User manual
![](/img.php?id=3859033&img=bg1.png)
1
Contents
Safety .................................................................................................................... 3
Environment ........................................................................................................ 4
1 Getting Started ................................................................................................. 5
1.1 Getting to know your touch phone .................................................... 5
1.2 Installing the SIM card and storage card ........................................... 5
1.3 Charging the Battery .......................................................................... 6
1.4 Starting up the device......................................................................... 6
1.5 Status Icons ........................................................................................ 9
2 Using phone features ..................................................................................... 10
2.1 Turning the phone function on and off ............................................ 10
2.2 Making a call ................................................................................... 11
2.3 Answering and Ending a call ........................................................... 11
2.4 In-call options .................................................................................. 11
2.5 Using call history ............................................................................. 12
2.6 Call settings ...................................................................................... 12
3 Setting on your device .................................................................................... 12
4 ActiveSync ....................................................................................................... 15
5 Contacts .......................................................................................................... 17
6 Exchanging Messages .................................................................................... 19
7 Internet ........................................................................................................... 23
7.1 Ways of Connecting to the Internet ................................................. 23
7.2 Browser ............................................................................................ 24
8 Experiencing Multimedia .............................................................................. 25
8.1 Camera & Picture ............................................................................. 25
8.2 Music................................................................................................ 27
8.3 FM Radio ......................................................................................... 30
9 Other applications .......................................................................................... 30
9.1 Calendar ........................................................................................... 30
2
9.2 Alarm Clock ..................................................................................... 31
9.3 Calculator ......................................................................................... 32
3
Safety
Never attempt to disassemble your phone. You alone are responsible for how
you use your phone and any consequences of its use.
As a general rule, always switch off your phone wherever the use of a phone is
prohibited. Use of your phone is subject to safety measures designed to protect
users and their environment.
Do not use your phone in damp areas (bathroom, swimming pool…). Protect it
from liquids and other moisture.
Do not expose your phone to extreme temperatures lower than - 10°C and
higher than + 55°C.
The physicochemical processes created by chargers impose temperature limits
when charging the battery. Your phone automatically protects the batteries in
extreme temperatures.
Do not leave your phone within the reach of small children (certain removable
parts may be accidentally ingested).
Electrical safety: Only use the chargers listed in the manufacturer’s catalogue.
Using any other charger may be dangerous; it would also invalidate your
warranty. Line voltage must be exactly the one indicated on the charger’s serial
plate.
Aircraft safety: When traveling by plane, you will need to switch your phone
off when so instructed by the cabin crew or the warning signs.
Using a mobile phone may be dangerous to the operation of the aircraft and may
disrupt the phone network.
Its use is illegal and you could be prosecuted or banned from using cellular
networks in the future if you do not abide by these regulations.
Explosive materials: Please comply with warning signs at petrol station asking
you to switch your phone off. You will need to comply with radio equipment
usage restrictions in places such as chemical plants, fuel depots and at any
location where blasting operations are under way.
Electronic equipment: To avoid the risk of demagnetization, do not let
electronic devices close to your phone for a long time.
Electronic medical equipment: Your phone is a radio transmitter which may
interfere with electronic medical equipment or implants, such as hearing aids,
pacemakers, insulin pumps, etc. It is recommended that a minimum separation
of 15 cm be maintained between the phone and an implant. Your doctor or the
4
manufacturers of such equipment will be able to give you any advice you may
need in this area.
Hospitals: Always make sure that your phone is switched off in hospitals when
so instructed by warning signs or by medical staff.
Road safety: Do not use your phone when driving. In order to give your full
attention to driving, stop and park safely before making a call. You must comply
with any current legislation.
Environment
Packaging: To facilitate the recycling of packaging materials, please obey the
sorting rules instituted locally for this type of waste.
Batteries: Spent batteries must be deposited at the designated collection points.
The product: The crossed-out waste bin mark affixed to the product means that
it belongs to the family of electrical and electronic equipment.
To promote the recycling and recovery of waste electrical and electronic
equipment (WEEE) and at the same time safeguard the environment, European
regulations require you to obey the sorting rules instituted locally for this type
of waste.
![](/img.php?id=3859033&img=bg5.png)
5
1 Getting Started
1.1 Getting to know your touch phone
1.2 Installing the SIM card and storage card
You need to remove the back cover before you can install the SIM card and
storage card. Also, you can remove and install the SIM card and storage card
when the phone is turning on.
To remove the back cover
1. Make sure your device is turned off.
2. Firmly hold the device with both hands and the front panel facing down.
3. Push the back cover up with your thumbs until it disengages from the device
and then slide it up to remove.
To install the SIM card
The SIM card contains your phone number, service details, and phone book/
message memory. Your device is supported 2G, 3G (WCDMA) SIM cards.
1. Remove the back cover if it is installed.
2. Locate the SIM card slot, and then insert the SIM card with its gold contacts
facing down and its cut-off corner facing out the card slot.
3. Slide the SIM card completely into the slot.
Note: • The phone can be supported the double SIM cards. The card slot
will be supported GSM or 3G (WCDMA), but one SIM card can use 3G
networks only.
• Some legacy SIM cards may not function with your device. You should
consult with your service provider for a replacement SIM card. There may
be fees for this service.
To install a memory card
To have additional storage for your images, videos, music, and files, you can
purchase a memory card and install it into your device.
1. Make sure that your device is turned off, and then remove the back cover.
2. Locate the memory card slot on the upper part of the exposed right panel.
3. Insert the memory card into the slot with its gold contacts facing down until it
clicks into place.
6
Note: To remove the memory card, press it to eject it from the slot.
1.3 Charging the Battery
Your device comes with a rechargeable lithium-ion battery and is designed to
use only manufacturer-specified original batteries and accessories. Battery
performance depends on many factors, including network configuration, signal
strength, and usage patterns.
Warning: To reduce risk of fire or burns:
• Do not attempt to open, disassemble, or service the battery pack.
