TC-900 USER GUIDE1. Tune your video receiver to 916.5 MHz2. Connect power adapter at “Connector A”.3. Connect a video source to the transmitter at “Connector B”.4. The transmitted picture should now be seen on the monitor.5. For best results make sure that the antenna is notobstructed.6. IMPORTANT! Using the TC-900 closer than 10 feet tothe receiver may result in a distorted picture.SPECIFICATIONSFREQUENCY: 916.5 MHz STABILITY: ±±±± 10kHzPOWER OUTPUT: 0.75mW, 50 mV/m@3mCURRENT: 18 mA @ 9VVOLTAGE: 7 - 14 V DCVIDEO INPUT: 1 V pk-pk NTSC or PALABTHIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS.(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVEDTHAT MAY CAUSE UNDESIRED OPERATION.Made in Canada
