LCD Monitors

Why do we have such conﬁdence in our

products? While others outsource, we continue

to do our own R&D, manufacturing and quality

control. Our longstanding commitment to this “do

it ourselves” approach guarantees the highest qual-

ity, craftsmanship and reliability, while enabling

us to develop and market innovative products and

features at a faster pace.

This centralized approach results in a

number of other advantages as well. EIZO moni-

tors give you greater control over how things look

At EIZO, our mission is clear: satisfying the

most demanding users.

If your monitor is an important part of your

working day, you are one of those users. Whether

you’re in brokerage, graphic design, ﬁnance, IT or

a business ﬁeld, your monitor greatly affects how

effectively and how comfortably you work. We

have specialized in creating the world’s best moni-

tors for over 20 years, with a total commitment to

providing unrivaled quality and complete satisfac-

tion.

If your ﬁrst priority is quality, your ﬁrst choice is EIZO.

onscreen. Whether you’re ﬁne-tuning the color or

setting the best viewing mode for your application,

EIZO’s leading-edge circuitry provides unmatched

capabilities. Our ASIC (application speciﬁc inte-

grated circuit) for example, incorporates ten years

of improvements and enhancements, and now offers

beneﬁts like 12-bit gamma control and 16-bit inter-

nal processing and picture-in-picture.

EIZO monitors set the standard for ergo-

nomics and ﬂexibility, with features like ultra-

slim bezels, easy positioning and a wide range of

mounting solutions.

All of our monitors comply with leading

international safety and environmental standards,

as well as with our own strict standard: EIZO Eco

Products.

Finally, we offer the ﬁrst ﬁve-year warranty

in the industry, backed by a deep commitment to

service and support.

If you appreciate quality, and insist on it

above all else, EIZO monitors are your ﬁrst choice.

If your ﬁrst priority is quality, your ﬁrst choice is EIZO.

MODELS

Wide Gamut

These wide gamut

LCD monitors repro-

duce 95% or more of

the Adobe RGB color

space so they can

display most colors in

a photograph taken

in Adobe RGB mode.

Furthermore, an

sRGB mode is in-

cluded to accurately

reproduce this narrower but commonly used color

space. This ensures that colors meant for sRGB such as

those used on web pages and any photos taken with a

digital camera’s sRGB mode will be reproduced on the

screen as intended.

Fast Response Time

An overdrive circuit is included to reduce midtone

response time and ensure that movies and other

moving images look clean and sharp with an absolute

minimum of blurring and ghosting.

Brightness and Color Uniformity with DUE

Uniformity errors usually seen as brighter or darker

areas on the screen are characteristic of all LCD pan-

els. A Digital Uniformity Equalizer (DUE) function

effectively compensates for these errors, resulting in a

much more uniform image.

12-Bit Gamma, 16-Bit Internal Processing

EIZO’s latest integrated circuit is built-in and fea-

tures a 12-bit look-up table with a color palette of 68

billion colors from which the most appropriate 16.7

million (8-bits) are displayed. It also has 16-bit inter-

nal processing for smooth display of grayscale tones,

especially in dark areas of an image.

These widescreen monitors are the

high-end choice for graphic

design, video editing, 3-D CAD, and

other imaging tasks. Featuring a wide

color gamut, uniform brightness across

the screen, and fast response times,

they are equally suitable for working

with still or moving images.

FEATURES

Without DUE: uneven

brightness distribution

With DUE: uniform bright-

ness across the screen

Without overdrive circuit With overdrive circuit

0.1

0.2

0.3

0.4

0.5

0.6

0.7

0.8

0.9

0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8

Color reproductionarea

（xy coordinate）

NTSC

sRGB

SX3031W

Adobe RGB

FlexScan SX3031W color

gamut comparison

Error Rate (%)

-1

-2

-3

-1

-2

-3

32 64 96 160 192 224 255128

0326496 160 192 224 255128

Error Rate (%)

Internal 16-Bit Processing

Internal 10-Bit Processing

To nes (0 – 255)

With 10-bit processing, the error rate is high in low tonal

areas during calculation. With 16-bit processing, accuracy is

signiﬁcantly improved resulting in fewer conversion errors.

SX3031W 30"Color LCD Monitor

MODELS

Flexible Screen Positioning

The stands let you set the screen to

the optimum viewing position with

wide-ranging height adjustment, 40°

tilt, and 70° swivel. They also pivot

90° for portrait mode viewing.

Color Vision Deﬁciency

Simulation

To accommodate people with red-green color vision

deﬁciency (protanopia and deuteranopia), care must

be taken in choosing color schemes for things like

maps, signage, indicator lights, etc. The FlexScan

SX2462W instantly simulates how still and moving

images appear to people with color vision deﬁciency,

and does so much faster than software-based tools

that slow down with larger ﬁles.

Customer Assurance

SX2462W

SX3031W SX2462W SX3031W SX2462W SX 3031W

Two Monitors in One with Picture-By-Picture

Increase your

work efﬁciency

by dividing the

screen into two

equal halves of

1280 × 1600 or

1200 × 1600 and

displaying input

from two comput-

ers simultane-

ously. There is no

distracting bezel

between the two halves and no toggling back and

forth between the two computers (FlexScan SX3031).

New Button Guide

The FlexScan SX2462W incorporates a new on-

screen button guide. Even when working in a dark

environment, button names and icons can be seen,

making screen adjustment easier than ever.

Deuteranope mode

Original mode

SX2462W 24.1"Color LCD Monitor

An on-screen button guide is provided for easy monitor

adjustment, even in a dark room.

Dividing the screen into two equal

1200 × 1600 halves gives you two

computer screens in one.

ð ð

0DFLQWRVK :LQGRZV

MODELS

Minimize your running costs while

bringing EIZO’s most ecological

and ergonomic features to your office

or trading floor. These “EcoView”

widescreen monitors feature a lightweight,

compact design, an energy-saving

presence sensor, and extremely low power

consumption when in normal operation.

FEATURES

Presence Sensor for Power Savings

An integrated presence sensor called EcoView Sense

prompts the monitor to switch to power save mode

when it does not detect anyone for 40 seconds with

the EV2303W and EV2023W, or 70 seconds with the

EV2333W and EV2313W, and then resumes nor-

mal operation when the user returns. To prevent the

screen from reactivating when it shouldn’t, EcoView

Sense differentiates between the user’s presence and a

still object like an empty chair.

