OWNER'S MANUAL
MS9923TT
HOME AUDIO SYSTEM
with 5 CD CHANGER,
3 SPEED TURNTABLE,
DUAL CASSETTE DECK
and REMOTE CONTROL
Visit our web site at www.emersonradio.com
MS9923TT_B022806.p65 28/2/2006, 9:4437
1
TO PREVENT FIRE OR SHOCK HAZARD, DO NOT USE THIS PLUG WITH AN
EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES
CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE. TO PREVENT FIRE
OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
IMPORTANT SAFETY INSTRUCTIONS
1.) Read these instructions. Keep these instructions. Follow all instructions. Heed all warnings.
2.) Do not use this apparatus near water.
3.) Clean only with dry cloth.
4.) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
5.) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
6.) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two
blades with one wider than the other. A grounding type plug has two blades and a third grounding
prong. The wide blade or the third prong is provided for your safety. If the provided plug does not
fit into your outlet, consult an electrician for replacement of the obsolete outlet.
7.) Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
8.) Only use attachments / accessories specified by the manufacturer.
9.) Unplug this apparatus during lightning storms or when unused for long periods of time.
10.) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has
been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
11.) This appliance shall not be exposed to dripping or splashing water and no object filled with liquids
such as vases shall be placed on the apparatus.
12.) Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-over.
13.) Do not overload wall outlet. Use only power source as indicated.
14.) Use replacement parts as specified by the manufacturer.
15.) The product may be mounted to a wall only if recommended by the manufacturer.
16.) Upon completion of any service or repairs to this product, ask the service technician to perform
safety checks.
!
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrow-
head symbol, within an equi-
lateral triangle is intended to
alert the user to the presence
of uninsulated ‘dangerous voltage’
within the product’s enclosure
that may be of sufficient
magnitude to constitute a risk
of electric shock to persons.
The exclamation point within
an equilateral triangle is in-
tended to alert the user to
the presence of important
operating and maintenance
(servicing) instructions in
the literature accompany-
ing the appliance.
WARNING: TO REDUCE THE
RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER
(OR B A CK), NO US E R
SERVICEABLE PARTS INSIDE
REFER SERVICING TO
QUALIFIED SERVICE
PERSONNEL.
CAUTION
The Caution Marking maybe located at the bottom enclosure of the apparatus.
MS9923TT_B022806.p65 28/2/2006, 9:441
2
Thank you……………
For purchasing this Emerson complete home audio system including a
stereo radio, 5 disc changer, dual cassette deck, stereo phonograph,
matching speakers, and remote control.
Please read this Owner’s Manual carefully and completely to make sure
that you get the maximum benefit out of all the outstanding features we’ve
included in this compact system. It’s designed to give you many years of
trouble free operation with an absolute minimum of care and maintenance.
Every component in this system was in perfect working order when it left
our factory. If you experience any problems with the set up or operation of
this system please do not return it to the retail store. Please call the Emerson
Customer Service Hotline toll free at 1-800-898-9020 and one of our service
technicians will attempt to diagnose and correct the problem for you.
Once again, thanks for purchasing this Emerson audio product.
MS9923TT_B022806.p65 28/2/2006, 9:442
3
•Avoid installing this unit in places exposed
to direct sunlight or close to heat radiating
appliances such as electric heaters, on top
of other stereo equipment that radiates too
much heat, places lacking ventilation or
dusty areas, places subject to constant
vibration and/ or humid or moist areas.
•Do not attempt to clean this unit with
chemical solvents as this might damage the
finish. Use a clean dry cloth.
CLASS 1 LASER PRODUCT
FCC Information
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
•Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
•Operate controls and switches as described
in the manual.
•Before turning ‘On’ the power, make certain
that power cord is properly installed.
•Store your CDs in a cool area to avoid
damage from heat.
•When moving the set, be sure to first
disconnect the power cord.
IMPORTANT NOTES
CLASS 1 LASER PRODUCT
APPAREIL Á LASER DE CLASSE 1
PRODUCTO LASER DE CLASE 1
CAUTION
INVISIBLE LASER RADIATION
WHEN OPEN AND INTERLOCKS
DEFEATED.
AVOID EXPOSURE TO BEAM
This product contains a low power Laser Device.
NOTE: This product complies with DHSS Rule 21 Subchapter J at date of manufacture.
MS9923TT_B022806.p65 28/2/2006, 9:443
4
SPEAKER CONNECTION
Connect each speaker to the corresponding speaker terminals on the back panel
of the main unit.
Make sure that the left speaker is connected to the left pair of speaker terminals
and the right speaker to the right pair of speaker terminals.
Also make sure that the speaker wires are correctly connected:
The red wires are connected to the red (+) terminals.
The black wires are connected to the black (–) terminals.
PREPARATION FOR USE
R
L
SPEAKERS : 4
RED
BLACK
Depress the plastic lever to open the terminal, insert the bare end of the speaker
wire into the opening and release.
Right SpeakerLeft Speaker
MS9923TT_B022806.p65 28/2/2006, 9:444
5
CONNECTING THE AC POWER CORD
After connecting the speakers unwind the AC power cord fully and connect it to any
convenient household AC outlet.
NOTE: This product is designed to operate on normal 120V 60Hz AC only.
Connecting this system to any other power supply could result in damage to
the unit which is not covered by your warranty.
