2. Re-start the headphone and enter pair status. Press and hold the multi-function
key for about 5 seconds to enter the pairing settings, and pair with the second
device.
3. Select connecting with the headphone from the first device. Now the
headphone is connected with the first and second devices.
4. Making call via headphone
1. Basic operations
Headphone status
Incoming call
ringing
Incoming call
ringing
Calling
Talking
Talking
Talking
Talking
Talking(muted)
Talking
(headphone)
Talking
(mobile phone)
Device connected
and without call
Device connected
and without call
Operation
Press multi-function key
Press and hold multi-function key
for about 2 seconds
Press multi-function key
Press multi-function key
Press + key
Press - key
Press and hold – key for about
2 seconds
Press and hold + key for about
2 seconds
Press and hold multi-function key
for about 2 seconds
Press and hold multi-function key
for about 2 seconds
Double press multi-function key
Double press multi-function key
Cancel Call
End call
Increase volume
Decrease volume
Mute
Transfer call
to mobile
Cancel mute
Transfer call
to headphone
Last number
redial
Voice dial
2. Three party call operation
3. Connect call from two mobiles
Caution: Use for extended periods at high volume may affect your hearing capacity.
Use product responsibly.
Tips:
1. When the volume of the headphone is set to its maximum, you will hear
prompt.
2. Voice dial function just be useful for the mobile phone that has voice
function assistant (such as siri of iPhone), and for the android mobile
phone, it needs under un-lock status for use.
3. Press +/- keys at the same time when without conversation to enable
the voice assistant function, again press +/- keys at the same time to
disenable the voice assistant function.ᷜ
Function
Answer new incoming call
and end the current call
Answer new incoming call
and put the current call on hold
Switch call
End the current call and switch
to the on-hold call
Headphone status
Incoming the
second call
Talking
Incoming the
second call
Talking
Operation
Press multi
-function key
Double press
multi-function key
Double click
multi-function key
Press multi
-function key
Function Headphone status Operation
End the first mobile call and
answer the second incoming call
Put the first mobile call on hold
and answer the second incoming
call
Switch call
End the current call and return
to the on-hold mobile call
Talking while one
call is on hold
Press multi
-function key
Double press
multi-function key
Double click
multi-function key
Press multi
-function key
Another call comes in
when you are on
the first call
Another call comes in
when you are on
the first call
Talking while one
call is on hold
Operation
Press + key
Press - key
Press multi-function key
Press multi-function key
Function
Increase volume
Decrease volume
Previous track
Next track
Pause
Resume play
Headphone status
Play music
Play music
Play music
Play music
Play music
Pause to play music
5. Play music
ᲗMaintenance and repair
Please read the following suggestions. These suggestions will help you stay in
compliance with the warranty terms and prolong the product life.
Გ Keep the product dry and away from wet places to avoid moisture
getting into internal circuit. Do not use the product during intense exercise
or when you sweat too much.
Გ Do not place the product under directly the sunlight or near heat sources.
High temperature will shorten the electronic components’ life and
damage batteries and cause certain plastic parts deformation.
Გ Do not put the product in very cold places in order to prevent its internal
circuit board from being damaged.
Გ Do not dismantle the product. Non-technician may damage the product.
Გ Do not drop, violently vibrate or strike the product with hard items. It may
cause damage to the circuit.
Გ Do not use strong chemical products or detergent to clean the
headphone.
Გ Do not use any sharp items to scratch the product surface. It may
damage the housing surface.
Press and hold – key for about 2 seconds
Press and hold + key for about 2 seconds
IC Caution
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including interference that may cause
undesired operation of the device.
Le present appareil est conforme a ux CNR d'Industrie Canada
applicables aux appareils radio exempts de licence. L'exploitation estautorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareildoit accepter tout brouillageradioélectrique subi, mêmesi le brouillage est susceptible d'en compromettre le
fonctionnement.
FCC Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authori ty to operate the
equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate
radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
IB-200-000000-08
