Type EZR with Type 6358B Relief Pilot

E0220

INLET PRESSURE

OUTLET PRESSURE

ATMOSPHERIC PRESSURE

July 2008 Type EZR

LOADING PRESSURE

A - VENT (TO ATMOSPHERE OR DOWNSTREAM PIPING)

C - TO TYPE EZR LOADING CHAMBER

D - PILOT SUPPLY (FROM UPSTREAM)

C

D

A