• Do not crush, puncture, short external contacts, or dispose of in fire or water.
• Do not expose to temperatures above 60°C (140°F).
• Replace only with the battery pack designated for this product.
• Recycle or dispose of used battery as stipulated by local regulations.
New batteries are shipped partially charged. Before you start using your device,
it is recommended that you install and charge the battery. Some batteries
perform best after several full charge/discharge cycles.
Note: Only the AC adapter and USB sync cable provided with your device must
be used to charge the device.
Connect the USB connector of the AC adapter to the sync connector on your
device, and then plug in the AC adapter to an electrical outlet to start charging
the battery.
As the battery is being charged while the device is on, a charging icon appears
in the title bar of the Home screen. After the battery has been fully charged, a
full battery icon appears in the title bar of the Home screen.
Warning: • Do not remove the battery from the device while you are charging it
using the AC or car adapter.
• As a safety precaution, the battery stops charging before it overheats.
1.4 Starting up the device
Power on/off
To power off your phone, press & hold POWER. On release, the Phone options
menu opens. Select ‘Power off’ and confirm.
To power on again, press & hold POWER.
![](/img.php?id=3859033&img=bg7.png)
7
Silent mode
To silence your phone quickly, press & hold the – volume button to zero
volume.
Screen sleep
After a period of inactivity, your screen will go to sleep (display will turn black).
In sleep, your phone uses less battery power. You can control this behavior:
Set screen timeout period
1. On the Home screen, touch and select Settings.
2. Select Display > Sleep. Select a time from the menu.
Prevent sleep while charging
1. On the Home screen, then touch and select Settings.
2. Select System > Developer options > ‘Stay awake’ check box.
Lock screen & put phone to sleep
Except when on a phone call, from any screen, press POWER (immediately).
While not on a call, to lock your control buttons and screen from accidental
touch activation, press POWER.
You can increase the security of your phone by setting ‘Screen lock’ pattern.
Once set, in order to unlock your screen, you’ll have to draw the correct unlock
pattern. You can set your screen unlock pattern as follows:
1. On the Home screen, touch and select Settings.
2. Select Security & location > Screen lock.
3. Set or change your unlock pattern by selecting ‘Screen lock’ pattern, as
applicable.
4. Follow the prompts to define your pattern.
Note: You must slide your finger along the screen to create the pattern, not
select individual dots. Connect at least four dots.
If you want your pattern to be hidden as you draw it, Switch off ‘Make pattern
visible’.
Home screen
The Home screen is your starting point for using all the applications on your
phone. You can customize your Home screen to display applications and
8
shortcuts as you like.
1. The Home screen actually extends beyond the screen width. On Home screen,
slide your fingertip left and right along the screen to reveal the full width of the
Home screen. This additional space gives you more room to customize Home
with applications and shortcuts.
2. Create Home screen shortcuts:
• On Home screen, touch & hold the blank screen to select ‘SHORTCUTS’.
• Touch and hold to pick up an Application shortcut, a Shortcut to some of your
saved information (such as a play list) for your Home screen. You can place the
shortcut slide your fingertip right along the screen to reveal the width of the
Home screen.
• The application, shortcut and folder appears on Home screen.
3. To create an application shortcut quickly, touch the application tab to reveal
all the application icons, then touch & hold an application icon. Its shortcut is
added to the Home screen.
4. To remove a shortcut from your Home screen, touch & hold and then drag the
item to enter ‘Remove mode’. Without lifting your finger (or you’ll drop out of
remove mode), drag the item to ‘Remove’ button and release.
5. Move objects on the Home screen
• To move an icon or other item on the Home screen, you must first touch &
hold it to enter ‘Remove mode ’.
• Without lifting your finger (or you’ll drop out of remove mode), drag the
object to the new position. To move an item to a section of the Home screen not
in view, move it to the edge of the screen and hold it there for a moment. The
screen view will shift; position the object and release.
6. application quick operation
On Home screen, touch & hold the application icon to open quick operation
window. For example, on the contacts quick operation window, you can add
new contact or view contacts app info.
7. Change application icon shape
On Home screen, Press Menu key to select ‘Home Settings’. On home settings
screen, select ‘Change icon shape’. At present, in addition to system default icon
![](/img.php?id=3859033&img=bg9.png)
9
there are four different options: square, squircle, circle and teardrop.
1.5 Status Icons
Connection status icons
Along the top of your phone screen is the status bar. On the left side, icons will
appear, notifying you of a new message, upcoming calendar event, or something
else you should notice. On the right side of the status bar, you’ll see connection
status icons.
Network signal
E:GSM
3G:WCDMA Data synchronization
Call forward Song is playing
Missed call
WLAN service
connected
SMS/MMS Call in progress
Alarm is set
Wireless services are
off (Airplane mode)
Ringer is off Phone on mute
Bluetooth is on Battery is low
Connected the earphone Battery is charging
Read your notifications
When you see a notification in the status bar, touch the bar and slide your finger
down the screen to open the list of notifications displayed in the sliding window.
Ongoing notifications report activities such as call forwarding ON, current call
status, song playing.
Notifications report the arrival of new messages, calendar events, and alarms.
You can clear notifications list by selecting ‘CLEAR ALL’ notifications at the
bottom of the notifications window.
![](/img.php?id=3859033&img=bga.png)
10
To open the message, reminder, or other notification, you can touch the items.
To close the notifications window, slide your finger up the screen.
If you are temporarily unable to handle some application notice, you only need
to slide the notice until you see the clock icon. Click the clock icon to let this
notice disappear from the notification bar temporarily, and then come back after
set time.
Notes: On the home screen, touch the bar and slide your finger down the
screen to open the list of notifications displayed in the sliding window, you
can touch the icon on the top of the screen to enter the
shortcuts screen, such as Airplane mode, Wi-Fi, Bluetooth, Data connection,
Airplane mode, you can open or close the selected function directly.
