Multi Point Lock Trim Price Book

Eective February 6, 2017

Bronze Patina is a living nish that will

gracefully age, revealing the underlying bronze

over time. Because of this characteristic, no nish

warranty is oered on bronze patina products.

Unlacquered Brass (US3NL) is a custom,

made-to-order finish. It is available with an

upcharge, per item and requires an additional 2-3

day lead time. This living finish will gracefully age

and evolve in appearance over time. Because of

this characteristic, no finish warranty is offered on

unlacquered brass products.

Door Configuration #4

American Cylinder Hub Above Handle, 3⁄” Center to Center

ref. Ashland®, G-U®, Caradco®, JELD-WEN®, Jeldwen® Custom

Collection (formerly Pozzi®), Marvin®, PGT®, Premium Collection

(formerly Norco®), Weathershield®

To determine your Multi-Point Lock configuration:

1) Identify the manufacturer of your patio door and multi-point lock

2) Measure the center-to-center hole spacing between the lever and the cylinder

3) Check the lever position: is it above or below the cylinder?

4) Identify the type of cylinder used in the door: is it American or Euro Profile Cylinder?

EMTEK MULTI POINT LOCK TRIM FOR SWINGING PATIO DOORS

CHOOSE TRIMSETS FROM 7 DOOR & LOCK CONFIGURATIONS, AVAILABLE IN BOTH KEYED AND NONKEYED FUNCTIONS

Door Configuration #1

American Cylinder Hub Below Handle, 3⁄” Center to Center

ref. Atrium®, G-U®, KML by Andersen®, Andersen®,

Marvin Integrity®, Paddock Lockmaster™, Superior®

PAGE

Door Configuration #2

American Cylinder Hub Above Handle, 3⁄” Center to Center

ref. BiltBest®, G-U®, Hurd® (Energy Saver), Andersen®

Door Configuration #3

American Cylinder Hub Above Handle, 4⁄” Center to Center

ref. Andersen®

> >

Door Configuration #5

Euro Profile Cylinder Below Handle, 3⁄” Center to Center

ref. Crestline®, Hoppe®, Hurd®, KFV®, Kolbe & Kolbe®, Lincoln®,

Loewen®, Paddock Lockmaster™, Peachtree®, Semco®, Sierra

Pacific®, Signature®, Simpson®, Therma-Tru®, Vetter®, Willmar®,

Windsor®, Weathershield®

Door Configuration #7

American Cylinder Hub Above Handle, 6” Center to Center

ref. Trillenium® (formerly W&F Manufacturing)

Product Index

Order Form

Lifetime Limited Warranty

Door Configuration #6

American Cylinder Hub Below Handle, 3⁄” Center to Center

ref. Milgard®, Pella®

PAGE

HANDING

HANDING OF DOOR IS ALWAYS DETERMINED FROM THE OUTSIDE

Determining handing for door hardware is different than determining handing for carpentry (ordering and

hanging doors). If you follow the standard carpentry rules for handing door hardware, instead of following the

diagram below, there is good chance you may end up with a lock that is handed incorrectly. Please refer to the

diagram below and if you have any questions, call Customer Service at (800) 356-2741.

LEFT

(LH)

IN-SWING

DOOR

OUT-SWING

DOOR

IN-SWING

DOOR

OUT-SWING

DOOR

LEFT

(LH)

RIGHT

(RH)

RIGHT

(RH)

TERMS AND CONDITIONS

Minimum Advertised Price Policy

Effective February 6, 2017

Emtek has determined that in order to better compete

against existing competitors it must exercise a greater

degree of control over the distribution of its products.

Therefore, all sales of Emtek products will be subject to

this Policy. This Policy has been unilaterally adopted and

will be enforced strictly and uniformly.

Although resellers remain free to establish their own

resale prices, to the extent that any customer elects to

advertise products of Emtek in any manner, that is in

print, in electronic media, on its website, etc., and provides

price information for such products, that price information

must be no less than List Price less 20%, this is the

Minimum Advertised Price (MAP). Advertisements and

offers to sell that do not include a particular price, but

require further action that implies a price that is lower

than the Minimum Advertised Price violate the MAP

Policy. Examples of such unauthorized advertisements

include “drop in cart” pricing, “add to cart” pricing, “click to

see” pricing, and discount coupon pricing. Also prohibited

are advertisements that indicate that discounts may be

available when a customer takes specific action that goes

beyond buying the product, such as “special price option”

or “name your price.”

To assure fair business practices, we will strictly enforce

this policy. Violations of this MAP Policy will include

termination of our business relationship with a customer.

On the first offense there will be a written notice

counseling any customer that disregards this policy. Any

customer who violates the policy a second time, within

one year of receiving a written notice of a first violation,

will be terminated.

Emtek will not discuss any conditions of acceptance

related to this Policy, as it is non-negotiable and will not

be altered for any dealer. In addition, Emtek neither

solicits, nor will it accept, any assurance of compliance

with this Policy. Nothing in this Policy shall constitute an

agreement between Emtek and any reseller that the

reseller will comply with this Policy.

Terms:

Net 30 Days on established credit.

Prices:

Prices are subject to change without prior notice. All prices listed

are in U.S. funds.

Minimum Order:

There is no minimum order quantity.

Shipping:

Emtek assembles all products to order in City of Industry, California.

Orders typically ship within two business days. For shipments to

customers located in the U.S. or Canada, Emtek ships freight

prepaid via 3 day service. For shipments to customers located in

Mexico, Emtek ships freight prepaid via UPS ground. For shipments

to customers located outside of North America, Emtek ships freight

prepaid to the U.S. location of the customer’s freight forwarder via

3 day service.

If a reduced transit time is needed, shipments can be upgraded to

2nd Day Service or Next Day Service for a fee. Orders not shipping

to the customer’s place of business must ship via 2nd Day or Next

Day Service, and additional charges will apply for shipments to a

residential address. Emtek cannot use a customer’s freight account

for shipping charges.

Returned Goods:

For your convenience, dealers can now process returns directly

from the Emtek website. Go to www.emtek.com, click on “Dealer

Site”, and then select “Return Goods”. Fill out the RGA form, and

follow the link to generate a UPS call tag (terms and conditions

apply – see the website for details). A completed RGA form must

accompany all packages for returned goods. Returns can only be

accepted from, and any refunds made to, the Emtek dealer who

originally purchased the product being returned. All returned

goods are subject to a minimum 25% handling charge.

Living Finishes:

Unlacquered Brass and Bronze Patina finishes will gracefully age

and evolve in appearance over time. Because of this characteristic,

no finish warranty is offered on these products.

Technical Specifications and Door Thickness Reference

Manual:

Available on the Emtek website. Select Resources and then

Technical Specifications.

http://emtek.com/technical-specifications.php

* For Single Door Application Only.

Geneva Lever

(GV)*

Triton Lever

(TRT)

Mercury Lever

(MC)

Stuttgart Lever

(STU)

Hermes Lever

(HER)

Luzern Lever

(LU)

Basel Lever

(BA)

Argos Lever

(AG)

Hercules Lever

(HEC)

Helios Lever

(HLO)

Aireon Lever

(A)

Poseidon Lever

(POS)

Sion Lever

(SIO)

Athena Lever

(ATN)

Cologne Lever

(CO)

Stuttgart Lever

(STT)

Kiel Lever

(KL)

Dresden Lever

(DD)

Poseidon Lever

(PO)

Athena Lever

(AT)

Hercules Lever

(HS)

Helios Lever

(HL)

Hermes Lever

(HES)

Medici Lever

(MDI)

Napoli Lever

(NA)

Octagon Lever

(OCL)

Padua Lever

(PD)

LEVER OPTIONS

Solid Brass

Brass Modern

Stainless Steel

Sandcast Bronze

Lost Wax Cast Bronze

Cody Lever

(CD)

Cimarron Lever

(CR)

Durango Lever

(D)

Lariat Lever

(LR) Montrose Lever

(MT)

Teton Lever

(TT) Yuma Lever

(YM)*

Aurora Lever

(AR)

Coventry Lever

(CV)

Rope Lever

(RL)

Cortina Lever

(C)

Ribbon & Reed Lever

(RBL)

Merrimack Lever

(ME)

Turino Lever

(T)

Elan Lever

(EN)

Santa Fe Lever

(SF)

Rustic Lever

(R)

Milano Lever

(M)

Wembley Lever

(WM)

CLASSICDESIGNER**

** Flat Black (US19) NOT available for Designer Levers.

DOOR CONFIGURATION

American Cylinder Hub Below Handle

3⁄” Center to Center

ref. Atrium®, G-U®, KML by Andersen®, Andersen®

Marvin Integrity®, Paddock Lockmaster™, Superior®

Each Multi Point Lock Trim now includes the Spring Assist function

which returns the lever to the neutral position and eliminates

sagging handles.

Handing Required

• Key codes may be specified. Fits standard door thickness of 1¾”. Specify if thicker.

• Set includes plates, handles and cylinders (where applicable). Multi Point lock mechanism is not included.

Weiser®(WR5) Keyway

• Specify by adding "W" to the beginning of Product Code.

• No upcharge for cylinder substitution. Can be keyed into existing Weiser® system.

8To order: (W) Product Code + Lever Style + Handing + Finish Code

Brass Concord

1½” x 11” Non-Keyed

Rustic Levers

Brass Concord

2” x 10” Keyed

Cortina Levers

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 1½” x 11” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

Sets with 2” x 10” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

1171

1172

1173

1174

1175

1181

1182

1183

1184

1185

BRASS PLATES, CONCORD STYLE

See Page 7 for

Brass & Modern

Brass Lever

Options.

Polished Brass - Lifetime (US3)

French Antique (US7)

Oil Rubbed Bronze (US10B)

Satin Nickel (US15)

Pewter (US15A)

Flat Black (US19)

Polished Chrome (US26)

Unlacquered Brass (US3NL)*

$194.00

*Unlacquered Brass (US3NL)

finish available for a $40 List Price

upcharge per item.

Handing Required

• Key codes may be specified. Fits standard door thickness of 1¾”. Specify if thicker.

• Set includes plates, handles and cylinders (where applicable). Multi Point lock mechanism is not included.

Weiser®(WR5) Keyway

• Specify by adding "W" to the beginning of Product Code.

• No upcharge for cylinder substitution. Can be keyed into existing Weiser® system.

emtek.com 800.356.2741

ref. Atrium®, G-U®, KML by Andersen®, Andersen®, Marvin Integrity®, Paddock Lockmaster™, Superior® DOOR CONFIGURATION #1

METRIC KNOB

TRAIL KNOB

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 1½” x 11” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

Sets with 2” x 10” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

11A1

11A2

11A3

11A4

11A5

11B1

11B2

11B3

11B4

11B5

BRASS PLATES, MODERN STYLE

See Page 7 for

Brass & Modern

Brass Lever

Options.

$194.00

Brass Modern

2” x 10” Keyed

Triton Levers

Brass Modern

1½” x 11” Non-Keyed

Luzern Levers

Stainless Steel

2” x 10” Keyed

Dresden Levers

Stainless Steel

1½” x 11” Non-Keyed

Athena Levers

METRIC KNOB

TRAIL KNOB

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 1½” x 11” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

Sets with 2” x 10” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

11A1

11A2

11A3

11A4

11A5

11B1

11B2

11B3

11B4

11B5

STAINLESS STEEL PLATES, MODERN STYLE

See Page 7 for

Stainless Steel

Lever Options.

Stainless Steel (SS) $204.00

*Unlacquered Brass (US3NL)

finish available for a $40 List Price

upcharge per item.

