The Neo-Flex LCD Arm is the perfect accessory to add

flexibility to your LCD monitor or TV. Sleek and streamlined,

it frees up desk space and allows you to easily adjust the height

of your LCD. With the simple touch of a button, you can raise or

lower the LCD to:

• Increase viewing comfort

• Reduce glare

• Meet the sight line needs of other users

For quick vertical adjustment, simply push the side button with

one hand while lifting the LCD with the other hand. Then position

the LCD where you want it and release the button. It’s ideal for

home and office use, especially for situations where several

people use the same display.

Highlights

• Great value at a great price

• Easily position your LCD for

maximum comfort & productivity

• 8" (203 mm) vertical adjustment

range accommodates seated

average height male and

female users

• Allows LCD to be rotated for

portrait/landscape viewing

• Easy installation; mounts via

desk clamp or grommet

• Patent-pending technology

provides premium long-life LCD

adjustment while maintaining

touch-screen stability

• LCD weight capacity up to

18 lbs (8.2 kg)

• Rugged construction ensures

durability

• Integrated cable clip organizes

and routes cables

• Easily attaches to LCDs that

are VESA MIS-D, 100/75, C

compliant

Product Sheet

870-05-057, rev. 24/08/06

© 2006 Ergotron, Inc. All rights reserved

By Ergotron®

Neo-Flex™ LCD Arm

© 2006 Ergotron, Inc.

rev. 24/08/2006 870-05-057

Ergotron Europe

Beeldschermweg 3

3821 AH Amersfoort

The Netherlands

Tel: +31 33 45 45 600

Fax: +31 33 45 45 620

info.eu@ergotron.com

www.ergotron-europe.com

Basic Specifications:

Description: Neo-Flex™ LCD Arm

Brown Box Part Number: 45-174-300 (silver)

Attachment Options:

• Desk clamp: mounts to surfaces up to 2" (51 mm) thick

• Grommet: mounts through holes up to 2" (51 mm) wide,

to surfaces up to 1-3/4" (44.5 mm) thick. Grommet must be

center mounted on the through hole.

Easily attach your LCD to the arm with

four screws. Then position the height and

angle of the LCD for maximum comfort and

productivity.

Gently press button and smoothly lift your

LCD into the position that fits your needs.

Cables are guided along the underside of arm

for a clutter-free desk.

Robust desk clamp base uses little space yet

ensures stability even as the LCD is adjusted

(optional grommet mount kit included).

The Neo-Flex LCD Arm is compatible with

LCDs that are VESA compliant. Simply remove

the existing base of the LCD and attach the

LCD to the Arm.

Range of Motion:

180° up/down

LCD tilt

180° right/left

LCD tilt

360° LCD

portrait/landscape

rotation

8" (203 mm) arm

height adjustment

360° arm side-to-side range

LCD Interface Options:

• Accommodates VESA MIS-D, 100/75, C compliant LCDs

Weight Capacity: 18 lbs (8.2 kg)

Shipping Weight: 9 lbs (4.09 kg)

Warranty: 3-year

MM

MM

MM

MM

Content is subject to change

without notification.
