CP-EX252N LCD Projector
Cost-effective LCD projector
captures attention in classrooms or
conference rooms with dynamic images
and 2,700 ANSI lumens.
Key Features
■ XGA 1024 x 768 resolution
■ 2,700 ANSI lumens white/color output
■ 16W audio output
■ 2,000:1 contrast ratio
■ HDMI x 1 input
■ 10,000 hours lamp life (Eco-2 mode)*
■ 5,000 hours unwoven lter**
1.800.HITACHI
dmd.info@hal.hitachi.com
hitachi-america.us/projectors
CP-EX252N
From the classroom to the conference room, Hitachi’s cost-effective
CP-EX252N LCD projector combines superior image clarity, high quality
value, and long-life reliability. Bright, vivid colors with razor-sharp text and bold
graphics will truly enhance any lesson or meeting and make it more memo-
rable. For added security, the CP-EX252N includes PIN lock protection which
can limit projector users. An MS-1WL wireless multifunction switcher is avail-
able for the CP-EX252N and operates in conjunction with the receiver to pro-
vide expanded source selection and switching options for connected devices.
Plus, Hitachi’s Intelligent Eco Mode with ImageCare combines optimal picture
performance with maximum energy savings for a lower total cost of owner-
ship. For added peace of mind, Hitachi’s CP-EX252N is also backed by a
generous warranty and our world-class service and support programs.
CP-EX252N LCD Projector
Input/Outputs
CP-EX252N
Left Profile
Right Profile
Top View
1314 91011 812
1. LAN
2. USB Type B
3. HDMI
4. Audio in 2
5. Audio in 1
6. Computer in 1
7. Computer in 2/Monitor Out
8. Kensington Lock
9. Control (RS-232C)
10. Audio Out
11. Video
12. Audio in 3
13. AC
14. Security Bar
Front View
HI0509-09/16
All specifications subject to change without notice.
3LCD and the 3LCD logo are registered trademarks of the Seiko Epson Corporation.
©2016 Hitachi America, Ltd. All Rights Reserved
.
Intelligent Eco and Saver Modes
Automatically changes the brightness of the
lamp according to the brightness level of
the screen. Also, automatically changes the
brightness of the lamp if there is no change
in the screen image. Using ImageCare
technology, these features give optimal
picture performance with maximum energy
savings.
ImageCare Technology
ImageCare is a lamp power control function
that combines optimal picture performance
with maximum energy savings by decreasing
energy usage, improving contrast ratio and
lengthening lamp life. The result is a lower
total cost of ownership and decreased
maintenance cost.
PIN Lock / MyScreen / MyText
PIN lock protection can limit projector users.
MyScreen PIN lock keeps captured images
on the startup screen. Users can set any
name logo to MyScreen, clearly identifying
ownership. MyText provides the ability to
write text on the startup screen such as
model name, serial number or location.
FEATURES
Network Control, Maintenance and Security
Embedded networking gives you the ability
to manage and control multiple projectors
over your LAN. Features include scheduling
of events, centralized reporting, and e-mail
alerts for reactive and routine maintenance.
Hitachi America, Ltd.
Toll Free: 1.800.HITACHI • Email: dmd.info@hal.hitachi.com
Web: hitachi-america.us/projectors
Blog: dmd.hitachi-america.us/blog
31 2 4 765
CP-EX252N LCD Projector
* Actual lamp life will vary by individual lamp based on environmental conditions, selected operating mode, user settings and usage. Hours of average lamp
life specified are not guaranteed and do not constitute part of the product or lamp warranty. Lamp brightness decreases over time.
** Actual filter life will vary by individual filter based on environmental conditions, selected operating mode, user settings and usage. Hours of average filter
life specified are not guaranteed and do not constitute part of the product warranty.
Accessories and Lenses
Supplied
Accessories
Remote control, power cord, computer
cable, 2 AA batteries, user's manual CD,
user's manual
Optional
Accessories
NA
Optional Lenses NA
Replacement Parts
Lamp DT01481 with filter
Remote Control HL03031
Filter UX38841
Specifications
Display
Projection Technology 3LCD, 3 chip technology
Resolution XGA - 1024 x 768
White Light Output 2,700 ANSI lumens
Color Light Output 2,700 ANSI lumens
Colors 16.7 million colors
Aspect Ratio Native 4:3 and 14:9 / 16:9 / 16:10 compatible
Contrast Ratio 2,000 : 1 (using active IRIS)
Throw Ratio
(distance : width)
1.5 - 1.8 : 1
Focus Distance 35" - 429"
Display size 30" - 300"
Lens & Operation
Lens F = 2.1 - 2.3, f = 19 - 23 mm, x 1.2 manual zoom
Lamp Wattage 225W
Expected Lamp Life* Approximately 5,000 hours (standard mode)
10,000 hours (Eco-2 mode)
Expected Filter Life** Approximately 5,000 hours
Speaker Output 16W
Keystone V: +/- 30°
Compatibility
Computer VGA, SVGA, XGA, WXGA/
WXGA+/SXGA/SXGA+/UXGA (compressed), MAC16"
H-Sync 15 kHz - 106 kHz
V-Sync 50 Hz - 120 Hz
Composite Video NTSC, NTSC4.43, PAL, PAL-M, -N, SECAM
Component Video 480i, 480p, 576i, 720p, 1080i, 1080p
HDMI 480i, 480p, 576i, 720p, 1080i, 1080p,
Computer signal TMDS clock 27 MHz - 150 MHz
Connectors
Digital Input HDMI x 1 (HDCP compliant)
Computer Input 1 15-pin mini D-sub x 1 (shared with analog component video input)
Computer Input 2 15-pin mini D-sub x 1 (shared with analog component video input
and monitor output)
Computer Monitor Output 15-pin mini D-sub x 1 (shared with analog computer Input 2 and
analog component video input)
Video Input
Composite Video RCA jack x 1
Component Video 15-pin mini D-sub x 2 (shared with computer in 1, in 2/monitor out)
Audio Input 3.5 mm stereo mini jack x 2, RCA jack (L/R) x 1
Audio Output 3.5 mm stereo mini jack x 1
Network LAN Wired RJ-45 port
Network LAN Wireless N/A
USB Type B x 1 (mouse control)
Control Terminals 9-pin D-sub x 1 (RS-232 control)
Ratings & Warranty
Power Supply AC100-120V / AC220-240V, 50/60Hz
Power Consumption 330W / 310W
Operating Temperature 41ºF - 95ºF (5ºC - 35ºC)
Dimensions (W x D x H) 12.6" x 9.7" x 3.4" (excl. protruding parts)
Weight Approximately 6.8 lbs.
Approvals UL 60950-1 / cUL FCC Part 15 subpart B class B
Warranty 3 year limited parts and labor
Extended Service Contract available (additional cost)
Projection Throw Chart
Screen Size 4:3 Throw Distance
Diagonal
Width Min Max
30 24 34 41
60 48 70 84
80 64 94 113
100 80 118 142
200 160 237 285
300 240 357 428
Throw Ratio: 1.5 - 1.8 : 1 (distance : width)
Screen size and throw distance are measured in inches.