Satin Brass (US4)

Oil Rubbed Bronze (US10B)

Satin Nickel (US15)

Flat Black (US19)

Polished Chrome (US26)

Unlacquered Brass (US3NL)*

10 To order: (W) Product Code + Lever Style + Handing + Finish Code

DOOR CONFIGURATION

American Cylinder Hub Below Handle

3⁄” Center to Center

ref. Atrium®, G-U®, KML by Andersen®, Andersen®

Marvin Integrity®, Paddock Lockmaster™, Superior®

Each Multi Point Lock Trim now includes the Spring Assist function

which returns the lever to the neutral position and eliminates

sagging handles.

Handing Required

• Key codes may be specified. Fits standard door thickness of 1¾”. Specify if thicker.

• Set includes plates, handles and cylinders (where applicable). Multi Point lock mechanism is not included.

Weiser®(WR5) Keyway

• Specify by adding "W" to the beginning of Product Code.

• No upcharge for cylinder substitution. Can be keyed into existing Weiser® system.

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 1½” x 11” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

Sets with 2” x 10” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

1111

1112

1113

1114

1115

1121

1122

1123

1124

1125

SANDCAST BRONZE PLATES, ARCHED STYLE

See Page 7 for

Sandcast Bronze

Lever Options.

Flat Black Bronze (FB)

Medium Bronze (MB)

Tumbled White Bronze (TWB)

$216.00

Sandcast

Arched

1½” x 11” Non-Keyed

Cimarron Levers

Sandcast

Arched

2” x 10” Keyed

Durango Levers

emtek.com 800.356.2741

ref. Atrium®, G-U®, KML by Andersen®, Andersen®, Marvin Integrity®, Paddock Lockmaster™, Superior® DOOR CONFIGURATION #1

Handing Required

• Key codes may be specified. Fits standard door thickness of 1¾”. Specify if thicker.

• Set includes plates, handles and cylinders (where applicable). Multi Point lock mechanism is not included.

Weiser®(WR5) Keyway

• Specify by adding "W" to the beginning of Product Code.

• No upcharge for cylinder substitution. Can be keyed into existing Weiser® system.

Bronze Tuscany

1½” x 11” Non-Keyed

Octagon Levers

Bronze Tuscany

2” x 10” Keyed

Medici Levers

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 1½” x 11” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

Sets with 2” x 10” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

1131

1132

1133

1134

1135

1141

1142

1143

1144

1145

LOST WAX CAST BRONZE PLATES, TUSCANY STYLE

See Page 7 for Lost

Wax Cast Bronze

Lever Options.

Flat Black Bronze (FB)

Medium Bronze (MB)

$216.00

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 1½” x 11” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

Sets with 2” x 10” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

1151

1152

1153

1154

1155

1161

1162

1163

1164

1165

SANDCAST BRONZE PLATES, RECTANGULAR STYLE

See Page 7 for

Sandcast Bronze

Lever Options.

Flat Black Bronze (FB)

Medium Bronze (MB)

Tumbled White Bronze (TWB)

$216.00

Sandcast

Rectangular

2” x 10” Keyed

Montrose Levers

Sandcast

Rectangular

1½” x 11” Non-Keyed

Cody Levers

12 Decorative Multi Point Lock Trim for Swinging Patio Doors

DOOR CONFIGURATION #1 Specification Sheet for Components and Door Thickness

American Cylinder Below Handle 3 ⁄" Center to Center

Steel

Spindle

Rosette

Screws

Cylinder Tailpiece

Keyed Plates with American Cylinder Includes non-keyed thumbturn inside

Standard Components:

• Single Cylinder Tailpiece

• 3 ¾” Steel Spindle

• 2” Rosette Screws

• 1 ½” Rosette Screws for 1 ⁄” thick door

Standard Components:

• Thumbturn Tailpiece

• 3 ¾” Steel Spindle (half-spindle for fixed handle out/operating handle in)

• 2” Rosette Screws

• 1 ½” Rosette Screws for 1 ⁄” thick door

Extended Components:

• Long Single Cylinder Tailpiece

• 4 ½” Steel Spindle

• 2 ½” Rosette Screws

• 2” Rosette Screws for 2” - 2 ⁄” thick door

Extended Components:

• Long Thumbturn Tailpiece

• 4 ½” Steel Spindle (half-spindle for fixed handle out/operating handle in)

• 2 ½” Rosette Screws

• 2” Rosette Screws for 2” - 2 ⁄” thick door

Non-Keyed Plates Includes non-keyed passage, fixed handle out/operating handle in, and dummy (uses screws only)

Standard Door Thickness: from 1⁄” to 2”

Extended Door Thickness: Over 2” to 2¾”

CONSTRUCTION KEYING

Charge for Construction Keying - $3.00 (NET)

• Locks that are both construction keyed and keyed alike in a house group will be charged a total of $5.00 (NET) per cylinder.

Charge for Re-Keying - $2.00 (NET) per Cylinder

• Locks that are keyed to code or keyed alike in a house group will be charged $2.00 (NET) per cylinder.

Keying to Code

• Order by indicating “Key Code XXXXX “ next to applicable locks.

Keying Alike

• Order by indicating “Keyed Alike” next to applicable locks if only one keyed alike group is wanted.

• If ordering multiple groups (houses) indicate “Keyed Alike House #_” next to applicable locks.

- Construction devices used on one or

more of last four positions.

- Dimples drilled in plug in this position.

• Lost ball system.

• Last four pin locations drilled for lost ball application.

• Master key pins used for code variability.

• Construction keys and owner keys sent separately.

• Order by indicating “Construction Keyed, House #_” next to applicable locks.

emtek.com 800.356.2741

Specification Sheet for Trim and Cylinder Styles DOOR CONFIGURATION #1

2” x 10” Plates, Product Codes 1121, 1141, 1161, 1181, 11B11 ½” x 11” Plates, Product Codes 1111, 1131, 1151, 1171, 11A1

2” x 10” Plates, Product Codes 1122, 1142, 1162, 1182, 11B2

1 ½” x 11” Plates, Product Codes 1112, 1132, 1152, 1172, 11A2

1 ½” x 11” Plates, Product Codes 1113, 1133, 1153, 1173, 11A3 2” x 10” Plates, Product Codes 1123, 1143, 1163, 1183, 11B3

2” x 10” Plates, Product Codes 1124, 1144, 1164, 1184, 11B4

1 ½” x 11” Plates, Product Codes 1114, 1134, 1154, 1174, 11A4

1 ½” x 11” Plates, Product Codes 1115, 1135, 1155, 1175, 11A5 2” x 10” Plates, Product Codes 1125, 1145, 1165, 1185, 11B5

Set includes plates, handles and cylinders (where applicable). Multi Point lock mechanism is not included.

Atrium®, G-U®, KML by Andersen®, Andersen®, Marvin Integrity®, Paddock Lockmaster™, Superior®

Keyed with American Cylinder (for Active Door, Schlage® Keyway Standard, Weiser® Keyway Optional, Rekeyable)

Non-Keyed, Passage (for Semi-Active Door)

Non-Keyed, American Style Thumbturn Inside (for Active Door)

Non-Keyed, Fixed Handle Outside, Operating Handle Inside (for Semi-Active Door)

Dummy Pair (for Non-Active Door)

Fixed

Fixed Fixed Fixed

Fixed

Handing Required

• Key codes may be specified. Fits standard door thickness of 1¾”. Specify if thicker.

• Set includes plates, handles and cylinders (where applicable). Multi Point lock mechanism is not included.

Weiser®(WR5) Keyway

• Specify by adding "W" to the beginning of Product Code.

• No upcharge for cylinder substitution. Can be keyed into existing Weiser® system.

DOOR CONFIGURATION

American Cylinder Hub Above Handle

3⁄” Center to Center

ref. BiltBest®, G-U®, Hurd® (Energy Saver), Andersen®

Each Multi Point Lock Trim now includes the Spring Assist function

which returns the lever to the neutral position and eliminates

sagging handles.

14 To order: (W) Product Code + Lever Style + Handing + Finish Code

Brass Concord

2” x 10” Non-Keyed

Santa Fe Levers

Brass Concord

1½” x 11” Non-Keyed

Turino Levers

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 1½” x 11” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

Sets with 2” x 10” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

1271

1272

1273

1274

1275

1281

1282

1283

1284

1285

BRASS PLATES, CONCORD STYLE

See Page 7 for

Brass & Modern

Brass Lever

Options.

Polished Brass - Lifetime (US3)

French Antique (US7)

Oil Rubbed Bronze (US10B)

Satin Nickel (US15)

Pewter (US15A)

Flat Black (US19)

Polished Chrome (US26)

Unlacquered Brass (US3NL)*

$194.00

*Unlacquered Brass (US3NL)

finish available for a $40 List Price

upcharge per item.

Handing Required

• Key codes may be specified. Fits standard door thickness of 1¾”. Specify if thicker.

• Set includes plates, handles and cylinders (where applicable). Multi Point lock mechanism is not included.

Weiser®(WR5) Keyway

• Specify by adding "W" to the beginning of Product Code.

• No upcharge for cylinder substitution. Can be keyed into existing Weiser® system.

emtek.com 800.356.2741

ref. BiltBest®, G-U®, Hurd® (Energy Saver), Andersen® DOOR CONFIGURATION #2

Brass Modern

1½” x 11” Non-Keyed

Helios Levers

Brass Modern

2” x 10” Non-Keyed

Hercules Levers

Stainless Steel

2” x 10” Non-Keyed

Hermes Levers

Stainless Steel

1½” x 11” Keyed

Poseidon Levers

See Page 7 for

Brass & Modern

Brass Lever

Options.

METRIC KNOB

TRAIL KNOB

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 1½” x 11” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

Sets with 2” x 10” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

12A1

12A2

12A3

12A4

12A5

12B1

12B2

12B3

12B4

12B5

BRASS PLATES, MODERN STYLE

Satin Brass (US4)

Oil Rubbed Bronze (US10B)

Satin Nickel (US15)

Flat Black (US19)

Polished Chrome (US26)

Unlacquered Brass (US3NL)*

$194.00

METRIC KNOB

TRAIL KNOB

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 1½” x 11” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

Sets with 2” x 10” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

12A1

12A2

12A3

12A4

12A5

12B1

12B2

12B3

12B4

12B5

STAINLESS STEEL PLATES, MODERN STYLE

See Page 7 for

Stainless Steel

Lever Options.

Stainless Steel (SS) $204.00

*Unlacquered Brass (US3NL)

finish available for a $40 List Price

upcharge per item.

Handing Required

• Key codes may be specified. Fits standard door thickness of 1¾”. Specify if thicker.

• Set includes plates, handles and cylinders (where applicable). Multi Point lock mechanism is not included.

Weiser®(WR5) Keyway

• Specify by adding "W" to the beginning of Product Code.

• No upcharge for cylinder substitution. Can be keyed into existing Weiser® system.

DOOR CONFIGURATION

American Cylinder Hub Above Handle

3⁄” Center to Center

ref. BiltBest®, G-U®, Hurd® (Energy Saver), Andersen®

Each Multi Point Lock Trim now includes the Spring Assist function

which returns the lever to the neutral position and eliminates

sagging handles.

16 To order: (W) Product Code + Lever Style + Handing + Finish Code

Sandcast

Arched

2” x 10” Keyed

Teton Levers

Sandcast

Arched

1½” x 11” Keyed

Durango Levers

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 1½” x 11” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

Sets with 2” x 10” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

1211

1212

1213

1214

1215

1221

1222

1223

1224

1225

SANDCAST BRONZE PLATES, ARCHED STYLE

See Page 7 for

Sandcast Bronze

Lever Options.