You will note that this system is equipped
with a polarized AC power plug having one
blade wider than the other. This is a safety
feature. If this plug does not fit into your
existing AC outlet, do not try to defeat this
safety feature by filing the wide blade to
make it fit into your outlet. If this plug will
not fit into your outlet, you probably have
an out-dated non-polarized AC outlet. You
should have your outlet changed by a
qualified licensed electrician.
AC Plug
AC Outlet
MS9923TT_B022806.p65 28/2/2006, 9:445
6
PROTECT YOUR FURNITURE
This model is equipped with non-skid rubber 'feet' to prevent the product from
moving when you operate the controls. These 'feet' are made from non-migrating
rubber material specially formulated to avoid leaving any marks or stains on your
furniture. However certain types of oil based furniture polishes, wood preservatives,
or cleaning sprays may cause the rubber 'feet' to soften, and leave marks or a
rubber residue on the furniture. To prevent any damage to your furniture we strongly
recommend that you purchase small self-adhesive felt pads, available at hardware
stores and home improvement centers everywhere, and apply these pads to the
bottom of the rubber 'feet' before you place the product on fine wooden furniture.
MS9923TT_B022806.p65 28/2/2006, 9:446
7
LOCATION OF CONTROLS AND INDICATORS
PLAY
PLAY
REWIND
F. FWD
F.FWD
STOP/EJECT
STOP/EJECT
PAUSE PAUSE
RANDOM
INTRO
PLAY/PAUSE
MEMORY
MULTI-FUNCTION LCD DISPLAY
DISC
1
DISC
2
DISC
3
DISC
4
DISC
5
REMOTE
SENSOR
DIGITAL FILTER PROCESSING SYSTEM
REPEAT/MEM. UP
TUNING / SKIP / SEARCH
STOP/MEM. DOWN
4 BAND PRESET EQUALIZER
AM / FM DIGITAL TUNING
STANDBY
VOLUME
PRESET
EQUALIZER
RECORD
AUX/PHONO
TAPE
CD/DISC SKIP
TUNER/BAND
FM ST. - MONO /
HI-SPEED DUBBING
BASS BOOST
PHONES OPEN/
CLOSE
ROCK
POP FLAT
EQ
PLAYBACK
RECORD
AUTO STOP
PLAYBACK
BBS
5 COMPACT DISC
40 TRACK PROGRAM MEMORY
AUTOMATIC CHANGER
STANDBY
1
2
3
4
5
6
7
8
9
10
11
12
13 14 15 17 19 20
21
22
18
23
24
25
26
27
28
29
30
31
16
FRONT PANEL
MS9923TT_B022806.p65 28/2/2006, 9:447
8
1.)5 CD CHANGER Tray.
2.)Cassette DECK A Control Keys:
RECORD / PLAY / REWIND / F. FWD (Fast Forward) / STOP-EJECT / PAUSE.
3.)Cassette DECK A Compartment.
4.)REPEAT / MEM. UP Button.
5.)TUNING / SKIP SEARCH Button.
6.)INTRO Button.
7.)RANDOM Button.
8.)PHONES Jack.
9.)PRESET EQUALIZER (FLAT / CLASSIC / ROCK / POP) Buttons & Indicators.
10.)BASS BOOST Button.
11.)STANDBY Button.
12.)STANDBY Indicator.
13.)FM ST. – MONO / HI-SPEED DUBBING Button.
14.)BBS (Bass Boost) ‘On’ Indicator.
15.)REMOTE SENSOR.
16.)Turntable Dust Cover.
17.)MULTI-FUNCTION LCD DISPLAY.
18.)CD DISC 1, 2, 3, 4, 5 Select Buttons.
19.)TAPE Button.
20.)AUX / PHONO Button.
21.)CD / DISC SKIP Button.
22.)TUNER / BAND Button.
23.)VOLUME Up Button.
24.)CD Tray OPEN / CLOSE Button.
25.)VOLUME Down Button.
26.)CD PLAY / PAUSE Button.
27.)TUNING / SKIP SEARCH Button.
28.)STOP / MEM. DOWNN Button.
29.)MEMORY Button.
30.)Cassette DECK B Compartment.
31.)Cassette DECK B Control Keys:
PLAY / REWIND / F. FWD (Fast Forward) / STOP-EJECT / PAUSE.
MS9923TT_B022806.p65 28/2/2006, 9:448
9
32.)SPEAKER Terminals.
33.)FM Lead Wire Antenna.
34.)RESET Button (Inside pin hole).
35.)AUX IN (RIGHT/LEFT) Jacks.
36.)AC Power Cord.
BACK PANEL
16
32 34
35
36
33
MS9923TT_B022806.p65 28/2/2006, 9:449
10
REMOTE CONTROL
1.)TUNING Up/CD Skip Fwd Button.
2.)CD Play/Pause Button.
3.)TUNING Down/CD Skip Rev Button.
4.)CD Stop /MEMORY DOWNN Button.
5.)CD INTRO Button.
6.)MEMORY UP/REPEAT Button.
7.)MEMORY Button.
8.)OPEN/CLOSE Button.
9.)TUNER/BAND Button.
10.)TAPE Button.
11.)AUX/PHONO Button.
12.)POWER Button.
13.)MUTE Button.
14.)CD/DISC SKIP Button.