Thinner and Lighter

These monitors debut an innovative, compact design

that reduces the number of internal components,

making them thinner and lighter than previous

FlexScan 20" and 24" widescreen models. This al-

lows the monitor to be shipped in a smaller container

which uses up to 100% recycled material.

Placement Flexibility

EIZO introduces two new ergonomic stands: the

highly-versatile FlexStand (shown below) and the

space-saving TriStand. Both stands offer tilt, swivel

and height adjustment. The FlexStand also offers

portrait rotation and a maximum 225 mm range of

height adjustment. A quick release feature allows for

easy monitor reconﬁguration.

EcoView Sense automatically signals the screen to activate

and stay on, or switch to power save mode by detecting the

user’s presence or absence.

FlexStand

portrait mode

FlexStand

height & tilt

FlexStand

quick release

Compared to a previ-

ous FlexScan 24"

widescreen monitor, the

FlexScan EV2303W’s

slimmed-down cabinet

design cuts the use and

weight of sheet metal

components, shown

here, by up to 90%.

EV2333W 23"Color LCD Monitor

MODELS

Optimized Brightness with Auto EcoView

A sensor on the front of the monitor called Auto

EcoView measures ambient light and optimizes the

screen’s brightness to levels akin to viewing a sheet

of paper under typical ofﬁce lighting conditions.

Since the screen is never too bright, eye strain is

reduced while power consumption is cut by up to

40% compared to operating the monitor with Auto

EcoView turned off and set to the default factory

brightness of 100%.

Energy Efﬁciency Gauge

To encourage

environmental

consciousness

while working,

a user-activated

gauge called “EcoView Index” indicates energy con-

sumption in correlation with the screen’s brightness.

When EcoView Index is fully illuminated, the moni-

tor is operating at optimum energy efﬁciency.

Zero Watts When Turned Off

When the power save mode and off timer are set,

the EV2303W and EV2023W consume less than 0.7

watts and the EV2333W and EV2313W consume less

than 1 watt of power. When turned off via the main

power switch, they consume no electricity at all.

16:9 Aspect Ratio

These are the ﬁrst FlexScan models to feature 16:9

aspect ratios. The 16:9 wide format is the same as-

pect ratio used by HDTV and it lets you enjoy multi-

media content without horizontal letterboxing.

Preset Modes for Optimum Viewing

These monitors come with ﬁve preset modes: Text

mode for ofﬁce applications, Movie mode for video,

Picture mode for graphics, sRGB mode for web brows-

ing, and Custom mode for user-deﬁned settings.

Eco-Friendly Backlight,

Lower Power Consumption

The EV2313W incorporates a mercury-free LED

(light-emitting diode) backlight. With the LED back-

light and Auto EcoView in use, the monitor consumes

just 16 W during typical operation.

Next Generation Connectivity

DisplayPort connectivity with the EV2333W

and EV2313W allows digital audio and video

signal transmission via a single, high-bandwidth cable at

distances up to 15 meters without any signal degradation.

Customer Assurance

EV2313W

EV2333W

EV2303W

EV2023W

EV2313W 23"Color LCD Monitor EV2023W 20"Color LCD Monitor

MODELS

Optimized Brightness with Auto EcoView

A sensor on the front bezel measures ambient light

and optimizes the screen’s brightness, ensuring that

these monitors are never too bright or too dark.

This results in improved ergonomics while cutting

power consumption by up to 51%.

Energy Efﬁciency Gauge

To encourage

environmental

consciousness

while working,

a user-activated

gauge called “EcoView Index” indicates energy con-

sumption in correlation with the screen’s brightness.

When EcoView Index is fully illuminated, the moni-

tor is operating at optimum energy efﬁciency.

Improved Efﬁciency, Reduced Visual Fatigue

EIZO conducted a survey in 2008 to establish the

relationship between eye fatigue and monitor use.

Results showed that features like Auto EcoView,

ergonomic stands, and the EyeCare Manager helped

reduce eye fatigue and improved work efﬁ ciency by

12.5%.

For a white paper regarding this study please visit

www.eizo.com/global/support/wp/pdf/wp_08-001.pdf

Zero Watts When Turned Off

The power save mode and off timer on these moni-

tors reduces their energy consumption to less than

1.5 watts. When turned off via the main power

switch, they consume no electricity at all.

Wide Color Gamut

The S2433W, S2243W, and S2233W reproduce 95%

or more of the Adobe RGB color space. This means

they can display most

colors of a photograph

taken in a camera’s

Adobe RGB mode

including many shades

of cyan and emerald

green that fall outside

the color gamut of typ-

ical sRGB monitors.

Rising energy costs, global environ-

mental concerns, and demands for

increased worker productivity require cre-

ative solutions. To address these challenges,

EIZO offers ﬁve monitors with reduced

power consumption and superb visual er-

gonomics. Available in 24.1" and 22" sizes

with VA or TN technology, these monitors

let you go green and save money at the

same time.

FEATURES

0.1

0.2

0.3

0.4

0.5

0.6

0.7

0.8

0.9

0.0

sRGB

Adobe RGB

S2243W

Color reproduction area

0.10.2

0.3

0.40.5 0.60.7 0.8

FlexScan S2243 color gamut

comparison

Model Auto EcoView OFF* Auto EcoView

Power Reduction

FlexScan S2202W 38 W 23 W 39%

FlexScan S2233W 66 W 32 W 51%

FlexScan S2243W 69 W 36 W 47%

FlexScan S2402W 43 W 27 W 38%

FlexScan S2433W 71 W 40 W 43%

* Figures for Auto EcoView turned off assume monitors are set to the default factory brightness of 100%.

Increases in Quantity of Monitor Work

Quantity of Work

Measurement Condition

Standard

(maximum brightness)

Appropriate

brightness

Appropriate brightness

+ correct working posture,

regular breaks

[%]115

110

105

100

4.6%

increase

7. 9%

increase

100%

104.6%

112.5%

S2433W 24.1"Color LCD Monitor

MODELS

Preset Modes for Optimum Viewing

EIZO’s Fine Contrast function has six preset modes:

Text mode for ofﬁce applications, Movie mode for

video, Picture mode for graphics, sRGB mode for

web browsing, EyeCare mode for use in very dimly-

lit environments, and Custom mode for user-deﬁned

settings.