Flat Black Bronze (FB)

Medium Bronze (MB)

Tumbled White Bronze (TWB)

$216.00

Handing Required

• Key codes may be specified. Fits standard door thickness of 1¾”. Specify if thicker.

• Set includes plates, handles and cylinders (where applicable). Multi Point lock mechanism is not included.

Weiser®(WR5) Keyway

• Specify by adding "W" to the beginning of Product Code.

• No upcharge for cylinder substitution. Can be keyed into existing Weiser® system.

emtek.com 800.356.2741

ref. BiltBest®, G-U®, Hurd® (Energy Saver), Andersen® DOOR CONFIGURATION #2

Sandcast

Rectangular

2” x 10” Keyed

Montrose Levers

Sandcast

Rectangular

1½” x 11” Keyed

Lariat Levers

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 1½” x 11” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

Sets with 2” x 10” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

1251

1252

1253

1254

1255

1261

1262

1263

1264

1265

SANDCAST BRONZE PLATES, RECTANGULAR STYLE

See Page 7 for

Sandcast Bronze

Lever Options.

Flat Black Bronze (FB)

Medium Bronze (MB)

Tumbled White Bronze (TWB)

$216.00

Bronze Tuscany

1½” x 11” Non-Keyed

Napoli Levers

Bronze Tuscany

2” x 10” Non-Keyed

Padua Levers

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 1½” x 11” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

Sets with 2” x 10” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

1231

1232

1233

1234

1235

1241

1242

1243

1244

1245

LOST WAX CAST BRONZE PLATES, TUSCANY STYLE

See Page 7 for Lost

Wax Cast Bronze

Lever Options.

Flat Black Bronze (FB)

Medium Bronze (MB)

$216.00

18 Decorative Multi Point Lock Trim for Swinging Patio Doors

DOOR CONFIGURATION #2 Specification Sheet for Components and Door Thickness

Door Configuration #2 American Cylinder Above Handle 3 ⁄" Center to Center

Steel

Spindle

Rosette

Screws

Cylinder Tailpiece

Keyed Plates with American Cylinder Includes non-keyed thumbturn inside

CONSTRUCTION KEYING

Charge for Construction Keying - $3.00 (NET)

• Locks that are both construction keyed and keyed alike in a house group will be charged a total of $5.00 (NET) per cylinder.

Charge for Re-Keying - $2.00 (NET) per Cylinder

• Locks that are keyed to code or keyed alike in a house group will be charged $2.00 (NET) per cylinder.

Keying to Code

• Order by indicating “Key Code XXXXX “ next to applicable locks.

Keying Alike

• Order by indicating “Keyed Alike” next to applicable locks if only one keyed alike group is wanted.

• If ordering multiple groups (houses) indicate “Keyed Alike House #_” next to applicable locks.

- Construction devices used on one or

more of last four positions.

- Dimples drilled in plug in this

position.

• Lost ball system.

• Last four pin locations drilled for lost ball application.

• Master key pins used for code variability.

• Construction keys and owner keys sent separately.

• Order by indicating “Construction Keyed, House #_” next to applicable locks.

Non-Keyed Plates Includes non-keyed passage, fixed handle out/operating handle in, and dummy (uses screws only)

Standard Door Thickness: from 1⁄” to 2”

Extended Door Thickness: Over 2” to 2¾”

Standard Components:

• Single Cylinder Tailpiece

• 3 ¾” Steel Spindle

• 2” Rosette Screws

• 1 ½” Rosette Screws for 1 ⁄” thick door

Standard Components:

• Thumbturn Tailpiece

• 3 ¾” Steel Spindle (half-spindle for fixed handle out/operating handle in)

• 2” Rosette Screws

• 1 ½” Rosette Screws for 1 ⁄” thick door

Extended Components:

• Long Single Cylinder Tailpiece

• 4 ½” Steel Spindle

• 2 ½” Rosette Screws

• 2” Rosette Screws for 2” - 2 ⁄” thick door

Extended Components:

• Long Thumbturn Tailpiece

• 4 ½” Steel Spindle (half-spindle for fixed handle out/operating handle in)

• 2 ½” Rosette Screws

• 2” Rosette Screws for 2” - 2 ⁄” thick door

emtek.com 800.356.2741

Specification Sheet for Trim and Cylinder Styles DOOR CONFIGURATION #2

2” x 10” Plates, Product Codes 1221, 1241, 1261, 1281, 12B1

2” x 10” Plates, Product Codes 1222, 1242, 1262, 1282, 12B2

2” x 10” Plates, Product Codes 1224, 1244, 1264, 1284, 12B4

1 ½” x 11” Plates, Product Codes 1215, 1235, 1255, 1275, 12A5

1 ½” x 11” Plates, Product Codes 1211, 1231, 1251, 1271, 12A1

1 ½” x 11” Plates, Product Codes 1212, 1232, 1252, 1272, 12A2

1 ½” x 11” Plates, Product Codes 1213, 1233, 1253, 1273, 12A3 2” x 10” Plates, Product Codes 1223, 1243, 1263, 1283, 12B3

1 ½” x 11” Plates, Product Codes 1214, 1234, 1254, 1274, 12A4

2” x 10” Plates, Product Codes 1225, 1245, 1265, 1285, 12B5

Fixed

Fixed Fixed

Fixed

Fixed Fixed

Keyed with American Cylinder (for Active Door, Schlage® Keyway Standard, Weiser® Keyway Optional, Rekeyable)

Non-Keyed, Passage (for Semi-Active Door)

Non-Keyed, American Style Thumbturn Inside (for Active Door)

Non-Keyed, Fixed Handle Outside, Operating Handle Inside (for Semi-Active Door)

Dummy Pair (for Non-Active Door)

Set includes plates, handles and cylinders (where applicable). Multi Point lock mechanism is not included.

BiltBest®, G-U®, Hurd® (Energy Saver), Andersen®

Handing Required

• Key codes may be specified. Fits standard door thickness of 1¾”. Specify if thicker.

• Set includes plates, handles and cylinders (where applicable). Multi Point lock mechanism is not included.

Weiser®(WR5) Keyway

• Specify by adding "W" to the beginning of Product Code.

• No upcharge for cylinder substitution. Can be keyed into existing Weiser® system.

DOOR CONFIGURATION

American Cylinder Hub Above Handle

41⁄8” Center to Center

ref. Andersen®

Each Multi Point Lock Trim now includes the Spring Assist function

which returns the lever to the neutral position and eliminates

sagging handles.

20 To order: (W) Product Code + Lever Style + Handing + Finish Code

Brass Concord

1½” x 11” Keyed

Wembley Levers

Brass Concord

2” x 10” Non-Keyed

Rope Levers

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 1½” x 11” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

Sets with 2” x 10” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

1371

1372

1373

1374

1375

1381

1382

1383

1384

1385

BRASS PLATES, CONCORD STYLE

See Page 7 for

Brass & Modern

Brass Lever

Options.

Polished Brass - Lifetime (US3)

French Antique (US7)

Oil Rubbed Bronze (US10B)

Satin Nickel (US15)

Pewter (US15A)

Flat Black (US19)

Polished Chrome (US26)

Unlacquered Brass (US3NL)*

$194.00

*Unlacquered Brass (US3NL)

finish available for a $40 List Price

upcharge per item.

Handing Required

• Key codes may be specified. Fits standard door thickness of 1¾”. Specify if thicker.

• Set includes plates, handles and cylinders (where applicable). Multi Point lock mechanism is not included.

Weiser®(WR5) Keyway

• Specify by adding "W" to the beginning of Product Code.

• No upcharge for cylinder substitution. Can be keyed into existing Weiser® system.

emtek.com 800.356.2741

ref. Andersen® DOOR CONFIGURATION #3

Brass Modern

1½” x 11” Keyed

Aireon Levers

Brass Modern

2” x 10” Keyed

Helios Levers

Stainless Steel

1½” x 11” Keyed

Athena Levers

Stainless Steel

2” x 10” Non-Keyed

Dresden Levers

METRIC KNOB

TRAIL KNOB

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 1½” x 11” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

Sets with 2” x 10” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

13A1

13A2

13A3

13A4

13A5

13B1

13B2

13B3

13B4

13B5

BRASS PLATES, MODERN STYLE

See Page 7 for

Brass & Modern

Brass Lever

Options.

Satin Brass (US4)

Oil Rubbed Bronze (US10B)

Satin Nickel (US15)

Flat Black (US19)

Polished Chrome (US26)

Unlacquered Brass (US3NL)*

$194.00

METRIC KNOB

TRAIL KNOB

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 1½” x 11” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

Sets with 2” x 10” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

13A1

13A2

13A3

13A4

13A5

13B1

13B2

13B3

13B4

13B5

STAINLESS STEEL PLATES, MODERN STYLE

See Page 7 for

Stainless Steel

Lever Options.

Stainless Steel (SS) $204.00

*Unlacquered Brass (US3NL)

finish available for a $40 List Price

upcharge per item.

Handing Required

• Key codes may be specified. Fits standard door thickness of 1¾”. Specify if thicker.

• Set includes plates, handles and cylinders (where applicable). Multi Point lock mechanism is not included.

Weiser®(WR5) Keyway

• Specify by adding "W" to the beginning of Product Code.

• No upcharge for cylinder substitution. Can be keyed into existing Weiser® system.

DOOR CONFIGURATION

American Cylinder Hub Above Handle

41⁄8” Center to Center

ref. Andersen®

Each Multi Point Lock Trim now includes the Spring Assist function

which returns the lever to the neutral position and eliminates

sagging handles.

22 To order: (W) Product Code + Lever Style + Handing + Finish Code

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 1½” x 11” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

Sets with 2” x 10” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

1311

1312

1313

1314

1315

1321

1322

1323

1324

1325

SANDCAST BRONZE PLATES, ARCHED STYLE

See Page 7 for

Sandcast Bronze

Lever Options.

Flat Black Bronze (FB)

Medium Bronze (MB)

Tumbled White Bronze (TWB)

$216.00

Sandcast

Arched

1½” x 11” Keyed

Durango Levers

Sandcast

Arched

2” x 10” Non-Keyed

Cody Levers

Bronze Tuscany

2” x 10” Non-Keyed

Padua Levers

Handing Required

• Key codes may be specified. Fits standard door thickness of 1¾”. Specify if thicker.

• Set includes plates, handles and cylinders (where applicable). Multi Point lock mechanism is not included.

Weiser®(WR5) Keyway

• Specify by adding "W" to the beginning of Product Code.

• No upcharge for cylinder substitution. Can be keyed into existing Weiser® system.

emtek.com 800.356.2741

ref. Andersen® DOOR CONFIGURATION #3

Bronze Tuscany

1½” x 11” Keyed

Medici Levers

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 1½” x 11” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

Sets with 2” x 10” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

1331

1332

1333

1334

1335

1341

1342

1343

1344

1345

LOST WAX CAST BRONZE PLATES, TUSCANY STYLE

See Page 7 for Lost

Wax Cast Bronze

Lever Options.

Flat Black Bronze (FB)

Medium Bronze (MB)

$216.00

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 1½” x 11” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

Sets with 2” x 10” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

1351

1352

1353

1354

1355

1361

1362

1363

1364

1365

SANDCAST BRONZE PLATES, RECTANGULAR STYLE

See Page 7 for

Sandcast Bronze

Lever Options.

