SureColor T-Series
User’s Guide
Epson SureColor T-Series User’s Guide
Copyrights and Trademarks
2
Copyrights and
Trademarks
No part of this publication may be reproduced, stored in a retrieval
system, or transmitted in any form or by any means, electronic,
mechanical, photocopying, recording, or otherwise, without the prior
written permission of Seiko Epson Corporation. The information
contained herein is designed only for use with this Epson printer. Epson
is not responsible for any use of this information as applied to other
printers.
Neither Seiko Epson Corporation nor its affiliates shall be liable to the
purchaser of this product or third parties for damages, losses, costs, or
expenses incurred by the purchaser or third parties as a result of
accident, misuse, or abuse of this product or unauthorized
modifications, repairs, or alterations to this product, or (excluding the
U.S.) failure to strictly comply with Seiko Epson Corporation’s
operating and maintenance instructions.
Seiko Epson Corporation shall not be liable for any damages or
problems arising from the use of any options or any consumable
products other than those designated as Original Epson Products or
Epson Approved Products by Seiko Epson Corporation.
Seiko Epson Corporation shall not be held liable for any damage
resulting from electromagnetic interference that occurs from the use of
any interface cables other than those designated as Epson Approved
Products by Seiko Epson Corporation.
EPSON®, Epson UltraChrome®, EPSON EXCEED YOUR VISION,
EXCEED YOUR VISION and their logos are registered trademarks or
trademarks of Seiko Epson Corporation.
Microsoft®, Windows®, Windows Vista® and PowerPoint® are registered
trademarks of Microsoft Corporation.
Apple®, Macintosh®, Mac® and OS X® are registered trademarks of Apple
Inc.
Intel® is a registered trademark of Intel Corporation.
PowerPC® is a registered trademark of International Business Machines
Corporation.
Adobe®, PostScript®, Photoshop®, Elements®, Lightroom®, and Adobe®
RGB (1998) are either registered trademarks or trademarks of Adobe
Systems Incorporated in the United States and/or other countries.
HP-GL/2® and HP RTL® are registered trademarks of Hewlett-Packard
Corporation.
Android is a trademark of Google Inc.
General Notice: Other product names used herein are for identification
purposes only and may be trademarks of their respective owners. Epson
disclaims any and all rights in those marks.
© 2014 Seiko Epson Corporation. All rights reserved.
9/14
CPD-41582
Epson SureColor T-Series User’s Guide
3
Contents
Copyrights and Trademarks
Introduction
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . 6
When choosing a place for this product. . . . . . . . . . 6
When setting up this product . . . . . . . . . . . . . . . . . . 6
When using this product . . . . . . . . . . . . . . . . . . . . . . 6
When handling the ink cartridges. . . . . . . . . . . . . . . 7
Note on this Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Meaning of Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Illustrations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Operating System Versions . . . . . . . . . . . . . . . . . . . . 7
Printer Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Back . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Roll 2 unit (T7270D/T5270D) . . . . . . . . . . . . . . . . . 13
Roll paper adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Screen View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
High Productivity . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
High Resolution. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Easy to Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Notes on Usage and Storage . . . . . . . . . . . . . . . . . . . . . 20
Installation space . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Notes when using the printer. . . . . . . . . . . . . . . . . . 20
Notes when not using the printer . . . . . . . . . . . . . . 21
Notes on handling ink cartridges . . . . . . . . . . . . . . 21
Notes on handling paper . . . . . . . . . . . . . . . . . . . . . 22
Provided Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Contents of the Software Disk . . . . . . . . . . . . . . . . . 24
Summary of the Printer Driver . . . . . . . . . . . . . . . . 26
Basic Operations
Loading and Removing the Roll Paper . . . . . . . . . . . . 27
Attaching the Roll Paper Adapter . . . . . . . . . . . . . . 27
Loading Roll Paper on Roll 1 . . . . . . . . . . . . . . . . . . 28
Loading Roll 2
(T7270D/T5270D only) . . . . . . . . . . . . . . . . . . . . . . 31
Cutting the roll paper . . . . . . . . . . . . . . . . . . . . . . . . 32
Removing Roll paper or Roll 1. . . . . . . . . . . . . . . . . 34
Removing Roll 2
(T7270D/T5270D only) . . . . . . . . . . . . . . . . . . . . . . 35
Loading and Removing Cut Sheets . . . . . . . . . . . . . . . 37
Loading Cut Sheets . . . . . . . . . . . . . . . . . . . . . . . . . .37
Removing Cut Sheets. . . . . . . . . . . . . . . . . . . . . . . . .39
Loading and Removing Poster Board . . . . . . . . . . . . .39
Loading Poster Board . . . . . . . . . . . . . . . . . . . . . . . .39
Removing Poster Board . . . . . . . . . . . . . . . . . . . . . .42
Viewing and Changing Media Settings . . . . . . . . . . . .43
Replacing Paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Using the Paper Basket (T7270/T5270/T3270) . . . . .45
Storing and Opening . . . . . . . . . . . . . . . . . . . . . . . . .46
Adjusting the Position. . . . . . . . . . . . . . . . . . . . . . . .47
Using the Large-Capacity Paper Basket
(T7270D/T5270D) . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
Storing and Adjusting the Position . . . . . . . . . . . . .49
Using the Auto Take-up Reel Unit (T7270 Only) . . .51
Using the Control Panel . . . . . . . . . . . . . . . . . . . . . .52
Attaching the Paper . . . . . . . . . . . . . . . . . . . . . . . . . .52
Removing Paper from the Auto Take-up Reel Unit .
55
Basic Printing Methods
(Windows) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
Basic Printing Methods
(Mac OS X) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
Printable area. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
Roll Paper Printable Area . . . . . . . . . . . . . . . . . . . . .63
Cut Sheets Printable Area. . . . . . . . . . . . . . . . . . . . .63
Using the Power Off Timer. . . . . . . . . . . . . . . . . . . . . .64
Canceling Printing . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65
Saving to and Reprinting on the Op-
tional Hard Disk Unit
Function Summary. . . . . . . . . . . . . . . . . . . . . . . . . . . . .67
Saving Print Jobs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68
Viewing and Printing Saved Print Jobs . . . . . . . . . . . .69
Copying and Scanning
Large Copying and Large Scanning using the Multi-
function Scanner (Option) . . . . . . . . . . . . . . . . . . . . . .71
Function Summary . . . . . . . . . . . . . . . . . . . . . . . . . .71
Starting Copy Center. . . . . . . . . . . . . . . . . . . . . . . . .72
Address Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72
Loading Documents . . . . . . . . . . . . . . . . . . . . . . . . .73
Large Copying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75
Large Scan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77
Changing the document eject direction . . . . . . . . .77
Contents
Epson SureColor T-Series User’s Guide TOC.FM (A4 size) Rev.
Contents
4
Operations for Image Files that were Scanned or Re-
ceived. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
More Ways to Print
Enlargements and Horizontal and Vertical Banners 80
Fitting Documents to the Width of the Roll Paper. .
80
Choosing a Print Size . . . . . . . . . . . . . . . . . . . . . . . . 82
Fitting Documents to the Output Size . . . . . . . . . . 83
Printing at Non-Standard Sizes . . . . . . . . . . . . . . . . . . 84
Printing CAD Drawings . . . . . . . . . . . . . . . . . . . . . . . . 86
Printing in the CAD / Line Drawing mode of the
printer driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Printing while Emulating HP-GL/2 and HP RTL. 87
Switching Roll Paper Automatically before Printing
(T7270D/T5270D Only) . . . . . . . . . . . . . . . . . . . . . . . . 87
Switching to Roll 1/Roll 2 by Paper Type. . . . . . . . 87
Switching to Roll 1/Roll 2 by Document Size . . . . 89
Switching to Roll 1/Roll 2 by Roll Length . . . . . . . 90
Borderless Printing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Types of Borderless Printing Methods . . . . . . . . . . 92
Supported Media Sizes for Borderless Printing . . 92
About Roll Paper Cutting. . . . . . . . . . . . . . . . . . . . . 94
Setting Procedures for Printing. . . . . . . . . . . . . . . . 95
Correct color and print . . . . . . . . . . . . . . . . . . . . . . . . . 97
Multi-Page/Poster Printing. . . . . . . . . . . . . . . . . . . . .100
Folded Double-Side (Windows only). . . . . . . . . . 100
N-up. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .101
Poster (Windows only). . . . . . . . . . . . . . . . . . . . . .102
Printing Multiple Documents (the Layout Manager)
(Windows Only). . . . . . . . . . . . . . . . . . . . . . . . . . . . . .107
Setting Procedures for Printing. . . . . . . . . . . . . . .107
Saving and Recalling Settings. . . . . . . . . . . . . . . . .108
Color Management Printing
About Color Management . . . . . . . . . . . . . . . . . . . . .109
Color Management Print Settings . . . . . . . . . . . . . . .109
Setting profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . .110
Setting color management with the applications. . .110
Setting color management with the printer driver . 111
Color management printing by Host ICM (Win-
dows) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .111
Color management printing by ColorSync (Mac OS
X) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .112
Color management printing by Driver ICM
(Windows Only) . . . . . . . . . . . . . . . . . . . . . . . . . . .113
Tips for Using the Printer Driver
(Windows)
Displaying the Settings Screen . . . . . . . . . . . . . . . . . .115
With the Start button . . . . . . . . . . . . . . . . . . . . . . .115
Displaying Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .116
Click the Help Button to Display. . . . . . . . . . . . . .116
Right-click on the item you want to check and dis-
play. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .116
Customizing the Printer Driver . . . . . . . . . . . . . . . . .117
Saving various settings as your Select Settings. . .117
Adding Media Types . . . . . . . . . . . . . . . . . . . . . . . .117
Rearranging display items . . . . . . . . . . . . . . . . . . .118
Overview of the Utility Tab. . . . . . . . . . . . . . . . . . . . .119
Uninstalling the printer driver . . . . . . . . . . . . . . . . . .121
Tips for Using the Printer Driver
(Mac OS X)
Displaying the Settings Screen . . . . . . . . . . . . . . . . . .122
Displaying Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .122
Using Epson Printer Utility 4 . . . . . . . . . . . . . . . . . . .122
Starting Epson Printer Utility 4 . . . . . . . . . . . . . . .122
Epson Printer Utility 4 Functions . . . . . . . . . . . . .122
Uninstalling the printer driver . . . . . . . . . . . . . . . . . .124
Removing EPSON LFP Remote Panel 2. . . . . . . .124
Using the Control Panel Menu
Menu Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . .125
Menu List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .126
Menu Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . .132
Print Queues menu . . . . . . . . . . . . . . . . . . . . . . . . .132
Paper menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .134
The Maintenance Menu . . . . . . . . . . . . . . . . . . . . .138
Setup menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .139
Large Copy / Large Scan menu . . . . . . . . . . . . . . .153
Maintenance
Adjusting the Print Head. . . . . . . . . . . . . . . . . . . . . . .156
Checking for clogged nozzles. . . . . . . . . . . . . . . . .156
Cleaning the print head. . . . . . . . . . . . . . . . . . . . . .157
Minimizing Print Misalignments (Head Alignment)
158
Replacing Consumables. . . . . . . . . . . . . . . . . . . . . . . .161
Replacing Ink Cartridges . . . . . . . . . . . . . . . . . . . .161
Replacing Ink Maintenance Tanks . . . . . . . . . . . .162
Replacing the Cutter . . . . . . . . . . . . . . . . . . . . . . . .163
Cleaning the Printer . . . . . . . . . . . . . . . . . . . . . . . . . . .165
Epson SureColor T-Series User’s Guide TOC.FM (A4 size) Rev.
Contents
5
Cleaning the outside . . . . . . . . . . . . . . . . . . . . . . . .165
Cleaning the inside . . . . . . . . . . . . . . . . . . . . . . . . .165
Cleaning the Multifunction Scanner (option) . . . . .166
Problem Solver
What to do When a Message is Displayed . . . . . . . .168
When a Maintenance Call/Service Call Occurs . . . . 172
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .173
You cannot print (because the printer does not
work) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173
The printer sounds like it is printing, but nothing
prints . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .175
The prints are not what you expected . . . . . . . . .175
Feeding or ejecting problems. . . . . . . . . . . . . . . . .178
Others . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .181
Trouble when the optional Multifunction Scanner is
connected . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .182
Appendix
Options and Consumable Products. . . . . . . . . . . . . .185
Supported Media . . . . . . . . . . . . . . . . . . . . . . . . . . . . .187
Epson Special Media Table. . . . . . . . . . . . . . . . . . .187
Usable Commercially Available Paper Size . . . . . 195
Before printing on non-Epson media. . . . . . . . . .196
Notes When Moving or Transporting the Printer . 197
Notes When Moving the Printer. . . . . . . . . . . . . .197
Notes on Transporting . . . . . . . . . . . . . . . . . . . . . .198
Notes when reusing the printer . . . . . . . . . . . . . . . 199
System Requirements. . . . . . . . . . . . . . . . . . . . . . . . . .200
System Requirements of the Printer Driver. . . . . 200
System Requirements for CopyCenter . . . . . . . . .200
Specifications Table . . . . . . . . . . . . . . . . . . . . . . . . . . .201
Standards and Approvals . . . . . . . . . . . . . . . . . . . .203
Where To Get Help
Technical Support Web Site . . . . . . . . . . . . . . . . . . . .204
Contacting Epson Support . . . . . . . . . . . . . . . . . . . . .204
Before Contacting Epson . . . . . . . . . . . . . . . . . . . .204
Help for Users in North America . . . . . . . . . . . . .205
Software License Terms
OPEN SOURCE SOFTWARE LICENSE . . . . . . . . .206
Bonjour . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .207
Other Software Licenses . . . . . . . . . . . . . . . . . . . . . . .212
Info-ZIP copyright and license . . . . . . . . . . . . . . . 212
Epson SureColor T-Series User Guide
Introduction
6
Introduction
Important Safety
Instructions
Read all of these instructions before using the printer.
Also be sure to follow all warnings and instructions
marked on the printer.
When choosing a place for this
product
OPlace this product on a flat, stable surface that is
larger than this product. This product will not
operate properly if it is tilted or at an angle.
OAvoid places subject to rapid changes in
temperature and humidity. Also keep it away from
direct sunlight, strong light, or heat sources.
OAvoid places subject to shocks and vibrations.
OKeep this product away from dusty areas.
OPlace this product near a wall outlet where the plug
can be easily unplugged.
When setting up this product
ODo not block or cover the openings in this
product’s cabinet.
ODo not insert objects through the slots. Take care
not to spill liquid on this product.
OThis product’s power cord is for use with this
product only. Use with other equipment may
result in fire or electric shock.
OConnect all equipment to properly grounded
power outlets. Avoid using outlets on the same
circuit as copiers or air control systems that
regularly switch on and off.
OAvoid electrical outlets controlled by wall switches
or automatic timers.
OKeep the entire computer system away from
potential sources of electromagnetic interference,
such as loudspeakers or the base units of cordless
telephones.
OUse only the type of power source indicated on the
product’s label.
OUse only the power cord that comes with this
product. Use of another cord may result in fire or
electric shock.
ODo not use a damaged or frayed power cord.
OIf you use an extension cord with this product,
make sure the total ampere rating of the devices
plugged into the extension cord does not exceed
the cord’s ampere rating. Also, make sure the total
ampere rating of all devices plugged into the wall
outlet does not exceed the wall outlet’s ampere
rating.
ODo not attempt to service this product yourself.
OUnplug this product and refer servicing to
qualified service personnel under the following
conditions:
The power cord or plug is damaged; liquid has
entered the product; the product has been dropped
or the cabinet damaged; the product does not
operate normally or exhibits a distinct change in
performance.
OIf you plan to use the printer in Germany, observe
the following:
To provide adequate short-circuit protection and
over-current protection for this printer, the
building installation must be protected by a 10 or
16 amp circuit breaker.
OIf damage occurs to the plug, replace the cord set
or consult a qualified electrician. If there are fuses
in the plug, make sure you replace them with fuses
of the correct size and rating.
When using this product
ODo not put your hand inside this product or touch
the ink cartridges during printing.
ODo not move the print heads by hand; otherwise
you may damage this product.
Epson SureColor T-Series User Guide
Introduction
7
OAlways turn the product off using the Power
button on the control panel. When this button is
pressed, the Power light flashes briefly then goes
off. Do not unplug the power cord or turn off the
product until the Power light stops flashing.
When handling the ink
cartridges
OKeep ink cartridges out of the reach of children
and do not drink.
OIf ink gets on your skin, wash it off with soap and
water. If it gets in your eyes, flush them
immediately with water.
OBefore installing the new ink cartridge in the
printer, shake it back and forth horizontally in five
centimeter movements about 15 times within five
seconds.
OUse the ink cartridge before the date printed on its
package.
OUse up the ink cartridge within a year of
installation for best results.
ODo not dismantle the ink cartridges or try to refill
them. This could damage the print head.
ODo not touch the IC chip on the side of the
cartridge. This may affect normal operation and
printing.
OThe IC chip on this ink cartridge retains a variety
of cartridge-related information, such as the ink
cartridge status, so that the cartridge may be
removed and reinserted freely. However, each time
the cartridge is inserted, some ink is consumed
because the printer automatically performs a
reliability check.
OIf you remove an ink cartridge for later use, protect
the ink supply area from dirt and dust, and store it
in the same environment as this product. Note that
there is a valve in the ink supply port, making
covers or plugs unnecessary, but care is needed to
prevent the ink from staining items that the
cartridge touches. Do not touch the ink supply
port or surrounding area.
Note on this Guide
Meaning of Symbols
Illustrations
Unless otherwise noted, the illustrations in this
documentation show the T7270.
Operating System Versions
In this documentation, the following abbreviations are
used.
Windows refers to Windows 8.1, 8, 7, Vista, XP.
OWindows 8.1 refers to Windows 8.1, Windows 8.1
Pro, and Windows 8.1 Enterprise.
OWindows 8 refers to Windows 8, Windows 8 Pro,
and Windows 8 Enterprise.
OWindows 7 refers to Windows 7 Home Basic,
Windows 7 Home Premium, Windows 7
Professional, and Windows 7 Ultimate.
OWindows Vista refers to Windows Vista Home
Basic Edition, Windows Vista Home Premium
Edition, Windows Vista Business Edition,
Windows Vista Enterprise Edition, and Windows
Vista Ultimate Edition.
!Warning: Warnings must be followed to avoid
serious bodily injury.
!Caution: Cautions must be followed to avoid
damage to this product or bodily
injury.
cImportant: Notes contain important
information on the operation of this
product.
Note: Tips contain useful or additional
information on the operation of this
product.
Epson SureColor T-Series User Guide
Introduction
8
OWindows XP refers to Windows XP Home
Edition, Windows XP Professional x64 Edition,
and Windows XP Professional.
OWindows Server 2012 refers to Windows Server
2012 Essentials Edition, Server 2012 standard
Edition.
OWindows Server 2008 refers to Windows Server
2008 Standard Edition and Windows Server 2008
Enterprise Edition.
OWindows Server 2008 x64 refers to Windows
Server 2008 x64 Standard Edition, Windows
Server 2008 x64 Enterprise Edition, Windows
Server 2008 R2 Standard Edition, and Windows
Server 2008 R2 Enterprise Edition.
OWindows Server 2003 refers to Windows Server
2003 Standard Edition and Windows Server 2003
Enterprise Edition.
OWindows Server 2003 x64 refers to Windows
Server 2003 x64 Standard Edition and Windows
Server 2003 x64 Enterprise Edition.
Macintosh refers to OS X.
OOS X refers to OS X 10.5.8 and later versions.
Epson SureColor T-Series User Guide
Introduction
9
Printer Parts
Front
The illustration shows the T7270. The operation is the same even when the shape of the paper basket or other items
are different.
APrinter cover
Open this cover when cleaning the printer or clearing jams.
BPoster board support
Raise this support so that you can place the media on it when printing on poster board. The support ensures that poster
board feeds smoothly.
U“Loading and Removing Poster Board” on page 39
CInk Maintenance Tank covers
Open these covers when replacing the Ink Maintenance Tank.
Some models have only the right cover.
U“Replacing Ink Maintenance Tanks” on page 162
Epson SureColor T-Series User Guide
Introduction
10
DPaper basket/Large-capacity paper basket
Output from the printer collects in this basket, keeping the media clean and free of creases.
U“Using the Paper Basket (T7270/T5270/T3270)” on page 45
U“Using the Large-Capacity Paper Basket (T7270D/T5270D)” on page 49
ECasters
There are two casters on each leg. The casters are normally kept locked once the printer is in place.
FStack guides
(T7270/T5270/T3270 only)
Select a guide according to the size of the media output to the paper basket.
U“Using the Paper Basket (T7270/T5270/T3270)” on page 45
GStack guide switch lever
(T7270/T5270/T3270 only)
Use to choose a stack guide.
HCartridge cover
Open when replacing ink cartridges.
U“Replacing Ink Cartridges” on page 161
IInk cartridges
Install all ink cartridges into each slot.
JAC inlet
Connect the supplied power cable here.
KOption port
Use when connecting the options such as the Multifunction Scanner.
LUSB port
Use when connecting to a computer using a USB cable.
MLAN port
Connects the LAN cable.
NData light
The network connection status and data reception are indicated by a lit or flashing light.
On : Connected.
Flashing : Receiving data.
OStatus light
The color indicates the network transmission speed.
Off : 10Base-T
Red : 100Base-T
Green : 1000Base-T
PControl panel
U“Control panel” on page 14
Epson SureColor T-Series User Guide
Introduction
11
QAlert lamp
This lamp lights or flashes when an error occurs.
Lights
or
flashes
: An error occurred. How the lamp lights or flashes varies with the type of error. The control panel displays a
description of the error.
Off : No error.
RRoll rest
When loading roll paper, place it on this rest and attach the roll paper adapters.
U“Attaching the Roll Paper Adapter” on page 27
SAdapter guides
Guides for attaching roll paper. Move the roll along these guides to attach it to the adapter holder.
U“Attaching the Roll Paper Adapter” on page 27
TRoll lock lever
A lever that locks roll paper in place after the roll is attached to the adapter holder.
UAdapter holder
The roll paper adapter is placed in this holder after the roll paper is attached.
VPaper slot
The slot through which roll paper and single sheets are fed during printing.
Feed single sheets one at a time.
WPrint head
Fires ink via high density nozzles while moving left and right to print.
XRoll paper cover
Cover to protect the roll paper. Except when loading or removing roll paper, it should be closed when using the printer.
YPaper eject guide
Guides paper output from the printer smoothly into the paper basket.
Epson SureColor T-Series User Guide
Introduction
12
Back
The illustration shows the T7270D.
AOption slot
Slot to connect the optional hard disk unit or Adobe PostScript 3 Expansion Unit.
BRoll 2 unit connector
(T7270D/T5270D only)
Connect the connection cable of the Roll 2 unit.
Normally the cable is connected when using the printer.
CRear cover
(T7270D/T5270D only)
When roll paper loaded to the Roll 2 unit is jammed, open the cover, and then remove the jammed paper.
Normally closed when using the printer.
U“Roll paper jam” on page 179
Epson SureColor T-Series User Guide
Introduction
13
Roll 2 unit (T7270D/T5270D)
The illustration shows the T7270D.
Roll paper adapter
Use the supplied roll paper adapter when loading roll
paper onto the printer.
U“Attaching the Roll Paper Adapter” on page 27
APaper slot
Insertion slot to feed roll paper.
U“Loading Roll 2 (T7270D/T5270D only)” on page 31
BDrawer handles
When you load or remove roll paper, hold these
handles and pull out or push in the Roll 2 unit.
U“Loading Roll 2 (T7270D/T5270D only)” on page 31
CAdapter guides
Move the roll paper adapter loaded with a roll along
these guides to attach it to the adapter holder.
U“Loading Roll 2 (T7270D/T5270D only)” on page 31
DAdapter holder
The roll paper adapter is placed in this holder after the
roll paper is attached.
ERoll lock lever
A lever that locks roll paper in place after the roll is
attached to the adapter holder.
AAdapter lock lever
Lift to unlock, lower to lock. Unlock when attaching roll
paper to the adapter, lock once the roll is attached.
BSize lever
Position according to the size of the roll core.
Epson SureColor T-Series User Guide
Introduction
14
Control panel
APbutton (power button)
Turns the power on and off.
BPlight (power light)
The printer’s operational status is indicated by a lit or
flashing light
On : The power is on.
Flashing : The printer is receiving data or cleaning
the print head or performing other
operations in the course of being shut
down.
Off : The power is off.
C(button (Load/Remove Paper button)
Pressing this button displays the Load/Remove Paper
menu. Instructions for loading or removing the paper
can be displayed by highlighting either Remove
Paper or the type of paper currently loaded and then
pressing the Z button. Follow the on-screen
instructions to load or remove the paper.
DScreen
Displays the printer's status, menus, error messages,
and so on. U“Screen View” on page 15
EMenu button
Displays the menu for the tab currently selected in the
display. (Excluding the and + tabs.)
U“Using the Control Panel Menu” on page 125
Fybutton (back button)
If menus are displayed, pressing this button takes you
up one level in the menu hierarchy. U“Menu
Operations” on page 125
Gl/rbuttons (left and right arrow buttons)
OUse these buttons to select tabs. The selected tab
is highlighted and the content of the info display
area is updated for the selected tab.
U“Screen View” on page 15
OIf menus are displayed, these buttons can be used
to position the cursor or delete characters when
entering text for items such as Setting Name or IP
Address.
Hu/dbuttons (Up/Down buttons)
When menus are displayed, these buttons can be used
to highlight items or options. U“Menu Operations”
on page 125
Epson SureColor T-Series User Guide
Introduction
15
Screen View
IZbutton
ODisplays the menu for the tab currently selected in
the display.
U“Using the Control Panel Menu” on page 125
OWhen menus are displayed and an item is
highlighted, pressing this button displays the
sub-menu for the highlighted item.
OIf pressed while a parameter is selected from the
Menu, the parameter is set or executed.
Jbutton (Help button)
Except when printing is in progress, pressing this
button displays the Help menu. Highlight an item and
press the Z button to view help for the highlighted
item.
K"button (Maintenance button)
Displays the Maintenance menu, which is used for
nozzle checks and head cleaning.
U“Adjusting the Print Head” on page 156
LWbutton (pause/cancel button)
OThe printer enters pause status if this is pressed
while printing. To release the pause status, press
the W button again, or select Pause Cancel on
the screen and then press the Z button. To
cancel print jobs being processed, select Job
Cancel on the screen and then press the Z
button.
OPressing this button while a menu or help is
displayed closes the menu or help and returns the
printer to ready status.
M)button (Feed/Cut Media button)
OThis button is used with roll paper only. If the
printer is loaded with cut sheets or poster board,
pressing this button will have no effect.
OIt is used to manually cut roll paper using the
built-in cutter.
U“Manual cut method” on page 33
OIf printing is not currently in progress and the
printer is loaded with roll paper, you can feed
paper ahead by pressing first this button and then
the d button. Press the u button to rewind. Keep
the d button pressed to feed the paper up to 3 m.
Keep the d button pressed to rewind the paper
up to 20 cm.
When the u button is used to rewind roll paper,
the paper will pause when the end of the roll
reaches the starting print position. Release the
button and then press it again to resume.
Epson SureColor T-Series User Guide
Introduction
16
AMessage
Displays the printer’s status, operation, and error
messages.
U“What to do When a Message is Displayed” on page
168
BTabs/Info Display Area
The tab/info display area contains the seven tabs listed
below.
Use the l/r buttons to select a tab.
Information on the selected tab appears in the info
display area.
,: The Print Queues Tab
Print job information appears in the info display
area.
When you press the Menu button, the Print
Queues menu appears.
U“Print Queues menu” on page 132
The Info Display Area
The name of the job being printed appears
when the printer driver is used.
If an optional hard disk unit or Adobe PostScript
3 Expansion Unit is installed, it also shows the
number of held jobs, if any.
cImportant:
A flashing , icon indicates that an optional
hard disk unit or Adobe PostScript 3
Expansion Unit is transmitting data to the
printer. Do not disconnect the power cord or
turn the printer off while the icon is flashing.
Failure to observe this precaution could
corrupt the data on the hard disk unit or
Adobe PostScript 3 Expansion Unit.
.: The Paper Tab
The information of loaded paper appears in the
info display area.
When you press the Menu button, the Paper
menu appears.
U“Paper menu” on page 134
The Info Display Area
Displays the Source and Media Type of the
loaded paper.
When roll paper is used, it also shows the roll
width. When Roll Paper Remaining is On, it
shows the amount of roll paper remaining.
When the length remaining reaches or falls
below the value selected for Remaining Alert, a
icon appears above the tab icon and an
alert like that shown below is displayed to warn
that the printer is nearing the end of the roll.
When roll paper is loaded on Roll 1/Roll 2 of the
T7270D/T5270D, you can check which is
selected (in use) by looking at the icon.
: Indicates a roll that is selected (in use).
The number indicates either Roll 1 or
Roll 2.
: Indicates a roll in a standby state.
If there is an automatic switching
command, this roll is selected for
printing.
Automatic switching of roll paperU“Switching
Roll Paper Automatically before Printing
(T7270D/T5270D Only)” on page 87
:The Ink Tab
Shows ink cartridge status in the info display
area.
The Info Display Area
As shown in the following illustrations, the icon
changes based on the status of the ink cartridge.
Normal Warning or error
Epson SureColor T-Series User Guide
Introduction
17
1 Status indicators
: No error. The height of the
indicator changes with the level of
ink remaining.
: Ink is low. You need to prepare a
new ink cartridge.
: Ink cartridge is expended; replace
with a new ink cartridge.
: An error occurred. Check the
message on the screen, and clear
the error.
2Ink color codes
C:Cyan
Y : Yellow
M:Magenta
M
K
: Matte Black
P
K
: Photo Black
-: The Maintenance Tab
Displays Ink Maintenance Tank status in the info
display area.
When you press the Menu button, the
Maintenance menu appears.
U“The Maintenance Menu” on page 138
The Info Display Area
As shown in the following illustrations, the icon
changes based on the status of the Ink
Maintenance Tank.
Normal Warning or error
1
1 Status indicators
: No error. The height of the
indicator corresponds to the
amount of space remaining.
: The Ink Maintenance Tank is
nearing the end of its service life.
You need to prepare a new Ink
Maintenance Tank.
: Ink Maintenance Tank is at the end
of its service life. Replace the Ink
Maintenance Tank with a new one.
/:The Setup Tab
Shows the specified IP address in the info
display area.
When you press the Menu button, the Setup
menu appears.
U“Setup menu” on page 139
: The Large Copy Tab
This tab is displayed only when the optional
Multifunction Scanner is connected.
In this tab, select a job you want to do, and then
press the Z button. When the optional hard
disk unit or Adobe PostScript 3 Expansion Unit is
installed, you can also use the scan function.
U“Large Copying and Large Scanning using
the Multifunction Scanner (Option)” on page 71
Epson SureColor T-Series User Guide
Introduction
18
Features
The main features of this printer are described below.
High Productivity
High-speed printing
The speeds of the print head and paper feed have been
increased for faster printing.
The printer is equipped with a high-speed rotary cutter
for quick cutting, significantly increasing productivity.
Paper basket holds consecutive sheets
(T7270/T5270/T3270)
The paper basket accommodates up to 20 sheets of
A2/A1/A0/ARCH D/US D/US E plain paper,
promoting automation for improved productivity.
U“Using the Paper Basket (T7270/T5270/T3270)” on
page 45
Large-capacity paper basket which can continually
accommodate various mixed paper sizes
(T7270D/T5270D)
This basket can hold various mixed paper sizes from
A1 Landscape size and smaller.
In addition, if you set the basket to the compact
position, you can reduce the protrusion of the paper
basket so it can be used even in narrow spaces.
U“Using the Large-Capacity Paper Basket
(T7270D/T5270D)” on page 49
Improved operability with an easy to see and use
color screen
Designed for intuitive operation, the large, brightly-lit,
color LCD display is easy to understand and easy to
use.
The large display offers detailed, easy-to-understand
error messages and illustrated guides to loading paper.
U“Screen View” on page 15
Checking current operating status from a distance
with an alert lamp
Errors are immediately obvious even at a distance,
thanks to the large, highly visible alert lamp. This helps
prevent any wasted time when printing has stopped
due to running out of ink or paper.
Loading two roll papers and increasing productivity
(T7270D/T5270D)
You can load roll paper at two locations, Roll 1 (upper
section) and Roll 2 (lower section). This feature
increases productivity in the following manner.
OBecause you can load different types of roll paper
in Roll 1 and Roll 2, specify the media type on the
printer driver during printing, and switch printing
between Roll 1 and Roll 2, you do not need to reset
the paper every time you change the media type.
U“Switching to Roll 1/Roll 2 by Paper Type” on
page 87
OIf you load different sizes of roll paper in Roll 1 and
Roll 2 in advance, the printer switches to the roll
paper with the smaller margin during printing
automatically in accordance with the document
size of the print job. This feature makes it easy to
conserve paper.
U“Switching to Roll 1/Roll 2 by Document Size”
on page 89
OWhen you load the same types and sizes of roll
paper in Roll 1 and Roll 2 in advance, and the
printer determines that the roll paper remaining is
shorter than the print length, it switches to the roll
paper that is longer than the print length
automatically and continues printing. This feature
allows continuous unattended operation.
U“Switching to Roll 1/Roll 2 by Roll Length” on
page 90
High Resolution
Thanks to newly developed Epson UltraChrome XD
Ink technology, the printer can be used for high-quality
posters and CAD drawings.
CAD drawings: clear, legible, and with unsurpassed
water resistance
Newly-developed, high-density Matte Black ink
enables the printer to produce extremely detailed
drawings.
Pigmented inks are used for all colors for unsurpassed
water resistance, allowing print results to be safely
carried out-of-doors.*1
Epson SureColor T-Series User Guide
Introduction
19
The printer driver offers a line drawing mode, making
it easier to optimize printing for line drawing and,
through unsurpassed reproduction of line drawing and
fine lines in the form of connected lines, diagonals, and
curves, ensuring the best possible results when the
printer is used for drawings.
Vivid, highly lightfast posters and displays*2
Our new magenta ink improves the reds so important
to posters, making them even more noticeable.
The printer driver offers a poster mode that simplifies
the printing of vivid posters. Posters with vivid hues
can be printed simply by selecting poster mode.
Thanks to the pigmented inks used for all colors, the
results are highly water-resistant and can be used for
short-term outdoor display. They are also extremely
lightfast and fade-resistant and can be safely displayed
in direct sunlight.
Easy to Use
Spindle-free roll paper adapter makes loading roll
paper a snap
The lack of a spindle makes it possible to load and
remove roll paper even in environments where space is
at a premium.
To load roll paper, simply place it on the roll rest and
attach roll paper adapters to both ends. The roll rest is
low, making it easy even for short workers to load
paper.
U“Attaching the Roll Paper Adapter” on page 27
Ease of Maintenance
Roll paper and all replacements, including ink
cartridges, Ink Maintenance Tanks, and cutters, are
installed from the front, allowing the printer to be
placed against a wall. The printer does not have to be
moved to allow rear access.
Choose from three sizes of cartridge according to
the task
Choose from 110, 350, and 700 ml cartridges according
to the frequency with which the printer is used. Use
cost-effective 700 ml cartridges for high-volume poster
printing or select individual 110 or 350 ml cartridges
for monochrome printing.
New printer driver offers greatly improved
ease-of-use
Print settings can be optimized simply by choosing the
desired use or target. This spares you the trouble of
adjusting print settings individually.
On startup, the printer driver automatically checks the
status of the paper loaded in the printer and displays it
in the Media Settings dialog box, preventing errors
caused by failure to check paper status before printing.
The printer driver displays printer settings graphically,
reducing errors caused by inappropriate choices of
settings.
Multifunction Scanner that can be integrated and
installed with the printer
You can connect the optional Multifunction Scanner to
the top of the printer when you use the dedicated stand.
This feature reduces the installation space and allows
you to load documents and print copies at one
location.
Furthermore, this feature provides a stress-free
workflow because printing starts at high speed after
copying.
U“Large Copying and Large Scanning using the
Multifunction Scanner (Option)” on page 71
*1 When you are printing for outdoor use, use
lamination processing.
*2 It is not possible to obtain the same results for all
paper.
Epson SureColor T-Series User Guide
Introduction
20
Notes on Usage and
Storage
Installation space
Make sure that you secure the following space, clear of
any other objects, so that paper ejection and
consumable replacement are not obstructed.
See the “Specifications Table” for the external
dimensions of the printer.
U“Specifications Table” on page 201
T7270/T5270/T3270
T7270D/T5270D
When the Multifunction Scanner is installed
The following illustration shows the installation space
when the dedicated stand is used to attach the
Multifunction Scanner.
Notes when using the printer
Note the following points when using this printer to
avoid breakdowns, malfunctions, and print quality
decline.
OWhen using the printer, observe the operating
temperature and humidity range described in the
"Specifications Table".
U“Specifications Table” on page 201
Even when the conditions above are met, you may
not be able to print properly if the environmental
conditions are not suitable for the paper. Be sure to
use the printer in an environment where the
paper's requirements are met. For more details, see
the documentation supplied with the paper.
Also, when operating in dry areas, air conditioned
environment, or under direct sunlight, maintain
the appropriate humidity.
* When printing on poster board, ensure that there is
sufficient space both in front of and behind the printer.
U“Loading and Removing Poster Board” on page 39
5.9 in. (150 mm)
0.39 in.
(10 mm)
23.6 in.
(600 mm) 5.9 in. (150 mm)
5.9 in. (150 mm)
19.7 in.
(500 mm)
5.9 in. (150 mm)
0.39 in.
(10 mm) 3.9 in.
(100 mm)
* When the thickness of the document to be loaded is
.01 inch (0.25 mm) or larger, ensure that there is
sufficient space both in front of and behind the printer.
U“How to Load Documents” on page 74
*1 For T7270D/T5270D
*2 For T7270/T5270/T3270
0.39 in.
(10 mm)
0.39 in.
(10 mm)
3.9 in. (100 mm)
19.7 in. (500 mm) *1
23.6 in. (600 mm) *2
Epson SureColor T-Series User Guide
Introduction
21
ODo not install the printer next to heat sources or
directly in the path of air from a ventilator or air
conditioner. Failure to observe this precaution
could result in the print head nozzles drying and
clogging.
OThe print head may not be capped (i.e., may not
move to the right-hand side) if an error occurs and
the printer is turned off without first resolving the
error. Capping is a function for automatically
covering the print head with a cap (lid) to prevent
the print head from drying out. In this case, turn
on the power and wait a while until capping is
performed automatically.
OWhen the power is on, do not remove the power
plug or cut the power at the breaker. The print
head may not be capped properly. In this case, turn
on the power and wait a while until capping is
performed automatically.
OEven when the printer is not in use, some ink will
be consumed by head cleaning and other
maintenance operations needed to keep the print
head in good condition.
Notes when not using the
printer
If you are not using it, note the following points when
storing the printer. If it is not stored correctly, you may
not be able to print properly the next time it is used.
OIf you do not print for a long time, the print head
nozzles may become clogged. We recommend that
you print once a week to prevent the print head
from clogging.
OThe roller may leave an impression on paper that is
left in the printer. This can also cause wavy or
curled paper resulting in paper feeding problems
or the print head could be scratched. Remove any
paper when storing.
