Elexa Consumer GWD1 Guardian Water Detector User Manual
Elexa Consumer Products Inc. Guardian Water Detector
User Manual
`
Water Detector
What’s included? How to use?
Water Detector-Front
view
Water Detector-Back
view
Magnet located
under grips
How to use?- without the remote lead
You can use the Water Detector to monitor most appliances and pipes for leaks
without the remote lead. Once paired with your Guardian Valve Controller, place the
Water Detector on a at surface under the item you want monitored where water
will collect if it leaks from above.
Base moulding
SOLIDWORKS Educational Product. For Instructional Use Only.
Water Detector can be made
to rest against 3-1/4” base
moulding for placement near
a wall
SOLIDWORKS Educational Product. For Instructional Use Only.
Leaking Water Sensor
Water Detector can also
detect water that col-
lects under it due to a
leakage
SOLIDWORKS Educational Product. For Instructional Use Only.
Remote Lead
Remote Senosor
Metal Feet
How to use?- with the remote lead
Mount the Water Detecto-
ron a metallic surface of an
appliance using the magnets
on it’s back and place the
remote lead in the area you
want to montitor.Make sure
the remote lead is laying at
with its metal feet making
full contact with the oor or
surface.
Use the remote lead with the Water Detector to detect leaks in hard-to-reach areas.
The remote lead plugs into the Water Detector through the 3.5mm mini jack.
SOLIDWORKS Educational Product. For Instructional Use Only.
Remote Lead un-
der the appliance
Appliance
Leak Sensor
SOLIDWORKS Educational Product. For Instructional Use Only.
What’s included?
SOLIDWORKS Educational Product. For Instructional Use Only.
SOLIDWORKS Educational Product. For Instructional Use Only.
Sensors to detect water
Sensor to detect temperature
Sensors to detect water
PIN
1. After installing and conguring your Guardian Valve Controller with the Guard-
ian App, follow instructions on the App to include your Water Detector to the
system.
2. Click on “Add new Device” > “set up a new sensor” and enter the pin number
located on the back of the Water Detector
How to use?- with the remote lead
To monitor the water level in your sump
pump pit, place the Water Detector on a
nearby surface and suspend the Remote
Lead in the pit 5 inches below the lid.
Suspending the Remote Lead in the pit
allows you to get a notication before
the water starts to overow the pit.
Sump Pump Pit
Remote Lead
Water Detector
NEED HELP? CONTACT GUARDIAN CUSTOMER SERVICE
If you have questions, our trained Customer Service Department is happy to
assist you 24 hours a day, 7 days a week. Contact Guardian Customer Service as
follows: • In North America dial: 1-855-249-1754 • Email Guardian at support@
getguardian.com
DO NOT RETURN THIS PRODUCT TO THE STORE OR WEBSITE FROM WHICH IT
WAS PURCHASED If you believe the product is defective, has a missing or broken
part or are having difculty with it please contact Guardian by Elexa as listed
above for a quick and efcient solution to the problem.
Legal Notices: This device complies with part 15 of the FCC rules. Operation is
subject to the following two conditions (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including
interference thatmay cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio fre-
quency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installa-
tion. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures: Reorient or
relocate the receiving antenna; increase the separation between the equipment and the
receiver; connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.The manufacturer
is not responsible for any radio or TV interference caused by unauthorized modica-
tions to this equipment. Such modications could void the user’s authority to operate
the equipment. Caution: Any changes or modications to this device not explicitly
approved by manufacturer could void your authority to operate this equipment. This
device complies with Industry Canada license-exempt RSS standard(s). Operation is
subject to the following two conditions: (1) this device may not cause interference,
and (2) this device must accept any interference, including interference that may cause
undesired operation of the device.
1 Year Limited Warranty
Elexa Consumer Products, Inc. (”ECP”) warrants to the original retail purchaser (”Purchas-
er”) that the Guardian (the “Product”) will be free of defects in materials or workmanship
under use for one (1) year from the date of purchase (the “Warranty period”).
For the Purchaser only, if the Product fails to perform as specied during the Warranty Pe-
riod due to defective parts or faulty workmanship, ECP will repair or replace the defective
or damaged parts of the Product. Normal wear and tear is not covered nor is abnormal
use, misuse, mishandling, faulty installation, improper shipping, damage caused by disas-
ters such as re, ood or earthquake, neglect, accident or tampering. This warranty covers
only normal use in the United States or Canada.
To obtain warranty service during the Warranty Period, call Guardian Customer Service (1-
855-249-1754) or email: support@getguardian.com for instructions on sending damaged
parts and documentation for a Return Material Authorization (RMA). Products returned to
ECP for repair or replacement without authorization will be returned at the sender’s ex-
pense. All warranty claims must be accompanied by a legible copy of the original receipt
showing date and details of purchase. The RMA number must be clearly written on the
side of the shipping container in which you return the Product or defective parts. Unless
otherwise instructed by ECP, the Product must be sent freight pre-paid to the following
address:
Elexa Consumer Products, c/o Promac,
1153 Timber Dr., Elgin, IL 60123
ECP will repair or replace the defective parts and return them at ECP’s cost by a ship-
ping method selected by ECP. When contacting ECP to obtain an RMA, Purchaser may
request expedited return shipping at Purchaser’s expense.
THIS WARRANTY IS NOT TRANSFERABLE, AND, TO THE MAXIMUM EXTENT PERMITTED
BY APPLICABLE LAW IS IN LIEU OF ALL OTHER WARRANTIES, REPRESENTATIONS AND
CONDITIONS, EXPRESSED OR IMPLIED, STATUTORY OR OTHERWISE, INCLUDING BUT
NOT LIMITED TO THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR
A PARTICULAR PURPOSE. NO OTHER PERSON OR REPRESENTATIVE IS AUTHORIZED TO
MAKE ANY OTHER WARRANTY ON BEHALF OF ECP OR ASSUME FOR ECP ANY OTHER
LIABILITY IN CONNECTION WITH THE SALE OF THIS PRODUCT. IN NO EVENT WILL ECP
BE LIABLE FOR ANY DAMAGES, INCLUDING BUT NOT LIMITED TO INCIDENTAL, SPECIAL
OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OR INABILITY TO USE THE
PRODUCT, INCLUDING DAMAGES DUE TO ECP’S NEGLIGENCE.THIS WARRANTY GIVES
YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY
FROM STATE TO STATE AND COUNTRY TO COUNTRY.
CORRECT DISPOSAL OF BATTERIES IN THIS PRODUCT
This marking on the product, accessories or literature indicates that the product and
its electronic accessories should not be disposed of with other household waste. To
prevent possible harm to the environment or human health from uncontrolled waste
disposal, please separate these items from other types of waste and recycle them
responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product,
or their government ofce, for details of where and how they can take these items for
environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the
purchase contract. This product and its electronic accessories should not be mixed with
other wastes for disposal.
This marking on the battery, manual or packaging indicates that the batteries in this
product should not be disposed of with other household waste. Where marked, the
chemical symbols Hg, Cd or Pb indicate that the battery contains mercury, cadmium
or lead above the reference levels in EC Directive 2006/66. If batteries are not properly
disposed of, these substances can cause harm to human health or the environment.
©2016 Elexa Consumer Products, Inc.
2275 Half Day Rd., Suite 160
Bannockburn, IL 60015
www.getguardiancom