Flat Black Bronze (FB)

Medium Bronze (MB)

Tumbled White Bronze (TWB)

$216.00

Sandcast

Rectangular

1½” x 11” Keyed

Lariat Levers

Sandcast

Rectangular

2” x 10” Keyed

Montrose Levers

24 Decorative Multi Point Lock Trim for Swinging Patio Doors

DOOR CONFIGURATION #3 Specification Sheet for Components and Door Thickness

Door Configuration #3 American Cylinder Above Handle 4 ⁄" Center to Center

Keyed Plates with American Cylinder Includes non-keyed thumbturn inside

CONSTRUCTION KEYING

Charge for Construction Keying - $3.00 (NET)

• Locks that are both construction keyed and keyed alike in a house group will be charged a total of $5.00 (NET) per cylinder.

Charge for Re-Keying - $2.00 (NET) per Cylinder

• Locks that are keyed to code or keyed alike in a house group will be charged $2.00 (NET) per cylinder.

Keying to Code

• Order by indicating “Key Code XXXXX “ next to applicable locks.

Keying Alike

• Order by indicating “Keyed Alike” next to applicable locks if only one keyed alike group is wanted.

• If ordering multiple groups (houses) indicate “Keyed Alike House #_” next to applicable locks.

- Construction devices used on one or

more of last four positions.

- Dimples drilled in

plug in this position.

• Lost ball system.

• Last four pin locations drilled for lost ball application.

• Master key pins used for code variability.

• Construction keys and owner keys sent separately.

• Order by indicating “Construction Keyed, House #_” next to applicable locks.

Steel

Spindle

Rosette Screws

Cylinder Tailpiece

Includes Configuration #3

Special Mounting Hardware

Non-Keyed Plates Includes non-keyed passage, fixed handle out/operating handle in, and dummy (uses screws only)

Standard Door Thickness: from 1⁄” to 2”

Extended Door Thickness: Over 2” to 2¾”

Standard Components:

• Single Cylinder Tailpiece

• 3 ¾” Steel Spindle

• 2” Rosette Screws

• 1 ½” Rosette Screws for 1 ⁄” thick door

Standard Components:

• Configuration #3 Thumbturn Tailpiece

• 3 ¾” Steel Spindle (half-spindle for fixed handle out/operating handle in)

• 2” Rosette Screws

• 1 ½” Rosette Screws for 1 ⁄” thick door

Extended Components:

• Long Single Cylinder Tailpiece

• 4 ½” Steel Spindle

• 2 ½” Rosette Screws

• 2” Rosette Screws for 2” - 2 ⁄” thick door

Extended Components:

• Configuration #3 Thumbturn Tailpiece

• 4 ½” Steel Spindle (half-spindle for fixed handle out/operating handle in)

• 2 ½” Rosette Screws

• 2” Rosette Screws for 2” - 2 ⁄” thick door

2” x 10” Plates, Product Codes 1321, 1341, 1361, 1381, 13B1

Fixed

Fixed Fixed Fixed Fixed

emtek.com 800.356.2741

Specification Sheet for Trim and Cylinder Styles DOOR CONFIGURATION #3

2” x 10” Plates, Product Codes 1322, 1342, 1362, 1382, 13B2

2” x 10” Plates, Product Codes 1323, 1343, 1363, 1383, 13B3

2” x 10” Plates, Product Codes 1325, 1345, 1365, 1385, 13B5

2” x 10” Plates, Product Codes 1324, 1344, 1364, 1384, 13B4

1 ½” x 11” Plates, Product Codes 1311, 1331, 1351, 1371, 13A1

1 ½” x 11” Plates, Product Codes 1312, 1332, 1352, 1372, 13A2

1 ½” x 11” Plates, Product Codes 1313, 1333, 1353, 1373, 13A3

1 ½” x 11” Plates, Product Codes 1314, 1334, 1354, 1374, 13A4

1 ½” x 11” Plates, Product Codes 1315, 1335, 1355, 1375, 13A5

Set includes plates, handles and cylinders (where applicable). Multi Point lock mechanism is not included.

Andersen®

Keyed with American Cylinder (for Active Door, Schlage® Keyway Standard, Weiser® Keyway Optional, Rekeyable)

Non-Keyed, Passage (for Semi-Active Door)

Non-Keyed, American Style Thumbturn Inside (for Active Door)

Non-Keyed, Fixed Handle Outside, Operating Handle Inside (for Semi-Active Door)

Dummy Pair (for Non-Active Door)

Fixed

Handing Required

• Key codes may be specified. Fits standard door thickness of 1¾”. Specify if thicker.

• Set includes plates, handles and cylinders (where applicable). Multi Point lock mechanism is not included.

Weiser®(WR5) Keyway

• Specify by adding "W" to the beginning of Product Code.

• No upcharge for cylinder substitution. Can be keyed into existing Weiser® system.

DOOR CONFIGURATION

American Cylinder Hub Above Handle

3⁄” Center to Center

ref. Ashland®, G-U®, Caradco®, JELD-WEN®

Jeldwen® Custom Collection (formerly Pozzi®)

Marvin®, PGT®, Premium Collection (formerly Norco®)

Weathershield®

Each Multi Point Lock Trim now includes the Spring Assist function

which returns the lever to the neutral position and eliminates

sagging handles.

See Configuration #1 for Marvin Integrity® Doors

26 To order: (W) Product Code + Lever Style + Handing + Finish Code

Brass Concord

1½” x 11” Keyed

Coventry Levers

Brass Concord

2” x 10” Non-Keyed

Santa Fe Levers

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 1½” x 11” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

Sets with 2” x 10” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

1471

1472

1473

1474

1475

1481

1482

1483

1484

1485

BRASS PLATES, CONCORD STYLE

See Page 7 for

Brass & Modern

Brass Lever

Options.

Polished Brass - Lifetime (US3)

French Antique (US7)

Oil Rubbed Bronze (US10B)

Satin Nickel (US15)

Pewter (US15A)

Flat Black (US19)

Polished Chrome (US26)

Unlacquered Brass (US3NL)*

$194.00

*Unlacquered Brass (US3NL)

finish available for a $40 List Price

upcharge per item.

Handing Required

• Key codes may be specified. Fits standard door thickness of 1¾”. Specify if thicker.

• Set includes plates, handles and cylinders (where applicable). Multi Point lock mechanism is not included.

Weiser®(WR5) Keyway

• Specify by adding "W" to the beginning of Product Code.

• No upcharge for cylinder substitution. Can be keyed into existing Weiser® system.

emtek.com 800.356.2741

ref. Ashland®, G-U®, Caradco®, JELD-WEN®, Jeldwen® Custom Collection, Marvin®, PGT®, Premium Collection, Weathershield® DOOR CONFIGURATION #4

Brass Modern

1½” x 11” Keyed

Aireon Levers

Stainless Steel

1½” x 11” Keyed

Stuttgart Levers

Brass Modern

2” x 10” Non-Keyed

Hercules Levers

Stainless Steel

2” x 10” Non-Keyed

Hermes Levers

METRIC KNOB

TRAIL KNOB

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 1½” x 11” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

Sets with 2” x 10” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

14A1

14A2

14A3

14A4

14A5

14B1

14B2

14B3

14B4

14B5

BRASS PLATES, MODERN STYLE

See Page 7 for

Brass & Modern

Brass Lever

Options.

Satin Brass (US4)

Oil Rubbed Bronze (US10B)

Satin Nickel (US15)

Flat Black (US19)

Polished Chrome (US26)

Unlacquered Brass (US3NL)*

$194.00

METRIC KNOB

TRAIL KNOB

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 1½” x 11” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

Sets with 2” x 10” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

14A1

14A2

14A3

14A4

14A5

14B1

14B2

14B3

14B4

14B5

STAINLESS STEEL PLATES, MODERN STYLE

See Page 7 for

Stainless Steel

Lever Options.

Stainless Steel (SS) $204.00

*Unlacquered Brass (US3NL)

finish available for a $40 List Price

upcharge per item.

Handing Required

• Key codes may be specified. Fits standard door thickness of 1¾”. Specify if thicker.

• Set includes plates, handles and cylinders (where applicable). Multi Point lock mechanism is not included.

Weiser®(WR5) Keyway

• Specify by adding "W" to the beginning of Product Code.

• No upcharge for cylinder substitution. Can be keyed into existing Weiser® system.

DOOR CONFIGURATION

American Cylinder Hub Above Handle

3⁄” Center to Center

ref. Ashland®, G-U®, Caradco®, JELD-WEN®

Jeldwen® Custom Collection (formerly Pozzi®)

Marvin®, PGT®, Premium Collection (formerly Norco®)

Weathershield®

Each Multi Point Lock Trim now includes the Spring Assist function

which returns the lever to the neutral position and eliminates

sagging handles.

See Configuration #1 for Marvin Integrity® Doors

28 To order: (W) Product Code + Lever Style + Handing + Finish Code

Sandcast

Arched

1½” x 11” Keyed

Montrose Levers

Sandcast

Arched

2” x 10” Non-Keyed

Cody Levers

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 1½” x 11” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

Sets with 2” x 10” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

1411

1412

1413

1414

1415

1421

1422

1423

1424

1425

SANDCAST BRONZE PLATES, ARCHED STYLE

See Page 7 for

Sandcast Bronze

Lever Options.

Flat Black Bronze (FB)

Medium Bronze (MB)

Tumbled White Bronze (TWB)

$216.00

Sandcast

Rectangular

2” x 10” Keyed

Teton Levers

Handing Required

• Key codes may be specified. Fits standard door thickness of 1¾”. Specify if thicker.

• Set includes plates, handles and cylinders (where applicable). Multi Point lock mechanism is not included.

Weiser®(WR5) Keyway

• Specify by adding "W" to the beginning of Product Code.

• No upcharge for cylinder substitution. Can be keyed into existing Weiser® system.

emtek.com 800.356.2741

ref. Ashland®, G-U®, Caradco®, JELD-WEN®, Jeldwen® Custom Collection, Marvin®, PGT®, Premium Collection, Weathershield® DOOR CONFIGURATION #4

Bronze Tuscany

1½” x 11” Non-Keyed

Napoli Levers

Bronze Tuscany

2” x 10” Keyed

Napoli Levers

Sandcast

Rectangular

1½” x 11” Keyed

Lariat Levers

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 1½” x 11” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

Sets with 2” x 10” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

1431

1432

1433

1434

1435

1441

1442

1443

1444

1445

LOST WAX CAST BRONZE PLATES, TUSCANY STYLE

See Page 7 for Lost

Wax Cast Bronze

Lever Options.

Flat Black Bronze (FB)

Medium Bronze (MB)

$216.00

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 1½” x 11” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

Sets with 2” x 10” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

1451

1452

1453

1454

1455

1461

1462

1463

1464

1465

SANDCAST BRONZE PLATES, RECTANGULAR STYLE

See Page 7 for

Sandcast Bronze

Lever Options.

Flat Black Bronze (FB)

Medium Bronze (MB)

Tumbled White Bronze (TWB)

$216.00

30 Decorative Multi Point Lock Trim for Swinging Patio Doors

DOOR CONFIGURATION #4 Specification Sheet for Components and Door Thickness

Door Configuration #4 American Cylinder Above Handle 3 ⁄" Center to Center

Steel

Spindle

Rosette

Screws

Cylinder Tailpiece

CONSTRUCTION KEYING

Charge for Construction Keying - $3.00 (NET)

• Locks that are both construction keyed and keyed alike in a house group will be charged a total of $5.00 (NET) per cylinder.

Charge for Re-Keying - $2.00 (NET) per Cylinder

• Locks that are keyed to code or keyed alike in a house group will be charged $2.00 (NET) per cylinder.

