19-INCH COLOR TV/DVD/VHS

EWC19T2

OWNER’S

MANUAL

As an ENERGY STAR

Partner, our company has

determined that this product meets

the ENERGY STAR guidelines for

energy efficiency. ENERGY STAR is

a U.S. registered mark.

If you need additional operating assistance after reading this owner’s

manual or to order replacement accessories, please call

TOLL FREE : 1-800-256-2487.

Please read before using this equipment

INSTRUCCIONES EN ESPAÑOL INCLUIDAS.

This Owner’s Manual is

made of recycled paper. SUPPLIED ACCESSORIES

Batteries

Remote Control Unit

ACCESSORIES

2 AA Batteries

NE203UD

PART NO.

“EMERSON AND THE G-CLEF LOGO ARE REGISTERED TRADEMARKS

OF EMERSON RADIO CORP., PARSIPPANY, NEW JERSEY, U.S.A.”

TD503_01-36 02.2.26 10:09 AM Page 1

1.Read instructions-All the safety and operating instructions

should be read before the appliance is operated.

2.Retain Instructions-The safety and operating instructions

should be retained for future reference.

3.Heed Warnings-All warnings on the appliance and in the

operating instructions should be adhered to.

4.Follow Instructions-All operating and use instructions

should be followed.

5.Cleaning-Unplug TV/DVD/VHS from the wall outlet before

cleaning. Do not use liquid cleaners or aerosol cleaners. Use

a damp cloth for cleaning.

EXCEPTION: Aproduct that is meant for uninterrupted

service and, that for some specific reason, such as the possi-

bility of the loss of an authorization code for a CATV con-

verter, is not intended to be unplugged by the user for clean-

ing or any other purpose, may exclude the reference to

unplugging the appliance in the cleaning description other-

wise required in item 5.

6.Attachments-Do not use attachments not recommended by

the TV/DVD/VHS manufacturer as they may cause hazards.

7.Water and Moisture-Do not use this TV/DVD/VHS near

water-for example, near a bath tub, wash bowl, kitchen sink,

or laundry tub, in a wet basement, or near a swimming pool,

and the like.

8.Accessories-Do not place this TV/DVD/VHS on an unstable

cart, stand, tripod, bracket, or table. The TV/DVD/VHS may

fall, causing serious injury to someone, and serious damage

to the appliance. Use only with a cart, stand, tripod, bracket,

or table recommended by the manufacturer, or sold with the

TV/DVD/VHS. Any mounting of

the appliance should follow the

manufacturer’s instructions and

should use a mounting accessory

recommended by the manufacturer.

An appliance and cart combination

should be moved with care.Quick

stops, excessive force, and uneven

surfaces may cause the appliance

and cart combination to overturn.

AMEUBLES- Cet appareil ne doit

être placé que sur un meuble (avec

ou sans roulettes) recommandé par

le fabricant. Si vous l’installez sur

un meuble à roulettes, déplacez les

deux ensembles avec précaution.

Un arrêt brusque, l’utilisation

d’une force excessive et des sur-

faces irrégulières risquent de désta-

biliser l’ensemble et de le renverser.

9. Ventilation-Slots and openings in the cabinet and the back

or bottom are provided for ventilation and to ensure reliable

operation of the TV/DVD/VHS and to protect it from over-

heating, and these openings must not be blocked or cov-

ered. The openings should never be blocked by placing the

TV/DVD/VHS on a bed, sofa, rug, or other similar surface.

This TV/DVD/VHS should never be placed near or over a

radiator or heat register. This TV/DVD/VHS should not be

placed in a built-in installation such as a bookcase or rack

unless proper ventilation is provided or the manufacturer’s

instructions have been adhered to.

10.Power Sources-This TV/DVD/VHS should be operated

only from the type of power source indicated on the mark-

ing label. If you are not sure of the type of power supply to

your home, consult your appliance dealer or local power

company. For TV/DVD/VHSs intended to operate from

battery power, or other sources, refer to the operating

instructions.

11.Grounding or Polarization-This TV/DVD/VHS is

equipped with a polarized alternating-current line plug(a

plug having one blade wider than the other). This plug will

fit into the power outlet only one way. This is a safety fea-

ture. If you are unable to insert the plug fully into the out-

let, try reversing the plug. If the plug should still fail to fit,

contact your electrician to replace your obsolete outlet. Do

not defeat the safety purpose of the polarized plug.

12.Power-Cord Protection-Power-supply cords should be

routed so that they are not likely to be walked on or

pinched by items placed upon or against them, paying par-

ticular attention to cords at plugs, convenience receptacles,

and the point where they exit from the appliance.

- 2 - EN

1B15

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE

TO RAIN OR MOISTURE.

CAUTION: TO REDUCE THE RISK OF ELECTRIC

SHOCK, DO NOT REMOVE COVER (OR BACK).

NO USER SERVICEABLE PARTS INSIDE. REFER

SERVICING TO QUALIFIED SERVICE PERSON-

NEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

THIS SYMBOL INDICATES THAT DAN-

GEROUS VOLTAGE CONSTITUTING A

RISK OF ELECTRIC SHOCK IS PRESENT

WITHIN THIS UNIT.

THIS SYMBOL INDICATES THAT THERE

ARE IMPORTANT OPERATING AND

MAINTENANCE INSTRUCTIONS IN THE

LITERATURE ACCOMPANYING THE

APPLIANCE.

The caution marking is located on the rear of the cabinet.

IMPORTANT SAFEGUARDS

PORTABLE CART WARNING

S3126A

SYMBOLE D'AVERTISSEMENT POUR

LES COMPOSANTES

APPAREIL ET MEUBLE A ROULETTES

S3126A

TD503_01-36 02.2.26 10:09 AM Page 2

- 3 - EN

1B15

13.Outdoor Antenna grounding-If an outside antenna or

cable system is connected to the TV/DVD/VHS, be sure

the antenna or cable system is grounded so as to provide

some protection against voltage surges and built-up static

charges. Article 810 of the National Electrical Code,

ANSI/NFPA No. 70, provides information with respect to

proper grounding of the mast and supporting structure,

grounding of the lead-in wire to an antenna discharge unit,

size of grounding conductors, location of antenna-discharge

unit, connection to grounding electrodes, and requirements

for the grounding electrode. (Fig. A)

14.Lightning-For added protection for this TV/DVD/VHS

receiver during a lightning storm, or when it is left unat-

tended and unused for long periods of time, unplug it from

the wall outlet and disconnect the antenna or cable system.

This will prevent damage to the TV/DVD/VHS due to

lightning and power-line surges.

15.Power Lines-An outside antenna system should not be

located in the vicinity of overhead power lines or other

electric light or power circuits, or where it can fall into

such power lines or circuits. When installing an outside

antenna system, extreme care should be taken to keep from

touching such power lines or circuits as contact with them

might be fatal.

16.Overloading-Do not overload wall outlets and extension

cords as this can result in a risk of fire or electric shock.

17.Object and Liquid Entry-Never push objects of any kind

into this TV/DVD/VHS through openings as they may

touch dangerous voltage points or short out parts that could

result in a fire or electric shock. Never spill liquid of any

kind on the TV/DVD/VHS.

18.Servicing-Do not attempt to service this TV/DVD/VHS

yourself as opening or removing covers may expose you to

dangerous voltage or other hazards. Refer all servicing to

qualified service personnel.

19.Damage Requiring Service-Unplug this TV/DVD/VHS

from the wall outlet and refer servicing to qualified service

personnel under the following conditions:

a. When the power-supply cord or plug is damaged or frayed.

b. If liquid has been spilled, or objects have fallen into the

TV/DVD/VHS.

c. If the TV/DVD/VHS has been exposed to rain or water.

d. If the TV/DVD/VHS does not operate normally by follow-

ing the operating instructions. Adjust only those controls

that are covered by the operating instructions, as improper

adjustment of other controls may result in damage and will

often require extensive work by a qualified technician to

restore the TV/DVD/VHS to its normal operation.

e. If the TV/DVD/VHS has been dropped or damaged in any

way.

f. When the TV/DVD/VHS exhibits a distinct change in per-

formance-this indicates a need for service.

20.Replacement Parts-When replacement parts are required,

be sure the service technician has used replacement parts

specified by the manufacturer that have the same character-

istics as the original part. Unauthorized substitutions may

result in fire, electric shock, injury to persons or other haz-

ards.

21.Safety Check-Upon completion of any service or repairs to

this TV/DVD/VHS, ask the service technician to perform

routine safety checks to determine that the TV/DVD/VHS

is in proper operating condition.

22.Heat-This TV/DVD/VHS product should be situated away

from heat sources such as radiators, heat registers, stoves,

or other products (including amplifiers) that produce heat.

GROUND CLAMPS

NEC - NATIONAL ELECTRICAL CODE

EXAMPLE OF ANTENNA GROUNDING AS PER

NATIONAL ELECTRICAL CODE

S2898A

WIRE

DISCHARGE UNIT

(NEC SECTION 810-20)

GROUNDING CONDUCTORS

(NEC SECTION 810-21)

ELECTRODE SYSTEM

(NEC ART 250, PART H)

SERVICE

EQUIPMENT

CLAMP

ANTENNA

LEAD IN

ANTENNA

POWER SERVICE GROUNDING

GROUND

ELECTRIC

FIGURE A

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY

INSERT.

ATTENTION: POUR ÉVITER LES CHOC ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS LARGE DE

LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET POUSSER JUSQU’AU FOND.

TD503_01-36 02.2.26 10:09 AM Page 3

- 4 - EN

1B15

RADIO-TV INTERFERENCE

This equipment has been tested and found to com-

ply with the limits for a Class B digital device, pur-

suant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against

harmful interference in a residential installation.

This equipment generates, uses, and can radiate

radio frequency energy and, if not installed and

used in accordance with the instructions, may cause

harmful interference to radio communications.

However, there is no guarantee that interference

will not occur in a particular installation. If this

equipment does cause harmful interference to

radio or television reception, which can be deter-

mined by turning the equipment off and on, the

user is encouraged to try to correct the interfer-

ence by one or more of the following measures:

1) Reorient or relocate the receiving antenna.

2) Increase the separation between the equipment

and receiver.

3) Connect the equipment into an outlet on a cir-

cuit different from that to which the receiver is

connected.

4) Consult the dealer or an experienced radio/TV

technician for help.

FCC WARNING- This equipment may gener-

ate or use radio frequency energy. Changes or

modifications to this equipment may cause

harmful interference unless the modifications

are expressly approved in the instruction man-

ual. The user could lose the authority to oper-

ate this equipment if an unauthorized change

or modification is made.

IMPORTANT COPYRIGHT INFORMATION

Unauthorized copying, broadcasting, public perfor-

mance and lending of discs are prohibited.

LASER SAFETY

This unit employs a laser. Only a qualified service

person should remove the cover or attempt to ser-

vice this device, due to possible eye injury.

CAUTION: USE OF CONTROLS OR ADJUST-

MENTS OR PERFORMANCE OF PROCE-

DURES OTHER THAN THOSE SPECIFIED

HEREIN MAY RESULT IN HAZARDOUS

RADIATION EXPOSURE.

CAUTION: VISIBLE AND INVISIBLE LASER

RADIATION WHEN OPEN AND INTERLOCK

DEFEATED. DO NOT STARE INTO BEAM.

LOCATION: INSIDE, NEAR THE DECK

MECHANISM.

This Class B digital apparatus complies with

Canadian ICES-003.

Cet appareil numérique de la classe B est con-

forme à la norme NMB-003 du Canada.

CAUTION: TO PREVENT ELECTRIC SHOCK,

MATCH WIDE BLADE OF PLUG TO WIDE

SLOT, FULLY INSERT.

ATTENTION: POUR ÉVITER LES CHOC

ÉLECTRIQUES, INTRODUIRE LA LAME LA

PLUS LARGE DE LA FICHE DANS LA

BORNE CORRESPONDANTE DE LA PRISE

ET POUSSER JUSQU’AU FOND.

PRECAUTIONS

TD503_01-36 02.2.26 10:09 AM Page 4

- 5 - EN

1C29

AVOID THE HAZARDS OF

ELECTRICAL SHOCK AND FIRE

LOCATION

For safe operation and satisfactory performance of

your TV/DVD/VHS, keep the following in mind

when selecting a place for its installation:

•Shield it from direct sunlight and keep it away from

sources of intense heat.

•Avoid dusty or humid places.

•Avoid places with insufficient ventilation for proper

heat dissipation. Do not block the ventilation holes at

the top and bottom of the unit. Do not place the unit

on a carpet because this will block the ventilation

holes.

•Install unit in a horizontal position.

•Avoid locations subject to strong vibration.

•Do not place the TV/DVD/VHS near strong magnetic

fields.

•Avoid moving TV/DVD/VHS to locations where

temperature differences are extreme.

•Do not handle the power cord with wet hands.

•Do not pull on the power cord when disconnecting

it from an AC wall outlet. Grasp it by the plug.

•If, by accident, water is spilled on your unit, unplug

the power cord immediately and take the unit to our

Authorized Service Center for servicing.

•Do not put your fingers or objects into the

TV/DVD/VHS disc loading tray.

•Do not place anything directly on top of the unit.

WARNING

Moisture condensation may occur inside the unit

when it is moved from a cold place to a warm place,

or after heating a cold room or under conditions of

high humidity. If a DVD is played in a TV/DVD/

VHS which has moisture, it may damage the DVD

and TV/DVD/VHS. Therefore when the condensation

occurs inside the unit, turn the POWER button on

and allow at least 2 hours for the unit to dry out.

The serial number of this product may be found on the back of the unit. No other TV/DVD/VHS has the same

serial number as yours. You should record the number and other vital information here and retain this book as

a permanent record of your purchase to aid identification in case of theft. Serial numbers are not kept on file.

Date of Purchase

Dealer Purchase from

Dealer Address

Dealer Phone No.

Model No.

Serial No.

ANOTE ABOUT RECYCLING

This product’s packaging materials are recyclable and can be reused. Please dispose of any materials in

accordance with your local recycling regulations.

Batteries should never be thrown away or incinerated but disposed of in accordance with your local regula-

tions concerning chemical wastes.

TD503_01-36 02.2.26 10:09 AM Page 5

- 6 - EN

1C29

TABLE OF CONTENTS

CIMPORTANT SAFEGUARDS . . . . .2

CPRECAUTIONS . . . . . . . . . . . . . . . .4

LOCATION . . . . . . . . . . . . . . . . . . .5

AVOID THE HAZARDS OF

ELECTRICAL SHOCK AND FIRE .5

WARNING . . . . . . . . . . . . . . . . . . . .5

CFEATURES . . . . . . . . . . . . . . . . . . . .7

COPERATING CONTROLS AND

FUNCTIONS . . . . . . . . . . . . . . . . . . .9

CPREPARATION FOR USE . . . . . . .11

ANTENNA/CABLE

CONNECTIONS . . . . . . . . . . . . . . .11

CONNECTING TO EXTERNAL

INPT JACKS . . . . . . . . . . . . . . . . .12

INSTALLING THE BATTERIES . .12

EXTERNAL INPUT MODE . . . . . .12

CONNECTING TO A STEREO

SYSTEM (for DVD) . . . . . . . . . . . .13

CONNECTING TO AN AMPLIFIER

EQUIPPED WITH DIGITAL INPUT

JACKS, MD DECK OR DAT DECK

(for DVD) . . . . . . . . . . . . . . . . . . . .13

CONNECTING TO A DOLBY

DIGITAL DECODER

OR DTS DECODER (for DVD) . . .14

CSET UP FOR USE . . . . . . . . . . . . .15

CHANNEL SET UP

FOR THE FIRST TIME . . . . . . . . .15

DELETING (OR ADDING)

CHANNEL . . . . . . . . . . . . . . . . . . .15

CHANNEL SET UP AGAIN . . . . . .16

SELECTING THE LANGUAGE . .16

DAYLIGHT-SAVING TIME . . . . . .16

CLOCK SET UP

(AUTO / MANUAL) . . . . . . . . . . . .17

TV/VCR SECTION

CTV OPERATION . . . . . . . . . . . . . . .19

WATCHING A TV PROGRAM . . .19

DEGAUSSING . . . . . . . . . . . . . . . .19

PICTURE CONTROL . . . . . . . . . . .19

CLOSED CAPTION SYSTEM . . . .20

V-CHIP SET UP . . . . . . . . . . . . . . .21

CMTS(Multi-Channel Television

sound)SYSTEM . . . . . . . . . . . . . . . .23

CHECKING THE SELECTED

MTS MODE . . . . . . . . . . . . . . . . . .23

MTS RECORDING/MONITOR

MODE . . . . . . . . . . . . . . . . . . . . . .23

SELECTING THE MTS SYSTEM .24

CVIDEO CASSETTE . . . . . . . . . . . . .25

PLAYBACK . . . . . . . . . . . . . . . . . . .26

NORMAL PLAYBACK . . . . . . . . .26

TRACKING ADJUSTMENT . . . . .26

SLOW MOTION . . . . . . . . . . . . . .26

PICTURE SEARCH . . . . . . . . . . . .26

STILL PICTURE . . . . . . . . . . . . . .26

VERTICAL HOLD CONTROL . . .26

CSPECIAL PLAYBACK . . . . . . . . . .27

RENTAL PLAYBACK . . . . . . . . . .27

AUTO REPEAT PLAYBACK . . . . .27

CSEARCH . . . . . . . . . . . . . . . . . . . . .28

ZERO RETURN . . . . . . . . . . . . . . .28

TIME SEARCH . . . . . . . . . . . . . . .28

INDEX SEARCH . . . . . . . . . . . . . .29

CSPECIAL FEATURES . . . . . . . . . .29

REAL TIME TAPE COUNTER . . .29

AUTO REWIND-EJECT . . . . . . . .29

CRECORDING . . . . . . . . . . . . . . . . .30

NORMAL RECORDING . . . . . . . .30

SKIPPING UNWANTED SCENES

DURING

RECORDING . . . . . . . . . . . . . . . . .30

OTR (One Touch Recording) . . . . . .31

COPYING A VIDEO CASSETTE

(Requires a VCR or camcorder) . . .31

CTIMER . . . . . . . . . . . . . . . . . . . . . .32

AUTOMATIC

TIMER RECORDING . . . . . . . . . .32

TIMER PROGRAM EXTENSION .33

HINTS FOR AUTOMATIC TIMER

RECORDING . . . . . . . . . . . . . . . . .34

AUTO RETURN . . . . . . . . . . . . . . .34

SLEEP TIMER . . . . . . . . . . . . . . . .34

CON SCREEN DISPLAY . . . . . . . . .35

CCABLE CHANNEL

DESIGNATIONS . . . . . . . . . . . . . .35

DVD SECTION

CABOUT THE DISCS . . . . . . . . . . . .36

PLAYABLE DISCS . . . . . . . . . . . .36

DISC TYPES . . . . . . . . . . . . . . . . .36

SYMBOLS USED IN

THIS MANUAL . . . . . . . . . . . . . . .36

CPLAYING A DISC . . . . . . . . . . . . . .37

PLAYING A DVD VIDEO OR AN

AUDIO CD

. . . . . . . . . . . . . . . . . . .36

USING THE DVD MENUS . . . . . .36

USING THE TITLE MENU . . . . . .36

RESUMING PLAYBACK

FROM THE POINT WHERE

PLAYBACK STOPPED . . . . . . . . .38

FAST FORWARD/REVERSE . . . . .38

PAUSING PLAYBACK OR DIS-

PLAYING

ASTILL PICTURE . . . . . . . . . . . . .38

STEPPING THROUGH FRAMES .38

SLOW MOTION . . . . . . . . . . . . . .39

PLAYING FROM A DESIRED

TITLE OR CHAPTER . . . . . . . . . .39

STARTING FROM A DESIRED

TIME COUNT

. . . . . . . . . . . . . . . . .39

STARTING FROM A DESIRED

TRACK . . . . . . . . . . . . . . . . . . . . . .39

REPEAT . . . . . . . . . . . . . . . . . . . . .40

A-B REPEAT . . . . . . . . . . . . . . . . .40

MARKER . . . . . . . . . . . . . . . . . . . .41

PROGRAM (Audio CD) . . . . . . . . .41

RANDOM (Audio CD) . . . . . . . . . .42

ZOOM PLAYBCK . . . . . . . . . . . . .42

PLAYING AN MP3 DISC . . . . . . . .42

CHANGING THE ONSCREEN

DISPLAY DURING MP3

DISC PLAY . . . . . . . . . . . . . . . . . .43

PLAYING AN MP3 DISC FROM

ADESIRED TRACK . . . . . . . . . . .43

PLAYING AN MP3 DISC IN A

PROGRAMMED WAY . . . . . . . . . .43

PLAYING AN MP3 DISC AT

RANDOM . . . . . . . . . . . . . . . . . . . .44

CSETTINGS . . . . . . . . . . . . . . . . . . .44

CHANGING THE AUDIO

LANGUAGE OR SOUND MODE .44

CHANGING THE SUBTITLE

LANGUAGE . . . . . . . . . . . . . . . . .45

CHANGING THE CAMERA

ANGLE (Multi-Angle Pictures) . . . .45

CHANGING THE ON-SCREEN

DISPLAY . . . . . . . . . . . . . . . . . . . .46

CCHANGING THE SETUP ITEMS .47

LANGUAGE SETTINGS . . . . . . . .47

DISPLAY SETTINGS . . . . . . . . . . .48

AUDIO SETTINGS . . . . . . . . . . . .49

PARENTAL LOCK . . . . . . . . . . . . .50

CLANGUAGE CODE LIST . . . . . . . .51

CTROUBLESHOOTING GUIDE . . .52

CMAINTENANCE . . . . . . . . . . . . . . .55

DISC HANDLING . . . . . . . . . . . . .55

CSPECIFICATIONS . . . . . . . . . . . . .56

CWARRANTY . . . . . . . . . . .Back Cover

TD503_01-36 02.2.26 10:09 AM Page 6

- 7 - EN

1C29

•

Hi-Fi system

–The Hi-Fi stereo recording system

offers you excellent sound quality with a dynamic

range of 80dB, frequency response from 20Hz to

20kHz, and 0.005% wow and flutter.

•

Rotary 4-head Record/Playback System–Four heads

ensure excellent picture quality and special effects playback.

•Index Search–

Fast-forwards to start of next recording.

•Slow Motion–View recorded program at slower

than normal speed.

•Infrared remote control

•Trilingual on screen tv/vcr setup display selec-

table in English or Spanish or French

•

Real time counter–This shows the elapsed recording

or playback time in hours, minutes, and seconds.

The

“–” indication will appear when the tape is rewound

further than the tape counter position “0:00:00”.

•181 channel capability PLL frequency synthesiz-

er tuner with direct station call–(A converter may

be necessary to view scrambled cable channels.)

•Auto Clock Setting–Allows you to set the clock

function from a PBS broadcast station.

•Closed caption system–You may view specially

labeled (cc) TV programs, movies, news, prere-

corded tapes, etc. with either a dialogue caption or

text display added to the program.

•Auto power on and off system–Automatically

turns on the TV/DVD/VHS when you insert the

cassette, turns off after auto-rewind, and ejects

when the beginning of the tape is reached.