15.)RANDOM Button.
16.)REMAIN Button.
17.)VOLUME + Button.
18.)VOLUME – Button.
19.)Battery Compartment (Back Cabinet).
BATTERY INSTALLATION
1.)Open the battery compartment cover.
2.)Insert two "AA" (UM3) batteries (not included) to
match the polarities as indicated inside the
battery compartment.
3.)Close the cover.
VOLUME
MEMORY DOWN
TUNING
POWER
INTRO
REPEAT
REMAIN
MEMORY UP
TUNER
TAPE
AUX/PHONO
BAND
MEMORY OPEN/CLOSE
CD/TUNER CONTROL
RANDOM
CD MUTE
DISC SKIP
R
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
Battery Precautions
•Replacement of batteries must be done by an adult.
•Do not mix old and new batteries.
•Do not mix alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium)
batteries.
•The supply terminals are not to be short-circuited.
•Non-rechargeable batteries are not to be recharged.
•Exhausted batteries are to be removed.
•Only batteries of the equivalent type are to be used.
•Batteries are to be inserted with the correct polarity.
•Dispose of batteries properly. Do not dispose of batteries in fire. The batteries
may explode or leak.
MS9923TT_B022806.p65 28/2/2006, 9:4410
11
OPERATING INSTRUCTIONS
GENERAL CONTROLS
PRESET Electronic EQUALIZER
When the unit is switched ‘On’ for the first time, the Equalizer will be in the “Flat”
setting. Press the appropriate PRESET EQUALIZER button to select “ROCK”,
“POP”, “CLASSIC” or “FLAT” sound effect to suit your taste. The appropriate EQ
Indicator lights to confirm your selection.
BASS BOOST System
The Bass Boost feature intensifies low frequency sound for richer bass reproduction.
1.)Press the BASS BOOST button once to activate Bass Boost. The BBS indicator
will light up.
2.)To turn ‘Off’ the Bass Boost system, press the BASS BOOST button again.
The BBS indicator will go ‘Off’.
NOTE: If you are listening to music with heavy bass at high volume, with EQ
set to “ROCK” and BASS BOOST ‘On’, you may experience some distortion.
If this occurs, set the EQ to “FLAT”, switch the BASS BOOST ‘Off’, or reduce
the volume.
MUTE Button (On Remote Control Only)
To temporarily shut off the sound from the speakers press the MUTE button on the
remote control.
The MUTE indicator will appear on the LCD
display. Press the MUTE button again to cancel
Mute and restore the sound. The MUTE indicator
goes “Off”.
FM ST.–MONO / HI-SPEED DUBBING Button
This button is used to select between the FM STEREO and FM MONO operation
modes. It is also used to select either Normal Speed or High Speed tapepe
dubbing.
To receive FM Stereo broadcasts this switch must be set to the FM ST. position.
However if you are listening to a distant or weak FM Stereo station and reception is
unsatisfactory, press the button to the MONO position may provide some
improvement.
MS9923TT_B022806.p65 28/2/2006, 9:4411
12
LISTENING TO THE RADIO
Radio Operation
1.) Press the STANDBY (POWER) button to turn the system ‘On’. The STANDBY
indicator goes ‘Off’. The LCD display and the EQ indicator light up.
2.) Press the TUNER/BAND button to select the Radio mode.
3.) To switch between AM and FM bands, press the TUNER/BAND button again.
If you tune in a FM stereo station, and the
the FM ST.– MONO button is set at FM ST.
position, the STEREO indicator will
appear on the LCD display.
4.) Press the TUNING or TUNING buttons to tune to the desired station as
follows.
Manual Tuning
Press the TUNING or TUNING buttons as many times as required until
the frequency of the desired station appears on the display.
Automatic Tuning
Press and hold the TUNING or TUNING buttons for approximately 2
seconds. The Tuner will begin scanning up or down automatically and will lock
onto the next strong signal.
5.) Adjust the VOLUME, BASS BOOST and EQ controls as desired.
MS9923TT_B022806.p65 28/2/2006, 9:4412
13
Memorizing Preset Stations
You can store up to 40 of your favorite FM and AM stations randomly. Once a
station is preset in the memory, you will have quick and easy access to that station.
1.) Press the TUNER/BAND button to select the Radio mode.
2.) To switch between AM and FM bands, press the TUNER/BAND button again.
3.) Select the desired station by pressing the
TUNING or TUNING buttons.
Example: FM 103.5 MHz.
4.) Press the MEMORY button. The MEMORY,
CH, and channel number ‘00’ indicators will
flash in the display.
5.) Press the MEM. UP or MEM. DOWN button
to select any one of the 40 available preset
station memories. Example: CH 01.
6.) Press the MEMORY button again to enter
the selected radio station into the selected
memory location.
7.) Repeat the above steps 2 – 6 to enter all your desired stations into the preset
station memories.
After you have entered up to 40 stations in the preset memories, you can select
any one of the memorized stations quickly and easily by simply pressing the
REPEAT/MEM. UP or STOP/MEM. DOWN buttons until the desired memory
number and station frequency appear in the display.
MS9923TT_B022806.p65 28/2/2006, 9:4413
14
Antenna Information
For best FM reception, the FM lead wire antenna, located on the back of the set,
should fully unwound and extended.