Keying to Code

• Order by indicating “Key Code XXXXX “ next to applicable locks.

Keying Alike

• Order by indicating “Keyed Alike” next to applicable locks if only one keyed alike group is wanted.

• If ordering multiple groups (houses) indicate “Keyed Alike House #_” next to applicable locks.

- Construction devices used on

one or more of last four positions.

- Dimples drilled in

plug in this position.

• Lost ball system.

• Last four pin locations drilled for lost ball application.

• Master key pins used for code variability.

• Construction keys and owner keys sent separately.

• Order by indicating “Construction Keyed, House #_” next to applicable locks.

Keyed Plates with American Cylinder Includes non-keyed thumbturn inside

Non-Keyed Plates Includes non-keyed passage, fixed handle out/operating handle in, and dummy (uses screws only)

Standard Door Thickness: from 1⁄” to 2”

Extended Door Thickness: Over 2” to 2¾”

Standard Components:

• Single Cylinder Tailpiece

• 3 ¾” Steel Spindle

• 2” Rosette Screws for 1 ⁄” - 1 ¾” thick door

• 2 ½” Rosette Screws for 1 ¾” - 2” thick door

Standard Components:

• Thumbturn Tailpiece

• 3 ¾” Steel Spindle (half-spindle for fixed handle out/operating handle in)

• 2” Rosette Screws for 1 ⁄” - 1 ¾” thick door

• 2 ½” Rosette Screws for 1 ¾” - 2” thick door

Extended Components:

• Long Single Cylinder Tailpiece

• 4 ½” Steel Spindle

• 2 ½” Rosette Screws 2” - 2 ¼” think door

• 3” Rosette Screws for 2 ¼” - 2 ¾” thick door

Extended Components:

• Long Thumbturn Tailpiece

• 4 ½” Steel Spindle (half-spindle for fixed handle out/operating handle in)

• 2 ½” Rosette Screws 2” - 2 ¼” think door

• 3” Rosette Screws for 2 ¼” - 2 ¾” thick door

emtek.com 800.356.2741

Specification Sheet for Trim and Cylinder Styles DOOR CONFIGURATION #4

Set includes plates, handles and cylinders (where applicable). Multi Point lock mechanism is not included.

Ashland®, G-U®, Caradco®, JELD-WEN®, Jeldwen® Custom Collection (formerly Pozzi®), Marvin®, PGT®, Premium Collection (formerly Norco®), Weathershield®

Keyed with American Cylinder (for Active Door, Schlage® Keyway Standard, Weiser® Keyway Optional, Rekeyable)

Non-Keyed, Passage (for Semi-Active Door)

Non-Keyed, American Style Thumbturn Inside (for Active Door)

Non-Keyed, Fixed Handle Outside, Operating Handle Inside (for Semi-Active Door)

Dummy Pair (for Non-Active Door)

2” x 10” Plates, Product Codes 1421, 1441, 1461, 1481, 14B1

1 ½” x 11” Plates, Product Codes 1411, 1431, 1451, 1471, 14A1

1 ½” x 11” Plates, Product Codes 1412, 1432, 1452, 1472, 14A2

1 ½” x 11” Plates, Product Codes 1413, 1433, 1453, 1473, 14A3

1 ½” x 11” Plates, Product Codes 1414, 1434, 1454, 1474, 14A4

1 ½” x 11” Plates, Product Codes 1415, 1435, 1455, 1475, 14A5

2” x 10” Plates, Product Codes 1422, 1442, 1462, 1482, 14B2

2” x 10” Plates, Product Codes 1423, 1443, 1463, 1483, 14B3

2” x 10” Plates, Product Codes 1425, 1445, 1465, 1485, 14B5

2” x 10” Plates, Product Codes 1424, 1444, 1464, 1484, 14B4

Fixed

Fixed Fixed Fixed

Fixed

Handing Required

• Key codes may be specified. Fits standard door thickness of 1¾”. Specify if thicker.

• Set includes plates, handles and cylinders (where applicable). Multi Point lock mechanism is not included. Weiser® keyway not available for Configuration 5, Euro cylinder.

DOOR CONFIGURATION

Euro Profile Cylinder Below Handle

35⁄8” Center to Center

ref. Crestline®, Hoppe®, Hurd®, KFV®, Kolbe & Kolbe®

Lincoln®, Loewen®, Paddock Lockmaster™, Peachtree®

Semco®, Sierra Pacific®, Signature®, Simpson®

Therma-Tru®, Vetter®, Willmar®, Windsor®

Weathershield®

Each Multi Point Lock Trim now includes the Spring Assist function

which returns the lever to the neutral position and eliminates

sagging handles.

32 To order: Product Code + Lever Style + Handing + Finish Code

Brass Concord

1½” x 11” Keyed

Turino Levers

Brass Concord

2” x 10” Keyed

Rustic Levers

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 1½” x 11” Plates

Keyed with Euro Profile Cylinder

(Schlage® Keyway standard, Rekeyable)

Non-Keyed Passage

Non-Keyed Euro Profile Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

Sets with 2” x 10” Plates

Keyed with Euro Profile Cylinder

(Schlage® Keyway standard, Rekeyable)

Non-Keyed Passage

Non-Keyed Euro Profile Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

1571

1572

1573

1574

1575

1581

1582

1583

1584

1585

BRASS PLATES, CONCORD STYLE

See Page 7 for

Brass & Modern

Brass Lever

Options.

Polished Brass - Lifetime (US3)

French Antique (US7)

Oil Rubbed Bronze (US10B)

Satin Nickel (US15)

Pewter (US15A)

Flat Black (US19)

Polished Chrome (US26)

Unlacquered Brass (US3NL)*

$194.00

*Unlacquered Brass (US3NL)

finish available for a $40 List Price

upcharge per item.

Handing Required

• Key codes may be specified. Fits standard door thickness of 1¾”. Specify if thicker.

• Set includes plates, handles and cylinders (where applicable). Multi Point lock mechanism is not included. Weiser® keyway not available for Configuration 5, Euro cylinder.

emtek.com 800.356.2741

DOOR CONFIGURATION #5

ref. Crestline®, Hoppe®, Hurd®, KFV®, Kolbe & Kolbe®, Lincoln®, Loewen®, Paddock Lockmaster™, Peachtree®, Semco®

Sierra Pacific®, Signature®, Simpson®, Therma-Tru®, Vetter®, Willmar®, Windsor®, Weathershield®

Brass Modern

1½” x 11” Keyed

Hermes Levers

Brass Modern

2” x 10” Keyed

Triton Levers

Stainless Steel

2” x 10” Non-Keyed

Hercules Levers

Stainless Steel

1½” x 11” Keyed

Stuttgart Levers

See Page 7 for

Brass & Modern

Brass Lever

Options.

METRIC KNOB

TRAIL KNOB

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 1½” x 11” Plates

Keyed with Euro Profile Cylinder

(Schlage® Keyway standard, Rekeyable)

Non-Keyed Passage

Non-Keyed Euro Profile Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

Sets with 2” x 10” Plates

Keyed with Euro Profile Cylinder

(Schlage® Keyway standard, Rekeyable)

Non-Keyed Passage

Non-Keyed Euro Profile Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

15A1

15A2

15A3

15A4

15A5

15B1

15B2

15B3

15B4

15B5

BRASS PLATES, MODERN STYLE

Satin Brass (US4)

Oil Rubbed Bronze (US10B)

Satin Nickel (US15)

Flat Black (US19)

Polished Chrome (US26)

Unlacquered Brass (US3NL)*

$194.00

METRIC KNOB

TRAIL KNOB

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 1½” x 11” Plates

Keyed with Euro Profile Cylinder

(Schlage® Keyway standard, Rekeyable)

Non-Keyed Passage

Non-Keyed Euro Profile Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

Sets with 2” x 10” Plates

Keyed with Euro Profile Cylinder

(Schlage® Keyway standard, Rekeyable)

Non-Keyed Passage

Non-Keyed Euro Profile Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

15A1

15A2

15A3

15A4

15A5

15B1

15B2

15B3

15B4

15B5

STAINLESS STEEL PLATES, MODERN STYLE

See Page 7 for

Stainless Steel

Lever Options.

Stainless Steel (SS) $204.00

*Unlacquered Brass (US3NL)

finish available for a $40 List Price

upcharge per item.

Handing Required

• Key codes may be specified. Fits standard door thickness of 1¾”. Specify if thicker.

• Set includes plates, handles and cylinders (where applicable). Multi Point lock mechanism is not included. Weiser® keyway not available for Configuration 5, Euro cylinder.

DOOR CONFIGURATION

Euro Profile Cylinder Below Handle

35⁄8” Center to Center

ref. Crestline®, Hoppe®, Hurd®, KFV®, Kolbe & Kolbe®

Lincoln®, Loewen®, Paddock Lockmaster™, Peachtree®

Semco®, Sierra Pacific®, Signature®, Simpson®

Therma-Tru®, Vetter®, Willmar®, Windsor®

Weathershield®

Each Multi Point Lock Trim now includes the Spring Assist function

which returns the lever to the neutral position and eliminates

sagging handles.

34 To order: Product Code + Lever Style + Handing + Finish Code

Sandcast

Arched

1½” x 11” Keyed

Lariat Levers

Sandcast

Arched

2” x 10” Keyed

Durango Levers

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 1½” x 11” Plates

Keyed with Euro Profile Cylinder

(Schlage® Keyway standard, Rekeyable)

Non-Keyed Passage

Non-Keyed Euro Profile Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

Sets with 2” x 10” Plates

Keyed with Euro Profile Cylinder

(Schlage® Keyway standard, Rekeyable)

Non-Keyed Passage

Non-Keyed Euro Profile Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

1511

1512

1513

1514

1515

1521

1522

1523

1524

1525

SANDCAST BRONZE PLATES, ARCHED STYLE

See Page 7 for

Sandcast Bronze

Lever Options.

Flat Black Bronze (FB)

Medium Bronze (MB)

Tumbled White Bronze (TWB)

$216.00

Handing Required

• Key codes may be specified. Fits standard door thickness of 1¾”. Specify if thicker.

• Set includes plates, handles and cylinders (where applicable). Multi Point lock mechanism is not included. Weiser® keyway not available for Configuration 5, Euro cylinder.

emtek.com 800.356.2741

DOOR CONFIGURATION #5

ref. Crestline®, Hoppe®, Hurd®, KFV®, Kolbe & Kolbe®, Lincoln®, Loewen®, Paddock Lockmaster™, Peachtree®, Semco®

Sierra Pacific®, Signature®, Simpson®, Therma-Tru®, Vetter®, Willmar®, Windsor®, Weathershield®

Bronze Tuscany

1½” x 11” Keyed

Octagon Levers

Sandcast

Rectangular

2” x 10” Non-Keyed

Montrose Levers

Sandcast

Rectangular

1½” x 11” Keyed

Teton Levers

Bronze Tuscany

2” x 10” Keyed

Padua Levers

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 1½” x 11” Plates

Keyed with Euro Profile Cylinder

(Schlage® Keyway standard, Rekeyable)

Non-Keyed Passage

Non-Keyed Euro Profile Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

Sets with 2” x 10” Plates

Keyed with Euro Profile Cylinder

(Schlage® Keyway standard, Rekeyable)

Non-Keyed Passage

Non-Keyed Euro Profile Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

1531

1532

1533

1534

1535

1541

1542

1543

1544

1545

LOST WAX CAST BRONZE PLATES, TUSCANY STYLE

See Page 7 for Lost

Wax Cast Bronze

Lever Options.

