Contents
1. Introduction ...................................................................................................................................... - 3 -
2. Installing Guide ................................................................................................................................... - 4 -
3. Uninstalling Guide ............................................................................................................................... - 7 -
4. Launching the Access Manager ............................................................................................................ - 9 -
5. Activating the Wireless Modem ........................................................................................................... - 10 -
6. Setting up the Internet connection ....................................................................................................... - 11 -
7. Display the Statistic information ........................................................................................................... - 11 -
8. Settings and Information ..................................................................................................................... - 12 -
9. Specifications ................................................................................................................................. - 14 -
10. FAQs ............................................................................................................................................ - 15 -
Photon Access Manager
EpiValley
- 3 -
+
1. Introduction
Congratulations on your p urchase of the advan ced an d compact Pho ton+ USB Da ta Modem De vice, desi gned to
operate with the latest digital mobile communication technology.
The Use r Gui de co ntains i mportant information on the proper u se a nd co rrect op eration of Ph oton+ USB Dat a
Modem Device. Please read carefully to ensure optimal performance and also to prevent any misuse of the product,
as any improper usage outside of this User Guide may result in warranty void.
Contents of the pack
1 USB Modem, 1 Quick Guide, 1 Extension Cable, Warranty Card
Operation System Requirements
Windows 2000, XP, Vista and select Linux versions
Supports standard USB 1.1 ( USB 2.0 Compatible )
100Mb free hard disk space or above
128Mb RAM or above
Photon Access Manager
EpiValley
- 4 -
+
2. Installing Guide
Introduction for installation
The Wireless Modem supports an automatic installation function of USB driver and PC-Client tool (Acce ss Manager)
for Windows® 2000, Windows® XP, Windows® Vista 32 / 64.
After plugging the Wireless Modem on your computer, it will mount a CD Driver. It has an execute file as Autorun.exe
program which will check whether your computer needs to install it or not.
If your comp uter need s to inst all it, the Autorun.exe program will execute to the Setup Wizard prog ram for
installation.
Starting Setup
Insert the Wireless Modem into a USB po rt on your comput er. To run the inst allation function, please wait abo ut 1
minute for loading the installation file through the Wireless Modem.
- Autorun.exe program i n the CD Driver of ‘Photon+’ could be disabled on some computers du e to local IT
policies. Contact your system administrator in this case.
- If the AutoRun feature on Windows is disabled on your computer, you can install it m anually. Follow the steps
below for the first time installation.
1) Open Windows Explorer or My Computer, and the CD Driver ‘Photon+’ appears.
2) Clic k CD Driver ‘Photon+’.
3) Execute ‘Autorun.exe’ program for starting the installation.
Photon Access Manager
EpiValley
- 5 -
+
Starting Installation
After the ‘Initializing…’ display in the S tarting Setup, ‘Welcome to the Photon+ Access Manager 1.0 Setup
Wizard’ will appear.
1) Click ‘Next’ button in order to proceed.
2) Default Installation directory is ‘C:\Program Files\TATA\Photon+\’. You can change it to the desired directory
location by Pressing the ‘Browse…’ button. Please use the Default installation directory recommanded.
Click ‘Install’ button to continue the installation.
Photon Access Manager
EpiValley
- 6 -
+
3) When the installation is completed, click ‘Finish’.
USB Driver Installation
After ‘Starting Installation’ stage, the Wireless Modem automatically change to the Modem instead of the CD Driver.
Then you will notice that the device driver s are bein g automatically installed at this stage (Notice th e System tray at
the bottom right of the screen) and once the installation process is completed “Your New hardware is installed and
ready to Use” will be displayed.
IMPORTANT NOTE
• DO NOT unplug the Wireless Modem during the USB driver installation.
• DO NOT move the Access Manager launched automatically during the USB driver installation.
• DO NOT restart the computer during the USB driver installation.
※ If the installation is not complete properbly, you need to have the re-install prcosss
for the Photon+ CM with USB driver. Please note the below article “3. Uninstalling Guide”.
Photon Access Manager
EpiValley
- 7 -
+
3. Uninstalling Guide
Please note t hat in the Access Manager you will not be able to Completely Uninst all the Access Manager if the
Access Manager is running either on desktop or in the system tray.