2 Using phone features
2.1 Turning the phone function on and off
To enable or disable Airplane Mode
In many countries, you are required by law to turn off the phone while on board
an aircraft. Another way to turn off the phone function is to switch your device
to Airplane Mode.
When you enable Airplane Mode, all wireless radios on your device are turned
off, including the phone function, Bluetooth, and WLAN.
1. Touch > Settings > Network & Internet.
2. Touch ‘Airplane mode’ to enable or disable.
When you disable Airplane mode, the phone function is turned back on and the
previous state of Bluetooth and WLAN are restored.
Adjusting the volume
Press Volume button on the side of the phone to show the volume screen.
If the phone is in vibrating mode, the voice will be muted automatically and the
device will vibrate when there is an incoming call.
![](/img.php?id=3859033&img=bgb.png)
11
2.2 Making a call
On Home screen, you can touch > Phone to enter the dial screen.
1. Touch the on-screen dial pad to enter a number, touch ‘Delete’ button to
delete numbers you’ve entered. Touch & hold to delete all the numbers in the
field.
To dial a call, touch ‘Call’ button (Green icon) to make a call.
To end a call, touch ‘End’ button (Red icon).
2. On the dial screen, touch Call history tab to show the call records,
select an entry listed in the log to call the number.
3. Also, enter Contacts tab that the contacts with phone numbers are
listed. Select a contact, and then select the phone number to dial the call.
2.3 Answering and Ending a call
When you receive a phone call, the incoming voice call screen will appear,
allowing you to either answer or ignore the call.
1. To answer an incoming call, slide ‘ANSWER’ (Blue icon) button rightward.
2. To reject a call, slide ‘REJECT’ button (Red icon) button leftward.
2.4 In-call options
While on a call, reveal the in-call options: Speaker, Mute, Hold, End.
Note that if Bluetooth services are on and you are connected to a hands-free
device, the more menu indicator will show Bluetooth on.
1. Speaker: To use the speaker, select ‘Speaker’. To turn it off, select it again.
The status bar will display the icon when the speaker is on.
2. Mute: To mute your side of the conversation, select ‘Mute’. To turn it off,
select it again. The status bar will display the icon when Mute is on.
3. Hold: To put an active call on hold, select ‘Hold. To resume the call, or take
the call off hold, select it again. If you take a call while already on a call, the
first call will be placed on hold automatically.
4. Add call: If you need to enter numbers while on a call, touch ‘Add call’.
5. Incoming call: During call in progress, if you are on a call (“call in progress”)
when another call comes in (“incoming call”), you have a few choices:
• Answer the incoming call and place the call in progress on hold. To switch
![](/img.php?id=3859033&img=bgc.png)
12
calls at any time, touch ‘Swap calls’.
• If you don’t want to interrupt your call in progress, then touch ‘END’.
6. While on a call, you can start a conference call. Note that you can also have
an additional caller on hold during a conference call, regardless of how many
participants are on the conference.
Note: Whether the group call function can be used depends on whether the
network operator supports and provides such function as well as whether you
have applied for such function. Please contact network operator for details.
2.5 Using call history
1. The missed call icon appears in the title bar when you missed a call.
2. Use ‘Call history’ tab to check who the caller was, or view all your dialed
numbers, and received calls. To open ‘Call history’ tab, touch ‘Call history’
button in the phone screen to enter the call history list.
3. Scroll to select the contact or number you want to dial, touch ‘Call ’ button.
4. Tap the selected contact you want to call, and then you can make to do the
following options of call, send message or view the call details.
2.6 Call settings
On the dialing screen, press MENU > Settings to enter Call settings menu, you
can make the operation of call settings and general settings.
3 Setting on your device
Control phone-wide settings from the Home settings screen: touch and
select Settings.
3.1 Network & Internet
Wi-Fi
1. Select this check box if you prefer to use Wi-Fi for your data connection.
2. Wi-Fi settings: Open the Wi-Fi settings screen; select it from the network list.
Provide your user name or password if required.
SIM cards
You can select to set the information of the SIM card, and activate or deactivate
data connection.
![](/img.php?id=3859033&img=bgd.png)
13
Airplane mode
Airplane mode on/off: When airplane mode is selected, all wireless connectivity
is off. This icon will display in the status bar when airplane mode is
selected.
3.2 Connected devices
Bluetooth
1. Use this check box to turn Bluetooth services on or off.
2. With Bluetooth services on, you can touch Bluetooth to open the Bluetooth
settings screen.
3.3 Apps & notifications
Apps
View all the applications stored on your phone and how much space they
occupy. If you’ve downloaded an application from Android Market, you can
uninstall it from this screen. Select a specific application to:
1. Clear your user data (if you have any associated with a particular
application).
2. Uninstall - If you’ve downloaded an application from Android Market, you
will be able to uninstall it from this screen by selecting Uninstall.
Notification dots
On Apps & notifications screen, touch Notifications and select ‘Allow
notification dots’ checkbox on, then notification dots will be displayed on home
screen for all applications. Note that you can override this setting for individual
apps in the app settings screen.
3.4 Display
Brightness level: Select to open the brightness control, and then slide your
finger along the brightness bar to set the level. In sunlight, increase the level.
Sleep: Select to decide how long your phone must be inactive before the screen
turns off.
Font style: Select to open font manager screen. Go to the online tab, download
the font style from online, and then the downloaded font style will be displayed
on local tab. Go to the loacal tab, you can set the it to default font style or delete
it from your phone device.
14
3.5 Sound
Volumes: Select to open the volume control, and then slide your finger along the
volume bar to set an incoming call ring volume or alarm volume, playing back
music, videos volume.
Phone ringtones: Select to decide on a ring tone to use for incoming calls. Note
that you can override this setting for individual contacts in the Edit contact
details screens.
Default notification sound: Select a ring tone to use for a notification (e.g., new
message). Note that you can override this setting for new Calendar event
notifications, text and multimedia message notifications. Go to the applications
settings screens to select specific ring tones.