•Auto rewind when the end of a tape is

reached–This function doesn’t occur when using

timer recording.

•Smooth mode change–TV/VCR mode, DVD

mode automatically changes without control.

•2 Step picture search operation–You can view a

video program at a high speed or super high speed

in either a forward or reverse direction in LP and

SLP mode. For SP mode only high speed.

•Three different playback tape speeds : SP/LP/SLP

•Two different recording tape speeds : SP/SLP

•Auto Head Cleaner–Automatically cleans video

heads as you insert or remove a cassette.

•Zero Return–The tape returns to counter of

0:00:00 by rewinding or fast forwarding.

•Still–“Freeze” the picture at any time, for close

viewing of a particular scene.

•Digital Auto Tracking (DTR)–Automatically

adjusts the tracking for each tape you play.

•Rental play mode–Improves playback picture

quality from worn tapes, such as rental tapes.

•Auto repeat–Allows you to repeat the playing of a

tape indefinitely without pressing the PLAY button.

•Time search–Let you set the TV/DVD/VHS to

advance the tape by entering the desired playback

time you want to skip.

•OTR (One Touch Recording)–Instant timed

recording from 30 to 480 minutes is possible at the

push of the REC/OTR button.

•1 Year, 8 events (including Daily and Weekly

Timer Recording)–The built-in timer allows you to

record up to 8 programs at different times on dif-

ferent channels up to 1 year in advance. The Daily

timer allows recordings to be made of daily broad-

casts, and the Weekly timer allows recording to be

made once a week up to the end of the tape.

•Auto return–After timer recording is finished, the

TV/DVD/VHS can return to the beginning of the

recording.

•Sleep timer–Allows you to have the

TV/DVD/VHS

automatically turn on or off at a desired time.

Timer Program Extension–Allow you to shift the

time schedule for automatic timer recording.

•V-CHIP–Enables parents to prevent their children

from watching inappropriate material on TV.

FEATURES

TV/VCR

TD503_01-36 02.2.26 10:09 AM Page 7

- 8 - EN

1C29

DVD

¡Dolby Digital surround

This player can handle Dolby Digital surround sound

having 5.1 channels when connected to a Dolby Digital

decoder.

¡Still/fast/slow/step playback

Various playback modes are available including still pic-

tures, fast forward/reverse, slow motion and step frames.

¡Random playback for audio CD and MP3

This player can shuffle the order of tracks to play them in

random order.

¡Program playback for audio CD and MP3

You can program the order of tracks to play them in any

desired order.

¡DVD menus in a desired language

You can display DVD menus in a desired language, if

available on a DVD.

¡Screen saver/Auto power-off functions

The screen saver program starts when there is no input

from the player for five minutes in the stop mode. When

the screen saver program is activated for 30 minutes, the

DVD power is automatically turned off, and "DVD"

appears on the screen.

¡Subtitles in a desired language

You can select a desired language for the display subtitles,

if that language is available on a disc.

¡Selecting a camera angle

You can select the desired camera angle, if a disc contains

sequences recorded from different angles.

¡Choices for audio language and sound mode

You can select the desired audio language and sound

mode, if different languages and modes are available on a

disc.

¡Parental lock

You can set the control level to limit playback of discs

which may not be suitable for children.

¡Automatic detection of discs

This player automatically detects if a loaded disc is DVD,

audio CD or MP3 on disc.

¡Playing an MP3 disc

You can enjoy MP3 files which are recorded on CD-

R/RW.

¡Direct Search

You can search the desired title, chapter, and track with

numeric button during playback or in stop mode.

¡On-screen display

Information about the current operation can be displayed

on a TV screen, allowing you to confirm the currently

active functions (such as program playback), on the TV

screen using the remote control.

•Sleep timer

Allows you to have the

TV/DVD/VHS automatically

turn off at a desired time.

¡DTS (Digital Theater System)

You can enjoy 5.1channel surround system developed by

the Digital Theater System co. which reproduces the orig-

inal sound as truthfully as possible.

¡Search

Chapter search: Search for the chapter designated by user

is possible.

Title search: Search for the title designated by user is

possible.

Track search: Search for the track designated by user is

possible.

Time search: Search for the time designated by user is

possible.

¡Repeat

Chapter: Repeated playback of the chapter of the

disc being played is possible.

Title: Repeated playback of the title of the disc

being played is possible.

Track: Repeated playback of the track of the disc

being played is possible.

Disc

(audio CD)

:Repeated playback of the entire disc being

(MP3) played is possible.

A-B: The part between A and B designated by

user is possible.

Album: Repeated playback of the folder of the

MP3 disc being played is possible.

¡Zoom

2-time and 4-time magnified screen can be displayed.

¡Marker

The part designated by user can be called back.

¡Resume Play

User can resume to playback from the part at which the

play was stopped.

¡SRS TruSurround

You can enjoy stereophonic virtual space on your existing

stereo system.

¡Dimmer

Brightness of the display can be varied.

¡Bit rate indication

¡DRC (Dynamic range control)

NOTE:

•We do not recommend the use of universal remote controls. Not all of the functions may be controlled with

a universal remote control.

If you decide to use a universal remote control with this unit, please be aware that the code number given

may not operate this unit. In this case, please call the manufacturer of the universal remote control.

This unit employs TruSurround system

of SRS Labs, Inc. as virtual

technology.

TruSurround and the symbol are trademarks of

SRS Labs, Inc.

TruSurround technology is incorporated under license

from SRS Labs, Inc.

TD503_01-36 02.2.26 10:09 AM Page 8

- 9 - EN

1C29

OPERATING CONTROLS AND FUNCTIONS

6.OPEN/CLOSE button

[DVD P.37]

Press to insert discs into or remove them from the

tray.

7.Disc loading tray

8.DVD indicator

Lights on during DVD mode.

9.SELECT button

Press to change to TV/VCR mode or DVD mode.

NOTE: For about 4 seconds just after the DVD

mode has switched to the TV mode, the button

does not work to switch back to the DVD mode.

10. TV/VCR indicator

Lights on during TV/VCR mode.

11. CHANNEL K/Lbuttons

Press to select memorized channel.

12. Recording indicator

Flashes during recording. Lights up in the Stand-

by mode for Timer Recording.

13. REC/OTR (RECORD) button

[TV/VCR P.28]

Press for manual recording. Activates One Touch

Recording. (OTR is only during TV/VCR mode.)

14. REW button (for TV/VCR)

[TV/VCR P.26]

Press to rewind the tape, or to view the picture

rapidly in reverse during playback mode. (Rewind

Search)

15. FWD button (for TV/VCR)

[TV/VCR P.26]

Press to rapidly advance the tape, or to view the

picture rapidly in forward during playback mode.

(Forward Search)

16. STOP/EJECT button

[TV/VCR P.28]

Press to stop the tape motion. Press in the Stop

mode to remove tape from the unit.

17. Remote sensor window

18. HEADPHONE jack

To connect headphone (not supplied) for personal

listening.

19. VIDEO input jack

Connect to the video output jack of a video

camera or VCR.

- REMOTE CONTROL - [Fig. 2]

1.POWER button

[TV/VCR P.15 / DVD P.37]

Press to turn the power on and off.

2.VOLUME X/Ybuttons

Press to control the volume level for the DVD and TV.

3.SKIP buttons (for DVD)

[P.37]

Skip chapters or tracks to a desired point.

4.PLAY button

[TV/VCR P.26 / DVD P.37]

Starts playback of the disc or tape contents.

5.STOP button

[P.37]

Stops operation of the disc.

- TV/DVD/VHS FRONT PANEL - [Fig.1]

AUDIO

VIDEO

HEADPHONE

VOLUME

POWER SKIP PLAY

SKIP REW PLAYREC/OTR STOP/EJECTF.FWDSTOP OPEN/CLOSE SELECT

DVD TV/VCR

CHANNEL

DVD buttons TV/VCR buttons

12 4 5 6 1071514983 3 4

11 12 13 212019181716

PAUSE

PLAY

STOP

ENTER

RECORD

DISC

RETURNTITLESETUP

REPEATSEARCH MODE

CLEAR

MODE ANGLESUBTITLEAUDIO

DISPLAY

SPEED C.RESET

POWER PICTURE SELECTSLEEP

CH.

VOL.

MUTEZOOM

123

456

789

0+10

+100

(DVD) 3

(TV/VCR) 14

3 (DVD)

15 (TV/VCR)

TD503_01-36 02.2.26 10:10 AM Page 9

- 10 - EN

1C29

ANT.

AUDIO OUT

COAXIAL

4746 48 49

20. AUDIO L/R input jacks

Connect to the audio output jacks of a video

camera or VCR.

21. Cassette compartment

22. PICTURE button

Press to adjust the picture.

23. Number buttons

TV Mode:

[P.15]

Press two digits to directly access the desired

channel.

Remember to press a "0" before a single digit

channel.

+100 button–

Press to select cable channels which are equal or

greater than number 100.

DVD Mode:

Press to enter the desired number.

+10 button–

Press to enter the desired numbers which are

equal or greater than number 10.

24. PAUSE button

[TV/VCR P.26 / DVD P.38]

Pauses the current disc or tape operation.

25. SPEED button

[TV/VCR P.30]

Press to choose the desired recording speed:

SP/SLP.

26. C.RESET button

[TV/VCR P.28]

Press to reset counter to 0:00:00.

Press to cancel a setting of timer program. (See

page 33.)

27. DISPLAY button

TV/VCR Mode:

Display the counter or the current channel number

and current time on the TV screen.

DVD Mode:

[P.43]

Displays the current status on the TV screen for

checking purposes.

28. SETUP button

[TV/VCR P.15]

Press to enter or exit the TV menu or DVD setup

mode.

29. TITLE button

[DVD P.37]

Displays the title menu.

30. CLEAR button

Resets a setting.

31. MODE button

[DVD P.41]

Activates program playback or random playback mode.

32. SEARCH MODE button

[DVD P.39]

Press to locate a desired point.

33. AUDIO button

[DVD P.44]

Press to select a desired audio language or sound

mode.

34. SUBTITLE button

[DVD P.45]

Press to select a desired subtitle language.

35. REPEAT button

[DVD P.40]

Repeats playback of the current disc, title, chapter

or track.

36. ANGLE button (DVD mode)

[DVD P.45]

Press to change the camera angle to see the

sequence being played back from a different angle.

37. A-B REPEAT button

[DVD P.40]

Repeats playback of a selected section.

38. RETURN button

Returns to the previous operation.

39. ENTER button

Press to accept a setting.

40. Arrow buttons

TV/VCR Mode:

Press to select a setting mode from the menu on

the TV screen.

Press to select or adjust from a particular menu.

DVD Mode:

Use when making settings while watching the

display on a TV screen.

41. DISC MENU button

[DVD P.37]

Displays the menus in the DVD.

42. ZOOM Button

[DVD P.42]

Enlarges part of a DVD-reproduced image.

43. MUTE button

Mutes the sound. Press it again to resume sound.

44. SLEEP button

[TV/VCR P.34]

Sets the Sleep Timer. (See page 34.)

45. SELECT button

Press to switch TV/VCR and DVD mode. You can

see the mode (TV/VCR or DVD) on the front

panel indicator.

- TV/DVD/VHS REAR PANEL - [Fig.3]

TD503_01-36 02.2.26 10:10 AM Page 10

- 11 - EN

1C29

CABLE WITH CONVERTER/

DESCRAMBLER BOX OR SATELLITE

BOX

If your cable service supplies you with a converter

box or if you use a satellite system, you can use the

basic connection shown in the ilustration.

By using this connection you can also record scram-

bled channels. However, channel selection must be

made with the converter box or satellite box. This

means that channels cannot be changed using the

TV/DVD/VHS Remote Control. Unattended timer

recording is limited to one channel at a time.

PREPARATION FOR USE

CABLE WITHOUT CONVERTER/

DESCRAMBLER BOX

Use this connection if your cable system connects

directly to your TV/DVD/VHS without a converter

box.

By using this connection you can:

1) Use the TV/DVD/VHS remote to select channels.

2) Program one or more unscrambled channels for

Automatic Timer Recording.

NOTE: This unit will ONLYrecord and view the

same channel.

VHF/UHF SEPARATE ANTENNAS

In some areas it will be necessary to use an outdoor

antenna.

Antenna/Cable Connections

Continued on the Next Page.

ANT.

AUDIO OUT

COAXIAL

ANT.

OUT

VHF/UHF Antenna

(Not supplied)

VHF/UHF

Combiner

(Not supplied)

Flat twin-lead cable

UHF Antenna

(Not supplied)

VHF Antenna (Not supplied)

From Cable

System

75-ohm Coaxial

Cable (Not

supplied)

75-ohm

Coaxial

Cable

(Not sup-

plied)

Satellite Box or

Cable Box (Not supplied)

From Cable System or

Satellite Dish

46. ANT. in jack

Connect to an antenna, cable system, or satellite

system.

47. Power cord

Connect to a standard AC outlet (120V/60Hz).

NOTE: Remove the power cord from the hook to

avoid breaking a wire before you connect

to a standard AC outlet.

48. COAXIAL digital audio out jack

Connect to the digital input of an external

amplifier or decoder.

49. AUDIO L/R output jack

Connect to the analog audio input of an external

amplifier or decoder.

[Fig. 4]

ANTENNA/CABLE CONNECTION

TD503_01-36 02.2.26 10:10 AM Page 11

- 12 - EN

1C29

TO RECORD A SCRAMBLED/UNSCRAM-

BLED CHANNEL

1. Set the TV/DVD/VHS channel selector to the out-

put channel of the Cable Converter Box or Satellite

Box. (Ex. CH3)

2.Select the channel to record from your Cable

Converter Box or Satellite Box.

INSTALLING THE BATTERIES

1)Open the battery compartment cover by pressing

the cover on the remote unit in the direction of the

arrow.

2)Insert 2 “AA” penlight batteries into the battery

compartment in the direction indicated by the

polarity (+/-) markings.

3)Replace the cover.

EXTERNAL INPUT MODE

When using an external input signal (another VCR or

video camera), connect the player’s audio/video out-

put cables to the AUDIO L/R IN/

VIDEO IN jacks of your

TV/DVD/VHS. Then press the

CHANNEL Kor Lbutton until

“AUX” appears on the screen.

AUX

Note to CATV system installer:

This reminder is provided to call the CATV sys-

tem installer’s attention to Article 820-40 of the

NEC that provides guidelines for proper ground-

ing and, in particular, specifies that the cable

ground shall be connected to the grounding sys-

tem of the building as close to the point of cable

entry as practical.

CONNECTING TO EXTERNAL

INPUT JACKS

When you watch a program recorded on an another

source (VCR or video camera), use the audio/video

input jacks on the front of the TV/DVD/VHS.

Connect the audio/video output jacks of another

source to the AUDIO L/R and VIDEO jacks of this

TV/DVD/VHS.

Then press the CHANNEL K/Lbuttons until "AUX"

appears on the screen.

NOTE:

•When you connect a monaural VCR (another

source) to this TV/DVD/VHS, connect the Audio

output jack of the monaural VCR (another source)

to the AUDIO L jack of this TV/DVD/VHS. The

audio will output in both L and R channel equally.

L-AUDIO-R

VIDEO

HEADPHONE

[Another source]

To the audio

output jacks

Audio/Video

cable

(not supplied)

etc.

To the video

output jack

[Front of the

TV/DVD/VHS]

[Fig. 5]

TD503_01-36 02.2.26 10:10 AM Page 12

- 13 - EN

1C29

CONNECTING TO A STEREO SYSTEM (for DVD)

ANT.

AUDIO OUT

COAXIAL

To Right (red) and Left (white)

AUDIO OUT jacks

(only DVD AUDIO OUT)

Stereo system

To ANALOG AUDIO INPUT jacks

NOTES:

•Be sure to turn off the power to all components in the system before connecting another component.

•Refer to the Owner's Manuals for your, stereo system and any other components to be connected to the

TV/DVD/VHS.

CONNECTING TO AN AMPLIFIER EQUIPPED WITH DIGITAL

INPUT JACKS SUCH AS MD DECK OR DAT DECK (for DVD)

Use an audio coaxial digital cables (not included) for the audio connections.

Connecting to an amplifier equipped with digital input jacks such as MD Deck or Dat Deck.

NOTES:

•The audio source on a disc in a 5.1 channel Dolby Digital surround format cannot be recorded as digital

sound by an MD or DAT deck.

•Be sure to turn off the power to all components in the system before connecting another component.

•Refer to the Owner's Manuals for the components to be connected to the TV/DVD/VHS.

•Set Dolby Digital and DTS to OFF for audio output in the setup mode. Playing a TV/DVD/VHS using

incorrect settings may generate noise distortion, and may also damage the speakers.

•When Dolby Digital is set to OFF and VIRTUAL 3D to ON for audio output in the setup mode and you

select the audio source in a 5.1 channel Dolby Digital surround format, the audio will be muted.

ANT.

AUDIO OUT

COAXIAL

Amplifier equipped with digital

input jacks, MD deck,

DAT deck, etc.

To COAXIAL DIGITAL

AUDIO INPUT jack

To DIGITAL AUDIO OUT

(PCM/BITSTREAM)

COAXIAL jack

(only DVD AUDIO OUT)

[Fig. 6]

[Fig. 7]

TD503_01-36 02.2.26 10:10 AM Page 13

- 14 - EN

1C29

CONNECTING TO A DOLBY DIGITAL DECODER,

DTS DECODER, OR MPEG DECODER (for DVD)

If using this TV/DVD/VHS to play back a TV/DVD/VHS in a 5.1 channel Dolby Digital surround, DTS sur-

round, or MPEG surround format, the TV/DVD/VHS outputs a Dolby Digital, DTS, or MPEG data stream

from its COAXIAL DIGITAL AUDIO OUT jack. By hooking the player up to a Dolby Digital or DTS

decoder, you can enjoy a more convincing, realistic ambience with powerful and high-quality surround sound

of a professional standard such as can be heard in movie theaters.

Use an audio coaxial digital cables (not included) for the audio connections.

NOTES:

•Be sure to turn off the power to all components in the system before connecting another component.

•Refer to the Owner’s Manuals for the components to be connected to the TV/DVD/VHS.

•If output Dolby Digital audio, connect to a Dolby Digital decoder, and set Dolby Digital to on for audio

output in the setup mode.

•If output DTS audio, connect to a DTS decoder, and set DTS to ON for audio output in the setup mode.

•If played a disc indicated MPEG audio, connect to a MPEG decoder, and set MPEG to ON for audio output

in the setup mode.

•Unless connected to a Dolby Digital decoder, a DTS decoder, or a MPEG decoder, set Dolby Digital, DTS,

or MPEG to off for audio output in the setup mode. Playing a TV/DVD/VHS using incorrect settings may

generate noise distortion, and may also damage the speakers.

•When Dolby Digital is set to OFF and VIRTUAL 3D to ON for audio output in the setup mode and you

select the audio source in a 5.1 channel Dolby Digital surround format, the audio will be muted.

ANT.

AUDIO OUT

COAXIAL

Front speaker

(left)

Center

speaker Front speaker

(right)

Surround

speaker

(left)

Surround

speaker

(right)

Subwoofer

To DIGITAL AUDIO OUT

(PCM/BITSTREAM)

COAXIAL jack

To COAXIAL DIGITAL

AUDIO INPUT jack

Dolby Digital

or DTS decoder

Center

speaker for

MPEG (left)

Center

speaker for

MPEG (right)

Manufactured under license from Dolby

Laboratories. “Dolby” and the double-D sym-

bol are trademarks of Dolby Laboratories.

“DTS” and “DTS Digital Out” are trademarks of

Digital Theater Systems, Inc.

[Fig. 8]

TD503_01-36 02.2.26 10:10 AM Page 14

- 15 - EN

1C29

SET UP FOR USE

You can program the tuner to scan all the channels you receive in your area.

NOTE: Channel memory programming is NOT needed when connected to a cable box or satellite box. Just

select the TV/DVD/VHS channel selector to the output channel of the cable box or satellite box (Ex CH3).

Then select the channel to be viewed on the Cable Box or Satellite Box.

CHANNEL SET UP FOR THE

FIRST TIME

1Plug in the TV/DVD/VHS power cord

Plug the TV/DVD/VHS power cord

into a standard AC outlet.

NOTE:

•If some digits appear in the corner of

the screen, press the POWER button

without unplugging the power cord.

2Turn on the TV/DVD/VHS

Press the POWER button to turn on the TV/DVD/VHS.

3Select “ENGLISH” or “ESPAÑOL” or

“FRANÇAIS”

Select “ENGLISH” or

“ESPAÑOL”=Spanish or

“FRANÇAIS” =French using the

Arrow Bor sbutton. “[ ]” indi-

cate the selected language.

4Begin auto preset

Press the Arrow Kor Lbutton to

point to “AUTO PRESET”.

Then press the Arrow Bbutton.

The tuner scans and memorizes all

active channels in your area.

NOTES:

•The TV/DVD/VHS distinguishes between standard

TV channels and cable channels.

•If you want to play or record a video tape

BEFORE presetting the tuner, you must press the

SETUP button on the remote control. To preset the

tuner again, see “CHANNEL SET UP AGAIN” on

page 16.

•The TV/DVD/VHS may memorize TV channels as

CATV channels if reception conditions is poor. If

this happens, try AUTO MEMO action again when

reception conditions are better.

5After scanning

The tuner stops on the lowest memorized channel.

If you want to recall the selected channels, you can

select the desired channel directly with the remote

control number buttons or CHANNEL Kor L.

DELETING (OR ADDING)

CHANNEL

The channels you no longer receive or seldom watch

can be deleted from the memory. (Of course, you can

add the deleted channel into the memory again.)

1Select “CHANNEL SET UP”

Press the SETUP button on the

remote control.

Press the Arrow Kor Lbutton to

point to “CHANNEL SET UP”.

Then, press the Arrow Bbutton.

2Select “ADD/DELETE CH”

Press the Arrow Kor Lbutton to

point to “ADD/DELETE CH”.

Press the Arrow Bbutton.

3Enter the desired channel number

Press the Arrow Kor Lbutton until

your desired channel number

appears. (You can also use the num-

ber buttons or the CHANNEL K/L

button to enter it) (Example: CH8)

4Delete (or add) it from (into) memory

Press the Arrow Bor sbutton. The channel number

changes to light red. The channel is deleted from

memory.

•To delete another channel, repeat steps [3] and [4].

•If you press the Arrow Bor sbutton again, the

channel is memorized again.

5Exit the channel setup mode

Press the SETUP button on the remote control to

returns to TV mode.

NOTE: To confirm that channel(s) has been deleted

or added, press the CHANNEL Kor Lbutton.

Added channel: Light blue.

Deleted channel: Light red.

– SET UP –

BLANGUAGE

[ENGLISH] ESP FRA

AUTO PRESET

– SET UP –

LANGUAGE

[ENGLISH] ESP FRA

BAUTO PRESET

- TV/VCR SETUP -

TIMER PROGRAMMING

SETTING CLOCK

BCHANNEL SET UP

USER’S SET UP

V-CHIP SET UP

LANGUAGE [ENGLISH]

CAPTION [OFF]

ZERO RETURN

TIME SEARCH

INDEX SEARCH

– CHANNEL SET UP –

BADD / DELETE CH (TV)

AUTO PRESET

ADD / DELETE

TV/VCR SECTION

TD503_01-36 02.2.26 10:10 AM Page 15

- 16 - EN

1C29

CHANNEL SET UP AGAIN

Make sure ...