IMPORTANT NOTE
• Please UNPLUG your Wireless Modem before uninstalling.
• Before uninstalling the Access Manager, please CLOSE the Access Manager on the desktop and
also from the system tray.
(You will see a ‘Photon+ Access Manager’ icon at the bottom right of your desktop screen.)
Uninstalling Step 1
Exit the Access Manager from the system tray as shown below:
Select ‘Exit’ on Tray Menu Æ Click ‘OK’ button.
Uninstalling Step 2
Program could be uninstalled by either accessing the Uninstall menu.
Open START menu ÆPrograms Æ TATA Æ Photon+ Æ Click Uninstall
Or
Open START menu Æ Control Panel Æ Add Remove Programs Æ Change or Remove Programs Æ Click Photon+
Access Manager 1.0.
Click YES to Continue
Photon Access Manager
EpiValley
- 8 -
+
Uninstalling Step 3
Click YES if you want to remove the entire Access manager along with the USB Modem Drivers.
Click NO to just remove the Access Manager application.
- Remember Uninstalling the Modem drivers requires restarting the computer.
Uninstalling Step 4
Click YES to complete, and your computer will restart.
But if you didn ’t unplug the Wireless Modem during the un-installation process, the below window will pop-up. In this
case, click OK to complete and manually restart your computer.
Photon Access Manager
EpiValley
- 9 -
+
4. Launching the Access Manager
Running Access Manager
Plug the Wirel ess Modem in a USB port, and Access M anager will run automatica lly on Windows OS. Otherwi se
double click ‘Photon+’( ) icon in your desktop or select ‘Start Æ All Program Æ TATA Æ Photon+’.
After initialization, the main window of application will be displ ayed on the screen as shown below . The main window
has five Menus with specific functions.
Menu Item Description
Display for the internet connection manager.
Display for the log statistics.
Set General, Lock, Network, Information, Activate Wizard.
Open the e-mail client.
Open the Internet explorer browser.
Status information
The below table lists the status information on the Access Manager.
Status Item Description
Status bar The status bar display for date/time, network signal and packet information.
Network signal Information Photon+ network information
: Indicates the network signal strength.
: Indicates the Photon+ network identification.
Internet Connection When connected, you can check connection time and received packet size, also
the packet speed is shown on the status bar.
: Rx/Tx packet speed on the status bar.
: Current time and total Rx packet.
Tray ICON When presse the Minimize button, the Access Manager will disappear, later you
can see the Tray icon as following.
: Normal Status / : Disconnected Status
Photon Access Manager
EpiValley
- 10 -
+
5. Activating the Wireless Modem
If you see the following me ssage on the Acce ss Mana ger, you should activate the Wirele ss Modem followin g the
audio instructions received from the Server by PC-Voice.
1) Click “Dial *228 to activate Modem” button, the Access Manager will try to call for activation.
2) If the activate call is con nected successfully, ‘PIN Code Dialog’ will pop-up. Input the corre ct PIN Cod e following
the instructions received from the Server.
3) If the activating procedure is successful, “Programming Successful..” message will be displayed.
Photon Access Manager
EpiValley
- 11 -
+
6. Setting up the Internet connection
Click ‘Web’ icon.
Editing Profile
When installing the Wireless Modem the Internet connection profile is created. To edit the profile information follow the
steps below.
1) Click ‘Web’ icon to display the Internet connection profile details.
2) Select the Internet connection profile displayed.
3) Click ‘Edit’.
4) Enter the Internet connection number ‘#777’.
5) Enter the user name as ‘internet’ and password as ‘internet’.
6) Click ‘OK’ button in order to save.
Internet Connection on ‘Web’
Click the Connect button ( ) flashing on the Web screen to establish the connection.
There is a default profile to connect to the TATA Indicom web page. Click the belo w logo at the bottom right of the
Access Manager.
7. Display the Statistic information
Click ‘Log’ Icon.
The ‘Internet Log’ feature provides information on the Internet usages such as Date, Duration, Rx, Tx total bytes.