OStore the printer after confirming that the print
head has been capped (the print head is positioned
at the far right). If the print head is left uncapped
for a long time, the print quality may decline.
OTo prevent the accumulation of dust and other
foreign matter in the printer, close all covers before
placing it in storage.
If the printer will be not be used for an extended
period, protect it with an anti-static cloth or other
cover.
The print head nozzles are very small, and they can
become clogged easily if fine dust gets on the print
head, and you may not be able to print properly.
OWhen turned on after an extended period of
disuse, the printer may automatically perform
head cleaning to ensure print quality.
Head cleaning will end after about 10 to 15
minutes.
Notes on handling ink cartridges
Note the following points when handling ink
cartridges to maintain good print quality.
OThe supplied ink cartridges and Ink Maintenance
Tank are for use during the initial charging. The
supplied ink cartridges and Ink Maintenance Tank
will be require replacement relatively quickly.
OWe recommend that ink cartridges be stored at
room temperature out of direct sunlight and used
before the expiry date printed on the packaging.
OTo ensure good results, use all the ink in the
cartridge within a year of installation.
OInk cartridges that have been stored at low
temperatures for an extended period should be
allowed to return to room temperature over a
period of four hours.
ODo not touch the IC chips on the tops of the ink
cartridges. You may not be able to print properly.
OInstall all ink cartridges into each slot. You cannot
print if any of the slots are empty.
ODo not leave the printer without ink cartridges
installed. The ink in the printer may dry,
preventing it from printing as expected. Leave ink
cartridges in all slots even while you do not use the
printer.
Note:
If the print head is not capped, turn the printer on, and
then turn it off.
Epson SureColor T-Series User Guide
Introduction
22
OThe ink level and other data are stored in the IC
chip, allowing cartridges to be used after being
removed and replaced.
OTo avoid getting dirt on the ink supply port, store
the removed ink cartridge properly. The ink
supply port has a valve in it so it does not need to
be capped.
ORemoved ink cartridges may have ink around the
ink supply port, so be careful not to get any ink on
the surrounding area when removing the
cartridges.
OTo maintain the quality of the print head, this
printer stops printing before ink cartridges are
completely expended.
OAlthough the ink cartridges may contain recycled
materials, this does not affect printer function or
performance.
ODo not dismantle or remodel ink cartridges. You
may not be able to print properly.
ODo not drop or knock ink cartridges against hard
objects; otherwise, the ink may leak.
Notes on handling paper
Note the following points when handling and storing
the paper. If the paper is not in good condition, print
quality may decline.
Check the documentation supplied with each paper.
Notes on handling
OUse Epson special media under normal room
conditions (temperature: 59 to 77°F (15 to 25°C),
humidity: 40 to 60%).
ODo not fold the paper or scratch the surface of the
paper.
OAvoid touching the printable surface of the paper
with your bare hands. Moisture and oils from your
hands can affect print quality.
OHandle paper by the edges. We recommend
wearing cotton gloves.
OChanges in temperature and humidity may cause
paper to become wavy or curled. Be careful not to
scratch or soil the paper, and flatten it before
loading it in the printer.
ODo not wet the paper.
ODo not throw away the paper packaging as you can
use it for storing the paper.
OAvoid locations that are subject to direct sunlight,
excessive heat, or humidity.
OKeep cut sheets in their original package after
opening, and keep them in a flat place.
ORemove roll paper that is not in use from the
printer. Rewind it correctly and then store it in the
original packaging that came with the roll paper. If
you leave the roll paper in the printer for a long
time, its quality may decline.
Notes on handling printed paper
To maintain long lasting, high quality print results,
note the following points.
ODo not rub or scratch the printed surface. If they
are rubbed or scratched, the ink may peel off.
ODo not touch the printed surface; failure to observe
this precaution may cause ink to rub off.
OMake sure the print outs are completely dry before
folding or stacking; otherwise, the color may
change where they touch (leaving a mark). These
marks will disappear if they are separated
immediately and dried; however, they will remain
if not separated.
OIf you put the print outs in an album before they
are completely dry, they may be blurred.
ODo not use a dryer to dry the print outs.
OAvoid direct sunlight.
OPrevent color distortion while displaying or
storing the print outs by following the instructions
in the paper's documentation.
Epson SureColor T-Series User Guide
Introduction
23
Note:
Typically, print outs and photos fade over time (color
distortion) due to the effects of light and various
constituents in the air. This also applies to Epson special
media. However, with the correct storage method, the
degree of color distortion can be minimized.
OSee the documentation supplied with Epson special
media for detailed information on handling the
paper after printing.
OThe colors of photos, posters, and other printed
materials appear different under different lighting
conditions (light sources*). The colors of print outs
from this printer may also appear different under
different light sources.
* Light sources include sunlight, fluorescent light,
incandescent light, and other types.
Epson SureColor T-Series User Guide
Introduction
24
Provided Software
Contents of the Software Disk
The provided Software Disk contains the following software. Install as required.
More information can be found in the Network Guide (pdf) or via online help for the application in question.
For Windows
For Mac OS X
Software Name Summary
Epson Driver and Utilities The following software is installed.
Printer Driver
The printer driver is required when using the printer.
It can be installed by selecting Install during setup.
U“Summary of the Printer Driver” on page 26
EPSON LFP Remote Panel 2
This software is used for custom paper settings and other configurations.
Epson Network Utilities Select this option during installation if the printer and computer are connected via a
network. Installing this utility allows a wizard to be used to simplify the process of setting
the addresses needed for network connections.
EpsonNet Print is also installed. With this software, you can perform direct TCP/IP
printing when the computer and the printer are connected via a network.
EpsonNet Config With this software, you can configure various network settings for the printer from your
computer. This is useful as it allows you to enter addresses and names using the
keyboard.
The manual is also installed along with the software.
LFP Print Plug-In for Office This is a plug-in for Microsoft Office applications (Word, Excel, and PowerPoint).
Installing this plug-in displays a ribbon in Office applications that gives quick access to
horizontal and vertical banner printing and enlarged printing.
Before installing the plug-in, check the following.
OOffice 2003, Office 2007, Office 2010 or Office 2013 is installed.
ONone of these applications (Office 2003, Office 2007, Office 2010 or Office 2013) is
running.
This plug-in is not included in some regions.
Software Name Summary
Epson Driver and Utilities The following software is installed.
Printer Driver
The printer driver is required when using the printer.
It can be installed by selecting Install during setup.
U“Summary of the Printer Driver” on page 26
EPSON LFP Remote Panel 2
This software is used for custom paper settings and other configurations.
Epson SureColor T-Series User Guide
Introduction
25
Epson Network Utilities Select this option during installation if the printer and computer are connected via a
network. Installing this utility allows a wizard to be used to simplify the process of setting
the addresses needed for network connections.
EpsonNet Config With this software, you can configure various network settings for the printer from your
computer. This is useful as it allows you to enter addresses and names using the
keyboard.
The manual is also installed along with the software.
Software Name Summary
Epson SureColor T-Series User Guide
Introduction
26
Summary of the Printer Driver
The main functions of the printer driver are described
below.
OConverts print data received from applications
into printable data and sends it to the printer.
OSettings such as document size and print quality
can be adjusted from the settings dialogs.
Windows
You can save these settings and easily import or
export these saved settings.
U“Customizing the Printer Driver” on page 117
Mac OS X
OAllows you to execute printer maintenance
functions to maintain print quality, check the
printer's status, and so on.
Windows
You can easily import or export printer driver
settings.
U“Overview of the Utility Tab” on page 119
Mac OS X
Epson SureColor T-Series User’s Guide
Basic Operations
27
Basic Operations
Loading and Removing
the Roll Paper
Load roll paper after attaching the supplied roll paper
adapters.
On the T7270D/T5270D, the methods for loading roll
paper on Roll 1 and Roll 2 are different. After attaching
the roll paper adapter, see the following sections.
Loading on Roll 1U“Loading Roll Paper on Roll 1”
on page 28
Loading on Roll 2U“Loading Roll 2
(T7270D/T5270D only)” on page 31
Attaching the Roll Paper
Adapter
1Turn on the printer by pressing the P button.
2Place roll paper on the roll rest on top of the
printer.
cImportant:
Insert the paper just before printing. The roller
may leave an impression on paper that is left in
the printer.
Note:
OThe paper that can be used in the printer is detailed
in the following section.
U“Supported Media” on page 187
OWhen the optional Multifunction Scanner has been
attached to the printer using the dedicated stand,
raise the scanner until you hear a click.
Note:
OClosing the paper basket makes the work
easier.
T7270/T5270/T3270 U“Storing and
Opening” on page 46
T7270D/T5270D U“Storing” on page 49
OLeaving the poster board supports raised can
cause jams; lower all the supports before
proceeding. To lower the supports, grasp
them, pull them diagonally downward, and
then release.
Epson SureColor T-Series User’s Guide
Basic Operations
28
3Move the size switch levers of the two supplied
roll paper adapters in accordance with the
roll-core size of the roll paper to be loaded.
4Raise the adapter lock lever to release the lock
on each of the two roll paper adapters.
5Attach an adapter to each end of the roll.
Press the adapters in until they are fully inserted
in the roll, with no gaps.
6Lower the lock levers to lock the adapters in
place.
Loading Roll Paper on Roll 1
Buttons that are used in the following settings
Epson SureColor T-Series User’s Guide
Basic Operations
29
1Open the roll paper cover.
2Confirm that the adapter holder lock lever is
raised.
3Slide the roll paper right until it contacts the
adapter guide. Next, following the adapter
guide, slide the roll slowly inside.
4Press the ( button on the control panel.
Confirm that Roll Paper or Roll 1 is highlighted
in the display and press the Z button.
5Make sure that the roll paper is free of slack and
the end is not folded, and then insert it into the
paper slot.
When the Auto Loading is set to On on the
T7270D/T5270D
When roll paper is being inserted, a beep tone
sounds. If you hear the sound, proceed to Step 6.
T7270/T5270/T3270
When the Auto Loading is set to Off on the
T7270D/T5270D.
Pull the edge of the paper straight outside the
printer as shown.
If the edge of the paper is not horizontal or not
cut cleanly, you can use the built-in cutter to
make a cut in Step 6.
Note:
Do not touch the paper where it will be printed.
After loading the roll paper, rotate the roll paper
adapters as shown to feed the paper through.
Epson SureColor T-Series User’s Guide
Basic Operations
30
6Lower the roll paper lock lever, and then press
the Z button.
When the Auto Loading setting is set to Off on
the T7270/T5270/T3270 or T7270D/T5270D,
you can cut the edge of the roll paper with the
built-in cutter by pressing the Z button, and
then pressing the ) button within 5 seconds.
7Close the roll paper cover.
8Check the media type.
If an identification barcode is printed on the
roll
When the paper is loaded, the barcode is read
automatically, and the Media Type and Roll
Paper Remaining settings are configured
automatically.
After Ready is displayed, you can print.
If an identification barcode is not printed on
the roll
The display shows the Media Type currently
selected with the printer.
To print with the displayed settings, use the d/u
buttons to select Keep Settings Above, and
press the Z button.
To change the settings, select Change Settings,
and press the Z button.
U“Viewing and Changing Media Settings” on
page 43
Note:
When the optional Multifunction Scanner has
been raised upon loading roll paper, make sure to
return the scanner back in place for use.
Epson SureColor T-Series User’s Guide
Basic Operations
31
Loading Roll 2
(T7270D/T5270D only)
Buttons that are used in the following settings
1Lower the paper basket to the horizontal
position.
U“Adjusting the Position” on page 50
2Press the ( button on the control panel.
Use the d/u buttons to select Roll 2 and press
the Z button.
3Hold the drawer handles of Roll 2 unit, and then
pull the unit out.
4Confirm that the roll paper lock lever is raised.
5Place the roll paper adapters on the adapter
guides so the flat surfaces of the adapters is
facing down. Next, following the adapter guides,
slide the roll slowly inside.
6Make sure that the roll paper is free of slack and
the end is not folded, and then insert it into the
paper slot.
cImportant:
Do not pull out the Roll 2 unit unless you
are instructed to do so by the control panel
screen. If the unit is carelessly pulled out
while paper is loaded, paper jams or paper
damage may occur.
Epson SureColor T-Series User’s Guide
Basic Operations
32
If roll paper is being inserted, paper is loaded
automatically, and a beep tone sounds.
7Lower the roll lock lever.
8Set the Roll 2 unit, and then press Z button.
9Check the media type.
If a barcode giving information on the paper is
printed on the roll
When the paper is loaded, the barcode is read
automatically, and the Media Type and Roll
Paper Remaining settings are configured
automatically.
After Ready is displayed, you can print.
If a barcode giving information on the paper is
not printed on the roll
The display shows the Media Type currently
selected with the printer.
To print with the displayed settings, use the d/u
buttons to select Keep Settings Above, and
press the Z button.
To change the settings, select Change Settings,
and press the Z button. U“Viewing and
Changing Media Settings” on page 43
Cutting the roll paper
The printer is equipped with a built-in cutter. You can
cut roll paper after printing by using one of the
following methods.
OAuto Cut:
The cutter cuts automatically at a determined
position each time a page is printed in accordance
with the setting of the printer driver or control
panel menu.
OManual cut:
The cutting position is specified on the control
panel, and then the roll paper is cut. A cutline is
printed for manual cutting and can be used as a
guide when cutting paper using the built-in cutter.
Epson SureColor T-Series User’s Guide
Basic Operations
33
Setting Auto Cut
You can specify the method either on the control panel
or the printer driver. Note, however, that the setting
selected with the printer driver takes priority when the
printer driver is used.
Setting on the computer
Set Auto Cut from the Advanced tab - Roll Paper
Option in the printer driver’s Properties (or Printing
preferences) screen.
Setting from the printer
Use the l/r buttons of the control panel to select the
/ tab and press the Z button or Menu button. In the
displayed Setup menu, select Printer Setup > Roll
Paper Setup > Auto Cut > On. For manual cutting,
select Off. The default setting is On.
U“Setup menu” on page 139
Manual cut method
When Off is selected in the printer driver or Off is
selected for Auto Cut in the control panel, the paper
can be cut in any location after printing as described
below.
Buttons that are used in the following settings
cImportant:
The commercially available media types, such as
those shown below, may not be cut cleanly by the
built-in cutter. Furthermore, cutting the following
media types may damage or reduce the lifetime of
the built-in cutter.
OFine art paper
OCanvas
OVinyl
OMatte poster board
OAdhesive paper
OBanner media
Cut these media types with commercially
available scissors or a cutter in the following
manner:
Press the ) button. Keep the d button pressed
to feed the paper so that the cut location is below
the paper eject guide. Cut the paper using scissors
or a third-party cutter.
When you are using the T7270D/T5270D, we
recommend loading these paper types in Roll 1.
Note:
ODisable printer driver Auto Cut and printer Auto
Cut options when using the optional auto take-up
reel unit.
OIt may take a while to cut the roll paper.
OIf the cutting noise is bothersome, set Cutting Mode
to Silent.
U“Setup menu” on page 139
Epson SureColor T-Series User’s Guide
Basic Operations
34
1Press the)button. Viewing the interior of the
printer without opening the printer cover, press
the d button to align the cut location with the
mark on the right side of the printer's
interior.
2Press the Z button.
The paper is cut by the built-in cutter.
Removing Roll paper or Roll 1
This section describes how to remove and store roll
paper after printing. The pressure rollers may leave
impressions on paper that is left in the printer.
Buttons that are used in the following settings
1Confirm that the printer is ready and press the
( button.
The Load/Remove Paper menu will be
displayed.
2Press the d/u buttons to highlight Remove
Paper and press the Z button.
If you are using the T7270D/T5270D and roll
paper is also loaded on Roll 2, select Roll 1, and
then press the Z button.
If On is selected for Roll Paper Remaining, the
printer will automatically print a barcode.
3The paper will automatically be rewound.
T7270/T5270/T3270
Once the paper is rewound, the printer will
display Press and load paper.
T7270D/T5270D
After the paper is rewound, a beep tone sounds.
Note:
The minimum length of paper that can be cut
with the built-in cutter is fixed at 2.4 to 5.0
inches (60 to 127 mm) and cannot be changed. If
the cutting position is shorter than the shortest
length above, the paper has to be automatically
fed to that length, and thus extra paper will be
included. Cut off the extra paper with a cutter
sold at a store.
Note:
When the display shows Turn roll paper adapter
to wind up roll paper, open the roll paper cover
and rewind the paper by hand.
Epson SureColor T-Series User’s Guide
Basic Operations
35
4Open the roll paper cover.
5Raise the roll lock lever.
6Holding the paper by the roll adapters, move the
roll to the roll rest.
7Lift the adapter lock levers to release the roll
paper adapters.
8Remove the roll paper adapters.
After rewinding the roll paper carefully, store it
in the original package.
Close the roll paper cover.
Removing Roll 2
(T7270D/T5270D only)
This section describes how to remove and store roll
paper of Roll 2 after printing. The pressure rollers may
leave impressions on paper that is left in the printer.
Note:
When removing the roll paper, you can use the
optional roll paper belt to prevent the roll paper
from unwinding.
Epson SureColor T-Series User’s Guide
Basic Operations
36
Buttons that are used in the following settings
1Confirm that the printer is ready and press the
( button.
The Load/Remove Paper menu will be
displayed.
2Press the d/u buttons to highlight Remove
Paper and press the Z button.
If roll paper is also loaded on Roll 1, select Roll
2, and then press the Z button.
If On is selected for Roll Paper Remaining, the
printer will automatically print a barcode.
3The paper will automatically be rewound.
After the paper is rewound, a beep tone sounds.
4Lower the paper basket to the horizontal
position.
U“Adjusting the Position” on page 50
5Hold the drawer handles of Roll 2 unit, and then
pull the unit out.
6Raise the roll lock lever.
7Move the roll paper to the roll rest on top of the
printer.
Note:
When removing the roll paper, you can use the
optional roll paper belt to prevent the roll paper
from unwinding.
Epson SureColor T-Series User’s Guide
Basic Operations
37
8Slide the Roll 2 unit back into the printer.
9Lift the adapter lock levers to release the roll
paper adapters.
10 Remove the roll paper adapters.
After rewinding the roll paper carefully, store it
in the original package.
Loading and Removing
Cut Sheets
The procedure for loading and positioning cut sheets
varies with the thickness of the paper.
.003 to .03 inches (0.08 to 0.8 mm) U“Loading Cut
Sheets” on page 37
.03 to .06 inches (0.8 to 1.5 mm) U“Loading Poster
Board” on page 39
Loading Cut Sheets
cImportant:
If the paper is wavy or curled, flatten the paper
before loading it in the printer, or use new paper.
If wavy or curled paper is loaded, this printer may
not be able to recognize the paper size, feed the
paper, or print correctly.
We recommend that you return the paper to its
original package and store it flat, and take it out
of the package just before you use it.
cImportant:
Insert the paper just before printing. The pressure
rollers may leave impressions on paper that is left
in the printer.
Note:
The paper that can be used in the printer is detailed in
the following section.
U“Supported Media” on page 187
Epson SureColor T-Series User’s Guide
Basic Operations
38
Buttons that are used in the following settings
1Turn on the printer by pressing the P button.
2Press the ( button on the control panel. Press
the d/u button to highlight Cut Sheet and press
the Z button.
3Feed the paper into the paper slot with the
printable surface toward you.
Insert the paper into the paper slot, keeping its
right edge aligned with the loading mark on the
roll paper cover. Slide the paper in until it stops.
4Confirm that Press Z is displayed and press
the Z button.
The paper will be fed into the printer.
5Check the media type.
The display shows the type of paper currently
selected with the printer. To print with the
displayed settings, use the d/u buttons to select
Keep Settings Above, and press the Z button.
To change the settings, select Change Settings,
and press the Z button.
U“Viewing and Changing Media Settings” on
page 43
Note:
OClosing the paper basket makes the work
easier.
T7270/T5270/T3270 U“Storing and
Opening” on page 46
T7270D/T5270D U“Storing” on page 49
OLeaving the poster board supports raised can
cause jams; lower all the supports before
proceeding. To lower the supports, grasp
them, pull them diagonally downward, and
then release.
cImportant:
Insert all paper in portrait orientation.
Inserting paper in landscape orientation
may cause a decline in print quality.
Epson SureColor T-Series User’s Guide
Basic Operations
39
Removing Cut Sheets
This section describes how to remove cut sheets when
printing is complete.
Buttons that are used in the following settings
1Confirm that Paper Eject is displayed in the
control panel.
Keeping a hand on the cut sheets to prevent
them falling from the printer, press the Z
button.
2The paper will be fully ejected from the printer
and can then be removed by hand.
Loading and Removing
Poster Board
This section describes how to load and remove poster
board from 0.8 to 1.5mm thick.
The printer can be used with board of the following
sizes.
A2/A1/B2/B1*/B1 landscape*/24 × 30 inch/30 × 40
inch*
* Not supported by the T3270.
Loading Poster Board
Poster board requires space both behind and in front of
the printer. The approximate amount of space required
is shown below. If the printer is set up near a wall, make
sure there is enough space at the rear.
Note:
To remove paper that was loaded but not used, press the
( button and select Remove Paper.
Paper Size Front (a) Back (b)
A2 17.4 inches
(444 mm)
5.3 inches
(135 mm)
A1 27.2 inches
(691 mm)
15.0 inches
(382 mm)
24 × 30 inch 24.1 inches
(612 mm)
11.9 inches
(303 mm)
30 × 40 inch 34.1 inches
(866 mm)
21.9 inches
(557 mm)
cImportant:
Insert the paper just before printing. The roller
may leave an impression on paper that is left in
the printer.
Epson SureColor T-Series User’s Guide
Basic Operations
40
Buttons that are used in the following settings
1Turn on the printer by pressing the P button.
2Press the ( button on the control panel. Press
the d/u button to highlight Poster Board and
press the Z button.
3Raise all the poster board supports.
Press the supports diagonally downwards and
then lift them straight up.
4Place the side to printable face up with its edge
in front of the projecting supports as shown.
Note:
The paper that can be used in the printer is detailed in
the following section.
U“Supported Media” on page 187
Note:
Closing the paper basket makes the work easier.
T7270/T5270/T3270 U“Storing and Opening”
on page 46
T7270D/T5270D U“Storing” on page 49
Epson SureColor T-Series User’s Guide
Basic Operations
41
5Insert the board, using the edge to keep the
supports pressed down.
6Open the printer cover.
7Insert the board, checking to be sure that it
passes under the rollers.
8Close the printer cover.
9Position the trailing and right edges of the board
as shown by the loading indicators.
Center the right edge over the groove to the
right of the paper eject guide and align the
trailing edge with the ends of poster board
supports, as shown.
Epson SureColor T-Series User’s Guide
Basic Operations
42
10 After positioning the media, press the Z
button.
The paper will be fed into the printer.
11 Check the media type.
The display shows the type of paper currently
selected with the printer. To print with the
displayed settings, use the d/u buttons to select
Keep Settings Above, and press the Z button.
To change the settings, select Change Settings,
and press the Z button. U“Viewing and
Changing Media Settings” on page 43
Removing Poster Board
This section describes how to remove poster board
when printing is complete.
Buttons that are used in the following settings
1Confirm that Paper Eject is displayed in the
control panel.
Keeping a hand on the poster board to prevent it
falling from the printer, press the Z button.
2Pull the poster board forward as shown in the
on-screen instructions.
After removing the poster board, press the Z
button.
Note:
To remove paper that was loaded but not used, press the
( button and select Remove Paper.
cImportant:
If poster board will not be used in the next
print job, lower all the poster board
supports. Leaving the supports raised may
cause paper to jam.
To lower the supports, grasp them as shown,
pull them diagonally downward, and then
release.
Epson SureColor T-Series User’s Guide
Basic Operations
43
Viewing and Changing
Media Settings
After the paper is loaded, the control panel screen
shows the media type currently selected with the
printer.
Follow the steps below to change the settings displayed.
If you are using the T7270D/T5270D, settings are
retained for each loaded roll paper (Roll 1/Roll 2).
Buttons that are used in the following settings
1Use the d/u buttons to select Change Settings
and press the Z button.
If you will print with the displayed media type,
select Keep Settings Above, and press the Z
button. Next, proceed to Step 5.
2Select the media type, and then press the Z
button.
3Select the media name, and then press the Z
button.
4If On is selected for Roll Paper Remaining, you
will be prompted to enter the length of the roll.
Press the d/u buttons to choose a value
between 5.0 and 150 m and press the Z button.
You can set in 0.5 m increments.
If you press the r button, you can change Roll
Paper Remaining to Off.
To change the setting back to On, use Roll
Paper Remaining in the Paper menu.
U“Paper menu” on page 134
The printer will display Ready after a brief pause,
showing that it is ready to print. Send the data to be
printed from the computer.
Roll Paper Remaining
When On is selected for Roll Paper Remaining, the
printer tracks the following roll paper data.
OTime until replacement
The following settings are recorded in a barcode
printed on the roll.
The amount of paper remaining, the value selected
for remaining alert, and the paper type.
The barcode is automatically printed at the end of
the roll when the roll is rewound. The barcode is
automatically read and settings adjusted the next
time the paper is used, improving efficiency when
multiple rolls of paper are used.
OTracking the amount of paper remaining in the .
tab info display area
The info display area shows the amount of paper
remaining in the current roll. Once the amount of
paper remaining falls below the limit, the amount
is replaced by a warning indicator showing that
paper is running low.
U“Screen View” on page 15
OPrinting Availability
The printer predicts whether the current job can be
printed on the amount of paper remaining and
Note:
If On is selected for Roll Paper Remaining and roll
paper with a barcode for roll data is loaded, the printer
will read the barcode and adjust settings automatically.
Imformation
Selected Paper Type :
Plain Paper
Keep Settings Above
Change Settings
Proceed
Epson SureColor T-Series User’s Guide
Basic Operations
44
displays the results, preventing waste caused the
paper running out part way through a print job.
This allows you to choose whether to print on the
existing roll or replace the paper, preventing waste.
The T7270/T5270/T3270 can predict availability
only when the optional hard disk unit or Adobe
PostScript 3 Expansion Unit has been installed.
U“Saving to and Reprinting on the Optional
Hard Disk Unit” on page 67
If paper has run out, the T7270D/T5270D can
switch to Roll 1 or Roll 2 automatically based on
predicted availability and continue printing.
U“Switching to Roll 1/Roll 2 by Roll Length” on
page 90
Replacing Paper
This section describes how to replace paper. The
process for removing the current paper differs with the
type of paper loaded; follow the instructions displayed
in the control panel.
Buttons that are used in the following settings
1Confirm that the printer is ready and press the
( button.
The Load/Remove Paper menu will be
displayed.
2Press the d/u buttons to select the type of paper
used to replace the current paper, and then press
the Z button.
3The printer will eject the current paper.
The process for ejecting the paper varies with
the type of paper loaded, as described below.
If On is selected for Roll Paper Remaining
Barcode printing will begin; when printing is
complete, the roll will rewind automatically.
If Off is selected for Roll Paper Remaining
The roll rewinds automatically.
Note:
When the display shows Turn roll paper adapter
to wind up roll paper, open the roll paper cover
and rewind the paper by hand.
Epson SureColor T-Series User’s Guide
Basic Operations
45
Cut Sheets
Cut sheets are automatically ejected to the rear,
where they can be removed by hand.
Poster Board
Poster board is partially ejected to the front.
Supporting the board with one hand to prevent
it falling, press the Z button and pull out the
board.
If the next job will not use poster board, lower all
the poster board supports. Leaving the supports
raised may cause paper to jam.
To lower the supports, grasp them as shown,
pull them diagonally downward, and then
release.
4Follow the on-screen instructions to load the
paper for the next job.
Using the Paper Basket
(T7270/T5270/T3270)
The paper basket collects paper from the printer,
preventing it falling to the floor and becoming creased
or dirty.
If one sheet is to be collected, paper up to the following
sizes can be collected regardless of the paper type.
Maximum size when one sheet is collected
When collecting one sheet, use the paper basket in the
standard position.
Adjusting the PositionU“Adjusting the Position” on
page 47
The basket can hold up to 20 sheets of the same size
when you print in line drawing mode to plain paper
rolls of the following sizes.
When the paper basket will collect paper continually,
change the position of the paper basket in accordance
with the paper size to be stored.
Adjusting the PositionU“Adjusting the Position” on
page 47
Paper Width Paper Length
T7270 About 44 inches (1118 mm) Approx.
46.8 inches
(1189 mm)
T5270 About 36 inches (914 mm)
T3270 About 24 inches (610 mm)
Note:
Close the paper basket before printing banners or other
documents that exceed the maximum length. Before the
paper ejected from the printer touches the floor, we
suggest that you take it in both hands close to the paper
eject guides and continue to lightly support it until
printing is complete.
Epson SureColor T-Series User’s Guide
Basic Operations
46
Paper size and position during continual collection
* Not supported by the T3270.
Storing and Opening
Storing
Close the paper basket before loading paper or moving
the printer.
Press the paper basket to the opposite side.
A paper basket in the horizontal position cannot be
stored. Set the basket to the standard position before
storing it.
U“Adjusting the Position” on page 47
Opening
If the paper basket is closed, it can be opened for use as
described below.
Lightly pull the paper basket down.
Paper Size Position
A1 Portrait 23.4 × 33.1 in.
(594 × 841 mm) Standard position (lower
stack guide)
US D Portrait 22 × 34 in.
(558.8 × 863.6 mm)
A0 Portrait 33.1 × 46.8 in.
(841 × 1189 mm)*Standard position (raise
stack guide)
US E Portrait 34 × 44 in.
(863.6 × 1117.6 mm)*
A2 Portrait 16.5 × 23.4 in.
(420 × 594 mm)
Horizontal position
ARCH C Portrait 18 × 24 in.
(457.2 × 609.6 mm)
A1 Landscape 33.1 × 23.4 in.
(841 × 594 mm)*
ARCH D Portrait 36 × 24 in.
(914.4 × 609.6 mm)*
US D Portrait (34 × 34 in)(34
× 22 in)*
cImportant:
If you print to plain paper sizes other than the
sizes above, collecting consecutive sheets in the
paper basket may result in stains, folds, or other
damage to the printed sheets. When you print
continuously, remove the sheet in the printer
before the next sheet is collected.
Epson SureColor T-Series User’s Guide
Basic Operations
47
Adjusting the Position
Adjust the position to match the size of the paper to be
collected.
Standard position
1Pull the basket toward you slightly, and lower it.
2Use the top stack guide switching lever to lower
the top stack guide.
As shown in the following illustrations, adjust the
lower stack guide to match the size of the paper to be
collected.
Guide positioned for continual collection of A1
Portrait/US D Portrait (22 × 34 in) size paper
cImportant:
The paper basket will not function correctly when
opened to the position shown below at right.
Stop when the paper basket is in the position
shown below at left.
Note:
The paper basket may with some documents or in some
environments fail to hold the paper correctly, resulting
in the paper wrinkling or folding.
Epson SureColor T-Series User’s Guide
Basic Operations
48
Guide positioned for other sizes of paper
Horizontal position
1Use the top stack guide switch lever to raise the
top stack guide.
2Lift the guide up, and then lower it lightly.
Note:
If the standard position is erroneously set instead
of the horizontal position, lift the guide up, and
then lower it while pushing lightly.
Epson SureColor T-Series User’s Guide
Basic Operations
49
Using the Large-Capacity
Paper Basket
(T7270D/T5270D)
The large-capacity paper basket collects paper from the
printer, preventing it falling to the floor and becoming
creased or dirty.
If a single sheet is to be collected, any size or type of
paper can be collected after printing.
The following chart shows the maximum paper lengths
that can be collected.
Maximum paper length when a single sheet is
collected
When you print in line drawing mode on a plain paper
roll, this basket can collect various sizes of sheets up to
A1 Landscape.
When collecting multiple sheets, use the paper basket
in the large-capacity position.
U“Adjusting the Position” on page 50
Storing and Adjusting the
Position
Storing
Close the large-capacity paper basket before loading
paper or moving the printer.
Large-capacity position Approx. 62.2 inches
(1580 mm)
Compact position Approx. 46.8 inches
(1,189 mm)
Note:
Close the paper basket before printing banners or other
documents that exceed the maximum length. Before the
paper ejected from the printer touches the floor, we
suggest that you take it in both hands close to the paper
eject guides and continue to lightly support it until
printing is complete.
* Up to 20 sheets under normal temperatures. Note that
the number of sheets that can be collected is reduced
by work environment, images to be printed, and other
factors. If too many sheets are collected, a paper jam
may occur.
cImportant:
If you collect consecutive sheets of A1 Portrait
plain paper or larger, stains, folds, or other
damage to the printed sheets may occur.
Epson SureColor T-Series User’s Guide
Basic Operations
50
Adjusting the Position
Compact position
Drop down the basket to the position in which it is
fixed by the lower protrusions of the left and right
frames.
Large-capacity position
Pull the basket toward you slightly, and then lower it.
Lower the basket to the position in which it is fixed by
the upper protrusions of the left and right frames.
Epson SureColor T-Series User’s Guide
Basic Operations
51
Horizontal position
Pull the basket toward you slightly, and then lower it.
Next, push it in straight.
To change the basket from the horizontal position to
another position, reverse the procedure above.
Using the Auto Take-up
Reel Unit (T7270 Only)
The optional auto take-up reel unit automatically takes
up paper as it is printed. It improves efficiency for
banners or large jobs involving continuous printing on
roll paper.
The auto take-up reel unit for this printer can take up
paper in either of the directions shown below. Some
types of paper may not support one or the other of
these directions or may place restrictions on the
take-up direction.
See the following section for information on take-up
support and take-up direction.
U“Epson Special Media Table” on page 187
Taking-up with printed side out places the printed
surface on the outside of the roll.
Taking-up with printed side in places the printed
surface on the inside of the roll.
Printed side out Printed side in
!Caution:
OFix the roll core for the auto take-up reel unit
in place as described in the documentation.
Dropping the roll core could cause injury.
OBe careful that your hands, hair, or other
objects do not get caught in the moving parts
of the auto take-up reel unit.
Failure to observe this precaution could
result in injury.
Epson SureColor T-Series User’s Guide
Basic Operations
52
Using the Control Panel
This section describes how to use the control panel for
the auto take-up reel unit.
Attaching the Paper
This section describes how to attach roll paper to the
auto take-up reel unit roll core.
The procedure varies with the take-up direction.
Taking Up the Paper Printable Side
Out
For information on installing the roll core, see the
Setup Guide for the optional auto take-up reel unit.
cImportant:
Confirm that the end of the roll is cut straight
across. The unit will not function as expected if
the end of the roll is wavy or curved.
U“Manual cut method” on page 33
Note:
For information on installing the auto take-up reel unit,
see the documentation supplied with the auto take-up
reel unit attachment.
APower lamp
Displays the status of the auto take-up reel unit.
On : The auto take-up reel unit is
ready for use.
Flickering : The auto take-up reel unit is in
use.
Blinking : The auto take-up reel unit is in
power-saving mode.
Intermittent
blinking
: An error has occurred.
Off : The power is off.
BAuto switch
Selects the auto take-up direction.
Backwar
d
: The roll is taken up with the printable
side in.
Forward : The roll is taken up with the printable
side out.
Off : The auto take-up reel unit does not take
up paper.
CManual switch
Selects the manual take-up direction.
The setting selected with the Manual switch takes
effect when the Auto switch is in the Off position.
Backwar
d
: The roll is taken up with the printable
side in.
The speed will increase after the button
is pressed for more than three seconds.
Forward : The roll is taken up with the printable
side out.
The speed will increase after the button
is pressed for more than three seconds.
cImportant:
Before proceeding, select Off for Auto Cut. Using
the auto take-up reel unit when On is selected will
cause errors.
U“Cutting the roll paper” on page 32
BAuto switch
Epson SureColor T-Series User’s Guide
Basic Operations
53
Buttons that are used in the following settings
1Set the auto take-up reel unit Auto switch to Off.
Plug the power cord into an outlet and confirm
that the power lamp lights.
2Turn on the printer by pressing the P button.
3Check that the roll paper is correctly loaded in
the printer.
4Press the ) button on the control panel.
Keep the d button pressed until the end of the
roll reaches the roll core.
5Tape the end to the roll core.
Place tape (available from third-party suppliers)
at the center and then at the left and right ends.
6Keep the d button in the control panel pressed
until you have fed enough paper for about three
wraps around the roll core.
7Keep the Manual switch pressed to Forward to
wrap the paper three times around the core.
Epson SureColor T-Series User’s Guide
Basic Operations
54
After wrapping the paper around the core,
ensure that paper around the core is sufficiently
loose.
8Set the Auto switch to Forward.
Taking Up the Paper Printable Side In
For information on installing the roll core, see the
Setup Guide for the optional auto take-up reel unit.
Buttons that are used in the following settings
1Set the auto take-up reel unit Auto switch to Off.
Plug the power cord into an outlet and confirm
that the power lamp lights.
2Turn on the printer by pressing the P button.
3Check that the roll paper is correctly loaded in
the printer.
4Press the ) button on the control panel.
Keep the d button pressed until the end of the
roll reaches the roll core.
5Tape the end to the roll core.
Note:
The tensioner supplied with the auto take-up reel
unit is used with some types of paper. Slacken the
paper and insert the tensioner near the center of
the paper as shown. See the following section for
information on paper that requires the tensioner.
U“Epson Special Media Table” on page 187
Epson SureColor T-Series User’s Guide
Basic Operations
55
Place tape (available from third-party suppliers)
at the center and then at the left and right ends.
6Keep the d button in the control panel pressed
until you have fed enough paper for about three
wraps around the roll core.
7Keep the Manual switch pressed to Backward to
wrap the paper three times around the core.
After wrapping the paper around the core,
ensure that paper around the core is sufficiently
loose.
8Set the Auto switch to Backward.
Removing Paper from the Auto
Take-up Reel Unit
This section describes how to remove paper from the
auto take-up reel unit.
!Caution:
Removing paper from the auto take-up reel unit
requires two workers, one on each end of the roll.
A single worker working alone could drop the roll,
resulting in injury.
Epson SureColor T-Series User’s Guide
Basic Operations
56
Buttons that are used in the following settings
1Set the Auto switch to Off.
2Cut the paper and take it up until it is all on the
auto take-up reel unit roll core.
U“Manual cut method” on page 33
After cutting the paper, support the end to
prevent the printed surface touching the floor;
continue to support the paper until it is all taken
up. Keep the Manual switch pressed in the
take-up direction (either Forward or Backward).
3Unlock the movable unit and remove it from the
roll core.
When removing the movable unit, support the
roll core with one hand to prevent it falling to
the floor.
4Remove the roll core from the auto take-up reel
unit.
Epson SureColor T-Series User’s Guide
Basic Operations
57
Basic Printing Methods
(Windows)
Printing is performed from the application used to
create the document you wish to print. The basic
procedure is described below.
1 Turn on the printer, and load the paper.
U“Attaching the Roll Paper Adapter” on page
27
U“Loading Cut Sheets” on page 37
U“Loading Poster Board” on page 39
2When you have created the data, click Print in
the File menu.
3After confirming that the printer is selected,
click Printer properties or Properties to
display the Printer Settings tab.
4Check the options selected for Media Settings.