Vibrate: Select to have your phone vibrate for incoming calls.
Dial pad touch tones: Select to have a tone sound when you use the on-screen
Dialer.
Touch sounds: Select to have a sound play when you select an item on the
screen either using touch.
3.6 Storage
View and manage the data storage on your phone.
3.7 Security & location
Google Play Protect: It regularly checks your apps and device for harmful
behavior. You will be notified of any security risks found.
Screen unlock pattern: Create a pattern you will be asked to draw before your
screen will unlock. You can select to make the pattern visible or invisible as you
draw it.
SIM card lock settings: Lock your SIM card for extra security. You can also
change your SIM card PIN from this screen. If you don’t know your SIM PIN,
you can obtain it from your wireless operator.
Show passwords: Select to have your password display as you type it.
Location: Select a source for determining your location.
3.8 Users & accounts
Turn on/off synchronization for all services.
3.9 System
![](/img.php?id=3859033&img=bgf.png)
15
Date & time
Set time, time zone, and date: Use Automatic unless you need to override the
network values.
Time format: Select from 12 or 24 hour formats.
Developer options
Developer options is invisible by default. Continuous touch the Build number
several times to make it visible. If you are an application developer, you may be
interested in these settings:
USB debugging: If you want be able to communicate with your phone directly
via USB, select ‘USB debugging’ check box.
Stay awake: To prevent your phone from sleeping while charging (via power
adapter or USB), select ‘Stay awake’ check box.
Erase all data(factory reset)
You can select to reset your phone to factory settings. This will erase all your
data from the phone and require you to sign in and go through the setup screens
to use any of the applications.
About phone
View your phone Status: This screen lists a variety of information, including
your phone number, the network you are currently using, the type of network,
signal strength, whether you are roaming or not, any WLAN addresses you’re
connected to, and more.
View the model number and version information for your phone.
4 ActiveSync
4.1 Data synchronization
Some applications on your phone (Contacts and so on) give you access to the
same personal information that you can add, view, and edit on your computer
using Web applications. This means that when you add, change, or delete your
information in any of these applications on the Web, the updated information
also appears on your phone, and vice verse. Also, if you lose your phone or if
your phone is destroyed, your personal information is not lost and will appear,
as before, on a replacement phone.
![](/img.php?id=3859033&img=bg10.png)
16
This mirroring of information happens through over-the-air data
synchronization, or data “syncing”. Data syncing occurs in the background and
shouldn’t ever get in your way.
Because sending large amounts of data back and forth over the air can take time
and require considerable bandwidth, there are some settings on the phone that
allow you to control data sync.
Sync by application
To control synchronization Contacts, you can do the following:
1. On the Home screen, then touch and select Settings.
2. Select Users & accounts. When any of the applications are synchronizing,
you will see the “sync” icon . You will also see the last time your data was
synchronized.
3. By default, the personal information in Contacts will sync whenever you
make a change or receive a new message. You can change this behavior:
Auto-sync: When selected, Auto-sync will sync Contacts automatically, as you
make changes or receive new messages. When OFF, information will not be
synced automatically, although you can force sync by using the individual
application check boxes described below.
4.2 Bluetooth
You can use Bluetooth to send and receive calls using a headset or hands-free
car kit.
Turn on Bluetooth services
1. On the Home screen, then touch and select Settings.
2. Select Connected devices, and then select ‘Bluetooth’ check box to turn on
Bluetooth services. When on, the Bluetooth icon appears in the status bar.
3. The other Bluetooth devices will see your phone in their scans for Bluetooth
devices.
Name your Bluetooth device
1. Make sure you have turned Bluetooth on.
2. Select Settings > Connected devices > Bluetooth > Device name.
3. Type the name for your device in the dialog box, and then select ‘RENAME’.
4. Your new device name appears on the Bluetooth settings screen.
![](/img.php?id=3859033&img=bg11.png)
17
Pair & connect with Bluetooth devices
Before your phone can communicate with a Bluetooth headset or hands-free car
kit, the devices must “pair & connect”:
1. Make sure you have turned Bluetooth on.
2. Your phone starts scanning for Bluetooth devices within range. As they are
found, the devices appear in the list of Bluetooth devices.
3. To pair with a device in the list, select it.
4. On the pair confirm dialog, select ‘Pair’.
5. Once paired, the device will connect automatically.
6. Pairing and connection status appear under the device name.
7. Once the other Bluetooth device shows “connected” status, you can start
using it to make and receive phone calls.
8. To un-pair with a device, touch the icon on the side of device to open the
context menu. Select FORGET, as appropriate. If you select ‘FORGET’ when
connected, you will be disconnected as well.
Notes: The phone supports only the headset and hands-free Bluetooth profiles,
so if you try to connect to a device that is not a headset or hands-free car kit,
then you will receive an “unable to connect” message.
If you pair with a second headset while connected to the first, the first headset
will remain connected. To switch connection to the second headset you must
manually select that headset again after pairing.
5 Contacts
The contacts on your phone are synced with your account contacts stored on the
Web.
To view the contacts on your phone, touch and select Contacts icon.
All coantacts stored on the phone or google account are listed in the Contacts
screen. You also can select to list the contacts belonging to a specific group (you
can choose which group). Browse through your contacts by sliding your finger
up and down on the screen. Another way to find a contact quickly is to touch
‘SEARCH’ icon, input the first letter of the name you’re looking for, the
![](/img.php?id=3859033&img=bg12.png)
18
matching contacts are appeared on the screen.
From the Contacts screen, you can:
1. Go to Contact details: Select the contact’s name to open the Contact details
screen, where all screen the information you’ve saved for this contact is
displayed.
2. Take action on a contact: On the Contact details screen, you can view, call the
contact’s number, send a text message, add remove a star or edit the contact
details.
3. On the Contact details screen, press MENU to open the context menu. From
the menu you can select to share, place on home screen, or delete the contact.