Compact, High Resolution Screen

With a 1920 × 1200 native resolution, the 22"

FlexScan S2243W displays the same amount of

information as a typical 24.1" monitor, but in 10%

less desk space. This is ideal for ofﬁces where a

24.1" monitor is desired, but cannot be installed due

to space constraints.

Customer Assurance

Next Generation Connectivity

Connect up to three computers at once via the moni-

tors’ DVI-D (digital), D-Sub (analog), and Display-

Port (digital) input terminals. With a DisplayPort

connection, audio and video signals are transmitted

via a single, high-band width cable at distances up to

15 meters without any signal degradation.

Unobtrusive Speakers

0.5 watt speakers are hidden within the monitor cabi-

net, so you can enjoy sound while bezel size is kept to

a minimum. If you require greater volume, the sepa-

rately sold i-Sound L3 with dual 0.9 watt speakers

can be attached to the bottom of the monitor.

Placement Flexibility

A selection of ergonomic stands offer height adjust-

ment, tilt, swivel, and portrait mode viewing. For

installations that require frequent rearrangement of

equipment, a quick mount attachment option allows

the monitor to be quickly and easily mounted and

dismounted with the pull of a lever.

511 mm 566 mm

24.1" 22"

Typical 24.1" monitor FlexScan S2243W

The FlexScan S2243W occupies 10% less desk space than

a typical 24.1" monitor, but displays the same amount of

information.

DisplayPort

Connector

DisplayPort DVI-D D-Sub

QM1 quick mount

attachment

Height adjustable

stand

EzUp

stand

S2202W 22"Color LCD MonitorS2243W 22"Color LCD Monitor

MODELS

SlimEdge Design

Both of these models have thin bezels that save

space on crowded desktops. The FlexScan S1961

has ultra-slim side bezels of only 6.9 mm, ensuring

nearly seamless multi-panel conﬁgurations on the

trading ﬂoor.

Preset Modes for Optimum Viewing

Choose from different preset modes depending on

what kind of work you are doing. The FlexScan

S2100 comes with Text, Picture, Movie, sRGB, and

Custom (user-deﬁned settings) modes. The FlexScan

S1961 offers Text, sRGB, and Custom modes.

Image Mode Assignment

Part of the ScreenManager Pro for LCD utility

software, this function lets you assign a preset

mode to a speciﬁc application. Whenever you use

the application, the screen automatically changes

to the assigned mode.

The FlexScan S2100 and S1961 are

designed to meet the requirements

of graphics professionals and trading

room environments respectively. The

FlexScan S1961 features the thinnest side

bezels we have ever offered – only 6.9 mm

wide – saving considerable desktop space,

especially in multi-panel conﬁgurations.

Both monitors come with EIZO’s

BrightRegulator function which provides

optimum viewing in any ambient light

environment as well as energy savings.

Optimized Brightness with BrightRegulator

A sensor on the front of the monitor measures

ambient light and optimizes the screen’s brightness

to levels akin to viewing a sheet of paper under

typical ofﬁce lighting conditions. Since the screen

is never too bright, eye strain is reduced and energy

is saved.

Brightness Stabilization

At startup or upon wakeup, an EIZO-patented

drift correction function quickly stabilizes the

brightness level. In addition, a sensor measures the

backlight brightness and compensates for bright-

ness ﬂuctuations caused by the ambient tempera-

ture and the passage of time.

100

150

200

250

20 40 60 80 100

With Brightness Drift Correction

Without Brightness Drift Correction

Minutes

Brightness (cd/m2)

Preset Value

FEATURES

S2100 21. 3"Color LCD Monitor

MODELS

Versatile Positioning

Position the screen how you like with height ad-

justment, tilt, swivel, and pivot for portrait mode.

Compliance with VESA standards allows for

mounting on a movable arm or wall bracket.

Audio Capability

The FlexScan S1961 is available with or without

dual 0.3 watt built-in speakers. They are hidden at

the back of the cabinet so bezel size can be kept to

a minimum. For both models, the separately sold

i-Sound L3 sound unit is available. The i-Sound L3

comes with dual 0.9 watt speakers and attaches to

the bottom of the monitor.

Customer Assurance

S2100 S1961 S1961 S2100

10-Bit Gamma Correction

These monitors automatically take 8-bit inputs

signals (256 tones for each primary color) from

the graphics board and uses a 10-bit look-up table

(1,021 tones) to produce smoother, more accurate

gradations of color.

Fast Response Time

The FlexScan 2100 comes with an overdrive cir-

cuit that reduces gray-to-gray response time and

ensures that moving images look clean and sharp

with a minimum of blurring and ghosting.

022520516279 12147

With Overdrive CircuitWithout Overdrive Circuit (Standard Monitor)

Fall

Rise

Response time as measured by EIZO.

162

255

162

121

255

205

Response

Time

(ms)

Response

Time

(ms)

Fall

Rise

162

255

162

121

255

205

Response time varies

by grayscale tone.Response time uniform

for all grayscale tones.

S1961 19"Color LCD Monitor

MODELS

These monitors offer high quality and

reliability in standard 5:4 and 4:3

aspect ratios. Ideal for back ofﬁces, trading

ﬂoors, government facilities, and SOHO,

they have a uniform cabinet design and

offer a wide variety of size, panel, speaker,

and stand combinations.

FEATURES

Preset Modes for Optimum Viewing

Text, sRGB, and Custom (user-deﬁned) imag-

ing modes come as standard with all models. The

FlexScan S1932 also includes Picture, Movie, and

CAD modes for further functionality.

Image Mode Assignment

A USB upstream port allows the use of EIZO’s

ScreenManager Pro for LCD software. With this

software, you can adjust color, screen, and volume

settings with the mouse or keyboard. You can also

use it to assign any of the monitor’s imaging modes

such as Text or sRGB to a particular application so

that when the application is activated, the screen

automatically changes to the assigned mode. (A USB

upstream port is standard with the S1932 and op-

tional with the S1921 and S1721.)