•Press the POWER button to turn on the

TV/DVD/VHS.

1Select “CHANNEL SET UP”

Press the SETUP button on the

remote control.

Press the Arrow Kor Lbutton to

point to “CHANNEL SET UP”.

Then, press the Arrow Bbutton.

2Begin auto preset

Press the Arrow Kor Lbutton to

point to “AUTO PRESET”.

Then, press the Arrow Bbutton.

The tuner scans and memorizes all

the active channels in your area.

3After scanning

The tuner stops on the lowest memorized channel.

SELECTING THE LANGUAGE

Make sure ...

•Press the POWER button to turn on the

TV/DVD/VHS.

NOTE: This function effects only the language on

the screen menu and not the audio source.

1Select “LANGUAGE”

Press the SETUP button on the

remote control.

Press the Arrow Kor Lbutton to

point to “LANGUAGE”.

2Select “ENGLISH” or “ESPAÑOL” or

“FRANÇAIS”

Select “ENGLISH” or “ESPAÑOL”= Spanish or

“FRANÇAIS”= French using the Arrow Bor s

button.

3Exit the Language mode

Press the SETUP button on the remote control to

return to TV mode.

NOTE: If Spanish or French is selected accidentally,

press the SETUP button on the remote control, press

the Arrow Kbutton to point to “IDIOMA

[ESPAÑOL]” or “LANGAGE” [FRANÇAIS], then

press the Arrow Bbutton, then press the SETUP

button on the remote control.

DAYLIGHT-SAVING TIME

Select this feature and the TV/DVD/VHS’s clock

automatically will advance one hour in April, then

reverse one hour in October.

When Daylight-Saving Time is ON, the clock will

change automatically as follows:

•First Sunday of April : At 2 AM the clock imme-

diately changes to 3 AM. Any timer programming

you have set to occur between 2 AM and 3 AM

will not record.

•Last Sunday of October : At 2 AM the clock

immediately changes to 1 AM.

Make sure ...

•Press the POWER button to turn on the

TV/DVD/VHS.

1Select “SETTING CLOCK”

Press the SETUP button on the

remote control.

Press the Arrow Kor Lbutton to

point to “SETTING CLOCK”.

Then, press the Arrow Bbutton.

2Set “D.S.T.” (Daylight-Saving Time) to [ON]

Press the Arrow Kor Lbutton to

point to “D.S.T.”.

Then, press the Arrow Bor sbut-

ton until [ON] appears.

3Exit the Daylight-Saving Time mode

Press the SETUP button on the remote control to

return to TV mode.

TO CANCEL THE DAYLIGHT-SAVING

TIME

Repeat steps [1] to [2], select [OFF] using the Arrow

Bor sbutton.

- TV/VCR SETUP -

TIMER PROGRAMMING

SETTING CLOCK

BCHANNEL SET UP

USER’S SET UP

V-CHIP SET UP

LANGUAGE [ENGLISH]

CAPTION [OFF]

ZERO RETURN

TIME SEARCH

INDEX SEARCH

– CHANNEL SET UP –

ADD / DELETE CH (TV)

BAUTO PRESET

- TV/VCR SETUP -

TIMER PROGRAMMING

SETTING CLOCK

CHANNEL SET UP

USER’S SET UP

V-CHIP SET UP

BLANGUAGE [ENGLISH]

CAPTION [OFF]

ZERO RETURN

TIME SEARCH

INDEX SEARCH

- TV/VCR SETUP -

TIMER PROGRAMMING

BSETTING CLOCK

CHANNEL SET UP

USER’S SET UP

V-CHIP SET UP

LANGUAGE [ENGLISH]

CAPTION [OFF]

ZERO RETURN

TIME SEARCH

INDEX SEARCH

– SETTING CLOCK –

AUTO CLOCK [ON]

AUTO CLOCK CH [AUTO]

MANUAL CLOCK SET

BD.S.T. [ON]

TD503_01-36 02.2.26 10:10 AM Page 16

- 17 - EN

1C29

CLOCK SET UP

(AUTO / MANUAL)

Set the clock accurately for proper automatic timer

recording. If the Public Broadcasting Station (PBS) is

available in your area, follow “AUTO CLOCK SET-

TING”. If it is not, follow “MANUAL CLOCK SET-

TING”.

AUTO CLOCK SETTING

You can have the TV/DVD/VHS set the clock auto-

matically by using the Public Broadcasting Station

(PBS) channel in your area. Once you have set the

clock by using the following procedure, the

TV/DVD/VHS will automatically monitor the correct

time and date being broadcast by the PBS station in

your area, using a new service called Extended Data

Service (XDS).

Make sure ...

•TV/DVD/VHS power must be turned on.

•Confirm that the antenna connections are correct.

•The cable converter box must be turned on if your

TV/DVD/VHS is connected directly to it. (See

NOTES:)

•The channel is properly set in advance. (See page

16.)

NOTES:

•Auto clock setting only needs to be set once. But it

can be done again if the clock’s time has become

incorrect for some reason.

•If the TV/DVD/VHS is connected directly to a

cable converter box or satellite box, the local PBS

station must be selected on the cable box itself, and

the TV/DVD/VHS must be set to the output chan-

nel of the cable converter box or satellite box (usu-

ally channel 3 or 4), to be able to set up or correct

the clock automatically.

If you do not know what your local PBS station is,

then follow “Manual Clock Settings” on page 18.

The TV/DVD/VHS cannot control the channels of

the cable converter box or satellite box.

1Select “SETTING CLOCK”

Press the SETUP button on the

remote control.

Press the Arrow Kor Lbutton to

point to “SETTING CLOCK”.

Then, press the Arrow Bbutton.

2Set “AUTO CLOCK” to [ON]

Press the Arrow Bor sbutton

repeatedly until [ON] appears.

3Enter the channel number for the PBS station

Press the Arrow Kor Lbutton to

point to “AUTO CLOCK CH”.

Then press the Arrow Bor sbut-

ton until the channel number for

your local PBS station appears.

If you do not know the PBS channel number, leave it

set to [AUTO] which is located before [2]. The

TV/DVD/VHS will search automatically all available

channels for the local PBS station, and will select

that channel.

4Exit the Auto Clock Setting

Press the SETUP button on the remote control to

return to TV mode.

5Turn off the TV/DVD/VHS

Turn the TV/DVD/VHS off. Because the Auto Clock

functions automatically while the TV/DVD/VHS is

off.

If you choose [AUTO],

•the TV/DVD/VHS must search until the PBS chan-

nel is found. It must scan each channel for a couple

of seconds to determine if that channel is transmit-

ting the XDS signal.

•if the time, that is automatically set by this selected

PBS station is incorrect, it may not be your local

PBS station, but one from a different time zone. Or

there is a case that no channel is broadcasting the

XDS signal in your area, as shown by no time. In

these cases, you must manually enter the correct

local PBS station, or set the clock manually and

turn off the Auto Clock Setting feature.

- TV/VCR SETUP -

TIMER PROGRAMMING

BSETTING CLOCK

CHANNEL SET UP

USER’S SET UP

V-CHIP SET UP

LANGUAGE [ENGLISH]

CAPTION [OFF]

ZERO RETURN

TIME SEARCH

INDEX SEARCH

– SETTING CLOCK –

BAUTO CLOCK [ON]

AUTO CLOCK CH [AUTO]

MANUAL CLOCK SET

D.S.T. [OFF]

– SETTING CLOCK –

AUTO CLOCK [ON]

AUTO CLOCK CH [AUTO]

MANUAL CLOCK SET

BD.S.T. [OFF]

TD503_01-36 02.2.26 10:10 AM Page 17

- 18 - EN

1C29

MANUAL CLOCK SETTING

Make sure ...

•TV/DVD/VHS power must be turned on.

In the example below, the clock is to be set to:

DATE May 7th, 2002

SETTING TIME 5:40PM

1Select “SETTING CLOCK”

Press the SETUP button on the

remote control.

Press the Arrow Kor Lbutton to

point to “SETTING CLOCK”.

Then, press the Arrow Bbutton.

2Select “MANUAL CLOCK

SET”

Press the Arrow Kor Lbutton to

point to “MANUAL CLOCK SET”.

Then, press the Arrow Bbutton.

3Select the month

Press the Arrow Kor Lbutton until

your desired month appears.

(Example: May →05)

Then, press the Arrow Bbutton.

4Select the day

Press the Arrow Kor Lbutton until

your desired day appears.

(Example: 7th →07)

Then, press the Arrow Bbutton.

5Select the year

Press the Arrow Kor Lbutton until

your desired year appears.

(Example: 2002)

Then, press the Arrow Bbutton.

6Select the hour

Press the Arrow Kor Lbutton until

your desired hour appears.

(Example: 5, PM)

Then, press the Arrow Bbutton.

7Select the minute

Press the Arrow Kor Lbutton until

the desired minute appears.

(Example: 40)

8Start the clock

Press the SETUP button on the

remote control.

Although seconds are not displayed,

they begin counting from 00 when

you press the SETUP button on the

remote control. Use this feature to synchronize the

clock with the correct time.

NOTE:

When unplugging the AC cord or if there is a power

failure for more than 30 seconds, you may have to

reset the clock.

TO CHANGE CLOCK SETTING

If you want to change the clock,

1)Follow steps [1] and [2].

2)Select where you want to change using the Arrow

Bor sbutton.

3)Enter correct numbers using the Arrow Kor L

button.

4)Press the SETUP button on the remote control to

start the clock.

PLEASE NOTE:

If there is no local PBS station in your area or on

your cable system, select “AUTO CLOCK” and

press the Arrow Bor sbutton to turn [OFF] this

function. Then you can manually adjust the clock.

- TV/VCR SETUP -

TIMER PROGRAMMING

BSETTING CLOCK

CHANNEL SET UP

USER’S SET UP

V-CHIP SET UP

LANGUAGE [ENGLISH]

CAPTION [OFF]

ZERO RETURN

TIME SEARCH

INDEX SEARCH

– SETTING CLOCK –

AUTO CLOCK [ON]

AUTO CLOCK CH [AUTO]

BMANUAL CLOCK SET

D.S.T. [OFF]

– MANUAL CLOCK SET –

MONTH DAY YEAR

0 5 / – – – – – – – – –

HOUR MINUTE

– – : – – – –

– MANUAL CLOCK SET –

MONTH DAY YEAR

0 5 / 0 7 – – – – – – –

HOUR MINUTE

– – : – – – –

– MANUAL CLOCK SET –

MONTH DAY YEAR

0 5 / 0 7 TUE 2 0 0 2

HOUR MINUTE

– – : – – – –

– MANUAL CLOCK SET –

MONTH DAY YEAR

0 5 / 0 7 TUE 2 0 0 2

HOUR MINUTE

0 5 : – – PM

– MANUAL CLOCK SET –

MONTH DAY YEAR

0 5 / 0 7 TUE 2 0 0 2

HOUR MINUTE

0 5 : 4 0 PM

5:40 PM

TD503_01-36 02.2.26 10:10 AM Page 18

- 19 - EN

1C29

TV OPERATION

DEGAUSSING

Magnetism from nearby appliances might affect the

color of the TV picture.

If this happens, move this unit away from the appli-

ance. If the color is still not correct, disconnect power

cord from AC outlet then reconnect it after 30 minutes.

WATCHING A TV PROGRAM

1Turn on the TV/DVD/VHS

Press the POWER button to turn on the

TV/DVD/VHS.

2Select the channel number

Press the CHANNEL Kor Lbutton to select your

desired channel number or press the number buttons

on the remote control.

Remember: If the TV/DVD/VHS is connected to a

cable box or satellite box, the TV/DVD/VHS must be

on CH3 or CH4, then the channel to be viewed must

be selected on the cable box or satellite box.

3Adjust sound

Press the VOLUME XXor YYbutton

to adjust the volume.

NOTES:

•If you press the CHANNEL oor p in the DVD

mode, you can change the TV channels.

Even if you turn off the TV/DVD/VHS in the DVD

mode, when you turn it on again, it will go into the

TV/VCR mode.

Arrow sArrow B

BRIGHT to decrease to increase

brightness brightness

CONTRAST to decrease to increase

contrast contrast

COLOR to pale to brilliant

TINT to purple to green

SHARPNESS to soft to clear

PICTURE CONTROL

The TV/DVD/VHS’s picture controls – BRIGHT,

CONTRAST, COLOR, TINT and SHARPNESS –

are preset to factory specifications. Although they are

usually the best, you may need to make some further

adjustments for a natural looking image.

NOTES:

•Procedures must be followed within 5 seconds or

the Picture Control mode will be cancelled.

•When setting the Picture Control, the Game mode

will be cancelled.

Make sure ...

•TV/DVD/VHS power must be turned on.

1Select “PICTURE CONTROL”

Press the PICTURE button on the remote control.

2Select item you want to adjust

Press the Arrow Kor Lbutton until desired control

is displayed.

BRIGHT

CONTRAST

COLOR

TINT

SHARPNESS

3Adjust the picture control

Press the Arrow Bor sbutton to adjust to your

desired level.

•If there is a power failure of any kind, the unit will

retain its memory for this feature.

VOLUME 20

C C C C C C C C C C C C

BRIGHT

– PPPPPPPPPPPPPPCCPPPPPPPPPPPPPP +

TD503_01-36 02.2.26 10:10 AM Page 19

- 20 - EN

1C29

CLOSED CAPTION SYSTEM

You can view specially labeled (cc) TV programs,

movies, news, pre-recorded tapes with either a dia-

logue caption or text display.

CAPTION mode: By choosing the caption mode, you

can watch dramas, movies and news while captioning

the dialogues and the contents of news.

TEXT mode: By choosing the text mode, you can

watch half screen text information if you want.

1-2: You may get these captions or text information

by selecting either “1” or “2”. Caption “2” is used,

usually for a second language if available.

NOTE:

Not all programs are broadcast with closed captions.

Your television is designed to provide error free

closed captions from high quality antenna, cable and

VCR signals. Conversely, poor quality signals are

likely to result in caption errors or no captions at all.

Common signal conditions which may cause captions

errors are listed below:

•Automobile ignition noise

•Electric motor brush noise

•Weak snowy reception on TV screen

•Multiplex signal reception displaying picture

ghosts or airplane flutter.

•Playback of poorly recorded or worn VCR tapes.

NOTE:

If the TV/DVD/VHS displays a

black box on the TV screen, this

means that the TV/DVD/VHS is set

to the TEXT mode. To clear screen,

select [CAPTION1], [CAPTION2]

or [OFF].

Make sure ...

•TV/DVD/VHS power must be turned on.

1Select “CAPTION”

Press the SETUP button on the

remote control.

Press the Arrow Kor Lbutton to

point to “CAPTION”.

2Select your desired caption menu

Press the Arrow Bor sbutton

until your desired caption menu

appears.

([CAPTION1], [CAPTION2],

[TEXT1] or [TEXT2])

3Exit the caption setting mode

Press the SETUP button on the remote control to

return to TV mode.

TO CANCEL THE CLOSED CAPTION

SYSTEM

Repeat steps [1] and [2], select [OFF] using the

Arrow Bor sbutton. Press the SETUP button on

the remote control to return to TV mode.

WHEN THE CLOSED CAPTION MODE

IS ON

The On-Screen Display will disappear after 5 sec-

onds.

•This is also true when the MUTE button is pressed,

and when the PAUSE button is pressed while

recording.

•If there is a power failure of any kind, the unit will

retain its memory for this feature.

- TV/VCR SETUP -

TIMER PROGRAMMING

SETTING CLOCK

CHANNEL SET UP

USER’S SET UP

V-CHIP SET UP

LANGUAGE [ENGLISH]

BCAPTION [OFF]

ZERO RETURN

TIME SEARCH

INDEX SEARCH

- TV/VCR SETUP -

TIMER PROGRAMMING

SETTING CLOCK

CHANNEL SET UP

USER’S SET UP

V-CHIP SET UP

LANGUAGE [ENGLISH]

BCAPTION [CAPTION1]

ZERO RETURN

TIME SEARCH

INDEX SEARCH

TD503_01-36 02.2.26 10:10 AM Page 20

- 21 - EN

1C29

V-CHIP SET UP

V-CHIP enables parents to prevent their children

from watching inappropriate material on TV.

V-CHIP reads the ratings for programming (except

for news and sports programs, unedited movies on

premium cable channels, and Emergency Broadcast

System signals), then denies access to programming

if the program’s rating meets the limitations you

select. In this case, “PROTECTED PROGRAM by

...” message appears on the TV screen. You can

watch the protected program by entering access code

(default 0000).

To block ratings, follow the steps below.

•Programming may be rated by the Motion Picture

Association of America (MPAA) or according to

the Television Parental Guidelines. In order to

block any inappropriate programming, set your

limits in both places (MPAA RATING and TV

RATING).

TV RATING SET UP

Make sure ...

•TV/DVD/VHS power must be turned on.

1Select “V-CHIP SET UP”

Press the SETUP button on the

remote control.

Press the Arrow Kor Lbutton to

point to “V-CHIP SET UP”.

Then, press the Arrow Bbutton.

2Input Access code

Use the number buttons to enter 4-

digit access code. The default code

is 0000.

3Select “TV RATING”

Press the Arrow Kor Lbutton to

point to “TV RATING”.

Then, press the Arrow Bbutton.

4Select your desired item

Press the Arrow Kor Lbutton to

point to your desired item.

Then, press the Arrow Bbutton to

select [BLOCK] or [VIEW].

Selection Rating Category Explanations

TV-Y Appropriate for all children

TV-Y7 Appropriate for children seven and older

TV-G General Audience

TV-PG Parental Guidance suggested.

TV-14 Unsuitable for children under 14

TV-MA Mature audience only

•When you select the rating category and turn it

[BLOCK], the higher rating will turn [BLOCK]

automatically. Also, the lower rating will turn

[VIEW] automatically.

•When you turn “TV-Y” to [VIEW], the all ratings

will turn to [VIEW] automatically.

- TV/VCR SETUP -

TIMER PROGRAMMING

SETTING CLOCK

CHANNEL SET UP

USER’S SET UP

BV-CHIP SET UP

LANGUAGE [ENGLISH]

CAPTION [OFF]

ZERO RETURN

TIME SEARCH

INDEX SEARCH

ACCESS CODE

_ _ _ _

BTV–Y [VIEW]

TV–Y7 ( ) [VIEW]

TV–G [VIEW]

TV–PG ( ) [VIEW]

TV–14 ( ) [VIEW]

TV–MA ( ) [VIEW]

– V-CHIP SET UP –

BTV RATING

MPAA RATING

CHANGE CODE

When you select TV-Y7, TV-PG, TV-14, or TV-MA

and you press the Arrow Bbutton, the sub-ratings

will appear on the TV screen.

If you select the rating category (example: TV-PG)

and turn it [BLOCK] or [VIEW], the sub-ratings

(example: V for Violence) will turn [BLOCK] or

[VIEW] automatically.

You can set the sub-ratings to [BLOCK] or [VIEW]

individually when the rating category is set to

[BLOCK].

To set the sub-ratings individually, follow the steps

below.

•When you select [TV-Y7]:

Press the Arrow Lor Kbutton to

select “FV” (Fantasy Violence).

Then, press the Arrow Bbutton

to select [BLOCK] or [VIEW].

•When you select [TV-PG], [TV-14] or [TV-MA]:

Press the Arrow Lor Kbutton to

select “D”(Suggestive Dialog),

“L”(Coarse Language),

“S”(Sexual Situation), or

“V”(Violence). Then, press the

Arrow Bbutton to select

[BLOCK] or [VIEW].

Note: When you select [TV-MA], “D” does not

appear on the TV screen.

•The sub-ratings which set to

[BLOCK] appears next to the rat-

ing category in the TV RATING

menu.

5Exit the V-Chip setting mode

Press the SETUP button on the remote control to

return to original mode.

TV–Y7 [BLOCK]

BFV [BLOCK]

TV–PG [BLOCK]

BD[BLOCK]

L[BLOCK]

S[BLOCK]

V[BLOCK]

BTV–Y [VIEW]

TV–Y7 ( ) [VIEW]

TV–G [VIEW]

TV–PG (DLSV) [BLOCK]

TV–14 (DLSV) [BLOCK]

TV–MA ( LSV ) [BLOCK]

TD503_01-36 02.2.26 10:10 AM Page 21

- 22 - EN

1C29

4Select your desired item

Press the Arrow Kor Lbutton to

point to your desired item.

Then, press the Arrow Bbutton to

select [BLOCK] or [VIEW].

•When you select the rating cate-

gory and turn it [BLOCK], the higher rating will

turn [BLOCK] automatically. Also, the lower rat-

ing will turn [VIEW] automatically.

•When you turn “G” to [VIEW], the all ratings will

turn to [VIEW] automatically.

5Exit the V-Chip setting mode

Press the SETUP button on the remote control to

return to original mode.

MPAA RATING SET UP

Make sure ...

•TV/DVD/VHS power must be turned on.

1Select “V-CHIP SET UP”

Press the SETUP button on the

remote control.

Press the Arrow Kor Lbutton to

point to “V-CHIP SET UP”.

Then, press the Arrow Bbutton.

Use the number buttons to enter 4-

digit access code. The default code

is 0000.

3Select “MPAA RATING”

Press the Arrow Kor Lbutton to

point to “MPAA RATING”.

Then, press the Arrow Bbutton.

Selection Rating Category Explanations

GGeneral Audience

PG Parental Guidance suggested.

PG-13 Unsuitable for children under 13

RRestricted; under 17 requires accompa-

nying parent or adult guardian

NC-17 No one under 17 admitted

XMature audience only

- TV/VCR SETUP -

TIMER PROGRAMMING

SETTING CLOCK

CHANNEL SET UP

USER’S SET UP

BV-CHIP SET UP

LANGUAGE [ENGLISH]

CAPTION [OFF]

ZERO RETURN

TIME SEARCH

INDEX SEARCH

– V-CHIP SET UP –

TV RATING

BMPAA RATING

CHANGE CODE

G[VIEW]

PG [VIEW]

PG–13 [VIEW]

BR[BLOCK]

NC–17 [BLOCK]

X[BLOCK]

ACCESS CODE

_ _ _ _

CHANGE ACCESS CODE

To change access code, follow the steps.

Press the SETUP button so that the TV/VCR SETUP

display appears on the TV screen.

Press the Arrow Kor Lbutton to

point to "V-CHIP SET UP". Then,

press the Arrow Bbutton.

Use the number buttons to enter 4-

digit access code. The default code

is 0000.

Press the Arrow Kor Lbutton to

point to "CHANGE CODE". Then,

press the Arrow Bbutton.

Use the number buttons to enter

your desired access code in the

NEW CODE space. Then enter the

same code in the CONFIRM

CODE space. V-CHIP SET UP

screen appear on the screen.

•If you enter wrong code, repeat

step 5, making sure you enter the

same new code exactly in the

confirm code space.

Press the SETUP button to exit the TV/VCR SETUP.

