User manual

Page 1 of 14
B2CC033AA
B2CC033AA Product Manual
5 GHz WLAN Radio Module
Document Date: July 2007
Document Number: PM-B2CC033AA
Document Version Number: 3
Document Status: Release
© Copyright 2006 by BelAir Networks.
All rights reserved..
B2CC033AA Product Manual – 5 GHz WLAN Radio Module
July 2007 Page 2 of 14
PM-B2CC033AA Version 2
B2CC033AA Product Manual – 5 GHz WLAN Radio Module
July 2007 Page 3 of 14
PM-B2CC033AA Version 2
Contents
About this Document....................................................................... 3
Introduction...................................................................................... 4
Conditions of Use ............................................................................. 5
Module Installation and Service..................................................... 7
Final Product Requirements........................................................... 8
Regulatory Statements ..................................................................11
About this Document
This document is a product manual for the B2CC033AA 5 GHz WLAN Radio
Module, including its limitations on use in any product marketed or offered for
sale. It is intended as a supplement to training and documentation by BelAir
Networks Inc. or its authorized agents.
B2CC033AA Product Manual – 5 GHz WLAN Radio Module
July 2007 Page 4 of 14
PM-B2CC033AA Version 2
Introduction
The B2CC033AA (hereafter referred to as “the module”) is a 5 GHz radio
module compatible with the IEEE 802.11 standard for Wireless LAN operation.
It is designed to be interoperable with WLAN products which are based on
Direct Sequence Spread Spectrum (DSSS) radio technology.
The module contains a complete 802.11a radio and Medium Access Control
(MAC) protocol engine which allows implementation of an 802.11a module.
The module is not intended for stand-alone operation. It will only be marketed
as a complete product, in conjunction with a package, DC power supply and
antenna (hereafter referred to as “the product” or the “final product”).
Since the module has a BelAir networks proprietary digital interface, it cannot
be directly connected to any standard telecommunications or computer devices.
It can only be used with final products designed and authorized specifically for
that purpose.
B2CC033AA Product Manual – 5 GHz WLAN Radio Module
July 2007 Page 5 of 14
PM-B2CC033AA Version 2
Conditions of Use
General Conditions of Use
This manual is intended to supplement training provided by BelAir Networks or
authorized parties. The module B2CC033AA is only intended for use in BelAir
Networks products and is not for sale to the general public as a stand-alone
module.
Please read this entire document, including the Regulatory Statements section
before attempting to install or operate the module.
Warning: Any use of B2CC033AA in any manner which is not expressly
specified within this manual or specifically approved by BelAir Networks or its
authorized agents will void the user’s right to operate this module, and is
expressly forbidden by BelAir Networks. This includes any modification of the
module, installation of the module in a configuration or used with an antenna
which is not expressly listed in this document or approved by BelAir Networks.
List of Approved Final Products
The B2CC033AA module is only approved for use in the following BelAir
Networks products:
• BelAir200. See BelAir200 documentation for complete manufacturing
instructions.
• BelAir100. See BelAir100 documentation for complete manufacturing
instructions.
• BelAir50c. See BelAir50c documentation for complete manufacturing
instructions.
Operation of the module within the products expressly listed above is required
to ensure compliance to all FCC and Industry Canada regulations. Any
modification of the module, or its use in any configuration not expressly listed
above may void the user’s right to operate this module.
B2CC033AA Product Manual – 5 GHz WLAN Radio Module
July 2007 Page 6 of 14
PM-B2CC033AA Version 2
Country of Use
B2CC033AA is certified with limited modular approval for use as an
Intentional Radiator in the United States as device: FCC ID: RAR20001003
and in Canada as IC: 4674A-20001003. Please read all regulatory statements at
the end of this document before any attempt to install or operate this module.
The module is only certified for operation in the United States and Canada.
Before attempting to install and operate this module in any other country,
contact BelAir Networks for approval.
