Ericsson Wi Fi 20001002 U-NII band radio module User Manual PM B2CC001AA E Manual
Ericsson Wi-Fi U-NII band radio module PM B2CC001AA E Manual
Manual
Page 1 of 12
B2CC001AA-E
B2CC001AA-E Product Manual
5 GHz WLAN Radio Module
Document Date: August 2004
Document Number: PM-B2CC001AA-E
Document Version Number: 1
Document Status: Release
© Copyright 2004 by BelAir Networks.
All rights reserved..
B2CC001AA-E Product Manual – 5 GHz WLAN Radio Module
August 2004 Page 2 of 12
PM-B2CC001AA-E version 1
Contents
About this Document ............................................................. 2
Introduction............................................................................. 3
Conditions of Use.................................................................... 4
Module Installation and Service ............................................ 6
Final Product Requirements.................................................. 7
Regulatory Statements........................................................... 9
About this Document
This document is a product manual for the B2CC001AA 5 GHz WLAN Radio
Module, including its limitations on use in any product marketed or offered for
sale. It is intended as a supplement to training and documentation by BelAir
Networks Inc. or its authorized agents.
B2CC001AA-E Product Manual – 5 GHz WLAN Radio Module
August 2004 Page 3 of 12
PM-B2CC001AA-E version 1
Introduction
The B2CC001AA-E (hereafter referred to as “the module”) is a 5 GHz radio
module compatible with the IEEE 802.11 standard for Wireless LAN
operation. It is designed to be interoperable with WLAN products which are
based on Direct Sequence Spread Spectrum (DSSS) radio technology.
The module contains a complete 802.11a radio and Medium Access Control
(MAC) protocol engine which allows implementation of an 802.11a device.
The module is not intended for stand-alone operation. It will only be
marketed as a complete product, in conjunction with a package, DC power
supply and antenna (hereafter referred to as “the product” or the “final
product”).
Since the module has a BelAir networks proprietary digital interface, it cannot
be directly connected to any standard telecommunications or computer
devices. It can only be used with final products designed and authorized
specifically for that purpose.
B2CC001AA-E Product Manual – 5 GHz WLAN Radio Module
August 2004 Page 4 of 12
PM-B2CC001AA-E version 1
Conditions of Use
General Conditions of Use
This manual is intended to supplement training provided by BelAir Networks
or authorized parties. The module B2CC001AA-E is only intended for use in
BelAir Networks products and is not for sale to the general public as a stand-
alone module.
Please read this entire document, including the Regulatory Statements section
before attempting to install or operate the module.
Warning: Any use of B2CC001AA-E in any manner which is not
expressly specified within this manual or specifically approved by BelAir
Networks or its authorized agents will void the user’s right to operate this
module, and is expressly forbidden by BelAir Networks. This includes any
modification of the module, installation of the module in a configuration or
used with an antenna which is not expressly listed in this document or
approved by BelAir Networks.
List of Approved Final Products
The B2CC001AA-E module is only approved for use in the following BelAir
Networks products:
• BelAir100. See BelAir100 documentation for complete manufacturing
instructions. The BelAir100 may contain up to one B2CC001AA-E module
(FCC ID: RAR20001002, IC: 4674A-20001002) and up to one BEL20000
module (FCC ID: RAR20000001, IC: 4674A-20000001).
Operation of the module within the products expressly listed above is
required to ensure compliance to all FCC and Industry Canada regulations.
Any modification of the module, or its use in any configuration not expressly
listed above may void the user’s right to operate this module.
Country of Use
B2CC001AA-E is certified with limited modular approval for use in the United
States as an Intentional Radiator as device: FCC ID: RAR20001002 and in
B2CC001AA-E Product Manual – 5 GHz WLAN Radio Module
August 2004 Page 5 of 12
PM-B2CC001AA-E version 1
Canada as IC: 4674A-20001002. Please read all regulatory statements at the
end of this document before any attempt to install or operate this module.
The module is only certified for operation in the United States and Canada.
Before attempting to install and operate this module in any other country,
contact BelAir Networks for approval.
Module Labeling
One or more labels are applied to the module during manufacture, including a
label which identifies the FCC and Industry Canada identification numbers. Do
not attempt to remove any labels from the module.
B2CC001AA-E Product Manual – 5 GHz WLAN Radio Module
August 2004 Page 6 of 12
PM-B2CC001AA-E version 1
Module Installation and Service
Installation into a Product
The module shall only be installed by a technician trained by BelAir Networks
or its authorized agents. It should only be installed into an approved product
(see above) following all manufacturing and service procedures for that
product. The module should only be installed into a final product in a
manufacturing or service depot site.
Caution: B2CC001AA-E is an electro-static discharge (ESD) sensitive device.
All appropriate ESD measures must be taken when handling the module.
Failure to employ appropriate ESD protection may damage the module.
Module Service
The module is not intended as a field-serviceable unit. It contains no field-
replaceable or field-serviceable parts, or any external adjustable mechanisms.
The module should only be serviced in a manufacturing or service depot site
approved by BelAir Networks or its authorized agents.
B2CC001AA-E Product Manual – 5 GHz WLAN Radio Module
August 2004 Page 7 of 12
PM-B2CC001AA-E version 1
Final Product Requirements
The requirements below apply to any final product in which the B2CC001AA-
E module is installed.