Flat Black Bronze (FB)

Medium Bronze (MB)

$216.00

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 1½” x 11” Plates

Keyed with Euro Profile Cylinder

(Schlage® Keyway standard, Rekeyable)

Non-Keyed Passage

Non-Keyed Euro Profile Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

Sets with 2” x 10” Plates

Keyed with Euro Profile Cylinder

(Schlage® Keyway standard, Rekeyable)

Non-Keyed Passage

Non-Keyed Euro Profile Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

1551

1552

1553

1554

1555

1561

1562

1563

1564

1565

SANDCAST BRONZE PLATES, RECTANGULAR STYLE

See Page 7 for

Sandcast Bronze

Lever Options.

Flat Black Bronze (FB)

Medium Bronze (MB)

Tumbled White Bronze (TWB)

$216.00

36 Decorative Multi Point Lock Trim for Swinging Patio Doors

DOOR CONFIGURATION #5 Specification Sheet for Components and Door Thickness

Door Configuration #5

Euro Profile Cylinder Below Handle

3 ⁄" Center to Center

Keyed Plates with Euro Profile Cylinder

Standard Components:

• 2 ⁄” Euro Profile Cylinder

• 3 ¾” Steel Spindle

• 1 ½” Rosette Screws

Standard Components:

• 1 ⁄” Euro Profile Half-Cylinder

• 3 ¾” Steel Spindle

• 1 ½” Rosette Screws

Extended Components:

• 3 ⁄” Euro Profile Cylinder

• 4 ½” Steel Spindle

• 2” Rosette Screws

Extended Components:

• 1 ⁄” Euro Profile Half-Cylinder

• 4 ½” Steel Spindle

• 2” Rosette Screws

Extended Components:

• 3 ⁄” Euro Profile Cylinder

• 5” Steel Spindle

• 3” Rosette Screws

Extended Components:

• 2 ⁄” Euro Profile Half-Cylinder

• 5” Steel Spindle

• 3” Rosette Screws

Non-Keyed Plates with Euro Profile Half Cylinder

Non-Keyed Plates Includes non-keyed passage, fixed handle out/operating handle in, and dummy (uses screws only)

Standard Door Thickness: from 1⁄” to 2”

Extended Door Thickness: Over 2” to 2½”

Extended Door Thickness: Over 2½”to 2¾”

CONSTRUCTION KEYING

Charge for Construction Keying - $3.00 (NET)

• Locks that are both construction keyed and keyed alike in a house group will be charged a total of $5.00 (NET) per cylinder.

Charge for Re-Keying - $2.00 (NET) per Cylinder

• Locks that are keyed to code or keyed alike in a house group will be charged $2.00 (NET) per cylinder.

Keying to Code

• Order by indicating “Key Code XXXXX “ next to applicable locks.

Keying Alike

• Order by indicating “Keyed Alike” next to applicable locks if only one keyed alike group is wanted.

• If ordering multiple groups (houses) indicate “Keyed Alike House #_” next to applicable locks.

- Construction devices used on one

or more of last four positions.

- Dimples drilled in plug

in this position.

• Lost ball system.

• Last four pin locations drilled for lost ball application.

• Master key pins used for code variability.

• Construction keys and owner keys sent separately.

• Order by indicating “Construction Keyed, House #_”

next to applicable locks.

Steel

Spindle

Rosette

Screws

Full Euro Profile Cylinder

Cylinder

Screw

Full Euro Profile Cylinder Half Euro Profile Cylinder

CY4-ERSGL35

CY4-ERSGL32

CY4-ERSGL25 CY4-ERHLF16TT

CY4-ERHLF19TT

CY4-ERHLF21TT

Standard Components:

• 3 ¾” Steel Spindle (half-spindle for fixed handle out/operating handle in)

• 2” Rosette Screws

• 1 ½” Rosette Screws for 1 ⁄” thick door

Extended Components:

• 4 ½” Steel Spindle (half-spindle for fixed handle out/operating handle in)

• 2 ½” Rosette Screws

• 2” Rosette Screws for 2” - 2 ⁄” thick door

Standard Door Thickness: from 1⁄” to 2” Extended Door Thickness: Over 2” to 2¾”

Fixed

Fixed Fixed

Fixed

Fixed Fixed

emtek.com 800.356.2741

Specification Sheet for Trim and Cylinder Styles DOOR CONFIGURATION #5

2” x 10” Plates, Product Codes 1524, 1544, 1564, 1584, 15B4

1 ½” x 11” Plates, Product Codes 1511, 1531, 1551, 1571, 15A1

1 ½” x 11” Plates, Product Codes 1512, 1532, 1552, 1572, 15A2

1 ½” x 11” Plates, Product Codes 1513, 1533, 1553, 1573, 15A3 2” x 10” Plates, Product Codes 1523, 1543, 1563, 1583, 15B3

1 ½” x 11” Plates, Product Codes 1514, 1534, 1554, 1574, 15A4

2” x 10” Plates, Product Codes 1525, 1545, 1565, 1585, 15B51 ½” x 11” Plates, Product Codes 1515, 1535, 1555, 1575, 15A5

2” x 10” Plates, Product Codes 1522, 1542, 1562, 1582, 15B2

2” x 10” Plates, Product Codes 1521, 1541, 1561, 1581, 15B1

Set includes plates, handles and cylinders (where applicable). Multi Point lock mechanism is not included.

Crestline®, Hoppe®, Hurd®, KFV®, Kolbe & Kolbe®, Lincoln®, Loewen®, Paddock Lockmaster™, Peachtree®,

Semco®, Sierra Pacific®, Signature®, Simpson®, Therma-Tru®, Vetter®, Willmar®, Windsor®, Weathershield®

Keyed with Euro Profile Cylinder (for Active Door, Schlage® Keyway Standard, Rekeyable)

Non-Keyed, Passage (for Semi-Active Door)

Non-Keyed, Euro Profile Style Thumbturn Inside (for Active Door)

Non-Keyed, Fixed Handle Outside, Operating Handle Inside (for Semi-Active Door)

Dummy Pair (for Non-Active Door)

Handing Required

• Key codes may be specified. Fits standard door thickness of 1¾”. Specify if thicker.

• Set includes plates, handles and cylinders (where applicable). Multi Point lock mechanism is not included.

Weiser®(WR5) Keyway

• Specify by adding "W" to the beginning of Product Code.

• No upcharge for cylinder substitution. Can be keyed into existing Weiser® system.

DOOR CONFIGURATION

American Cylinder Hub Below Handle

3⁄” Center to Center

ref. Milgard®, Pella®

Each Multi Point Lock Trim now includes the Spring Assist function

which returns the lever to the neutral position and eliminates

sagging handles.

38 To order: (W) Product Code + Lever Style + Handing + Finish Code

Brass Concord

1½” x 11” Keyed

Cortina Levers

Brass Concord

2” x 10” Non-Keyed

Santa Fe Levers

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 1½” x 11” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

Sets with 2” x 10” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

1671

1672

1673

1674

1675

1681

1682

1683

1684

1685

BRASS PLATES, CONCORD STYLE

See Page 7 for

Brass & Modern

Brass Lever

Options.

Polished Brass - Lifetime (US3)

French Antique (US7)

Oil Rubbed Bronze (US10B)

Satin Nickel (US15)

Pewter (US15A)

Flat Black (US19)

Polished Chrome (US26)

Unlacquered Brass (US3NL)*

$194.00

*Unlacquered Brass (US3NL)

finish available for a $40 List Price

upcharge per item.

Handing Required

• Key codes may be specified. Fits standard door thickness of 1¾”. Specify if thicker.

• Set includes plates, handles and cylinders (where applicable). Multi Point lock mechanism is not included.

Weiser®(WR5) Keyway

• Specify by adding "W" to the beginning of Product Code.

• No upcharge for cylinder substitution. Can be keyed into existing Weiser® system.

emtek.com 800.356.2741

ref. Milgard®, Pella® DOOR CONFIGURATION #6

Brass Modern

1½” x 11” Non-Keyed

Hercules Levers

Brass Modern

2” x 10” Non-Keyed

Luzern Levers

Stainless Steel

1½” x 11” Non-Keyed

Athena Levers

Stainless Steel

2” x 10” Non-Keyed

Hercules Levers

METRIC KNOB

TRAIL KNOB

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 1½” x 11” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

Sets with 2” x 10” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

16A1

16A2

16A3

16A4

16A5

16B1

16B2

16B3

16B4

16B5

BRASS PLATES, MODERN STYLE

See Page 7 for

Brass & Modern

Brass Lever

Options.

Satin Brass (US4)

Oil Rubbed Bronze (US10B)

Satin Nickel (US15)

Flat Black (US19)

Polished Chrome (US26)

Unlacquered Brass (US3NL)*

$194.00

METRIC KNOB

TRAIL KNOB

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 1½” x 11” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

Sets with 2” x 10” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

16A1

16A2

16A3

16A4

16A5

16B1

16B2

16B3

16B4

16B5

STAINLESS STEEL PLATES, MODERN STYLE

See Page 7 for

Stainless Steel

Lever Options.

Stainless Steel (SS) $204.00

*Unlacquered Brass (US3NL)

finish available for a $40 List Price

upcharge per item.

Handing Required

• Key codes may be specified. Fits standard door thickness of 1¾”. Specify if thicker.

• Set includes plates, handles and cylinders (where applicable). Multi Point lock mechanism is not included.

Weiser®(WR5) Keyway

• Specify by adding "W" to the beginning of Product Code.

• No upcharge for cylinder substitution. Can be keyed into existing Weiser® system.

DOOR CONFIGURATION

American Cylinder Hub Below Handle

3⁄” Center to Center

ref. Milgard®, Pella®

Each Multi Point Lock Trim now includes the Spring Assist function

which returns the lever to the neutral position and eliminates

sagging handles.

40 To order: (W) Product Code + Lever Style + Handing + Finish Code

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 1½” x 11” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

Sets with 2” x 10” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

1611

1612

1613

1614

1615

1621

1622

1623

1624

1625

SANDCAST BRONZE PLATES, ARCHED STYLE

See Page 7 for

Sandcast Bronze

Lever Options.

Flat Black Bronze (FB)

Medium Bronze (MB)

Tumbled White Bronze (TWB)

$216.00

Sandcast Arched

1½” x 11” Non-Keyed

Teton Levers

Sandcast Arched

2” x 10” Keyed

Durango Levers

Handing Required

• Key codes may be specified. Fits standard door thickness of 1¾”. Specify if thicker.

• Set includes plates, handles and cylinders (where applicable). Multi Point lock mechanism is not included.

Weiser®(WR5) Keyway

• Specify by adding "W" to the beginning of Product Code.

• No upcharge for cylinder substitution. Can be keyed into existing Weiser® system.

emtek.com 800.356.2741

ref. Milgard®, Pella® DOOR CONFIGURATION #6

Sandcast

Rectangular

2” x 10” Keyed

Montrose Levers

Sandcast

Rectangular

1½” x 11” Non-Keyed

Lariat Levers

Bronze Tuscany

1½” x 11” Keyed

Octagon Levers

Bronze Tuscany

2” x 10” Non-Keyed

Napoli Levers

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 1½” x 11” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

Sets with 2” x 10” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

1631

1632

1633

1634

1635

1641

1642

1643

1644

1645

LOST WAX CAST BRONZE PLATES, TUSCANY STYLE

See Page 7 for Lost

Wax Cast Bronze

Lever Options.