Add a contact
1. On the Home screen, then touch and select Contacts. Your contact list
appears.
2. Touch the ‘+ ’icon on the right-down of the screen to add new contact.
3. Add all the information you want to store for this contact in the appropriate
fields. You must add some information to save a contact. To change a default
label, select the label name to open the label menu. Select a different label. To
add more fields, select ‘ More fields’.
4. You can assign a Caller ID icon to your contact by touching Caller ID icon.
The Pictures application opens. Navigate to a picture and select it, size the
cropper with your finger. When finished, select ‘SAVE’. The picture is
associated with your contact. If you do not assign an icon, a default android icon
will be assigned.
5. To save your contact, touch ‘SAVE’ icon.
Edit contact details
You can always make changes to the information you’ve stored for a contact:
1. From Contacts, touch the contact you want to open the Contact details screen.
2. Select ‘Edit’ icon. The Edit contact screen appears.
3. Make your edits, then press ‘SAVE’ icon.
Communicate with a contact
From Contacts you can quickly call or text a contact’s default number, as
displayed below their name on the screen. However, to view all the information
19
you’ve stored for a contact, and to initiate other types of communication with
that contact, open the Contact details screen. To open a contact’s details screen,
simply select their name from Contacts.
1. Call a contact: From the contact list, touch the contact you want to open the
Contact details screen. Touch the call number directly to dial that contact’s
number.
2. Send a text or multimedia: To send a text or multimedia message to a contact,
you must have a phone number stored for them in their contact details. From the
Contact details screen, select a phone number and touch ‘Message’ icon, a
Compose screen opens for your new message. Complete your message and
select ‘Send’.
3. Send email to a contact: To send an email message to a contact, you must
have an email address stored for them in their contact details.
• Select the contact you want to email. Their Contact details screen opens.
• In the Send email section, select the email address. If you are fetching POP3 or
IMAP email accounts to your phone, then select the account you wish to use to
send. A Compose screen opens for your new message.
• Complete your message, select ‘Send’.
SIM contacts importer
If you have stored names and phone numbers on your SIM card, you can add
these to the Contacts stored on your phone by selecting this settings option.
From the contact list, press MENU to select Settings > ‘Import’, you can select
to import from google account, SIM card, phone storage or memory card,
once the list of names and numbers appears you can:
Import only certain names/numbers in the list - Select the name/number you
want to import, then repeat for others as you wish. After you finished selecting
the name/number, select OK, and it will be imported.)
6 Exchanging Messages
6.1 SMS and MMS messaging
To open the SMS & MMS Messaging application, on the Home screen, then
![](/img.php?id=3859033&img=bg14.png)
20
touch and select Messaging icon.
About text and multimedia messages
SMS messages are also known as “text” messages which can contain emoticons
and can each be around 160 characters. If you continue to type after the limit is
reached, your message will be delivered as one, but count as more than one
message. These are called “concatenated” messages.
MMS messages are also known as “multimedia” or “picture” messages and can
contain text, emoticons, emotion Sticker, location, picture, audio, and video
files.
When you compose a message, the phone will automatically convert a text
message into a multimedia message as soon as you add an attachment, or if you
address the message using an email address rather than a phone number.
View the message from the message list
Select a message thread in the list to open it for reading. When open, the
individual messages appear stacked on the screen, much like with instant
messaging conversations (or chats).
Note that messages you send are also listed in the Read view.
1. Reading multimedia messages
If you have selected to auto-download your multimedia messages, then the
message will be download automatically.
From a message read view, you can do the following:
1. To view details about a particular message, in the Read view, touch & hold
the message to open the context menu. Select View details icon.
2. Reply to a message: Simply start typing your message in the text box at the
bottom of the screen to reply to a message. You can always press ‘+’ icon and
select to an attachment to convert it to a multimedia message. Select ‘Send’ icon
when ready.
3. Links in messages: If a message contains a link to a Web page, it will be
selectable. To view the Web page in the Browser, simply select it.
4. Delete messages: Your messages will be saved until you explicitly delete
them.
• Delete one message in a thread - With the message thread open in Read view,
21
touch & hold the individual message you want to delete to open the context
menu, and then select ‘Delete’ icon.
• Delete all messages in a thread - From the message list, you can also delete an
entire thread from the message list by pressing & holding the thread, then touch
‘Delete’ icon on the top of the screen.
• Delete all message threads - From the message list, press MENU, select the
threads what you want to delete and then select ‘Delete’ icon.
Compose text and multimedia messages
1. Touch ‘+’ New conversation icon. The New conversation screen opens. If you
want to start group conversation, select ‘Start group conversation’ icon on the
New conversation screen, the New Group conversation screen opens.
2. Add recipients by typing a name, phone number, or email address in the
‘Type name or number’ field. Matching contacts will appear. Select the recipient
or continue typing. Add as many recipients as you wish. If you send the
message to an email address, the message will automatically convert from a text
to a multimedia message.
3. To add an attachment, touch ‘+’ icon. Adding an attachment will always
convert the message to a multimedia message. Select from audio or picture files.
You can select to take a new picture if you want, or record an audio file. Any
recordings you make will be stored automatically in Music application in a play
list named “My recordings”. To remove an attachment, select the attachment’s
‘Remove’ button.
4. Type your message. As you type, you’ll be able to track how many
characters/messages you’re creating. Remember that text messages have a limit
around 160 characters. Once you go over that limit, a new message is actually
created but automatically joined into one when received.
5. Select ‘Send’ when ready. You can also save a draft.
6. As your message sends, progress displays. If you see this icon to the right of
the message, it means your message is still being delivered.
Save message as draft
While composing, press BACK, your message automatically saves as a draft.
Text and multimedia message settings
![](/img.php?id=3859033&img=bg16.png)
22
To set text and multimedia message preferences, from the message list, press
MENU and select ‘Settings’.