When using T7270/T5270/T3270
On startup, the printer driver automatically
downloads information on the media in the
printer and displays it in the Media Settings
area.
To print at current settings, proceed to the next
step.
When using T7270D/T5270D
If Roll Auto - **mm has been selected when the
printer driver starts, the printer applies the
media type and width of the roll paper currently
in use on the printer. When the printer starts
printing, it switches to the roll paper to be
printed in accordance with the Roll Switch
Condition setting in the Setup menu of the
printer.
Epson SureColor T-Series User’s Guide
Basic Operations
58
U“Switching Roll Paper Automatically before
Printing (T7270D/T5270D Only)” on page 87
If the desired settings are not displayed, replace
the media in the printer with the desired paper
type and click the Acquire Info button. The
driver will reacquire data from the printer and
update the information displayed in the Media
Settings area.
5In the Size Settings area, choose the desired
Paper Size.
Choose the Paper Size selected when the
document was created in the application.
If the desired size is not available in the menu,
click Custom Paper Size to add a custom paper
size. U“Printing at Non-Standard Sizes” on
page 84
6Select "fit to" and borderless printing options.
To resize the document to fit it to the width of
the roll when using roll paper, simply select Fit
to Roll Paper Width.
To print without borders (margins), select
Borderless.
For borderless printing on paper larger than the
original document size, select both the "fit to"
and borderless options.
Advanced fit and borderless settings are
available in the Layout tab.
U“Enlargements and Horizontal and Vertical
Banners” on page 80
U“Borderless Printing” on page 92
7In the Print Quality area, choose an option for
Select Target.
Note:
If the Acquire Info button is clicked, information
about the paper loaded on the printer is displayed.
Epson SureColor T-Series User’s Guide
Basic Operations
59
Choose an option according to the type of
document and how it will be used.
To choose a color correction method or adjust
colors, select Advanced Settings.
U“Correct color and print” on page 97
8Check settings.
The selected settings are reflected in the area on
the right; check that settings are correct.
9Click the OK button.
10 When settings are complete, click Print.
The progress bar is displayed, and printing
starts.
Screen while printing
The following screen is displayed when you start
printing, and the progress bar (the computer's
processing status) is displayed. On this screen you can
check the remaining ink level, product numbers for the
ink cartridges, and so on.
Epson SureColor T-Series User’s Guide
Basic Operations
60
An error message is displayed if an error occurs or an
ink cartridge needs replacing while printing. Basic Printing Methods
(Mac OS X)
1Turn on the printer, and load the paper.
U“Attaching the Roll Paper Adapter” on page
27
U“Loading Cut Sheets” on page 37
U“Loading Poster Board” on page 39
2When you have created the data, from the File
menu of the application, click Print and so on.
3The print screen is displayed.
Mac OS X Lion or later
Click Show Details at the bottom of the dialog
box.
Epson SureColor T-Series User’s Guide
Basic Operations
61
For Mac OS X 10.6 and 10.5, click the arrow
( ) to make settings on the Page Setup screen.
4Check that this printer is selected, and then set
the paper size.
Select one of the following options for Paper
Size. XXXX is the actual paper size, such as A4.
XXXX: Print with margins on roll paper. Print
using the Roll Paper Margin> selected on the
printer.
U“Print Queues menu” on page 132
XXXX (cut sheet): Print with margins on cut
sheets. Print with top, right, and left margins of
3 mm and a bottom margin of 14 mm.
When performing borderless or banner
printing; see U“Borderless Printing” on page
92, U“Enlargements and Horizontal and
Vertical Banners” on page 80
5To view basic print settings, select Printer
Settings from the list.
Mac OS X 10.6 or later (when using
T7270/T5270/T3270)
On startup, the printer driver automatically
downloads information on the media in the
printer and displays it in the Page Setup and
Media Type areas. To print at current settings,
proceed to the next step.
Mac OS X 10.6 or later (when using
T7270D/T5270D)
If Auto has been selected for Roll Switch when
the printer driver starts, the printer applies the
media type and width of the roll paper currently
in use on the printer. When the printer starts
printing, it switches to the roll paper to be
printed in accordance with the Roll Switch
Condition setting in the Setup menu of the
printer.
U“Switching Roll Paper Automatically before
Printing (T7270D/T5270D Only)” on page 87
Note:
If page settings are not displayed in the print
dialog, click the "page settings" option (e.g., Page
Setup) in the File menu.
Epson SureColor T-Series User’s Guide
Basic Operations
62
Mac OS X 10.5
Choose Page Setup and Media Type according
to the type of paper loaded in the printer.
If the desired settings are not displayed, replace
the media in the printer with the desired paper
type and click the Acquire Info button. The
driver will reacquire data from the printer and
update the information displayed.
6Choose how the printed document will be used.
Choose an option according to the type of
document and how it will be used.
To choose a color correction method or adjust
colors, select Advanced Settings for Mode.
U“Correct color and print” on page 97
7Check settings.
The selected settings are reflected in the area on
the right; check that settings are correct.
8When settings are complete, click Print.
The printer icon is displayed in the Dock while
printing. Click the printer icon to display the status.
You can check the progress of the current print job and
the printer status information. You can also cancel a
print job.
Also, if an error occurs while printing, a notification
message is displayed.
Epson SureColor T-Series User’s Guide
Basic Operations
63
Printable area
This section describes the printable areas for the
printer.
If the margin set in an application is larger than the
following setting values, sections beyond the specified
margins are not printed. For example, if 15 mm is
selected for the left and right margins in the printer
menus and the document fills the page, the 15 mm at
the left and right sides of the page will not be printed.
Roll Paper Printable Area
The gray area in the illustration below shows the
printable area.
When printing borderless on the left and right, the left
and right margins are 0 mm. When printing borderless
on all edges, all margins are 0 mm.
The arrow in the illustration indicates the direction of
the ejected paper.
*1 T7270/T7270D
*2 T5270/T5270D
*3 T3270
*4 If Banner is selected for Roll Paper Option in the
printer driver Advanced tab, the top and bottom
margins are 0 mm.
Margins for roll paper depend on the option selected
for Roll Paper Margin in the menus, as shown in the
table below.
Roll Paper Margin SettingsU“Setup menu” on page
139
indicates factory default settings.
Cut Sheets Printable Area
When printing borderless on the left and right, the left
and right margins are 0 mm. (Borderless printing is not
available with poster board.)
3~45mm
3mm/15m
m
254mm~1118mm
254mm~914mm
254mm~620mm
1
27mm
~
15m
3mm/15mm 3mm/15mm
4
4
1
2
3
A
C
D
B
Roll Paper Margin
Parameter
Margin Values
Normal A,C=15 mm*
B,D=3 mm
Top15mm/Bottom15mm A,C=15 mm
B,D=3 mm
Top35mm/Bottom15mm A=35 mm
C=15 mm
B,D=3 mm
Top45mm/Bottom15mm A=45 mm
C=15 mm
B,D=3 mm
3 mm A,B,C,D=3 mm
15 mm A,B,C,D=15 mm
* When Normal is selected, the value for A is 20 mm for
the following paper.
Premium Photo Paper Glossy (250)/Premium Photo
Paper Semigloss (250)/Ultra Premium Photo Paper
Luster (260)/Premium Semimatte Photo Paper (260)
When the following media are used in CAD / Line
Drawing mode, the value for AC is 3 mm.
Singleweight Matte Paper
cImportant:
OPrinting is distorted when the trailing edge of
the roll paper comes off the core. Make sure
the trailing edge does not come inside the
printing area.
OThe print size does not change even when the
margins are changed.
Epson SureColor T-Series User’s Guide
Basic Operations
64
The arrow in the illustration indicates the direction of
the ejected paper.
*1 T7270/T7270D
*2 T5270/T5270D
*3 T3270
Using the Power Off
Timer
The printer offers the following two power
management options.
OSleep mode
The printer enters sleep mode when there are no
errors, no print jobs being received, and no control
panel or other operations performed. When the
printer enters sleep mode, the control panel's
screen turns off and the internal motors and other
parts switch off to consume less power.
Sleep mode is cleared if a print job is received or a
button on the control panel is pressed.
The delay before the printer enters sleep mode can
be selected from values between 5 and 210
minutes. At default settings, the printer enters
sleep mode if no operations are performed for 15
minutes. The delay can be changed from the Setup
menu. U“Setup menu” on page 139
OPower Off Timer
The printer is equipped with a Power Off Timer
option that automatically turns the printer off if no
errors occur, no print jobs are received, and no
control panel or other operations are performed
for a set period of time. The delay before the
printer turns off automatically can be selected
from values between 1 and 24 hours in increments
of 1 hour.
This section shows the default settings.
OT7270/T5270/T3270
The printer turns off automatically if no
errors occur, no print jobs are received, and
no operations on the panel or other
operations are performed for eight hours or
longer.
OT7270D/T5270D
Note:
When the printer enters sleep mode, the control
panel's screen goes blank as if the power has been
turned off, but the P light remains lit.
Epson SureColor T-Series User’s Guide
Basic Operations
65
The setting is Off.
Power Off Timer settings can be adjusted in the
Setup menu. U“Setup menu” on page 139
About Power Management
You can adjust the time before Power Management is
applied. Any increase will affect the printer’s energy
efficiency. Please consider the environment before
making any change.
Canceling Printing
There are a few ways to stop printing operations
depending on the situation.
When the computer has finished sending data to the
printer, you cannot cancel the print job from the
computer. Cancel on the printer.
Canceling from the computer (Windows)
When the Progress Bar is displayed
Click Cancel.
When the Progress Bar is not displayed
1Click the printer icon in the task bar while
printing is in progress.
Whether or not an icon is displayed depends on
the settings selected for Windows.
2Right click the name of the job you want to
cancel and select Cancel from the document
menu.
To cancel all jobs, click Cancel All Documents
in the Printer menu.
If the job has been sent to the printer, print data
is not displayed on the above screen.
Epson SureColor T-Series User’s Guide
Basic Operations
66
Canceling from the computer (Mac OS X)
1Click the printer icon in the Dock.
2Select the job you want to cancel, and then click
Delete.
If the job has been sent to the printer, print data
is not displayed on the above screen.
Canceling on the printer
Press the W button, select Job Cancel on the screen,
and then press the Z button.
The print job is canceled even in the middle of printing.
It may take a while before the printer returns to ready
status after canceling a job.
Note:
You cannot delete print jobs which are in the print
queue on the computer using the above operation. See
"Canceling from the computer" to delete print jobs in the
print queue.
Epson SureColor T-Series User’s Guide
Saving to and Reprinting on the Optional Hard Disk Unit
67
Saving to and
Reprinting on the
Optional Hard Disk
Unit
Function Summary
When an optional hard disk unit or Adobe PostScript 3
Expansion Unit (hereinafter referred to as the hard
disk) is installed, print jobs can be viewed and managed
as described below.
Extended functions
Print jobs can be viewed and managed as described
below.
cImportant:
The optional hard disk unit for the
T3000/T5000/T7000 cannot be installed to this
printer. Always use a hard disk unit intended for
this printer.
U“Options and Consumable Products” on page
185
• Viewing Print Jobs
When there are multiple print jobs with some in the
queue, the following information can be displayed.
OEstimated print start time
OEstimated print time
OOther information, including whether the job can
be printed without replacing consumables
• Viewing and Resuming Held Print Jobs
(T7270/T5270/T3270 only)
If the source or other settings selected with the printer
differ from the settings specified in the print job, an
error will occur and printing will be suspended.
When an error occurs, printing cannot be restarted
until the printer has been readied by, for example,
replacing the paper.
However, the following types of print job can be held
temporarily on the hard disk.
Therefore, after printing all the jobs that can be printed
with the current paper, you can replace the paper with
the media specified in the held print jobs and resume
printing, making your work more efficient.
OPrint jobs that specify sources that differ from that
selected with the printer
OPrint jobs that specify paper types that differ from
that selected with the printer
OPrint jobs that specify output paper sizes (widths)
that are larger than that selected with the printer
Note:
Held print jobs can be saved if On is selected for
Store Held Job in the control panel Setup menu.
The factory default setting is Off.
U“Setup menu” on page 139
• Viewing and Printing Stored Jobs
Print jobs can be stored on the hard disk and printed at
a later date.
Print jobs selected for printing at a later date can be
printed directly on the hard disk without increasing the
load on your computer.
Print jobs are saved using the printer driver.
U“Saving Print Jobs” on page 68
Note:
OLarge copy and enlarged copy print jobs
created with an optional Multifunction
Scanner or a commercially available scanner
connected to the printer cannot be saved to
the hard disk.
OJobs printed with the following applications
are always saved to the hard disk.
For information on other applications, see the
software documentation or online help.
OLFP Print Plug-In for Office
OEPSON CopyFactory5
Epson SureColor T-Series User’s Guide
Saving to and Reprinting on the Optional Hard Disk Unit
68
Print Job Management
Data on a Hard Disk
Data on a hard disk cannot be copied to a computer or
other device. Even when print jobs have been stored on
the hard disk, save the original data on a computer.
Data on a hard disk may be lost or corrupted in the
following situations.
OWhen the disk is affected by static electricity or
electrical noise
OWhen the disk has been used incorrectly
OAfter a malfunction or repair
OWhen the disk was damaged by a natural disaster
We take no responsibility for any data loss, data
corruption, or other problems due to any cause, even
including those listed above and within the warranty
period. Be aware that we are also not responsible for
the recovery of lost or corrupted data.
Saving Print Jobs
This section describes the print driver settings used to
save print jobs.
• From the Print Job menu of the Control Panel
Detailed procedureU“Viewing and Printing Saved
Print Jobs” on page 69
• From Remote Manager
The Remote Manager utility is included in the standard
install of the printer network interface and, in addition
to managing the print jobs stored on the hard disk, can
be used for viewing printer status and adjusting
network settings. It is launched by entering the
printer's IP address in a computer web browser.
When managing in the Remote Manager, you can
cancel jobs waiting to be printed individually and
cancel and resume held jobs individually.
Note:
If the printer’s IP address is entered in a web
browser when the optional Multifunction Scanner
has been connected, the following screen appears.
To start the Remote Manager, click Remote
Manager.
For more information, see the online help for Remote
Manager.
For information on launching Remote Manager, see
U the Network Guide (pdf)
• From LFP HDD Utility (Windows only)
The LFP HDD Utility can be used to manage print jobs
stored on a hard disk. It is used when the printer is
connected to the computer via USB.
It can be downloaded from the Epson website.
http://www.epson.com
Epson SureColor T-Series User’s Guide
Saving to and Reprinting on the Optional Hard Disk Unit
69
1When you have created the data, click Print in
the File menu.
2After confirming that the printer is selected,
click Printer properties or Properties to
display printer settings.
3In the Advanced tab, click the Settings button in
the Hard Disk Unit area and select Print and
Save or Save only.
4Next, print the document normally.
If Save only is selected, the print job will be
saved to the optional hard disk unit but not
printed.
Viewing and Printing
Saved Print Jobs
This section describes how to view and print saved jobs
from the control panel.
Buttons that are used in the following settings
1Confirm that the printer is ready to print. Press
the l/r buttons to highlight , and press the Z
button.
The Print Queues menu will be displayed.
2Press the d/u buttons to highlight Stored Job
and press the Z button.
Epson SureColor T-Series User’s Guide
Saving to and Reprinting on the Optional Hard Disk Unit
70
The print job tab info display area shows the
names of stored print jobs.
3Press the d/u buttons to highlight the desired
job and press the Z button.
Information on the selected job will be
displayed.
To exit without printing the job, press the W
button after viewing job data.
To print the job, proceed to Step 4.
4Press the Z button.
You will be prompted to enter the number of
copies.
5Press the d/u buttons to choose the number of
copies and press the Z button.
Epson SureColor T-Series User’s Guide
Copying and Scanning
71
Copying and
Scanning
Large Copying and Large
Scanning using the
Multifunction Scanner
(Option)
Function Summary
Main Functions
If you connect the optional Multifunction Scanner, you
can use the following functions.
Large Copy
If you connect the optional Multifunction Scanner to
the T7270/T5270/T7270D/T5270D, you can load
documents up to 36 inches and make large copies.
Large Scan
To perform a large scan, in addition to connecting the
Multifunction Scanner, you need the optional hard
disk unit or Adobe PostScript 3 Expansion Unit
(hereinafter referred to generally as the hard disk).
Scanned images are saved as JPEG files or PDF files and
can be sent and saved as shown below.
OAttached to e-mails, and then sent to another
printer.* (Scan To e-mail)
OSaved to a shared folder on the network. (Scan To
Shared Folder)
OSaved to a hard disk installed to a printer
connected to the Multifunction Scanner that
performed the scan. (Scan To HDD)
Operation
You can perform large copy/scan operations or
manage scanned image files in the following locations.
OOn the Large Copy/Large Scan screen of the
control panel
See the following procedure for detailed
instructions.
OFrom Copy Center
You can use the Copy Center software to copy and
scan on a tablet terminal or computer connected to
the printer via the network.
Starting Copy CenterU“Starting Copy Center”
on page 72
Function compatibility chart
The following chart shows available functions by tool.
* The destination printer must have a Multifunction
Scanner and a hard disk installed. To confirm whether
this function is supported, see the manual included
with the printer.
Control
panel
Copy
Center
Large Copy ✓✓
Large Scan*1 ✓✓
Scan To e-mail ✓✓
Receive e-mail ✓✓
Scan To Shared Folder ✓✓
Scan To HDD ✓✓
Operations for image
files that were scanned
or received by e-mail*2
Print*3 ✓✓
Send as an e-mail
attachment ✓✓
Send to a folder ✓✓
Download file - ✓
Delete ✓✓
Add or edit e-mail
destination addresses -✓
Add or edit shared folder
addresses -✓
Check file operation
history -✓
Scanner maintenance
Epson SureColor T-Series User’s Guide
Copying and Scanning
72
Starting Copy Center
Copy Center is included on the network interface of
the printer, and it functions when the Multifunction
Scanner is connected to the printer.
The following procedure describes how to start Copy
Center.
1Start a web browser on a tablet terminal or
computer connected to the printer via the
network.
2Enter the IP address specified on the printer in
the address bar, and then press the Enter key or
the return key.
3In the displayed screen, click Copy Center.
The printer does not have a wireless LAN function. To
connect the printer and a tablet terminal over the
network, you need a wireless LAN router or wireless
LAN access point.
Example
For supported operating systems and browsers, see the
following section.
U“System Requirements” on page 200
Address Settings
To scan to e-mail or scan to a shared folder, you must
configure the mail server and register the e-mail
destination address and shared folder address in
advance.
Mail Server Settings
Use Remote Manager to configure the mail server
settings (SMTP/POP3). As with Copy Center, Remote
Manager is included in the network interface of this
printer.
Calibration ✓-
Feed Adjust ✓-
*1 Available only when the optional hard disk unit or
Adobe PostScript 3 Expansion Unit has been
installed.
*2 In the case of Scan To e-mail and Scan To Shared
Folder as well, all scanned image files are saved to
the hard disk of the printer.
*3 Printing is limited to JPEG files saved at a directly
printable resolution.
Control
panel
Copy
Center
cImportant:
If you use the Scan to e-mail or Scan to Shared
folder functions or manage in CopyCenter
without configuring the security settings,
problems may occur, including the interception or
falsification of information.
We recommend that before you use the product,
you sufficiently understand the problems that can
occur during operation without configuring
security settings, and then configure the security
settings at your own discretion and responsibility.
LAN
Epson SureColor T-Series User’s Guide
Copying and Scanning
73
The following procedure describes how to start Copy
Center.
1Start a web browser on a tablet terminal or
computer connected to the printer via the
network.
2Enter the IP address specified on the printer in
the address bar, and then press the Enter key or
the return key.
3In the displayed screen, click Remote Manager.
4Select the Step tab screen, and then click Mail in
the menu on the left of the screen.
See the help for more details on Remote Manager.
Creating and Editing the Address
Book
Use Copy Center to create and edit the address book.
1Start Copy Center.
2In the upper part of the screen, click the Settings
icon.
See the help for more details on Copy Center.
Loading Documents
Notes on Loading Documents in the
Scanner
This section describes the document widths and paper
types that can be loaded and documents that cannot be
loaded.
Width of documents that can be loaded
152 to 914 mm (6 to 36 inches)
Document paper types that can be loaded
OPlain Paper
ORecycled paper
OTracing paper
OMatte film
OBlueprint copy
OMatte paper for ink jet printers
OSynthetic paper
ONewspaper
OAdvertisement paper
OPhotopaper
Documents that cannot be loaded
Do not load the following documents. Failure to
observe this precaution could cause paper jams or
damage the scanner.
ODocuments with creases or wrinkles
ODocuments with bindings
ODocuments with curls
ODocuments with carbon backing
ODocuments with staples, paper clips, or glue
attached
ODocuments with many holes, such as loose leaf
paper
ODocuments with irregular shapes or not cut at
right angles
ODocuments with photos, stickers, or labels
attached
OTransparent documents
OGlossy documents
ODeteriorated documents
cImportant:
If a document covered in dust is loaded, the dust
may adhere inside the Multifunction Scanner and
decline the quality of copied or scanned images.
Before loading a document in the scanner, remove
any dust from the document.
* When loading a thin document, we recommend
placing it between clear holders or other similar
objects.
Epson SureColor T-Series User’s Guide
Copying and Scanning
74
ODocuments with rips
How to Load Documents
Before you load a document with the thickness of 0.25
mm or larger, carry out the following three actions.
Remove the paper eject guides (when document
thickness is 0.25 mm or more)
Remove all paper eject guides of the scanner.
If the paper eject guides are left attached, the document
will strike them and not be ejected.
Set the document eject direction to forward (when
document thickness is 0.25 mm or more)
Make sure the document eject direction is forward.
If the document is ejected backward with the paper
eject guides removed, the document will fall to the rear
side and be damaged by folding or dirt.
U“Changing the document eject direction” on page
77
Ensure forward and backward space (when
document thickness is 0.25 mm or more)
When the document is read, it is pushed out forward
and backward. The approximate amount of space
required is shown below. If the printer is set up near a
wall, make sure there is enough space at the rear.
Loading documents
1Align the loading guide with the document
loading position.
To ensure that the document is not fed on an
angle, we recommend inserting the long side of
the document.
Paper Size Forward (a) Backward (b)
A2 185mm 220mm
A1 432mm 467mm
24 × 30 inch 353mm 388mm
30 × 40 inch 607mm 642mm
Epson SureColor T-Series User’s Guide
Copying and Scanning
75
2With the side of the document to be read facing
up, align the right edge of the document with the
loading guide.
3Insert the document horizontally so that the
entire edge touches all inner rollers.
If the edge touches the roller, the document is
fed to the read start position automatically.
After automatic loading starts, release your
hand and do not obstruct the loading of the
document.
4After the document has been loaded, remove the
loading guide, and then make sure the left edge
of the document and the guide line are aligned.
If the document is copied or scanned with the
loading guide still attached, the edge of the
document may be damaged.
Large Copying
This section describes the procedure to copy on the
control panel of the printer.
Copies are printed along the following loading paths
depending on the model you are using.
OT7270/T5270/T3270
Loaded roll paper or cut sheet
cImportant:
If the document slants greatly from the
guide line, the slanted and protruding
section is not copied or scanned. Press the
r button to eject the document, and then
reload the document.
Note:
If the document is 1 m or longer, support it with
your hands so that it does not slant during
reading.
Epson SureColor T-Series User’s Guide
Copying and Scanning
76
OT7270D/T5270D
Select Roll 1/2, and then print
The procedure to select Roll 1/2 is described in
Step 6 below.
Buttons that are used in the following settings
1Turn on the printer by pressing the P button.
When the printer is turned on, the scanner is
also turned on.
2Load paper suitable for large copying on the
printer.
U“Epson Special Media Table” on page 187
3Load document on the scanner.
U“How to Load Documents” on page 74
4Make sure that the Large copy/Large scan screen
appears.
If another screen appears, use the l/r buttons
to select the tab.
5At Large copy/Large scan screen, use the d/u
buttons to select Copy and press the Z button.
The Large copy screen appears.
6On the Large copy screen, you can press the
d/u buttons to select the number of copies.
Press the Z button to start copying.
To change the copy settings or enlargement
ratio, press the Menu button to display the Copy
settings menu. When the Multifunction Scanner
is connected to the T7270D/T5270D, you can
specify whether to print to Roll 1 or Roll 2 in the
Copy settings menu.
Using the Copy Settings menuU“Menu
Operations” on page 125
SettingsU“Large Copy / Large Scan menu” on
page 153
7When copying has finished, the screen returns
to the one in Step 6. Press the r button to eject
the document. When the Z button is pressed
after loading a document, copying can continue.
After copying has finished, always eject the
document. If the next document is loaded with
the previous document still inside, the next
document cannot be fed correctly.
You can change the eject direction of the
document. Changing the eject
directionU“Changing the document eject
direction” on page 77
Epson SureColor T-Series User’s Guide
Copying and Scanning
77
Large Scan
This section describes the procedure to scan on the
control panel of the printer.
Buttons that are used in the following settings
1Turn on the printer by pressing the P button.
If the printer is turned on, the scanner is also
turned on.
2Load paper suitable for the large scan function
of the printer.
U“Epson Special Media Table” on page 187
3Load document on the scanner.
U“How to Load Documents” on page 74
4Make sure that the Large copy/Large scan screen
appears.
If another screen appears, use the l/r buttons
to select the tab.
5At Large copy/Large scan screen, use the d/u
buttons to select Scan and press the Z button.
A screen appears to select the save/send
destination of the scanned file.
6Use the d/u buttons to select save/send
destination and press the Z button.
If the HDD was selected, proceed to Step 8.
If Shared Folder or Send By Mail was selected,
proceed to Step 7.
7Use the d/u buttons to select the save
destination folder or address, and then press the
Z button.
8The details of the main scan settings appear.
When the Z button is pressed, scanning starts.
To change the settings, press the Menu button
to display the Scan Setting menu.
Using the Scan Setting menu
U“Menu Operations” on page 125
Settings
U“Large Copy / Large Scan menu” on page
153
9When scanning has finished, the screen returns
to the one in Step 8. Press the r button to eject
the document. When the Z button is pressed
after loading the document, you can continue
saving or sending scanned files to the same
save/send destination.
After scanning has finished, always eject the
document. If the next document is loaded with
the previous document still inside, the next
document cannot be fed correctly.
You can change the eject direction of the
document.
Changing the eject direction
U“Changing the document eject direction” on
page 77
Changing the document eject
direction
After copying or scanning has finished, you can change
the eject direction when the document eject operation
is performed. The default setting is forward ejection.
Epson SureColor T-Series User’s Guide
Copying and Scanning
78
When the direction has been changed to backward,
attach the paper eject guides before use. If the
document is ejected backward with the paper eject
guides removed, the document will fall to the rear side
and be damaged by folding or dirt.
Buttons that are used in the following settings
1At Large copy/Large scan screen, use the d/u
buttons to select Scanner Maintenance and
press the Z button.
2Use the d/u buttons to select Eject Direction
and press the Z button.
3Use the d/u buttons to select the desired option
and press the Z button.
4Press the W button to exit.
Operations for Image Files that
were Scanned or Received
You can perform the following operations for scanned
files or scanned files that were sent by e-mail from
another printer.
OPrint (JPEG files with a resolution that supports
direct printing only)
Load paper suitable for the large scan function on
the printer.
U“Epson Special Media Table” on page 187
Furthermore, printing is carried out along the
following loading paths depending on the model
you are using.
OT7270/T5270/T3270
Loaded roll paper or cut sheet
OT7270D/T5270D
Roll paper currently in use
You can check whether the roll paper
currently in use in is Roll 1 or Roll 2 by
selecting the . tab.
OSend as an e-mail attachment
OSend to a shared folder on the network
ODelete a file
Buttons that are used in the following settings
1Make sure that the Large copy/Large scan screen
appears.
If a value such as (3) appears up in Received File
Options, the value indicates the number of
unprinted files of the received files that support
direct printing.
2At Large copy/Large scan screen, use the d/u
buttons to select Received File Options or Scan
File Options and press the Z button.
A list of selected files appears. The following
chart shows the meaning of the icons beside the
file names.
Epson SureColor T-Series User’s Guide
Copying and Scanning
79
When Received File Options was selected
When Scan File Options was selected
3Use the d/u buttons to select the file you want
to manage and press the Z button.
When a file with displayed is selected in
Received File Options and you press the Z
button, printing starts.
If another job was selected, proceed to Step 4.
4Use the d/u buttons to select the operation you
want to carry out and press the Z button.
If Print or Delete was selected, check the screen
display and carry out the operation.
When Send To Shared Folder or Send by Mail
has been selected, a screen appears to select the
save destination folder or send destination.
Follow the same operations as when scanning.
5When the operation has been completed, the
screen returns to the file list screen.
Press the y button to exit.
Indicates an unprinted JPEG file that
supports direct printing. If printed even
once, the icon changes to .
Indicates a file that cannot be printed
directly.
Indicates a JPEG file with a resolution
that supports direct printing.
Indicates an image file that was sent to a
shared folder. Indicates a file that cannot
be printed directly.
Indicates an image file that was sent to a
shared folder. Indicates a JPEG file with a
resolution that supports direct printing.
Indicates an image file that was saved to
a hard disk. Indicates a file that cannot
be printed directly.
Indicates an image file that was saved to
a hard disk. Indicates a JPEG file with a
resolution that supports direct printing.
Indicates an image file that was sent by
e-mail. Indicates a file that cannot be
printed directly.
Indicates an image file that was sent by
e-mail. Indicates a JPEG file with a
resolution that supports direct printing.
Note:
When you press the r button, information on the
selected file is displayed.
Epson SureColor T-Series User’s Guide
More Ways to Print
80
More Ways to Print
Enlargements and
Horizontal and Vertical
Banners
The printer driver can enlarge or reduce documents for
different paper sizes. There are three setting methods.
Before printing at non-standard sizes, including
vertical or horizontal banners and documents with
equal sides, enter the desired paper size in the printer
driver.
U“Printing at Non-Standard Sizes” on page 84
OFit to Roll Paper Width
Automatically enlarges or reduces the image size to
fit the roll paper width.
OSpecify Size
You can specify the enlargement or reduction
ratio. Use this method for a non-standard paper
size.
OFit to Output Size
Automatically enlarges or reduces the image size to
fit the paper size.
Fitting Documents to the Width
of the Roll Paper
Making Settings in Windows
1Display the printer driver's Printer Settings tab
and select a Paper Size that matches the
document page size.
A4
1000mm
Note:
OWhen printing from applications designed
expressly for horizontal or vertical banners, adjust
printer driver settings as described in the
application documentation.
OWhen using Windows applications designed for
horizontal or vertical banners, select Banner in the
Advanced tab as required.
Epson SureColor T-Series User’s Guide
More Ways to Print
81
U“Basic Printing Methods (Windows)” on
page 57
2In the Layout tab, select Reduce/Enlarge and
click Fit to Roll Paper Width.
3Choose whether to fit the short or long edge of
the document to the roll paper width.
4Check other settings, and then start printing.
Making Settings for Mac OS X
1Choose Page Layout Settings from the list in
the print dialog and select Reduce/Enlarge.
U“Basic Printing Methods (Mac OS X)” on
page 60
2Select Fit to Roll Paper Width and choose
whether to fit the short or long edge of the
document to the roll paper width.
3Check other settings, and then start printing.
Note:
Output can also be fitted to the roll width by
selecting Fit to Roll Paper Width in the Printer
Settings tab.
Epson SureColor T-Series User’s Guide
More Ways to Print
82
Choosing a Print Size
Making Settings in Windows
1Display the printer driver's Printer Settings tab
and select a Paper Size that matches the
document page size.
U“Basic Printing Methods (Windows)” on
page 57
2In the Layout tab, select Reduce/Enlarge and
click Specify Size.
3Choose an input method and select a size.
Enter a value directly or click the arrows to the
right of the scale box to set the value.
4Check other settings, and then start printing.
Making Settings for Mac OS X
1Choose Page Layout Settings from the list in
the print dialog and select Reduce/Enlarge.
U“Basic Printing Methods (Mac OS X)” on
page 60
2Select Specify Size, choose a method for
specifying the size, and select a size.
Enter a value directly or click the arrows to the
right of the scale box to set the value.
3Check other settings, and then start printing.
Epson SureColor T-Series User’s Guide
More Ways to Print
83
Fitting Documents to the Output
Size
Making Settings in Windows
1Display the printer driver's Printer Settings tab
and select a Paper Size that matches the
document page size.
U“Basic Printing Methods (Windows)” on
page 57
2In the Layout tab, select Reduce/Enlarge and
click Fit to Output Size.
3Select the size of the paper used for printing.
To print the document, margins excluded, at
precisely the selected output size, select
Oversize.
4Check other settings, and then start printing.
Making Settings for Mac OS X
1Choose Page Layout Settings from the list in
the print dialog and select Reduce/Enlarge.
U“Basic Printing Methods (Mac OS X)” on
page 60
2Select Fit to Output Size and choose a paper
size that matches the paper in the printer.
3Check other settings, and then start printing.
Note:
When printing using Oversize, load paper that is
as large as the selected Output Size plus the
margins needed by the printer.
Printer marginsU“Printable area” on page 63
Note:
Output can also be fitted to the paper size by selecting
Scale to fit paper size in the print dialog Paper
Handling pane.
Epson SureColor T-Series User’s Guide
More Ways to Print
84
Printing at Non-Standard
Sizes
Before printing at non-standard sizes, including
vertical or horizontal banners and documents with
equal sides, save the desired paper size in the printer
driver. Once they have been saved in the printer driver,
custom sizes can be selected in the application Page
Setup and other print dialogs.
The following sizes can be used.
*1. The maximum printable width is 610 mm.
*2. The paper length can be longer if using applications that
support banner printing. However, the actual print size
depends on the application, the paper size loaded in the
printer, and the computer environment.
Making Settings in Windows
1Display the printer driver's Printer Settings tab
and click the Custom Paper Size.
U“Basic Printing Methods (Windows)” on
page 57
2Enter the desired size in the User Defined Paper
Size dialog and click Save.
OYou can enter up to 24 single-byte
characters for the Paper Size Name.
OTo view Paper Width and Paper Height
values for a standard size close to the
desired custom size, select the appropriate
option for Base Paper Size.
OIf you specify the desired Fix Aspect Ratio
and select Landscape or Portrait for Base,
you need only enter either the Paper Width
or Paper Height.
Paper
Width
T7270/T7270D 89 to 1,118 mm
T5270/T5270D 89 to 914 mm
T3270 89 to 620 mm*1
Length*2 Windows: 127 to 15,000 mm
Mac OS X: 127 to 15,240 mm
cImportant:
OThe smallest size supported by the printer is
254 mm wide
×
127 mm long. If a smaller size
is entered in the printer driver as a Custom
Paper Size, the document will print with
wider-than-expected margins, which must be
trimmed.
OFor Mac OS X Custom Paper Sizes, although
you can specify a large paper size which
cannot be loaded on this printer, it will not be
printed properly.
OThe available output size is limited
depending on the application.
cImportant:
Custom Paper Size is not available when
Front - Poster Board is selected for Source.
Epson SureColor T-Series User’s Guide
More Ways to Print
85
3Click OK.
The saved sizes are now available in the Paper
Size menu of the Printer Settings tab.
You can now print as normal.
Making Settings for Mac OS X
1When the Print screen is displayed, select
Manage Custom Sizes from the Paper Size list.
U“Basic Printing Methods (Mac OS X)” on
page 60
2Click +, and then enter the paper size name.
3Enter the Width, Height for the Paper Size,
enter the margins, and then click OK.
The range of values available for page sizes and
margins vary with the printer model and the
values selected with the printer.
U“Printable area” on page 63
4Click OK.
You can select the paper size you saved from the
Paper Size pop-up menu.
You can now print as normal.
Note:
OTo change the paper size you saved, select the
paper size name from the list on the left.
OTo delete the user-defined size you saved,
select the paper size name from the list on the
left, and then click Delete.
OYou can save up to 100 paper sizes.
Note:
If page setting options are not available in the
application's print dialog, display the page settings
dialog.
Note:
OTo edit a saved custom size, choose its name
from the list on the left.
OTo copy a saved custom size, select the size in
the list on the left and click Duplicate.
OTo delete a saved custom size, select it in the
list on the left and click -.
OThe custom paper size setting differs
depending on the operating system version.
See your operating system's documentation
for details.
Epson SureColor T-Series User’s Guide
More Ways to Print
86
Printing CAD Drawings
The printer supports the HP-GL/2 driver and HP RTL
(Raster Transfer Language) used in plotters. You can
use one of the following methods to print CAD
drawings with this printer.
OPrint in the CAD / Line Drawing mode of the
included printer driver.
OPrint while emulating HP-GL/2 and HP RTL,
which are used in plotters.
Whether the printer prints normally or prints while
emulating HP-GL/2 and HP RTL is determined and
selected automatically by the print data sent. If
operation mode switching and printing are not
performed correctly, open the Setup menu and set
Printer Mode to HP-GL/2.
Printing in the CAD / Line
Drawing mode of the printer
driver
When you will print a CAD drawing with Windows
applications software, we recommend printing in the
CAD / Line Drawing mode of the printer driver.
Windows
1Open the Printer Settings tab of the printer
driver. Set Print Quality to Select Target, and
then select CAD / Line Drawing (Black), CAD
/ Line Drawing (Color) or CAD / Line
Drawing (Bi-Level).
2Check other settings, and then start printing.
Mac OS X
1Display the print dialog and select Printer
Settings from the list.
U“Basic Printing Methods (Mac OS X)” on
page 60
2Set Mode to Select Target, and then select CAD
/ Line Drawing (Black), CAD / Line Drawing
(Color), or CAD / Line Drawing (Bi-Level).
3Check other settings, and then start printing.
Note:
The CAD / Line Drawing (Black), CAD / Line
Drawing (Color) , and CAD / Line Drawing
(Bi-Level) options are available for Select Target
when a paper type suited to printing CAD
drawings is selected.
Note:
The CAD / Line Drawing (Black) and CAD /
Line Drawing (Color) options are available for
Select Target when a paper type suited to printing
CAD drawings is selected.
Epson SureColor T-Series User’s Guide
More Ways to Print
87
Printing while Emulating
HP-GL/2 and HP RTL
The printer can emulate* HP-GL/2 (compatible with
HP Designjet 750C) and HP RTL.
When you want to print with applications using
HP-GL/2 or HP RTL output, configure the output
equipment as shown below according to your model.
OT7270/T7270D/T5270/T5270D
HP Designjet 750C C3195A
OT3270
HP Designjet 750C C3196A
When you will print while emulating HP-GL/2 and HP
RTL, observe the following points.
OSelect Paper Type setting
Set one of the following options for the Select
Paper Type setting of the printer. If other paper
types are used, print quality may be reduced.
Singleweight Matte/Plain Paper/Tracing
Paper/Tracing Paper <Low Duty>
OHP-GL/2 Settings
When you will print while emulating HP-GL/2 and
HP RTL, set the Print Settings as follows: On the
printer, select Setup menu > Printer Setup >
HP-GL/2 Settings.
U“Setup menu” on page 139
Switching Roll Paper
Automatically before
Printing (T7270D/T5270D
Only)
Explanations in this section use a typical method to
switch automatically to the appropriate roll paper for
the print job.