Note:

•If you unplug the power code or power failure

occures, the changed access code will be lost and

will return to default (0000). Change your access

code again as necessary.

- TV/VCR SETUP -

TIMER PROGRAMMING

SETTING CLOCK

CHANNEL SET UP

USER’S SET UP

BV-CHIP SET UP

LANGUAGE [ENGLISH]

CAPTION [OFF]

ZERO RETURN

TIME SEARCH

INDEX SEARCH

ACCESS CODE

_ _ _ _

– V-CHIP SET UP –

TV RATING

MPAA RATING

BCHANGE CODE

NEW CODE

_ _ _ _

CONFIRM CODE

_ _ _ _

NEW CODE

X X X X

CONFIRM CODE

_ _ _ _

TD503_01-36 02.2.26 10:10 AM Page 22

- 23 - EN

1C29

MTS(Multi-Channel Television sound)SYSTEM

You can record or listen to a program in MTS stereo.

CHECKING THE SELECTED MTS MODE

When you play a VHS tape, or receive a broadcast

on the TV/DVD/VHS tuner channel you are watching,

the status shown below will appear when you press

the DISPLAY button on the remote control.

PLAY B12:00AM

HIFI CH 123

STEREO/SAP

SP COUNT 0:00:00

1] When a program is broadcast in stereo, STEREO

appears on the TV screen.

2] When a program is broadcast in second audio,

SAP appears on the TV screen.

3] When a program broadcast both in stereo and sec-

ond audio, STEREO and SAP appear on the TV

screen.

NOTE: Although a program may be broadcast in

both stereo and second audio, you cannot

record in both stereo and second audio at

the same time.

4] While the TV/DVD/VHS is set in HIFI stereo

mode and playback mode. HIFI appears on the

TV screen. While the TV/DVD/VHS is set in

monaural(MONO) mode, HIFI disappears from

the TV screen.

NOTE: If you play non-HIFI tapes while the

TV/DVD/VHS is set in HIFI, HIFI will dis-

appear from the TV screen and the

TV/DVD/VHS will play automatically in

monaural.

MTS RECORDING/MONITOR MODE

Type of broadcast Display on STEREO/SAP Hi-Fi audio track(2-channel) Normal audio

the TV screen SELECTION L-channel R-channel track

Regular -None- -Invalid- Mono Mono Mono

(monaural audio)

Stereo broadcast STEREO -Invalid- L R L+R

Bilingual broadcast SAP STEREO* Main audio Main audio Main audio

program program program

SAP* Sub audio Sub audio Sub audio

program program program

Stereo & Bilingual STEREO STEREO* L R L+R

broadcast SAP SAP* sub audio sub audio sub audio

program program program

*You must select the recording mode in TV AUDIO [STEREO] or [SAP] when you record a broadcast.

SAP Second Audio Program, which means your

program, can also be received in a second

language or sometimes a radio station.

HIFI High Fidelity which produces better sound

than standard stereo TV/DVD/VHSs.

TD503_01-36 02.2.26 10:10 AM Page 23

- 24 - EN

1C29

SELECTING THE MTS SYSTEM

Make sure ...

•TV/DVD/VHS power must be turned on.

TO SELECT HIFI MODE

1Select “USER’S SET UP”

Press the SETUP button on the

remote control.

Press the Arrow Kor Lbutton to

point to “USER’S SET UP”. Then,

press the Arrow Bbutton.

2Select“VCR AUDIO”

Press the Arrow Kor Lbutton to

point to“VCR AUDIO”. Then, press

the Arrow Bbutton.

3 Select [HIFI]

Press the Arrow Bor sbutton

until [HIFI] appears.

4To return to TV mode

Press the SETUP button on the remote control to

return to TV mode.

NOTES:

•Normally, “HIFI” should be selected for playback-

with HIFI sound.

• When you play non-HIFI tapes, the TV/DVD/VHS

will play automatically in the monaural mode.

•The TV/DVD/VHS records automatically MTS

broadcasts in HIFI stereo sound unless you select

SAP mode recording before you begin recording.

TO SELECT STEREO, SAP, OR MONO

1Select “USER’S SET UP”

Press the “SETUP” button on the

remote control.

Press the Arrow Kor Lbutton to

point to “USER’S SET UP”.Then,

press the Arrow B

button.

2Select “TV AUDIO”

Press the Arrow Kor Lbutton to

point to“TV AUDIO”. Then, press

the Arrow Bbutton.

3Select [STEREO], [SAP], or [MONO]

Press the Arrow Bor sbutton until [STEREO],

[SAP], or [MONO] appears.

4To return to TV mode

Press the SETUP button on the remote control to

return to TV mode.

NOTES:

• You must select the recording mode,either TV

AUDIO [STEREO] or [SAP] when you record a

broadcast.

Refer to “MTS RECORDING/MONITOR MODE”.

• If you select second audio when second audio is not

available, the TV/DVD/VHS will record normal

audio.

- TV/VCR SETUP -

TIMER PROGRAMMING

SETTING CLOCK

CHANNEL SET UP

BUSER’S SET UP

V-CHIP SET UP

LANGUAGE [ENGLISH]

CAPTION [OFF]

ZERO RETURN

TIME SEARCH

INDEX SEARCH

- TV/VCR SETUP -

TIMER PROGRAMMING

SETTING CLOCK

CHANNEL SET UP

BUSER’S SET UP

V-CHIP SET UP

LANGUAGE [ENGLISH]

CAPTION [OFF]

ZERO RETURN

TIME SEARCH

INDEX SEARCH

– USER’S SET UP –

RENTAL [OFF]

REPEAT PLAY [OFF]

AUTO RETURN [OFF]

BVCR AUDIO [HIFI]

TV AUDIO [STEREO]

– USER’S SET UP –

RENTAL [OFF]

REPEAT PLAY [OFF]

AUTO RETURN [OFF]

VCR AUDIO [HIFI]

BTV AUDIO [STEREO]

– USER’S SET UP –

RENTAL [OFF]

REPEAT PLAY [OFF]

AUTO RETURN [OFF]

BVCR AUDIO [HIFI]

TV AUDIO [STEREO]

TO SELECT MONO MODE

You can change the selection to “MONO” if you

want to listen to HIFI tapes in normal audio play-

back.

1) Press the SETUP button on the remote control.

Press the Arrow Kor Lbutton to point to

“USER’S SET UP”.Then, press the Arrow B

button.

2) Press the Arrow Kor Lbutton to point to

“VCR AUDIO”. Then, press Arrow Bbutton.

3) Press the Arrow Bor sbutton until [MONO]

appears.

4) Press the SETUP button on the remote control to

return to TV mode.

TD503_01-36 02.2.26 10:10 AM Page 24

- 25 - EN

1C29

VIDEO CASSETTE

This TV/DVD/VHS will operate with any cassette that has the mark. For best results,

we recommend the use of high-quality tapes. Do not use poor quality or damaged tapes.

REMOVING A CASSETTE

1)In the Stop mode, press the EJECT button on the

remote control or press the STOP/EJECT button on

the TV/DVD/VHS. The cassette will eject.

2)Pull the cassette out of the cassette compartment.

3)Store the cassette in its case as shown.

NOTE:

• In DVD mode, Whether the cassette is with tab or

without tab you insert, it doesn’t start playing until

you press the PLAY button.

In TV/VCR mode, if th cassette without tab is

inserted, playback will automatically start.

PRECAUTIONS

•Avoid moisture. Moisture condensation may occur

on the tape if it is moved from a cold place to a

warm place or visa versa. Before using a tape with

these conditions, to avoid damage of the tape and

your TV/DVD/VHS, wait until the tape has

warmed to room temperature and the moisture has

evaporated.

•Avoid extreme heat, high humidity and magnetic

fields.

•Do not tamper with the cassette mechanism.

•Do not touch the tape with your fingers.

INSERTING A CASSETTE

Insert the cassette in the direction as shown. Push in

gently, but continuously, on the center-back of the

cassette until it is drawn into the TV/DVD/VHS. The

TV/DVD/VHS will automatically turn on.

TWO DIFFERENT TAPE SPEEDS

Before recording, select the tape speed from : SP

mode (Standard Play) or SLP mode (Super Long

Play).

The table below shows the maximum recording/play-

back time using T60, T120 or T160 tapes in each

mode.

Note: You can play back a tape recorded in LP mode

(Long Play).

Tape Speed Recording/Playback Time

Type of tape

T60 T120 T160

SP mode 1 hour 2 hours 2-2/3 hours

SLP mode 3 hours 6 hours 8 hours

ERASE PREVENTION

You can prevent accidental

erasing of recording by

breaking off the tab on the

back edge of the cassette.

If you decide to record on

the tape again, cover the

hole with plastic tape.

CORRECT

Window

WRONG

Tab

Transparent Tape

TD503_01-36 02.2.26 10:10 AM Page 25

- 26 - EN

1C29

PLAYBACK

NORMAL PLAYBACK

Make sure ...

•TV/DVD/VHS power must be turned on.

1Insert a prerecorded tape

If the erase-protection tab has been removed, the

TV/DVD/VHS will start playback automatically.

2To begin playback

Press the PLAY button.

3To stop playback

Press the STOP button when play-

back is completed.

NOTES:

•If you press the TV/VCR side PLAY button in the

DVD mode, you can start the VCR playback.

•If you press the SELECT button in the VCR

playback, it will stop and the mode will

change to the DVD mode. In addition, the

same function operates with the DVD side

PLAY button or OPEN/CLOSE button.

TRACKING ADJUSTMENT

•Tracking adjustment will be set automatically

(Digital Tracking function) when you start play-

back.

•However when playing pre-recorded tapes or tapes

recorded on units other than your own, noise lines

(black and white streaks) may appear on the play-

back picture. If this occurs, you can adjust the

tracking control manually by pressing the CHAN-

NEL Kor Lbutton until the streaks disappear. To

return to the DTR function, stop the tape once and

start playback again.

•You can reduce the noise lines by pressing the

CHANNEL Kor Lbutton in slow mode, too.

Tracking adjustment in Slow mode will not be set

automatically.

NOTE:

•In Still mode, press the SLOW button and press the

CHANNEL Kor Lbutton until streaks disappear.

To return to Still mode, press the PAUSE button

again.

PICTURE SEARCH

This feature is very useful in finding or skipping over

a particular scene on a tape. In this mode, the sound

will be muted.

1)You may view a video tape at a high speed in

either a forward or reverse direction by pressing

the F.FWD or REW button. (in the SP / LP / SLP

modes)

NOTE:

•If you press the F.FWD or REW button on the

front panel in the DVD mode, the VCR forward or

reverse will start. Please press the STOP / EJECT

button once to stop it, twice to eject it.

2)Press it again and the TV/DVD/VHS will now

search in super high speed. (in the LP / SLP modes

only)

NOTE:

• Tapes recorded in the SP or LP mode will dis-

play a noise bar on the TV screen and the picture

may revert to Black and White. This is normal.

3)Press the PLAY button to return to normal speed.

STILL PICTURE

You can view a still picture on the TV screen during

playback (the Still mode). Press the PAUSE button

during playback. Only tapes recorded in the SLP

mode will show the least amount of lines.Press the

PLAY button to return to playback.

NOTES:

•You can advance the picture one frame at a time by

pressing the PAUSE button during the Still mode.

•If it is left in the Pause mode for more than five

minutes, the TV/DVD/VHS will automatically

switch to the Stop mode.

VERTICAL HOLD CONTROL

In the Pause/Still mode only, when the picture begins

to vibrate vertically, stabilize the picture by pressing

the CHANNEL Kor Lbutton.

NOTE:

If there are video noise lines on the screen, see Tracking

Adjustment section.

SLOW MOTION

During pause, press the FWD button to reduce the

playback speed. The TV/DVD/VHS mutes the sound

during slow motion. Press the PLAY button to return

to normal playback.

NOTE: If it is left in the Slow mode for more than

five minutes, the TV/DVD/VHS will automatically

go into the Stop mode.

PLAY B

STOP

TD503_01-36 02.2.26 10:10 AM Page 26

- 27 - EN

1C29

SPECIAL PLAYBACK

This function enables you to improve the picture

quality when playing back worn cassettes such as

rented tapes.

1Select “USER’S SET UP”

Press the SETUP button on the

remote control.

Press the Arrow Kor Lbutton to

point to “USER’S SET UP”.

Then, press the Arrow Bbutton.

2Set “RENTAL” to [ON]

Press the Arrow Kor Lbutton to

point to “RENTAL”.

Press the Arrow Bor sbutton

until [ON] appears.

3Exit the Rental setting

Press the SETUP button on the remote control to

return to the TV mode.

4Start playback

Press the PLAY button to start playback. “RENTAL

PLAY B” appears.

•Once you select the Rental mode, it stays in effect

even after you turn off the TV/DVD/VHS.

TO CANCEL THE RENTAL MODE

Repeat steps [1] and [2], select [OFF] using the

Arrow Bor sbutton on the remote control. Press

the SETUP button on the remote control to return to

TV mode.

If there is a power failure of any kind, the unit

will retain its memory for this feature.

Make sure ...

•TV/DVD/VHS power must be turned on.

•Insert a prerecorded tape.

•Before playback, follow steps below.

RENTAL PLAYBACK

The TV/DVD/VHS has the auto repeat function that

allows you to repeat a tape indefinitely without

touching the PLAY button.

ALL REPEAT: Repeat playback from the beginning

to the end of the tape.

BLANK REPEAT: Repeat playback from the begin-

ning to a blank part, which is blank for more than

10 seconds.

1Select “USER’S SET UP”

Press the SETUP button on the

remote control.

Press the Arrow Kor Lbutton to

point to “USER’S SET UP”.

Then, press the Arrow Bbutton.

2Select “ALL” or “BLANK”

Press the Arrow Kor Lbutton to

point to “REPEAT PLAY”.

Press the Arrow Bor sbutton

repeatedly until your desired selec-

tion [ALL] or [BLANK] appears.

3Exit the Repeat Play setting

Press the SETUP button on the remote control to

return to the TV mode.

4Start playback

Press the PLAY button to start the Repeat Play.

”REPEAT PLAY B” appears.

•Once you select the Repeat Play mode, it stays in

effect even after you turn off the TV/DVD/VHS.

•If the Rental mode is set [ON], the “RENTAL

PLAY B” display has priority.

TO CANCEL THE REPEAT PLAY MODE

Repeat steps [1] and [2], select [OFF] using the

Arrow Bor sbutton on the remote control. Press

the SETUP button on the remote control to return to

TV mode.

If there is a power failure of any kind, the unit

will retain its memory for this feature.

AUTO REPEAT PLAYBACK

- TV/VCR SETUP -

TIMER PROGRAMMING

SETTING CLOCK

CHANNEL SET UP

BUSER’S SET UP

V-CHIP SET UP

LANGUAGE [ENGLISH]

CAPTION [OFF]

ZERO RETURN

TIME SEARCH

INDEX SEARCH

– USER’S SET UP –

BRENTAL [ON]

REPEAT PLAY [OFF]

AUTO RETURN [OFF]

VCR AUDIO [HIFI]

TV AUDIO [STEREO]

- TV/VCR SETUP -

TIMER PROGRAMMING

SETTING CLOCK

CHANNEL SET UP

BUSER’S SET UP

V-CHIP SET UP

LANGUAGE [ENGLISH]

CAPTION [OFF]

ZERO RETURN

TIME SEARCH

INDEX SEARCH

– USER’S SET UP –

RENTAL [OFF]

BREPEAT PLAY [ALL]

AUTO RETURN [OFF]

VCR AUDIO [HIFI]

TV AUDIO [STEREO]

TD503_01-36 02.2.26 10:10 AM Page 27

- 28 - EN

1C29

Make sure ...

•TV/DVD/VHS power must be turned on.

•Insert a tape.

This function allows you to search easily a beginning

point that you want to review by rewinding or fast

forwarding.

NOTE:

Zero Return WILL NOT work on a blank tape or a

blank portion of a tape.

1Stop a tape at your desired point

Rewind or fast forward the tape to the beginning

point at which you want to review.

2Reset the counter to 0:00:00

Press the COUNTER RESET button repeatedly.

3Begin recording or playback

Press the RECORD or PLAY button.

Press the STOP button when recording or playback is

completed.

4To activate “ZERO RETURN” mode

Press the SETUP button on the

remote control.

Press the Arrow Kor Lbutton to

point to “ZERO RETURN”.

Then, press the Arrow Bbutton.

The counter will appear on the TV screen.

The tape will automatically stop when the counter

returns to 0:00:00.

ZERO RETURN

The Time Search function makes it possible to quick-

ly advance the tape to your desired position simply

by entering the exact amount of playback time you

want to skip.

NOTES:

•Time Search can be set up to a maximum of 9

hours 50 minutes (9:50) by 10 minutes at a time.

TIME SEARCH

•This function will not operate in recording mode.

•This function is not operative when a cassette tape

is not inserted in the TV/DVD/VHS.

In the example below: To watch a program after 2

hour 50 minutes from the present position, in either

direction.

1Insert a tape.

2Select “TIME SEARCH” mode

Press the SETUP button on the

remote control.

Press the Arrow Kor Lbutton to

point to “TIME SEARCH”.

Then, press the Arrow Bbutton.

3Enter your desired time

Press the Arrow Kor Lbutton until

your desired time appears.

(Example: “2:50” stands for 2 hours

50 minutes)

If you wish to cancel the Time

Search at this point, press the SETUP button on the

remote control.

4Begin Time Search

By pressing the Arrow sor Bbutton, the

TV/DVD/VHS will rewind or fast forward to the

specified point.

The time counts down as the searching progresses.

When 0:00 is reached, the tape will start playback

automatically.

TO CANCEL THE TIME SEARCH at this

point

Press the STOP/EJECT button on the TV/DVD/VHS

or the remote control. This will delete the selected

time.

- TV/VCR SETUP -

TIMER PROGRAMMING

SETTING CLOCK

CHANNEL SET UP

USER’S SET UP

V-CHIP SET UP

LANGUAGE [ENGLISH]

CAPTION [OFF]

BZERO RETURN

TIME SEARCH

INDEX SEARCH

- TV/VCR SETUP -

TIMER PROGRAMMING

SETTING CLOCK

CHANNEL SET UP

USER’S SET UP

V-CHIP SET UP

LANGUAGE [ENGLISH]

CAPTION [OFF]

ZERO RETURN

BTIME SEARCH

INDEX SEARCH

TIME SEARCH

2 : 50

TD503_01-36 02.2.26 10:10 AM Page 28

- 29 - EN

1C29

INDEX SEARCH

This feature provides a method of indexing the start-

ing point so that it can be easily returned to in either

fast forward or rewind mode.

•The index mark will be made automatically when

the REC button is pressed. It will also be marked at

the starting point of Timer recording and OTR.

•The index mark will not be recorded if the PAUSE

button is pressed and released during recording.

•The time gap between making the index marks on

the tape should be greater than 1 minute for SP

recording, 2 minutes for LP recording and 3 min-

utes for SLP recording.

•In some cases, the index mark at the beginning of

video tape cannot be detected.

Example: You are watching program number 4 and

want to fast forward to program number 7. You

must skip three programs.

1Select “INDEX SEARCH”

Press the SETUP button on the

remote control.

Press the Arrow Kor Lbutton to

point to “INDEX SEARCH”. Then,

press the Arrow Bbutton

2Enter your desired number

Press the Arrow Kor Lbutton until

the number of programs that you

want to skip appears.

(Example: “03” for 3 programs)

•The Index Search mode will be

canceled if the procedures are not activated in 30

seconds.

3Begin Index Search

Press the Arrow sor Bbutton. The TV/DVD/VHS

begins rewinding or fast forwarding to the beginning

of desired program.

NOTE: Every time an index signal is skipped, the

number in the program indicator decreases by one.

4After Index Search

When the preset program is reached, the

TV/DVD/VHS will start playback automatically.

•Avideo cassette must be inserted in the

TV/DVD/VHS for this function to work.

•The number of Index Searches can be set up to 20.

•

This function will not operate in the recording mode.

•When you want to cancel the Index Search while

in progress, press the STOP button.

Pro.1 Pro.2 Pro.3 Pro.4 Pro.5 Pro.6 Pro.7

4321123

End of tape

Beginning of tape

CURRENT PLAYBACK PROGRAM

INDEX MARK

- TV/VCR SETUP -

TIMER PROGRAMMING

SETTING CLOCK

CHANNEL SET UP

USER’S SET UP

V-CHIP SET UP

LANGUAGE [ENGLISH]

CAPTION [OFF]

ZERO RETURN

TIME SEARCH

BINDEX SEARCH

INDEX SEACH

0 3

SPECIAL FEATURES

REAL TIME TAPE COUNTER

This shows the elapsed recording or playback time in

hours, minutes, and seconds. (The displayed time will

not change on a blank tape or blank portions on the

tape.)The “–” indication will appear when the tape has

rewound further than “0:00:00” on the tape counter.

AUTO REWIND-EJECT

•When the end of a tape is reached during record-

ing, playback, or fast-forward, the tape will auto-

matically rewind to the beginning. After rewinding

finishes, the TV/DVD/VHS will eject the tape and

turn itself to off.

•This function is operative when Repeat Play is set

to the [OFF] position.

•The tape will not auto-rewind during timer record-

ing or One Touch Recording.

TD503_01-36 02.2.26 10:10 AM Page 29

- 30 - EN

1C29

RECORDING

Make sure ...

•TV/DVD/VHS power must be turned on.

•Insert a cassette tape with its erase prevention tab in place. (If necessary, rewind or fast forward the tape to

the point at which you want to begin recording.)

NOTES:

•This unit will ONLYrecord and view the same channel.

•This unit cannot record the contents from the built-in DVD.

You can ONLYwatch the same TV program that is

being recorded.

1Select the channel to be recorded

Press the number buttons on the

remote control or the CHANNEL

Kor Lbutton.

Remember: If the TV/DVD/VHS is

connected to a cable box or satellite

box, the TV/DVD/VHS must be on CH3 or CH4,

then the channel to be recorded must be selected on

the cable box or satellite box.

2Select the tape speed

Press the SPEED button to select

the desired tape speed (SP/ SLP).

3Begin recording

Press the RECORD button.

4Stop recording

Press the STOP button when recording is completed.

NORMAL RECORDING

Press the PAUSE button to tem-

porarily stop recording.

Press the PAUSE or RECORD but-

ton to resume recording.

NOTES:

•After five minutes, the

TV/DVD/VHS will automatically switch to the

Recording mode to prevent tape damage.

•If “CLOSED CAPTION (ON)” is selected, the On-

Screen Display will appear for 5 seconds, then dis-

appear.

SKIPPING UNWANTED

SCENES DURING RECORDING

CH 10

REC

PAUSE

TD503_01-36 02.2.26 10:10 AM Page 30

- 31 - EN

1C29

This function enables you to set a recording length

simply by pressing the REC/OTR button on the

TV/DVD/VHS.

Make sure ...

•TV/DVD/VHS power must be turned on.

•Insert a cassette tape with its erase prevention tab

in place. (If necessary, rewind or fast forward the

tape to the point at which you want to begin

recording.)

NOTES:

•This function CANNOT be done from the remote

control.

•Recording starts immediately when the REC/OTR

button is pressed.