Optimized Brightness with BrightRegulator

A sensor on

the front of the

monitor measures

ambient light and

optimizes the

screen’s brightness

to levels akin to viewing a sheet of paper under typi-

cal ofﬁce lighting conditions. Since the screen is never

too bright, eye strain is reduced and energy is saved.

Brightness Stabilization

At startup or upon wakeup, an EIZO-patented

drift correction function quickly stabilizes the

brightness level. In addition, a sensor measures the

backlight brightness and compensates for bright-

ness ﬂuctuations caused by the ambient tempera-

ture and the passage of time (FlexScan S1932,

S1921, and S1721).

10-Bit Gamma Correction

Automatically takes 8-bit

input signals (256 tones

for each primary color)

from the graphics board

and uses a 10-bit look-up

table (1,021 tones) to produce smoother, more ac-

curate gradations of color (FlexScan S1932, S1921,

S1721, and S1701).

100

150

200

250

20 40 60 80 100

With Brightness Drift Correction

Without Brightness Drift Correction

Minutes

Brightness (cd/m2)

Preset Value

S1932 19"Color LCD Monitor

MODELS

Color Control

Brightness, color temperature, and gain settings are

available in the OSD menu for all models. In addi-

tion, the FlexScan S1932 also offers contrast, satura-

tion, hue, and gamma settings.

Fast Response Time

The FlexScan S1932 comes with an overdrive circuit

that reduces gray-to-gray response time and ensures

that moving images look clean and sharp with a

minimum of blurring and ghosting.

Unobtrusive Speakers

With most of the models

shown here you can choose

your monitor with or without

dual speakers. Because the

speaker housings are on the

back of the monitor, they

don’t obstruct your working space. This ensures

monitors ﬁt neatly together in multi-panel conﬁgu-

rations. The monitor itself looks the same whether

you choose speakers or not. (Speakers are included

as standard with the FlexScan S1932 and S1501 and

optional with other models.)

Versatile Positioning

Choose from three types of stands. The height adjust-

able stand offers height, tilt and swivel adjustment,

and pivots for portrait mode. The ArcSwing stand

provides a wide range of adjustment for screen tilt,

distance, and vertical orientation. The EzUp stand of-

fers added ﬂexibility and viewing comfort by combin-

ing the adjustment capabilities of the other two stands.

(The FlexScan S1501 comes with a tilt stand only.)

Uniform Design

All models presented here share the same cabinet

design so you can maintain a consistent appearance

if you need to purchase several monitors for people in

your company with different requirements.

Customer Assurance

S1932

S1501

S1921

S1901

S1721

S1701

EzUp standHeight adjustable

stand

ArcSwing stand

S1701 17"Color LCD MonitorS1921 19"Color LCD Monitor

MODELS

Analog Capacitive Screen

An analog capacitive panel provides fast touch re-

sponse, extremely long touch life (minimum 225 mil-

lion touches), and high optical clarity. (All models but

the FlexScan T1501 and T1502.)

Communications Protocols

The L760T-C, L362T, and T1501 offer a touch

interface through an RS-232C serial port, and the

L761T-C, L560T-CB, L363T-C, and T1502 through

a USB port.

High Image Quality

These high performance touch panels feature excellent

contrast ratio and brightness, displaying vivid colors

and sharp, clear images. Their viewing angles are wide

(178° for the L761T-C, L760T-C and L560T-CB), with

minimal color shift when viewed from the side.

Brightness Stabilization

At startup or upon wakeup, an EIZO-patented drift cor-

rection function quickly stabilizes the brightness level. In

addition, a sensor measures the backlight brightness and

compensates for brightness ﬂuctuations caused by the

ambient temperature and the passage of time. (All models

except the FlexScan T1501 and T1502.)

Digital and Analog Inputs

With both DVI-D and D-Sub mini 15-pin inputs,

you can use a computer that has either a digital or an

analog graphics board (or both if connected to two

computers), and quickly switch between the inputs

via a front panel button.

Auto Adjustment

With an analog signal, pressing a button on the front

panel automatically adjusts four basic monitor param-

eters: clock pulse, phase, screen position, and range.

(All models but the FlexScan T1501 and T1502.)

sRGB Mode

Sets the monitor to the international sRGB color

space for color matching with applications and pe-

ripherals like scanners, printers and digital cameras.

Versatile Positioning

Position the screen wherever you like with 82 mm

height adjustment, 40° tilt and 70° swivel (FlexScan

L761T-C, L760T-C and L560T-CB). The power sup-

ply is built in, so there is no separate power brick or

The convenience of touch panel moni-

tors makes them a practical choice

for places like hospitals, factories, recep-

tion areas and retail shops. EIZO touch

panel monitors offer superior color and

clarity, and feature slim bezels on the top

and sides to save space on the desk or

counter. Finger touch is standard, with

pen touch available when using the option-

al TP1 dedicated touch pen. EIZO offers a

wide range of models to meet your speciﬁc

requirements.

FEATURES

L760T-C

19" Touch Panel Color LCD Monitor

MODELS

cord. All models comply with VESA mounting stan-

dards so the panel can be removed from the stand

and placed on a movable arm or wall bracket.

Detailed Image Control

This function offers independent control of hue,

saturation, and gain, and adjustment of color

temperature in 500 K increments from 4,000 to

10,000 K (including 9,300 K) for accurate, natural

display of color.

Touch Panel Pointer

For factories or other environ-

ments where gloves are required,

the dedicated TP1 touch pen is

available. (Sold separately.)

Product Information Display

The model name, serial number, and total usage

time are all accessible in the OSD menu.

Customer Assurance

Most models meet the strictest medical, safety and

EMC emission standards, including TÜV/GM, CE

and UL2601-1. They also conform to EIZO’s own

strict Eco Products 2006, 2004, and 2002 environ-

mental criteria for design, manufacture, packaging

and usage, including the introduction of lead-free

solder and chrome-free steel plates.