DISCLAIMER NOTE
This Internet Log feature p rovided with this utility gives only approximat e usage of Data and Time and is strictly
indicative to facilit ate customers to understand approximate consumption, which would vary from a ctual figures
due to vari ous extran eous factors. The se det ails are o nly for your in dication and not use d for bil ling pu rpose
which shall be purely as per the Switch reports - Tata Indicom
Photon Access Manager
EpiValley
- 12 -
+
8. Settings and Information
Click ‘Settings’ Icon
General Settings
Select ‘Settings’ Icon Æ Click ‘General’ tab.
Items Description
Auto termination when Windows go
to power saving mode
The Access Manager will exit automatically when your computer is
switched to power saving mode.
Auto execution when Windows startup The Access Manager will start automatically when the Windo ws is
booted.
Execute the Access Manager
on Background
The Access Manager is minimized on the Tray bar and runs on the
background when you click “Close”.
Lock Settings
Select ‘Settings’ Icon Æ Click ‘Lock’ tab.
The default lo ck value is fo ur zero “0000”. For changi ng the lock value, follow the stpe s mentioned under ‘Change
Lock Code’ setup.
Items Description
General Lock When set, you need to enter the lock code every time you r un the
Access Manager.
Internet Lock When set, you need to en ter the lock code every time you acce ss the
‘Web’ for the Internet connection.
Change Lock Code You can change the lock code value.
1) Enter the current lock value.
2) Enter the new lock value.
3) Retype the new lock value in ‘Confirm New Lock Code’.
4) Click ‘OK’ button.
Photon Access Manager
EpiValley
- 13 -
+
Network Settings
Select ‘Settings’ Icon Æ Click ‘Network’ tab.
You can change the mode of preference as ‘Hybrid Mode’, ‘1xOnly’ and ‘Photon+ Only’.
Preference Mode Description
Hybrid mode The Wireless Modem will operate in dual mode with Photon+ and 1x periodically.
1xOnly T he Wireless Modem will operate only in CDMA1x mode without Photon+.
You may use the 1xOnly mode when y ou st ay an ne twork pla ce u nrecognized for
Photon+.
Photon+ Only The Wireless Modem will operate only in Photon+ mode without CDMA1x.
If you don’t need to use the CDMA 1x data service, and you can di sable the CDMA1x
data service.
Information
Select ‘Settings’ Icon Æ Click ‘Information’ tab.
The information tab displays the following items:
1) Applicati on Information Version.
2) PRL ID information
3) Wireless Modem information as Model name, S/W version, H/W version, MEID and pESN.
Activation Wizard
You can reactivate the Wireless USB Modem in the Setting Menu.
Select ‘Settings’ Icon Æ Click ‘Activate Wizard’ tab Æ Input Lock Code “0000”.
* The default Lock Code is four zero “0000”, and it is different from the General Lock Code.
Please follow step “5. Activation the Wireless Modem” on page 10.
Photon Access Manager
EpiValley
- 14 -
+
9. Specification
Functions Specifications
Main Operation Chip QSC-60 85
CDMA Standard IS-856-A, TIA/EIA/IS-2000, IS-98E
Backwards compatibility with IS-95 A/B
Frequency Band
Cellular 800 Single Band Support
Band Class 0
TX: 824.70 ~ 848.31 MHz
RX: 869.70 ~ 893.31 MHz
Transmit Power 200mW
Power supply USB Power
LEDs 1 Multi-Color LED
RSSI Level: Normal (Green) / Week (Orange) / No service (Red)
PRL/OTA support IS-683C
Roaming (PRL Support) and Over the Air Service Provisioning (OTASP)
Antenna Intenna / Rx Diversity
Interface Type USB Connector / USB 1.1 (&2. 0 Compatible / Full Speed)
T-Flash Not Supported
Voice Jack Supported (Only for activation procedure)
Dimension W :26 D:78 H:10 (mm)
Weight Net (15g), Gift box (71g)
Case Material PC Plastic
Operating environment
Operating temperature range -20C to +60C
S torage temperature range -30C to +65C
Humidity 5% to 95%(non-condensing)
Do not use the Wireless Modem in the following places, or the Wireless Modem may be damaged:
- Where the temperature is too high or too low.
