Elpas Solutions B01 Personal Badge User Manual
Elpas Solutions Ltd. Personal Badge
User Manual
Personal Badge Instruction Manual and Specsheet
FCC Compliance
The FCC Wants You to Know
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by tuning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
a) Reorient or relocate the receiving antenna.
b) Increase the separation between the equipment
and receiver.
c) Connect the equipment to an outlet on a circuit
different from that to which the receiver is
connected.
d) Consult the dealer or an experienced radio/TV
technician.
FCC Warning
Modifications not expressly approved by manufacturer could void
the user authority to operate the equipment under FCC rules.
15.9 (a) Labeling Requirements
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions. (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
IR and RF Personal Badge
P/N: PBU00916 (916.5 MHz)
IR/RF Personal Badge
Description
A small, portable, personal clip-on badge. The badge sends Infra Red signals, in
addition to RF signals in the frequency of 916.5 MHz. The tag is used for locating
people in enclosed environments and providing various location dependent functions
(open doors, alert indication, etc.).
General
Electrical power
source One 3-Volt lithium battery
Data rate 19,200 bits per second
Message
protocol 4 bytes proprietary format
Message
duration 2.08 ms
Button on badge Location dependent function. Button press transmitted
with IR and RF message. Four identical button messages
are transmitted 0.4sec apart on every button press.
Button press decoded by RF and IR RDRs or Central PC.
Battery type CR-2430 Renata
Battery life 18 months, assuming movement 8 hr / day
Battery status
indication Battery status transmitted with every message
LED indicator
on badge Activated with every RF and IR message.
Badge ID Unique factory programmed (ID code, transmit rate,
motion sensor activation and deactivation, etc.)
Dimensions 79 x 39 x 7 mm
Weight
(including
battery)
24 gram
Temperature:
Operating -10 to 70°C
Temperature:
Storage -20 to 60°C
Humidity :
Operating Operating – 5 to 95% RH @ 70°C
Humidity :
Storage Non Operating (12 Hours) – 5 to 95% RH @ 85°C
Safety
Compliance UL 1950, CE EN 60950
IR Transmission
Peak optical
transmitted
power
500mW
Peak
transmission
wavelength
880nm
Peak radiant
intensity 120 mW/Sr
Frequency of
transmission Carrier at 455 KHz
Transmission
rate During human movement – every 3 to 5 sec message.
During rest (no movement) – every 60 sec
Transmission
angle 360° badge plane. ±60° to badge perpendicular axis
RF Transmission
916.5 MHz RF
Modulation ASK (Amplitude Shift Keying of 916.5 MHz carrier)
transmitted 200ms after IR transmission
Average
effective
radiated power
In motion: less than –35 dbm. Motionless: less than –45
dbm
Stability +/- 20ppm
Min ERP -25 dbm (min)
Peak ERP -15 dbm (max)
Transmission
pattern Omnidirectional
Standards Compliance
916.5 MHz RF
FCC compliance FCC Part 15.249
CE compliance 300 220-1
EN 55022
Using the Personal Badge
The following is a set of procedures to ensure proper use of the Personal Badge.
To use the Personal Badge:
1. Keep the IR transmission area clear.
2. Use the pad of your finger to press the button on the back of the badge.
3. The RDRs within the facility pick up the signals.
4. A brief press of the button is all it takes.
5. Maintain the position of the badge for about one second.
Battery Replacement
The battery is located inside the Personal Badge. In order to replace the battery, you
need to remove the two screws of the plastic backing of the Personal Badge and
then remove the old battery and replace it with a new one.
Replace the plastic casing and secure it with the two screws.