Switching to Roll 1/Roll 2 by
Paper Type
For example, when you use the following method
often, if you use the settings described below, the
printer can switch between Roll 1 and Roll 2
automatically in accordance with the paper type.
Usage example
You use different types of paper depending on the
purpose of its use. For example you print to plain paper
for drawings for in-house checks and print to color
print paper for presentations and drawings for clients.
In this example, the paper is loaded as follows. All
paper has the same width.
Roll 1: Plain Paper
Roll 2: Singleweight Matte Paper
Settings on Windows
1Using the control panel of the printer, confirm
Type Match is set in Setup menu > Printer
Setup > Roll Paper Setup > Roll Switch
Condition > Paper Type.
The default Paper Type setting is Type Match.
If the setting has not been changed, the setting is
Type Match.
U“Setup menu” on page 139
2Open the Printer Settings tab of the printer
driver and confirm that Source is Roll Auto -
XXXXX.
XXXXX indicates the width of the roll paper
currently in use.
* Not all functions are supported. If you will use an
untested application, test its output in advance.
For a list of applications that have been tested, visit the
Epson website at http://www.epson.com.
cImportant:
The printer may not perform as expected if the
volume of the data to be printed is extremely
large.
Epson SureColor T-Series User’s Guide
More Ways to Print
88
If the setting is not Roll Auto - XXXXX, click it
and select Roll Auto - XXXXX.
3For Media Type, select the paper type you want
to use for printing.
In this example, Plain Paper or Singleweight
Matte Paper is selected depending on the
purpose of its use.
4Set Paper Size, Print Quality, and other
necessary settings, and then print.
If a message The Media Type differs to the
setting on the printer. is appears, click Ignore.
Making Settings for Mac OS X
1Using the control panel of the printer, confirm
Type Match is set in Setup menu > Printer
Setup > Roll Paper Setup > Roll Switch
Condition > Paper Type.
The default Paper Type setting is Type Match.
If the setting has not been changed, the setting is
Type Match.
U“Setup menu” on page 139
2On the computer, open the Print screen,
confirm that Paper Size is Roll Paper, and then
select Printer Settings from the list.
3Check that the Roll Switch is Auto.
If the setting is not Auto, click it and select
Auto.
4For Media Type, select the paper type you want
to use for printing.
Epson SureColor T-Series User’s Guide
More Ways to Print
89
In this example, Plain Paper or Singleweight
Matte Paper is selected depending on the
purpose of its use.
5Set Print Quality and other necessary settings,
and then print.
If a message The Media Type differs to the
setting on the printer. is appears, click Ignore.
Switching to Roll 1/Roll 2 by
Document Size
For example, when you use the following method
often, if you use the settings described below, the
printer can switch between Roll 1 and Roll 2
automatically in accordance with the document size of
the print job.
Usage example
You want to switch automatically to the roll paper with
the smaller margin automatically when printing
drawings of various sizes including A0, A1, A2, and A3.
In this example, the paper is loaded as follows. The
paper type is the same.
Roll 1: A2 width
Roll 2: A0 width
Settings on Windows
1Using the control panel of the printer, confirm
Best Fit is set in Setup menu > Printer Setup >
Roll Paper Setup > Roll Switch Condition >
Paper Width.
The default Paper Width setting is Best Fit. If
the setting has not been changed, the setting is
Best Fit.
U“Setup menu” on page 139
2Open the Printer Settings tab of the printer
driver and confirm that Source is Roll Auto -
XXXXX.
XXXXX indicates the width of the roll paper
currently in use.
If the setting is not Roll Auto - XXXXX, click it
and select Roll Auto - XXXXX.
3For Paper Size, select the Paper Size set in the
application.
In this example, select A1 594 x 841 mm.
Epson SureColor T-Series User’s Guide
More Ways to Print
90
4Set Print Quality and other necessary settings,
and then print.
The printer prints to the roll paper of Roll 2 (A0
Width).
If A3 or A2 is selected in Step 3, the printer
prints to the roll paper of Roll 1 (A2 Width).
Making Settings for Mac OS X
1Using the control panel of the printer, confirm
Best Fit is set in Setup menu > Printer Setup >
Roll Paper Setup > Roll Switch Condition >
Paper Width.
The default Paper Width setting is Best Fit. If
the setting has not been changed, the setting is
Best Fit.
U“Setup menu” on page 139
2On the computer, open the Print screen,
confirm that Paper size is Roll Paper.
In this example, select A1.
3Check that the Roll Switch is Auto.
If the setting is not Auto, click it and select
Auto.
4Set Print Quality and other necessary settings,
and then print.
The printer prints to the roll paper of Roll 2 (A0
Width)
If A3 or A2 is selected in Step 2, the printer
prints to the roll paper of Roll 1 (A2 Width).
Switching to Roll 1/Roll 2 by Roll
Length
If you use the settings described below, the printer
switches between Roll 1 and Roll 2 automatically to
print using the roll with the most paper remaining.
Usage example
You want to predict whether the roll paper remaining
is less than the print job during continuous unattended
operation of a large print job, switch to the other roll
paper automatically, and continue printing without
stopping.
In this example, the paper is loaded as follows.
Roll 1: Plain Paper A1 Width
Roll 2: Plain Paper A1 Width
Settings on Windows
1Use the control panel of the printer to open the
Paper menu and set Roll Paper Remaining to
On, and then set the Roll Paper length loaded
into both Roll 1 and Roll 2.
When you set the roll paper, if roll paper length
has been set or a barcode with roll data is
printed on the current roll, proceed to Step 2.
U“Paper menu” on page 134
2Using the control panel of the printer, confirm
Print Length is set in Setup menu > Printer
Setup > Roll Paper Setup > Roll Switch
Condition > Paper Length.
The default Paper Length setting is Print
Length. If the setting has not been changed, the
setting is Print Length.
U“Setup menu” on page 139
3Open the Printer Settings tab of the printer
driver and confirm that Source is Roll Auto -
XXXXX.
Epson SureColor T-Series User’s Guide
More Ways to Print
91
XXXXX indicates the width of the roll paper
currently in use.
If the setting is not Roll Auto - XXXXX, click it
and select Roll Auto - XXXXX.
4Set Paper Size, Print Quality, and other
necessary settings, and then print.
If the printer predicts that the roll paper
remaining is shorter than the print length
during printing, it switches to the roll paper that
is longer than the print length automatically and
continues printing.
Making Settings for Mac OS X
1Use the control panel of the printer to open the
Paper menu and set Roll Paper Remaining to
On, and then set the Roll Paper length loaded
into both Roll 1 and Roll 2.
When you set the roll paper, if roll paper length
has been set or a barcode with roll data is
printed on the current roll, proceed to Step 2.
U“Paper menu” on page 134
2Using the control panel of the printer, confirm
Print Length is set in Setup menu > Printer
Setup > Roll Paper Setup > Roll Switch
Condition > Paper Length.
The default Paper Length setting is Print
Length. If the setting has not been changed, the
setting is Print Length.
U“Setup menu” on page 139
3On the computer, open the Print screen,
confirm that Paper Size is Roll Paper, and then
select Printer Settings from the list.
4Check that the Roll Switch is Auto.
If the setting is not Auto, click it and select
Auto.
5Set Print Quality and other necessary settings,
and then print.
If the printer predicts that the roll paper
remaining is shorter than the print length
during printing, it switches to the roll paper that
is longer than the print length automatically and
continues printing.
Epson SureColor T-Series User’s Guide
More Ways to Print
92
Borderless Printing
You can print your data without margins on the paper.
The types of borderless printing you can choose vary as
shown below depending on the media type.
Roll Paper: No margins for all edges, no margins for
the left and right
Cut Sheets: No margins for the left and right only
(Borderless printing is not available with poster board.)
When printing borderless for all edges, you can also
configure the cutting operation.
U“About Roll Paper Cutting” on page 94
When performing left and right borderless printing,
margins appear on the top and bottom of the paper.
Top and bottom margin values
U“Printable area” on page 63
Types of Borderless Printing
Methods
You can perform borderless printing using the
following two methods.
OAuto Expand
The printer driver enlarges the print data to a size
slightly larger than the paper size and prints the
enlarged image. The sections which are beyond the
paper edges are not printed; therefore, resulting in
borderless printing.
Use settings such as Page Setup in the applications
to set the size of the image data as follows.
ORetain Size
Create the print data larger than the paper size in
the applications to produce borderless output. The
printer driver does not enlarge the image data. Use
settings such as Page Setup in the applications to
set the size of the image data as follows.
Select this setting if you want to avoid image
enlargement by the printer driver.
Supported Media Sizes for
Borderless Printing
The following media sizes are supported for borderless
printing.
The sizes supported vary with the printer model.
- Match the paper size and page setting for the print
data.
- If the application has margin settings, set the margins
to 0 mm.
- Make the image data as large as the paper size.
- Create print data larger than its actual print size by 3
mm on the left and right (6 mm in total).
- If the application has margin settings, set the margins
to 0 mm.
- Make the image data as large as the paper size.
Epson SureColor T-Series User’s Guide
More Ways to Print
93
Depending on the media type, the print quality may
decline or borderless printing cannot be selected.
U“Epson Special Media Table” on page 187
Supported
paper
widths
SC-T7200
Series/
SC-T7200
D Series
SC-T5200
Series/
SC-T5200
D Series
SC-T3200
Series
10 inch ✓✓✓
30 cm ✓✓✓
Super A3/
329 mm/
13 inch
✓✓✓
16 inch ✓✓✓
US C/17 inch ✓✓✓
B2/515 mm ✓✓✓
A1/594mm ✓✓✓
24 inch ✓✓✓
B1/728 mm ✓✓ -
A0/841 mm ✓✓ -
36 inch ✓✓ -
B0/1030 mm ✓--
44 inch ✓--
Epson SureColor T-Series User’s Guide
More Ways to Print
94
About Roll Paper Cutting
When performing borderless printing on roll paper, you can specify whether it is left and right borderless printing
or all edges borderless printing, and how to cut the paper in the printer driver's Roll Paper Option. The cutting
operation for each value is shown in the following chart.
Printer driver
settings Borderless Single Cut Double Cut
Cutting Operation
Explanation
The default printer driver
setting is Borderless.
OThe top area may become
slightly uneven depending
on the image since the
print operation stops while
cutting the top edge of the
roll paper.
OIf the cut position is
misaligned slightly, small
parts of the image may be
shown on the top or
bottom of the adjacent
pages. If this occurs,
perform Adjust Cut
Position.
U“The Maintenance
Menu” on page 138
OWhen you print one page
only or print one page
multiple times, the
operation is the same as
that for Double Cut. When
continuously printing
multiple sheets, the printer
cuts 1 mm inside on the
top edge of the first page
and the bottom edge of
the subsequent pages to
avoid showing margins.
OThe top area may become
slightly uneven depending
on the image since the
print operation stops while
cutting the top edge of the
roll paper.
OThe printed paper is
approximately 2 mm
shorter than the specified
size since the printer cuts
the paper inside the image
to avoid showing top and
bottom margins.
OAfter cutting the bottom
edge of the previous page,
the printer feeds the paper,
and then cuts the top edge
of the following page.
Although this produces 60
to 127 mm cut-off pieces,
the cut is more accurate.
Epson SureColor T-Series User’s Guide
More Ways to Print
95
Setting Procedures for Printing
Making Settings in Windows
1Display the printer driver's Printer Settings tab
and adjust the following settings.
U“Basic Printing Methods (Windows)” on
page 57
2Select Borderless in the Size Settings area.
To fit output to the roll width, choose Fit to Roll
Paper Width before selecting Borderless.
3In the Layout tab Borderless Enlargement
Setting area, select either Auto Expand or
Retain Size.
If Auto Expand is selected, click Amount of
Enlargement and choose the amount cut off at
the edges.
4When roll paper is used, Auto Cut options are
available in the Advanced tab Roll Paper
Option area.
U“About Roll Paper Cutting” on page 94
Note:
Retain Size is not available when Fit to Roll
Paper Width is selected in the Printer Settings tab
or Reduce/Enlarge is selected in the Layout tab.
Max : 3 mm for left and 5 mm for right
(the image shifts 1 mm to the right)
Standard : 3 mm for left and right
Min : 1.5 mm for left and right
Note:
Moving the slider towards Min decreases the
image enlargement ratio. Therefore, some margins
may appear at the edges of the paper depending on
the paper and printing environment.
Epson SureColor T-Series User’s Guide
More Ways to Print
96
5Check other settings, and then start printing.
Making Settings for Mac OS X
1Open the Print screen and select the paper size
from the Paper Size option, and then select a
borderless printing method.
U“Basic Printing Methods (Mac OS X)” on
page 60
The selections for borderless printing methods
are displayed as shown below.
XXXX (Roll Paper - Borderless (Auto Expand))
XXXX (Roll Paper - Borderless (Retain Size))
XXXX (Sheet - Borderless (Auto Expand))
XXXX (Sheet - Borderless (Retain Size))
Where XXXX is the actual paper size, such as
A4.
2If Auto Expand is selected for paper size, select
Page Layout Settings from the list and click
Expansion.
The following section shows how much the
image will be larger than the paper edges.
3When using roll paper, select Advanced from
the list and choose an Auto Cut option.
U“About Roll Paper Cutting” on page 94
4Check other settings, and then start printing.
Note:
If page setting options are not available in the
application's print dialog, display the page settings
dialog.
Max : 3 mm for left and 5 mm for right
(the image shifts 1 mm to the right)
Standard : 3 mm for left and right
Min : 1.5 mm for left and right
Note:
Moving the slider towards Min decreases the
image enlargement ratio. Therefore, some margins
may appear at the edges of the paper depending on
the paper and printing environment.
Epson SureColor T-Series User’s Guide
More Ways to Print
97
Correct color and print
The printer driver automatically and internally
corrects colors to match the color space. You can select
from the following color correction modes.
OEPSON Standard (sRGB)
Optimizes the sRGB space and corrects the color.
OBusiness Graphics
Performs color correction to sharpen your images
based on the sRGB space.
OLine Drawing
Optimizes color correction for line drawing by
processing the border between lines and the
background as discontinuous.
OICM
Performs color management to match the colors in
the image data to those in the printed output
(Windows only).
U“Color Management Printing” on page 109
OOff (No Color Management)
Color correction is not performed by the printer
driver. Choose if color management is performed
by the application.
U“Color Management Printing” on page 109
If EPSON Standard (sRGB)/Business Graphics/Line
Drawing is selected for Color Mode, a Settings button
will be displayed.
Click the Settings button to adjust Gamma, Brightness,
Contrast, Saturation, and color balance.
Use this option when the application in use does not
have a color correction function.
Making Settings in Windows
1When using applications featuring a color
management function, specify how to adjust
colors from these applications.
When using applications without a color
management function, start from Step 2.
Depending on the type of the application, make
the settings following the table below.
Adobe Photoshop CS3 or later
Adobe Photoshop Elements 6 or later
Adobe Photoshop Lightroom 1 or later
In other applications, set No Color
Management.
Example of Adobe Photoshop CS5
Open the Print screen.
Note:
The color correction options available vary with the
operating system and the type of paper used.
OS Color Management
Settings
Windows 8.1,
Windows 8,
Windows 7,
Windows Vista
Printer Manages Colors
Windows XP
(Service Pack 2 or
later and .NET 3.0
or later)
Windows XP (other
than the above)
No Color Management
Note:
For information on supported platforms, see the
website for the application in question.
Epson SureColor T-Series User’s Guide
More Ways to Print
98
Select Color Management and then Document.
Select Printer Manages Colors as the Color
Handling setting, and then click Print.
2In the printer driver's Printer Settings tab, select
Advanced Settings for Print Quality and
choose a color correction option.
U“Basic Printing Methods (Windows)” on
page 57
Additional adjustments can be made by clicking
Settings.
3Clicking the Settings button allows you to
adjust Gamma, Brightness, Contrast,
Saturation, color balance, and other settings.
See the printer driver help for more details on
each item.
4Check other settings, and then start printing.
Making Settings for Mac OS X
1When using applications featuring a color
management function, specify how to adjust
colors from these applications.
When using applications without a color
management function, start from Step 2.
When using the following applications, select
the Printer Manages Colors color management
option.
Adobe Photoshop CS3 or later
Adobe Photoshop Elements 6 or later
Adobe Photoshop Lightroom 1 or later
In other applications, set No Color
Management.
Example of Adobe Photoshop CS5
Note:
You can adjust the correction value by checking
the sample image on the left side of the screen.
Color balance can also be adjusted by selecting
Color Circle or Slide Bar for Color Adjustment
Method.
Note:
For information on supported platforms, see the
website for the application in question.
Epson SureColor T-Series User’s Guide
More Ways to Print
99
Open the Print screen.
Select Color Management and then Document.
Select Printer Manages Colors as the Color
Handling setting, and then click Print.
2Display the Print screen.
U“Basic Printing Methods (Mac OS X)” on
page 60
3Select Color Matching from the list, and then
click EPSON Color Controls.
4Choose Printer Settings from the list and select
Advanced Settings for Mode.
5Choose a color correction option from the
Color Mode list.
Additional adjustments can be made by clicking
Settings.
6Make the necessary settings.
See the printer driver help for more details on
each item.
7Check other settings, and then start printing.
Note:
EPSON Color Controls will not be available in
the following applications if Step 1 is omitted.
OAdobe Photoshop CS3 or later
OAdobe Photoshop Lightroom 1 or later
OAdobe Photoshop Elements 6 or later
Note:
When using the following applications with Mac
OS X 10.5, clear the Use Generic RGB checkbox.
OAdobe Photoshop CS3 or later
OAdobe Photoshop Lightroom 1 or later
OAdobe Photoshop Elements 6 or later
Select the check box when using a different
application from those listed above.
Epson SureColor T-Series User’s Guide
More Ways to Print
100
Multi-Page/Poster
Printing
You can print multiple pages on a single sheet or a
single page across multiple sheets.
The following three multi-page/poster printing
methods are available.
Folded Double-Side (Windows
only)
1In the printer driver's Layout tab, select Page
Layout. Next, select Folded Double-Side and
click the Settings button.
U“Basic Printing Methods (Windows)” on
page 57
• Folded Double-Side (Windows only)
Two consecutive pages are printed on a single sheet.
The second page is flipped 180° and printed adjacent
to the first page, allowing the paper to be folded to
make a double-sided document.
•N-up
Two or four consecutive pages can be printed on a
single sheet.
•Poster (Windows only)
A single page can be printed across multiple sheets.
The sheets can then be joined together to form large
posters (up to 16 times the original size). If Borderless
Poster Print is selected, the sheets can be joined
without trimming the edges, but because the portions
outside the edges of the paper will be lost, the joins
may be imperfect.
Epson SureColor T-Series User’s Guide
More Ways to Print
101
2In the Folded Double-Side Setting dialog box,
set Binding Edge and Binding Margin.
3Check other settings, and then start printing.
N-up
Making Settings in Windows
1In the printer driver's Layout tab, select Page
Layout. Next, select N-up and click the Settings
button.
U“Basic Printing Methods (Windows)” on
page 57
2In the Print Layout dialog box, select the
Number of pages per sheet and Page Order.
If the Print page frames check box is selected,
page frames are printed on each page.
3Check other settings, and then start printing.
Making Settings for Mac OS X
1When the Print screen is displayed, select
Layout from the list, and then specify the
number of pages per sheet and so on.
Note:
OIn Windows, you cannot use the N-up printing
function when performing borderless printing.
OIn Windows, you can use the Reduce/Enlarge
function (Fit to Page) to print the data on different
sizes of paper.
U“Printing at Non-Standard Sizes” on page 84
Epson SureColor T-Series User’s Guide
More Ways to Print
102
U“Basic Printing Methods (Mac OS X)” on
page 60
2Check other settings, and then start printing.
Poster (Windows only)
1In the printer driver's Layout tab, select Page
Layout. Next, select Poster and click the
Settings button.
U“Basic Printing Methods (Windows)” on
page 57
2In the Poster Settings dialog box, select the
Number of panels.
3Enable or disable borderless printing.
When borderless is selected:
Select Borderless Poster Print.
Note:
You can print frames around arranged pages
using the Border function.
Note:
OIf Borderless Poster Print is grayed out, the
selected paper or the size does not support
borderless printing.
U“Supported Media Sizes for Borderless
Printing” on page 92
U“Epson Special Media Table” on page 187
OIf Single Cut or Double Cut is selected for
Auto Cut, the paper will be cut 1 or 2 mm
inside the image, resulting in imperfect joins.
Epson SureColor T-Series User’s Guide
More Ways to Print
103
When with margins is selected:
Clear Borderless Poster Print.
4Check other settings, and then start printing.
Joining Poster Sheets with Printed Borders
If Overlapping Alignment Marks is selected, join
guides (indicated by the lines drawn through and
around the X marks in the illustration below) will be
printed on each sheet.
The following section describes how to join four
printed pages together.
Note:
Regarding the size after joining together:
If Borderless Poster Print is not selected, a Print
Cutting Guides option will be displayed.
The finished size is the same whether or not Trim
Lines is selected. However, if Overlapping
Alignment Marks is selected, the finished size is
smaller with an overlap.
Note:
If the output is in color, the join guides will be in blue
and the cut guides in red; otherwise, all the guides will be
printed in black.
Epson SureColor T-Series User’s Guide
More Ways to Print
104
1Ready the two top sheets and trim the excess
from the left sheet by cutting along the line
joining the two join guides (the centers of the X
marks).
2Lay the upper left sheet on top of upper right
sheet. Lineup the X marks as shown in the
illustration below, and temporarily fasten them
using an adhesive tape on the back.
3With the two sheets overlapping, trim the excess
by cutting along the line joining the two cut
guides (the lines to the left of the X marks).
4Rejoin the two sheets.
Use an adhesive tape to stick the backs of the
sheets together.
5Repeat Steps 1 to 4 for the lower sheets.
Epson SureColor T-Series User’s Guide
More Ways to Print
105
6Trim the bottom from the upper sheets by
cutting along the line joining the two guides (the
lines above the X marks).
7Lay the upper sheet on top of the lower sheet.
Lineup the X marks as shown in the illustration
below, and temporarily fasten them using an
adhesive tape on the back.
8With the two sheets overlapping, trim the excess
by cutting along the line joining the two cut
guides (the lines above the X marks).
9Join the upper and lower sheets together.
Epson SureColor T-Series User’s Guide
More Ways to Print
106
Use an adhesive tape to stick the backs of the
sheets together. 10 After joining all the sheets, trim off the borders
by cutting along the cut guides (outside the X
marks).
Epson SureColor T-Series User’s Guide
More Ways to Print
107
Printing Multiple
Documents (the Layout
Manager)
(Windows Only)
Documents created in different applications can be
printed together in your choice of layout. The Layout
Manager can be used to improve efficiency and
conserve paper.
Sample Multi-Document Layout
Sample Free Vertical/Horizontal Layout
Setting Procedures for Printing
1Open the file you want to print in your
application.
2In the printer driver's Printer Settings tab, select
Layout Manager and in the Size Settings area
select the Paper Size chosen for the document
in the source application.
U“Basic Printing Methods (Windows)” on
page 57
3Click OK. When printing with an application,
the Layout Manager screen opens.
The print data is not printed, but one page is
placed on the paper of the Layout Manager
screen as one object.
4Leaving the Layout Manager screen open, repeat
Steps 1 to 3 until all the documents have been
added to the layout.
The objects are added to the Layout Manager
screen.
5Arrange the objects on the Layout Manager
screen.
Objects can be dragged to new positions and
resized; in addition, they can be rearranged or
rotated using the options in the Object menu.
Note:
The Paper Size is the size of the document in the
Layout Manager. The actual printing paper size is
set in the screen in Step 6.
Epson SureColor T-Series User’s Guide
More Ways to Print
108
The overall size and placement of the objects can
be changed using the Preferences and
Arrangement options in the File menu.
See the Layout Manager screen help for more
details on each function.
6Click Properties in the File menu and adjust
printer settings in the printer driver dialog.
Check the Media Settings and choose a Print
Quality.
7Click the File menu on the Layout Manager
screen, and then click Print.
Printing starts.
Saving and Recalling Settings
You can save the Layout Manager screen arrangement
and setting contents to a file. If you need to close your
application in the middle of a job, you can save it to a
file and then open it later to continue your work.
Saving
1On the Layout Manager screen, click File menu
and then Save As.
2Enter the file name, select the location, and then
click Save.
3Close the Layout Manager screen.
Opening saved files
1Right-click the Utility shortcut icon on the
Windows Taskbar ( ), and then click Layout
Manager on the menu displayed.
The Layout Manager screen is displayed.
If the Utility shortcut icon is not displayed on
the Windows Taskbar
U“Overview of the Utility Tab” on page 119
2On the Layout Manager screen, click File menu
and then Open.
3Select the location and open the required file.
Epson SureColor T-Series User’s Guide
Color Management Printing
109
Color Management
Printing
About Color Management
Even when using the same image data, the original
image and the displayed image may look different, and
the printed results may look different to the image you
see on the display. This occurs due to the difference in
characteristics when input devices such as scanners
and digital cameras capture colors as electronic data,
and when output devices such as display screens and
printers reproduce colors from the color data. The
color management system is a means to adjust
differences in color conversion characteristics among
input and output devices. A color management system
is included with operating systems such as Windows
and Mac OS, in addition to image processing
applications. Windows and Mac OS X include the ICM
and ColorSync color management systems,
respectively.
In a color management system, a color definition file
called a "Profile" is used to perform color matching
between devices. (This file is also called an ICC profile.)
The profile of an input device is called an input profile
(or source profile), and the profile of an output device,
such as a printer, is called a printer profile (or output
profile). A profile is prepared for each media type in
this printer's driver.
The color conversion areas by the input device and the
color reproduction area by the output device differ. As
a result, there are color areas that do not match even
when performing color matching using a profile. In
addition to specifying profiles, the color management
system also specifies conversion conditions for areas
where color matching failed as "intent". The name and
type of intent vary depending on the color
management system you are using.
You cannot match the colors on the printed results and
display by color management between the input device
and the printer. To match both colors, you need to
perform color management between the input device
and the display as well.
Color Management Print
Settings
You can perform color management printing using
this printer's printer driver in the following two ways.
Choose the best method according to the application
you are using, the operating system environment, the
aim of the print out, and so on.
Setting color management with the applications
This method is for printing from applications that
support color management. All color management
processes are carried out by the application's color
management system. This method is useful when you
want to obtain the same color management print
results using a common application among different
operating system environments.
U“Setting color management with the applications”
on page 110
Setting color management with the printer driver
The printer driver uses the operating system's color
management system and carries out all color
management processes. You can make color
management settings in the printer driver using the
following two methods.
OHost ICM (Windows) / ColorSync (Mac OS X)
Set when printing from applications that support
color management. This is effective in producing
similar print results from different applications
under the same operating systems.
U“Color management printing by Host ICM
(Windows)” on page 111
U“Color management printing by ColorSync
(Mac OS X)” on page 112
ODriver ICM (Windows only)
This allows you to perform color management
printing from applications that do not support
color management.
U“Color management printing by Driver ICM
(Windows Only)” on page 113
Epson SureColor T-Series User’s Guide
Color Management Printing
110
Setting profiles
Settings for the input profile, printer profile, and intent
(matching method) vary between three types of color
management printing since their color management
engines are used differently. This is because color
management usage differs between the engines. Make
settings in the printer driver or application as described
in the following table.
Printer profiles for each paper type that is needed when
performing color management are installed with the
printer's printer driver. You can select the profile from
the printer driver's settings screen.
See the following for detailed information.
U“Color management printing by Driver ICM
(Windows Only)” on page 113
U“Color management printing by Host ICM
(Windows)” on page 111
U“Color management printing by ColorSync (Mac
OS X)” on page 112
U“Setting color management with the applications”
on page 110
Setting color
management with the
applications
Print using applications with a color management
function. Make the color management settings in the
application and disable the printer driver's color
adjustment function.
1Make color management settings in the
applications.
Example using Adobe Photoshop CS5
Open the Print screen.
Select Color Management and then Document.
Select Photoshop Manages Colors as the Color
Handling setting, select the Printer Profile and
the Rendering Intent, and then click Print.
2Display the printer driver's settings screen
(Windows) or Print screen (Mac OS X).
Make printer driver settings.
For Windows
U“Basic Printing Methods (Windows)” on
page 57
For Mac OS X
U“Basic Printing Methods (Mac OS X)” on
page 60
3Set color management to off.
Input
profile
settings
Printer
profile
settings
Intent
settings
Driver ICM
(Windows)
Printer
Driver
Printer
Driver
Printer
Driver
Host ICM
(Windows)
Application Printer
Driver
Printer
Driver
ColorSync
(Mac OS X)
Application Printer
Driver
Application
Application Application Application Application
Epson SureColor T-Series User’s Guide
Color Management Printing
111
For Windows
In the Printer Settings tab, select Advanced
Settings in the Print Quality area and choose
Off (No Color Management) for Color Mode.
For Mac OS X
Choose Printer Settings from the list and select
Advanced Settings for Mode. Select Off (No
Color Management) for Color Mode.
4Check other settings, and then start printing.
Setting color
management with the
printer driver
Color management printing by
Host ICM (Windows)
Use image data in which an input profile has been
embedded. Also, the application must support ICM.
1Make the settings for color adjustment using the
application.
Depending on the type of the application, make
the settings following the table below.
Adobe Photoshop CS3 or later
Adobe Photoshop Elements 6 or later
Adobe Photoshop Lightroom 1 or later
In other applications, set No Color
Management.
Example using Adobe Photoshop CS5
Open the Print screen.
OS Color Management
Settings
Windows 8.1,
Windows 8,
Windows 7,
Windows Vista
Printer Manages Colors
Windows XP
(Service Pack 2 or
later and .NET 3.0
or later)
Windows XP
(other than the
above)
No Color Management
Note:
For information on supported platforms, see the
website for the application in question.
Epson SureColor T-Series User’s Guide
Color Management Printing
112
Select Color Management and then Document.
Select Printer Manages Colors as the Color
Handling setting, and then click Print.
When using applications without a color
management function, start from Step 2.
2In the printer driver's Printer Settings tab, select
Advanced Settings for Print Quality, then
select ICM for Color Mode and click Settings.
U“Basic Printing Methods (Windows)” on
page 57
3Select Host ICM.
When Epson special media is selected for Media
Type in the Printer Settings tab, the printer
profile corresponding to the media type is
automatically selected and displayed in the
Printer Profile Description box.
To change the profile, select Show all profiles at
the bottom.
4Check other settings, and then start printing.
Color management printing by
ColorSync (Mac OS X)
Use image data in which an input profile has been
embedded. Also, the application must support
ColorSync.
1Disable the color management functions in the
application.
2Display the Print screen.
U“Basic Printing Methods (Mac OS X)” on
page 60
3Select Color Matching from the list, and then
click ColorSync.
Note:
Depending on the application, color management
printing by ColorSync may not be supported.
Epson SureColor T-Series User’s Guide
Color Management Printing
113
4Choose Printer Settings from the list and select
Advanced Settings for Mode. Select Off (No
Color Management) for Color Mode.
5Check other settings, and then start printing.
Color management printing by
Driver ICM
(Windows Only)
The printer driver uses its own printer profiles to
perform color management. You can use the following
two color correction methods.
ODriver ICM (Basic)
Specify one type of profile and intent for
processing the entire image data.
ODriver ICM (Advanced)
The printer driver distinguishes the image data
into the Image, Graphics, and Text areas. Specify
three types of profiles and intents for processing
each area.
When using applications featuring a color
management function
Make the settings for color processing using the
application before making printer driver settings.
Depending on the type of the application, make the
settings following the table below.
Adobe Photoshop CS3 or later
Adobe Photoshop Elements 6 or later
Adobe Photoshop Lightroom 1 or later
In other applications, set No Color Management.
Example using Adobe Photoshop CS5
Open the Print screen.
Select Color Management and then Document. Select
Printer Manages Colors as the Color Handling
setting, and then click Print.
1In the printer driver's Printer Settings tab, select
Advanced Settings for Print Quality, then
select ICM for Color Mode and click Settings.
OS Color Management
Settings
Windows 8.1,
Windows 8,
Windows 7,
Windows Vista
Printer Manages Colors
Windows XP
(Service Pack 2 or later and
.NET 3.0 or later)
Windows XP
(other than the above)
No Color Management
Note:
For information on supported platforms, see the website
for the application in question.
Epson SureColor T-Series User’s Guide
Color Management Printing
114
U“Basic Printing Methods (Windows)” on
page 57
2From ICM Mode in the ICM screen, select
Driver ICM (Basic) or Driver ICM
(Advanced).
If you select Driver ICM (Advanced), you can
specify the profiles and intent for each image
such as photos, graphics, and text data.
3Check other settings, and then start printing.
Intent Explanation
Saturation Keeps the current saturation
unchanged and converts the
data.
Perceptual Converts the data so that a
more visually natural image is
produced. This feature is used
when a wider gamut of color is
used for image data.
Relative
Colorimetric
Converts the data so that a set
of color gamut and white point
(or color temperature)
coordinates in the original data
match their corresponding
print coordinates. This feature
is used for many types of color
matching.
Absolute
Colorimetric
Assigns absolute color gamut
coordinates to the original and
print data and converts the
data. Therefore, color tone
adjustment is not performed
on any white point (or color
temperature) for the original or
print data. This feature is used
for special purposes such as
logo color printing.
Epson SureColor T-Series User’s Guide
Tips for Using the Printer Driver (Windows)
115
Tips for Using the
Printer Driver
(Windows)
Displaying the Settings
Screen
You can access the printer driver in the following ways:
OFrom Windows applications
U“Basic Printing Methods (Windows)” on page
57
OWith the Start button
With the Start button
Follow the steps below when specifying common
settings among applications or performing printer
maintenance, such as Nozzle Check or Head Cleaning.
1Open the Printer or Printers and Faxes folder.
For Windows 7 / Windows 8.1/ Windows 8
Click in the following order: Start (or Settings)
> Control Panel > Hardware and Sound (or
Hardware) > Devices and Printers.
For Windows Vista
Click , Control Panel, Hardware and
Sound, and then Printer.
For Windows XP
Click Start, Control Panel, Printers and Other
Hardware, and then Printers and Faxes.
2Right-click your printer icon, and click Printing
preferences.
The printer driver dialog will be displayed.
Make the necessary settings. These settings become the
default settings of the printer driver.
Note:
If your Windows XP Control Panel is in Classic
View, click Start, Control Panel, and then
Printers and Faxes.
Epson SureColor T-Series User’s Guide
Tips for Using the Printer Driver (Windows)
116
Displaying Help
You can access the printer driver help in the following
ways:
OClick Help
ORight-click on the item you want to check and
display
Click the Help Button to Display
By displaying Help, you can use the contents page or
keyword search to read the help.
Right-click on the item you want
to check and display
Right-click the item, and then click Help.
Note:
In Windows XP, click on the title bar, and then click
the help item you want to view.
Epson SureColor T-Series User’s Guide
Tips for Using the Printer Driver (Windows)
117
Customizing the Printer
Driver
You can save the settings or change the display items as
you prefer.
Saving various settings as your
Select Settings
All printer driver settings can be saved to Select
Setting. In addition, Select Setting contains
pre-defined settings recommended for a variety of
common situations.
Recall Select Setting to increase efficiency if you often
print at the same settings.
1In the Printer Settings, Layout, and Advanced
tabs, select the settings you wish to save to Select
Setting.
2Click Save/Del.
3Enter any name in the Name box, and then click
Save.
You can save up to 100 settings. You can choose a
setting you have registered from the Select Setting list
box.
Adding Media Types
Select Print Quality and Media Settings for the type of
media you wish to add and save it as a custom media
type. The custom media type will be added to the
Media Type menu in the Media Settings area.
1In the Printer Settings tab, select Advanced
Settings and adjust settings as desired.
Note:
You can save the settings as a file by clicking Export.
You can share the settings by clicking Import to import
the saved file on another computer.
Note:
You can not add a custom media type if Select
Target is selected in the Print Quality area.
Epson SureColor T-Series User’s Guide
Tips for Using the Printer Driver (Windows)
118
2Click Advanced Media Control in the
Advanced tab.
3Adjust settings for the new custom media and
click OK.
4Click Custom Settings in the Advanced tab.
5Enter any name in the Name box, and then click
Save.
You can save up to 100 settings. You can choose a
setting you have registered from the Media Type list
box.
Rearranging display items
To display frequently used items right away, you can
arrange Select Setting, Media Type, and Paper Size as
follows.
OHide unnecessary items.
ORearrange in an order of most frequent use.
OArrange in groups (folders).
1Go to the Utility tab and click Menu
Arrangement.
Note:
You can save the settings as a file by clicking Export.
You can share the settings by clicking Import to import
the saved file on another computer.
Epson SureColor T-Series User’s Guide
Tips for Using the Printer Driver (Windows)
119
2Select Edit Item.
3Order or group items in the List box.
OYou can move and order items by dragging
and dropping.
OTo add a new group (folder), click Add
Group.
OTo delete a group (folder), click Delete
Group.
ODrag and drop unnecessary items to Not
Display.
4Click Save.
Overview of the Utility
Tab
The printer driver's Utility tab provides access to the
following.
Nozzle Check
This function prints a nozzle check pattern to check if
the print head nozzles are clogged. If you see banding
or gaps in the print outs, perform head cleaning to clear
any clogged nozzles.
U“Cleaning the print head” on page 157
Head Cleaning
If you see banding or gaps in the print outs, perform
head cleaning. Cleans the surface of the print head to
improve the print quality.
U“Cleaning the print head” on page 157
Print Head Alignment
If the print results appear grainy or out of focus,
perform Print Head Alignment. The Print Head
Alignment function corrects print head gaps.
U“Minimizing Print Misalignments (Head
Alignment)” on page 158
EPSON Status Monitor 3
You can check the printer's status, such as the
remaining ink level and error messages, on the
computer's screen. When roll paper is loaded on Roll 1
or Roll 2 of the T7270D/T5270D, you can also check
which is selected as the active roll.
Note:
When Delete Group is performed, the group
(folder) is deleted, however the items in the deleted
group (folder) remain.
Epson SureColor T-Series User’s Guide
Tips for Using the Printer Driver (Windows)
120
T7270/T5270/T3270 Series
T7270D/T5270D
Monitoring Preferences
You can select the error notifications displayed on the
EPSON Status Monitor 3 screen, or register a shortcut
for the Utility icon to the Taskbar.
Print Queue
You can display the list of all waiting jobs.
On the Print Queue screen, you can view information
on the data waiting to be printed, delete and reprint
these jobs.
Speed and Progress
You can set various functions for printer driver basic
operations.
Menu Arrangement
You can arrange the display items of Select Setting,
Media Type, and Paper Size. For example, you can
reorder them by frequency of access. U“Rearranging
display items” on page 118
Export or Import
You can export or import the printer driver settings.
This function is useful when you want to make the
same printer driver settings on multiple computers.
EPSON LFP Remote Panel 2
You can configure custom paper settings and other
settings. See the EPSON LFP Remote Panel 2 help for
details.
Note:
If you select the Shortcut Icon on the Monitoring
Preferences screen, the Utility shortcut icon is displayed
on the Windows Taskbar.
By right-clicking the icon, you can display the following
menu and perform maintenance functions.