Antenna Usage
B2CC001AA-E module shall only be used in conjunction with the following
antenna types:
• BelAir Networks model: BEL20007, 15 dBi directional antenna, horizontal
beamwidth 45 degrees.
• BelAir Networks model: BMA000216, 12 dBi directional antenna,
horizontal beamwidth 45 degrees.
• BelAir Networks model: BMA000210, 10.5 dBi directional antenna,
horizontal beamwidth 65 degrees.
Warning: Use of this module in conjunction with any antenna not expressly
listed above will void authority to install or operate this equipment.
Product Installation
Products which contain B2CC001AA-E shall only be installed by professional
installers trained by BelAir Networks or its authorized agents. In addition to
normal installation procedures and good installation practice, professional
installers are responsible to ensure that:
1. Only an approved antenna (see above) is connected to the module,
2. The antenna is mounted in such a manner and in such a location that
access to the antenna by the general population is minimized. Access to
the antenna by the general population should be limited to greater than 20
cm (8 inches) during normal operation.
3. Only the approved BelAir Networks AC power cable (model BMC200003)
may be used when this module is deployed with the BelAir100 product.
Use of any other power cable may void the regulatory approvals of the
BelAir100 and is prohibited.
4. In the UNI-3 band (5725-5825 MHz), the 15dBi antenna can only be used
with maximum conducted power of 17dBm for point-to-point
B2CC001AA-E Product Manual – 5 GHz WLAN Radio Module
August 2004 Page 8 of 12
PM-B2CC001AA-E version 1
configurations. If UNI-3 band operation with a multi-point configuration is
required, conducted power must be reduced to 14 dBm. Reduced
transmit power is software controlled and provisioned at system
installation.
Adherence to these rules by the professional installer is mandatory. See full
installation procedures for the particular product for details.
Product Labeling
The following permanent label, or one containing equivalent information, must
be affixed in a conspicuous location on the exterior of every product
containing this module:
This device contains the following:
FCC ID: RAR20001002 IC: 4674A-20001002
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2)
This device must accept any interference received, including
interference that may cause undesired operation.
B2CC001AA-E Product Manual – 5 GHz WLAN Radio Module
August 2004 Page 9 of 12
PM-B2CC001AA-E version 1
Regulatory Statements
The following regulatory notes apply to the product which contains module
B2CC001AA-E. The following sections or equivalent information shall appear
in the user-manual of the final product.
Regulatory Information and Disclaimers
Installation and use of this device must be in strict accordance with the
instructions included in the user documentation provided with the product.
Any changes or modifications to this product not expressly approved by the
party responsible for compliance could void the user’s authority to operate
this equipment.
The manufacturer is not responsible for any interference to radio or television
equipment caused by unauthorized modification of this device, or attachment
of any antennas or equipment other than those specified by the manufacturer.
The manufacturer or its authorized resellers or distributors will assume no
liability for any damage or violation of government regulations arising from
failing to comply with these guidelines.
Manufacturer’s FCC Conformity Statement
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions (1) this device may not
cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
FCC Interference Statement
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
B2CC001AA-E Product Manual – 5 GHz WLAN Radio Module
August 2004 Page 10 of 12
PM-B2CC001AA-E version 1
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Manufacturer’s Industry Canada Conformity Statement
This device has been designed to operate with an antenna having a maximum
gain of 15 dBi. Antenna having a higher gain is strictly prohibited per
regulations of Industry Canada. The required antenna impedance is 50 ohms.
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
To reduce potential radio interference to other users, the antenna type and its
gain should be so chosen that the equivalent isotropically radiated power
(EIRP) is not more than that required for successful communication.
This Class B Digital apparatus meets all the requirements of the Canadian
Interference-Causing Equipment Regulations.
RF Exposure Statement
This Wireless LAN radio device has been evaluated under FCC Bulletin OET
65C and found to be compliant to the requirements set forth in CFR 47
Sections 2.1091, 2.1093, and 15.247 (b) (4) addressing RF exposure from radio
frequency devices.
This device complies with FCC RF radiation exposure limits for an
uncontrolled environment. The radiated output power of this Wireless LAN
device is below the FCC radio frequency exposure limits. However, this
device should still be installed and used in such a manner that the potential for
human contact during normal operation is minimized. In order to comply with
RF exposure limits established in the ANSI C95.1 standard, this equipment
B2CC001AA-E Product Manual – 5 GHz WLAN Radio Module
August 2004 Page 11 of 12
PM-B2CC001AA-E version 1
should be installed and operated at a minimum distance of 20 centimeters (8
inches) between the radiator and a human body.
B2CC001AA-E Product Manual – 5 GHz WLAN Radio Module
August 2004 Page 12 of 12
PM-B2CC001AA-E version 1
BelAir Networks U.S. East
11921 Freedom Drive
Suite 550
Reston, VA
USA
20190
703-736-8306
BelAir Networks U.S. West
1902 Wright Place
Suite 200
Carlsbad, CA
USA
92008
760-918-5544
BelAir Networks Inc.
603 March Road
Kanata, Ontario
Canada
K2K 2M5
613-254-7070
Sales
sales@belairnetworks.com
Support
support@belairnetworks.com
General Information
Info@belairnetworks.com