6.2 Email accounts
Add an email account
You can fetch messages from gmail, exchange, POP3 or IMAP accounts. Follow
these steps:
1. On the Home screen, then touch and select email application.
2. The Set up new account screen appears.
3. Type your account email address and password.
4. Select ‘Next’.
Follow the prompts to type the email server, protocol, and other account
information yourself. After your account settings have been verified, select
‘Next’ to go to your Inbox.
6. To add more accounts, from an Inbox or your Accounts screen, press MENU
and select ‘Add account’.
Use your email account
Once you’ve set up an account, you can do the following:
1. Refresh Inbox: From the Inbox, slide your finger down to update your Inbox
with any previously-unfetched email.
2. Read email: You can display or collapse the messages in your Inbox by
selecting Inbox. Unread messages display with black bolded text.
3. Forward, Reply, Reply all: You can forward, reply, or reply all to an email
message from the Inbox. From the Inbox, touch the message to open message
view screen. Select the action you want to take.
4. Compose new
From the Inbox: 1. Press ‘Compose’ icon. 2. Add recipients by typing a name or
address in the ‘To’ field. Matching contacts will appear. Select the recipient or
continue typing the address. Add as many as you wish. 3. Type a subject and
message. 4. Select ‘Send’, or press Menu and select ‘Save draft’, or ‘Discard’.
Pressing BACK will also save as draft unless you have not typed anything.
5. Delete message
From the Inbox: 1. Expand the Inbox to display the messages. 2. Touch & hold
23
the message you want to delete. 3. Select ‘Delete’. 4. Your message is moved to
the Trash.
6. Empty Trash: Once you’ve moved a message to the Trash, to empty messages
in the Trash you should go to your Inbox, press MENU and select ‘Trash’ to
enter the Trash. From the trash, touch ‘EMPTY TRASH NOW’.
Note that the message is only deleted from your phone, not from the account
server.
7. Remove an email account: You can always remove a email account from your
phone. Go to your Inbox, press MENU and select ‘Settings’. Touch the account
to open account settings screen. Press Menu and select Manage accounts. On
Users & accounts screen, touch the account you want to remove, and then select
REMOVE ACCOUNT. You will be asked to confirm before the account is
removed.
Edit account settings
To open your Account settings screen, do the following:
1. From your account Inbox, press MENU and select ‘Settings’ > touch the
account you want to set.
2. The Account settings screen appears.
Add another account
To add another account, go to your Inbox, press MENU and select ‘Settings’ >
‘Add accounts’.
7 Internet
7.1 Ways of Connecting to the Internet
Your device’s networking capabilities allow you to access the Internet or your
corporate network through WLAN or mobile data (if SIM card supported).
You can also add and set up a VPN or proxy connection.
WLAN
WLAN provides wireless Internet access over distances of up to 100 meters
(300 feet). To use WLAN on your device, you need access to a wireless access
point or “hotspot”.
Note: The availability and range of your device’s WLAN signal depends on the
![](/img.php?id=3859033&img=bg18.png)
24
number, infrastructure, and other objects through which the signal passes.
7.2 Browser
To open the Browser, touch and select Browser applicaiton.
The Browser always opens to the last Web page you were viewing. The first
time you enter the Browser after powering on, your home page will display.
You can change your home page by pressing MENU > Settings >General > Set
homepage.
The Browse screen
From the Browse screen you can do the following:
1. Go to a Web page: Make sure the focus is not on a text box and then start
typing the URL.
2. Add a bookmark: Bookmark the Web page you are currently viewing:
• Press MENU and select ‘Save to bookmarks’.
• Confirm the URL and name, and then select ‘OK’.
• To view all your bookmarks, press MENU and select Bookmarks/History.
3. Refresh a Web page: To refresh the contents of the current page, press MENU
and select ‘Refresh’.
Open pages in separate windows
You can keep more than one Web page open by using multiple windows to
display the pages. You can open up to eight windows.
Open a new window: From a Web page, Slide the finger down to reveal browser
navigation bar, and touch ‘Windows’ icon. The Current windows screen opens,
showing the Web page you started from, plus a “new window”. Touch ‘+’ icon.
Your home page opens in a new window. To return to one of the other windows,
slide the finger down to reveal browser navigation bar, and touch ‘Windows’
icon.. Select the page you want to view.
Manage bookmarks
You can store as many bookmarks as you want on your phone.
Press MENU and select ‘Bookmarks/History’. The Bookmarks screen opens.
1. Send bookmarked page’s URL: Touch & hold the bookmark you want to
open. The context menu opens. Select ‘Share link’. Select to share your picture
via Messaging (MMS), or another application (if you have another application
25
installed on your phone that supports sharing).
2. View bookmarked page: Touch & hold the bookmark you want to open. The
context menu opens. Select Open or Open in new window.
3. Edit bookmark: Touch & hold the bookmark you want to e open. The context
menu opens. Select ‘Edit bookmark’. The edit bookmark dialog box opens.
Type your change and select ‘OK’.
4. Delete a bookmark: Touch & hold the bookmark you want to open. The
context menu opens. Select ‘Delete bookmark’. You will be asked to confirm.
5. Set bookmark as homepage: Touch & hold the bookmark you want to open.
The context menu opens. Select ‘Set as homepage’. The selected bookmark will
be set as homepage.
Set your home page
You set your home page from the Settings screen:
1. Press MENU and select Settings. The Settings screen opens.
2. In the settings screen, select ‘General’ > ‘Set home page’ to open the dialog
box.
3. On the dialog box, select any options to set as homepage.You also can select
Other and type the URL of the page you want to set as home, and then select
‘OK’.
Download Web files and applications
Before you download any files or applications using the Browser, note the
following:
Applications downloaded from the Web can be from unknown sources. To
protect your phone and personal data, only download applications from sources
you trust, such as Android Market.
8 Experiencing Multimedia
8.1 Camera & Picture
All the pictures you can capture or view on your phone are stored on the phone
storage.
