Type 1098-EGR with Type Y600AM Pilot

M1008

INLET PRESSURE

OUTLET PRESSURE

LOADING PRESSURE

PILOT SUPPLY PRESSURE

ATMOSPHERIC PRESSURE

February 2007 Type 1098-EGR

95 SERIES

TYPE Y600AM

FIXED RESTRICTOR

OPTIONAL:

TYPE 112

RESTRICTOR