L760T-C

L362T

T1502

T1501

L761T-C

L760T-C

L560T-CB

L363T-C

L362T

L363T-C

L560T-CB

1 7 " Touch Panel Color LCD Monitor

L363T-C

1 5 " Touch Panel Color LCD Monitor

SPECIFICATIONS

Model Variations ––FlexStand, TriStand FlexStand, TriStand FlexStand, TriStand FlexStand, TriStand Height Adjustable Stand, EzUp Stand, Without

Stand Height Adjustable Stand, EzUp Stand, Without

Stand

Panel Size 29.8" / 76 cm (756 mm diagonal) 24.1" / 61 cm (611 mm diagonal) 23" / 58 cm (584 mm diagonal) 23" / 58 cm (584 mm diagonal) 23" / 58 cm (584 mm diagonal) 20" / 51 cm (508 mm diagonal) 24.1" / 61 cm (611 mm diagonal) 24.1" / 61 cm (611 mm diagonal)

Active Display Size (H × V) 641.3 × 400.8 mm 518.4 × 324 mm 509.8 × 286.7 mm 509.8 × 286.7 mm 509.8 × 286.7 mm 442.8 × 249.1 mm 518.4 × 324 mm 518.4 × 324 mm

Panel Type VA (with overdrive circuit) IPS (with overdrive circuit) VA (with overdrive circuit) TN (with overdrive circuit) TN VA VA (with overdrive circuit) TN

Viewing Angles (H, V) 178°, 178° (at contrast ratio of 10:1) 178°, 178° (at contrast ratio of 10:1) 178°, 178° (at contrast ratio of 10:1) 170°, 160° (at contrast ratio of 10:1) 170°, 160° (at contrast ratio of 10:1) 178°, 178° (at contrast ratio of 10:1) 178°, 178° (at contrast ratio of 10:1) 170°, 160° (at contrast ratio of 10:1)

178°, 178° (at contrast ratio of 5:1)

Brightness 260 cd/m2270 cd/m2300 cd/m2250 cd/m2250 cd/m2250 cd/m2360 cd/m2300 cd/m2

Contrast 900:1 850:1 3000:1 1000:1 1000:1 3000:1 1000:1 1000:1

Response Time (Typical) Gray-to-gray: 6 ms, black-white-black: 12 ms Gray-to-gray: 5 ms, black-white-black: 13 ms Gray-to-gray: 7 ms, black-white-black: 25 ms Gray-to-gray: 4 ms, black-white-black: 5 ms Gray-to-gray: – , black-white-black: 5 ms Gray-to-gray: – , black-white-black: 25 ms Gray-to-gray: 6 ms, black-white-black: 16 ms Gray-to-gray: – , black-white-black: 5 ms

Native Resolution 2560 × 1600 (16:10 aspect ratio) 1920 × 1200 (16:10 aspect ratio) 1920 × 1080 (16: 9 aspect ratio) 1920 × 1080 (16: 9 aspect ratio) 1920 × 1080 (16: 9 aspect ratio) 1600 × 900 (16: 9 aspect ratio) 1920 × 1200 (16:10 aspect ratio) 1920 × 1200 (16:10 aspect ratio)

Pixel Pitch 0.2505 × 0.2505 mm 0.270 × 0.270 mm 0.2655 × 0.2655 mm 0.2655 × 0.2655 mm 0.2655 × 0.2655 mm 0.2768 × 0.2768 mm 0.270 × 0.270 mm 0.270 × 0.270 mm

Display Colors 16.77 million from a palette of 68 billion DVI: 16.77 million from a palette of 68 billion

DisplayPort: 1.07 billion from a palette of 68 billion 16.77 million from a palette of 1.06 billion 16.77 million from a palette of 1.06 billion 16.77 million from a palette of 1.06 billion 16.77 million from a palette of 1.06 billion 16.77 million from a palette of 1.06 billion 16.77 million from a palette of 1.06 billion

Wide Gamut Coverage Adobe RGB: 97%, 100% vs. NTSC Adobe RGB: 98%, 102% vs. NTSC –– ––Adobe RGB: 96%, 92% vs. NTSC –

Look-Up Table 12 bits per color 12 bits per color 10 bits per color 10 bits per color 10 bits per color 10 bits per color 10 bits per color 10 bits per color

Internal Processing 16 bits per color 16 bits per color –– ––––

Cabinet Colors Black Black Gray, Black Gray, Black Gray, Black Gray, Black Gray, Black Gray, Black

Dot Clock Digital: 269 MHz Analog: 170 MHz, Digital: 164.5 MHz Analog: 148.5 MHz, Digital: 148.5 MHz Analog: 148.5 MHz, Digital: 148.5 MHz Analog: 148.5 MHz, Digital: 148.5 MHz Analog: 108 MHz, Digital: 108 MHz Analog: 202.5 MHz, Digital: 162 MHz Analog: 202.5 MHz, Digital: 162 MHz

Analog Scanning Frequency (H, V) –31 – 76 kHz, 49 – 56 Hz 31 – 81 kHz, 55 – 76 Hz 31 – 81 kHz, 55 – 76 Hz 31 – 81 kHz, 55 – 76 Hz 31 – 68 kHz, 55 – 76 Hz 31 – 94 kHz, 55 – 76 Hz 31 – 94 kHz, 55 – 76 Hz

Digital Scanning Frequency (H, V) 31 – 100 kHz, 59 – 61 Hz (VGA Text: 69 – 71 Hz) 31 – 76 kHz, 59 – 61 Hz (VGA Text: 69 – 71 Hz) 31 – 68 kHz, 59 – 61 Hz (VGA Text: 69 – 71 Hz) 31 – 68 kHz, 59 – 61 Hz (VGA Text: 69 – 71 Hz) 31 – 68 kHz, 59 – 61 Hz (VGA Text: 69 – 71 Hz) 31 – 60 kHz, 59 – 61 Hz (VGA Text: 69 – 71 Hz) 31 – 76 kHz, 59 – 61 Hz (VGA Text: 69 – 71 Hz) 31 – 76 kHz, 59 – 61 Hz (VGA Text: 69 – 71 Hz)

Video Input Terminals DVI-D 24 pin × 2 (dual link × 1, single link × 1

[with HDCP]) DVI-I 29 pin × 2 (with HDCP), DisplayPort (with

HDCP) D-Sub mini 15 pin, DVI-D 24 pin (with HDCP),

DisplayPort (with HDCP) D-Sub mini 15 pin, DVI-D 24 pin (with HDCP),

DisplayPort (with HDCP) D-Sub mini 15 pin, DVI-D 24 pin (with HDCP) D-Sub mini 15 pin, DVI-D 24 pin (with HDCP) D-Sub mini 15 pin, DVI-D 24 pin (with HDCP),