Module Labeling
One or more labels are applied to the module during manufacture, including a
label which identifies the FCC and Industry Canada identification numbers. Do
not attempt to remove any labels from the module.
B2CC033AA Product Manual – 5 GHz WLAN Radio Module
July 2007 Page 7 of 14
PM-B2CC033AA Version 2
Module Installation and Service
Installation into a Product
The module shall only be installed by a technician trained by BelAir Networks
or its authorized agents. It should only be installed into an approved product
(see above) following all manufacturing and service procedures for that product.
The module should only be installed into a final product in a manufacturing or
service depot site.
Caution: B2CC033AA is an electro-static discharge (ESD) sensitive device.
All appropriate ESD measures must be taken when handling the module.
Failure to employ appropriate ESD protection may damage the module.
Module Service
The module is not intended as a field-serviceable unit. It contains no field-
replaceable or field-serviceable parts, or any external adjustable mechanisms.
The module should only be serviced in a manufacturing or service depot site
approved by BelAir Networks or its authorized agents.
B2CC033AA Product Manual – 5 GHz WLAN Radio Module
July 2007 Page 8 of 14
PM-B2CC033AA Version 2
Final Product Requirements
The requirements below apply to any final product in which the B2CC033AA
module is installed.
Antenna Usage and Module Transmit Power
B2CC033AA module shall only be used in conjunction with the following
antenna types:
• BelAir Networks models BMA000210 and BMA000203: 10 and 15 dBi
antennas.
• MaxRad model: MMO58004NF, 4 dBi omni-directional antenna.
• MaxRad model: MMO58010NF, 10 dBi omni-directional antenna.
• Huber+Suhner model: SPA 5600/9/23/0/V, 23 dBi omni-directional
antenna.
In order to comply with the FCC and Industry Canada rules in the USA and
Canada, respectively, it is required to respect the maximum transmit power
limits as follows for each of the antenna types.
Antenna Models and Maximum Allowable Power Setting
Frequency Band Channels Location Maximum Rated Transmit Power with Antenna Type
5.15 – 5.25 GHz 36 to 50 Indoor Only
Antenna Gain Max Rated Transmit
Power
MaxRad MMO58004NF 4 dBi 16 dBm
MaxRad MMO58010NF
BelAir BMA000210 10 dBi 12 dBm
BelAir BMA000203 15 dBi 7 dBm
H+S SPA 5600/9/23/0/V 23 dBi Not for use in this band.
B2CC033AA Product Manual – 5 GHz WLAN Radio Module
July 2007 Page 9 of 14
PM-B2CC033AA Version 2
5.725 – 5.850 GHz 148 to 167 Indoor /
Outdoor
Antenna Gain Max Rated Transmit
Power
MaxRad MMO58004NF 4 dBi 20 dBm
MaxRad MMO58010NF
BelAir BMA000210 10 dBi 20 dBm
BelAir BMA000203 15 dBi 20 dBm
H+S SPA 5600/9/23/0/V 23 dBi 20 dBm (P2P)*
else
13 dBm
* P2P indicates that the rated transmit power is only permissible for use in
point-to-point links. For point-to-multipoint or multipoint-to-multipoint links
the power must be reduced as shown.
Warning: Use of this module in conjunction with any antenna not
expressly listed above will void authority to install or operate this equipment.
Warning: Setting of module transmit power above the limits specified in
the above table for a particular combination of antenna type, frequency of
operation, and type of usage, will exceed FCC or Industry Canada limits and
void authority to install or operate this equipment.
Product Installation
Products which contain B2CC033AA-A shall only be installed by professional
installers trained by BelAir Networks or its authorized agents. In addition to
normal installation procedures and good installation practice, professional
installers are responsible to ensure that:
1. Only an approved antenna (see above) is connected to the module, and,
2. The antenna is mounted in such a manner and in such a location that access
to the antenna by the general population is minimized. Access to the
antenna by the general population should be limited to more than the
minimum safety distance. This distance is:
B2CC033AA Product Manual – 5 GHz WLAN Radio Module
July 2007 Page 10 of 14
PM-B2CC033AA Version 2
• 25 cm (9.8 inches) for operation in all bands with the 4 and 10 dBi
antennas.