The AM bar antenna is inside the cabinet. To improve AM reception, you may have
to move or slightly rotate the main unit until you obtain the best reception.
PLAY PLAYREWIND REWINDF. FWD F.FWDSTOP/EJECT
STOP/EJECT
PAUSE PAUSE
RANDOM
INTRO
PLAY/PAUSE
MEMORY
MULTI-FUNCTION LCD DISPLAY
DISC
1
DISC
2
DISC
3
DISC
4
DISC
5
REMOTE
SENSOR
DIGITAL FILTER PROCESSING SYSTEM
REPEAT/MEM. UP
TUNING / SKIP / SEARCH
STOP/MEM. DOWN
4 BAND PRESET EQUALIZER
AM / FM DIGITAL TUNING
STANDBY
VOLUME
PRESET
EQUALIZER
RECORD
AUX/PHONO
TAPE
CD/DISC SKIP
TUNER/BAND
FM ST. - MONO /
HI-SPEED DUBBING
BASS BOOST
PHONES OPEN/
CLOSE
ROCK
POP FLAT
EQ
PLAYBACK
RECORD
AUTO STOP
PLAYBACK
BBS
5 COMPACT DISC
40 TRACK PROGRAM MEMORY
AUTOMATIC CHANGER
STANDBY
MS9923TT_B022806.p65 28/2/2006, 9:4414
15
COMPACT DISC PLAYBACK
This system features a carousel type 5 CD CHANGER which can provide you with
up to 5 hours of uninterrupted music playback. You may load up to 5 CDs in the
changer for continuous playback, or you may program up to 40 tracks among all 5
discs to be played back in the specific order you select.
Loading the Discs
1.) Press the STANDBY (POWER) button to turn the system ‘On’.
2.) Press the CD/DISC SKIP button to select the CD mode.
3.) Press the OPEN/CLOSE button to
open the CD tray. When the tray
opens two of the five CD pockets
will be accessible to you.
Load up to 2 CDs in the pockets
making sure that the label side of
the discs face up and that the discs
are correctly centered in the
pockets.
4.) Press the CD/DISC SKIP button to rotate the CD tray and expose the 3rd 4th,
and 5th CD pocket.
Insert additional discs in the open pockets if desired.
5.) Press the OPEN/CLOSE button to close the CD tray. The CD player will search
for the first disc and the display will show the number of tracks and total playing
time of that disc.
NOTES:
• Keep the CD disc tray closed when the system is not in use to prevent dirt
and dust from entering the CD mechanism.
• Never place more than one CD in the same pocket of the CD tray. If two
discs are loaded in the same pocket, the CD mechanism may jam and/or
the discs themselves may be damaged.
MS9923TT_B022806.p65 28/2/2006, 9:4415
16
To Begin CD Playback
After you have loaded up the 5 CDs in the changer:
1.)Press the PLAY/PAUSE button to begin playback. The changer will search
for the first available disc in the tray and will
begin playback from Track 1 on the first disc.
The number of the disc being played flashes
on the display. It will continue playing until it
has played all of the discs in the tray and
then stops automatically.
NOTE: To begin playback from a specific disc, press the CD/DISC SKIP
button to select the desired disc, and then press the PLAY/PAUSE
button.
Or, press the appropriate disc button (DISC 1, DISC 2, DISC 3, DISC 4,
DISC 5) for the disc you wish to start. Playback will begin on Track 1 of the
selected disc. It stops automatically after finished playing all discs.
2.)Adjust the VOLUME, BASS BOOST, or EQ controls as desired.
3.)To temporarily stop playback, press the PLAY/PAUSE button again. The
“II” indicator appears in the display, and the play time flashes.
The disc continues to spin, but no sound is
heard. Press the PLAY/PAUSE button
once more to cancel pause and resume
playback.
4.)To stop playback before the end of a disc, press the STOP button.
IMPORTANT
If the disc is smudged or scratched it may skip or stop completely. This does
not indicate a problem with the player. If this occurs, try playing another disc.
If that disc plays properly, you may assume that the first disc is damaged and
unplayable.
MS9923TT_B022806.p65 28/2/2006, 9:4416
17
Forward And Backward SKIP/SEARCH Buttons
To skip forward or backward to the beginning of a particular track during playback,
press the or SKIP/SEARCH buttons repeatedly until the desired track number
appears on the display. Playback will begin on the desired track.
To search for a particular passage on a track during playback, press and hold the
or SKIP/SEARCH buttons. The player will search rapidly forward or back.
Release the button when you reach the desired point on the track and normal
speed playback will resume at that point.
Remaining Time Indication
While the CD is playing, each time you press the REMAIN button on the Remote
Control, the Display changes as shown below:
1.) Elapsed Time Of The Track.
2.) Remaining Time Of The Track.
3.) Total Remaining Time Of The Disc.
4.) Total Elapsed Play Time.
TRACK
TOTAL REMAIN
ALL
DISC
MS9923TT_B022806.p65 28/2/2006, 9:4417
18
PROGRAMMED CD PLAYBACK
You can program the CD changer to play up to a total of 40 tracks on all 5 discs in
any desired order.
NOTE: You can not program the CD changer during playback. If a disc is playing
press the STOP button first and then follow the instructions.
Entering A Program
1.)Press the MEMORY button once. The
MEMORY, the track number indicators will
flash in the display. Program number P-01
appears.