DisplayPort (with HDCP) D-Sub mini 15 pin, DVI-D 24 pin (with HDCP)

Audio Input/Output Terminals ––3.5 mm stereo jack / 3.5 mm headphone jack 3.5 mm stereo jack / 3.5 mm headphone jack 3.5 mm stereo jack / 3.5 mm headphone jack 3.5 mm stereo jack / 3.5 mm headphone jack 3.5 mm stereo jack / 3.5 mm headphone jack 3.5 mm stereo jack / 3.5 mm headphone jack

Speakers ––0.35 W speaker 0.35 W speaker 0.45 W speaker 0.45 W speaker 0.5 W + 0.5 W speakers 0.5 W + 0.5 W speakers

USB Ports / Standard 1 upstream, 2 downstream / USB 2.0 1 upstream, 2 downstream / USB 2.0 –– ––1 upstream, 2 downstream / USB 2.0 –

Plug & Play VESA DDC 2B VESA DDC 2B VESA DDC 2B VESA DDC 2B VESA DDC 2B VESA DDC 2B VESA DDC 2B VESA DDC 2B

Power Requirements AC 100 – 120 V / 200 – 240 V, 50 / 60 Hz AC 100 – 120 V / 200 – 240 V, 50 / 60 Hz AC 100 – 120 V / 200 – 240 V, 50 / 60 Hz AC 100 – 120 V / 200 – 240 V, 50 / 60 Hz AC 100 – 120 V / 200 – 240 V, 50 / 60 Hz AC 100 – 120 V / 200 – 240 V, 50 / 60 Hz AC 100 – 120 V / 200 – 240 V, 50 / 60 Hz AC 100 – 120 V / 200 – 240 V, 50 / 60 Hz

Power Consumption 170 W (maximum); 82 W (typical) 95 W (maximum); 48 W (typical) 45 W (maximum); 25 W (typical) 32 W (maximum); 16 W (typical) 33 W (maximum); 18 W (typical) 40 W (maximum); 25 W (typical) 95 W (maximum); 40 W (typical) 58 W (maximum); 27 W (typical)

Power Save Mode Less than 2 W Less than 0.9 W Less than 1.0 W Less than 0.9 W Less than 0.7 W Less than 0.7 W Less than 1.5 W Less than 0.7 W

Height Adjustment Range 118 mm 82 mm With FlexStand: 225 mm (171.3 mm at 0° tilt)

With TriStand: 60 mm With FlexStand: 225 mm (171.3 mm at 0° tilt)

With TriStand: 60 mm With FlexStand: 225 mm (192.5 mm at 0° tilt)

With TriStand: 60 mm With Height Adjustable Stand: 82 mm

With EzUp Stand: 153.1 mm With Height Adjustable Stand: 82 mm

With EzUp Stand: 153.1 mm

Tilt / Swivel / Pivot 40° Up, 0° Down / 35° Right, 35° Left / – 40° Up, 0° Down / 35° Right, 35° Left / 90° With FlexStand: 30° Up, 0° Down / 172° Right,

172° Left / 90°; With TriStand: 25° Up, 0° Down

/ 172° Right, 172° Left / –

With FlexStand: 30° Up, 0° Down / 172° Right,

172° Left / 90°; With TriStand: 25° Up, 0° Down

/ 172° Right, 172° Left / –

With FlexStand: 30° Up, 0° Down / 172° Right,

172° Left / 90°; With TriStand: 25° Up, 0° Down

/ 172° Right, 172° Left / –

With FlexStand: 30° Up, 0° Down / 172° Right,

172° Left / 90°; With TriStand: 25° Up, 0° Down

/ 172° Right, 172° Left / –

With Height Adjustable Stand: 40° Up, 0° Down /

35° Right, 35° Left / 90°; With EzUp Stand: 25°

Up, 0° Down / 172° Right, 172° Left / 90°

With Height Adjustable Stand: 40° Up, 0° Down /

35° Right, 35° Left / 90°; With EzUp Stand: 25°

Up, 0° Down / 172° Right, 172° Left / 90°

Dimensions (W × H × D) With Stand: 689 × 511.5 – 629.5 × 254.7 mm;

Without Stand: 689 × 450 × 90 mm With Stand: 566 × 456 – 538 × 230 mm;

Without Stand: 566 × 367 × 85 mm With FlexStand: 547 × 346.5 – 517.8 × 221 –

236 mm; With TriStand: 547 × 382 – 442 × 200

mm; Without Stand: 547 × 332 × 47.5 mm

With FlexStand: 547 × 346.5 – 517.8 × 221 –

236 mm; With TriStand: 547 × 382 – 442 × 200

mm; Without Stand: 547 × 332 × 44 mm

With FlexStand: 547 × 346.5 – 517.8 × 221 –

236 mm; With TriStand: 547 × 382 – 442 × 200

mm; Without Stand: 547 × 332 × 44 mm

With FlexStand: 476 × 306.5 – 498 × 219 –

236 mm; With TriStand: 476 × 362 – 442 × 200

mm; Without Stand: 476 × 292 × 47 mm

With Height Adjustable Stand: 566 × 456 –

538 × 208.5 mm; With EzUp Stand:

566 × 380.4 – 533.5 × 279.9 – 307.6 mm;

Without Stand: 566 × 367 × 85 mm

With Height Adjustable Stand: 566 × 456 –

538 × 208.5 mm; With EzUp Stand:

566 × 380.4 – 533.5 × 279.9 – 307.6 mm;