EPSON Status Monitor 3 starts when the printer name
is clicked from the displayed menu.
Note:
If EPSON LFP Remote Panel 2 is grayed out, EPSON
LFP Remote Panel 2 is not installed. Install EPSON LFP
Remote Panel 2 from the Software List in the Software
disc.
Epson SureColor T-Series User’s Guide
Tips for Using the Printer Driver (Windows)
121
Uninstalling the printer
driver
Follow the steps below to remove the printer driver and
EPSON LFP Remote Panel 2.
1Turn off the printer, and unplug the interface
cable.
2Go to the Control Panel and click Uninstall a
program from the Programs category.
3Select the software you want to remove and then
click Uninstall/Change (or
Change/Remove/Add or remove).
You can remove EPSON Status Monitor 3 and
the printer driver by selecting EPSON
SC-XXXXX Printer Uninstall.
Select EPSON LFP Remote Panel 2 to remove
EPSON LFP Remote Panel 2.
4Select the target printer icon, and then click OK.
5Follow the on-screen instructions to continue.
When the delete confirmation message appears,
click Yes.
Restart the computer if you are reinstalling the printer
driver.
cImportant:
OYou must log in with an Administrators
group.
OIn Windows 7/Windows Vista, if an
Administrator password or confirmation is
requested, enter the password and then
continue with the operation.
Epson SureColor T-Series User’s Guide
Tips for Using the Printer Driver (Mac OS X)
122
Tips for Using the
Printer Driver
(Mac OS X)
Displaying the Settings
Screen
The display method of the printer driver setting screen
may differ depending on the application or the OS
version.
U“Basic Printing Methods (Mac OS X)” on page 60
Displaying Help
Click in the printer driver setting screen to display
Help.
Using Epson Printer
Utility 4
You can perform maintenance tasks such as Nozzle
Check or Head Cleaning by using Epson Printer Utility
4. This utility is installed automatically when you
install the printer driver.
Starting Epson Printer Utility 4
Mac OS X 10.6.x or later
1Select System Preferences > Print & Scan (or
Print & Fax) from the Apple menu.
2Select the printer and click Options & Supplies
> Utility > Open Printer Utility.
Mac OS X 10.5.8
1Select System Preferences > Print & Fax from
the Apple menu.
2Select the printer and click Open Print Queue >
Utility.
Epson Printer Utility 4 Functions
You can perform the following maintenance functions
from Epson Printer Utility 4.
Epson SureColor T-Series User’s Guide
Tips for Using the Printer Driver (Mac OS X)
123
EPSON Status Monitor
You can check the printer's status, such as the
remaining ink level and error messages, on the
computer's screen. When roll paper is loaded on Roll 1
or Roll 2 of the T7270D/T5270D, you can also check
which is selected as the active roll.
T7270/T5270/T3270
T7270D/T5270D
Nozzle Check
This function prints a nozzle check pattern to check if
the print head nozzles are clogged. If you see banding
or gaps in the print outs, perform head cleaning to clear
any clogged nozzles.
U“Cleaning the print head” on page 157
Head Cleaning
If you see banding or gaps in the print outs, perform
head cleaning. This function cleans the surface of the
print head to improve the print quality.
U“Cleaning the print head” on page 157
Print Head Alignment
If the print results appear grainy or out of focus,
perform Print Head Alignment. The Print Head
Alignment function corrects print head gaps.
U“Minimizing Print Misalignments (Head
Alignment)” on page 158
EPSON LFP Remote Panel 2
You can configure custom paper settings and other
settings. See the EPSON LFP Remote Panel 2 help for
details.
Epson SureColor T-Series User’s Guide
Tips for Using the Printer Driver (Mac OS X)
124
Uninstalling the printer
driver
Before reinstalling or upgrading the printer driver or
EPSON LFP Remote Panel 2, uninstall the affected
software.
Use the Uninstaller to uninstall the printer driver.
Downloading the Uninstaller
Download the Uninstaller from the Epson website.
http://www.epson.com/
Using the Uninstaller
Follow the instructions on the Epson website.
Removing EPSON LFP Remote
Panel 2
Drag and drop the EPSON Remote Panel 2 folder
from the Applications folder into the Trash.
Epson SureColor T-Series User’s Guide
Using the Control Panel Menu
125
Using the Control Panel Menu
Menu Operations
The steps for displaying the various menus are shown below.
The example below shows the steps for accessing the Paper menu.
*1 Available when the optional hard disk unit or Adobe PostScript 3 Expansion Unit has been connected
*2 Standard menu (when the hard disk unit or Adobe PostScript 3 Expansion Unit has not been connected)
*3 After pressing the Z button to select the highlighted option, press the y button to return to the previous menu. Press the W
button to exit.
When the optional Multifunction Scanner is connected
Start copying
Epson SureColor T-Series User’s Guide
Using the Control Panel Menu
126
Menu List
The items and options available in the menu are described below. See the reference pages for more details on each
item.
*1. T7270D/T5270D only
*2. T7270/T5270/T3270 only
*3. When the optional hard disk unit or Adobe PostScript 3 Expansion Unit has been connected only
*4. When the optional Adobe PostScript 3 Expansion Unit has been connected only
,Print Queues menu
U“Print Queues menu” on page 132
.Paper menu
U“Paper menu” on page 134
Menu item Description
Print Queue*3 XXXXXXXXXXX (name of waiting print
job)
Lists the Waiting Job Name, User, Estimated Start Time,
Estimated Print Time, and Printing Availability.
Hold Queue*2, *3 Check Held Jobs XXXXXXXXXXX
(name of paused job)
Lists the Paused Job Name, User, Paper Type, Source, Size,
and Reason For Hold.
Resume All Jobs Press Z to start printing.
Savd Job
Queue*3
XXXXXXXXXXX (name of stored print job) Lists the Stored Job Name, User, Length, Pages, Paper Type,
Copies, Source, Size, and Estimated Print Time.
Press Z to resume printing
Print Job Log Sheet Press Z to start printing.
Menu item Description
Load/Remove
Paper
Remove Paper Not displayed when no paper is loaded
Roll Paper*2 Displays instructions for loading the paper.
Roll 1*1
Roll 2*1
Cut Sheet (up to 0.8 mm thick)
Poster Board
Select Paper
Type
Plain Paper Lists supported Epson media.
Photo Paper
Matte Paper
Others
Custom Paper Lists the names of user-defined custom paper types.
Epson SureColor T-Series User’s Guide
Using the Control Panel Menu
127
-Maintenance menu
U“The Maintenance Menu” on page 138
Custom Paper
Setting
XXXXXXXXXXXX
XXXXXXXX
(name of custom
paper type)
Select Reference
Paper
Plain Paper Lists supported Epson
media.
Photo Paper
Matte Paper
Others
No Paper Selected No Paper Selected
Platen Gap Narrow, Standard, Wide, Wider
Detect Paper
Thickness
Press Z to start printing.
Paper Feed Adjust Pattern Press Z to start printing.
Value -0.70 to +0.70%
Paper Suction -4 to 0
Roll Paper Tension Normal, High, Extra High
Remove Skew On, Off
Setting Name 22 characters or less (letters, numbers, and symbols)
Restore Settings Yes, No
Print Paper List Press Z to start printing.
Roll Paper Remaining On, Off
Remaining Alert 1 to 15 m
Menu item Description
Nozzle Check Press Z to start printing.
Head Cleaning
Head Alignment Auto(Uni-D) Press Z to start printing/alignment.
Auto(Bi-D)
Manual(Uni-D) Press Z to start printing.
Manual(Bi-D)
Cutter
Maintenance
Adjust Cut Position -3 to 3 mm
Replace Cutter Press Z to start move.
Menu item Description
Epson SureColor T-Series User’s Guide
Using the Control Panel Menu
128
/Setup menu
U“Setup menu” on page 139
Menu item Description
Printer Setup Roll Paper Setup Auto Cut On, Off
Cutting Mode Normal, Silent
Refresh Margin On, Off
Page Line On, Off
Roll Paper Margin Normal, Top15mm/Bottom15mm, Top 35 mm/Bottom 15
mm, Top 45 mm/Bottom 15 mm, 3mm,15mm
Roll End Option Continue, Stop Printing, Reprint*3
Auto Loading*1 On, Off
Roll Switch Setting*1 Auto, Roll 1, Roll 2
Roll
Switch
Conditio
n*1
Paper
Type
Type Match, Disable
Paper
Length
Print Length, Remaining Amount, Disable
Paper
Width
Best Fit, Width Match, Disable
Print Job
Priority*
3
Roll In Use, In Order
Advanced
Settings
Roll Paper Tension 1 to 5
Less Head Scuffing On, Off
Drying Time Per Page Off to 60 min
Paper Size Check On, Off
Paper Skew Check On, Off
Store Held Job*3 On, Off
USB Timeout 10 to 600 sec
Epson SureColor T-Series User’s Guide
Using the Control Panel Menu
129
HP-GL/2
Settings
Quality Speed, Fine
Output Size Auto, A Series, US-ANSI, US-ARCH, B Series, Photo Series,
Others, User Defined
Margin 3mm, 5mm
Margin Options Standard, Add Margins, Clip By Margins
Rotate 0°, 90°, 180°, 270°
Mirror On, Off
Select Palette Software, Default, Palette A, Palette B
Define
Palette
Palette
A
Pen
Number
Pen Width, Pen Color
Palette B Pen
Number
Pen Width, Pen Color
Line Merge On, Off
Reset HP-GL/2
Settings
Yes, No
Restore Settings Yes, No
Option Setup*4 PS3 Expansion
Unit
Version PostScript Version, PDF Version
PS Status Sheet Press Z to start printing.
Output Size Auto, A Series, US-ANSI, US-ARCH, B Series, Photo Series,
Others, User Defined
Quality Speed, Normal, Fine
Color Mode Color, Grayscale
Dot Correction On, Off
CMYK Simulation SWOP v2, US Web Uncoated v2, US Sheetfed Coated v2, US
Sheetfed Uncoated v2, Coated GRACoL 2006, SWOP Grade
3 Paper, SWOP Grade 5 Paper, Coated FOGRA27, Web
Coated FOGRA28, Uncoated FOGRA29, Coated FOGRA39,
Euroscale Coated v2, Euroscale Uncoated v2,
JapanWebCoated (Ad), JapanColor2001Coated,
JapanColor2001Uncoated, JapanColor2002Newspaper,
JapanColor2003WebCoated, EPSON_TOYO, EPSON_DIC,
Off
RGB Source sRGB, Adobe RGB (1998), Apple RGB, ColorMatch RGB, Off
Rendering Intent Absolute, Relative, Perceptual, Saturation
Black Pt
Compensation
On, Off
Auto Rotate On, Off
Caching To HDD On, Off
PS Error Sheet On, Off
Menu item Description
Epson SureColor T-Series User’s Guide
Using the Control Panel Menu
130
Printer Status Firmware Version xxxxxxx,x.xx,xxxx
Option Status Displays the options connected.
Show Total Prints XXXXXX m2
Print Status Sheet Press Z to start printing.
Network Setup IP Address Setting Auto -
Panel IP Address, Subnet Mask, Default Gateway
IPv6 Setting Enable, Disable
IPsec Setting Enable, Disable
PSK Setting Set key at 20 characters or less (half-size characters or
symbols)
IEEE802.1x Setting Enable, Disable
HTTPS Redirect Setting Enable, Disable
Print Status Sheet Press Z to start printing.
Restore Settings Yes, No
Power Settings Sleep Mode 5 to 210 minutes
Power Off Timer Off, 1 to 24 hours
Restore Settings Yes, No
Preference Language Lists the supported languages.
Unit: Length m, ft/in
Alert Lamp Setting On, Off
Administrator
Menu
Change Password Enter a password.
Operational
Control
Network Setup Password Required, No Password Required
Power Cleaning
Manage HDD*3 Format Hard Disk Yes, No
Printer Mode Auto, PostScript*4, HP-GL/2
Date And Time MM/DD/YY HH:MM
Time Zone Enter the time difference between GMT and the current
time zone.
Reset PS Settings*4 Yes, No
Reset All Settings Yes, No
Menu item Description
Epson SureColor T-Series User’s Guide
Using the Control Panel Menu
131
Large Copy / Large Scan menu
This menu is displayed only when the optional Multifunction Scanner is connected.
U“Large Copying and Large Scanning using the Multifunction Scanner (Option)” on page 71
Menu item Description
Copy Settings Roll Select Roll 1, Roll 2
Scaling Manual 25 to 400%
Auto
Color/Grayscale Color, Grayscale
Document type Text/Line Drawing, Tracing Paper, Recycled Paper,
Blueprint, Poster
Width Auto, ISO A, US-ANSI, US-ARCH, JIS B, ISO B, cm, inch
Quality Speed, Fine
Density Level -3 to 3
Contrast Level -3 to 3
Background Level -3 to 3
Sharpness Level -3 to 3
Scan Setting*3 Color/Grayscale Color, Grayscale
Document type Text/Line Drawing, Tracing Paper, Recycled Paper,
Blueprint, Poster
Width Auto, ISO A, US-ANSI, US-ARCH, JIS B, ISO B, cm, inch
Save Image type JPEG, PDF
Resolution Direct Print (360dpi), 200dpi, 300dpi, 400dpi, 600dpi
File Size Compression High, Normal, Low
Density Level -3 to 3
Contrast Level -3 to 3
Background Level -3 to 3
Sharpness Level -3 to 3
Epson SureColor T-Series User’s Guide
Using the Control Panel Menu
132
Menu Descriptions
Print Queues menu
When the printer printed without using the printer driver included with the printer or the PS driver included with
the optional Adobe PostScript 3 Expansion Unit, the job names and estimated times in the following table may not
be displayed correctly.
*1. T7270D/T5270D only
*2. T7270/T5270/T3270 only
*3. When the optional hard disk unit or Adobe PostScript 3 Expansion Unit has been connected only
*4. When the optional Adobe PostScript 3 Expansion Unit has been connected only
Item Description
Print Queue*3 XXXXXXXXXXX (name of
waiting print job)
Waiting Job Name
User
Estimated Start
Time
Estimated Print
Time
Printing
Availability
Lists the estimated start time and time needed to
print the selected job.
It also predicts whether the job can be completed
without replacing paper, ink or the Ink
Maintenance Tank. The estimates are guidelines
only. We recommend proceeding even if Can Not
Complete is displayed.
Remote Manager and the LFP HDD Utility display
the reason for the Can Not Complete message
and allow you to hold or cancel the job.
U“Function Summary” on page 67
Printing availability by paper remaining cannot
be performed correctly if Roll Paper Remaining
is Off.
The printer will not predict availability on the
basis of the amount of ink remaining when
documents are printed using LFP Print Plug-In for
Office or EPSON CopyFactory5.
When the printer printed using the PS driver
included with the optional Adobe PostScript 3
Expansion Unit, Estimated Start Time and
Estimated Print Time are displayed as "0
minutes".
Held Queue*2, *3 View Hold
Queue
XXXXXXXX
XXX (name
of held job)
Paused Job Name
User
Paper Type
Source
Size
Reason For Hold
This option is available only if On is selected for
Store Held Job in the Setup menu,
Displays the print settings for held jobs and the
reason the job is held.
Jobs that are held because the job print settings
differ from those currently selected for the printer
can be printed as described below.
(1) Replace the paper and take whatever other
steps may be necessary to ready the device for
printing.
(2) Select Resume All Jobs.
Resume All Jobs Press the Z button to resume all held jobs currently in the queue.
Epson SureColor T-Series User’s Guide
Using the Control Panel Menu
133
Saved Job Queue*3 XXXXXXXXXXX (name of
stored print job)
Stored Job Name
User
Length
Pages
Paper Type
Copies
Source
Size
Estimated Print
Time
Shows the status of the selected stored job when
it was last printed.
After viewing the job, press the Z button to
enter the number of copies. Press the u/d
buttons to choose the number of copies and
press the Z button to display the estimated
print time and print availability. Press the Z
button to start printing.
Print Job Log Sheet Press the Z button to print the print job log.
Notes on ink consumption
This is a simple tool for estimating ink consumption for a given print job.
EPSON DOES NOT WARRANT ACCURACY. Actual ink consumption varies
considerably depending on such factors as software used, firmware
version, image printed, print settings, substrate types, frequency of use,
temperature, and variations in printer performance and user preferences
and practices. Estimates do not account for ink used over the life of the
cartridge for ink remaining in the cartridge after the replace cartridge
signal. Some Epson printers have multiple tools for estimating cost or ink
consumption and not all tools work the same way.
Item Description
Epson SureColor T-Series User’s Guide
Using the Control Panel Menu
134
Paper menu
If you use the Custom Paper Setting to register print settings for commercial paper on the T7270D/T5270D,
observe the following precautions.
If you are printing on both the Roll 1 and Roll 2, configure them individually, even when the paper is the same. If
the Custom Paper Setting set by the conditions set in Roll 1 is applied to the same type of paper loaded in Roll 2, but
the paper path, paper width, or other print conditions are different, printing will not be performed correctly.
*1. T7270D/T5270D only
*2. T7270/T5270/T3270 only
*3. When the optional hard disk unit or Adobe PostScript 3 Expansion Unit has been connected only
*4. When the optional Adobe PostScript 3 Expansion Unit has been connected only
* Default setting
Item Description
Load/Remove Paper Remove Paper Instructions are not displayed if no paper is
loaded.
Roll Paper*2 Highlight the paper to be loaded and press the
Z button. Follow the on-screen instructions to
load the paper.
If paper is already loaded in the printer, the
instructions for removing the loaded paper type
will be displayed before loading instructions are
shown.
Roll 1*1
Roll 2*1
Cut Sheet (up to
0.8 mm thick)
Poster Board
Select
Paper Type
Plain Paper Select the type of paper loaded.
Photo Paper
Matte Paper
Others
Custom Paper Select the name of the custom paper loaded in the printer.
Epson SureColor T-Series User’s Guide
Using the Control Panel Menu
135
Custom
Paper
Setting
XXXXXXXXXXX
(name of
custom paper
type)
Select
Reference
Paper
Plain Paper You can select the media type that is the closest
to the paper you are using.
Photo Paper
Matte Paper
Others
No Paper Selected Select this option if you do not wish to specify the
paper type.
Platen Gap Narrow Select the platen gap, which is the distance
between the print head and the paper. Normally,
select Standard. Select a wider setting if printed
images are smeared. If, upon performing head
alignment, you feel that it is still not completely
aligned, select Narrow.
Standard*
Wide
Wider
Detect Paper
Thickness
Press the Z button to print a pattern to determine the thickness of the
current paper.
Select the pattern number with the least misalignment from the print
results.
Item Description
Epson SureColor T-Series User’s Guide
Using the Control Panel Menu
136
Paper Feed
Adjust
Pattern Use this setting if you are unable to resolve
banding issues (horizontal striped lines or uneven
colors) in the standard print area (for cut sheets,
the area excluding the 1 to 2 cm strip at the
bottom of the paper) even after head cleaning or
head alignment.
Pattern selected
Press the Z button to print an adjustment
pattern. Measure the distance between the “+”
symbols.
Use only the distance between the center
symbols or the average of the distances between
the left, center, and right symbols.
After the adjustment pattern is printed, the
length of the pattern will be displayed in the
control panel. Press the u/d buttons to enter the
measured value and press the Zbutton.
Value selected
Choose an adjustment between -0.70 and
+0.70%.
Selecting too small a value causes dark bands;
adjust the amount upward. Similarly, choosing
too large a value causes white bands; adjust the
amount downward.
Value
Paper Suction -4 to 0 (0*) It is important to choose the appropriate amount
of suction for the paper used in order to maintain
the correct distance between the paper and the
print head. Choosing too high a value for thin or
soft paper will increase the distance between the
paper and the print head, causing print quality to
decline or preventing the paper feeding correctly.
In such cases, you will need to lower the paper
suction. The suction power is weakened when the
parameter is lowered.
Roll Paper
Tension
Normal*Select High or Extra High if the paper wrinkles
during printing.
If Extra High is set, the following setting is
enabled: Setup menu > Advanced Settings >
Roll Paper Tension.
High
Extra High
Remove Skew On*Select whether to enable (On) or disable (Off)
paper skew reduction.
Off
Item Description
Epson SureColor T-Series User’s Guide
Using the Control Panel Menu
137
Setting Name Enter a name of up to 22 characters for custom paper settings. Choose an
easy-to-remember name for quick selection.
Restore
Settings
Yes Restore the selected custom paper settings to
default values.
No
Print Paper List Press the Z button to print a list of custom paper settings.
Roll Paper Remaining On*Select whether to display/record (On) or not to
display/record (Off) the amount of remaining roll
paper. If On is selected, you will be prompted to
enter the length of the roll. The following options
can be made available by entering the length of
the loaded roll.
OTime until replacement
When the roll is removed, a barcode will
automatically be printed on the roll stating
the length remaining, the value selected for
the roll remaining alert, and the paper type.
The barcode is automatically read and
settings adjusted the next time the paper is
used, improving efficiency when multiple
rolls of paper are used.
OPrinting Availability
The printer will estimate printing availability
based on the length of the roll.
Off
Remaining Alert 1 to 15 m (5*) Displayed when On is selected for Roll Paper
Remaining.
Set within a range from 1 to 15 m to display a
warning when the amount of remaining roll
paper drops below that limit. You can set in 1 m
increments.
Item Description
Epson SureColor T-Series User’s Guide
Using the Control Panel Menu
138
The Maintenance Menu
Item Description
Nozzle Check Press the Z button to print a nozzle check pattern. Inspect the
pattern visually and perform head cleaning if you detect faint or
missing colors.
U“Checking for clogged nozzles” on page 156
Head Cleaning
Inspect the printed pattern and select the check boxes for patterns
with faint or missing areas. To select all nozzles, place a check in the
box on the left.
U“Cleaning the print head” on page 157
Head Alignment Auto(Uni-D) If print results are grainy or out of focus, perform head alignment to
realign the print head. If Auto is selected, the printer will scan the
printed pattern during printing and realign the head automatically.
If Manual is selected, a pattern will be printed; inspect the pattern
visually and enter the value you think appropriate.
U“Minimizing Print Misalignments (Head Alignment)” on page 158
Auto(Bi-D)
Manual(Uni-D)
Manual(Bi-D)
Cutter Maintenance Adjust Cut Position -3 to 3 mm You can fine tune the cut position when printing
to roll paper with no margins in all directions. The
cut position can be adjusted in increments of 0.2
mm.
Replace Cutter Moves the cutter to the replacement position so it can be replaced.
Press the Z button to move the cutter to the replacement position.
The paper must be removed before the cutter can be replaced.
Remove the paper before proceeding. U“Replacing the Cutter” on
page 163
Epson SureColor T-Series User’s Guide
Using the Control Panel Menu
139
Setup menu
Selecting Administrator Menu displays a password prompt. No password is entered at shipment; press the Z
button to proceed. If the administrator password has been changed, enter the administrator password.
*1. T7270D/T5270D only
*2. T7270/T5270/T3270 only
*3. When the optional hard disk unit or Adobe PostScript 3 Expansion Unit has been connected only
*4. When the optional Adobe PostScript 3 Expansion Unit has been connected only
* Default setting
Printer Setup
Roll Paper Setup
Item Description
Auto Cut On*Choose On to automatically cut roll paper using the built-in
cutter as each page is printed or Off to disable auto paper
cutting. The setting selected with the printer driver takes priority
when the printer driver is used.
Off
Cutting Mode Normal*If you want to reduce operation noise during cutting, set Silent. If
Silent is set, the cutting speed is reduced.
Silent
Refresh Margin On*If On is selected during borderless printing, the printer will
automatically trim the leading edge to remove any ink stains that
may have been left by the previous copy; to disable this feature,
choose Off.
Off
Page Line On*If Auto Cut is Off, you can choose to print (On) or not print (Off)
cut lines on roll paper. Cut lines are not printed if Auto Cut is On
or when cut sheets or poster board is used.
Note, however, that if the roll width selected with the computer
is narrower than the paper loaded in the printer, cut lines will be
printed regardless of the option selected for Auto Cut.
The setting selected with the printer driver takes priority when
the printer driver is used.
Off
Roll Paper Margin Normal*When set to Normal, the top and bottom margins are 15 mm,
and the left and right margins are 3 mm.
Except for 15mm, the left and right margins for all other settings
are 3 mm.
U“Printable area” on page 63
Top15mm/Bottom
15mm
Top35mm/Bottom
15mm
Top45mm/Bottom
15mm
3 mm
15 mm
Roll End Option Continue Select the action to perform for a roll after replacement: print the
remaining data (Continue) / do not print (Stop Printing) / print
again from the beginning (Reprint).
Stop Printing*
Reprint*3
Epson SureColor T-Series User’s Guide
Using the Control Panel Menu
140
Auto Loading*1 On*Normally, leave the setting at On.
If you experience problems with automatic loading when you
use commercially available paper because of lack of tension,
slipperiness, extremely large curls, or other problems, set to Off.
Remove all paper before configuring this setting. If paper is
loaded, the setting cannot be changed.
While the setting is Off, the Roll 2 unit cannot be used.
Off
Roll Switch Setting*1 Auto*Select the action to take when the roll currently in use is under
the following conditions: automatically switch between Roll 1
and Roll 2 and print (Auto) / print fixed to Roll 1 (Roll 1)/print
fixed to Roll 2 (Roll 2).
OThe roll is finished, and there is data still to be printed.
OThe printer predicts that there is not enough roll paper
remaining, and printing cannot be completed.
OThe print margin will be large for the width of the print job.
When the setting is Auto, the roll is switched according to the
Roll Switch Condition setting.
Roll 1
Roll 2
Item Description
Epson SureColor T-Series User’s Guide
Using the Control Panel Menu
141
Advanced Settings
Roll Switch
Condition*1
Paper Type Type Match*From the following options, select the condition under which to
switch to another roll for printing when the current roll has run
out.
OType Match: Switch to the other roll for printing only when
the paper type specified in the job and the paper type of the
other roll are the same.
If a different type of paper has been loaded on the other roll,
an error appears, and the printer cannot print.
ODisable: Print even when the paper type is different.
Disable
Paper
Length
Print Length*From the following options, select the conditions when you want
to switch in consideration of roll paper remaining and print
length (length of one page of a print job).
Note that if Roll Paper Remaining is Off in the Paper menu, this
setting is disabled regardless of its configuration.
OPrint Length: If both Roll 1 and Roll 2 have enough paper
remaining for the print length, print using the roll with the
lower remaining amount. If the remaining amount of one
roll is shorter than the print length, print using the other roll.
ORemaining Amount: Print using the roll with the lower
remaining amount regardless of the print length.
ODisable: Print using the roll currently in use regardless of the
remaining amount or print length.
Remaining
Amount
Disable
Paper
Width
Best Fit*From the following options, select the conditions when you want
to use the roll paper that reduces print margins in consideration
of roll paper width and print job length (the value of Document
Size of the printer driver).
OBest Fit: Compare the roll width of Roll 1 and Roll 2 and the
width of the print job, and then print using the roll with the
smaller print margin.
OWidth Match: Print using the roll with a width that matches
the width of the print job.
ODisable: Print using the roll currently in use regardless of the
roll paper width or print job width.
Width Match
Disable
Print Job
Priority*3
Roll In Use Select the print job priority when there are several waiting jobs:
print jobs that can be printed by the roll currently in use, switch
to another roll, and then print the remaining jobs (Roll In Use) /
Print jobs in the order they were received (In Order). When the
setting is In Order, automatic roll switching operations may be
frequent depending on the settings of the print jobs, and this
may increase the overall print time.
In Order*
Item Description
Roll Paper Tension 1 to 5 (3*) This setting is used if one of the following settings are configured to
Extra High: Paper menu > Custom Paper Setting > Roll Paper Tension
or Printer driver's Paper Configuration > Roll Paper Tension.
If wrinkles are formed on the paper during printing when the
abovementioned Roll Paper Tension is High, set it to Extra High, and
then configure the strength of the tension using this setting.
Higher values produce higher tension.
Item Description
Epson SureColor T-Series User’s Guide
Using the Control Panel Menu
142
HP-GL/2 Settings
Less Head Scuffing On If the paper is thick, the print head may scuff the print surface. Choose On
to prevent scuffing. This option can be used to temporarily change the
value selected for Custom Paper Setting > Platen Gap in the Paper
menu. Note, however, that On has no effect when Wider is selected for
Platen Gap.
Off*
Drying Time Per Page Off to 60 minutes
(Off*)
Specify how long the printer pauses to allow the ink to dry after printing
each page; choose from values between 0 and 60 minutes. Depending
on the ink density or paper type, the ink may take a while to dry. If the ink
blurs on the paper, set a longer time for drying the ink.
The longer the drying time, the more time required for printing.
Paper Size Check On*Choose whether the printer automatically detects (On) or does not
detect (Off) the paper width. Try choosing Off if a paper setting error is
displayed when the paper is correctly loaded. Note, however, that the
printer may print outside the paper when Off is selected. If it prints
beyond the edges of the paper, the inside of the printer becomes dirty
with ink. We generally recommend to operate with this setting set to On.
Off
Paper Skew Check On*If On is selected, an error will be displayed in the control panel and
printing will stop if the paper is skewed; select Off to disable this feature.
On is recommended in most circumstances as skewed paper may cause
the printer to jam.
Off
Store Held Job*2, *3 On This setting is displayed if an optional hard disk unit or Adobe PostScript
3 Expansion Unit is connected. If On is selected, print jobs that require a
paper type, source, or output paper size (width) that differs from those
currently selected with the printer will be saved as held jobs; select Off to
disable this feature.
If Off is selected, an error will be displayed and will printing will stop if
the source selected for the print job does not match that selected with
the printer.
When On is selected, printing will not stop if an error occurs; instead, jobs
with non-matching settings will be saved to the hard disk unit or Adobe
PostScript 3 Expansion Unit as held jobs. Held jobs can be printed from
the Print Queue menu after the printer has been readied by, for example,
loading the correct type of paper.
U“Function Summary” on page 67
Off*
USB Timeout 10 to 600 seconds
(10*)
If printing stops mid-way when the printer and computer are connected
by a USB cable, set a longer time.
Item Description
Quality Speed Choose Print Quality in view of image quality and print speed.
Fine*
Item Description
Epson SureColor T-Series User’s Guide
Using the Control Panel Menu
143
Output Size Auto*The hard clip area of the PS command of the data becomes the base
output size. The actual output size depends on the Margin Options
setting.
When the data does not contain a PS command, the smallest rectangle
area of in the following illustration including the print object
becomes the base output size.
A
Series/US-ANSI/US
-ARCH/B
Series/Photo
Series/Others
Choose the base output size from the compatible standard sizes. The
actual output size depends on the Margin Options setting.
For a cut sheet, this setting is available only when the data does not
contain a PS command.
If the data contains a command, this setting is not available, and the hard
clip area of the PS command becomes the base output size.
User Defined Select this option when outputting at non-standard sizes. After selecting
this setting, set Paper Width and Paper Height. You can set in 0.1 mm
increments.
Paper Width
T7270/T7270D: 89*1 to 1,118 mm
T5270/T5270D: 89*1 to 914 mm
T3270: 89*1 to 610 mm
Paper Height
127 to 4,620 mm
The actual output size depends on the Margin Options setting.
*1. The smallest size supported by the printer is 254 mm wide × 127 mm
long. If a smaller size is entered for this setting, the document will print
with wider-than-expected margins, which must be trimmed.
Margin 3mm*Select the top, bottom, left, and right margin values.
For a cut sheet, the bottom margin is 14 mm regardless of the settings.
5mm
Item Description
Epson SureColor T-Series User’s Guide
Using the Control Panel Menu
144
Margin Options Standard*The position at which the margin is added depends on the Output Size
setting, as shown below.
OWhen set to Auto
Adds the value selected for Margin (area of in the following
illustration) outside the hard clip area of the PS command of the
data (area of in the following illustration).
OWhen set to a standard size or User Defined
Adds the value selected for Margin (area of in the following
illustration) inside the size selected for Output Size (area of in
the following illustration) and prints only the section within the area
excluding the margins.
Item Description
Epson SureColor T-Series User’s Guide
Using the Control Panel Menu
145
Add Margins The position at which the margin is added depends on the Output Size
setting, as shown below.
OWhen set to Auto
The result is the same as when Standard is selected.
OWhen set to a standard size or User Defined
Adds the value selected for Margin (area of in the following
illustration) outside the size selected for Output Size (area of in
the following illustration). With the actual Output Size, the margin
section becomes larger than the selected size (the area of in the
following illustration).
Item Description
Epson SureColor T-Series User’s Guide
Using the Control Panel Menu
146
Clip By Margins Depending on the Output Size setting, adds the value selected for
Margin (area of in the following illustration) inside the hard clip area
of the PS command of the data or the size selected for Output Size (area
of in the following illustration). When there is a print object in the
margin section, it is clipped and not printed.
Rotate 0°*You can rotate the coordinates of the drawn data counterclockwise in
units of 90° before printing. Note that objects drawn by RTL are not
rotated.
When both this setting and the RO command specify rotation, rotation is
performed using the combined amount of both values. Note that
rotation by the RO command is for objects only (the arrow section in the
following illustration), and rotation is not performed for the drawn area
(the square section in the following illustration). As a result, objects in a
section that protrude from the drawn area are not printed.
90°
180°
270°
Item Description
Epson SureColor T-Series User’s Guide
Using the Control Panel Menu
147
Mirror On Select whether to flip horizontally (mirror) using the center of the Output
Size width as the basis line and then print (On) or print without flipping
horizontally (Off).
If an angle is specified for Rotate, the rotated result is flipped
horizontally.
Off*
Select Palette Software*From the following selections, choose the palette that specifies the color
and thickness of the logical pen.
OSoftware: Print according to the pen configurations set in the
application, and ignore the built-in palette of the printer.
ODefault: Print according to the settings of the built-in palette of the
printer specified in advance. The settings of the palette cannot be
changed. The built-in palette specifies a logical pen with a pen
width of 0.35 mm and 256 colors. For a sample of colors that
correspond to the color numbers, see the included "Color
Palette.pdf".
"Color Palette.pdf" recommends checking a print result that was
printed with Print Quality set to CAD / Line Drawing (Color) in the
included printer driver.
OPalette A/Palette B: The printer prints according to the settings of
the built-in palette that you specified for Define Palette. If Define
Palette setting is not set, the results are the same as when Default
is selected.
When Default/Palette A/Palette B is set, the pen configurations set in
the application are ignored.
Default
Palette A
Palette B
Define Palette Palette A*You can define a unique built-in palette by specifying the pen width and
color for the 16 types of logical pen. There are two types of definable
built-in palettes: Palette A and Palette B. Select a palette to be defined,
select Pen Number, and then define the Pen Width and Pen Color for
each pen. For a sample of colors that correspond to the color numbers,
see the included "Color Palette.pdf".
"Color Palette.pdf" recommends checking a print result that was printed
with Print Quality set to CAD / Line Drawing (Color) in the included
printer driver.
Palette B
Item Description
Epson SureColor T-Series User’s Guide
Using the Control Panel Menu
148
Restore Settings
Option Setup*4
PS3 Expansion Unit
Line Merge On Select whether to merge the intersection of the overlapping lines within
the image according to the MC command of the data (On) / Move lines to
be printed later to the front at intersections (Off).
Off*
Reset HP-GL/2 Settings Yes If Yes is selected, the HP-GL/2 Settings are restored to default values.
No
Description
Yes If Yes is selected, the Printer Setup is restored to default values.
No
Item Description
Version The supported PostScript version and the latest version for processable PDF files are displayed.
If the PDF version displayed in the document properties of the PDF file is the same or earlier than
the version displayed here, the file can be processed.
PS Status Sheet If the Z button is pressed, the information of the Adobe PostScript 3 Expansion Unit is printed.
Output Size Auto Select the size of the paper used for printing.
When Auto is selected, the printer prints using the size of the
print data. The actual output size depends on the margin
settings.
When a standard size or User Defined is selected, all print data is
enlarged or reduced to the selected paper size and then printed.
The sizes that can be selected vary with the printer model.
When print data is created with the paper size set to A4, the
following settings have the described results.
Auto: data is printed with margins added outside the A4 size.
A4: data is printed with the A4 data reduced to the printable area
of the A4 size.
A Series
(A4*)/US-ANSI/US-ARCH/B
Series/Photo
Series/Others
User Defined
Quality Speed Choose Print Quality in view of image quality and print speed.
Normal*
Fine
Item Description
Epson SureColor T-Series User’s Guide
Using the Control Panel Menu
149
Color Mode Color*Specify whether to print in color or switch to black and white and
then print. Depending on the paper type specified on the printer,
the setting is not displayed. When you are using the
T7270D/T5270D, the setting depends on the paper type of the
roll paper currently in use.
Grayscale
Dot Correction On This setting is displayed only when the paper type is set to
Singleweight Matte Paper and Plain Paper.
When you are using the T7270D/T5270D, the setting depends on
the paper type of the roll paper currently in use.
If lines printed with CAD programs or similar programs have gaps
or smudges, you may be able to reduce them by setting On.
Off*
CMYK Simulation SWOP v2/US Web Uncoated v2/US Sheetfed Coated v2/US
Sheetfed Uncoatedv2/Coated GRACoL 2006/SWOP Grade 3
Paper/SWOP Grade 5 Paper/Coated FOGRA27/Web Coated
FOGRA28/Uncoated FOGRA29/Coated FOGRA39/Euroscale
Coated v2*/Euroscale Uncoated v2/JapanWebCoated
(Ad)/JapanColor2001Coated/JapanColor2001Uncoated/Jap
anColor2002Newspape/JapanColor2003WebCoate/EPSON_
TOYO/EPSON_DIC/Off
When you simulate CMYK ink
colors of offset printers, you
can select the color of the
CMYK ink to be simulated.
If Off is set, ink is not
simulated.
RGB Source sRGB When you will print RGB data, you can select the color space of
the RGB to be simulated.
If Off is set, ink is not simulated.
Adobe RGB (1998)*
Apple RGB
ColorMatch RGB
Off
Rendering Intent Absolute Select the conversion method (rendering intent) of color space
when carrying out CMYK simulation or RGB simulation from the
following four types.
OAbsolute Colorimetric: Assigns absolute color gamut
coordinates to the original and print data and converts the
data. Color tone adjustment is not performed on any white
point (or color temperature) for the original or print data.
This setting is appropriate for when color accuracy is
important, such as when printing logo colors.
ORelative Colorimetric: Converts the data so that a set of
color gamut and white point (or color temperature)
coordinates in the original data match their corresponding
print coordinates. This feature is used for many types of
color matching.
OPerceptual: Converts the data so that a more visually
natural image is produced. This setting is appropriate for
photo images.
OSaturation: Convert focusing on the vividness of color
rather than color accuracy. Suitable for business graphics
such as graphs and charts, for which the use of bright colors
is preferred.
Relative
Perceptual*
Saturation
Black Pt Compensation On When you have converted from a wide color space to narrow
color space or you feel that the shadows are smudged, set to On.
Off*
Item Description
Epson SureColor T-Series User’s Guide
Using the Control Panel Menu
150
Printer Status
Network Setup
Auto Rotate On Select whether to rotate portrait print data 90° to the right
automatically (On) or print without rotation (Off).
Print data that was created in a landscape orientation is not
automatically rotated even when this setting is On.