Take a picture
![](/img.php?id=3859033&img=bg1a.png)
26
Captured pictures are saved to the “DCIM” folder on the phone storage. Before
you take a picture, wipe the sensor window to remove any small amounts of oil.
1. To open the Camera, on the Home screen, touch and select Camera icon.
2. The Camera opens in capture mode. Frame your picture within the screen and
hold the phone steady. Touch Camera button to capture. Continue to hold the
camera steady for a second after you hear the shutter sound. The picture you
have captured is saved to Gallery application.
View your pictures
To view the pictures you’ve captured, as well as any you’ve stored on your
memory card or the phone storage, go to Gallery application:
1. To open Pictures, on the Home screen, touch and select Gallery icon.
2. Depending on how many pictures you’ve stored, they may take a few minutes
to load.
3. If you’ve stored your pictures in folders on your Memory card, then the
folders will display as separate “albums”. The top left album always contains all
the pictures in all the albums.
4. The individual pictures display in a grid in thumbnail format. You can select
to display smaller or large thumbnails in Settings.
5. To open a picture in full-screen view, touch the picture. Once in full-screen,
slide your finger left and right along the screen to scroll through the pictures
within that album.
Picture options
You can do the following while in Pictures. Note: In all the instructions below,
you can also touch & hold a picture to open the context menu to access all
actions, rather than open the picture in full-screen view.
1. View full-screen: Select a picture to open it in full-screen view.
2. Share a picture: In full-screen view, select Share. Select to share your picture
via Messaging (MMS), or another application (if you have another application
installed on your phone that supports sharing).
3. Set as wallpaper: In full-screen view, press MENU and select Set picture as.
From the menu that opens select Wallpaper. Select Set wallpaper, then wallpaper
setting window opens. By selecting different options, you can set the picture as
27
home screen wallpaper, lock screen wallpaper or both home screen and lock
screen wallpaper.
4. Set as contact picture: In full-screen view, press MENU and select Set picture
as. From the menu that opens, select Contact icon. Your contact list opens.
Select the contact you want to associate with the picture. On the contact photo
edit screen, drag the sizing spots of the cropper in or out to size. Touch & drag
the cropper to move it within the picture.
When you’re happy with the cropped area, select ‘SAVE’. The picture will now
appear in the Contact details screen, as well as on any incoming call
notifications.
5.Crop picture: In full-screen view, press MENU and select Crop. On the picture
edit screen, drag the edge of the cropper in or out to size. Touch & drag the
center of the cropper to move it within the picture.
When you are happy with the cropped area, select ‘SAVE’. Press BACK to
cancel the crop. The cropped picture is saved to Gallery.
6. Rotate picture: In full-screen view, press MENU and select Rotate left or
Rotate right. Your picture rotates.
7. Delete picture: In full-screen view, press MENU and select Delete.
The picture will be removed from the Memory card after you confirm.
8. View picture details: In full-screen view, press MENU and select Details.
The picture details window opens. You can see the title, resolution, file size, and
time of the picture.
8.2 Music
To open your music Library, on the Home screen, touch Music icon.
Your music is organized into four categories: Artists, Albums, Songs, and Play
lists. Select a category to view the lists within each. Once in a category, keep
selecting until you reach the music you want to play.
For example, if you select the Artists category, you will see a list of artists in
A-Z order. If you select an artist, the list opens to display that artist’s albums.
Select an album, and the album’s song list displays.
All the music you can listen to on your phone is stored on the phone storage or
the memory card.
28
Load music onto yourPhone Storage
Read the instructions below to add music to your phone storage.
1. Attach your phone to your computer using a USB cable that came in the box.
Select ‘Transfer files’ check box on ‘Use USB to’ window.
2. On your computer, find the mobile deive and open the phone storage.
3. Open ‘Music’ folder and copy music files into it. If you want, create folders
within “Music” to organize your music further. If you want to use certain music
files as phone, notification, or alarm ring tones.
Note: If you do not want a ringtone to appear in your music Library but you do
want it to be available as a ringtone, and thencopy music to the ‘Ringtones’,
‘Notifications’, or ‘Alarms’ folder outside your ‘music’ folder.
5. When finished copying, remove the USB cable from your phone and
computer.
Load music onto your Memory card
Read the instructions below to add music to your memory card.
1. Mount your memory card to your computer by doing one of the following:
Remove the memory card and insert it into a card reader attached to your
computer; or, attach your phone to your computer using a USB cable that came
in the box. If you use this method, select Transfer files check box on ‘Use USB
to’ window.
2. On your computer, find the mounted USB drive and open it.
3. Although your phone will find all music files on your memory card, it’s
advisable to keep the number of files or folders at the root level to a minimum.
So, if you wish, create a folder at the top-level called “music” (or whatever you
want) to store your files.
4. Open this folder and copy music files into it. If you want, create folders
within “music” to organize your music further. If you want to use certain music
files as phone, notification, or alarm ring tones.
Note: If you do not want a ringtone to appear in your music Library but you do
want it to be available as a ringtone, and then create the ‘ringtones’,
‘notifications’, or ‘alarms’ folder outside your ‘music’ folder.
5. When finished copying, close the USB drive window and un-mount or eject
29
the drive as required by your computer's operating system. Remove the USB
cable from your phone and computer.
Play back music
At any level in your Library, touch & hold a listing (a song, artist, album, or
playlist) to open the context menu. Select Play to begin play and go to the
Playback screen. You can do the following using the Playback screen:
1. Shuffle songs: Shuffle plays songs in random order. Touch to toggle shuffle
on and off. When the con is grey, shuffle is off.
2. Repeat mode: Touch to step through repeat modes: repeat all songs, repeat
current song, don’t repeat (grey icon).
3. Go to any point in song: Slide fingertip in progress bar to desired point in a
song.
4. Playback control: from left to right icons: Go to beginning song, Pause/
resume play and Go to next of song.
If a song is playing while you are on the Library screen, you can switch to the
Playback screen quickly by selecting the lower song bar.