•When the REC/OTR button is pressed 18 times, the

TV/DVD/VHS returns to the Normal Recording

mode.

•To stop the OTR operation, press the STOP button

on the TV/DVD/VHS or on the remote control.

•To show the remaining time, press the DISPLAY

button on the remote control so that “OTR”

appears on the TV screen. (It will show up momen-

tarily then disappear.)

•Recording stops when 0:00 is reached.

•Please note that in the SLP mode maximum record-

ing time, assuming the tape is started at the begin-

ning, is 8 hours using T-160 (or 6 hours using T-

120).

•If the tape runs out before the end time, the

TV/DVD/VHS will switch to the Stop mode imme-

diately, ejects the tape and turns itself off.

1Select the channel to be recorded

Press the number buttons on the remote control or

the CHANNEL Kor Lbutton.

Remember: If the TV/DVD/VHS is connected to a

cable box or satellite box, the TV/DVD/VHS must be

on CH3 or CH4, then the channel to be recorded is

selected on the cable box or satellite box.

2Select the tape speed

Press the SPEED button to select the desired tape

speed (SP/ SLP).

3Begin OTR

Press the REC/OTR button on the

TV/DVD/VHS as many times as

needed. The recording length will

be determined by the number of

times you press the REC/OTR button. Each addition-

al push will increase the recording time by 30 min-

utes. It is set up to 8 hours.

OTR (One Touch Recording) Push(es) Display Recording length

1 push (normal recording)

2 pushes 0:30 30 minutes

3 pushes 1:00 60 minutes

17 pushes 8:00 480 minutes

You can make copies of video tapes made by friends

or relatives for your enjoyment.

Connect your TV/DVD/VHS and a Source (Playing)

VCR using the following diagram.

1)Insert a pre-recorded video cassette into the Source

(Playing) VCR or camcorder.

2)Insert a blank video cassette, or one you want to

record over, into the TV/DVD/VHS’s cassette com-

partment.

3)Press the SPEED button on remote control for the

TV/DVD/VHS to select the desired recording

speed (SP/SLP).

4)Press the CHANNEL Kor Lbutton on the

TV/DVD/VHS until “AUX” appears on the screen.

5)Press the RECORD button on the TV/DVD/VHS.

6)Begin playback of the tape in the source (Playing)

VCR or camcorder.

NOTE: For best results during copying, use the

TV/DVD/VHS’s front panel controls whenever pos-

sible. The remote control might affect the source

(Playing) VCR’s playback operation.

COPYING A VIDEO CASSETTE

(Requires a VCR or camcorder)

WARNING: Unauthorized recordings of

copyrighted video tapes may be an

infringement of copyright laws.

L-AUDIO-RVIDEO

HEADPHONE

VIDEO

OUT

AUDIO

OUT

[Fig.8]

[Ex: Source (playing)

VCR or camcorder]

Audio/Video

adapter cable

(not supplied)

[The TV/DVD/VHS]

OTR(2 : 30)

TD503_01-36 02.2.26 10:10 AM Page 31

- 32 - EN

1C29

TIMER

You may set the TV/DVD/VHS to start and end a

recording while you are away. You can set 8 pro-

grams to record on specific days, daily or weekly

within a 1 year period.

In the example below, the timer is being set to record:

DATE: July 6th, 2001

SETTING TIME: from 7:30PM to 8:50PM

CHANNEL: CH61

TAPE SPEED: SP

Make sure ...

•If a cable box or satellite box is connected with the

TV/DVD/VHS you will be limited to record only

one channel. And the channel selector on the

TV/DVD/VHS must be selected to the output

channel of the boxes CH 3 or CH 4 and then the

actual channel to be recorded must be selected on

the boxes.

•Clock must be set to the correct time and date

before setting the timer.

•TV/DVD/VHS power must be turn on to program

it.

•Insert a cassette tape with its erase prevention tab

in place. (If necessary, rewind or fast forward the

tape to the point at which you want to begin

recording.)

•The channel you want to record is properly set in

advance. (See page 16.)

Avoid over lap of programs ...

There is a chance that a program will not be record-

ed. when programs overlap;

•The program with an earlier start has priority.

•Once the earliest program finishes, the overlapping

programs will begin recording in sequence.

•The illustration below demonstrates the sequence

of recordings.

Program 1 10:00AM - 11:00AM

Program 2 9:00AM - 10:00AM

Program 3 9:30AM - 12:00PM

1Select “TIMER PROGRAMMING”

Press the SETUP button on the remote control.

Confirm “TIMER PROGRAMMING” is pointed by

AUTOMATIC TIMER

RECORDING

9:00AM 10:00AM 12:00PM

Program 1

10:00AM-11:00AM

Program 2

9:00AM-10:00AM

Program 3

9:30AM-12:00PM

11:00AM

Recording Sequence

*Recording period is SHADED

pressing the Arrow Kbutton. And press the Arrow B

button.

•If you have not yet set the clock,

“MANUAL CLOCK SET”

appears. If so, follow stops [3] to

[8] on page 18. Then set the timer

recording.

2Select your desired program

position (1~8)

Press the Arrow Kor Lbutton to

select the desired program position.

Then, press the Arrow Bbutton.

3Set the channel number

Press the Arrow Kor Lbutton until

the desired channel number

appears.

(Example: CH61)

Then, press the Arrow Bbutton.

Remember: If the TV/DVD/VHS is connected to a

cable box or satellite box, the TV/DVD/VHS must be

on CH3 or CH4, then the channel to be recorded is

selected on the cable box or satellite box.

4Select once, every day or

weekly recording

For once recording :

Press the Arrow K(up) button

until the desired date appears.

(Example: “7/06” for July 6th). Then, press the

Arrow Bbutton.

For every day recording : To record a TV program

at the same time on the same chan-

nel every day. (Example: Monday

through Sunday)

Press the Arrow L(down) button

until “EVRY DAY” appears.

Then, press the Arrow Bbutton.

For weekly recording : To record a TV program at

the same time on the same channel

every week. (Example: every

Monday)

Press the Arrow L(down) button

until “EVRY” and your desired

day of the week appear together. Then, press the

Arrow Bbutton.

- TV/VCR SETUP -

BTIMER PROGRAMMING

SETTING CLOCK

CHANNEL SET UP

USER’S SET UP

V-CHIP SET UP

LANGUAGE [ENGLISH]

CAPTION [OFF]

ZERO RETURN

TIME SEARCH

INDEX SEARCH

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

B- - -/- - - - - -:- - -:- - - -

- - -/- - - - - -:- - -:- - - -

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

B61 -/- - - - - -:- - -:- - - -

- - -/- - - - - -:- - -:- - - -

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

B61 EVRY DAY -:- - -:- - - -

- - -/- - - - - -:- - -:- - - -

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

B61 7/06 FRI -:- - -:- - - -

- - -/- - - - - -:- - -:- - - -

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

B61 EVRY MON -:- - -:- - - -

- - -/- - - - - -:- - -:- - - -

TD503_01-36 02.2.26 10:10 AM Page 32

- 33 - EN

1C29

To shift the time schedule of an automatic timer

recording.

1)Press the POWER button.

2)Repeat step [1] on page 32.

3)Press the RECORD button and select the desired

program using the Arrow Kor Lbutton.

4)Press the RECORD button again.

Each additional push will shift forward the

begin/end time for recording by 10 minutes. When

the recording is already in progress, each additional

push will shift forward the end time only. If you

want to cancel while setting, press the PAUSE but-

ton on the remote control. The recording time

returns to the original time.

NOTE: When you shift forward the time schedule

during recording, the recording speed will automati-

cally be set to the SLP mode.

5)Press the Arrow Bor sbutton to exit the setting

menu. Then press the SETUP button on the remote

control to return to original mode.

TO CORRECT A PROGRAM

•While setting a program; press the Arrow sbut-

ton to go back one step and enter the correct num-

bers using the Arrow Kor Lbutton.

•After setting a program;

1)Press the POWER button.

2)Repeat steps [1] - [2] on page 32.

3)Press the Arrow Bbutton (or press the Arrow s

button to go back one step) until the part you

want to correct begins flashing, then make the

changes pressing the Arrow Kor Lbutton.

4)Press the POWER button to set automatic timer

recording.

TO CANCEL AN AUTOMATIC TIMER

RECORDING

•After setting a program;

1)Press the POWER button.

2)Repeat steps [1] ~ [2] on page 32 and select a

program you want to cancel.

3)Press the C.RESET button.

4)Press the SETUP button on the remote control to

return to TV mode.

•While recording is in progress;

1)Press POWER button.

2)Press the STOP/EJECT button on the

TV/DVD/VHS.

5Set beginning hour

Press the Arrow Kor Lbutton until

the desired hour appears.

(Example: “ 7, PM” for 7:30PM)

Then, press the Arrow Bbutton.

6Set beginning minute

Press the Arrow Kor Lbutton until

the desired minute appears.

(Example: “30” for 7:30PM)

Then, press the Arrow Bbutton.

7Set end hour

Press the Arrow Kor Lbutton until

the desired hour appears.

(Example: “8, PM” for 8:50PM)

Then, press the Arrow Bbutton.

8Set end minute

Press the Arrow Kor Lbutton

until the desired minute appears.

(Example: “50” for 8:50PM)

Then, press the Arrow Bbutton.

9Set the tape speed

Press the Arrow Kor Lbutton

until the desired tape speed

appears. (Example: SP)

10 Finish setting the program

Press the Arrow Bor sbutton. The program is now

completed.

•To set another program, repeat steps [2] to [10].

•Press the SETUP button on the remote control to

return to original mode.

11 Set the timer

Press the POWER button to set automatic timer

recording. The TIMER REC indicator lights up.

•You must turn off the TV/DVD/VHS to activate

automatic timer recording.

If power is not turned off and you continue watch-

ing TV, “TIMER REC STANDBY” starts flashing

on the TV screen 2 minutes before the programmed

start time.

TIMER PROGRAM EXTENSION

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

B61 7/06 FRI 7:12PM-:- - - -

- - -/- - - - - -:- - -:- - - -

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

B61 7/06 FRI 7:30PM-:- - - -

- - -/- - - - - -:- - -:- - - -

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

B61 7/06 FRI 7:30PM8:30PM- -

- - -/- - - - - -:- - -:- - - -

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

B61 7/06 FRI 7:30PM8:50PM- -

- - -/- - - - - -:- - -:- - - -

– TIMER PROGRAMMING –

CH DATE BEGIN END

- - -/- - - - - -:- - -:- - - -

B61 7/06 FRI 7:30PM8:50PMSP

- - -/- - - - - -:- - -:- - - -

TD503_01-36 02.2.26 10:10 AM Page 33

- 34 - EN

1C29

TO CHECK THE BEGIN/END TIME

1)Press the POWER button so that the REC indicator

goes off.

2)Press the SETUP button on the remote control.

3)Confirm “TIMER PROGRAMMING” is pointed.

4)Press the Arrow Bbutton. The details of programs

appear on the TV screen.

5)Press the SETUP button on the remote control to

return to TV mode.

HINTS FOR AUTOMATIC

TIMER RECORDING

•Make sure the channel you want to record is prop-

erly set in advance.

•It is not necessary to press the RECORD button for

timer recording.

•Recording begins automatically at the Start time.

•If you are recording using a Timer mode, you may

not operate the unit manually.

•The erase-prevention tab on the cassette must be in

place (or you must put tape over the hole).

•If the erase-prevention tab is removed, the cassette

will be ejected when the POWER button is pressed

to off.

•If the tape runs out before the end time, the

TV/DVD/VHS will switch to the Stop mode imme-

diately, and the tape will be ejected.

AUTO RETURN

With this feature, after timer recording is finished,

the beginning of the recorded program(s) can be

searched for automatically.

1Select “USER’S SET UP”

Press the SETUP button on the

remote control.

Press the Arrow Kor Lbutton to

point to “USER’S SET UP”.

Then, press the Arrow Bbutton.

2Set “AUTO RETURN” to [ON]

Press the Arrow Kor Lbutton to

point to “AUTO RETURN”.

Press the Arrow Bor sbutton

until [ON] appears.

3Auto Return will begin

When all the timer recordings are completed, the

TV/DVD/VHS will rewind to the beginning of the

recorded program(s).

NOTE:

•If you press the POWER button while tape is

rewinding, the Auto Return will stop.

4Watch the recorded program

Press the PLAY button.

TO CANCEL THE AUTO RETURN

MODE

Repeat steps [1] and [2], select [OFF] using the

Arrow Bor sbutton.

If there is a power failure of any kind, the unit

will retain its memory for this feature.

- TV/VCR SETUP -

TIMER PROGRAMMING

SETTING CLOCK

CHANNEL SET UP

BUSER’S SET UP

V-CHIP SET UP

LANGUAGE [ENGLISH]

CAPTION [OFF]

ZERO RETURN

TIME SEARCH

INDEX SEARCH

– USER’S SET UP –

RENTAL [OFF]

REPEAT PLAY [OFF]

BAUTO RETURN [ON]

VCR AUDIO [HIFI]

TV AUDIO [STEREO]

SLEEP TIMER

The Sleep Timer function turns off the

TV/DVD/VHS without using the POWER button

after a desired period of time.

NOTE:

•This function does not operate during Recording

mode.

1Select “SLEEP TIMER”

Press the SLEEP button on the remote control until

“SLEEP TIMER” appears.

2Set sleep time

Press the SLEEP button until your

desired sleep time appears.

Each additional push will increase

the time by 30 minutes up to 120

minutes.

After 5 seconds, exit the Sleep

Timer setting.

TO CANCEL THE SLEEP TIMER

Press the SLEEP button on the remote control until

“SLEEP TIMER” appears. Press the SLEEP button

until “SLEEP 0 MINUTES” appears.

SLEEP 120 MINUTES

TD503_01-36 02.2.26 10:10 AM Page 34

- 35 - EN

1C29

ON SCREEN DISPLAY

To check the Counter, Clock and Channel number on the TV screen, press the DISPLAY button on the remote

control. Each time you press the DISPLAY button on the remote control, the TV screen will change as follows:

When the Closed Caption mode is OFF:

•Counter mode: After 5 seconds, only the counter

remains. To clear it, press the DISPLAY button.

•Clock mode: After 5 seconds, only the clock and

the channel number remain. To clear them, press

the DISPLAY button.

When the Closed Caption mode is ON:

•The On Screen Display disappear after 5 seconds.

•This is true even if the MUTE button is pressed, or

the PAUSE button is pressed while recording.

OFF mode Clock/Counter mode

STOP 5:40 PM

CH2

SP COUNT 0:12:34

STOP STOP

SP SPCOUNT 0:12:34

COUNT 0:12:34

5:40PM

CH2

5:40PM

CH2

Counter

remains

Clock & Channel

remains

After 5 seconds After 5 seconds

OFF mode Counter mode Clock mode

CABLE CHANNEL DESIGNATIONS

If you subscribe to cable TV, the channels are displayed as 1-125. Cable companies often designate channels

with letters or letter-number combinations. Please check with your local cable company. The following is a

chart of common cable channel designations.

TV Display

CATV channel

TV Display

W+80 W+81 W+82 W+83 W+84

W+65 W+66 W+67 W+68 W+69 W+70 W+71 W+72 W+73 W+74 W+75 W+76 W+77 W+78 W+79

W+55 W+56 W+57 W+58 A-4 A-3 A-2 A-1 W+59 W+60 W+61 W+62 W+63 W+64

W+40 W+41 W+42 W+43 W+44 W+45 W+46 W+47 W+48 W+49 W+50 W+51 W+52 W+53 W+54

W+25 W+26 W+27 W+28 W+29 W+30 W+31 W+32 W+33 W+34 W+35 W+36 W+37 W+38 W+39

W+10 W+11 W+12 W+13 W+14 W+15 W+16 W+17 W+18 W+19 W+20 W+21 W+22 W+23 W+24

A-5

RSTUVWW+1 W+2 W+3 W+4 W+5 W+6 W+7 W+8 W+9

CDEFGH I JKLMNOPQ

5A 2 3 4 5 6 7 8 9 10 11 12 13 A B

123456789101112131415

16 17 18 19 20 21 22 23 24 25 26 27 28 29 30

31 32 33 34 35 36 37 38 39 40 41 42 43 44 45

46 47 48 49 50 51 52 53 54 55 56 57 58 59 60

61 62 63 64 65 66 67 68 69 70 71 72 73 74 75

76 77 78 79 80 81 82 83 84 85 86 87 88 89 90

91 92 93 94 95 96 97 98 99 100 101 102 103 104 105

106 107 108 109 110 111 112 113 114 115 116 117 118 119 120

121 122 123 124 125

CATV channel

TD503_01-36 02.2.26 10:10 AM Page 35

–36 –EN

01A11

DVD SECTION

ABOUT THE DISCS

The following discs can be played back on this DVD

player.

This player conforms to the NTSC color system. You can-

not play discs recorded in other color systems such as

PAL or SECAM.

¡Some discs include region codes as shown below.

¡The number inside the symbol refers to a region of the

world, and a disc encoded in a specific region format

can only be played back on DVD players with the same

region code.

The following discs cannot be played back on this

DVD player.

¡DVD with region codes other than 1 or ALL.

¡DVD-ROM

¡DVD-RAM (Never play back, otherwise

malfunction may result.)

¡CD-ROM

¡VSD

¡CDV (Only plays back the audio part.)

¡CD-G (Only plays back the sound.)

¡CD-R/CD-RW

(Only plays back the discs which audio CD and

MP3 is recorded.)

¡CD-I

(Never play back, otherwise malfunction may

result.)

¡SACD

¡Photo CD

(Never play back, otherwise malfunction may

result.)

Any other discs without compatibility indications

PLAYABLE DISCS

DVD

Video

12 cm

Approx. 4 h

(single-sided)

Approx. 80 min

(single-sided)

8 cm

Logo Maximum

Playback Time

ContentsDisc Type

Sound

and

Pictures

Disc Size

74 min

Approx. 8 h

(double-sided)

Approx. 160 min

(double-sided)

12 cm

20 min

8 cm

(singles)

Audio

CD Sound

[DVD]

Data on a DVD is divided into sections called "titles", and

then into subsections called "chapters", each of which is

given a title or chapter number. Playback conditions are

preset on some DVD video discs, and these playback con-

ditions take priority over user operations on this player. If

a function you selected do not run as desired, refer to the

manual accompanying the disc.

DISC TYPES

Example

Title 1 Title 2

Chapter 1 Chapter 2 Chapter 1 Chapter 2Chapter 3 Chapter 4

[AUDIO CD]

Data on an audio CD is divided into sections called

“tracks”, each of which is given a track number.

Example

Track 1 Track 2 Track 3 Track 4 Track 5 Track 6

[MP3]

Data on a MP3 is divided into sections called "albums",

and then into subsections called "tracks", each of which is

given an album or track number.

Example

Album 1 Album 2

Track 1 Track 2 Track 1 Track 2Track 3 Track 4

TD503_36-55 02.2.26 10:13 AM Page 36

–37 –EN

01A11

USING THE TITLE MENU

With a DVD containing a title menu, you can select

desired titles from the menu.

1 Press the TITLE button.

¡The title menu will appear.

2 Select the desired title.

¡Press the arrow buttons (L/K/B/s) to change the

setting, and then press the ENTER button.

CALLING UP A MENU SCREEN

DURING PLAYBACK

For DVDs

¡Press the DISC MENU button to call up the DVD

menu.

¡Press the TITLE button to call up the title menu.

Note

¡Contents of menus and corresponding menu

operations may vary between discs. Refer to the

manual accompanying the disc for details.

DVD

PLAYING A DVD VIDEO

OR AN AUDIO CD

Getting started

Turn on the power of the TV, amplifier and any other

components which are connected to the DVD player.

(Change the input system to suit the DVD player, and

check that the sound volume is correct.)

1 Press the POWER button.

¡The power will turn on.

2 Press the OPEN/CLOSE button.

¡The disc loading tray will open.

3 Place a disc into the tray.

¡Make sure the disc is sitting properly in the correct

recess, with the label side up.

4 Press the PLAY button.

¡The tray will close automatically, and playback will

then start from the first chapter or track of the disc.

You need to press the PLAY button only when the

tray has been closed by pressing the OPEN/CLOSE

button.

¡When you playback the DVD which a title menu is

recorded, it may appear on the screen. In this case,

refer to “USING THE TITLE MENU”.

5 Press the STOP button to stop play.

CDDVD

Notes

¡If you press the OPEN/CLOSE button in the

TV/VCR mode or power-off, the DVD tray will

open.

¡If you press the DVD side PLAY button in the

TV/VCR mode or power off, you can start the DVD

playback.

¡A“prohibited icon” may appear at

the top-right on the TV screen

during operation, warning that a

prohibited operation has been

encountered by the DVD player

or the disc.

PLAYING A DISC

USING THE DVD MENUS

Some DVDs contain their own menus, such as a

guidance menu which describes the contents of the

disc or a selection menu for sound, language and other

customized settings.

1 Press the DISC MENU button.

¡The DVD menu will appear.

2 Select the desired title.

¡Press the arrow buttons (L/K/B/s) to change the

setting, and then press the ENTER button.

3 Playback will start from the selected title.

DVD

¡If a disc is dirty or has scratches, the pictures may

appear distorted and the playback operation may

stop. In such cases, clean the disc and unplug the

power cord and then plug it again before resuming

playback.

¡With DVDs that use some titles for playback

program signals, playback may start from the second

title, or it may skip these titles.

¡During the playback of two layered disc, pictures

may stop for a moment. This happens when the 1st

layer switches to the 2nd layer. This is not a mal-

function.

TD503_36-55 02.2.26 10:13 AM Page 37

1 Press the STOP button during playback.

¡Playback will stop, and then

appear the resuming message at

the center.

2 Press the PLAY button. Playback will start

from the point where the previous playback

session was stopped.

Notes

¡Resuming playback is not available with some discs.

¡It is possible to switch from the DVD play mode to

the TV mode. Even if the power is turned off, the

resume function enables to playback on from the

previously interrupted point. But note that the

Marker commands are not saved.

¡The resume function can be reset by pressing the

STOP button twice or by opening the disc loading

tray.

CDDVD

–38 –EN

01A11

PAUSING PLAYBACK OR

DISPLAYING A STILL PICTURE

1 Press the PAUSE button during playback.

¡Playback will pause, with sound

muted.

2 Press the PLAY button to resume playback.

CDDVD

STEPPING THROUGH FRAMES

1 Press the PAUSE/STILL button while play-

back is paused.

¡The next picture frame is dis-

played with sound muted each

time the button is pressed.

2 Press the PLAY button to resume playback.

DVD

RESUMING PLAYBACK FROM

THE POINT WHERE

PLAYBACK STOPPED

Press 'PLAY' to play from here.

To play the beginning, press 'STOP' first

and then 'PLAY'.

FAST FORWARD/REVERSE

1 Press and hold the gor hbutton for

more than 1 second during playback.

¡For DVDs, pressing the FWD gor REV hbut-

ton cycles the playback speed in four steps. In case

of DVDs, the sound will mute.

¡For audio CDs, the playback speed is ×16 fixed.

2 Press the PLAY button to return to normal

playback speed.