Off*
Caching To HDD On Normally, leave the setting at Off. If the print head stops
frequently while waiting for data expansion during printing, set
to On.
Off*
PS Error Sheet On Select whether to print a sheet with the error condition listed
(On) or not to print (Off) when a PostScript error occurs during
printing or an error occurs during printing of a PDF file.
Off*
Item Description
Firmware Version xxxxxxx,x.xx,xxxx You can see the firmware version.
When an optional auto take-up reel unit is connected, its
firmware version is displayed below the firmware version of the
printer.
Furthermore, when an optional Adobe PostScript 3 Expansion
Unit is connected, its two control versions are displayed at the
end.
Option Status Lists the optional accessories currently connected to the printer and available for use.
Show Total Prints XXXXXX m2Displays the total area of media printed (to a maximum of six
digits).
Print Status Sheet Press the Z button to print a list of current printer settings.
Choose this option to view settings at a glance.
Item Description
IP Address Setting Auto*Select whether to use DHCP to set the IP address (Auto), or to set
the address manually (Panel). Choose Panel to enter the IP
address, Subnet Mask, and Default Gateway. Contact your
system administrator for detailed information.
Panel
IPv6 Setting Enable Select whether to enable or disable the IPv6 function.
Disable*
IPsec Setting Enable Select whether to enable or disable the IPsec function.
Disable*
PSK Setting Enter a Pre-Shared Key of up to 20 characters (half-width alphanumeric characters and symbols).
IEEE802.1x Setting Enable Select whether to enable or disable the IEEE802.1X function.
Disable*
HTTPS Redirect Setting Enable Select whether to enable or disable the function to auto-direct
HTTP to HTTPS.
Disable*
Item Description
Epson SureColor T-Series User’s Guide
Using the Control Panel Menu
151
Power Settings
Preference
Administrator Menu
Print Status Sheet Press the Z button to print a list of the Network Setup. Use this information for a complete
overview of network settings.
Restore Settings Yes Select Yes to restore all Network Setup content to default
values.
No
Item Description
Sleep Mode 5 to 210 minutes (15*) The printer will enter sleep mode if no errors have occurred, no
print jobs have been received, and no actions are performed on
the control panel for an extended period of time. This setting
selects the amount of time until the printer enters sleep mode.
U“Using the Power Off Timer” on page 64
Power Off Timer Off The printer turns off automatically when there are no errors, no
print jobs being received, and no control panel or other
operations are performed for eight hours.
The delay before the printer turns off can be selected from values
between 1 and 24 hours in increments of 1 hour.
Choose Off to prevent the printer turning off automatically.
1 to 24 hours (8*)
Restore Settings Yes Select Yes to restore all Eco Settings to default values.
No
Item Description
Language Japanese, English, French,
Italian, German,
Portuguese, Spanish,
Dutch, Russian, Korean,
Chinese
Select the language used on the control panel's screen.
Unit: Length m*Select the unit of length which is displayed on the control panel's
screen or printed on the patterns.
ft/in
Alert Lamp Setting On*Choose whether the large alert lamp lights (On) or does not light
(Off) when an error occurs.
Off
Item Description
Change Password Enter an administrator password of up to 20 characters.
Selecting Administrator Menu displays a password prompt. The Administrator
Menu will only be displayed if the correct password is entered, preventing
non-administrators from accidentally changing settings.
Keep the password in a safe place.
Should you forget the password, contact your dealer or Epson Support.
Item Description
Epson SureColor T-Series User’s Guide
Using the Control Panel Menu
152
Operational
Control
Network Setup Password Required Choose whether the administrator password is
required to access Network Setup from the
control panel or Remote Manager.
No Password Required*
Power Cleaning
Inspect the printed pattern and select the check boxes for patterns with faint or
missing areas. To select all nozzles, place a check in the box on the left.
Manage HDD*3 Format Hard Disk Yes If Yes is selected, an optional hard disk unit or
Adobe PostScript 3 Expansion Unit that is
connected to the printer is formatted.
Formatting the hard disk unit or Adobe PostScript
3 Expansion Unit deletes all stored print jobs.
Hard disk units or Adobe PostScript 3 Expansion
Units that have been used with other printers
must be formatted before they can be used with
this printer.
No
Printer Mode Auto*Normally, leave the setting at Auto. Sent print data is identified, and the
operation mode is switched automatically. If operation mode switching is not
performed correctly, and printing is not performed correctly, set to the operation
mode to be used.
PostScript*4
HP-GL/2
Date And Time MM/DD/YY HH:MM Set the printer’s built-in clock. The time provided
by the clock is used when printing logs and status
sheets.
Time Zone Enter the difference between the current time zone and GMT.
The selected time zone is used in e-mail notifications sent by Remote Manager
when an error occurs and so on.
Reset PS Settings*4 Yes Select Yes to initialize the user font and user ICC
profile saved in the user area of the Adobe
PostScript 3 Expansion Unit. Initialization deletes
saved data.
No
Reset All Settings Yes Select Yes to restore defaults for all settings
except the Date And Time, Language, and Unit:
Length options in the Setup menu.
No
Item Description
Epson SureColor T-Series User’s Guide
Using the Control Panel Menu
153
Large Copy / Large Scan menu
This menu is displayed only when the optional Multifunction Scanner is connected.
U“Large Copying and Large Scanning using the Multifunction Scanner (Option)” on page 71
*1. T7270D/T5270D only
*2. T7270/T5270
*3. Displayed when the optional hard disk unit or PS3 Expansion Unit has been connected
*4. Displayed when the optional PS3 Expansion Unit has been connected
* Default setting
Copy Settings
Item Description
Roll Select Roll 1*Choose whether to copy and print using Roll 1 or Roll 2.
When roll paper that does not support large copy/large
scan is loaded, this option is not displayed.
Roll 2
Scaling Manual*25 to 400% (100*) Choose whether to set the copy scaling manually
(Manual) or zoom automatically in accordance with the
width of the loaded roll paper (Auto).
Auto
Color/Grayscale Color*Choose whether to copy a color document and print it
with colors or in black and white.
Grayscale
Document Type Text/Line Drawing*Select the type in accordance with the loaded document.
Tracing Paper
Recycled Paper
Blueprint
Poster
Width Auto*The default setting of Auto is recommended in most
situations. Note that, depending on the document, it may
not be possible to detect the width correctly even when
the setting is Auto. In such cases, change from the
standard size and specify a width of your choosing.
ISO A, US-ANSI,
US-ARCH, JIS B, ISO
B
The supported sizes are
displayed.
cm 20 to 90 cm (20*)
inch 8 to 36 in (8*)
Quality Speed*Choose the quality of copying and printing.
Fine prioritizes quality so the print speed is slower.
The selectable options vary with the Document Type
setting.
Fine
Density Level -3 to 3 (0*) Set the copy density. Negative values (-) are lighter, and
positive values (+) is darker.
Contrast Level -3 to 3 (0*) Set the contrast. Negative values (-) are weaker, and
positive values (+) are stronger.
Epson SureColor T-Series User’s Guide
Using the Control Panel Menu
154
Scan Setting*1
Background Level -3 to 3 (0*) Set the adjustment value for the background. Configure
this setting when you are copying documents with colors
or documents that are thin, or when removing unwanted
backgrounds. Negative values (-) are weaker, and positive
values (+) are stronger.
Sharpness Level -3 to 3 (0*) Set the sharpness. Negative values (-) are weaker, and
positive values (+) are stronger.
Item Description
Color/Grayscale Color*Choose whether to scan colored documents with colors
or convert to black and white and then scan.
Grayscale
Document Type Text/Line Drawing*Select the type in accordance with the loaded document.
Tracing Paper
Recycled Paper
Blueprint
Poster
Width Auto*The default setting of Auto is recommended in most
situations. Note that, depending on the document, it may
not be possible to detect the width correctly even when
the setting is Auto. In such cases, change from the
standard size and specify a width of your choosing.
ISO A, US-ANSI,
US-ARCH, JIS B, ISO
B
The supported sizes are
displayed.
cm 20 to 90 cm (20*)
inch 8 to 36 in (8*)
Save Image Type JPEG*Select the file format for scanned images. When
Resolution is Direct Print (360dpi), only JPEG is
available.
PDF
Resolution Direct Print (360dpi)*Choose the resolution for scanning.
When Direct Print (360dpi) is selected, you can print
scanned image files directly. If you choose a resolution
other than Direct Print (360dpi), open Scan File
Options, perform Send To Shared Folder, and print on a
computer via an application.
200dpi
300dpi
400dpi
600dpi
File Size Compression High Choose the compression rate when saving scanned
images.
Normal*
Low
Density Level -3 to 3 (0*) Choose the density for scanning. Negative values (-) are
lighter, and positive values (+) is darker.
Contrast Level -3 to 3 (0*) Set the contrast. Negative values (-) are weaker, and
positive values (+) are stronger.
Item Description
Epson SureColor T-Series User’s Guide
Using the Control Panel Menu
155
Background Level -3 to 3 (0*) Set the adjustment value for the background. Configure
this setting when you are scanning documents with
colors or documents that are thin, or when removing
unwanted backgrounds. Negative values (-) are weaker,
and positive values (+) are stronger.
Sharpness Level -3 to 3 (0*) Set the sharpness. Negative values (-) are weaker, and
positive values (+) are stronger.
Item Description
Epson SureColor T-Series User’s Guide
Maintenance
156
Maintenance
Adjusting the Print Head
You need to adjust the print head if white lines appear
in your print outs or if you notice the print quality has
declined. You can perform the following printer
maintenance functions for maintaining the print head
in good condition to ensure the best print quality.
Carry out appropriate maintenance depending on the
print results and situation.
Checking for clogged nozzles
Perform a nozzle check to check for clogs if the printer
has not been used for an extended period or before
important print jobs. Visually inspect the printed
check pattern and clean the print head if you notice
faint or missing areas.
Cleaning the print head
Clean the print head if you notice faint or missing areas
in printed documents. Cleans the surface of the print
head to improve the print quality. Choose normal or
power cleaning according to the level of cleaning
required.
U“Cleaning the print head” on page 157
Normal cleaning is recommended in most
circumstances. Use power cleaning if the nozzles
remain clogged after normal cleaning has been
performed several times.
Adjusting the print head position (Print Head
Alignment)
Perform Head Alignment if lines are misaligned or
print results are grainy. The Head Alignment function
corrects print misalignments.
U“Minimizing Print Misalignments (Head
Alignment)” on page 158
Checking for clogged nozzles
Nozzle checks can be performing from a computer or
using printer's control panel.
From the computer
Explanations in this section use the Windows printer
driver as an example.
Use Epson Printer Utility 4 for Mac OS X.
U“Epson Printer Utility 4 Functions” on page 122
1Make sure that the roll paper or a cut sheet of A4
size or larger is loaded in the printer.
Make sure you set the paper source and media
type correctly according to the paper you use.
2Click Nozzle Check from the Utility tab in the
printer driver's Properties (or Printing
preferences) screen.
3Click Print.
The nozzle check pattern is printed.
4Check the nozzle check pattern.
If there is no problem: click Finish.
If there is a problem: click Clean.
After printing a nozzle check pattern, make sure
that the nozzle check pattern printing is
complete before printing your data or cleaning
the print head.
Epson SureColor T-Series User’s Guide
Maintenance
157
From the printer
Buttons that are used in the following settings
1Make sure that the roll paper or a cut sheet of A4
size or larger is loaded in the printer.
Make sure you set the paper source and media
type correctly according to the paper you use.
2Confirm that the printer is ready to print. Press
the " button.
The Maintenance menu will be displayed.
3Confirm that Nozzle Check is highlighted and
press the Z button.
A confirmation dialog will be displayed.
4Press the Z button to print a check pattern.
Review the printed check pattern while referring
to the following section.
Example of clean nozzles
There are no gaps in the nozzle check pattern.
Example of clogged nozzles
If there are areas missing from the pattern, select
Head Cleaning and clean the print head.
U“Cleaning the print head” on page 157
Cleaning the print head
Although head cleaning can be performed from the
computer or the printer, the cleaning procedures differ
as explained below.
OFrom the computer
All nozzles are cleaned.
OFrom the printer
You can clean all nozzles or select for cleaning only
those nozzles for which the printed nozzle check
pattern indicates a problem.
Notes on head cleaning
Note the following points when performing head
cleaning.
OClean the print head only if print quality declines;
for example, if the printout is blurry or the color is
incorrect or missing. Ink is consumed when head
cleaning is performed.
OCleaning all nozzles consumes some of each color
of ink. Even if you are using only black inks for
black and white printing, color inks are also
consumed.
OWhen repeating head cleaning in a short time
period, the Ink Maintenance Tank may fill up
quickly due to a small amount of ink evaporation
in the Ink Maintenance Tank. Prepare a spare Ink
Maintenance Tank if there is not enough empty
space in the box.
OIf the nozzles are still clogged after cleaning the
print head several times, we recommend trying
power cleaning.
OPower cleaning consumes more ink than normal
head cleaning. Check the remaining ink level in
advance, and prepare a new ink cartridge before
you start cleaning if the ink is low.
OIf the nozzles are still clogged after performing
power cleaning, turn off the printer and leave it
overnight or longer. When left for some time, the
clogged ink may dissolve.
If the nozzles are still clogged, contact your dealer
or Epson Support.
Head Cleaning
From the computer
Explanations in this section use the Windows printer
driver as an example.
Epson SureColor T-Series User’s Guide
Maintenance
158
Use Epson Printer Utility 4 for Mac OS X.
U“Using Epson Printer Utility 4” on page 122
1Click Head Cleaning from the Utility tab in the
printer driver's Properties (or Printing
preferences) screen.
2Click Start.
Head cleaning starts and it takes about one to
ten minutes.
3Click Print Nozzle Check Pattern.
Confirm the nozzle check pattern.
If any segments are missing in the nozzle check
pattern, click Clean.
From the printer
Buttons that are used in the following settings
1Confirm that the printer is ready to print. Press
the " button.
The Maintenance menu will be displayed.
2Press the d/u buttons to highlight Head
Cleaning and press the Z button.
You will be prompted to choose nozzle rows.
3Select nozzle rows for cleaning.
Press the l/r buttons to highlight numbers
corresponding to check patterns with faint or
missing segments and press the d/u button to
select.
You can select multiple nozzle rows.
To select all nozzles, place a check in the box on
the left.
4Pressing the Z button displays a confirmation
message. Press the Z button to start head
cleaning.
A confirmation message is displayed when
cleaning is complete.
5To print a check pattern and check the status of
the clog, press the d/u buttons to highlight
Nozzle Check and press the Z button.
To exit without performing a nozzle check,
highlight Exit and press the Z button.
Minimizing Print Misalignments
(Head Alignment)
Because there is a small distance between the print
head and paper, misalignment may occur due to
humidity or temperature, the inertial force of the print
head's movements, or by moving the print head
bidirectionally. This may result in grainy prints or lines
that are incorrectly placed. When this happens,
perform Head Alignment to correct the print
misalignment.
Although Head Alignment can be performed from the
computer or the printer, the alignment procedures
differ as explained below.
OFrom the printer
Head alignment can be performed automatically
or manually.
In auto adjustment, the sensor reads the
adjustment pattern while it is printing, and
automatically registers the optimum adjustment
value to the printer.
Auto head alignment takes about 30 minutes to
Epson SureColor T-Series User’s Guide
Maintenance
159
complete.
In manual adjustment, you need to check the
pattern and enter the optimum adjustment value
for alignment. Manual alignment can be used with
cut sheets or other paper that does not support
auto alignment or if auto alignment does not fix
the problem completely.
Printing the pattern for manual head alignment
takes from 7 to 11 minutes. The time required
varies with the size of the pattern printed.
Uni-D and Bi-D head alignment are available in
both auto and manual modes. Bi-D is
recommended in most circumstances. Choose
Uni-D if Bi-D head alignment does not completely
fix the problem.
OFrom the computer
A computer can be used for auto head alignment.
In most cases, head alignment can be performed
successfully with just this operation. We normally
recommend this method as this is the simplest
method. Auto head alignment takes about 30
minutes to complete. Manual head alignment can
be performed from the printer's control panel if
you are using cut sheets or other paper that does
not support auto alignment or if auto alignment
does to fix the problem completely.
From the computer
Explanations in this section use the Windows printer
driver as an example.
Use Epson Printer Utility 4 for Mac OS X.
U“Using Epson Printer Utility 4” on page 122
1Load roll paper in the printer.
Choose a paper type that matches the paper in
the printer.
2Click Print Head Alignment from the Utility
tab in the printer driver's Properties (or
Printing preferences) screen.
Note:
Head Alignment is adjusted according to the paper
currently loaded in the printer. Load the paper for which
head alignment is required.
Note, however, that auto head alignment is not
available with the paper or in the circumstances listed
below.
OTransparent or colored media is loaded in the
printer.
OThe paper loaded in the printer does not support
auto head alignment.
See the following for information on the types of
paper that support auto head alignment.
U“Epson Special Media Table” on page 187
OThe current paper is more than 1.0 mm thick.
OThe printer is exposed to direct sunlight or another
light source that causes optical interference.
Head Alignment may also fail to produce the desired
results if nozzles are clogged. Perform head cleaning to
clear any clogs before proceeding.
Epson SureColor T-Series User’s Guide
Maintenance
160
Follow the on-screen instructions to align the
print head.
The sensor reads the adjustment pattern while it
is printing, and automatically registers the
optimum adjustment value to the printer.
From the printer
Buttons that are used in the following settings
1Make sure that the roll paper or a cut sheet of A4
size or larger is loaded in the printer.
Make sure you set the paper source and media
type correctly according to the paper you use.
2Confirm that the printer is ready to print. Press
the l/r buttons to highlight - and press the
Z button.
The Maintenance menu will be displayed.
3Use the d/u buttons to select Head Alignment
and press the Z button.
4Press the d/u buttons to highlight a head
alignment option.
5Press the Z button to print an adjustment
pattern.
If Auto is selected, the printer will automatically
align the head as it prints the head alignment
pattern. The Maintenance menu will be
displayed when head alignment is complete.
If Manual is selected, proceed to Step 6 to enter
adjustment based on a visual inspection of the
pattern.
6Note the numbers of the patterns with the
fewest white lines or in which the white lines are
most evenly spaced.
This would be pattern 3 in the example shown in
the illustration.
7After confirming that C1 is displayed in the
control panel's screen, press the d/u buttons to
select the number noted in Step 6 and press the
Z button.
8Repeat for all colors from C1 to BK2, pressing
the Z button each time.
9The Maintenance menu will be displayed once
the last number has been entered.
Epson SureColor T-Series User’s Guide
Maintenance
161
Replacing Consumables
Replacing Ink Cartridges
If one of the installed ink cartridges is expended,
printing cannot be performed. If an ink low warning is
displayed, we recommend replacing the ink
cartridge(s) as soon as possible.
If an ink cartridge runs out while printing, you can
continue printing after replacing the ink cartridge.
However, when replacing ink during a print job, you
may see a difference in color depending on the drying
conditions.
Supported ink cartridges
U“Options and Consumable Products” on page 185
How to replace
You can use the same procedure to replace all ink
cartridges.
1Make sure the printer is on.
2Open the cartridge cover.
3Hook a finger into the indentation on the top of
the cartridge and pull it straight toward you.
4Remove the new ink cartridge from the bag.
Shake the ink cartridge for 10 seconds 30 times
horizontally in approximately 5 cm movements
as shown in the illustration.
5Holding the cartridge with the label out, slide it
all the way into the slot.
cImportant:
Epson recommends the use of genuine Epson ink
cartridges. Epson cannot guarantee the quality or
reliability of non-genuine ink. The use of
non-genuine ink may cause damage that is not
covered by Epson’s warranties, and under certain
circumstances, may cause erratic printer
behavior. Information about non-genuine ink
levels may not be displayed, and use of
non-genuine ink is recorded for possible use in
service support.
cImportant:
Removed ink cartridges may have ink
around the ink supply port, so be careful not
to get any ink on the surrounding area when
removing the cartridges.
cImportant:
Do not touch the IC chips on the ink
cartridges. You may not be able to print
properly.
Epson SureColor T-Series User’s Guide
Maintenance
162
Match the color of the cartridge to the color of
the label on the printer.
Repeat Steps 3 to 5 to replace other ink
cartridges.
6Close the cartridge cover.
Replacing Ink Maintenance
Tanks
If the message Not Enough Space is displayed, replace
the specified Ink Maintenance Tank.
Supported Ink Maintenance Tanks
U“Options and Consumable Products” on page 185
How to replace
Some models of printer have Ink Maintenance Tanks
on both the left and right sides, but the procedure for
replacing the boxes is the same in all cases.
1Open the ink maintenance tank cover.
2Pull the Ink Maintenance Tank out.
Lifting the Ink Maintenance Tank up releases
the lock, and you can simply pull it straight out.
cImportant:
Install all ink cartridges into each slot. You
cannot print if any of the slots are empty.
cImportant:
We recommend that you remove and shake the
installed ink cartridges once every three months to
ensure print quality.
cImportant:
Do not reuse Ink Maintenance Tanks that have
been removed and left out in the open for a long
period of time. The ink on the inside will be dry
and hard and will be unable to absorb enough
ink.
cImportant:
Do not replace the Ink Maintenance Tank while
printing. Waste ink may leak.
Epson SureColor T-Series User’s Guide
Maintenance
163
3Place the used Ink Maintenance Tank in the
clear bag included with your new Ink
Maintenance Tank, and make sure that the
zipper is closed tight.
4Install the new Ink Maintenance Tank.
5Close the ink maintenance tank cover.
Replacing the Cutter
Replace the cutter when it is not cutting paper cleanly.
Supported cutter
U“Options and Consumable Products” on page 185
Use a cross-head screwdriver to replace the cutter.
Make sure you have a cross-head screwdriver with you
before replacing the cutter.
Buttons that are used in the following settings
1Remove any paper from the printer.
U“Removing Roll paper or Roll 1” on page 34
U“Removing Cut Sheets” on page 39
U“Removing Poster Board” on page 42
2Confirm that the printer is ready to print. Press
the l/r buttons to highlight - and press the
Z button.
The Maintenance menu will be displayed.
3Press the d/u buttons to select Cutter
Maintenance, and then press the Z button.
4Press the d/u buttons to highlight Replace
Cutter and press the Z button.
5The cutter will move to the replacement
position.
6Remove the old cutter from the printer.
Loosen the screw holding the cutter in place
using a cross-head screwdriver and pull the
cutter straight out.
cImportant:
Do not touch the IC chip on the Ink
Maintenance Tank.
Doing so may prevent normal operation and
printing.
cImportant:
Take care not to damage the cutter blade.
Dropping it or knocking it against hard objects
may chip the blade.
Epson SureColor T-Series User’s Guide
Maintenance
164
7Install the new cutter.
Insert the cutter so that the pin on the printer
matches up with the hole on the cutter. Use a
cross-head screwdriver to tighten down the
screw to hold the cutter in place.
8After replacing the cutter, press the Z button.
The cutter will return to its original position.
Ready is displayed in the control panel when the
process is complete.
!Caution:
Do not store the cutter within the reach of
children. The cutter's blade could cause an
injury. Pay careful attention when replacing
the cutter.
cImportant:
Screw up the cutter firmly, otherwise the cut
position may be slightly shifted or skewed.
Epson SureColor T-Series User’s Guide
Maintenance
165
Cleaning the Printer
To keep your printer in optimum operating condition,
clean it regularly (about once a month).
Cleaning the outside
1Remove any paper from the printer.
2Make sure the printer is turned off and the
screen has turned off, and then unplug the
power cable from the outlet.
3Use a soft, clean cloth to carefully remove any
dust or dirt.
In particular, clean the rear and sides so that
dust does not accumulate. (The illustration
below shows the printer when the Adobe
PostScript 3 Expansion Unit is connected.
If there is a serious dirt problem, clean it using a
soft, clean cloth dampened with a mild
detergent. Then wipe off with a dry, soft cloth.
Cleaning the inside
Clean the pressure rollers if prints are smudged or
soiled.
Ink and particles of paper adhering to the platen
should be removed, as they may otherwise soil the
paper.
Cleaning the roller
Follow the steps below to clean the roller by feeding
plain paper.
1Turn on the printer, and load it with widest
available roll paper.
U“Loading and Removing the Roll Paper” on
page 27
2Press the ) button followed by the d button.
Paper is fed while the d button is pressed. If the
paper is not soiled, cleaning is complete.
Cut the paper after cleaning is done.
U“Manual cut method” on page 33
Cleaning Inside the Printer
1Make sure the printer is turned off and the
screen has turned off, and then unplug the
power cable from the electrical outlet.
2Leave the printer for a minute.
3Open the printer cover and use a soft, clean
cloth to carefully clean away any dust or dirt
inside the printer.
cImportant:
Never use benzene, thinners, or alcohol to
clean the printer. They could cause
discoloration and deformities.
cImportant:
Failure to remove dust and particles of paper
from the platen could result in clogged nozzles or
damage to the print head.
Epson SureColor T-Series User’s Guide
Maintenance
166
Thoroughly clean area (a), shown in blue in the
illustration below. To avoid spreading the dirt,
wipe from the inside to the outside. If there is a
serious dirt problem, clean it using a soft, clean
cloth dampened with a mild detergent. Then,
wipe the inside of the printer with a dry, soft
cloth.
4If any paper particles (that looks like white
powder) accumulates on the platen, use
something like a cocktail stick to push it in.
5When you have finished cleaning, close the
printer cover.
Cleaning the
Multifunction Scanner
(option)
If the glass surface or rollers of the scanner are covered
in dust or stained, unwanted stripes and lines may
appear in the copy results and scanned images.
After cleaning, if you feel that the problem is still not
resolved, perform calibration.
U“Calibration” on page 183
1Turn off the printer and make sure the printer
screen has turned off, and then unplug the
power cable from the outlet.
2Open the scanner cover.
Push up the lock levers on both ends of the cover
to release the locks and open the cover.
3Clean the glass surface.
cImportant:
OBe sure not to touch the roller or the ink
absorbing areas (b, shown in gray)
during cleaning; otherwise, prints may
be soiled.
OBe careful not to touch the ink tubes
inside the printer, otherwise, the printer
may be damaged.
(
1
)
Prepare two lint-free clean cloths.
Apply glass cleaner to one cloth, and then use it
to wipe the glass surface.
Use a neutral glass cleaner that does not leave
streaks.
Epson SureColor T-Series User’s Guide
Maintenance
167
4Clean the roller directly under the glass surface.
Apply office-use liquid cleaner to a lint-free
clean cloth, and then wipe the roller surface.
While rotating the loading roller in front, wipe
the roller well.
5Close the scanner cover until you hear a click.
(
2
)
Use the other cloth to wipe away any remaining
glass cleaner.
Epson SureColor T-Series User’s Guide
Problem Solver
168
Problem Solver
What to do When a Message is Displayed
If the printer displays one of the messages shown below, refer to the solution listed and take the necessary steps.
Messages What to do
Ink Cartridge Error
Ink cartridge cannot be
recognized. Insert again or replace
ink cartridge.
ORemove and reinsert the ink cartridge. If the message persists, insert a new ink
cartridge (do not reinstall the cartridge that caused the error).
U“How to replace” on page 161
OCondensation may occur in the ink cartridge. Leave it at room temperature for at
least four hours before installing the ink cartridge.
U“Notes on handling ink cartridges” on page 21
Ink Cartridge Error
Ink cartridge cannot be detected.
Insert again or replace ink
cartridge.
Ink Cartridge Error
Please install the correct ink
cartridge.
Insert a genuine Epson ink cartridge approved for use in the printer.
U“Options and Consumable Products” on page 185
U“Replacing Ink Cartridges” on page 161
Ink Low The ink is low. Ready a new ink cartridge.
U“Options and Consumable Products” on page 185
Paper Load Error
Paper from Roll 1 cannot be
detected.
Remove and then reload the roll paper in question.
Before you reset the paper, cut the edge of the roll paper straight horizontally. Cut off
any jagged or folded sections.
If there is a problem with the edge, an automatic paper load error will occur.
Paper Load Error
Paper from Roll 2 cannot be
detected.
F/W Install Error
Firmware update failed.
Restart the printer.
Turn the printer off, wait for a few minutes, and then turn on the printer again.
Update the firmware again.
If this message appears on the LCD panel again, contact your dealer or Epson Support.
Command Error
Check driver settings.
Press the W button and select Job Cancel to stop printing. Confirm that the printer
driver you are using supports this printer.
Reel Unit Error
Check Auto Take-up Reel Unit and
restart printer.
Turn the printer off, wait for a few minutes, and then turn on the printer again.
If this message appears on the LCD panel again, contact your dealer or Epson Support.
Reel Unit Error
Connect Auto Take-up Reel Unit
cable and restart printer.
After reconnecting the cable connecting the auto take-up reel unit to the printer, turn
the printer off and then on again.
UThe Setup Guide supplied with the optional auto take-up reel unit.
Reel Unit Disconnected
Auto Take-up Reel Unit is
disconnected. Do you continue?
The auto take-up reel unit is not connected. After reconnecting the cable connecting the
auto take-up reel unit to the printer, select No to turn the printer off. Turn the printer
again after a short pause.
UThe Setup Guide supplied with the optional auto take-up reel unit.
To continue printing without using the auto take-up reel unit, select Yes.
Epson SureColor T-Series User’s Guide
Problem Solver
169
Take-Up Error
Is anything obstructing the
take-up reel sensor system?
After checking the take-up reel unit sensor and removing any obstructions, press the Z
button.
If there is loose paper around the take-up reel unit roll core, set the Auto switch to Off
and keep the Manual pressed in the take-up direction to remove the slack. After
confirming that the paper is correctly attached, return the Auto switch to its original
position and press the Z button.
U“Using the Auto Take-up Reel Unit (T7270 Only)” on page 51
HDD Error
HDD used for another printer
needs to be formatted. Continue?
Optional hard disk units and Adobe PostScript 3 Expansion Units that have been
connected to other devices must be formatted after being connected to this printer. The
disk can not be used until it is formatted. To format the disk, use the Setup menu in the
control panel.
U“Setup menu” on page 139
Storage Error
Check if hard disk unit is correctly
installed.
Press the W button and select Job Cancel to stop printing. Remove and then reconnect
the optional hard disk unit or Adobe PostScript 3 Expansion Unit.
If this message appears on the LCD panel again, contact your dealer or Epson Support.
When you are printing via the printer driver included with a printer, you can print
regardless of the hard disk status if you select the Advanced tab in the printer driver,
open the Settings dialog box of Hard Disk Unit, and select Print only. When the Adobe
PostScript 3 Expansion Unit is connected, you cannot print via the PS driver.
Paper Cut Error
Remove uncut paper.
After pressing the Z button, pull out the paper and cut along the line of the failed cut
using scissors or a third-party cutter.
Pull the edge of the paper straight outside the printer.
Data Size Error
Data size of print job is too large.
Check on print job.
The optional hard disk unit or Adobe PostScript 3 Expansion Unit can store print jobs up
to 100 GB in size. To print larger jobs, select the Advanced tab in the printer driver, open
the Settings dialog box of Hard Disk Unit, and select Print only; alternatively, ensure
that print jobs are less than 100 GB in size.
HDD Store Error
Hard disk does not have enough
space.
See documentation for how to
delete stored print jobs.
Unwanted jobs can be deleted in Remote Manager or the LFP HDD Utility.
U“Saving to and Reprinting on the Optional Hard Disk Unit” on page 67
HDD Boot Error
Hard disk error. Hard disk cannot
be used.
Press the Z button to clear the error from the control panel. When you are printing via
the printer driver included with the printer, you can print regardless of the hard disk unit
status when you select Print only in the Settings dialog box of Hard Disk Unit. When the
Adobe PostScript 3 Expansion Unit is connected, you cannot print via the PS driver.
If this message appears on the LCD panel again, contact your dealer or Epson Support.
Copy Error
Can not start copy with this printer
setting.
Refer to manual for details.
The printer will be unable determine the size of the current paper and make enlarged
copies when Off is selected for Paper Size Check in the Setup menu. In the Setup menu,
set Paper Size Check to On, and then reload the paper.
U“Setup menu” on page 139
Scanner Error
Refer to manual for details.
ORelease the A3/A4 scanner transportation lock and turn the printer and scanner off
and then on again.
OTurn the devices on and off several times. The scanner can be used after the
message is no longer displayed.
If this message appears on the LCD panel again, contact your dealer or Epson Support.
Held Jobs Limit
Held job queue full.
The number of held jobs has reached 200.
Press the Z button and select Resume All Jobs.
U“Function Summary” on page 67
Messages What to do
Epson SureColor T-Series User’s Guide
Problem Solver
170
Paper Size Error
Loaded paper is not supported
size.
The loaded paper width is not supported. Press the Z button and remove the paper.
Paper for use in the printer must be at least 254 mm wide. Use paper that is at least 254
mm wide.
Should this message be displayed with paper of a width that can be used in the printer,
you may be able to print if you select Off for Paper Size Check in the Setup menu.
U“Setup menu” on page 139
Paper Sensor Error
Loaded paper or print out has a
problem.
Refer to manual for details.
Press the W button to clear the error from the control panel.
If this error is displayed when performing automatic head alignment, check the
following items.
ODoes the paper support auto head alignment?
Head alignment is not available with transparent or colored media, tracing paper,
paper not supported by the auto head alignment function, or paper that is 1.0 mm
or more thick.
See the following for information on the types of paper that support auto head
alignment.
U“Epson Special Media Table” on page 187
OAre outside light sources interfering with the process?
If the printer is exposed to direct sunlight or another light source that causes optical
interference, shade the printer from these sources.
OAre the default values selected for both Platen Gap and Less Head Scuffing?
Restore both items to their default values.
OAre some print head nozzles clogged?
Perform head cleaning. U“Head Cleaning” on page 157
If this error is displayed in circumstances other than those listed above, check that the
printer supports the current paper.
Roll Setting Error
Specified roll paper is not loaded.
Continue to print with paper
currently loaded?
In Source of the printer driver, roll paper which is not loaded is selected.
If the Z button is pressed, the printer is forced to print using the loaded roll paper.
If the ( button is pressed, paper can be loaded.
Paper Type Error
Cannot switch to specified roll
paper because paper type is
different.
Continue to print with paper
currently loaded?
The Media Type setting of the printer driver and the paper type of the roll paper loaded
on the printer are different.
If the Z button is pressed, the printer prints to the roll paper currently in use.
If the ( button is pressed, paper can be switched.
If you want to switch a roll paper even though it is a different type, open the Setup menu,
and then under Roll Switch Condition, change Paper Type to Disable.
U“Setup menu” on page 139
Paper Width Error
Cannot switch to specified roll
paper because paper width is
different.
Continue to print with paper
currently loaded?
The Source setting of the printer driver and the width of the roll paper loaded on the
printer are different.
If the Z button is pressed, the printer prints to the roll paper currently in use.
If the ( button is pressed, paper can be switched.
If you want to switch a roll paper even though it is a different paper width, open the
Setup menu, and then under Roll Switch Condition, change Paper Width to a setting
other than Width Match.
U“Setup menu” on page 139
Messages What to do
Epson SureColor T-Series User’s Guide
Problem Solver
171
Paper Length Error
Insufficient remaining amount in
specified roll paper.
Continue to print with paper
currently loaded?
The remaining amount of roll paper loaded in Roll 1 and Roll 2 is shorter than the print
length, so the roll paper cannot be switched.
If the Z button is pressed, the printer prints to the roll paper currently in use.
If the ( button is pressed, paper can be replaced.
If you want to print even though remaining amount of roll paper is shorter than the print
length, open the Setup menu, and then under Roll Switch Condition, change Paper
Length to a setting other than Print Length.
U“Setup menu” on page 139
Roll Switch Error
Cannot switch roll paper
automatically.
Check printer settings.
Continue to print with paper
currently loaded?
If one of the following settings in the Setup menu is set as follows, roll paper is not
switched automatically.
OAuto Cut is Off.
OAuto Loading is Off.
If the Z button is pressed, the printer prints to the roll paper currently in use.
If the ( button is pressed, paper can be replaced.
To enable automatic switching of roll paper, change both settings above to On.
U“Setup menu” on page 139
Firmware Error
Firmware mismatch between PS3
Expansion Unit and printer.
Refer to manual for details.
Operation is not possible because the versions of firmware of the optional Adobe
PostScript 3 Expansion Unit and the firmware of the printer are not compatible.
Update both to the latest firmware.
The latest firmware can be downloaded from the Epson website.
Information
Cannot start copy because
non-supported media is loaded.
Refer to manual for details.
Load paper that supports large copy/large scan, and then print the copy/scan file again.
For paper that supports large copy/large scan, see the following.
U“Epson Special Media Table” on page 187
Information
Cannot send file.
Refer to manual for details.
If you tried to copy or send a large-scan image file to a shared folder, and this message
appears, check the following.
OAre the folder path, username, and password configured correctly in the shared
folder address setting of CopyCenter?
OIs there already a file with the same name in the save/transfer destination folder?
OIs there sufficient empty space in the save/destination folder?
If you tried to send an e-mail, and this message appears, ask your network administrator
if the e-mail settings have been configured correctly.
Information
Cannot receive mail.
Refer to manual for details.
Ask your network administrator if the e-mail settings have been configured correctly.
Messages What to do
Epson SureColor T-Series User’s Guide
Problem Solver
172
When a Maintenance Call/Service Call Occurs
Error messages What to do
Maintenance Request
Replace Part Now/Soon XXXXXXXX
A part used in the printer is nearing the end of its service life.
Contact your dealer or Epson Support and tell them the maintenance request
code.
You cannot clear the maintenance request until the part is replaced. A service
call occurs if you continue to use the printer.
Call For Service
XXXX Error XXXX
Power off and then on. If this doesn’t
work, note the code and call for service.
A call for service occurs when:
OThe power cable is not connected securely
OAn error that cannot be cleared occurs
When a call for service has occurred, the printer automatically stops printing.
Turn off the printer, disconnect the power cable from the outlet and from the AC
inlet on the printer, and then reconnect. Turn on the printer again multiple
times.
If the same call for service is displayed on the LCD panel, contact your dealer or
EpsonSupport for assistance. Tell them the call for service code is "XXXX".
Epson SureColor T-Series User’s Guide
Problem Solver
173
Troubleshooting
You cannot print (because the
printer does not work)
The printer does not turn on.
The printer turns off automatically.
The printer driver is not installed
properly (Windows).
The printer driver is not installed
properly (Mac OS X).
The printer is not communicating
with the computer.
oIs the power cable plugged into the electrical
outlet or the printer?
Make sure the power cable is securely plugged into
the printer.
oIs there a problem with the power outlet?
Make sure your outlet works by connecting the
power cable for another electric product.
oIs Power Off Timer enabled?
To prevent the printer turning off automatically,
select Off.
U“Setup menu” on page 139
oIs the icon for this printer displayed in the
Devices and Printers/Printer/Printers and
Faxes folder?
OYes
The printer driver is installed. See "The printer is
not connected correctly to the computer" on
the next page.
ONo
The printer driver is not installed. Install the
printer driver.
oDoes the printer port setting match the
printer connection port?
Check the printer port.
Click the Port tab in the printer Properties dialog and
check the option selected for Print to following
port(s).
OUSB:USBxxx (x stands for the port number) for
the USB connection
ONetwork: The correct IP address for the network
connection
If it is not indicated, the printer driver is not installed
correctly. Delete and reinstall the printer driver.