2.)Press the CD/DISC SKIP button or one of
the five disc buttons to select the disc which
contains the first track you wish to program.
Example: Disc 2.
3.)Press the or SKIP buttons to selectct
the first track you wish to program.
Example: Track 08.
4.)Press the MEMORY button again to store
the desired disc and track number into
memory location Number 1. The display will
change from Program Number P-01 to
Program Number P-02.
5.)Use the CD/DISC SKIP button or one of the
five disc buttons to select the disc containing
the next track you wish to program.
Example: Disc 3.
MS9923TT_B022806.p65 28/2/2006, 9:4418
19
6.)Press the or SKIP buttons to selectct
the next track you wish to program.
Example: Track 18.
7.)Press the MEMORY button again to store the desired disc and track into
memory location Number 02.
Repeat the above procedure until you have
stored up to 40 tracks in the program memory
and FULL flashes in Display.
After all your desired tracks are programmed you may press the MEMORY
button to reconfirm that the information has been stored correctly. The display
will show you which disc and track number you have entered into program
memory Number 1.
Each time you press the MEMORY button the display will show you which disc
number and track number is stored in each successive memory location.
Programmed Playback
After you have stored and confirmed the program information, press the
PLAY/PAUSE button to begin programmed playback.
Playback will start at the first disc and track
which you have programmed and will continue
until all programmed discs and tracks.
Up to a total of 40 tracks have been played.
NOTE: If you press the or SKIP buttons during programmed playback,
the player will skip forward or back to the next track and disc which you have
programmed, not the next track on the disc which is being played.
To Clear The Program Memory
If the disc is playing, press the STOP button to stop the discs. Then press the
STOP button again to clear the program memory..
MS9923TT_B022806.p65 28/2/2006, 9:4419
20
REPEAT FUNCTION
This system has a four-way repeat function which allows you to continuously repeat
one track, one disc, all discs, or all of the tracks which you have programmed.
One Track Repeat
1.)Press the REPEAT button until the REPEAT
ONE indicator appears in the LCD display.
2.)Use the or SKIP buttons (and the CD/DISC SKIP button, if necessary) to
select the exact track that you wish to repeat.
Example: Disc 2, Track 8.
3.)Press the PLAY/PAUSE button to begin one track repeat. The selected
track will begin playing. It will repeat continuously until REPEAT ONE function
is cancelled.
One Disc Repeat
1.)Press the REPEAT button until the REPEAT
ONE DISC indicator appears on the LCD
display. Press the CD/DISC SKIP button to
select the disc you wish to play.
Example: Disc 5.
2.)Press the PLAY/PAUSE button. The selected disc will begin to play starting
with Track 1. When the final track on the disc has been played, it will
automatically begin playing again starting with Track 1.
3.)To cancel One Disc Repeat playback, press the REPEAT button until the
REPEAT ONE DISC indicator no longer appears in the Display.
MS9923TT_B022806.p65 28/2/2006, 9:4420
21
All Discs Repeat
1.)Press the REPEAT button until the REPEAT
ALL DISC indicator appears in the Display.
2.)Press the PLAY/PAUSE button, the changer will begin playing the first
track of the disc which is in the play position. It will continue until it has played
all tracks on all discs in the changer. When it has played the last track on the
last disc it will begin playing again with the first track on the first disc. This All
Discs Repeat will continue indefinitely.
3.)To cancel All Discs Repeat playback, press the REPEAT button until the
REPEAT ALL DISC indicator no longer appears in the Display.
Repeat Off
Press the REPEAT button until the indicator
disappears and the display shows ALL DISC.
Programmed Repeat
1.)Load up to 5 CDs in the changer and program up to 40 tracks into the CD
Program Memory.
Refer to the instructions for PROGRAMMED CD PLAYBACK on Page 18.
2.)Press the REPEAT button until the REPEAT
indicator appears in the LCD Display.
3.)Press the PLAY/PAUSE button. Playback will begin with the first
programmed track and continue until the last programmed track (up to a
maximum of 40 tracks). When the last track has been played, playback will
begin again with the first programmed track. This sequence will continue
indefinitely until Programmed Repeat Playback is cancelled.
MS9923TT_B022806.p65 28/2/2006, 9:4421
22
4.)To cancel the Programmed Repeat Playback, press the STOP button twice.
You may also cancel the Programmed Repeat Playback by pressing the
REPEAT button until the REPEAT Indicator no longer appears in the LCD
Display.
INTRO SCAN
The Intro Scan feature lets you hear a 10 second introduction of each track on a
disc. This feature is useful if you are trying to find a particular song but you do not
know the title.
1.)Press the INTRO button once. The INTRO indicator appears in the display.
The CD player will begin playing Track 1 of
the disc in the play position. After 10 seconds
it will advance to Track 2, and so on, until it
has played the first 10 seconds of every track,
every disc.
2.)To cancel Intro Scan and resume normal playback, press the INTRO button
again. The INTRO Indicator disappears.
RANDOM PLAYBACK
The Random Playback feature is useful when you want to ‘mix up the music’ instead
of playing all the tracks in numerical order.
1.)Press the RANDOM button once. The
RANDOM Indicator appears in the display.
2.)Press the PLAY/PAUSE button. The changer will randomly select the first
disc and track to be played. It will continue randomly selecting discs and tracks
until all tracks on all discs have played, and then stop.