Playlists
You can create as many playlists as you wish. Note that the ‘Recently added’
playlist is a system playlist and cannot be deleted or renamed. Also, if you make
any voice recordings as part of a MMS message, they will be stored
automatically in a playlist called “My recordings”.
Create a playlist on your phone
1. From the Library, select a category. From the list that appears, navigate to the
artist, album, or song that you want on a playlist.
2. Touch & hold the artist, album, or song to open the context menu.
3. Select Add to playlist.
4. In the Add to playlist menu that opens, select New to create a new playlist, or
one of the existing playlists.
5. The song(s) are added.
Manage your playlists
Go to the Library screen and select ‘Playlists’. All your playlists appear.
Touch & hold the playlist to open the context menu. You can do the following
30
from this screen: Play, Edit (rearrange songs), Delete and Rename.
Create ringtones from songs
You can set any of your songs as a phone ringtone:
1. From the Library, navigate to a song you want to use as a phone ringtone.
2. Touch & hold the song in the list to open the context menu.
3. Select Use as phone ringtone. The ringtone is set as your default incoming
call ringtone.
4. Now, when you go to Home > Settings > Sound, and select a phone ringtone,
your song will be listed as an option.
Delete music from memory card
All the music you play on your phone is stored on the phone storage or the
inserted memory card. From your phone, you can delete music stored on the
card:
1. From the Library screen, select the Artists, Albums, or Songs category.
2. Go to the screen that shows the artist, album, or song that you want to delete.
3. Touch & hold the item to open the context menu.
4. Select ‘Delete’. You will be asked to confirm that you want to delete the item
from your memory card or the phone storage.
8.3 FM Radio
This device provides radio function.
Note: Within doors or shielded environment, the receiving effect of radio may
be affected. You can improve the effect in the following ways: Near window,
adjust the position of earphone cable or adopt manual adjustment.
9 Other applications
9.1 Calendar
Calendar views
You can view your calendar in a variety of ways. Touch the date on the left-top
of the screen to select from Day, Week, Month or Agenda.
Create an event
From any of the views, press MENU and select ‘New event’ to open the new
![](/img.php?id=3859033&img=bg1f.png)
31
Event details screen.
• Type the event name that appears in Day view.
• Type the location.
• Select date & time.
• Description can be as long as you like.
• Select a calendar if you display more than one.
• Set default repetition time.
• Set a default reminder time.
• Set online presence: available or busy.
• Select calendar privacy from Default (as defined when calendar was created),
Private, or Public.
When finished, select ‘Done’. Pressing BACK also saves the event.
Tip: Create an event quickly in the Day or Week view by selecting an empty
time slot. A new Event details screen appears. The ‘From’ field contains the
selected time slot.
9.2 Alarm Clock
To open Alarm Clock, on the Home screen, then touch and select Clock
icon. The Alarm clock offers as many alarms as you want.
Set an alarm
Two alarms are set up for you, ready to customize. All two alarms are turned off
by default. Select the check box to turn on the alarm. If no day shows under the
set time, the alarm will go off once when the set time is reached.
To begin, select one of the default alarms to open Alarm settings.
Set the following options:
Alarm: Select the check box to turn alarm on (checked) or off (cleared). This is
the same check box that appears on the main Alarm Clock screen.
Time: The time the alarm will go off is shown. To change this time, select Time
to open the time setting screen. Set the time you want, and then select OK.
Repeat: The current repeat selection is shown. To change the setting, select
Repeat and make a selection from the options. To have your alarm will only go
off once at the set time, don’t select any of the options. A one-time alarm is
shown on the Alarm Clock screen without any days under the set time.
![](/img.php?id=3859033&img=bg20.png)
32
Ring tone: The current ring tone selection is shown. Select Ring tone to pick
another ring tone that will play when the alarm rings. (When you select a ring
tone, it plays briefly.) Note that when your alarm goes off, the ring tone will
play for five minutes etc which you can set from Alarms menu .
Vibrate: Select this check box to have your phone vibrate when it goes off.
Once your alarm goes off, you will receive an alert with the options to Snooze
(for 10 minutes etc.) or Dismiss.
Add more alarms
To add more than two alarms, from the main Alarm Clock screen, touch ‘+’
icon.
Change clock display
You can change the appearance of the clock displayed on the main Alarm Clock
screen:
1. Go to the main Alarm Clock screen.
2. Touch MENU on the right top of the screen and select ‘Style’ > Didital or
Analog.
3. Select ‘Display time with seconds’ checkbox to display time with seconds on
the main clock screen.
Change date & time display
You can change the format of the time displayed in your CLCOK screen from
the global Settings screen:
1. Go to the main Alarm Clock screen, then press MENU and select Settings.
2. Select ‘Change date & time’. The Date & time settings screen appears.
3. Select ‘Use 24 hour format’ check box if you wish to use that rather than 12
hour format.
9.3 Calculator
To open Calculator, on the Home screen, then touch and select the
Calculator icon.
Calculator panels
In the calculator, you can enter numbers and perform basic addition, subtraction,
multiplication, and division or insert advanced operators or delimiters, such as
sine, cosine, tangent, square root, parentheses, etc.
33
FCC Caution:
Any Changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the
following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
SAR tests are conducted using standard operating positions accepted by the
FCC with the phone transmitting at its highest certified power level in all tested
frequency bands, although the SAR is determined at the highest certified power
level, the actual SAR level of the phone while operating can be well below the
34
maximum value.
Before a new model phone is a available for sale to the public, it must be tested
and certified to the FCC that it does not exceed the exposure limit established
by the FCC, tests for each phone are performed in positions and locations (e.g.
at the ear and worn on the body) as required by the FCC
For body worn operation, this model phone has been tested and meets the FCC
RF exposure guidelines when used with an accessory designated for this product
or when used with an accessory that contains no metal and that positions the
handset a minimum of 10mm from the body.
Non-compliance with the above restrictions may result in violation of RF
exposure guidelines