CDDVD

Ex2

Ex8

Ex30

Ex60

Ex30

Ex60

Dx8

Dx2

REV Button Button

FWD

TD503_36-55 02.2.26 10:13 AM Page 38

–39 –EN

01A11

1 Press the numeric buttons to enter the

desired track number.

The selected track will be located, and playback will start.

You can also press the SEARCH

MODE button, use the numeric

buttons to enter the track number.

When the track number is entered

in the entry box, playback of the

desired track will start automatically.

SLOW MOTION

1 Press and hold the gbutton for more than

1 second while playback is paused. (Sound

remains muted.)

¡Slow motion mode will be activated.

¡Pressing and holding the gbutton for more than

1 second cycles the playback speed in three steps.

Select an appropriate speed while referring to the

speed indication on the screen.

2 Press the PLAY button to return to normal

playback speed.

Notes

¡Slow playback is not available with audio CDs.

¡The reverse of slow playback is not available.

¡If you press the gbutton and release immediate-

ly during playback is paused or slow, it returns to

normal playback.

DVD

×1/16 ×1/8 ×1/2

DButton

STARTING FROM A DESIRED

TRACK

TRICKS WITH THE SKIP BUTTONS (H, G)

If the SKIP button Gis pressed during playback or

while playback is paused, the current track is

skipped and the next track is played. When the SKIP

button His pressed once, the top of the current

track is located for replaying. When the SKIP button

His pressed again while Within 2-second

playback, the previous track is located.

STARTING FROM A DESIRED

TIME COUNT

1 Press the SEARCH MODE button twice.

2 Press the numeric buttons to set the desired

time count.

¡Example: 1 hour, 23 minutes and

30 seconds

1 →2 →3 →3 →0

Notes

¡In the case of DVD, Time Search in Title is effec-

tive. (But Time Search in Chapter is ineffective.)

¡In the case of CD, Time Search in Track is effective.

(But Time Search in the entire disc is ineffective.)

¡Playback from a desired time count is not available

with some discs or if the unit is in stop mode.

¡If wrong numbers are entered, press the CLEAR

button and re-enter the correct numbers.

CDDVD

TIME 1:23:30

TOTAL 1:23:45

TR __/ 15

1 Press the SEARCH MODE button and then

press the numeric buttons to select a title or

a chapter.

Perform the title search and the

chapter search after setting them on

the same screen at the same time.

Changeover by

K/L

buttons.

During playback, press the numeric buttons to select a

Chapter. The Chapter will be located and playback will

start.

When playback is stopped, press the numeric buttons to

select a Title. The Title will be located and playback

will start.

Notes

¡Playback from a desired title or chapter is not avail-

able with some DVDs.

¡Some discs which the chapter number isn’t dis-

played cannot playback from a desired chapter.

DVD

TRICKS WITH THE SKIP BUTTONS (H, G)

If the SKIP button Gis pressed during playback or

while playback is paused, the current chapter will be

skipped and the next chapter will be played. When the

SKIP button His pressed once, the top of the current

chapter will be located for replaying. When the SKIP

button His pressed again within 2-seconds after

playback begins, the previous chapter will be located.

PLAYING FROM A DESIRED

TITLE OR CHAPTER

TT : 1/ 2

CH __ / 49

TT : _/ 12

CH : 12/ 49

TD503_36-55 02.2.26 10:13 AM Page 39

–40 –EN

01A11

REPEAT

1 Press the REPEAT button.

For DVDs

¡Asingle title or chapter is played back repeatedly.

¡Pressing the REPEAT button cycles the display on

the screen as follows.

For audio CDs

¡The whole disc or a single track is played back

repeatedly.

¡Pressing the REPEAT button cycles the display on

the screen through Off, Track and All.

CDDVD

The current Title is

played back repeatedly.

REPEAT

[OFF]

REPEAT

[CHAPTER]

REPEAT

[TITLE]

The current Chapter is

played back repeatedly.

No repeat playback.

The whole Disc is

played back repeatedly.

REPEAT

[ALL]

REPEAT

[TRACK] The current Track is

played back repeatedly.

No repeat playback.

REPEAT

[OFF]

If the REPEAT button is pressed once dur-

ing program/random playback, the pro-

gram/random playback is performed

repeatedly.

If the REPEAT button is pressed again, the

current track is played back repeatedly.

Notes

¡Repeat playback is not available with some discs.

¡The REPEAT setting will be cleared when moving

to other title, chapter or track.

¡Repeat playback is not function during A-B repeat

playback.

A-B REPEAT

You can define a section to be played back repeatedly.

Press the A-B REPEAT button during playback.

¡The starting point (A) will then be

selected.

2 Press the A-B REPEAT button again at the

end point (B) of the desired section.

¡The selected section will be

played back repeatedly.

3 To exit A-B repeat playback, press the A-B

REPEAT button and set it to OFF.

Notes

¡With DVDs, the A-B repeat section can be set only

within the current title.

¡With audio CDs, the A-B repeat section can be set

within the current track.

¡A-B repeat is not available with some scenes in

DVD.

¡To cancel the A point which was set, press RETURN

button.

¡A-B repeat playback is not function during title,

chapter, track or all repeat playback had set.

CDDVD

REPEAT

[ A - ]

REPEAT

[ A - B ]

REPEAT

[ OFF ]

TD503_36-55 02.2.26 10:13 AM Page 40

–41 –EN

01A11

PROGRAM (Audio CD)

Press the MODE button in stop mode.

¡The program screen will appear.

PROGRAM TIME 0:00:00 2/2

RANDOM

: MODE

EXIT

: RETURN

START: PLAY

DELETE

: CLEAR

2 Press the numeric buttons to enter the

desired track numbers.

¡50 programs can be displayed at

once on the screen. Press “L” to

go to the next page.

3 Press the PLAY button.

¡Playback will start in the programmed order.

¡While the program is being played back, the STOP

button works as follows.

¡Press the STOP button once and then the PLAY

button again, playback will restart from the point

where the STOP button was pressed. (Program

continued)

¡Press the STOP button twice and then the PLAY but-

ton again, playback will restart from the track in the

usual way. (Program cleared)

Notes

¡Adding programs is not possible during program

playback. You must stop the current playback before

such operations can be carried out.

¡Press the CLEAR button to cancel a program. The

most recently entered program will then be deleted.

¡Up to 99 programs can be entered.

¡Playback from a desired track and random playback

are not available during program playback.

¡Program settings are cleared when the power is

turned off or the disc loading tray is opened.

¡Press the MODE button to check the programmed

setting.

02 05 07 04 10 14 06 15 21 08

20 28 10 25 35 12 30 42 11 34

49 16 40 58 18 45 63 01 03 _

PROGRAM TIME 2:07:43 1/1

RANDOM

: MODE

EXIT

: RETURN

START: PLAY

DELETE

: CLEAR

MARKER

You can define the part to be called back.

1 Press the SEARCH MODE button three

times during playback.

Set the marker

¡Using the cursor (s/B) button, position the cursor

on to the marker number shown as “NOT SET”.

Press the ENTER button when the screen to be

reviewed appears. The marked

time will be displayed. Up to 5

points can be marked.

Call back the marker

¡Using the cursor (s/B) button, position the cursor

on to the marker number to be called back and press

the ENTER button.

Clear the marker

¡Using the cursor (s/B) button, position the cursor

on to the marker number to be cleared and press the

CLEAR button.

To clear all markers, place the cursor on “AC” (All

clear markers) and press the ENTER button.

2 Press the SEARCH MODE button or the

RETURN button to exit the display.

CDDVD

1 2 3 4 5 AC

NOT SET

TD503_36-55 02.2.26 10:13 AM Page 41

–42 –EN

01A11

Note

¡Zooming function does not work while disc menu is

shown.

ZOOM PLAYBACK

(enlargement onscreen)

Images can be enlarged four times on the screen to

your taste.

1 Press the ZOOM button during playback.

¡An image will be enlarged at the center of the

screen.

¡Press the ZOOM button again, and the image will be

back to the previous size.

DVD

Zoom [x4]Zoom [x2] Zoom [OFF]

2 When the cursor (K/L/s/B) button is

pressed during zoom play, the part to be

zoomed moves.

¡The zooming frame can be moved from the center

.... 4 steps to the right. 4 steps to the left. 4 steps to

the top. 4 steps to the bottom when 2 time zooming.

The frames will move 6 steps when 4 time zooming.

¡Current position will be displayed on the right-bot-

tom of the screen. Press the ENTER button, and the

display disappears.

RANDOM (Audio CD)

1 Press the MODE button in stop mode.

¡The program setting menu screen will appear.

2 Press the MODE button again.

3 Press the PLAY button. Random playback

will then start.

Note

¡Program playback is not available during random

playback.

RANDOM

EXIT : MODESTART : PLAY

Insert an MP3 file-recorded disc.

¡The MP3 menu screen shows up.

¡Folders are referred to as

“ALBUMS” and files are

referred to as “TRACKS”.

¡“+” appears at the beginning

of the album name.

MP3

PLAYING AN MP3 DISC

¡If all the TRACKS cannot be displayed at once on

the screen, “L” appears to go to the next page. If

there is a previous page, “K” appears on-screen. On

the left of “L”, the current page and the total num-

ber of pages are displayed.

¡The player can recognize 255 ALBUMS and

TRACKS altogether.

2 Using the K/Lbuttons, select a ALBUM or

TRACKS to be played.

[When TRACKS are selected]

The TRACKS will be played

in the order of selection.

[When an ALBUM is selected]

Press the Bbutton. The TRACK

selection screen shows up. Using

the K/Lbuttons, select TRACKS

to be played.

¡Choose “FIRST PLAY”, and the ALBUMS and

TRACKS will be played from the beginning of the

disc.

¡Press the TITLE button, and the top hierarchy will

be called back.

¡ALBUMS can be played up to the 8th hierarchy.

FIRST PLAY

+ALBUM01

+ALBUM02

+ALBUM03

+ALBUM04 1/15

VOLUME LABEL

START

PLAY

SELECT:

ENTER:

RETURN:

+ALBUM11

+ALBUM12

+ALBUM13

+ALBUM14

+ALBUM15

ALBUM01

START

PLAY

SELECT:

ENTER:

RETURN:

TD503_36-55 02.2.26 10:13 AM Page 42

Press the MODE button in STOP mode.

¡The program screen shows up.

MP3

Press the SEARCH MODE button during play-

back.

¡The SERACH menu shows up.

¡Atrack currently in play or under

RESUME ON will be highlight-

ed. In the case of RESUME OFF,

the first track of the disc will be

highlighted.

¡Press the RETURN button, and

the SEARCH menu disappears.

2 Using the K/Lbuttons, select a track to be

played. Then press the PLAY button to start

playing.

MP3

–43 –EN

01A11

CHANGING THE ONSCREEN

DISPLAY DURING MP3 DISC PLAY

Notes

¡During play, a desired track can be directly searched.

Just type in the TRACK number with the numerical

buttons.

¡If the typed TRACK number is not available, the

“disable” symbol appears and the direct search mode

is cancelled.

¡Playback cannot be started from a desired time

count.

PLAYING AN MP3 DISC FROM A

DESIRED TRACK

PLAYING AN MP3 DISC IN A

PROGRAMMED WAY

+ALBUM01

TRACK11

TRACK12

TRACK13

TRACK14

ALBUM NAME

1/15

START

PLAY

SELECT:

ENTER:

RETURN:

2 Using the K/Lbuttons, select a track. Then

press the ENTER button to save it in a pro-

gram.

¡The programmed track is displayed in the right-hand

screen.

¡When the sbutton is pressed, the album stop in the

current left-hand screen will be highlighted.

¡If the entire program cannot be displayed at once on

the screen, “L” appears to go to the next page.

3 When the disc has been programmed, press

the PLAY button.

¡Programmed play starts.

Notes

¡Press the CLEAR button, and the last-programmed

entry will be deleted.

¡Press the RETURN button, and the STOP screen

will show up with the program contents in memory.

¡The program setting will be cancelled when the

power is turned off or the disc tray is opened.

3 Press the PLAY button.

¡Playback will start.

4 To stop the play, press the STOP button.

The information on an MP3 disc in play can be

checked.

Press the DISPLAY button during playback.

¡The TRACK currently in play

will be highlighted.

2 Press the DISPLAY button again.

¡The ALBUM name being displayed will be replaced

by the elapsed time of the track.

¡will be displayed when the repeat play has been

selected.

A: Album (folder) repeat

T: Track repeat

D : Disc repeat

MP3

TRACK11

TRACK12

TRACK13

TRACK14

TRACK15

FOLDER NAME

3 Press the DISPLAY button again, and the dis-

play screen disappears.

TRACK11

TRACK12

TRACK13

TRACK14

TRACK15

0:02:31 A

RANDOM: MODE

EXIT

: RETURN

START

: PLAY DELETE: CLEAR

+ALBUM01

+ALBUM02

+ALBUM03

TRACK01

TRACK02

PROGRAM FOLDER NAME

1/11 1/1

RANDOM: MODE

EXIT

: RETURN

START

: PLAY DELETE: CLEAR

+ALBUM11

+ALBUM12

TRACK11

TRACK12

TRACK13

TRACK11

PROGRAM - ALBUM01

1/11 1/1

RANDOM: MODE

EXIT

: RETURN

START

: PLAY DELETE: CLEAR

+ALBUM51

+ALBUM52

TRACK51

TRACK52

TRACK63

TRACK11

TRACK52

TRACK31

TRACK22

TRACK03

PROGRAM - ALBUM05

1/11 2/3

TD503_36-55 02.2.26 10:13 AM Page 43

–44 –EN

01A11

SETTINGS

CHANGING THE AUDIO

LANGUAGE OR SOUND MODE

The DVD player has a function which allows you to

select the desired audio language and sound mode.

For DVDs

Press the AUDIO button during playback, and then

press the AUDIO button to select the desired audio

language.

¡The audio language can be changed if multiple

languages are recorded on the DVD being played.

CDDVD

Notes

¡Pressing the Audio button may not work on some

DVDs with multiple audio languages (e.g. DVDs

which allow audio language setting on the disc

menu). Operation varies between discs, so refer to

the manual accompanying the disc.

¡Current audio language and sound mode will be dis-

played when you press the AUDIO button at first.

¡If a desired language is not shown after pressing the

Audio button several times, the disc does not have

an audio source in that language.

¡The audio language resets to the one which has been

selected in the setup mode, every time the power is

turned on or discs are replaced. If that language is

not available on a disc, a language defined by the

disc is selected.

¡The screen display will disappear after about 5

seconds.

¡If you use DIGITAL AUDIO OUT jack, the sound

mode of audio CDs can not be changed.

AUDIO 1.ENG DolbyD 5.1CH 48k/3

AUDIO 2.FRE DolbyD 5.1CH 48k/3

AUDIO 3.JPN DolbyD 5.1CH 48k/3

HELLO Bonjour

PLAYING AN MP3 DISC AT

RANDOM

Press the MODE button twice in STOP mode.

¡The random setting menu screen will appear.

2 Press the PLAY button.

¡Random play starts.

MP3

RANDOM

EXIT

: MODE

START

: PLAY

For audio CDs

Press the AUDIO button during playback.

¡Pressing the AUDIO button cycles the sound mode

through STEREO, L-CH and R-CH.

Both right and left channels

are active (stereo).

AUDIO STEREO

Only the left channel is active.

AUDIO L-CH

AUDIO R-CH

Only the right channel is active.

TD503_36-55 02.2.26 10:13 AM Page 44

–45 –EN

01A11

CHANGING THE SUBTITLE

LANGUAGE

The DVD player has a function which allows you to

select the desired language for subtitles.

1 Press the SUBTITLE button during playback,

and then press the SUBTITLE button to

select the desired subtitle language.

¡The subtitle language can be changed if the subtitles

are recorded in multiple languages on the DVD

being played.

¡The subtitle language cannot be changed if the

subtitles are recorded in a single language on the

DVD being played.

¡Pressing the SUBTITLE button cycles the subtitle

language from SUBTITLE 1, SUBTITLE 2 and all

the languages recorded.

¡Current subtitle mode will be displayed when you

press the SUBTITLE button at first.

¡Press the SUBTITLE button, and then press the cur-

sor (s/B) button to set it to on or off.

Notes

¡Some discs allow subtitle language setting on the

disc menu. (Operation varies between discs, so refer

to the manual accompanying the disc.)

¡If the desired language is not shown after pressing

the SUBTITLE button several times, the disc does

not have subtitles in that language.

¡The subtitle language resets to the one which has

been selected in the setup mode, every time the

power is turned on or discs are replaced. If that

language is not available on a disc, a language

defined by the disc is selected.

DVD

CHANGING THE CAMERA

ANGLE (Multi-Angle Pictures)

The DVD player has a function which allows you to

select the desired camera angle.

Press the ANGLE button during playback.

¡If the disc contains sequences recorded from differ-

ent camera angles, the angle icon ( ) will appear

at the top-right of the screen. You can change the

camera angle when the icon appears on the screen.

¡The camera angle cannot be changed if the disc does

not contain sequences recorded from different

camera angles.

Press the ANGLE button while the angle

number is shown on the screen.

Note

¡The screen display will disappear after about 5

seconds.

¡Current camera angle will be displayed when you

press the ANGLE button at first.

DVD

Subtitle 1

Subtitle 2

OFF

SUBTITLE 1.ENG/6

SUBTITLE 2.FRE/6

SUBTITLE OFF

Angle 1

Angle 2

Angle 8

ANGLE 1 / 8

ANGLE 2 / 8

ANGLE 8 / 8

HELLO Bon jour

¡It may take time to display the subtitles in the

selected language.

¡The screen display will disappear after about 5

seconds.

¡When “SUBTITLE NOT AVAILABLE” appears

onscreen, it means no subtitle is recorded on the

scene.

TD503_36-55 02.2.26 10:13 AM Page 45

You can enjoy stereophonic sound system when you

playback Dolby Digital and PCM 48kHz sound.

Press the MODE button twice during playback.

¡The setup screen will appear.

Press the ENTER button to set it on or off.

ON : TruSurround ON.(Default : OFF)

OFF : TruSurround OFF.

¡Press the DISPLAY button or the RETURN button

to exit the display.

–46 –EN

01A11

CHANGING THE ON-SCREEN

DISPLAY

TT 1/2 0:00:00 - 1:23:45

TT(Title):

Current title number

/ the number of total

titles.

TIME:

Elapsed time of the

current title on remaining

time of the current title.

You can check the information about the disc by

pressing the DISPLAY button on the remote control.

For DVDs

Press the DISPLAY button during playback.

CDDVD

Press the DISPLAY button again.

¡Use the number button to start from a desired chap-

ter.

3 Press the

DISPLAY

button again.

4 Press the

DISPLAY

button

or the RETURN but-

ton to exit the display.

CH 7/49 0:01:46 - 0:03:27

CH(Chapter):

Current chapter number

/ the number of total

chapter.

TIME:

Elapsed time of the

current chapter and

remaining time of the

current chapter.

BIT RATE

BIT RATE indicator will appear.

BIT RATE shows the quantity of

information which is recorded in DVD.

CL0

Layer number(*)

L0: Layer 0 is playing back

L1: Layer 1 is playing back

Current Repeat setting

C: Chapter repeat

T: Title repeat

A B: A-B repeat

*) It appears when the layered disc is playing back.

For audio CDs

Press the DISPLAY button during playback.

TR 4/12 0:03:21 - 0:02:15

TR(Track):

Current track number

/ the number of total

tracks.

TIME:

Elapsed time of the

current track and

remaining time of

the current track.

Press the DISPLAY button again.

¡Use the number button to start from a desired track.

All 4/12 0:13:45 - 0:45:40

All:

Current track number

/ the number of total

tracks.

TIME:

Elapsed time of the

current disk and

remaining time of

the current disc.

3 Press the

DISPLAY

button

or the RETURN but-

ton to exit the display.

You can set to make the black parts of the picture

brighter.

Press the MODE button during playback.

¡The setup screen will appear.

Press the ENTER button to set it on or off.

¡ON : It makes the dark parts brighter.(Default : OFF)

OFF : Original picture which is recorded on the disc

will be shown.

¡Press the RETURN button to exit the display.

BLACK LEVEL SETTINGS

BLACK LEVEL : OFF

TruSurround SETTINGS

SRS TruSurround ON

DVD

TD503_36-55 02.2.26 10:13 AM Page 46

–47 –EN

01A11

Press the SETUP button in STOP mode.

¡The setup screen appears.

2 Press the K/Lbuttons to select Language,

and then press the ENTER button.

3 Press the K/Lbuttons to select an item,

and then press the ENTER button.

AUDIO:

(Voice is played back in selected language.)

SUBTITLE:

(Subtitles are shown in selected language.)

DISCMENU:

(The disc menu appears in selected language.)

Press the

K/L

buttons to select a desired

item, and then press the ENTER button.

¡If “OTHER” is selected on the AUDIO, SUBTITLE

or DISC MENU setting screen, the Language Code

setting screen will appear. Press the numeric buttons

to enter the desired language code while referring to

the list on page 51.

5 Press the SETUP button.

¡The setup mode will be canceled and the ordinary

screen will appear.

Note

¡Be sure to press the SETUP button, or the setting

will not work.

¡Language Setting for Audio and Subtitle is not avail-

able with some discs. Then use the Audio and

Subtitle button. Details are on pages 44 and 45.

¡You can also select the item by pressing the numbers

which displayed with the item.

¡When you change the setup items, press the STOP

button if you are in playback mode.

CHANGING THE SETUP ITEMS

LANGUAGE SETTINGS

LANGUAGE

DISPLAY

AUDIO

PARENTAL

SET-UP

EXIT

: SETUP

CANCEL

: RETURN

SELECT:

/ SET

: ENTER

Please enter a 4-digit Language code.

- - - -

SET-UP

LANGUAGE CONTROLS

DISC MENU

LANGUAGE CODE

LANGUAGE

DISPLAY

AUDIO

PARENTAL

SET-UP

AUDIO ORIGINAL

SUBTITLE OFF

DISC MENU ORIGINAL

SET-UP

LANGUAGE CONTROLS

AUDIO ORIGINAL

SUBTITLE OFF

DISC MENU ORIGINAL

SET-UP

LANGUAGE CONTROLS

AUDIO ORIGINAL

SUBTITLE OFF

DISC MENU ORIGINAL

SET-UP

LANGUAGE CONTROLS

TD503_36-55 02.2.26 10:13 AM Page 47

Press the SETUP button in STOP mode.

¡The setup screen will appear.

2 Press the K/Lbuttons to select DISPLAY

and then press the ENTER button.

3 Press the K/Lbuttons to select an item, and

then press the ENTER button.

TV MODE (Default : 4:3 LETTER BOX)

4:3 LETTER BOX : Wide screen with black bars on top

and bottom

4:3 PAN & SCAN : Full height picture, trimmed both sides

–48 –EN

01A11

TV MODE 4:3 LETTER BOX

ANGLE ICON ON

AUTO POWER OFF ON

BACKGROUND BLACK

SET-UP

DISPLAY CONTROLS

1.4:3 LETTER BOX

2.4:3 PAN & SCAN

SET-UP

DISPLAY CONTROLS

TV MODE

TV MODE 4:3 LETTER BOX

ANGLE ICON ON

AUTO POWER OFF ON

BACKGROUND BLACK

SET-UP

DISPLAY CONTROLS

TV MODE 4:3 LETTER BOX

ANGLE ICON ON

AUTO POWER OFF ON

BACKGROUND BLACK

SET-UP

DISPLAY CONTROLS

SET-UP

DISPLAY CONTROLS

TV MODE 4:3 LETTERBOX

ANGLE ICON ON

AUTO POWER OFF ON

BACKGROUND BLACK

LANGUAGE

DISPLAY

AUDIO

PARENTAL

SET-UP

Press the

K/L

buttons to select a desired

item, and then press the ENTER button.