3.)To cancel Random Playback, press the RANDOM button again. The RANDOM
indicator disappears and normal playback resumes.
NOTE: If you press the RANDOM button while a disc is playing, the Random
selection will begin at the end of the track being played.
MS9923TT_B022806.p65 28/2/2006, 9:4422
23
CASSETTE OPERATION
This Emerson Audio System features a dual cassette mechanism which
allows you to play pre-recorded cassette tapes in either DECK A or DECK
B. You may also load tapes in both decks for continuous automatic playback
of two cassettes.
You may make tape recordings directly from the stereo receiver, the CD
changer, the Turntable, or external source connected to the AUX INPUT
jacks, or even from Tape to Tape (Dubbing) at either normal or high speed.
The built in ALC (Automatic Level Control) system adjusts the volume for
distortion-free recordings. You can change the playback volume control
settings during recordings without effecting the volume of the final recording.
For best results always use good quality blank tapes for recording. Although
blank tapes are available with various recording times we recommend that
you do not use tapes longer than C-90 which contain 90 minutes of recording
time (45 minutes per side). Longer tapes such as C-120’s (60 minutes per
side) use thinner material which may eventually stretch and can become
tangled in the mechanism.
Keep the critical parts of the tape mechanisms clean to insure trouble free
operation.
Refer to the cleaning instructions in the CARE AND MAINTENANCE section
of this manual.
MS9923TT_B022806.p65 28/2/2006, 9:4423
24
Cassette Playback
1.)Press the STANDBY (POWER) button to turn the system ‘On’.
2.)Press the TAPE button to select the ‘Tape’
function. The TAPE indicator appears in the
display.
3.)Press the STOP/EJECT key on either Deck A or Deck B to open the cassette
door.
4.)Insert the pre-recorded cassette(s) into the slots on the door with the exposed
tape facing down and the full reel on the left.
5.)Close the cassette door. Press the PLAY key to begin playback of your tape.
6.)Adjust the VOLUME and BASS BOOST or EQ controls as desired.
7.)Press the STOP/EJECT key to stop playback at any time. When the tape ends
the Automatic Stop System will release the PLAY key and shut off the tape
motor.
8.)Press the STOP/EJECT key again to open the cassette door and remove your
tape.
MS9923TT_B022806.p65 28/2/2006, 9:4424
25
F.FWD (Fast Forward) and REWIND Keys
Press either F.FWD or REWIND key at any time to move the tape rapidly forward or
back to any specific point. When you reach the desired point press the PLAY key
again to resume normal playback at that point.
Note: The Automatic Stop System does not function in the Fast Forward or
Rewind modes. If you fast forward or rewind to the end or beginning of the
tape, the F.FWD or REWIND keys will remain engaged and the tape motor
continues to run. Be sure to press the STOP/EJECT key to cancel Fast Forward
or Rewind and shut off the tape motor.
PAUSE Key
Press the PAUSE key to momentarily stop the tape movement in Playback or
Recording modes. The tape movement stops but the tape motor continues to run.
Press the PAUSE key again to cancel Pause and resume normal playback.
Note: The PAUSE key has no effect in the Fast Forward or Rewind modes.
Continuous Playback Of Two Cassettes
1.)Insert pre-recorded cassettes in both decks with the tape you wish to hear first
in Deck B.
2.)Press PLAY key of Deck B to start playback from Deck B. Then press the
PAUSE key and PLAY key of Deck A.
3.)When the tape in Deck B ends, it automatically stops.The PAUSE key of
Deck A will release automatically and the tape in Deck A begins to play.
4.)When the tape in Deck A ends both mechanisms stop.
5.)To play the other sides, turn both tapes over and repeat Steps 1 and 2 above.
MS9923TT_B022806.p65 28/2/2006, 9:4425
26
PLAYING PHONO RECORDS
1.) 45 rmp LP Record Adapter.
2.)Center Spindle.
3.)Platter.
4.)Tone Arm Lever (Cue Control).
5.)33/45/78 rmp Speed Slide Switch.
6.)Tone Arm.
7.)Tone Arm Rest and Clamp.
8.)Stylus lifter.
9.)Stylus and Protective Cover.
3
1
4
5
6
7
8
9
2
MS9923TT_B022806.p65 28/2/2006, 9:4426
27
Stereo Phonograph Operation
1.) Raise the turntable dust cover.
2.) Release the tone arm clamp, and remove the stylus protector.
3.) Press the AUX/PHONO button to select the
Phono mode. AUX/PHONO indicator appears in
the display
4.) Place a record on the turntable, over the center spindle.
5.) Place the 45 rpm adapter over the center spindle when playing 45 rpm records.
Set the Speed Selector Switch to 33, 45 or 78 rpm according to the record you
are playing.
6.) Raise the Cue Lever to lift the tone arm off the tone arm rest and move the
tone arm to the beginning of the record or to any desired track. This will cause
the turntable to start automatically.
7.) Gently lower the tone arm by the Cue Control Lever onto the record to start
playing. Adjust the VOLUME, BASS BOOST, and EQ setting as desired.
8.) The Turntable will stop automatically when the record finishes. To stop the
record before it ends, lift and replace the tone arm carefully onto the tone arm
rest.