U“Uninstalling the printer driver” on page 121
oIs the printer added to the printer list?
Select System Preferences > Print & Scan (or Print
& Fax) from the Apple menu.
If the printer name is not displayed, add the printer.
oIs the cable plugged in properly?
Confirm that the interface cable is securely
connected to both the printer port and the
computer. Also, make sure the cable is not broken
nor bent. If you have a spare cable, try connecting
with the spare cable.
oDoes the interface cable specification match
the specifications for the computer?
Make sure the interface cable specifications match
the specifications for the printer and the computer.
U“System Requirements” on page 200
oWhen using a USB hub, is it being used
correctly?
In the USB specification, daisy-chains of up to five
USB hubs are possible. However, we recommend
that you connect the printer to the first hub
connected directly to the computer. Depending on
the hub you are using, the operation of the printer
may become unstable. If this should occur, plug the
USB cable directly into your computer's USB port.
Epson SureColor T-Series User’s Guide
Problem Solver
174
You cannot print under the network
environment.
The printer has an error.
The printer stops printing.
Your problem is not listed here.
oIs the USB hub recognized correctly?
Make sure the USB hub is recognized correctly on the
computer. If the computer correctly detects the USB
hub, disconnect all USB hubs from the computer and
connect the printer directly to the computer USB
port. Ask the USB hub manufacturer about USB hub
operation.
oAre the network settings correct?
Ask your network administrator for the network
settings.
oConnect the printer directly to the computer
using a USB cable, and then try to print.
If you are able to print via USB, there is a problem
with network settings. Ask your system
administrator, or refer to the manual for your
network system. If you cannot print via USB, see the
appropriate section in this User’s Guide.
oView the message displayed in the control
panel.
U“Control panel” on page 14
U“What to do When a Message is Displayed” on
page 168
oIs the status of print queue Pause?
(Windows)
If you stop printing or the printer stops printing
because of an error, the print queue enters a Pause
status. You cannot print in this status.
Double-click the printer icon in the Devices and
Printers, Printers, or Printers and Faxes folder; if
printing is paused, open the Printer menu and clear
the Pause check box.
oDoes the current printer status show
Printing Paused (Mac OS X)?
Open the status dialog for your printer and check
whether printing is paused.
(1) Select System Preferences > Print & Scan (or
Print & Fax) > Open Print Queue from the Apple
menu.
(2) Double-click the icon for any printer that is
Paused.
(3) Click Resume Printer.
oDecide whether the trouble is caused by the
printer driver or the application. (Windows)
Perform a test print from the printer driver so that
you can check that the connection between the
printer and computer is correct and the printer driver
settings are correct.
(1) Make sure that the printer is turned on and in
ready status, and load A4 or larger paper.
(2) Open the Devices and Printers, Printers, or
Printers and Faxes folder.
(3) Right-click the target printer icon, and select
Properties.
(4) In the Properties dialog, select the General tab
and click Print Test Page.
After a while the printer starts to print a test page.
OIf the test page is printed correctly, the
connection between the printer and computer
is correct. Go to the next section.
OIf the test page is not printed correctly, check
the items above again.
U“You cannot print (because the printer does
not work)” on page 173
The "Driver Version" shown on the test page is the
version number of the Windows internal driver. This
differs from the Epson printer driver version that you
installed.
Epson SureColor T-Series User’s Guide
Problem Solver
175
The printer sounds like it is
printing, but nothing prints
The print head moves, but nothing
prints.
The nozzle check pattern is not
printed correctly.
The prints are not what you
expected
Print quality is poor, uneven, too
light, or too dark.
oConfirm the printer operation.
Print a nozzle check pattern. Because a nozzle check
pattern can be printed without connecting to a
computer, you can check the operations and print
status for the printer. U“Checking for clogged
nozzles” on page 156
Check the next section if the nozzle check pattern is
not printed correctly.
oIs the message Motor Self Adjustment
displayed on the control panel's screen?
The printer adjusts the internal motor. Wait for a
while without turning off the printer.
oPerform head cleaning.
The nozzles may be clogged. Print a nozzle check
pattern again after performing head cleaning.
U“Cleaning the print head” on page 157
oHas the printer been left unused for a long
time?
If the printer has not been used for a long time, the
nozzles may have dried up and have been clogged.
oAre the print head nozzles clogged?
If the nozzles are clogged, specific nozzles do not fire
ink and the print quality declines. Print a nozzle
check pattern.
U“Checking for clogged nozzles” on page 156
oWas Head Alignment performed?
With bidirectional printing, the print head prints
while moving left and right. If the print head is
misaligned, ruled lines may be misaligned
accordingly. If vertical ruled lines are misaligned with
bidirectional printing, perform Head Alignment.
U“Minimizing Print Misalignments (Head
Alignment)” on page 158
oAre you using a genuine Epson ink cartridge?
This printer is developed for use with Epson ink
cartridges. If you use non-Epson ink cartridges,
printouts may be faint, or the color of the printed
image may be changed because the remaining ink
level is not correctly detected. Be sure to use the
correct ink cartridge.
oAre you using an old ink cartridge?
The print quality declines when an old ink cartridge is
used. Replace the old ink cartridge with a new one.
We recommend using all the ink in the cartridge
before the expiry date printed on the package
(within a year of installation).
oHave the ink cartridges been shaken?
The ink cartridges for this printer contain pigment
inks. Shake the cartridges thoroughly before
installing them in the printer.
We also recommend that you remove and shake the
installed ink cartridges once every three months to
ensure print quality.
U“Replacing Ink Cartridges” on page 161
oAre the Media Type settings correct?
Print quality is affected if the Media Type you have
selected in the Printer Settings screen (Windows) or
Print screen (Mac OS X) in the printer driver does not
match with the paper that is loaded in the printer. Be
sure to match the media type setting with the paper
that is loaded in the printer.
oDid you select a low quality mode (such as
Speed) as the Print Quality?
If the options selected for Print Quality > Advanced
Settings place priority on speed, quality will be
sacrificed for print speed, potentially causing print
quality to decline. To improve print quality, select
Resolution options that give priority to quality.
oIs color management enabled?
Enable color management.
U“Color Management Printing” on page 109
Epson SureColor T-Series User’s Guide
Problem Solver
176
The color is not exactly the same as
another printer.
The print is not positioned properly
on the media.
Vertical ruled lines are misaligned.
The printed surface is scuffed or
soiled.
oHave you compared the printing result with
the image on the display monitor?
Since monitors and printers produce colors
differently, printed colors will not always match
on-screen colors perfectly.
oDid you open the printer cover while
printing?
If the printer cover is opened while printing, the print
head stops suddenly causing unevenness in the
color. Do not open the printer cover while printing.
oIs Ink Low displayed in the control panel?
The print quality may decline when the ink is low. We
recommend replacing the ink cartridge with a new
one. If there is a difference in color after replacing the
ink cartridge, try performing head cleaning a few
times.
oColors vary depending on the printer type
due to each printer's characteristics.
Because inks, printer drivers, and printer profiles are
developed for each printer model, the colors printed
by different printer models are not exactly the same.
You can achieve similar colors with the same color
adjustment method or the same gamma setting by
using the printer driver.
U“Color Management Printing” on page 109
To match the color precisely, use the color
measurement device to perform color management.
oHave you specified the print area?
Check the print area in the settings of the application
and the printer.
oIs the correct option selected for Paper Size?
If the option selected for Paper Size in the printer
driver does not match the paper loaded in the
printer, the print may not be in the correct position or
some of the data may be printed off the paper. In this
case, check the print settings.
oIs the paper skewed?
If Off is selected for Media Skew Check in the Setup
menu, printing will continue even if the paper is
skewed, resulting in data being printed off the paper.
Select On for Media Skew Check in the Setup menu.
U“Setup menu” on page 139
oDoes the print data fit within the paper
width?
Although under normal circumstances printing stops
if the print image is wider than the paper, the printer
may print outside the bounds of the paper when Off
is selected for Paper Size Check in the Setup menu.
Select On for Paper Size Check in the Setup menu.
U“Setup menu” on page 139
oIs the roll paper margin set to 15 mm or 35
mm?
If the value selected for Roll Paper Margin in the
Setup menu is wider than the margins selected in the
application, priority will be given to the value
selected for Roll Paper Margin. For example, if 15
mm is selected for the left and right margins in the
printer Setup menu and the document fills the page,
the 15 mm at the left and right sides of the page will
not be printed.
U“Printable area” on page 63
oIs the print head misaligned? (in
bidirectional printing)
With bidirectional printing, the print head prints
while moving left and right. If the print head is
misaligned, ruled lines may be misaligned
accordingly. If vertical ruled lines are misaligned with
bidirectional printing, perform Head Alignment.
U“Minimizing Print Misalignments (Head
Alignment)” on page 158
oIs the paper too thick or too thin?
Check that the paper specifications are compatible
with this printer. For information about the media
types and appropriate settings for printing on paper
from other manufacturers or when using RIP
software, see the documentation supplied with the
paper, or contact the dealer of the paper or the
manufacturer of the RIP.
Epson SureColor T-Series User’s Guide
Problem Solver
177
You see damage on the print surface
The paper is creased.
The reverse side of the printed paper
is soiled.
Too much ink is fired.
oIs the paper creased or folded?
Do not use old paper or paper with folds in it. Always
use new paper.
oIs the paper wavy or slack?
Cut sheets become wavy or slack due to changes in
temperature or humidity which may result in the
printer being unable to recognize the paper size
correctly. Flatten the paper before loading it in the
printer, or use new paper.
oIs the print head scuffing the printed
surface?
If the surface of the paper is scuffed, select a Platen
Gap option between Wide and Wider in the Paper
menu.
U“Paper menu” on page 134
oIs the print head scuffing the edge of the
paper?
Select Top35mm/Bottom15mm for the Roll Paper
Margin option in the Setup menu.
U“Setup menu” on page 139
oWiden the bottom margin
Depending on the paper usage, storage conditions,
and the content of the print data, the bottom edge
may be scuffed when printing. In this situation it is
best to create your data with a wider bottom margin.
oDoes the interior of the printer need
cleaning?
The rollers may need cleaning. Clean the rollers by
feeding and ejecting paper.
U“Cleaning the inside” on page 165
oIs there dust in the path of Roll 2?
Open the rear cover, and then wipe away the dust
with a dry, lint-free cloth.
Opening the rear coverU“Roll paper jam” on page
179
oAre you using the printer at normal room
temperature?
Epson special media should be used at normal room
temperature (temperature: 15 to 25°C, humidity: 40
to 60%). For information about paper such as thin
paper from other manufacturers that requires special
handling, see the documentation supplied with the
paper.
oWhen using non-Epson special media, have
you made the paper configuration?
When using non-Epson special media, configure the
paper characteristics (custom paper) before printing.
U“Before printing on non-Epson media” on page
196
oSelect On for Paper Size Check in the menus.
Although printing normally stops if the print image is
wider than the paper, when Off is selected for Paper
Size Check in the Setup menu, the printer may print
outside the bounds of the paper, getting ink on the
inside of the printer in the process. This can be
prevented by selecting On for Paper Size Check in
the Setup menu.
U“Setup menu” on page 139
oIs ink dry on the printed surface?
Depending on the printing density and media type,
the ink may take a while to dry. Do not stack the
paper until the printed surface is dry.
Also, if you set the Drying Time per Page in Paper
Configuration from the printer driver, you can stop
the operation after printing (ejecting and cutting
paper) and wait until the ink is dry. See the printer
driver help for more details on the Paper
Configuration dialog box.
U“Cleaning the inside” on page 165
oAre the Media Type settings correct?
Make sure that the printer driver's Media Type
settings match the paper that you are using. The
amount of ink to be fired is controlled according to
the media type. If the settings do not match the
paper loaded, too much ink may be fired.
Epson SureColor T-Series User’s Guide
Problem Solver
178
Margins appear in borderless
printing.
Feeding or ejecting problems
Unable to feed or eject paper.
oIs the Color Density setting correct?
Lower the density of the ink in the Paper
Configuration dialog box from the printer driver.
The printer may be firing too much ink for some
paper. See the printer driver help for more details on
the Paper Configuration dialog box.
oAre you printing on tracing paper?
If too much ink is used when printing in B&W on
tracing paper, you may get better results by
choosing a lower print density in the Paper
Configuration dialog box or by selecting Tracing
Paper <Low Duty> for Media Type.
oAre the settings for the print data in the
application correct?
Make sure that the paper settings in the application
are correct as well as in the printer driver.
U“Borderless Printing” on page 92
oAre the paper settings correct?
Make sure that the paper settings of the printer
match the paper that you are using.
oHave you changed the amount of
enlargement?
Adjust the amount of enlargement for borderless
printing. Margins may appear if you set the amount
of enlargement to Min.
U“Borderless Printing” on page 92
oIs the paper stored correctly?
The paper may expand or contract if it is not stored
correctly so that margins appear even when
borderless is set. See the documentation supplied
with the paper for more information on the storage
method.
oAre you using paper that supports
borderless printing?
Paper that does not support borderless printing may
expand or contract while printing so that margins
appear even when borderless is set. We recommend
using paper that is designed to support borderless
printing.
oTry adjusting the cutter.
When there are margins on the top and bottom of
the roll paper while performing borderless printing,
try performing Adjust Cut Position. It may reduce
the margins.
U“The Maintenance Menu” on page 138
oIs the paper loaded in the correct position?
See the following for the correct paper loading
positions.
U“Attaching the Roll Paper Adapter” on page 27
U“Loading and Removing Cut Sheets” on page 37
U“Loading and Removing Poster Board” on page
39
If the paper is loaded correctly, check the condition
of the paper that you are using.
oIs the paper loaded in the correct direction?
Load cut sheets vertically. If they are not loaded in
the correct direction, the paper may not be
recognized and an error may occur.
U“Loading and Removing Cut Sheets” on page 37
oIs the paper creased or folded?
Do not use old paper or paper with folds in it. Always
use new paper.
oIs the paper damp?
Do not use paper that is damp. Also, Epson special
media should be left in the bag until you intend to
use it. If it is left out for a long time, the paper curls up
and gets damp so that it does not feed properly.
oIs the paper wavy or slack?
Cut sheets become wavy or slack due to changes in
temperature or humidity which may result in the
printer being unable to recognize the paper size
correctly. Flatten the paper before loading it in the
printer, or use new paper.
Epson SureColor T-Series User’s Guide
Problem Solver
179
Paper does not collect in the paper
basket or is creased or folded when
the paper basket is used.
Roll paper jam
To remove jammed paper, follow the steps below:
1Turn off the printer.
2Turn the printer on.
After a pause, the message Open printer cover
then tear off and remove jammed portion. will
appear in the display.
3Open the printer cover and move the print head
away from the jam.
4Cut the top portion of any torn or crinkled areas
using a commercially available cutter.
5After removing the any torn or crinkled area,
press the Z button and close the printer cover.
6Remove the cut paper.
oIs the paper too thick or too thin?
Check that the paper specifications are compatible
with this printer. For information about the media
types and appropriate settings for printing on paper
from other manufacturers or when using RIP
software, see the documentation supplied with the
paper, or contact the dealer of the paper or the
manufacturer of the RIP.
oAre you using the printer at normal room
temperature?
Epson special media should be used at normal room
temperature (temperature: 15 to 25°C, humidity: 40
to 60%).
oIs paper jammed in the printer?
Open the printer cover of the printer and check that
there are no paper jams or foreign objects in the
printer. If paper is jammed, see "Paper jams" below
and clear the jammed paper.
oIs the paper suction too strong?
If you continue to have problems with ejected paper,
try lowering the Paper Suction (the amount of
suction used to keep the paper on the paper feed
path). U“Paper menu” on page 134
oDoes the print job require a lot of ink, or is
the humidity of the workplace high?
Depending on the job and the work environment,
paper may not collect in the paper basket. Take the
following measures as appropriate.
OPaper does not collect in the paper basket: Use
your hands to lightly press the paper into the
paper basket as it is ejected from the printer.
OThe paper folds after it has been cut
automatically: Select manual cutting and take
the paper in both hands after it is cut.
OThe paper creases and does not collect well in
the paper basket: Resume printing after closing
the paper basket. Before the paper ejected from
the printer touches the floor, take it in both
hands close to the paper eject guides and
continue to lightly support it until printing is
complete.
!Caution:
If you opened the printer cover in operation, do
not touch the area as indicated by the warning
labels.
High temperatures may cause burns.
cImportant:
Other than when you are removing paper
jams, do not touch the print head. If you
touch the print head with your hand, static
electricity may cause a malfunction.
Epson SureColor T-Series User’s Guide
Problem Solver
180
When using T7270/T5270/T3270
When roll paper loaded on Roll 1 is jammed
on the T7270D/T5270D
Remove the jammed paper via the paper feed
slot or the eject slot.
When roll paper loaded on Roll 2 is jammed
on the T7270D/T5270D
7After removing the paper, press the Z button.
Reload the paper and resume printing.
U“Attaching the Roll Paper Adapter” on page
27
(
1
)
Pull out the Roll 2 unit, and then rewind the roll
paper with your hand.
(
2
)
When paper is jammed at the rear side, open the
rear cover, and then remove the jammed paper.
(
3
)
Close the rear cover, and then tighten the three
fixing screws.
cImportant:
Before you reload the roll paper, cut the edge
straight horizontally. Cut any wavy or
creased sections.
If there is a problem at the edge, decreased
print quality and paper jams may occur.
Epson SureColor T-Series User’s Guide
Problem Solver
181
Cut sheets jam
To remove jammed paper, follow the steps below:
1Turn off the printer.
2Turn the printer on.
After a pause, the message Open printer cover
then tear off and remove jammed portion. will
appear in the display.
3Open the printer cover and move the print head
away from the jam.
4Cut the top portion of any torn or crinkled areas
using a commercially available cutter.
5After removing the any torn or crinkled area,
press the Z button and close the printer cover.
6Remove the cut paper.
7After removing the paper, press the Z button.
Reload the paper and resume printing.
U“Loading and Removing Cut Sheets” on
page 37
Others
The control panel display keeps
turning off.
Color ink runs out quickly even when
printing in the Black&White mode or
when printing black data.
The paper is not cut cleanly.
A light is visible inside the printer.
The administrator password has
been lost
!Caution:
If you opened the printer cover in operation, do
not touch the area as indicated by the warning
labels.
High temperatures may cause burns.
cImportant:
Other than when you are removing paper
jams, do not touch the print head. If you
touch the print head with your hand, static
electricity may cause a malfunction.
oIs the printer in sleep mode?
Sleep mode is exited if a print job is received or the P
button on the control panel is pressed. The delay
before the printer enters sleep mode can be selected
in the Setup menu.
U“Setup menu” on page 139
oColor ink is consumed during the head
cleaning process.
If all nozzles are selected when you perform Head
Cleaning or Power Cleaning, inks of all colors will be
used. (This is true even if you are currently printing in
black and white.)
U“Cleaning the print head” on page 157
oReplace the cutter.
If the paper is not cut cleanly, replace the cutter.
U“Replacing the Cutter” on page 163
oThis is not a failure.
The light is a light inside the printer.
oShould you forget the administrator password,
contact your dealer or Epson Support.
Epson SureColor T-Series User’s Guide
Problem Solver
182
Head cleaning starts when the
printer is turned on.
Trouble when the optional
Multifunction Scanner is
connected
The Large Copy/Large Scan tab does
not appear on the control panel
Document width is not recognized
correctly
A document cannot be pulled out / A
document is jammed
Open the cover of the Multifunction Scanner, and then
remove the document.
The following procedure shows how to remove the
document.
1Press the buttons on both sides of the cover to
release the locks.
2When the locks are released, the cover opens
automatically, and you can remove the
document.
Black or white horizontal stripes or
uneven colors appear in
copied/scanned images
oWhen turned on after an extended period of disuse,
the printer may automatically perform head cleaning
to ensure print quality.
Head cleaning will end after about 10 to 15 minutes.
oIs the power switch of Multifunction Scanner
off?
Flip the power switch of Multifunction Scanner to the
minus (-) side to switch on the power, and then turn
the printer off and then on again.
oIs the AC adapter plugged into the electrical
outlet and the Multifunction Scanner?
After reconnecting the cable of the AC adapter, turn
the printer off and then on again.
oIs the connection cable plugged in properly?
Confirm that the connection cable is securely
connected to the ports of the printer and the
Multifunction Scanner. Also, make sure the cable is
not broken.
oThe rollers or glass surface of the
Multifunction Scanner may be soiled.
Turn off the printer and open the scanner cover, and
then clean the rollers and glass surface.
U“Cleaning the Multifunction Scanner (option)” on
page 166
If document width cannot be recognized correctly
after cleaning, open the Copy Settings menu, and
then set the width of the document under Width.
U“Large Copy / Large Scan menu” on page 153
oThe rollers of the Multifunction Scanner may
be soiled.
Turn off the printer and open the scanner cover, and
then clean the rollers.
U“Cleaning the Multifunction Scanner (option)” on
page 166
Epson SureColor T-Series User’s Guide
Problem Solver
183
Scanned image files cannot be
printed
Calibration
If you cleaned the glass surface and rollers inside the
Multifunction Scanner, but horizontal lines are shifted
or there are uneven colors in the copy results or
scanned images, use the following procedure to
calibrate the scanner.
Use the calibration sheet included with the
Multifunction Scanner for calibration.
1Align the loading guide with the calibration
sheet set position.
2Align the right edge with the loading guide so
that calibration sheet is loaded from the black
side.
3Insert the calibration sheet horizontally until its
edge touches the inner roller.
oThe glass that covers the image sensor may
be soiled.
Turn off the printer and open the scanner cover, and
then inspect the top surface of the glass.
If the glass is stained, wipe it.
U“Cleaning the Multifunction Scanner (option)” on
page 166
If the glass surface is very scratched, contact your
dealer or local Epson Support.
oWas scanning performed at a resolution at
which direct print is available?
If a resolution at which direct print is not available
was chosen for a scanned image file, the file cannot
be printed.
Image files that cannot be directly printed can be
printed using the following procedure.
(1) Start CopyCenter, and then download the target
file to the computer.
(2) On the computer to which the file was
downloaded, open the image file in a supporting
application, and then print the file.
Epson SureColor T-Series User’s Guide
Problem Solver
184
The calibration sheet is loaded automatically
until the read start position.
4After the calibration sheet has been loaded,
remove the loading guide.
5At Large copy/Large scan screen, use the d/u
buttons to select Scanner Maintenance and
press the Z button.
6Use the d/u buttons to select Calibration and
press the Z button.
7If the Z button is pressed, calibration starts.
8A message is displayed when calibration is
complete. If you follow the message and press
the Z button, the calibration sheet is ejected.
Feed Adjust (Multifunction Scanner)
If the print results and document length of
copied/scanned files do not match, use the following
procedure to adjust document feeding. Differences in
length may occur due to the paper type used for
printing.
1At Large copy/Large scan screen, use the d/u
buttons to select Scanner Maintenance and
press the Z button.
2Use the d/u buttons to select Feed Adjust and
press the Z button.
3An adjustment setting screen will be displayed.
Press the d/u button to display the target
adjustment value, and then press the Z button.
The following section shows how the
adjustment values are calculated.
Example) Document length: 50 cm, print result:
50.1 cm
50/50.1 x 100-100=-0.1996, rounded at the
second decimal place
Adjustment value: -0.2
4After the adjustment value has been set, press
the W button to exit.
cImportant:
Do not turn off the printer during
calibration. If the printer turned off, the
Multifunction Scanner may malfunction.
Note:
Store the calibration sheet so it does not become soiled
or folded.
Note:
The adjustment result is enabled until the next time the
adjustment value is changed.
Epson SureColor T-Series User’s Guide
Appendix
185
Appendix
Options and Consumable Products
The following options and consumable products are available for use with your printer. (As of January, 2014)
For the latest information, see the Epson Web site.
Ink cartridges
Others
T7270D/T7270/T5270D/T5270/T3270
Explanation
Color
Capacity
700 ml 350 ml 110 ml
Photo Black T694100 T693100 T692100 Epson recommends the use of genuine Epson ink
cartridges. Epson cannot guarantee the quality or
reliability of non-genuine ink. The use of
non-genuine ink may cause damage that is not
covered by Epson’s warranties, and under certain
circumstances, may cause erratic printer
behavior. Information about non-genuine ink
levels may not be displayed,and use of
non-genuine ink is recorded for possible use in
service support. U“Replacing Ink Cartridges” on
page 161
Cyan T694200 T693200 T692200
Magenta T694300 T693300 T692300
Yellow T694400 T693400 T692400
Matte Black T694500 T693500 T692500
Product Part number Explanation
Epson Special Media U“Epson Special Media Table” on page 187
Ink Maintenance Tank T619300 Replacement Ink Maintenance Tank for Ink Maintenance Tank which
is at the end of its service life.
U“Replacing Ink Maintenance Tanks” on page 162
Auto Cutter Spare Blade S902007 See the following section to replace the cutter.
U“Replacing the Cutter” on page 163
Roll Adapter C12C811401 This is the same as the roll adapter supplied with the printer.
Internal Print Server (Hard Disk
Unit)
C12C848031 Use U“Saving to and Reprinting on the Optional Hard Disk Unit” on
page 67
Auto Take-up Reel Unit SCT70TUR Cannot be connected to models other than the T7270.
See the documentation supplied with the auto take-up reel unit for
information on installation.
Use U“Using the Auto Take-up Reel Unit (T7270 Only)” on page 51
Multifunction Module with 36"
mount
SCT36SCAN For use with the T5270 and T5270D printers.
Can scan and copy documents up to 36 × 96 inches (914 × 2,438 mm).
When used with the included hard disk unit or optional Adobe
PostScript 3 Expansion Unit, it can save scanned data, send it by
e-mail, and transfer it to shared folders.
Epson SureColor T-Series User’s Guide
Appendix
186
Multifunction Module with 44"
mount
SCT44SCAN For use with the T7270 and T7270D printers.
Can scan and copy documents up to 36 × 96 inches (914 × 2,438 mm).
When used with the included hard disk unit or optional Adobe
PostScript 3 Expansion Unit, it can save scanned data, send it by
e-mail, and transfer it to shared folders.
Adobe® PostScript® 3™ Expansion
Unit
C12C891131 This unit allows you to use the printer as a PostScript printer.
For information on using the unit, see the documentation supplied
with the Adobe PostScript 3 Expansion Unit.
Product Part number Explanation
Epson SureColor T-Series User’s Guide
Appendix
187
Supported Media
We recommend you use the following Epson special media for high-quality printing results.
Epson Special Media Table
Item descriptions
Size:Describes the size for cut sheet media or the width for roll paper.
Borderless:Describes whether borderless printing is available.
Head Alignment:Describes availability of auto Head Alignment with option of Auto(Bi-D) or Auto(Uni-D).
Take-up:Describes available taking up direction when using optional Auto Take-up Reel Unit:“F” means Forward
and “B” means Backward.
Large copy/Large scan: Describes availability of the Large copy/Large scan function when connecting the optional
Multifunction Scanner.
Roll Paper
Premium Glossy Photo Paper (250)
Premium Semigloss Photo Paper (250)
Note:
For information about the media types and appropriate settings for printing on paper other than Epson special media or
when using raster image processing (RIP) software, see the documentation supplied with the paper, or contact the dealer
of the paper or the manufacturer of the RIP.
Paper thickness: 0.27 mm Roll core size: 3 inches
ICC profile: EPSON SCT3000_5000_7000_Series Premium Glossy Photo Paper 250.icc
Size Borderless Head Alignment
Take-up
Large Copy/Large Scan
F B
406mm/16"
✓✓✓✓ ✓
610mm/24"
914mm/36"*1
1118mm/44"*2
*1 T3270 is not supported
*2 T7270/T7270D only are supported
Paper thickness: 0.27 mm Roll core size: 3 inches
ICC profile: EPSON SCT3000_5000_7000_Series Premium Semigloss Photo Paper 250.icc
Epson SureColor T-Series User’s Guide
Appendix
188
Premium Luster Photo Paper (260)
Premium Semimatte Photo Paper (260)
Size Borderless Head Alignment
Take-up
Large Copy/Large Scan
F B
406mm/16"
✓✓✓✓ ✓
610mm/24"
914mm/36"*1
1118mm/44"*2
*1 T3270 is not supported
*2 T7270/T7270D only are supported
Paper thickness: 0.27 mm Roll core size: 3 inches
ICC profile: EPSON SCT3000_5000_7000_Series Premium Luster Photo Paper 260.icc
Size Borderless Head Alignment
Take-up
Large Copy/Large Scan
F B
254mm/10"
✓✓
--
✓
300mm/11.8"
406mm/16"
✓✓
508mm/20" - -
610mm/24"
✓✓914mm/36"*1
1118mm/44"*2
*1 T3270 is not supported
*2 T7270/T7270D only are supported
Paper thickness: 0.27 mm Roll core size: 3 inches
ICC profile: EPSON SC-T3000_5000_7000_Series Premium Semimatte Photo Paper 260.icc
Size Borderless Head Alignment
Take-up
Large Copy/Large Scan
F B
406mm/16"
✓✓✓✓ ✓
610mm/24"
914mm/36"*1
1118mm/44"*2
Epson SureColor T-Series User’s Guide
Appendix
189
Photo Paper Gloss 250
Premium Glossy Photo Paper (170)
Premium Semigloss Photo Paper (170)
*1 T3270 is not supported
*2 T7270/T7270D only are supported
Paper thickness: 0.25 mm Roll core size: 3 inches
ICC profile: EPSON SCT3000_5000_7000_Series Photo Paper Gloss 250.icc
Size Borderless Head Alignment
Take-up
Large Copy/Large Scan
F B
432mm/17"
✓✓✓✓ ✓
610mm/24"
914mm/36"*1
1118mm/44"*2
*1 T3270 is not supported
*2 T7270/T7270D only are supported
Paper thickness: 0.18 mm Roll core size: 2 inches
ICC profile: EPSON SCT3000_5000_7000_Series Premium Glossy Photo Paper 170.icc
Size Borderless Head Alignment
Take-up
Large Copy/Large Scan
F B
420mm(A2) -
✓✓✓ ✓
610mm/24"
✓914mm/36"*1
1118mm/44"*2
*1 T3270 is not supported
*2 T7270/T7270D only are supported
Paper thickness: 0.18 mm Roll core size: 2 inches
ICC profile: EPSON SCT3000_5000_7000_Series Premium Semigloss Photo Paper 170.icc
Epson SureColor T-Series User’s Guide
Appendix
190
Enhanced Matte Paper
Doubleweight Matte Paper
Size Borderless Head Alignment
Take-up
Large Copy/Large Scan
F B
420mm(A2) -
✓✓✓ ✓
610mm/24"
✓914mm/36"*1
1118mm/44"*2
*1 T3270 is not supported
*2 T7270/T7270D only are supported
Paper thickness: 0.25 mm Roll core size: 3 inches
ICC profile: EPSON SCT3000_5000_7000_Series Enhanced and Archival Matte Paper.icc
Size Borderless Head Alignment
Take-up
Large Copy/Large Scan
F B
432mm/17"
✓*3 ✓✓-✓
610mm/24"
914mm/36"*1
1118mm/44"*2
*1 T3270 is not supported
*2 T7270/T7270D only are supported
*3 Borderless printing available, but borders may appear or print quality decline due to paper expanding or contracting.
Paper thickness: 0.21 mm Roll core size: 2 inches
ICC profile: EPSON SCT3000_5000_7000_Series Doubleweight Matte Paper.icc
Size Borderless Head Alignment
Take-up
Large Copy/Large Scan
F B
610mm/24"
✓✓✓
*3 -✓914mm/36"*1
1118mm/44"*2
*1 T3270 is not supported
*2 T7270/T7270D only are supported
Epson SureColor T-Series User’s Guide
Appendix
191
Singleweight Matte Paper
Enhanced Synthetic Paper
Enhanced Adhesive Synthetic Paper
*3 Use the tensioner supplied with the optional auto take-up reel unit
Paper thickness: 0.15 mm Roll core size: 2 inches
ICC profile: EPSON SCT3000_5000_7000_Series Singleweight Matte Paper.icc
Size Borderless Head Alignment
Take-up
Large Copy/Large Scan
F B
432mm/17"
✓-✓*3 -✓
610mm/24"
914mm/36"*1
1118mm/44"*2
*1 T3270 is not supported
*2 T7270/T7270D only are supported
*3 Use the tensioner supplied with the optional auto take-up reel unit
Paper thickness: 0.13 mm Roll core size: 2 inches
ICC profile: EPSON SCT3000_5000_7000_Series Enhanced Synthetic Paper.icc
Size Borderless Head Alignment
Take-up
Large Copy/Large Scan
F B
610mm/24"
✓*2 -✓✓ ✓
1118mm/44"*1
*1 T7270/T7270D only are supported
*2 Borderless printing available, but borders may appear or print quality decline due to paper expanding or contracting.
Paper thickness: 0.18 mm Roll core size: 2 inches
ICC profile: EPSON SCT3000_5000_7000_Series Enhanced Adhensive Synthetic Paper.icc
Size Borderless Head Alignment
Take-up
Large Copy/Large Scan
F B
610mm/24"
✓*2 -✓✓ -
1118mm/44"*1
Epson SureColor T-Series User’s Guide
Appendix
192
Cut sheet
Borderless printing with cut sheets can only be performed with no left and right margins.
Premium Glossy Photo Paper
Premium Semigloss Photo Paper
Premium Luster Photo Paper
*1 T7270/T7270D only are supported
*2 Borderless printing available, but borders may appear or print quality decline due to paper expanding or contracting.
Thickness: 0.27mm
ICC Profile: EPSON SC-T3000_5000_7000_Series Premium Glossy Photo Paper.icc
Size Borderless Head Alignment Large Copy/Large Scan*3
Super A3/B ✓*1
✓✓A2 -
US-C ✓*1
*1 Borderless printing available, but borders may appear or print quality decline due to paper expanding or contracting.
*2 Load the cut sheet, and then perform a copy operation.
*3 When Multifunction Scanner is connected to the T7270/T5270/T3270 only
When the Multifunction Scanner is connected to the T7270D/T5270D, cut sheets are not supported.
Thickness: 0.27mm
ICC Profile: EPSON SC-T3000_5000_7000_Series Premium Semigloss Photo Paper.icc
Size Borderless Head Alignment Large Copy/Large Scan*3
Super A3/B ✓*1
✓✓A2 -
US-C ✓*1
*1 Borderless printing available, but borders may appear or print quality decline due to paper expanding or contracting.
*2 Load the cut sheet, and then perform a copy operation.
*3 When Multifunction Scanner is connected to the T7270/T5270/T3270 only
When the Multifunction Scanner is connected to the T7270D/T5270D, cut sheets are not supported.
Thickness: 0.27mm
ICC Profile: EPSON SC-T3000_5000_7000_Series Premium Luster Photo Paper.icc
Epson SureColor T-Series User’s Guide
Appendix
193
Archival Matte Paper/Enhanced Matte Paper
Photo Quality Inkjet Paper
Enhanced Matte Posterboard
Size Borderless Head Alignment Large Copy/Large Scan*3
Super B ✓*1
✓✓A2 -
US-C ✓*1
*1 Borderless printing available, but borders may appear or print quality decline due to paper expanding or contracting.
*2 Load the cut sheet, and then perform a copy operation.
*3 When Multifunction Scanner is connected to the T7270/T5270/T3270 only
When the Multifunction Scanner is connected to the T7270D/T5270D, cut sheets are not supported.
Thickness: 0.26mm
ICC Profile: EPSON SC-T3000_5000_7000_Series Enhanced and Archival Matte Paper.icc
Size Borderless Head Alignment Large Copy/Large Scan
Super A3/B ✓*1
✓-A2 -
US-C ✓*1
*1 Borderless printing available, but borders may appear or print quality decline due to paper expanding or contracting.
Thickness: 0.12mm
ICC Profile: EPSON SC-T3000_5000_7000_Series Photo Quality Ink Jet Paper.icc
Size Borderless Head Alignment Large Copy/Large Scan
Super A3/B ✓*1
--A2 -
US-C ✓*1
*1 Borderless printing available, but borders may appear or print quality decline due to paper expanding or contracting.
Thickness: 1.30mm
ICC Profile: EPSON SC-T3000_5000_7000_Series Enhanced Matte Poster Board.icc
Epson SureColor T-Series User’s Guide
Appendix
194
Size Borderless Head Alignment Large Copy/Large Scan
610 × 762 mm (24" × 30")
-- -
762 × 1016 mm (30" × 40") *1
*1 T3270 not supported
Epson SureColor T-Series User’s Guide
Appendix
195
Usable Commercially Available
Paper Size
This printer supports the following paper
specifications for non-Epson media.
Roll Paper
Cut sheet
cImportant:
ODo not use paper that is wrinkled, scuffed,
torn, or dirty.
OAlthough plain paper and recycled paper
manufactured by other companies can be
loaded and fed in the printer as long as they
meet the following specifications, Epson
cannot guarantee the print quality.
OAlthough other paper types manufactured by
other companies can be loaded in the printer
as long as they meet the following
specifications, Epson cannot guarantee the
paper feeding and print quality.
Paper Type Plain paper and recycled paper
Roll core size 2 inch and 3 inch
Roll paper
outer diameter
150 mm or less
Width T7270/T7270D
254 mm (10 inches) to 1,118 mm (44
inches)
T5270/T5270D
254 mm (10 inches) to 914mm (36
inches)
T3270
254 mm (10 inches) to 610mm (24
inches)
Thickness 0.08 to 0.5 mm
Available
width for
borderless
printing
254mm/10inch
300mm/11.8inch
Super A3/B/329 mm
406mm/16inch
17 inch
B2/515 mm
A1/594mm
610mm/24inch
728 mm
A0/841 mm
914mm/36inch
1030 mm
1118mm/44inch
Paper Type Plain paper and recycled paper
Width T7270/T7270D
210 mm (A4) to 1,118 mm (44 inches)
T5270/T5270D
210 mm (A4) to 914 mm (36 inches)
T3270
210 mm (A4) to 610 mm (24 inches)
Length 279.4 to 1,580 mm
Thickness 0.08 to 0.8 mm
(Poster Board: 0.8 to 1.5 mm)
Available
width for
borderless
printing
254 mm/10 inch
300 mm/11.8 inch
Super A3/B/329 mm
406 mm/16 inch
17 inch
B2/515 mm
A1/594mm
610mm/24inch
728 mm
A0/841 mm
914mm/36inch
1030 mm
1118mm/44inch
Epson SureColor T-Series User’s Guide
Appendix
196
Before printing on non-Epson
media
When using non-Epson media (Custom Paper), make
the paper configuration according to the paper
characteristics before printing. Settings are adjusted as
follows.
OSelect Custom Paper Setting in the printer Paper
menu.
U“Paper menu” on page 134
OSave custom paper settings to the printer using
EPSON LFP Remote Panel 2.
OSave custom paper settings created in the printer
driver to the computer (Windows).
Save settings using the Custom Settings option in
the Advanced tab.
U“Adding Media Types” on page 117
When the custom media types are selected both
with the printer and in the printer driver Media
Type menu, priority is given to printer driver
settings.
OAdjusting Settings in the Printer Driver (Mac OS
X)
From the Advanced screen, open Paper
Configuration dialog and adjust settings as desired.