Flat Black Bronze (FB)

Medium Bronze (MB)

$216.00

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 1½” x 11” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

Sets with 2” x 10” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed Passage

Non-Keyed American Style Thumbturn Inside

Non-Keyed Fixed Handle Outside, Operating Handle Inside

Dummy Pair

1651

1652

1653

1654

1655

1661

1662

1663

1664

1665

SANDCAST BRONZE PLATES, RECTANGULAR STYLE

See Page 7 for

Sandcast Bronze

Lever Options.

Flat Black Bronze (FB)

Medium Bronze (MB)

Tumbled White Bronze (TWB)

$216.00

42 Decorative Multi Point Lock Trim for Swinging Patio Doors

DOOR CONFIGURATION #6 Specification Sheet for Components and Door Thickness

Door Configuration #6 American Cylinder Below Handle 3 ⁄" Center to Center

Steel

Spindle

Rosette

Screws

Cylinder Tailpiece

Keyed Plates with American Cylinder Includes non-keyed thumbturn inside

CONSTRUCTION KEYING

Charge for Construction Keying - $3.00 (NET)

• Locks that are both construction keyed and keyed alike in a house group will be charged a total of $5.00 (NET) per cylinder.

Charge for Re-Keying - $2.00 (NET) per Cylinder

• Locks that are keyed to code or keyed alike in a house group will be charged $2.00 (NET) per cylinder.

Keying to Code

• Order by indicating “Key Code XXXXX “ next to applicable locks.

Keying Alike

• Order by indicating “Keyed Alike” next to applicable locks if only one keyed alike group is wanted.

• If ordering multiple groups (houses) indicate “Keyed Alike House #_” next to applicable locks.

- Construction devices used on one or

more of last four positions.

- Dimples drilled in

plug in this position.

• Lost ball system.

• Last four pin locations drilled for lost ball application.

• Master key pins used for code variability.

• Construction keys and owner keys sent separately.

• Order by indicating “Construction Keyed, House #_” next to applicable locks.

Non-Keyed Plates Includes non-keyed passage, fixed handle out/operating handle in, and dummy (uses screws only)

Standard Door Thickness: from 1⁄” to 2”

Extended Door Thickness: Over 2” to 2¾”

Standard Components:

• Single Cylinder Tailpiece

• 3 ¾” Steel Spindle

• 2” Rosette Screws

• 1 ½” Rosette Screws for 1 ⁄” thick door

Standard Components:

• Thumbturn Tailpiece

• 3 ¾” Steel Spindle (half-spindle for fixed handle out/operating handle in)

• 2” Rosette Screws

• 1 ½” Rosette Screws for 1 ⁄” thick door

Extended Components:

• Long Single Cylinder Tailpiece

• 4 ½” Steel Spindle

• 2 ½” Rosette Screws

• 2” Rosette Screws for 2” - 2 ⁄” thick door

Extended Components:

• Long Thumbturn Tailpiece

• 4 ½” Steel Spindle (half-spindle for fixed handle out/operating handle in)

• 2 ½” Rosette Screws

• 2” Rosette Screws for 2” - 2 ⁄” thick door

Fixed Fixed

FixedFixed

emtek.com 800.356.2741

Specification Sheet for Trim and Cylinder Styles DOOR CONFIGURATION #6

2” x 10” Plates, Product Codes 1624, 1644, 1664, 1684, 16B4

1 ½” x 11” Plates, Product Codes 1611, 1631, 1651, 1671, 16A1

1 ½” x 11” Plates, Product Codes 1612, 1632, 1652, 1672, 16A2

1 ½” x 11” Plates, Product Codes 1613, 1633, 1653, 1673, 16A3 2” x 10” Plates, Product Codes 1623, 1643, 1663, 1683, 16B3

1 ½” x 11” Plates, Product Codes 1614, 1634, 1654, 1674, 16A4

2” x 10” Plates, Product Codes 1625, 1645, 1665, 1685, 16B51 ½” x 11” Plates, Product Codes 1615, 1635, 1655, 1675, 16A5

2” x 10” Plates, Product Codes 1622, 1642, 1662, 1682, 16B2

2” x 10” Plates, Product Codes 1621, 1641, 1661, 1681, 16B1

Set includes plates, handles and cylinders (where applicable). Multi Point lock mechanism is not included.

Milgard®, Pella®

Keyed with American Cylinder (for Active Door, Schlage® Keyway Standard, Weiser® Keyway Optional, Rekeyable)

Non-Keyed, Passage (for Semi-Active Door)

Non-Keyed, American Style Thumbturn Inside (for Active Door)

Non-Keyed, Fixed Handle Outside, Operating Handle Inside (for Semi-Active Door)

Dummy Pair (for Non-Active Door)

Handing Required

• Key codes may be specified. Fits standard door thickness of 1¾”. Specify if thicker.

• Set includes plates, handles and cylinders (where applicable). Multi Point lock mechanism is not included.

Weiser®(WR5) Keyway

• Specify by adding "W" to the beginning of Product Code.

• No upcharge for cylinder substitution. Can be keyed into existing Weiser® system.

DOOR CONFIGURATION

American Cylinder Hub Above Handle

6” Center to Center

ref. Trillenium® (formerly W&F Manufacturing)

Each Multi Point Lock Trim now includes the Spring Assist function

which returns the lever to the neutral position and eliminates

sagging handles.

44 To order: (W) Product Code + Lever Style + Handing + Finish Code

Brass Modern

2” x 10” Keyed

Poseidon Levers

Brass Modern

2” x 10” Non-Keyed

Hercules Levers

METRIC KNOB

TRAIL KNOB

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 2” x 10” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed American Style T-Turn Inside (Patio Function)

Dummy Pair

Non-Keyed American Style T-Turn Inside, Fixed Handles

17B1

17B3

17B5

17B6

BRASS PLATES, MODERN STYLE

See Page 7 for

Brass & Modern

Brass Lever

Options.

Satin Brass (US4)

Oil Rubbed Bronze (US10B)

Satin Nickel (US15)

Flat Black (US19)

Polished Chrome (US26)

Unlacquered Brass (US3NL)*

$194.00

*Unlacquered Brass (US3NL)

finish available for a $40 List Price

upcharge per item.

emtek.com 800.356.2741

ref. Trillenium® (formerly W&F Manufacturing) DOOR CONFIGURATION #7

Stainless Steel

2” x 10” Keyed

Stuttgart Levers

Stainless Steel

2” x 10” Non-Keyed

Hercules Levers

Sandcast Arched

2” x 10” Keyed

Montrose Levers

Sandcast Arched

2” x 10” Non-Keyed

Cody Levers

Sandcast

Rectangular

2” x 10” Non-Keyed

Lariat Levers

Sandcast

Rectangular

2” x 10” Keyed

Lariat Levers

METRIC KNOB

TRAIL KNOB

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 2” x 10” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed American Style T-Turn Inside (Patio Function)

Dummy Pair

Non-Keyed American Style T-Turn Inside, Fixed Handles

17B1

17B3

17B5

17B6

STAINLESS STEEL PLATES, MODERN STYLE

See Page 7 for

Brass & Modern

Brass Lever

Options.

Stainless Steel (SS)

METRIC KNOB

TRAIL KNOB

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 2” x 10” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed American Style T-Turn Inside (Patio Function)

Dummy Pair

Non-Keyed American Style T-Turn Inside, Fixed Handles

1761

1763

1765

1766

SANDCAST BRONZE PLATES, RECTANGULAR STYLE

See Page 7 for

Sandcast Bronze

Lever Options.

Flat Black Bronze (FB)

Medium Bronze (MB)

Tumbled White Bronze (TWB)

$216.00

METRIC KNOB

TRAIL KNOB

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 2” x 10” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed American Style T-Turn Inside (Patio Function)

Dummy Pair

Non-Keyed American Style T-Turn Inside, Fixed Handles

1721

1723

1725

1726

SANDCAST BRONZE PLATES, ARCHED STYLE

See Page 7 for

Sandcast Bronze

Lever Options.

Flat Black Bronze (FB)

Medium Bronze (MB)

Tumbled White Bronze (TWB)

$216.00

$204.00

Handing Required

• Key codes may be specified. Fits standard door thickness of 1¾”. Specify if thicker.

• Set includes plates, handles and cylinders (where applicable). Multi Point lock mechanism is not included.

Weiser®(WR5) Keyway

• Specify by adding "W" to the beginning of Product Code.

• No upcharge for cylinder substitution. Can be keyed into existing Weiser® system.

DOOR CONFIGURATION

American Cylinder Hub Above Handle

6” Center to Center

ref. Trillenium® (formerly W&F Manufacturing)

Each Multi Point Lock Trim now includes the Spring Assist function

which returns the lever to the neutral position and eliminates

sagging handles.

46 To order: (W) Product Code + Lever Style + Handing + Finish Code

Bronze Tuscany

2” x 10” Keyed

Padua Levers

Bronze Tuscany

2” x 10” Non-Keyed

Napoli Levers

METRIC KNOB

TRAIL KNOB

FinishProduct Code Lever Style (LH/RH) List Price

Sets with 2” x 10” Plates

Keyed with American Cylinder

(Schlage® Keyway standard, Weiser® Keyway optional, Rekeyable)

Non-Keyed American Style T-Turn Inside (Patio Function)

Dummy Pair

Non-Keyed American Style T-Turn Inside, Fixed Handles

1741

1743

1745

1746

LOST WAX CAST BRONZE PLATES, TUSCANY STYLE

See Page 7 for

Lost Wax Cast

Bronze Lever

Options.

Flat Black Bronze (FB)

Medium Bronze (MB)

$216.00

emtek.com 800.356.2741

Specification Sheet for Components and Door Thickness DOOR CONFIGURATION #7

Door Configuration #7 American Cylinder Above Handle 6" Center to Center

CONSTRUCTION KEYING

Charge for Construction Keying - $3.00 (NET)

• Locks that are both construction keyed and keyed alike in a house group will be charged a total of $5.00 (NET) per cylinder.

Charge for Re-Keying - $2.00 (NET) per Cylinder

• Locks that are keyed to code or keyed alike in a house group will be charged $2.00 (NET) per cylinder.

Keying to Code

• Order by indicating “Key Code XXXXX “ next to applicable locks.

Keying Alike

• Order by indicating “Keyed Alike” next to applicable locks if only one keyed alike group is wanted.

• If ordering multiple groups (houses) indicate “Keyed Alike House #_” next to applicable locks.

- Construction devices used on one or

more of last four positions.

- Dimples drilled in plug

in this position.

• Lost ball system.

• Last four pin locations drilled for lost ball application.

• Master key pins used for code variability.

• Construction keys and owner keys sent separately.

• Order by indicating “Construction Keyed, House #_” next to applicable locks.

Steel Spindles

(Half-Spindle) Rosette

Screws

Cylinder Tailpiece

Keyed Plates with American Cylinder Includes non-keyed thumbturn inside

Non-Keyed Plates Includes non-keyed passage, fixed handle out/operating handle in, & dummy (uses screws only)

Standard Door Thickness: from 1⁄” to 2”

Extended Door Thickness: Over 2” to 2¾”

Standard Components:

• Single Cylinder Tailpiece

• 2” Steel Spindles (Half-spindle)

• 2” Rosette Screws for 1 ⁄” - 1 ¾” thick door

• 2 ½” Rosette Screws for 1 ¾” - 2” thick door

Standard Components:

• Thumbturn Tailpiece

• 2” Steel Spindles (Half-spindle. No spindle for fixed handles)

• 2” Rosette Screws for 1 ⁄” - 1 ¾” thick door

• 2 ½” Rosette Screws for 1 ¾” - 2” thick door

Extended Components:

• Long Single Cylinder Tailpiece

• 2” Steel Spindles (Half-spindle)

• 2 ½” Rosette Screws 2” - 2 ¼” think door

• 3” Rosette Screws for 2 ¼” - 2 ¾” thick door

Extended Components:

• Long Thumbturn Tailpiece

• 2” Steel Spindles (Half-spindle. No spindle for fixed handles)

• 2 ½” Rosette Screws 2” - 2 ¼” think door

• 3” Rosette Screws for 2 ¼” - 2 ¾” thick door

48 Decorative Multi Point Lock Trim for Swinging Patio Doors

DOOR CONFIGURATION #7 Specification Sheet for Trim and Cylinder Styles

Set includes plates, handles and cylinders (where applicable). Multi Point lock mechanism is not included.