- Where the relative humidity is too high.
- In direct sunlight.
- Where there is dust or dirt.
Photon Access Manager
EpiValley
- 15 -
+
10. FAQs
Q1. What does each LED color stand for?
You can check the signal strength status from LED colors.
Normally it changes from Red → O range → Green gradually when you plug in the modem.
- Green: Strong signal area
- Orange: Weak signal area
- Red: No service
Q2. What shall I do if I cannot access the Internet?
1. Check the network signal strength.
2. Check whether you have activated the wireless online service. You can ask the local network operator
on how to activate it.
3. If the Wireless Modem is activated but still happen it, please check the User name / Password
in the internet profile on Web.
Q3. In spite of “Green” LED, the Access Manager is still not connected!
Firstly, Unplug the Wireless Modem.
Secondly, follow the step “3. Uninstalling Guide” on page 7, and restarting your computer.
Lastly, plug the Wireless Modem again, and follow step “2. Installing Guide” on page 4.
Q4. The software is not running automatically and it shows below screen.
Please follow the step s mentioned the Q3 step a gain. If the same messa ge appears contact the Service
Provider.
Q5. LED color is still “RED”! There’s no LED light!
Your Wireless Modem could defect. Please contact the Service Provider.
Q6. If you need to re-install the Access Manager with the USB Modem driver!
Please follow the steps mentioned the Q3 step again.
Photon Access Manager
EpiValley
- 16 -
+
Q7. The Photon+ auto-installation program did not appear automatically.
In this case, the AutoRun feature of Windows would be disabled by the local IT policies on windows,
so you need to install the PC-Dialer manually, please follow the step “Starting Setup” on Page 4.
Q8. Can not able to connect the Activation call.
Please contact the Service Provider, because your device information would be registered improperly on the
network system.
Q9.The Activation call is connected, but the Activation proceed is unsuccessful.
Please contact the Service Provider, because your device information would be registered improperly on the
network system.
Q10. There is no signal bars on the RSSI indicator of Access Manager and “No service” is displayed,
or the LED of the Wireless Modem is orange or red color.
Your may stay a week signal area for Photon+ service or CDMA1x service, you need to move a good
signal coverage area for getting these service.
Photon Access Manager
EpiValley
- 17 -
+
FCC
The highest SAR value for this CDMA 1x EV-DO USB Modem is 1.08 W/kg (CDMA Cellular Band) The FCC
has granted an Equipment Authorization for this Handheld Printer Terminal with all reported SAR levels
evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this model phone is on
file with the FCC and can be found under the Display Grant section of http://www.fcc.gov /oet / fcc id after
searching on FCC ID: R2NSEC-8380
Additional information on Specific Absorption Rates (SAR)can be found on the Cellular Telecommunications &
Internet Association (CTIA) web-site at http://phonefacts.net.*In the United States and Canada, the SAR limit
for mobile phones used by the public is 1.6watts/kg (W/kg)averaged over one gram of tissue. The standard
incorporates a substantial margin of safety to give additional protection for the public and to account for any
agitations in measurements.
In August 1996 the Federal Communications Commission (FCC) of the United States with its action in Report
and Order FCC 96-326 adopted an updated safety standard for human exposure to radio frequency (RF)
electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the
safety standard previously set by both U.S. and international standards bodies. The design of this phone
complies with the FCC guidelines and these international standards.
For more information about RF exposure, please visit the FCC website at www.fcc.gov
WARNING! Read this information before use
Caution
Modifications not expressly approved by the party responsible for compliance could void the user’s authority
to operate the equipment.
Near-Body Operation
To maintain compliance with FCC RF exposure requirements, maintain a 5mm, separation distance between
the user's body and the Handheld Printer Terminal, including the antenna, whether extended or retracted.
FCC Compliance Information
This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) This device must accept any interference received.
Including interference that may cause undesired operation.
Information to User
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
- Reorient or relocate the receiving antenna.- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/ tv technician for help.
Photon Access Manager
EpiValley
- 18 -
+
MEMO page