See the printer driver help for more details.
Detailed adjustments can be made to user media
settings using the Custom Paper Setting option in
the printer Paper menu.
Note:
OBe sure to check the paper characteristics such as
paper tension, ink fixating, or paper thickness
before setting the custom paper. For the paper's
characteristics, check the paper's documentation or
with your local dealer.
OTest the print quality with this printer before
purchasing a large amount of paper.
OIf colors in printed images on the custom paper are
uneven, use unidirectional printing. For
unidirectional printing, select Printer Settings >
Print Quality (Windows) or Mode (Mac OS X) >
Advanced Settings and clear the High Speed check
box.
OIf you are using the T7270D/T5270D and printing
with both Roll 1 and Roll 2, configure them
individually by setting the print settings using the
Custom Paper Setting, even when the paper is the
same. If the Custom Paper Setting set by the
conditions set in Roll 1 is applied to the same type of
paper loaded in Roll 2, but the paper path, paper
width, or other print conditions are different,
printing will not be performed correctly.
Epson SureColor T-Series User’s Guide
Appendix
197
Notes When Moving or
Transporting the Printer
This section describes precaution when moving and
transporting the product.
Notes When Moving the Printer
This section assumes that the product is being moved
to another location on the same floor without
traversing stairs, ramps, or lifts. See the following
section for information on moving the printer between
floors or to another building.
U“Notes on Transporting” on page 198
Getting Ready
1Confirm that the printer is off.
2Disconnect the power cords and all other cables.
3Close the paper basket.
When the optional auto take-up reel unit is
installed, remove any paper from it.
4When the optional Multifunction stand is
attached, pull up and fix the fall prevention
fixture of the stand.
5Unlock the stand.
Release the locks of the casters on the left and
right legs.
!Caution:
Do not tilt the product more than 10 degrees
forward or back while moving it. Failure to
observe this precaution could result in the printer
falling over, causing accidents.
cImportant:
Do not remove the ink cartridges. Failure to
observe this precaution could cause the print head
nozzles to dry out.
cImportant:
If the printer is moved with the fall
prevention fixture lowered, the floor may be
scratched.
Epson SureColor T-Series User’s Guide
Appendix
198
6Move the printer.
Notes on Transporting
Make the following preparations in advance before
transporting the printer.
OTurn off the printer and remove all cables.
ORemove any paper.
ORemove any optional components if they are
installed.
To remove the optional components, see the Setup
guide included with each of them, and then reverse
the attachment procedure.
Furthermore, repack it using the original box and
packing materials to protect it from shock and
vibration.
cImportant:
Use the casters on the dedicated printer
stand only to move the printer indoors a
short distance over a level floor. They can
not be used for transport.
cImportant:
When removing the Multifunction Scanner and
stand, first attach the metal fittings and
scratch-prevention sheet shown in the following
illustration to the stand. After attaching the metal
fittings, remove the Multifunction Scanner from
the stand. If the order is incorrect, the stand will
be damaged.
Epson SureColor T-Series User’s Guide
Appendix
199
When you move the printer while packaging it, place
your hands at the positions in the illustration, and then
lift.
T7270/T7270D/T5270/T5270D
T3270
Notes when reusing the printer
After moving or transporting, check if the print head is
clogged before use.
U“Checking for clogged nozzles” on page 156
!Caution:
OThe printer is heavy. When you pack or move
the printer, use two or more people for the
T3270 and four or more people for the
T7270/T7270D/T5270/T5270D when
carrying it.
OWhen you lift the printer, maintain a natural
posture.
OWhen you lift the printer, place your hands at
the locations indicated in the following
illustration.
If you lift the printer while holding other
sections, you may be injured. For example,
you may drop the printer or your fingers may
be pinched when lowering the printer.
BA
C
A D
B C
D
cImportant:
OOnly hold the required area; otherwise, the
printer may be damaged. Failure to observe
this precaution could damage the printer.
OMove and transport the printer with ink
cartridges installed. Do not remove the ink
cartridges; otherwise, the nozzles may be
clogged and make it impossible to print, or
ink may leak.
A
B
A
B
Epson SureColor T-Series User’s Guide
Appendix
200
System Requirements
System Requirements of the
Printer Driver
The following chart shows the system requirements to
install and use the printer driver included with this
printer.
For information on supported operating systems, see
the Epson website.
Windows
* Use a shielded twisted-pair cable (Category 5 or higher).
Mac OS X
System Requirements for
CopyCenter
The following chart shows the system requirements to
use CopyCenter.
For information on supported operating systems, see
the Epson website.
Tablet terminal
Windows
Mac OS X
Operating system Windows XP/Windows XP x64
Windows Vista/Windows Vista x64
Windows 7/Windows 7 x64
Windows 8/Windows 8 x64
Windows 8.1/Windows 8.1 x64
Windows Server 2003/Windows
Server 2003 x64/Windows Server
2008/Windows Server 2008
x64/Windows Server 2008
R2/Windows Server 2012
CPU Core 2 Duo 3.05 GHz or better
Memory 1 GB or more available memory
Available hard disk
space
32 GB or more
Interface Hi-Speed USB-Compatible with the
USB 2.0 Specification.
Ethernet 10BASE-T,
100BASE-TX/1000BASE-T*
Display resolution SVGA (800 x 600) or higher
resolution
Note:
When installing, you must log in as a user with an
computer administrator account (a user belonging to
the Administrators group).
Operating system Mac OS X 10.5.8 or later
CPU Core 2 Duo 3.05 GHz or better
Memory 1 GB or more available memory
Available hard disk
space
32 GB or more
Display resolution WXGA (1280 x 800) or higher
resolution
Interface Hi-Speed USB-Compatible with the
USB 2.0 Specification.
Ethernet 10BASE-T,
100BASE-TX/1000BASE-T*
* Use a shielded twisted-pair cable
(Category 5 or higher).
Operating system iOS 4.3 or later
Android
Operating system Windows XP/Windows XP x64
Windows Vista/Windows Vista x64
Windows 7/Windows 7 x64
Windows 8/Windows 8 x64
Windows 8.1/Windows 8.1 x64
Windows Server 2003/Windows
Server 2003 x64/Windows Server
2008/Windows Server 2008
x64/Windows Server 2008
R2/Windows Server 2012
Recommended
browser
Google Chrome/Safari
Display resolution 1024 x 768 or higher
Operating system Mac OS X 10.5.8 or later
Recommended
browser
Safari
Display resolution 1024 x 768 or higher
Epson SureColor T-Series User’s Guide
Appendix
201
Specifications Table
Printer Specifications
Printing method On-demand ink jet
Nozzle
configuration
Black: 360 nozzles x 2 rows x 2
colors (Photo Black and Matte
Black)
Color: 360 nozzles x 2 rows x colors
(Yellow, Magenta, and Cyan)
Resolution
(maximum)
2880×1440 dpi
Control code ESC/P raster (undisclosed
command)
HP-GL/2, HP RTL*1
Media feed
method
Friction feed
Built-in memory 1GB for Main
Network Functions IPv4, IPv6, WSD, IPsec/access
control, SSL communication,
IEEE802.1X
Rated voltage AC 100 to 240 V
Rated frequency 50 to 60 Hz
Rated current 1.0 to 0.5 A
Power consumption
In use T7270: Approximately 64 W
T5270: Approximately 60 W
T3270: Approximately 52 W
T7270D: Approximately 65 W
T5270D: Approximately 61 W
Ready mode T7270/T5270/T3270:
Approximately 16 W
T7270D/T5270D: Approximately 17
W
Sleep mode 3.0 W or less
Power off 0.5 W or less
Temperature Operating: 50 to 95 °F (10 to 35 °C)
Storage (before unpacking):
-4 to 140 °F (-20 to 60 °C) (within
120 hours at 140 °F (60 °C), within a
month at 104 °F (40 °C)
Storage (after unpacking):
-4 to 104 °F (-20 to 40 °C) (within a
month at 104 °F (40 °C))
Humidity Operating: 20 to 80% (without
condensation)
Storage (before unpacking): 5 to
85% (without condensation)
Storage (after unpacking): 5 to 85%
(without condensation)
Operation temperature/humidity (when the hard disk unit
or Adobe PostScript 3 Expansion Unit has not been
connected)
Operation temperature/humidity (when the hard disk unit
or Adobe PostScript 3 Expansion Unit has been
connected)
Printer Specifications
Epson SureColor T-Series User’s Guide
Appendix
202
*1 For information on HP-GL/2 and HP RTL, see the Epson
website.
*2 Paper basket/Large-capacity paper basket closed.
*3 Excluding ink cartridges.
Dimension
(W x D x H)
T7270:
63.3 x 30*2 x 44.4 inches
1608 x 762*2 x 1128 mm
T5270:
55.3 x 30*2 x 44.4 inches
1405 x 762*2 x 1128 mm
T3270:
41.3 x 30*2 x 44 inches
1050 x 762*2 x 1117 mm
T7270D:
63.3 x 28.9*2 x 44.4 inches
1608 x 734*2 x 1128 mm
T5270D:
55.3 x 28.9*2 x 44.4 inches
1405 x 734*2 x 1128 mm
Weight*3 T7270: Approximately 92 kg
T5270: Approximately 84 kg
T3270: Approximately 67 kg
T7270D: Approximately 133 kg
T5270D: Approximately 118 kg
Ink Specifications
Type Special ink cartridges
Pigment ink Black: Photo Black, Matte Black
Color: Yellow, Magenta, Cyan
Use by date See the date printed on the
package (at normal temperature)
Print quality
guarantee expiry
1 year (when installed in printer)
Printer Specifications
Storage
temperature
Uninstalled:
-4 to 104 °F (-20 to 40 °C) (within 4
days at -4 °F (-20 °C), within a
month at 104 °F (40 °C))
Installed in printer:
-4 to 104 °F (-20 to 40 °C) (within 4
days at -4 °F (-20 °C), within a
month at 104 °F (40 °C))
Transporting:
-4 to 140 °F (-20 to 60 °C) (within 4
days at -4 °F, within a month at 104
°F (40 °C), within 72 hours at 140 °F
(60 °C),
Cartridge
dimensions
(W x D x H)
700 ml:
1.6 x 12 x 4.3 inches
40 x 305 x 110 mm
350 ml:
1.6 x 12 x 4.3 inches
40 x 200 x 110 mm
110 ml:
1 x 12 x 4.3 inches
25 x 200 x 110 mm
cImportant:
OWe recommend that you remove and shake
the installed ink cartridges thoroughly once
every three months to ensure print quality.
OThe ink freezes if left at below -4 °F (-20°C)
for a long time. If it does freeze, leave it at
room temperature 77 °F (25°C) for at least
four hours (without condensation).
ODo not refill the ink.
Ink Specifications
Epson SureColor T-Series User’s Guide
Appendix
203
* The actual width becomes smaller by the size of the “Image
margin width”.
Standards and Approvals
T7270D/T5270D
T7270/T5270/T3270
Multifunction Scanner specifications
Read width 6 to 36 inches (153 to 914.4 mm)*
Image margin
width (copying/
scanning)
3 mm for up, bottom, left, and right
Document
Size (width) 6 to 38 inches (153 to 965.2 mm)
Size (length) 6 to 96 inches (153 to 2438.4 mm)
Thickness 0.002 to .05 inches (0.05 to 1.3 mm)
Eject direction Forward/backward (switchable)
Optical resolution 600 dpi
Scanning method Contact image sensor
Secondary
scanning method
Document movement (sheet
pass-through) method
Scan resolution 200, 300, 360, 400, 600 dpi
Scan file format JPEG, PDF
Copy resolution
Reading 300 dpi
Writing 360 dpi
Copy scaling 25 to 400%
Number of
continuous copies
1 to 99 sheets
Sensor CIS
Light source Dual LED (RGB)
Rated voltage 100-240 V
Rated frequency 50 to 60
Rated current 2.5 A
Power consumption
In use Approximately 50 W
Ready mode Approximately 25 W
Sleep
mode/power off
0.5 W or less
Safety UL 60950-1
CSA C22.2 No.60950-1
Low Voltage
Directive
2006/95/EC
EN 60950-1
EMC FCC part 15 subpart B Class A
CAN/CSA-CEI/IEC CISPR 22 Class A
AS/NZS CISPR 22 Class A
EMC Directive
2004/108/EC
EN 55022 Class A
EN 55024
EN 61000-3-2
EN 61000-3-3
!Warning:
This is a class A product. In a domestic
environment this product may cause radio
interference in which case the user may be
required to take adequate measures.
Safety UL 60950-1
CAN/CSA C22.2 No.60950-1
Low Voltage
Directive
2006/95/EC
EN 60950-1
EMC FCC part 15 subpart B Class B
CAN/CSA-CEI/IEC CISPR 22 Class B
AS/NZS CISPR 22 Class B
EMC Directive
2004/108/EC
EN 55022 Class B
EN 55024
EN 61000-3-2
EN 61000-3-3
Epson SureColor T-Series User’s Guide
Where To Get Help
204
Where To Get Help
New :See comments to select sections you need. Th e word "other" indicates products except fo r inkjet, SPC, Page, and SIDM.
Technical Support Web
Site
New :Only inkjet, SPC, and Scanner products are used in this section.
Epson’s Technical Support Web Site provides help
with problems that cannot be solved using the
troubleshooting information in your product
documentation. If you have a Web browser and can
connect to the Internet, access the site at:
http://support.epson.net/
If you need the latest drivers, FAQs, manuals, or other
downloadables, access the site at:
http://www.epson.com
Then, select the support section of your local Epson
Web site.
Contacting Epson
Support
New :For All products
Before Contacting Epson
If your Epson product is not operating properly and
you cannot solve the problem using the
troubleshooting information in your product
documentation, contact Epson support services for
assistance. If Epson support for your area is not listed
below, contact the dealer where you purchased your
product.
Epson support will be able to help you much more
quickly if you give them the following information:
OProduct serial number
(The serial number label is usually on the back of
the product.)
OProduct model
OProduct software version
(Click About, Version Info, or similar button in
the product software.)
OBrand and model of your computer
OYour computer operating system name and
version
ONames and versions of the software applications
you normally use with your product
Epson SureColor T-Series User’s Guide
Where To Get Help
205
Help for Users in North America
New :Use Inkjet, SPC, and "other" products Only.(general)
Epson provides the technical support services listed
below.
Internet Support
Visit Epson’s support website at
http://epson.com/support and select your product for
solutions to common problems. You can download
drivers and documentation, get FAQs and
troubleshooting advice, or e-mail Epson with your
questions.
Speak to a Support Representative
Dial: (562) 276-1300 (U.S.), or (905) 709-9475
(Canada), 6 am to 6 pm, Pacific Time, Monday
through Friday. Days and hours of support are subject
to change without notice. Toll or long distance charges
may apply.
Before you call Epson for support, please have the
following information ready:
OProduct name
OProduct serial number
OProof of purchase (such as a store receipt) and date
of purchase
OComputer configuration
ODescription of the problem
Note:
For help using any other software on your system, see the
documentation for that software for technical support
information.
Purchase Supplies and Accessories
You can purchase genuine Epson ink cartridges,
ribbon cartridges, paper, and accessories from an
Epson authorized reseller. To find the nearest reseller,
call 800-GO-EPSON (800-463-7766). Or you can
purchase online at http://www.epsonstore.com (U.S.
sales) or http://www.epson.ca (Canadian sales).
Epson SureColor T-Series User’s Guide
Software License Terms
206
Software License
Terms
OPEN SOURCE
SOFTWARE LICENSE
1) This printer product includes open source software
programs listed in Section 5) according to the license
terms of each open source software program.
2) We provide the source code of the GPL Programs,
LGPL Programs, Apache License Program and ncftp
license Program (each is defined in Section 5) until five
(5) years after the discontinuation of same model of
this printer product. If you desire to receive the source
code above, please see the “Contacting Epson Support”
in the User’s Guide, and contact the customer support
of your region. You shall comply with the license terms
of each open source software program.
3) The open source software programs are WITHOUT
ANY WARRANTY; without even the implied
warranty of MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE. See the license
agreements of each open source software program for
more details, which are described on
\Manual\Data\oss.pdf in the Printer Software Disc.
4) The license terms of each open source software
program are described on \Manual\Data\oss.pdf in the
Printer Software Disc.
5) The list of open source software programs which this
printer product includes are as follows.
GNU GPL
This printer product includes the open source
software programs which apply the GNU
General Public License Version 2 or later
version (“GPL Programs”).
The list of GPL Programs:
linux-2.6.35-arm1-epson12
busybox-1.17.4
ethtool-2.6.35
e2fsprogs-1.41.14
scrub-2.4
smartmontools-5.40
WPA Supplicant 0.7.3
GNU Lesser GPL
This printer product includes the open source
software programs which apply the GNU Lesser
General Public License Version 2 or later
version (“Lesser GPL Programs”).
The list of LGPL Programs:
uclibc-0.9.32
libusb-1.0.8
libiConv-1.14
Apache License
This printer product includes the open source
software program “Bonjour” which apply the
Apache License Version2.0 (“Apache License
Program”).
Bonjour License
This printer product includes the open source
software program “Bonjour” which applies the
terms and conditions provided by owner of the
copyright to the “Bonjour”.
Net-SNMP license
This printer product includes the open source
software program “Net-SNMP” which applies
the terms and conditions provided by owner of
the copyright to the “Net-SNMP”.
BSD License (Berkeley Software Distribution License)
This printer product includes the open source
software program which apply the Berkeley
Software Distribution License (“BSD
Program”).
Epson SureColor T-Series User’s Guide
Software License Terms
207
The list of BSD Licence Programs:
busybox-1.17.4
WPA Supplicant 0.7.3
Sun RPC License
This printer product includes the open source
software program “busybox-1.17.4” which apply
the Sun RPC License (“Sun RPC Program”).
ncftp license
This printer product includes the open source
software program “ncftp-3.2.4” which applies
the terms and conditions provided by owner of
the copyright to the “ncftp”.
e2fsprogs license
This printer product includes the open source
software program “e2fsprogs-1.41.14” which
applies the terms and conditions provided by
owner of the copyright to the “e2fsprogs”.
MIT license
This printer product includes the open source
software program “jQuery v1.8.2” which apply
the MIT License.
Bonjour
This printer product includes the open source software
programs which apply the Apple Public Source License
Version1.2 or its latest version ("Bonjour Programs").
We provide the source code of the Bonjour Programs
pursuant to the Apple Public Source License
Version1.2 or its latest version until five (5) years after
the discontinuation of same model of this printer
product. If you desire to receive the source code of the
Bonjour Programs, please see the "Contacting
Customer Support" in Appendix or Printing Guide of
this User's Guide, and contact the customer support of
your region.
You can redistribute Bonjour Programs and/or modify
it under the terms of the Apple Public Source License
Version1.2 or its latest version.
These Bonjour Programs are WITHOUT ANY
WARRANTY; without even the implied warranty of
MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE.
The Apple Public Source License Version1.2 is as
follows. You also can see the Apple Public Source
License Version1.2 at
http://www.opensource.apple.com/apsl/.
APPLE PUBLIC SOURCE LICENSE
Version 2.0 - August 6, 2003
1. General; Definitions. This License applies to any
program or other work which Apple Computer, Inc.
("Apple") makes publicly available and which contains
a notice placed by Apple identifying such program or
work as "Original Code" and stating that it is subject to
the terms of this Apple Public Source License version
2.0 ("License"). As used in this License:
1.1 "Applicable Patent Rights" mean: (a) in the case
where Apple is the grantor of rights, (i) claims of
patents that are now or hereafter acquired, owned by or
assigned to Apple and (ii) that cover subject matter
contained in the Original Code, but only to the extent
necessary to use, reproduce and/or distribute the
Original Code without infringement; and (b) in the
case where You are the grantor of rights, (i) claims of
patents that are now or hereafter acquired, owned by or
assigned to You and (ii) that cover subject matter in
Your Modifications, taken alone or in combination
with Original Code.
1.2 "Contributor" means any person or entity that
creates or contributes to the creation of Modifications.
1.3 "Covered Code" means the Original Code,
Modifications, the combination of Original Code and
any Modifications, and/or any respective portions
thereof.
Epson SureColor T-Series User’s Guide
Software License Terms
208
1.4 "Externally Deploy" means: (a) to sublicense,
distribute or otherwise make Covered Code available,
directly or indirectly, to anyone other than You; and/or
(b) to use Covered Code, alone or as part of a Larger
Work, in any way to provide a service, including but
not limited to delivery of content, through electronic
communication with a client other than You.
1.5 "Larger Work" means a work which combines
Covered Code or portions thereof with code not
governed by the terms of this License.
1.6 "Modifications" mean any addition to, deletion
from, and/or change to, the substance and/or structure
of the Original Code, any previous Modifications, the
combination of Original Code and any previous
Modifications, and/or any respective portions thereof.
When code is released as a series of files, a Modification
is: (a) any addition to or deletion from the contents of
a file containing Covered Code; and/or (b) any new file
or other representation of computer program
statements that contains any part of Covered Code.
1.7 "Original Code" means (a) the Source Code of a
program or other work as originally made available by
Apple under this License, including the Source Code of
any updates or upgrades to such programs or works
made available by Apple under this License, and that
has been expressly identified by Apple as such in the
header file(s) of such work; and (b) the object code
compiled from such Source Code and originally made
available by Apple under this License
1.8 "Source Code" means the human readable form of a
program or other work that is suitable for making
modifications to it, including all modules it contains,
plus any associated interface definition files, scripts
used to control compilation and installation of an
executable (object code).
1.9 "You" or "Your" means an individual or a legal
entity exercising rights under this License. For legal
entities, "You" or "Your" includes any entity which
controls, is controlled by, or is under common control
with, You, where "control" means (a) the power, direct
or indirect, to cause the direction or management of
such entity, whether by contract or otherwise, or (b)
ownership of fifty percent (50%) or more of the
outstanding shares or beneficial ownership of such
entity.
2. Permitted Uses; Conditions & Restrictions. Subject
to the terms and conditions of this License, Apple
hereby grants You, effective on the date You accept this
License and download the Original Code, a
world-wide, royalty-free, non-exclusive license, to the
extent of Apple's Applicable Patent Rights and
copyrights covering the Original Code, to do the
following:
2.1 Unmodified Code. You may use, reproduce,
display, perform, internally distribute within Your
organization, and Externally Deploy verbatim,
unmodified copies of the Original Code, for
commercial or non-commercial purposes, provided
that in each instance:
(a) You must retain and reproduce in all copies of
Original Code the copyright and other proprietary
notices and disclaimers of Apple as they appear in the
Original Code, and keep intact all notices in the
Original Code that refer to this License; and
(b) You must include a copy of this License with every
copy of Source Code of Covered Code and
documentation You distribute or Externally Deploy,
and You may not offer or impose any terms on such
Source Code that alter or restrict this License or the
recipients' rights hereunder, except as permitted under
Section 6.
2.2 Modified Code. You may modify Covered Code
and use, reproduce, display, perform, internally
distribute within Your organization, and Externally
Deploy Your Modifications and Covered Code, for
commercial or non-commercial purposes, provided
that in each instance You also meet all of these
conditions:
(a) You must satisfy all the conditions of Section 2.1
with respect to the Source Code of the Covered Code;
(b) You must duplicate, to the extent it does not
already exist, the notice in Exhibit A in each file of the
Source Code of all Your Modifications, and cause the
modified files to carry prominent notices stating that
You changed the files and the date of any change; and
Epson SureColor T-Series User’s Guide
Software License Terms
209
(c) If You Externally Deploy Your Modifications, You
must make Source Code of all Your Externally
Deployed Modifications either available to those to
whom You have Externally Deployed Your
Modifications, or publicly available. Source Code of
Your Externally Deployed Modifications must be
released under the terms set forth in this License,
including the license grants set forth in Section 3
below, for as long as you Externally Deploy the
Covered Code or twelve (12) months from the date of
initial External Deployment, whichever is longer. You
should preferably distribute the Source Code of Your
Externally Deployed Modifications electronically (e.g.
download from a web site).
2.3 Distribution of Executable Versions. In addition, if
You Externally Deploy Covered Code (Original Code
and/or Modifications) in object code, executable form
only, You must include a prominent notice, in the code
itself as well as in related documentation, stating that
Source Code of the Covered Code is available under the
terms of this License with information on how and
where to obtain such Source Code.
2.4 Third Party Rights. You expressly acknowledge and
agree that although Apple and each Contributor grants
the licenses to their respective portions of the Covered
Code set forth herein, no assurances are provided by
Apple or any Contributor that the Covered Code does
not infringe the patent or other intellectual property
rights of any other entity. Apple and each Contributor
disclaim any liability to You for claims brought by any
other entity based on infringement of intellectual
property rights or otherwise. As a condition to
exercising the rights and licenses granted hereunder,
You hereby assume sole responsibility to secure any
other intellectual property rights needed, if any. For
example, if a third party patent license is required to
allow You to distribute the Covered Code, it is Your
responsibility to acquire that license before
distributing the Covered Code.
3. Your Grants. In consideration of, and as a condition
to, the licenses granted to You under this License, You
hereby grant to any person or entity receiving or
distributing Covered Code under this License a
non-exclusive, royalty-free, perpetual, irrevocable
license, under Your Applicable Patent Rights and other
intellectual property rights (other than patent) owned
or controlled by You, to use, reproduce, display,
perform, modify, sublicense, distribute and Externally
Deploy Your Modifications of the same scope and
extent as Apple's licenses under Sections 2.1 and 2.2
above.
4. Larger Works. You may create a Larger Work by
combining Covered Code with other code not
governed by the terms of this License and distribute the
Larger Work as a single product. In each such instance,
You must make sure the requirements of this License
are fulfilled for the Covered Code or any portion
thereof.
5. Limitations on Patent License. Except as expressly
stated in Section 2, no other patent rights, express or
implied, are granted by Apple herein. Modifications
and/or Larger Works may require additional patent
licenses from Apple which Apple may grant in its sole
discretion.
6. Additional Terms. You may choose to offer, and to
charge a fee for, warranty, support, indemnity or
liability obligations and/or other rights consistent with
the scope of the license granted herein ("Additional
Terms") to one or more recipients of Covered Code.
However, You may do so only on Your own behalf and
as Your sole responsibility, and not on behalf of Apple
or any Contributor. You must obtain the recipient's
agreement that any such Additional Terms are offered
by You alone, and You hereby agree to indemnify,
defend and hold Apple and every Contributor
harmless for any liability incurred by or claims asserted
against Apple or such Contributor by reason of any
such Additional Terms.
Epson SureColor T-Series User’s Guide
Software License Terms
210
7. Versions of the License. Apple may publish revised
and/or new versions of this License from time to time.
Each version will be given a distinguishing version
number. Once Original Code has been published
under a particular version of this License, You may
continue to use it under the terms of that version. You
may also choose to use such Original Code under the
terms of any subsequent version of this License
published by Apple. No one other than Apple has the
right to modify the terms applicable to Covered Code
created under this License.
8. NO WARRANTY OR SUPPORT. The Covered
Code may contain in whole or in part pre-release,
untested, or not fully tested works. The Covered Code
may contain errors that could cause failures or loss of
data, and may be incomplete or contain inaccuracies.
You expressly acknowledge and agree that use of the
Covered Code, or any portion thereof, is at Your sole
and entire risk. THE COVERED CODE IS
PROVIDED "AS IS" AND WITHOUT WARRANTY,
UPGRADES OR SUPPORT OF ANY KIND AND
APPLE AND APPLE'S LICENSOR(S)
(COLLECTIVELY REFERRED TO AS "APPLE" FOR
THE PURPOSES OF SECTIONS 8 AND 9) AND ALL
CONTRIBUTORS EXPRESSLY DISCLAIM ALL
WARRANTIES AND/OR CONDITIONS, EXPRESS
OR IMPLIED, INCLUDING, BUT NOT LIMITED
TO, THE IMPLIED WARRANTIES AND/OR
CONDITIONS OF MERCHANTABILITY, OF
SATISFACTORY QUALITY, OF FITNESS FOR A
PARTICULAR PURPOSE, OF ACCURACY, OF
QUIET ENJOYMENT, AND NONINFRINGEMENT
OF THIRD PARTY RIGHTS. APPLE AND EACH
CONTRIBUTOR DOES NOT WARRANT AGAINST
INTERFERENCE WITH YOUR ENJOYMENT OF
THE COVERED CODE, THAT THE FUNCTIONS
CONTAINED IN THE COVERED CODE WILL
MEET YOUR REQUIREMENTS, THAT THE
OPERATION OF THE COVERED CODE WILL BE
UNINTERRUPTED OR ERROR-FREE, OR THAT
DEFECTS IN THE COVERED CODE WILL BE
CORRECTED. NO ORAL OR WRITTEN
INFORMATION OR ADVICE GIVEN BY APPLE,
AN APPLE AUTHORIZED REPRESENTATIVE OR
ANY CONTRIBUTOR SHALL CREATE A
WARRANTY. You acknowledge that the Covered
Code is not intended for use in the operation of nuclear
facilities, aircraft navigation, communication systems,
or air traffic control machines in which case the failure
of the Covered Code could lead to death, personal
injury, or severe physical or environmental damage.
9. LIMITATION OF LIABILITY. TO THE EXTENT
NOT PROHIBITED BY LAW, IN NO EVENT SHALL
APPLE OR ANY CONTRIBUTOR BE LIABLE FOR
ANY INCIDENTAL, SPECIAL, INDIRECT OR
CONSEQUENTIAL DAMAGES ARISING OUT OF
OR RELATING TO THIS LICENSE OR YOUR USE
OR INABILITY TO USE THE COVERED CODE, OR
ANY PORTION THEREOF, WHETHER UNDER A
THEORY OF CONTRACT, WARRANTY, TORT
(INCLUDING NEGLIGENCE), PRODUCTS
LIABILITY OR OTHERWISE, EVEN IF APPLE OR
SUCH CONTRIBUTOR HAS BEEN ADVISED OF
THE POSSIBILITY OF SUCH DAMAGES AND
NOTWITHSTANDING THE FAILURE OF
ESSENTIAL PURPOSE OF ANY REMEDY. SOME
JURISDICTIONS DO NOT ALLOW THE
LIMITATION OF LIABILITY OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THIS
LIMITATION MAY NOT APPLY TO YOU. In no
event shall Apple's total liability to You for all damages
(other than as may be required by applicable law)
under this License exceed the amount of fifty dollars
($50.00).
10. Trademarks. This License does not grant any rights
to use the trademarks or trade names "Apple", "Apple
Computer", "Mac", "Mac OS", "QuickTime",
"QuickTime Streaming Server" or any other
trademarks, service marks, logos or trade names
belonging to Apple (collectively "Apple Marks") or to
any trademark, service mark, logo or trade name
belonging to any Contributor. You agree not to use any
Apple Marks in or as part of the name of products
derived from the Original Code or to endorse or
promote products derived from the Original Code
other than as expressly permitted by and in strict
compliance at all times with Apple's third party
trademark usage guidelines which are posted at
http://www.apple.com/legal/guidelinesfor3rdparties.h
tml.
11. Ownership. Subject to the licenses granted under
this License, each Contributor retains all rights, title
and interest in and to any Modifications made by such
Contributor. Apple retains all rights, title and interest
in and to the Original Code and any Modifications
made by or on behalf of Apple ("Apple Modifications"),
and such Apple Modifications will not be
automatically subject to this License. Apple may, at its
sole discretion, choose to license such Apple
Modifications under this License, or on different terms
from those contained in this License or may choose not
to license them at all.
Epson SureColor T-Series User’s Guide
Software License Terms
211
12. Termination.
12.1 Termination. This License and the rights granted
hereunder will terminate:
(a) automatically without notice from Apple if You fail
to comply with any term(s) of this License and fail to
cure such breach within 30 days of becoming aware of
such breach;
(b) immediately in the event of the circumstances
described in Section 13.5(b); or
(c) automatically without notice from Apple if You, at
any time during the term of this License, commence an
action for patent infringement against Apple; provided
that Apple did not first commence an action for patent
infringement against You in that instance.
12.2 Effect of Termination. Upon termination, You
agree to immediately stop any further use,
reproduction, modification, sublicensing and
distribution of the Covered Code. All sublicenses to the
Covered Code which have been properly granted prior
to termination shall survive any termination of this
License. Provisions which, by their nature, should
remain in effect beyond the termination of this License
shall survive, including but not limited to Sections 3, 5,
8, 9, 10, 11, 12.2 and 13. No party will be liable to any
other for compensation, indemnity or damages of any
sort solely as a result of terminating this License in
accordance with its terms, and termination of this
License will be without prejudice to any other right or
remedy of any party.
13. Miscellaneous.
13.1 Government End Users. The Covered Code is a
"commercial item" as defined in FAR 2.101.
Government software and technical data rights in the
Covered Code include only those rights customarily
provided to the public as defined in this License. This
customary commercial license in technical data and
software is provided in accordance with FAR 12.211
(Technical Data) and 12.212 (Computer Software) and,
for Department of Defense purchases, DFAR
252.227-7015 (Technical Data -- Commercial Items)
and 227.7202-3 (Rights in Commercial Computer
Software or Computer Software Documentation).
Accordingly, all U.S. Government End Users acquire
Covered Code with only those rights set forth herein.
13.2 Relationship of Parties. This License will not be
construed as creating an agency, partnership, joint
venture or any other form of legal association between
or among You, Apple or any Contributor, and You will
not represent to the contrary, whether expressly, by
implication, appearance or otherwise.
13.3 Independent Development. Nothing in this
License will impair Apple's right to acquire, license,
develop, have others develop for it, market and/or
distribute technology or products that perform the
same or similar functions as, or otherwise compete
with, Modifications, Larger Works, technology or
products that You may develop, produce, market or
distribute.
13.4 Waiver; Construction. Failure by Apple or any
Contributor to enforce any provision of this License
will not be deemed a waiver of future enforcement of
that or any other provision. Any law or regulation
which provides that the language of a contract shall be
construed against the drafter will not apply to this
License.
Epson SureColor T-Series User’s Guide
Software License Terms
212
13.5 Severability. (a) If for any reason a court of
competent jurisdiction finds any provision of this
License, or portion thereof, to be unenforceable, that
provision of the License will be enforced to the
maximum extent permissible so as to effect the
economic benefits and intent of the parties, and the
remainder of this License will continue in full force and
effect. (b) Notwithstanding the foregoing, if applicable
law prohibits or restricts You from fully and/or
specifically complying with Sections 2 and/or 3 or
prevents the enforceability of either of those Sections,
this License will immediately terminate and You must
immediately discontinue any use of the Covered Code
and destroy all copies of it that are in your possession
or control.
13.6 Dispute Resolution. Any litigation or other
dispute resolution between You and Apple relating to
this License shall take place in the Northern District of
California, and You and Apple hereby consent to the
personal jurisdiction of, and venue in, the state and
federal courts within that District with respect to this
License. The application of the United Nations
Convention on Contracts for the International Sale of
Goods is expressly excluded.
13.7 Entire Agreement; Governing Law. This License
constitutes the entire agreement between the parties
with respect to the subject matter hereof. This License
shall be governed by the laws of the United States and
the State of California, except that body of California
law concerning conflicts of law.
Where You are located in the province of Quebec,
Canada, the following clause applies: The parties
hereby confirm that they have requested that this
License and all related documents be drafted in
English.
Les parties ont exigé que le présent contrat et tous les
documents connexes soient rédigés en anglais.
EXHIBIT A.
"Portions Copyright (c) 1999-2003 Apple Computer,
Inc. All Rights Reserved.
This file contains Original Code and/or Modifications
of Original Code as defined in and that are subject to
the Apple Public Source License Version 2.0 (the
'License'). You may not use this file except in
compliance with the License. Please obtain a copy of
the License at http://www.opensource.apple.com/apsl/
and read it before using this file.
The Original Code and all software distributed under
the License are distributed on an 'AS IS' basis,
WITHOUT WARRANTY OF ANY KIND, EITHER
EXPRESS OR IMPLIED, AND APPLE HEREBY
DISCLAIMS ALL SUCH WARRANTIES,
INCLUDING WITHOUT LIMITATION, ANY
WARRANTIES OF MERCHANTABILITY, FITNESS
FOR A PARTICULAR PURPOSE, QUIET
ENJOYMENT OR NON-INFRINGEMENT. Please see
the License for the specific language governing rights
and limitations under the License."
Other Software Licenses
Info-ZIP copyright and license
This is version 2007-Mar-4 of the Info-ZIP license. The
definitive version of this document should be available
at ftp://ftp.info-zip.org/pub/infozip/license.html
indefinitely and a copy at
http://www.info-zip.org/pub/infozip/license.html.
Copyright © 1990-2007 Info-ZIP. All rights reserved.
For the purposes of this copyright and license,
“Info-ZIP” is defined as the following set of
individuals:
Mark Adler, John Bush, Karl Davis, Harald Denker,
Jean-Michel Dubois, Jean-loup Gailly, Hunter Goatley,
Ed Gordon, Ian Gorman, Chris Herborth, Dirk Haase,
Greg Hartwig, Robert Heath, Jonathan Hudson, Paul
Kienitz, David Kirschbaum, Johnny Lee, Onno van der
Linden, Igor Mandrichenko, Steve P. Miller, Sergio
Monesi, Keith Owens, George Petrov, Greg Roelofs,
Kai Uwe Rommel, Steve Salisbury, Dave Smith, Steven
M. Schweda, Christian Spieler, Cosmin Truta, Antoine
Verheijen, Paul von Behren, Rich Wales, Mike White.
Epson SureColor T-Series User’s Guide
Software License Terms
213
Permission is granted to anyone to use this software for
any purpose, including commercial applications, and
to alter it and redistribute it freely, subject to the above
disclaimer and the following restrictions:
1. Redistributions of source code (in whole or in
part) must retain the above copyright notice,
definition, disclaimer, and this list of conditions.
2. Redistributions in binary form (compiled
executables and libraries) must reproduce the
above copyright notice, definition, disclaimer,
and this list of conditions in documentation
and/or other materials provided with the
distribution. The sole exception to this condition
is redistribution of a standard UnZipSFX binary
(including SFXWiz) as part of a self-extracting
archive; that is permitted without inclusion of this
license, as long as the normal SFX banner has not
been removed from the binary or disabled.
3. Altered versions--including, but not limited to,
ports to new operating systems, existing ports
with new graphical interfaces, versions with
modified or added functionality, and dynamic,
shared, or static library versions not from
Info-ZIP--must be plainly marked as such and
must not be misrepresented as being the original
source or, if binaries, compiled from the original
source. Such altered versions also must not be
misrepresented as being Info-ZIP
releases--including, but not limited to, labeling of
the altered versions with the names “Info-ZIP” (or
any variation thereof, including, but not limited
to, different capitalizations), “Pocket UnZip,”
“WiZ” or “MacZip” without the explicit permission
of Info-ZIP. Such altered versions are further
prohibited from misrepresentative use of the
Zip-Bugs or Info-ZIP e-mail addresses or the
Info-ZIP URL(s), such as to imply Info-ZIP will
provide support for the altered versions.
4. Info-ZIP retains the right to use the names
“Info-ZIP,” “Zip,” “UnZip,” “UnZipSFX,” “WiZ,”
“Pocket UnZip,” “Pocket Zip,” and “MacZip” for its
own source and binary releases.