Note: Do not turn or stop the turntable manually. Moving or jarring the Turntable
without securing the Tonearm clamp could result in damage to the Tonearm.
AUXILIARY INPUT CONNECTION
Sound from other Audio or Video equipment can be reproduced by connecting the
audio output of the equipment to the AUX IN jacks of this audio system.
Connect the left/right Auxiliary output, Line output, or Record output jacks of the
external equipment to the LEFT/RIGHT AUX IN jacks on the back panel of this
system.
Press the AUX/PHONO button of the audio system to select Auxiliary input sound.
Note:The “AUX” input signal will automatically mute when the Record Player
(Turntable) is operating.
MS9923TT_B022806.p65 28/2/2006, 9:4427
28
CASSETTE RECORDING
To record from the radio or CD changer:
1.)Press the STANDBY (POWER) button to turn the system ‘On’.
2.)Press the TUNER/BAND or CD/DISC SKIP button to select the appropriate
function. The TUNER or CD indicators will appear in the display.
3.)Press the STOP/EJECT key of Deck A to open
the cassette door. Insert a blank tape into the
slots on the door with the exposed tape facing
down and the full reel on the left side. Close
the cassette door.
4.)Operate the Tuner or CD changer to select the
material you wish to record.
Follow the instructions for LISTENING TO THE
RADIO or COMPACT DISC PLAYBACK if
necessary.
5.)When you are ready to begin recording, depress the RECORD key on Deck A.
(The PLAY key will also engage.) The music from the radio or CD will be
recorded directly on to the tape.
•Use the PAUSE key to stop the tape momentarily to avoid recording unwanted
material such as radio commercials.
•You can adjust the VOLUME and BASS BOOST and preset EQ controls during
the recording. These controls have no effect on the material being recorded
on the tape.
6.)When you have finished recording, press the STOP/EJECT key to stop the
tape.
Press again to open the door and remove the tape. When the tape ends, the
PLAY and RECORD keys are released automatically and the tape motor stops.
7.)To record on the other side of the tape, turn the cassette over so that the full
reel is again on the left side, and press the RECORD key again.
MS9923TT_B022806.p65 28/2/2006, 9:4428
29
To record from the Turntable:
1.)Press the AUX/PHONO button to the ‘AUX/PHONO’ mode.
2.)Select the part of the record for recording.
3.)Press the RECORD Key on Tape Deck A to start recording.
4.)Press the STOP/EJECT Key and place the tone arm on the rest when finished.
IMPORTANT NOTES: Never try to force the RECORD key. If it will not stay
down, this means that one of the erase prevention tabs on the cassette is
missing.
Refer to ABOUT CASSETTE TAPES on Page 31.
Tape To Tape Recording (Dubbing)
To copy a previously recorded tape:
1.)Press STANDBY (POWER) button to turn system ‘On’.
2.)Press TAPE button. The TAPE Indicator appears in the display.
3.)Press the STOP/EJECT key on both Decks to open the doors.
Insert the pre-recorded tape in Deck B and the blank tape in Deck A with exposed
tape facing down and full reels on the left. Close the cassette doors.
4.)Press the PAUSE key and then the RECORD key on Deck A.
Then press the PLAY key on Deck B. The PAUSE key of Deck A will release
automatically and both tapes will start simultaneously. All the material on the
pre-recorded tape in Deck B will be copied onto the blank tape in Deck A.
Recording Hint: Try to use a blank tape that is the same length or just slightly
longer than your pre-recorded tape. This will enable you to fit all the material
on the copy without excessive ‘blank space’.
High Speed Dubbing
When copying from tape to tape, you can reduce the recording time by pressing
the HI-SPEED DUBBING button to the ‘ On’ position. Both tapes will move at
approximately 2 times the normal speed to cut the recording time in half.
Note:Turn volume down to avoid unpleasant high speed sound.
MS9923TT_B022806.p65 28/2/2006, 9:4429
30
RESET Button
If the unit does not respond to commands from the remote control or from the front
panel controls, the internal processor may be “locked” and must be reset. Use a
paper clip or similar object to press the RESET button which is located inside a
pin-hole behind the back panel.
Depress the RESET button for a few seconds to clear the memory and restore
normal operation.
Notes:
1.)The system must be connected to an AC outlet in order to reset the internal
processor.
2.)After clearing the memory you must re-enter all of your favorite stations in
the Tuner Preset Memories.
RESET Pin Hole
PHONES Jack
The Stereo Headphone Jack is located on the left front panel. Connect a set of
stereo headphones (not included) to this jack for private listening without disturbing
others. The speakers are automatically disconnected when headphones are
connected to the headphone jack.
IMPORTANT: When using headphones always set the volume control to a low
level before you put the headphones on. Then put the headphones on and
gradually increase the volume to a comfortable listening level.
MS9923TT_B022806.p65 28/2/2006, 9:4430
31
ABOUT CASSETTE TAPES
Whenever you record on a cassette any previously recorded material is erased as
the new material is recorded. To prevent you from accidentally erasing material
which you wish to save, blank cassettes are equipped with erase prevention tabs
for each side of the tape. If the erase prevention tab for side A is removed, you
cannot accidentally record on side A. The record key cannot be depressed if the
erase prevention tab on the cassette has been removed.
To prevent accidental erasing on side A of a cassette use a small screw driver or
similar tool to break off the erase prevention tab for side A. This prevents the
record key from locking.