5 Press the SETUP button.

¡The setup mode will be canceled and the ordinary

screen will appear.

Notes

¡Be sure to press the SETUP button, or the setting

will not work.

¡You can also choose the item by pressing the num-

bers.

DISPLAY SETTINGS

LANGUAGE

DISPLAY

AUDIO

PARENTAL

SET-UP

EXIT

: SETUP

CANCEL

: RETURN

SELECT:

/ SET

: ENTER

AUTO POWER OFF (Default : ON)

Set or not set to turn off after the screen saver is started and

no keys are pressed for 30 minutes.

BACKGROUND COLOR (Default : BLACK)

Select blue or black.

ANGLE ICON (Default : ON)

Display or not display the Angle icon on the screen.

TD503_36-55 02.2.26 10:13 AM Page 48

–49 –EN

01A11

Press the SETUP button in STOP mode.

¡The setup screen will appear.

2 Press the K/Lbuttons to select Audio and

then press the ENTER button.

3 Press the K/Lbuttons to select an item, and

then press the ENTER button.

DRC (Default : OFF)

On : DRC

(Dynamic Range Control)

¡This function is for controlling the range of sound

volume. By compressing the range of sound volume,

it is possible not only to suppress the output of loud

sound at night and but also to raise the volume of

low sound.

¡This function is effective only for the sound record-

ed by Dolby Digital recording.

Dolby Digital (default : ON)

On : Output by Dolby Digital

Set to On when the unit is connected to Dolby Digital

Decoder.

DTS (Default : OFF)

On : Output DTS sound

Set to On when the unit is connected to DTS

Decoder.

Down Sampling (Default : AUTO)

Set the output for the DVD

recorded in PCM 96kHz (96kHz or 48kHz)

¡Press the K/L buttons to select an item, and then

press the ENTER button.

When playing a disc with copyright protection

¡If you select 96KHz, copyright protection will be

activated and no sound will come out. If you select

AUTO, sound will be down sampled at 48KHz.

Press the SETUP button.

¡The setup mode will be canceled and the ordinary

screen will appear.

AUDIO SETTINGS

LANGUAGE

DISPLAY

AUDIO

PARENTAL

SET-UP

EXIT

: SETUP

CANCEL

: RETURN

SELECT:

/ SET

: ENTER

LANGUAGE

DISPLAY

AUDIO

PARENTAL

SET-UP

EXIT

: SETUP

CANCEL

: RETURN

SELECT:

/ SET

: ENTER

DRC OFF

DOLBY DIGITAL ON

DTS OFF

DOWN SAMPLING AUTO

SET-UP

EXIT

: SETUP

CANCEL

: RETURN

SELECT:

/ SET

: ENTER

AUDIO CONTROLS

DRC OFF

DOLBY DIGITAL ON

DTS OFF

DOWN SAMPLING AUTO

SET-UP

EXIT

: SETUP

CANCEL

: RETURN

SELECT:

/ SET

: ENTER

AUDIO CONTROLS

SETUP MENU

AUDIO OPTIONS

1.DRC

OFF

DOLBY DIGITAL ON

DTS OFF

DOWN SAMPLING AUTO

EXIT

: SETUP

CANCEL

: RETURN

SELECT:

/ SET

: ENTER

DRC OFF

DOLBY DIGITAL ON

DTS OFF

DOWN SAMPLING AUTO

SET-UP

EXIT

: SETUP

CANCEL

: RETURN

SELECT:

/ SET

: ENTER

AUDIO CONTROLS

SET-UP

AUDIO CONTROLS

DOWN SAMPLING

AUTO

48kHz

96kHz

EXIT

: SETUP

CANCEL

: RETURN

SELECT:

/ SET

: ENTER

TD503_36-55 02.2.26 10:13 AM Page 49

Press the SETUP button.

¡The setup screen will appear.

2 Press the K/Lbuttons to select PARENTAL,

and then press the ENTER button.

3 Press the numeric buttons to enter the 4-

digit password, and then press the ENTER

button.

¡When doing this for the first time, enter any 4 digits.

(except for 4737) That number will be used as the

password from the second time onward.

¡By entering the password, you can then change the

control level and password settings.

Press the

K/L

buttons to select an item, and

then press the ENTER button.

–50 –EN

01A11

Press the SETUP button.

¡The setup mode will be canceled and the ordinary

screen will appear.

CONTROL LEVELS

ALL

All parental lock is cancelled.

Level 8

DVD software of any grade (adult/general/children)

can be played back.

Levels 7 to 2

Only DVD software intended for general use and

children can be played back.

Level 1

Only DVD software intended for children can be

played back, with those intended for adult and

general use prohibited.

Notes

¡With some DVDs, it may be difficult to find if they

are compatible with parental lock. Be sure to check

if the parental lock function operates in the way that

you have set.

¡Record the password in case you forget it.

IF YOU FORGET THE PASSWORD

1) Press the 4, 7, 3, 7 at step 3.

¡Password will be cleared and parental level will be

set to ALL.

2) Proceed the above steps 3-5 again.

PARENTAL LOCK

LANGUAGE

DISPLAY

AUDIO

PARENTAL

SET-UP

EXIT

: SETUP

CANCEL

: RETURN

SELECT:

/ SET

: ENTER

LANGUAGE

DISPLAY

AUDIO

PARENTAL

SET-UP

Please enter a 4-digit password.

- - - -

SET-UP

PARENTAL CONTROLS

PASSWORD

When “PARENTAL LEVEL” is selected

¡Press the K/Lbuttons to select an item from “ALL”

or 8 to 1 and then press the ENTER button.

When “CHANGE” is selected

¡Press the numeric buttons to enter the 4 digits pass-

word. Then press the ENTER button.

ALL

[NC-17]

[R]

SET-UP

EXIT

: SETUP

CANCEL

: RETURN

SELECT:

/ SET

: ENTER

PARENTAL CONTROLS

PARENTAL LEVEL

Please enter current password.

- - - -

SET-UP

EXIT

: SETUP

CANCEL

: RETURN

PARENTAL CONTROLS

PASSWORD

PARENTAL LEVEL ALL

CHANGE

SET-UP

PARENTAL CONTROLS

TD503_36-55 02.2.26 10:13 AM Page 50

–51 –EN

01A11

LANGUAGE CODE LIST

No. Language Country code

Afar

Abkhazian

Afrikaans

Amharic

Arabic

Assamese

Aymara

Azerbaijani

Bashkir

Byelorussian

Bulgarian

Bihari

Bislama

Bengali;Bangla

Tibetan

Breton

Catalan

Corsican

Czech

Welsh

Danish [DAN]

German [GER]

Bhutani

Greek [GRE]

English [ENG]

Esperanto

Spanish [SPA]

Estonian

Basque

Persian

Finnish [FIN]

Fiji

Faroese

French [FRE]

Frisian

Irish [IRI]

Scots Gaelic

Galician

Guarani

Gujarati

Hausa

Hindi

Croatian

Hungarian [HUN]

Armenian

Interlingua

Interlingue

Inupiak

Indonesian

Icelandic [ICE]

Italian [ITA]

Hebrew

Japanese

Yiddish

Japanese [JPN]

Georgian

Kazakh

Greenlandic

Cambodian

Kannada

Korean [KOR]

Kashmiri

Kurdish

Kirghiz

Latin

Lingala

Laothian

Lithuanian

4747

4748

4752

4759

4764

4765

4771

4772

4847

4851

4853

4854

4855

4860

4861

4864

4947

4961

4965

4971

5047

5051

5072

5158

5160

5161

5165

5166

5167

5247

5255

5256

5261

5264

5271

5347

5350

5358

5360

5367

5447

5455

5464

5467

5471

5547

5551

5557

5560

5565

5566

5569

5647

5655

5669

5747

5757

5758

5759

5760

5761

5765

5767

5771

5847

5860

5861

5866

100

101

102

103

104

105

106

107

108

109

110

111

112

113

114

115

116

117

118

119

120

121

122

123

124

125

126

127

128

129

130

131

132

133

134

135

136

No. Language Country code

Latvian;Lettish

Malagasy

Maori

Macedonian

Malayalam

Mongolian

Moldavian

Marathi

Malay

Maltese

Burmese

Nauru

Nepali

Dutch [DUT]

Norwegian [NOR]

Occitan

(Afan)Oromo

Oriya

Panjabi

Polish

Pashto;Pushto

Portuguese [POR]

Quechua

Rhaeto-Romance

Kirundi

Romanian [RUM]

Russian [RUS]

Kinyarwanda

Sanskrit

Sindhi

Sangho

Serbo-Croatian

Singhalese

Slovak

Slovenian

Samoan

Shona

Somali

Albanian

Serbian

Siswat

Sesotho

Sundanese

Swedish [SWE]

Swahili

Tamil

Telugu

Tajik

Thai

Tigrinya

Tu r km e n

Tagalog

Setswana

Tonga

Tu r kish [TUR]

Tsonga

Tatar

Twi

Ukrainian

Urdu

Uzbek

Vietnamese

Volapuk

Wolof

Xhosa

Yo r u b a

Chinese [CHI]

Zulu

5868

5953

5955

5957

5958

5960

5961

5964

5965

5966

5971

6047

6051

6058

6061

6149

6159

6164

6247

6258

6265

6266

6367

6459

6460

6461

6467

6469

6547

6550

6553

6554

6555

6557

6558

6559

6560

6561

6563

6564

6565

6566

6567

6568

6569

6647

6651

6653

6654

6655

6657

6658

6660

6661

6664

6665

6666

6669

6757

6764

6772

6855

6861

6961

7054

7161

7254

7267

If you choose a Language that has a 3 letter language code, the code will be displayed everytime you change the

Audio or Subtitle language setting on pages 21 and 22. If you choose any other languages, ‘---’ will be displayed

instead. (3 letter language code is written in bracket.)

TD503_36-55 02.2.26 10:13 AM Page 51

–52 –EN

01A11

Sometimes a performance problem can be easily solved by checking seemingly apparent but often overlooked

possibilities. Before arranging for service, check these items. It could save your time and money.

TV/VCR

TROUBLESHOOTING GUIDE

PROBLEM CORRECTIVE ACTION

No power. •Make sure the AC cord is connected to an AC outlet.

•Make sure the power is turned on.

Remote Control Doesn’t Work •Is TV/DVD/VHS plugged in?

•Power at outlet?

•Check batteries in Remote Control.

No picture and sound. •Make sure the AC cord is connected to an AC outlet.

•Check antenna connection.

•Let the TV/DVD/VHS program its tuner memory.

No picture or poor picture on •Adjust direction or replace antenna.

TV/DVD/VHS. •Adjust picture controls.

No sound or poor sound. •Adjust volume control on remote control or main unit.

•Press the MUTE button to restore sound.

Bars On Screen •If outside antenna is being used, check for broken wire.

•Check for local interference.

Picture Distorted or Blurred •Try a new channel, if OK, then possible station trouble.

•If outside antenna is being used, check for broken wire.

Picture Rolls Vertically •Try a new channel, if OK, then possible station trouble.

Lines or Streaks in Picture •If outside antenna is being used, check for broken wire.

•Check for local interference.

No Color •Try a new channel, if OK, then possible station trouble.

•Is antenna connected to terminal on the back of the set?

•If outside antenna is being used, check for broken wire.

•Adjust COLOR control.

Poor Reception on Some Channels •Try a new channel, if OK, then possible station trouble.

Ghosts in Picture •Is antenna connected to terminal on the back of the set?

•If outside antenna is being used, check for broken wire.

•Check for local interference.

Weak Picture •Try a new channel, if OK, then possible station trouble.

•Is antenna connected to terminal on the back of the set?

•If outside antenna is being used, check for broken wire.

•Adjust CONTRAST & BRIGHT control.

Sound OK, Picture Poor •Try a new channel, if OK, then possible station trouble.

•Is antenna connected to terminal on the back of the set?

•If outside antenna is being used, check for broken wire.

•Check for local interference.

•Adjust CONTRAST & BRIGHT control.

Picture OK, Sound Poor •Try a new channel, if OK, then possible station trouble.

•Check for local interference.

Timer recording is not possible. •Make sure the timer recording is set correctly.

•Make sure the power is off.

•Make sure the TV/DVD/VHS clock is set correctly.

Cannot go into Record mode. •Make sure the tape has an erase-prevention tab. If need, cover the

•hole with plastic tape.

TD503_36-55 02.2.26 10:13 AM Page 52

–53 –EN

01A11

CLOSED CAPTION PROBLEM POSSIBLE REMEDY

My TV/DVD/VHS is showing • You are watching a live broadcast and spelling errors made by the

captions that are misspelled. •closed captioning production company may pass through uncorrected.

•Aprerecorded program will not show any misspelled words because

• of the normal time available for editing the captions.

My TV/DVD/VHS will not show • Captions that are delayed a few seconds behind the actual

the text dialogue are common for live broadcast. Most captioning production

in its entirety or there is a delay of •companies can display a dialogue to a maximum of 220 words

what is being said. •per minute. If a dialogue exceeds that rate, selective editing is used

•to insure that the captions remain up-to-date with the current

•TV screen dialogue.

My captions are scrambled with • Interference caused by building, power lines, thunderstorms, etc.

white boxes on the TV screen. •may cause scrambled or incomplete captions to appear.

My program guide listed a TV show

• Broadcasters may at times use a time compression process to speed

as being closed captioned but none •up the actual program so that additional advertising time can be

of the captions were displayed. •given. Since the decoder cannot read the compressed information,

•captions will be lost.

My prerecorded video tape does not

• The video tape was either an illegal copy or the tape duplicating

show any captions. The tape box •company accidentally left out the captioning signals during the

mentions it being closed captioned. •copying process.

My TV screen shows a black box • You are in the TEXT mode. Select CAPTION mode to CAPTION

on certain channels. •[OFF].

Playback picture is partially noisy. •Adjust tracking control for a better picture using the CHANNEL K

•or Lbutton on the TV/DVD/VHS.

No picture but the audio is OK in •Head cleaning may be necessary. Refer to “AUTO HEAD

playback. •CLEANING” on page 53.

No operation by infrared Remote •Make sure the AC cord is connected to an AC outlet.

Control. •Check batteries in remote control.

Video or color fades in and out •You can not copy a copyrighted video tape. You are experiencing

when making a copy of a video tape

.•copy guard protection.

Uneven color •Unplug the AC cord for about 30 minutes, then plug it again.

PROBLEM CORRECTIVE ACTION

TD503_36-55 02.2.26 10:13 AM Page 53

–54 –EN

01A11

Symptom Cause Remedy

No power. •Loose power plug. •

Insert the power plug firmly into the wall out let

The player does not •The remote control is not aimed •Aim the remote control directly at the sensor

respond to the •at the sensor on the TV/DVD. •on the TV/DVD.

remote control. •Obstacles present between the •Remove the obstacles from the signal path.

•remote control and the sensor.

•The remote control is too far •Use the remote control within 7m of

•away from the TV/DVD. •the TV/DVD.

•Dead batteries. •Replace the batteries.

No picture •Loose video connection. •Connect the video cables firmly.

•Wrong disc. •Insert a correct video disc that plays on this

•TV/DVD.

Disc cannot be •No disc. •Insert a disc.

played •Dirty disc. •Clean the disc.

•Disc is placed upside down. •Place the disc correctly, with the label side up.

•Parental lock is active. •

Cancel the parental lock or change the control level.

No sound •Loose audio connection. •Connect the audio cables firmly.

•The power of the connected •Turn the power of the audio component on.

•audio component is off.

•Wrong audio output settings. •Correct the audio output settings.

•Wrong input settings on the •Correct the input settings on the audio

•connected audio component. •component.

•Copy protection is active. •Connect the player directly to the TV.

•Immediately after playing, •There are some cases where pictures may be

•press fast forward or in reverse. •slightly distorted, which are not a sign of a

Distorted picture •The 1st layer is switching to the •malfunction.

•2nd layer, when playing a two •Although Pictures may stop for a moment,

•layered disc. •this is not a malfunction.

Audio or subtitle •The selected language is not •No malfunction.

language does not •available for audio or subtitles

match the setup. •on the DVD.

The camera angle •The DVD does not contain •No malfunction.

cannot be changed. •sequences recorded from

•different camera angles.

Audio or subtitle •The DVD does not contain •No malfunction.

language cannot be •audio source or subtitles in the

changed. •selected language.

"Prohibited icon"

•That operation is prohibited by •No malfunction.

appears on the screen,

•the TV/DVD or disc.

prohibiting an operation

CD sound dropout •Scratched disc •Replace the disc with unscratched one.

No CD reproduction

DVD picture dropout

DVD picture freeze

DVD picture in mosaic

No DVD reproduction

NOTES:

•Some functions are not available in specific modes, but this is not a malfunction. Read the description in

this Owner’s Manual for details on correct operations.

•Playback from a desired track and random playback are not available during program playback.

If the TV/DVD does not perform properly when operated as instructed in this Owner’s Manual, check the

player, consulting the following checklist.

DVD

TD503_36-55 02.2.26 10:13 AM Page 54

–55 –EN

01A11

CABINET CLEANING

•Wipe the front panel and other exterior surfaces of

the TV/DVD with a soft cloth immersed in luke-

warm water and wrung dry.

•Never use a solvent or alcohol. Do not spray insec-

ticide liquid near the TV/DVD. Such chemicals

may cause damage and discoloration to the

exposed surfaces.

AUTO HEAD CLEANING

•Automatically cleans video heads as you insert or

remove a cassette, so you can see a clear picture.

•Playback picture may become blurred of interrupt-

ed while the TV program reception is clear. Dirt

accumulated on the video heads after long periods

of use, or the usage of rental or worn tapes can

cause this problem.

If a streaky or snowy picture appears during play-

back, the video heads in your TV/DVD/VHS may

need to be cleaned.

1.Please visit your local Audio/Video store and pur-

chase a good quality VHS Video Head Cleaner.

2.If a Video Head Cleaner does not solve the prob-

lem, please call our help line at 1-800-968-3429, to

locate an Authorized Service Center.

NOTES:

•Remember to read the instructions included with

the video head cleaner before use.

•Clean video heads only when problems occur.

SERVICING

•Should your TV/DVD become inoperative, do not

try to correct the problem by yourself. There are no

user-serviceable parts inside. Turn off, unplug the

power cord, and please call our help line at 1-800-

256-2487, to locate an Authorized Service Center.

IF THE LASER OPTICAL PICKUP UNIT IS DIRTY

•If the player still does not perform properly when it is operated while referring to the relevant sections and to

"TROUBLESHOOTING GUIDE" in this Owner's Manual, the laser optical pickup unit may be dirty. Consult

your dealer or an Authorized Service Center for inspection and cleaning of the laser optical pickup unit.

•Use discs which have the following logos on them.

(Optical audio digital discs.)

•Handle the discs so that fingerprints and dust do

not adhere to the surfaces of the discs.

•Always store the disc in its protective case when it

is not used.

DISC HANDLING

•To clean-off, use a soft cloth.

•Do not use a hard cloth since this will mar the disc.

•Wipe the disc in a straight line from center to edge.

•Never wipe with a circular motion.

•Do not use detergent or abrasive cleaning agents.

MAINTENANCE

TD503_36-55 02.2.26 10:13 AM Page 55

–56 –EN

01A11

CRT : 19 inch in-line gun, 90˚

deflection tube

Television system : NTSC-M

Closed caption system :§15.119/FCC

Video Heads : Rotary four-head

Tape width : 1/2 inch

Tape speed

SP : 33.40mm/sec.

LP : 16.67mm/sec.

SLP : 11.12mm/sec.

Tuner channel

TV VHF Low : #2~#6

TV VHF High : #7~#13

TV UHF : #14~#69

CATV

VHF : 5A

MID band : A5~A1, A~I

SUPER band : J~W

HYPER band : W+1~W+84

Product type: DVD Player

Discs: DVD video, Audio CD

Output signal format: NTSC color

Frequency response

(out put jack)

DVD (linear sound): 20 Hz to 22 kHz

(sample rate: 48 kHz)

20 Hz to 44 kHz

(sample rate: 96 kHz)

CD: 20 Hz to 20 kHz

Signal-to-noise ratio

(S/N ratio)(out put jack)

CD: 100 dB (EIAJ)

Dynamic range

(out put jack)

DVD (linear sound): 85 dB

CD: 84 dB (EIAJ)

Total distortion factor

CD: 0.07% (EIAJ)

Wow and flutter: Below the measurement

limitation (+/-0.001%

WPEAK) (EIAJ)

•Designs and specifications are subject to change without notice and without our legal obligation.

•If there is a discrepancy between languages, the default language will be English.

TV/VCR

DVD

GENERAL SPECIFICATIONS ELECTRICAL SPECIFICATIONS

Sound output: 2 speakers, 1W, 8 ohm

OTHER SPECIFICATIONS

Terminals

Antenna input: VHF/UHF/CATV

75 ohm unbalanced (F-type)

Video input: RCA connector [1

Audio L/R input: RCA connector [2

Headphone: 1/8” stereo (3.5 mm)

Coaxial digital

audio output: One pin jack,

500m Vpp (75 ohm)

Analog audio L/R

output : RCA connector [2

Remote control: Digital encoded

infrared light system

Operating

temperature: 5ºC to 40ºC

(41ºF~104ºF)

Power requirements: AC 120V, 60Hz

Power consumption

(Maximum): 85W

Picture tube: 19"

Dimensions: H:19-21/32” (500mm)

W:23-13/16” (605mm)

D:18-11/16” (475mm)

Weight: 48.5 lbs (22kg)

Accessories: Remote Control Unit with

2"AA"batteries

Owner’s Manual

SPECIFICATIONS

TD503_36-55 02.2.26 10:13 AM Page 56

–57 –EN

01A11

MEMO

TD503_36-55 02.2.26 10:13 AM Page 57

–58 –ES

1D18

INDICE

■ CONTROLES DE OPERACIÓN Y FUNCIONES . . . . . 58

PANEL FRONTAL DEL televisor/DVD/VHS . . . . . . . . . 58

MANDO A DISTANCIA . . . . . . . . . . . . . . . . . . . . . . . . . 58

VISTA POSTERIOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

■ PREPARACIÓN PARA LA UTILIZACIÓN . . . . . . . . . . 60

CONEXIONES DE ANTENA/TELEVISIÓN

POR CABLE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

INSTALACIÓN DE LAS PILAS. . . . . . . . . . . . . . . . . . . 60

CONEXIÓN A TOMAS DE ENTRADA EXTERNA. . . . 60

MODE DE ENTRADA EXTERNA. . . . . . . . . . . . . . . . . 60

CONEXIÓN A UN SISTEMA ESTÉREO (Para DVD) . . 60

CONEXIÓN A UN AMPLIFICADOR EQUIPADO CON

TOMAS DE ENTRADA DIGITAL PARA, POR EJEMPLO,

PLATINA MD O PLATINA DAT (Para DVD). . . . . . . . . 60

CONEXIÓN A UN DECODIFICADOR DOLBY DIGITAL,

DECODIFICADOR DTS O DECODIFICADOR MPEG

(Para DVD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

TV SECTION

■

PREPARACIÓN PARA LA UTILIZACIÓN

. . . . . . . . . . . . 62

SELECCIÓN DE IDIOMA . . . . . . . . . . . . . . . . . . . . . . . 62

PREAJUSTE DE CANALES. . . . . . . . . . . . . . . . . . . . . . 62

DVD SECTION

■ REPRODUCCIÓN DE UN DISCO . . . . . . . . . . . . . . . . 63

REPRODUCCIÓN DE UN DVD DE VÍDEO O UN CD DE

AUDIO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

CONTROLES DE

OPERACIÓN Y FUNCIONES

PANEL FRONTAL DEL

TELEVISOR/DVD

Consulte la figura 1 de la página 9

MANDO A DISTANCIA

Consulte la figura 2 de la página 9

VISTA POSTERIOR

Consulte la figura 3 de la página 10

1.Botón POWER

Púlselo para conectar y desconectar la alimentación.