Without Stand: 566 × 367 × 85 mm

Net Weight With Stand: 15.7 kg

Without Stand:11.2 kg With Stand: 10.7 kg

Without Stand: 7.1 kg With FlexStand: 7.1 kg

With TriStand: 5.5kg

Without Stand: 4.3 kg

With FlexStand: 6.2 kg

With TriStand: 4.6 kg

Without Stand: 3.4 kg

With FlexStand: 6.9 kg

With TriStand: 5.3 kg

Without Stand: 4.1 kg

With FlexStand: 6.7 kg

With TriStand: 5.1 kg

Without Stand: 3.9 kg

With Height Adjustable Stand: 10.2 kg

With EzUp Stand:12 kg

Without Stand: 7.2 kg

With Height Adjustable Stand: 10.2 kg

With EzUp Stand:12 kg

Without Stand: 7.2 kg

Preset Modes Fine Contrast (Text, Picture, Movie, sRGB,

Custom), Auto Fine Contrast2Color Mode (Text, Picture, Movie, sRGB, User1,

User2, User3), Auto Fine Contrast2Fine Contrast (Text, Picture, Movie, sRGB,

Custom), Auto Fine Contrast2Fine Contrast (Text, Picture, Movie, sRGB,

Custom), Auto Fine Contrast2Fine Contrast (EyeCare, Text, Picture, Movie,

sRGB, Custom), Auto Fine Contrast2Fine Contrast (Text, Picture, Movie, sRGB,

Custom), Auto Fine Contrast2

EcoView Settings Auto EcoView Auto EcoView, EcoView Index, EcoView Sense Auto EcoView, EcoView Index, EcoView Sense Auto EcoView, EcoView Index, EcoView Sense Auto EcoView, EcoView Index, EcoView Sense Auto EcoView, EcoView Index Auto EcoView, EcoView Index

Screen Adjustment Screen Size (full screen, enlarge, normal),

Smoothing (5 stages), Border Intensity Clock, Phase, Position, Range (Auto), Screen Size

(full screen, enlarge, normal) Clock, Phase, Position, Range (Auto), Screen

Size (full screen, enlarge, normal), Smoothing (5

stages), Border Intensity

Clock, Phase, Position, Range (Auto), Screen

Size (full screen, enlarge, normal), Smoothing (5

stages), Border Intensity

Clock, Phase, Position, Range (Auto), Signal

Filter, Screen Size (full screen, enlarge, normal),

Smoothing (5 stages), Border Intensity

Clock, Phase, Position, Range (Auto), Signal

Filter, Screen Size (full screen, enlarge, normal),

Smoothing (5 stages), Border Intensity

Clock, Phase, Position, Range (Auto), Signal

Filter, Screen Size (full screen, enlarge, normal),

Smoothing (5 stages), Border Intensity

Clock, Phase, Position, Range (Auto), Signal

Filter, Screen Size (full screen, enlarge, normal),

Smoothing (5 stages), Border Intensity

Color Adjustment Brightness, Independent 6-Color Control,

Gamma, Temperature, Saturation, Hue, Gain,

Reset

Brightness, Contrast, Independent 6-Color

Control, Gamma, Temperature, Saturation, Hue,

Gain, Contrast and Outline Enhancer, Reset

Brightness, Contrast, Gamma, Temperature,

Saturation, Hue, Gain, Overdrive, Reset Brightness, Contrast, Gamma, Temperature,

Saturation, Hue, Gain, Reset Brightness, Contrast, Gamma, Temperature,

Saturation, Hue, Gain, Reset

Power Management Power Save (DVI DMPM), Off Timer Power Save (VESA DPMS, DisplayPort Rev. 1.1a,

and DVI DMPM), Eco Timer Power Save (VESA DPMS, DisplayPort Rev. 1.1a,

and DVI DMPM), Off Timer Power Save (VESA DPMS, DisplayPort Rev. 1.1a,

and DVI DMPM), Off Timer Power Save (VESA DPMS and DVI DMPM), Off

Timer Power Save (VESA DPMS and DVI DMPM), Off

Timer Power Save (VESA DPMS, DisplayPort Rev. 1.1a,

and DVI DMPM), Off Timer Power Save (VESA DPMS and DVI DMPM), Off

Timer

Sound ––Volume, Power Save, Source (DisplayPort) Volume, Power Save, Source (DisplayPort) Volume, Power Save Volume, Power Save Volume, Power Save, Source (DisplayPort) Volume