Trillenium® (formerly W&F Manufacturing)

Keyed with American Cylinder (for Active Door, Schlage® Keyway Standard, Weiser® Keyway Optional, Rekeyable)

Non-Keyed, American Style T-Turn Inside (Active Door)

Dummy Pair (for Non-Active Door)

Non-Keyed, Fixed Handles, American Style T-Turn Inside (for Semi-Active Door)

2” x 10” Plates, Product Codes 1723, 1743, 1763, 17B3

2” x 10” Plates, Product Codes 1725, 1745, 1765, 17B5

2” x 10” Plates, Product Codes 1726, 1746, 1766, 17B6

2” x 10” Plates, Product Codes 1721, 1741,1761, 17B1

1111

1112

1113

1114

1115

1121

1122

1123

1124

1125

1131

1132

1133

1134

1135

1141

1142

1143

1144

1145

1151

1152

1153

1154

1155

1161

1162

1163

1164

1165

1171

1172

1173

1174

1175

1181

1182

1183

1184

1185

1211

1212

1213

1214

1215

1221

1222

1223

1224

1225

1231

1232

1233

1234

1235

1241

1242

1243

1244

1245

1251

1252

1253

1254

1255

1261

1262

1263

1264

1265

1271

1272

1273

1274

1275

1281

1282

1283

1284

1285

1311

1312

1313

1314

1315

1321

1322

1323

1324

1325

1331

1332

1333

1334

1335

1341

1342

1343

1344

1345

1351

1352

1353

1354

1355

1361

1362

1363

1364

1365

1371

1372

1373

1374

1375

1381

1382

1383

1384

1385

1411

1412

1413

1414

1415

1421

1422

1423

1424

1425

1431

1432

1433

1434

1435

1441

1442

1443

1444

1445

1451

1452

1453

1454

1455

1461

1462

1463

1464

1465

1471

1472

1473

1474

1475

1481

1482

1483

1484

1485

1511

1512

1513

1514

1515

1521

1522

1523

1524

1525

1531

1532

1533

1534

1535

1541

1542

1543

1544

1545

1551

1552

1553

1554

1555

1561

1562

1563

1564

1565

1571

1572

1573

1574

1575

1581

1582

1583

PRODUCT

CODE

PAGE

PRODUCT INDEX

1584

1585

1611

1612

1613

1614

1615

1621

1622

1623

1624

1625

1631

1632

1633

1634

1635

1641

1642

1643

1644

1645

1651

1652

1653

1654

1655

1661

1662

1663

1664

1665

1671

1672

1673

1674

1675

1681

1682

1683

1684

1685

1721

1723

1725

1726

1741

1743

1745

1746

1761

1763

1765

1766

11A1

11A2

11A3

11A4

11A5

11B1

11B2

11B3

11B4

11B5

12A1

12A2

12A3

12A4

12A5

12B1

12B2

12B3

12B4

12B5

13A1

13A2

13A3

13A4

13A5

13B1

13B2

13B3

13B4

13B5

14A1

14A2

14A3

14A4

14A5

14B1

14B2

14B3

14B4

14B5

15A1

15A2

15A3

15A4

15A5

15B1

15B2

15B3

15B4

15B5

16A1

16A2

16A3

16A4

16A5

16B1

16B2

16B3

16B4

16B5

17B1

17B3

17B4

17B5

44,45

G-U® is a registered trademark of G-U Hardware, Inc. Paddock™ is a registered trademark of Yale® UK. Pella® is a registered trademark of Pella

Corporation. Sierra Pacific Windows® is a registered trademark of Sierra Pacific Industries. Superior® is a registered trademark of Superior Engineered

Products Corporation. Willmar® is a registered trademark of JELD-WEN of Canada Ltd. Andersen® is a registered trademark of Andersen Corporation.

Trillenium® is a registered trademark of Endura Products, Inc. Eagle® is a registered trademark of Eagle Window and Door, Inc, BiltBest® is a registered

trademark of BiltBest Windows and Patio Doors. Ashland® is a registered trademark of Ashland Products, Inc. Caradco®, JELD-WEN, Norco® and Pozzi®

are registered trademarks of JELD-WEN Inc., Oregon, USA. Integrity® and Marvin® are registered trademarks of Marvin Windows and Doors. Milgard®

is a registered trademark of Milgard Windows, Inc. Therma-Tru® is a registered trademark of Therma-Tru Doors®. HOPPE® is a registered trademark

of HOPPE North America, Inc. Hurd® is a registered trademark of Hurd Millwork Company. Kolbe & Kolbe® is a registered trademark of Kolbe & Kolbe

Millwork Company, Inc. Lincoln® is a registered trademark of Lincoln Wood Products, Inc. Loewen® is a registered trademark of Loewen Windows.

PGT® is a registered trademark of PGT Industries. Peachtree® and Vetter® are registered trademark of The Peachtree Companies, Inc. Semco® is a

registered trademark of Semling-Menke Co. Inc. Weathershield® is a registered trademark of Weathershield Mfg. Inc. KML by Andersen® is a

registered trademark of KML by Andersen. Atrium® is a registered trademark of Atrium. KFV® is a registered trademark of KFV. Simpson® is a

registered trademark of Simpson. Signature® is a registered trademark of Signature. Crestline® is a registered trademark of Crestline. Windsor® is a

registered trademark of Windsor. With the exception of Paddock™, none of the aforementioned companies are affiliated with Emtek Products, Inc.

Door Manufacturers listed under each configuration are for reference only and are subject to change.

Some retrofitting may be necessary. Please carefully measure and identify your hardware using the

diagrams and steps listed on page 4 and 5.

Order Placed By Date

Billing Information

Company Name

Address

City State, Zip

Telephone

Shipping Address

EMTEK Products, Inc.

15250 E Staord Street

City of Industry, CA 91744

Tel: 800-356-2741 626-961-0413

Fax: 800-577-5771 626-336-2812

www.emtek.com

Company Name

Address

City State, Zip

Telephone

QTY Finish PriceConfiguration Product Code Lever Style Handing

(LH/RH)

Multi Point Lock Trim Order Form Acct#

PO# Note

Please Fax Order Form to (800) 577-5771

or Email to orders@emtek.com

Subject to the terms and conditions of this warranty, Emtek Products, Inc. (“Company”) extends a lifetime limited warranty to the original consumer

user (“Original User”) of our product (“Product”) against defects in material and workmanship, as long as the Original User occupies the residential

premises upon which the Product was originally installed.

This warranty only applies to the Original User of the Products. This warranty is not transferable. This warranty applies to all products sold on or after

April 2, 2012.

Original User: The Original User will return the defective Product to the Company, free and clear of all liens and encumbrances, transportation

prepaid, accompanied by a statement of defects and proof of purchase.

What Emtek will do: Upon return of the defective Product to Emtek, Emtek’s sole obligation, at its option, is to either repair or replace the Product,

or refund the original purchase price in exchange for the Product.

THE COMPANY MAKES NO OTHER WARRANTY OTHER THAN AS EXPRESSLY STATED HEREIN, AND ALL IMPLIED WARRANTIES, INCLUDING

ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE HEREBY EXCLUDED.

THE COMPANY’S MAXIMUM LIABILITY HEREUNDER IS LIMITED TO THE PURCHASE PRICE OF THE PRODUCT. IN NO EVENT SHALL THE

COMPANY BE LIABLE FOR ANY CONSEQUENTIAL, INDIRECT, INCIDENTAL OR SPECIAL AND/OR PUNITIVE DAMAGES OF ANY NATURE

ARISING FROM THE SALE OR USE OF THE PRODUCT, WHETHER BASED ON CONTRACT, WARRANTY, TORT, STRICT LIABILITY, PATENT

INFRINGEMENT, OR OTHERWISE, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Some local laws do not allow the exclusion or

limitation of incidental or consequential damages, so the above exclusion or limitation may not apply to you. This warranty gives specific legal rights

and a buyer may also have other rights which may vary from state to state.

WHAT IS NOT COVERED: THE FOLLOWING COSTS, EXPENSES AND DAMAGES ARE NOT COVERED BY THE PROVISIONS OF THIS LIMITED WARRANTY:

(I) LABOR COSTS INCLUDING, BUT NOT LIMITED TO, SUCH COSTS AS THE REMOVAL AND REINSTALLATION OF PRODUCT; AND (II) SHIPPING AND

FREIGHT EXPENSES REQUIRED TO RETURN PRODUCT TO EMTEK.

THE PROVISIONS OF THIS WARRANTY DO NOT APPLY TO PRODUCTS: (I) USED IN COMMERCIAL APPLICATIONS; (II) USED IN COMMON AREA

APPLICATIONS; (III) USED FOR PURPOSES FOR WHICH THEY ARE NOT DESIGNED OR INTENDED; (IV) WHICH HAVE BEEN SUBJECTED TO ALTERATION,

ABUSE, MISUSE, NEGLIGENCE OR ACCIDENT; (V) WHICH HAVE BEEN IMPROPERLY STORED, INSTALLED, MAINTAINED OR OPERATED; (VI) WHICH HAVE

BEEN USED IN VIOLATION OF WRITTEN INSTRUCTIONS PROVIDED BY EMTEK; (VII) WHICH HAVE BEEN SUBJECTED TO IMPROPER TEMPERATURE,

HUMIDITY OR OTHER ENVIRONMENTAL CONDITIONS; OR (VIII) WHICH, BASED ON EMTEK’S EXAMINATION, DO NOT DISCLOSE TO EMTEK’S

SATISFACTION NON-CONFORMANCE TO THE WARRANTY. Additionally, this warranty DOES NOT COVER scratches, abrasions, or deterioration due to

the use of paints, solvents or other chemicals.

Finish Warranty: Polished Brass-Lifetime finish carries a lifetime limited finish warranty. There is no finish warranty on Deep Burgundy, Medium

Bronze Patina, Silver Patina, Flat Black Patina, Tumbled White Bronze, and Unlacquered Brass finishes. All other finishes carry a five year finish warranty.

Warranty claims: For warranty service and shipping instructions contact customer service at:

EMTEK Products, Inc.

15250 E. Stafford Street

City of Industry, CA 91744

Tel: (626) 961-0413

LIFETIME LIMITED WARRANTY

EMTEK Products, Inc.

15250 E. Stafford Street

City of Industry • CA 91744

Tel: 800-356-2741 • 626-961-0413

Fax: 800-577-5771 • 626-336-2812

emtek.com

ASSA ABLOY is the global

leader in door opening solutions,

dedicated to satisfying

end-user needs for security,

safety and convenience

BX4-3PTPRICEBK2017

FEBRUARY 2017

Emtek Multi Point Lock Trim Price Book 2017 MP PB Web

Navigation menu

Versions of this User Manual:

Views

Navigation