2.Botones VOLUME X/Y

Púlselos para controlar el nivel del volumen para

el DVD y el televisor.

3.Botones SKIP (para DVD)

Salta capítulos o pistas hasta un punto deseado.

4.Botón PLAY

Inicia la reproducción del contenido del disco o la

cinta.

5.Botón STOP

Detiene la operación del disco o la cinta.

6.Botón OPEN/CLOSE

Púlselo para insertar discos en la bandeja o

retirarlos de ella.

7.Bandeja de carga del disco

8.Indicador de DVD

Parpadea durante el modo del DVD.

9.Botón SELECT

Púlselo para cambiar a un modo de televisor,

modo de entrada externa o modo de DVD.

10. Indicador del televisor/ la videograbadora

(TV/VCR)

Parpadea durante el modo del televisor/ la

videograbadora

11. Botones CHANNEL K/L

Púlselo para seleccionar el canal memorizado.

Púlselo para cambiar a un modo de televisor

cuando modo de DVD.

12. Indicador de grabación (RECORD)

Parpadea durante la grabación.

Se enciende en el modo de espera de la grabación con

temporizador.

Botón de grabación de un toque (OTR)

Activa la grabación de un toque. (Sólo en el televi-

sor/DVD/VHS)

13. Botón de grabación (REC)

Púlselo para iniciar la grabación manual.

14. Botón de rebobinado (REW) (para televisor/

videograbadora)

Púlselo para rebobinar la cinta, o para ver la imagen en

retroceso rápido durante el modo de reproducción.

(Búsqueda con rebobinado)

15. Botón de avance rápido (FWD) (para televisor/

videograbadora)

Púlselo para avanzar rápidamente la cinta, o para ver la

imagen en avance rápido durante el modo de reproduc-

ción. (Búsqueda con avance rápido)

16. Botón de parada (STOP)

Púlselo para detener la cinta.

Botón de expulsión (EJECT)

Púlselo en el modo de parada para expulsar la cinta del

televisor/videograbadora.

17. Ventanilla del sensor del mando a distancia

18. Toma HEADPHONE

Para conectar auriculares (no suministrados) y

escuchar en privado.

19. Toma de entrada VIDEO

Conecte aquí la toma de salida de vídeo de una

videocámara o de una videograbadora.

20. Tomas de entrada AUDIO L/R

Conecte aquí las tomas de salida de audio de una

videocámara o de una videograbadora.

21. Compartimiento del videocasete

22. Botón PICTURE

Presione para entrar en el modo de ajuste de ima-

gen.

TD503UDES 02.2.26 10:14 AM Page 58

–59 –ES

1D18

23. Botones de números

Modo del televisor:

Pulse dos dígitos para tener acceso directamente

al canal deseado.

Recuerde pulsar "0" antes de elegir un canal de un

solo dígito.

Botón +100

Púlselo para seleccionar canales de televisión por

cable cuyo número sea igual o superior al 100.

Modo DVD:

Púlselo para introducir el número deseado.

Botón +10

Púlselo para introducir los números deseados

cuyo número sea igual o superior al 10.

24. Botón PAUSE

Hace una pausa en la operación del disco o la

cinta.

25. Botón de velocidad de cinta (SPEED)

Púlselo para elegir la velocidad de grabación deseada:

SP/SLP.

26. Botón C-RESET

Púlselo para reponer el contador a 0:00:00.

27. Botón DISPLAY

Modo del televisor/ la videograbadora:

Púlselo para visualizar el número del canal en la

pantalla. Si lo pulsa de nuevo, el número del canal

desaparecerá.

Modo de DVD:

Visualiza el estado actual en la pantalla del televi-

sor con fines de comprobación.

28. Botón SETUP

Púlselo para activar o salir del modo de menús de

televisor o preparación de DVD.

29. Botón TITLE

Visualiza el menú de títulos.

30. Botón CLEAR

Repone un ajuste.

31. Botón MODE

Activa el modo de reproducción programada o el

modo de reproducción aleatoria.

32. Botón SEARCH MODE

Púlselo para localizar un punto deseado.

33. Botón AUDIO

Púlselo para seleccionar un idioma de audio o un

modo de sonido deseado.

34. Botón SUBTITLE

Púlselo para seleccionar un idioma de subtítulos

deseado.

35. Botón REPEAT

Repite la reproducción del disco, título, capítulo o

pista actual.

36. Botón ANGLE

Púlselo para cambiar el ángulo de la cámara y

verde, desde un ángulo diferente, la secuencia que

está siendo reproducida.

37. Botón A-B REPEAT

Repite la reproducción de una sección seleccionada.

38. Botón RETURN

Para volver a la operación anterior.

39. Botón ENTER

Púlselo para establecer un ajuste.

40. Botones de flechas

Modo de televisor:

Púlselo para seleccionar un modo de ajuste desde

el menú que aparece en la pantalla del televisor.

Púlselo para seleccionar o ajustar desde un menú

particular.

Modo de DVD:

Se utiliza cuando se hacen ajustes mientras se

observa la visualización en una pantalla de televisor.

41. Botón DISC MENU

Visualiza menús de DVD.

42. Botón ZOOM

Amplia parte de una imagen de DVD reproducida.

43. Botón MUTE

Pulse el botón MUTE para apagar el sonido de un

programa de TV. La visualización del nivel del

sonido cambia de ROJO CLARO a AZUL

CLARO.) Pulse de nuevo el botón MUTE o el

botón VOL Ko Lpara restaurar el sonido.

44. Botón SLEEP

Ajusta el temporizador para dormir.

45. Botón SELECT

Pulse para cambiar entre los modos TV/VCR y

DVD. Podrá ver el modo (TV/VCR o DVD) en el

indicador del panel delantero.

46. Toma de entrada ANT.

Conéctela a una antena, sistema de televisión por

cable o sistema de satélite.

47. Cable de alimentación

Conéctelo a una toma de CA convencional (120

V/60 Hz).

NOTA: Retire el cable de alimentación del gancho

para evitar romperlo antes de conectarlo a

una toma de CA convencional.

48. Toma de salida de audio digital COAXIAL

Conéctela a la entrada digital de un amplificador o

decodificador externo.

49. Toma de salida AUDIO L/R

Conéctela a la entrada de audio analógico de un

amplificador o decodificador externo.

NOTA:Las tomas de entrada de audio (roha y

blanca) en el lado trasero sirven para pro-

ducir no el son televisor ni el son de

entrada externa, sino el son DVD.

TD503UDES 02.2.26 10:14 AM Page 59

–60 –ES

1D18

fuente a las tomas AUDIO L/R y VIDEO de este tele-

visor/DVD/VHS. Y luego pulse el botón SELECT

hasta que "VIDEO" aparezca en la pantalla.

NOTA:

•Cuando conecte una videograbadora monoaural

(otra fuente) a este televisor/DVD/VHS, conecte la

toma de salida de audio de la videograbadora

monoaural (otra fuente) a la toma AUDIO L de este

televisor/DVD/VHS. El audio saldrá igualmente en

los canales L y R.

Conexiones de antena/televisión por cable

Continúa en la página siguiente.

Cuando utilice una señal de entrada externa (otra

videograbadora o una videocámara), conecte los

cables de salida de audio/vídeo del equipo de repro-

ducción a las tomas AUDIO IN/VIDEO IN de su

televisor/videograbadora. Y luego pulse el botón

CHANNEL Ko Lhasta que “AUX” aparezca en la

pantalla.

Usted puede programar el temporizador para que

explore todos los canales que puedan recibirse en su

zona.

NOTAS:

•Asegúrese de desconectar la alimentación a todos

los componentes del sistema antes de hacer la

conexión a otro componente.

•Consulte el manual del propietario de su sistema

estéreo y de cualquier otro componente que vaya a

conectar al televisor/DVD/VHS.

•Las tomas de entrada de audio (roha y blanca) en el

lado trasero sirven para producir no el son televisor

ni el son de entrada externa, sino el son DVD.

Utilice un cable digital coaxial (de venta en el comer-

cio) para las conexiones de audio.

Consulte la figura 7 de la página 13

Consulte la figura 6 de la página 13

CONEXIÓN A UN SISTEMA

ESTÉREO (Para DVD)

MODO DE ENTRADA EXTERNA

Consulte la figura 5 de la página 12

ANTENAS SEPARADAS DE VHF/UHF

En algunas áreas será necesario utilizar una antena

exterior.

TELEVISIÓN POR CABLE SIN CAJA DE

CONVERTIDOR/DECODIFICADOR

Utilice esta conexión si su sistema de televisión por

cable se conecta directamente a su

televisor/DVD/VHS sin necesidad de caja de conver-

tidor.

Consulte la figura 4 de la página 11

CONEXIONES DE ANTENA/

TELEVISIÓN POR CABLE

PREPARACIÓN PARA LA

UTILIZACIÓN

TELEVISIÓN POR CABLE CON CAJA

DE CONVERTIDOR/DECODIFICADOR

O CAJA DE SATÉLITE

Si su proveedor de servicios de televisión por cable le

suministra una caja de convertidor o si usted utiliza

un sistema de satélite, podrá utilizar la conexión bási-

ca mostrada aquí.

1) Abra la tapa del compartimiento de las pilas del

mando a distancia presionándola en el sentido de

la flecha.

2) Inserte 2 pilas tamaño "AA" en su compartimiento

colocando las polaridades (+/-) en sus posiciones

correspondientes.

3) Vuelva a poner la tapa.

Cuando vea un programa grabado en otra fuente

(videograbadora o videocámara), utilice las tomas de

entrada de audio/vídeo de la parte delantera del tele-

visor/DVD/VHS.

Conecte las tomas de salida de audio/vídeo de otra

CONEXIÓN A TOMAS DE

ENTRADA EXTERNA

INSTALACIÓN DE LAS PILAS

Consulte la figura 4 de la página 11

CONEXIÓN A UN

AMPLIFICADOR EQUIPADO

CON TOMAS DE ENTRADA

DIGITAL PARA, POR EJEMPLO,

PLATINA MD O PLATINA DAT

(Para DVD)

TD503UDES 02.2.26 10:14 AM Page 60

–61 –ES

1D18

Fabricado bajo licencia de Dolby

Laboratories. “Dolby” y el símbolo de la D

doble son marcas de fábrica de Dolby

Laboratories. Trabajos confidenciales sin

publicar.

“DTS” y “DTS Digital Out” son marcas de

fábrica de Digital Theater Systems, Inc.

NOTAS:

•La fuente de audio de un disco del formato de

sonido ambiental Dolby Digital de 5,1 canales no

puede ser grabada como sonido digital por una

platina MD o DAT.

•Asegúrese de desconectar la alimentación de todos

los componentes del sistema antes de hacer la

conexión a otro componente.

•Consulte los manuales del propietario de los com-

ponentes que vaya a conectar al

televisor/DVD/VHS.

•Ponga DOLBY DIGITAL y DTS en OFF para la

salida de audio en el modo de preparación. La

reproducción en el televisor/DVD/VHS utilizando

los ajustes incorrectos puede generar distorsión de

ruido, y también puede estropear los altavoces.

•El audio se silenciará cuando DOLBY DIGITAL se

ponga en OFF y VIRTUAL 3D se ponga en ON

para la salida de audio en el modo de preparación y

usted seleccione la fuente de audio del formato de

sonido ambiental Dolby Digital de 5,1 canales.

Si se utiliza este televisor/DVD/VHS para reproducir

fuentes del formato de sonido ambiental Dolby

Digital de 5,1 canales o de sonido ambiental DTS, el

televisor/DVD/VHS dará salida a un flujo de datos

Dolby Digital o DTS desde su toma de salida de

audio digital COAXIAL. Conectando el reproductor a

un decodificador Dolby Digital o DTS, usted podrá

disfrutar de un ambiente más convincente y real con

un sonido ambiental potente y de alta calidad de tipo

profesional tal como el que se oye en salas de cine.

Utilice cables digitales coaxiales (de venta en el com-

ercio) para las conexiones de audio.

NOTAS:

•Asegúrese de desconectar la alimentación de todos

los componentes del sistema antes de hacer la

conexión a otro componente.

•Consulte los manuales del propietario de los com-

ponentes que vaya a conectar al

televisor/DVD/VHS.

•Si conecta un decodificador Dolby Digital, ponga

DOLBY DIGITAL en ON para la salida de audio

en el modo de preparación.

•Si conecta un decodificador DTS, ponga DTS en

ON para la salida de audio en el modo de

preparación.

Consulte la figura 8 de la página 14

CONEXIÓN A UN

DECODIFICADOR DOLBY

DIGITAL, DECODIFICADOR

DTS O DECODIFICADOR

MPEG (Para DVD)

•Amenos que se haga la conexión a un decodifi-

cador Dolby Digital o DTS, ponga DOLBY DIGI-

TALy DTS en OFF para la salida de audio en el

modo de preparación. La reproducción en el televi-

sor/DVD/VHS utilizando los ajustes incorrectos

puede generar distorsión de ruido, y también puede

estropear los altavoces.

•El audio se silenciará cuando DOLBY DIGITAL se

ponga en OFF y VIRTUAL 3D se ponga en ON

para la salida de audio en el modo de preparación y

usted seleccione la fuente de audio del formato de

sonido ambiental Dolby Digital de 5,1 canales.

TD503UDES 02.2.26 10:14 AM Page 61

–62 –ES

1D18

Conecte el cable de alimentación a una toma de CA

convencional.

NOTA: Si aparecen algunos dígitos en la esquina de

la pantalla, pulse el botón POWER sin des-

enchufar el cable de alimentación.

Pulse el botón POWER para encender el

televisor/DVD/VHS.

Seleccione "ESPAÑOL" o "ENGLISH" (inglés),

"FRANÇAIS" (francés) utilizando el botón de flecha

Bo s.

Pulse el botón flecha Ko Lpara señalar “AUTOP-

RESELECCION”.

Luego pulse el botón flecha B. El sintonizador

explorará y memorizará todos los canales activos de

su área.

NOTAS:

•El televisor/videograbadora distingue entre los

canales de televisión estándar y los canales de tele-

visor por cable.

•Si desea reproducir o grabar una cinta ANTES de

preajustar el sintonizador, usted tendrá que pulsar

el botón SETUP en el mando a distancia. Para

preajustar de nuevo el sintonizador, consulte

“REPETICIÓN DE LA PREPARACIÓN DE

CANALES”.

•La unidad de televisor/videograbadora puede

reconocer los canales de TV como ellos de TV por

cable a causa de los condiciones de recepción. En

este caso, pruebe el preajuste automático de nuevo

en los condiciones finas de recepción.

El sintonizador se para en el canal memorizado más

bajo. Si desea recuperar canales seleccionados, usted

podrá seleccionar directamente el canal deseado con

los botones numerados del mando a distancia o con

los botones CHANNEL Ko L.

PREPARACIÓN DE CANALES

POR PRIMERA VEZ

TV SECTION

PREPARACIÓN PARA LA

UTILIZACIÓN

Cerciórese...

•La alimentación del televisor/videograbadora

deberá estar conectada.

En el ejemplo de abajo, el reloj va a ajustarse así:

FECHA: 1 de mayo de 2001

HORA: 5:40 PM

Pulse el botón SETUP en el mando a distancia.

Pulse el botón PLAY/Ko STOP/Lpara indicar

“AJUSTE RELOJ”. Luego, pulse el botón F.FWD/B.

Pulse el botón PLAY/Ko STOP/Lpara indicar

“AJUSTE MANUAL RELOJ”. Luego, pulse el botón

F.FWD/B.

Pulse el botón PLAY/Ko STOP/Lhasta que aparez-

ca el mes deseado. (Ejemplo: Mayo - 05) Luego,

pulse el botón F.FWD/B.

Pulse el botón PLAY/Ko STOP/Lhasta que aparez-

ca el día del mes deseado. (Ejemplo: 1 - 01) Luego,

pulse el botón F.FWD/B.

Pulse el botón PLAY/Ko STOP/Lhasta que aparez-

ca el año deseado. (Ejemplo: 2001) Luego, pulse el

botón F.FWD/B.

Pulse el botón PLAY/Ko STOP/Lhasta que aparez-

ca la hora deseada. (Ejemplo: 5, PM) Luego, pulse el

botón F.FWD/B.

Pulse el botón PLAY/Ko STOP/Lhasta que aparez-

ca el minuto deseado. (Ejemplo: 40)

Pulse el botón SRTUP en el mando a distancia.

Aunque los segundos no se visualizan, éstos

empiezan a contar desde 00 cuando se pulsa SETUP

en el mando a distancia. Utilice esta función para sin-

cronizar el reloj con la hora correcta.

AJUSTE DEL RELOJ

TD503UDES 02.2.26 10:14 AM Page 62

–63 –ES

1D18

REPRODUCCIÓN DE UN DVD

DE VÍDEO O UN CD DE AUDIO

Para empezar

Conecte la alimentación del televisor, amplificador y

cualquier otro componente que esté conectado al

reproductor DVD. (Cambie el sistema de entrada para

adaptarlo al reproductor DVD, y compruebe que el

volumen del sonido sea correcto.)

1 Pulse el botón POWER.

¡La alimentación se conectará.

2 Pulse el botón OPEN/CLOSE.

¡La bandeja de carga del disco se abrirá.

3 Ponga un disco en la bandeja.

¡Asegúrese de que el disco esté correctamente asen-

tado en el hueco correcto, con el lado de la etiqueta

hacia arriba.

4 Pulse el botón PLAY.

¡La bandeja se cerrará automáticamente y la repro-

ducción empezará desde el primer capítulo o pista

del disco. Necesitará pulsar el botón PLAY sólo

cuando la bandeja haya sido cerrada pulsando el

botón OPEN/CLOSE.

¡Cuando reproduzca un DVD que tenga grabado un

menú de títulos, el menú tal vez aparezca en la pan-

talla. En este caso, consulte "UTILIZACIÓN DEL

MENÚ DE TÍTULOS".

Pulse el botón STOP para detener la reproducción.

CDDVD

REPRODUCCIÓN DE UN

DISCO

DVD SECTION

TD503UDES 02.2.26 10:14 AM Page 63

Printed in Malaysia 0EMN01954

TD503UD ★★★★★

LIMITED WARRANTY

FUNAI CORP. will repair this Emerson product, free of charge in the USA in the event of defect in materials or

workmanship as follows:

DURATION:

PARTS: FUNAI CORP. will provide parts to replace defective parts without charge for one (1) year from the

date of original retail purchase. Two (2) years for Picture Tube. Certain parts are excluded from this

warranty.

LABOR: FUNAI CORP. will provide the labor without charge for a period of ninety (90) days from the date

of original retail purchase.

LIMITS AND EXCLUSIONS:

This warranty is extended only to the original retail purchaser. A purchase receipt or other proof of original retail

purchase will be required together with the product to obtain service under this warranty.

This warranty shall not be extended to any other person or transferee.

This warranty is void and of no effect if any serial numbers on the product are altered, replaced, defaced, missing

or if service was attempted by an unauthorized service center. This FUNAI CORPORATION Limited warranty does

not apply to any product not purchased and used in the United States.

This warranty only covers failures due to defects in material or workmanship which occurs during normal use. It

does not cover damage which occurs in shipment, or failures which are caused by repairs, alterations or product not

supplied by FUNAI CORP., or damage which results from accident, misuse, abuse, mishandling, misapplication,

alteration, faulty installation, improper maintenance, commercial use such as hotel, rental or office use of this

product or damage which results from fire, flood, lightning or other acts of God.

THIS WARRANTY DOES NOT COVER PACKING MATERIALS, ANY ACCESSORIES (EXCEPT REMOTE

CONTROL), ANY COSMETIC PARTS, COMPLETE ASSEMBLY PARTS, DEMO OR FLOOR MODELS.

FUNAI CORP. AND ITS REPRESENTATIVES OR AGENTS SHALL IN NO EVENT BE LIABLE FOR ANY

GENERAL, INDIRECT OR CONSEQUENTIAL DAMAGES ARISING OUT OF OR OCCASIONED BY THE

USE OF OR THE INABILITY TO USE THIS PRODUCT. THIS WARRANTY IS MADE IN LIEU OF ALL

OTHER WARRANTIES, EXPRESS OR IMPLIED, AND OF ALL OTHER LIABILITIES ON THE PART OF

FUNAI, ALL OTHER WARRANTIES INCLUDING THE WARRANTY OF MERCHANTABILITY, AND

FITNESS FOR A PARTICULAR PURPOSE, ARE HEREBY DISCLAIMED BY FUNAI AND ITS

REPRESENTATIVES IN THE UNITED STATES.

ALL WARRANTY INSPECTIONS AND REPAIRS MUST BE PERFORMED BY A FUNAI AUTHORIZED

SERVICE CENTER. THIS WARRANTY IS VALID WHEN THE UNIT IS CARRIED-IN TO FUNAI

AUTHORIZED SERVICE FACILITY.

IMPORTANT:

THIS LIMITED WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, YOU MAY HAVE OTHER RIGHTS

THAT VARY FROM STATE TO STATE, IF, AT ANY TIME DURING THE WARRANTY PERIOD, YOU ARE

UNABLE TO OBTAIN SATISFACTION WITH THE REPAIR OF THIS PRODUCT, PLEASE CONTACT FUNAI

CORP.

ATTENTION:

FUNAI CORP. RESERVES THE RIGHT TO MODIFY ANY DESIGN OF THIS PRODUCT

WITHOUT PRIOR NOTICE.

To locate your nearest Emerson Authorized Service Center or for general service procedure, please

call 1-800-256-2487 or write to the following:

FUNAI CORPORATION, INC.

Customer Service

100 North Street; Teterboro, NJ 07608

Tel :1-800-256-2487

PLEASE DO NOT SHIP YOUR UNIT TO THE TETERBORO ADDRESS.

TD503_36-55 02.2.26 10:13 AM Page 64

Emerson Ewc19T2 Owners Manual TD503_01 36

Navigation menu

Versions of this User Manual:

Views

Navigation