Other Settings Signal Settings, Product Information (name,

serial number, resolution, operating time,

etc.), OSD Menu Settings, Adjustment Lock,

Languages (English, French, German, Italian,

Japanese, Simpliﬁed and Traditional Chinese,

Spanish, Swedish), Beep, Power Indicator, Dual

Display3, Reset

Signal Switching, Product Information, OSD

Menu Settings, Auto Sharpness, Mode Preset,

Key Lock, DDC/CI Lock, Languages (English,

German, French, Italian, Japanese, Simpliﬁed

Chinese, Spanish, Swedish, Traditional Chinese),

Power Indicator, All Reset

Signal Switching, Product Information (name,

serial number, resolution, operating time,

etc.), OSD Menu Settings, Adjustment Lock,

Languages (English, French, German, Italian,

Japanese, Simpliﬁed and Traditional Chinese,

Spanish, Swedish), Power Indicator, Reset

Signal Switching, Product Information (name,

serial number, resolution, operating time, etc.),

OSD Menu Settings, Adjustment Lock, DDC/

CI Lock, Languages (English, French, German,

Italian, Japanese, Simpliﬁed and Traditional Chi-

nese, Spanish, Swedish), Power Indicator, Reset

Signal Switching, Product Information (name,

serial number, resolution, operating time, etc.),

OSD Menu Settings, Adjustment Lock, DDC/

CI Lock, Languages (English, French, German,

Italian, Japanese, Simpliﬁed and Traditional Chi-

nese, Spanish, Swedish), Power Indicator, Reset

Signal Switching, Product Information (name,

serial number, resolution, operating time, etc.),

OSD Menu Settings, Adjustment Lock, DDC/

CI Lock, Languages (English, French, German,

Italian, Japanese, Simpliﬁed and Traditional Chi-

nese, Spanish, Swedish), Power Indicator, Reset

Signal Switching, Product Information (name,

serial number, resolution, operating time, etc.),

OSD Menu Settings, Adjustment Lock, DDC/

CI Lock, Languages (English, French, German,

Italian, Japanese, Simpliﬁed and Traditional Chi-

nese, Spanish, Swedish), Power Indicator, Reset

EcoView Index, Sound Power Save, Signal Switch-

ing, Product Information (name, serial number,

resolution, operating time, etc.), OSD Menu

Settings, Adjustment Lock, DDC/CI Lock, DVI Input

Level, Languages (English, French, German, Ital-

ian, Japanese, Simpliﬁed and Traditional Chinese,

Spanish, Swedish), Power Indicator, Reset

Certiﬁcations and Standards TCO’03, TÜV/Ergonomics (including ISO

13406-2), TÜV/GS, c-Tick, CE, CB, UL (cTÜVus),

CSA (cTÜVus), FCC-B, Canadian ICES-003-B,

TÜV/S, VCCI-B, RoHS, WEEE, CCC, EIZO Eco

Products 2006

CUDO certiﬁed mark, TCO Displays 5.0, TÜV/

Ergonomics (including ISO 13406-2), TÜV/GS,

c-Tick, CE, CB, UL (cTÜVus), CSA (cTÜVus), FCC-

B, Canadian ICES-003-B, TÜV/S, VCCI-B, RoHS,

WEEE, EPEAT Silver, EIZO Eco Products 2009

TCO Displays 5.0, EPEAT Gold, TÜV/Ergonomics

(including ISO 13406-2), TÜV/GS, c-Tick, CE, CB,

UL (cTÜVus), CSA (cTÜVus), FCC-B, Canadian

ICES-003-B, TÜV/S, VCCI-B, EPA Energy Star,

RoHS, WEEE, EIZO Eco Products 2009

TCO Displays 5.1, EPEAT Gold, TÜV/Ergonomics

(including ISO 13406-2), TÜV/GS, c-Tick, CE, CB,

UL (cTÜVus), CSA (cTÜVus), FCC-B, Canadian

ICES-003-B, TÜV/S, VCCI-B, EPA Energy Star,

RoHS, WEEE, EIZO Eco Products 2009

TCO Displays 5.0, EPEAT Gold, TÜV/Ergonomics

(including ISO 13406-2), TÜV/GS, c-Tick, CE, CB,

UL (cTÜVus), CSA (cTÜVus), FCC-B, Canadian

ICES-003-B, TÜV/S, VCCI-B, EPA Energy Star,

RoHS, WEEE, EIZO Eco Products 2009

TCO Displays 5.0, EPEAT Gold, TÜV/Ergonomics

(including ISO 13406-2), TÜV/GS, c-Tick, CE, CB,

UL (cTÜVus), CSA (cTÜVus), FCC-B, Canadian

ICES-003-B, TÜV/S, VCCI-B, EPA Energy Star,

RoHS, WEEE, EIZO Eco Products 2009

TCO Displays 5.0, EPEAT Gold (EzUp stand option

is EPEAT Silver), TÜV/Ergonomics (including ISO

13406-2), TÜV/GS, c-Tick, CE, CB, UL (cTÜVus),

CSA (cTÜVus), FCC-B, Canadian ICES-003-B,

TÜV/S, VCCI-B, EPA Energy Star, RoHS, WEEE,

EIZO Eco Products 2009

TCO’03, EPEAT Silver, TÜV/Ergonomics (includ-

ing ISO 13406-2), TÜV/GS, c-Tick, CE, CB,

UL (cTÜVus), CSA (cTÜVus), FCC-B, Canadian

ICES-003-B, TÜV/S, VCCI-B, RoHS, WEEE, EIZO

Eco Products 2009

Supplied Accessories AC power cord, signal cables (DVI-D – DVI-D,

DVI-D – DVI-D (dual link supported), USB cable,

EIZO LCD Utility Disk (PDF user’s manual,

ScreenManager Pro for LCD [USB], ICC Proﬁle),

setup guide

AC power cord, signal cables (DVI-D – DVI-D,

DVI-I – D-Sub mini 15 pin), USB cable, setup

guide, EIZO LCD Utility Disk (PDF user’s manual,

ScreenManager Pro for LCD [USB], EIZO Screen-

Slicer software)

AC power cord, signal cables (DVI-D – DVI-D,

D-Sub – D-Sub), audio cable, EIZO LCD Utility

Disk (PDF user’s manual, ScreenManager Pro

for LCD [DDC/CI], EIZO ScreenSlicer software),

setup guide, spec sheet

AC power cord, signal cables (DVI-D – DVI-D,

D-Sub – D-Sub), audio cable, EIZO LCD Utility

Disk (PDF user’s manual, ScreenManager Pro

for LCD [DDC/CI], EIZO ScreenSlicer software),

setup guide, spec sheet

AC power cord, signal cables (DVI-D – DVI-D,

D-Sub – D-Sub), audio cable, EIZO LCD Utility

Disk (PDF user’s manual, ScreenManager Pro

for LCD [DDC/CI], EIZO ScreenSlicer software),

setup guide, spec sheet

AC power cord, signal cables (DVI-D – DVI-D,

D-Sub – D-Sub), audio cable, EIZO LCD Utility

Disk (PDF user’s manual, ScreenManager Pro

for LCD [DDC/CI], EIZO ScreenSlicer software),

setup guide, spec sheet

AC power cord, signal cables (DVI-D – DVI-D, D-

Sub – D-Sub), USB cable, audio cable, EIZO LCD

Utility Disk (PDF user’s manual, ScreenManager

Pro for LCD [USB], ScreenSlicer software),

setup guide

AC power cord, signal cables (DVI-D – DVI-D, D-

Sub – D-Sub), audio cable, EIZO LCD Utility Disk

(PDF user’s manual, ScreenManager Pro for LCD

[DDC/CI], ICC Proﬁle, ScreenSlicer software),

setup guide

Warranty Five Years4Five Years4Five Years4Five Years4Five Years4Five Years4Five Years4Five Years4

1 Model variations are subject to local availability. For details, please contact the EIZO subsidiary or distributor in your country. 2 The bundled ScreenManager Pro for LCD is necessary to activate Auto Fine Contrast. The USB version of ScreenManager Pro for LCD is compatible with Microsoft

Windows Vista/XP/2000. The DDC/CI version is compatible with Vista. 3 Dual 1200 × 1600 display is available with Dual Display mode. 4 The usage time is limited to 30,000 hours or less, and the warranty period of the LCD panel is limited to three years from the date of purchase.