If later you do wish to record on side A of the cassette, cover the tab opening with
a piece of cellophane tape. This will allow the record key to function again.
CASSETTE CARE
Two common causes of trouble experienced when using cassettes are:
1.) Tape jamming — Leading to uneven speed in playback, and
2.) Tape tangling — Where the tape wraps itself around vital parts of the mechanism.
To reduce the likelihood of these problems occurring, the following precautions
should be observed:
• Check that there are no loose layers of tape visible
through the cassette center window (see Fig. 1).
Take up any loose layers, using a pencil or
hexagonal barrelled ballpoint pen, before inserting
the cassette into the machine (see Fig. 2).

COVER OPENING WITH TAPE
IN ORDER TO RECORD AGAIN.

TAB FOR SIDE A.
BREAK OFF TO PREVENT RECORDING
CARE AND MAINTENANCE
MS9923TT_ B022806.p65 30/4/2004, 11:4931
32
• If the cassette feels “tight” while performing operation
shown (see Fig. 2), the tape may be jamming due to
“ridges” formed in the winding of the tape (visible through
the center window). These may be removed, in most
cases, by fast winding of the cassette from one end to the
other and back again.
• Use only well-known brands of tape. Avoid use of C-120 cassettes.
Furthermore, do not expose cassettes to direct sunlight, dust or oil, and do not touch
the tape surfaces.
HEAD CLEANING
The tape heads, pinch roller and capstan require periodic cleaning. This removes
particles of the metal oxide coating that wear off the tape and accumulate on these
parts and impair performance. Switch off the power, press the STOP/EJECT key
to open the cassette door, and press the PLAY key. Clean the tape heads, pinch
roller and capstan with a soft cloth or cotton pad dampened in isopropyl alcohol or
special tape head cleaner.
Record/Play
Erase head Head Capstan Pinch
Roller
Play Head Capstan Pinch Roller
DECK A DECK B
Fig. 2
MS9923TT_ B022806.p65 30/4/2004, 11:4932
33
COMPACT DISC CARE
•To remove a disc from its storage case, press down on the center of the case
and lift the disc out, holding it carefully by the edges.
•Fingerprints and dust should be carefully wiped off the disc’s recorded surface
with a soft cloth. Unlike conventional records, compact discs have no grooves
to collect dust and microscopic debris, so gently wiping with a soft cloth should
remove most particles. Wipe in a straight line from the inside to the outside of
the disc. Small dust particles and light stains will have absolutely no effect on
reproduction quality.
•Clean the disc periodically with a soft, lint-free, dry cloth. Never use detergents
or abrasive cleaners to clean the disc. If necessary, use a CD cleaning kit.
•Never write on or affix labels to the surface of compact discs.
MS9923TT_B022806.p65 28/2/2006, 9:4433
34
TO FIND THE LOCATION AND PHONE
NUMBER OF YOUR NEAREST SERVICE
CENTER PERMITTED TO PERFORM
WARRANTY...
CALL TOLL FREE: 1-800-695-0098
SERVICE
FOR CUSTOMER SERVICE,PLEASE WRITE TO:
Emerson Radio Corp.,
Consumer Affairs Dept.,
5101 Statesman Drive,
Irving, TX 75063.
FOR ADDITIONAL SET-UP OR OPERATING ASSISTANCE
PLEASE CALL:
1-800-898-9020
CARE OF THE CABINETS
•If the cabinets become dusty wipe them with a soft dry dust cloth. Do not use
any wax or polish sprays on the cabinets.
•If the front panel becomes dirty or smudged with fingerprints it may be cleaned
with a soft cloth slightly dampened with a mild soap and water solution. Never
use abrasive cloths or polishes as these will mar the finish of your unit.
Caution: Never allow any water or other liquids to get inside the unit while
cleaning.
MS9923TT_B022806.p65 28/2/2006, 9:4434
35
LIMITED WARRANTY
Emerson Radio Corp. warrants manufacturing defects in original material, including
original parts and workmanship, under normal use and conditions, for a period of
ninety (90) days from the date of original purchase in the U.S. With your dated
proof of purchase, we will provide repair service at no charge for labor and parts
at an authorized Depot Repair Facility, or replace the product in our discretion.
For repair or replacement, pack your unit in a padded box, enclose your check or
money order payable to Emerson Radio Corp. in the amount of $9.00 (not required
by California residents) to cover shipping and handling costs, and enclose a copy
of your proof of purchase. Send your unit to:
Emerson Radio Corp.,
5101 Statesman Drive,
Irving, TX 75063.
This warranty does not cover damage from negligence, misuse, abuse, accident,
failure to follow operating instructions, commercial use, rental, repairs by an
unauthorized facility, or products purchased, used, serviced or damaged outside
of the United States.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY
ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.
AU898M
The serial number of your system is located on a label on the back panel. Please
take a moment to locate the serial number and write the number in the space
provided below. You may need this number for insurance purposes in the event
your set is damaged or lost. You may also be asked to provide this number when
requesting service.
Model Number: MS9923TT
Serial Number:
MS9923TT_B022806.p65 28/2/2006, 9:4435
EMERSON
Part No. 16-2862B
602-01 Printed in China
MS9923TT_B022806.p65 28/2/2006, 9:4436

Navigation menu