• 25 cm (9.8 inches) for operation in the 5.15-5.25 GHz bands with the 15
dBi antenna.
• 33 cm (113 inches) for operation in the 5.725 – 5.850 GHz band with
the 15 dBi antenna.
• 72 cm (28.3 inches) for operation in the 5.725 to 5.850 GHz with the 23
dBi antenna.
Adherence to these rules by the professional installer is mandatory. See full
installation procedures for the particular product for details.
Product Labeling
The following permanent label, or one containing equivalent information, must
be affixed in a conspicuous location on the exterior of every product containing
this module:
This device contains the following:
FCC ID: RAR20001003 IC: 4674A-20001003
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2)
This device must accept any interference received, including
interference that may cause undesired operation.
B2CC033AA Product Manual – 5 GHz WLAN Radio Module
July 2007 Page 11 of 14
PM-B2CC033AA Version 2
Regulatory Statements
The following regulatory notes apply to the product which contains module
B2CC033AA. The following sections or equivalent information shall appear in
the user-manual of the final product.
Regulatory Information and Disclaimers
Installation and use of this device must be in strict accordance with the
instructions included in the user documentation provided with the product. Any
changes or modifications to this product not expressly approved by the party
responsible for compliance could void the user’s authority to operate this
equipment.
The manufacturer is not responsible for any interference to radio or television
equipment caused by unauthorized modification of this device, or attachment of
any antennas or equipment other than those specified by the manufacturer.
The manufacturer or its authorized resellers or distributors will assume no
liability for any damage or violation of government regulations arising from
failing to comply with these guidelines.
Manufacturer’s FCC Conformity Statement
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions (1) this device may not
cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
FCC Interference Statement
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
B2CC033AA Product Manual – 5 GHz WLAN Radio Module
July 2007 Page 12 of 14
PM-B2CC033AA Version 2
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Manufacturer’s Industry Canada Conformity Statement
This device has been designed to operate with an antenna having a maximum
gain of 23 dB. Antenna having a higher gain is strictly prohibited per
regulations of Industry Canada. The required antenna impedance is 50 ohms.
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
To reduce potential radio interference to other users, the antenna type and its
gain should be so chosen that the equivalent isotropically radiated power (EIRP)
is not more than that required for successful communication.
This Class B Digital apparatus meets all the requirements of the Canadian
Interference-Causing Equipment Regulations.
RF Exposure Statement
This Wireless LAN radio device has been evaluated under FCC Bulletin OET
65C and found to be compliant to the requirements set forth in CFR 47 Sections
2.1091, 2.1093, and 15.247 (b) (4) addressing RF exposure from radio
frequency devices.
This device complies with FCC RF radiation exposure limits for an
uncontrolled environment. The radiated output power of this Wireless LAN
B2CC033AA Product Manual – 5 GHz WLAN Radio Module
July 2007 Page 13 of 14
PM-B2CC033AA Version 2
device is below the FCC radio frequency exposure limits. However, this device
should still be installed and used in such a manner that the potential for human
contact during normal operation is minimized. In order to comply with RF
exposure limits established in the ANSI C95.1 standard, this equipment should
be installed and operated at a minimum distance between the radiator and a
human body. This minimum distance is:
• 25 cm (9.8 inches) for operation in all bands with the 4 and 10 dBi
antennas.
• 25 cm (9.8 inches) for operation in the 5.15-5.25 GHz bands with the 15
dBi antenna.
• 33 cm (113 inches) for operation in the 5.725 – 5.850 GHz band with
the 15 dBi antenna.
• 72 cm (28.3 inches) for operation in the 5.725 to 5.850 GHz with the 23
dBi antenna.
B2CC033AA Product Manual – 5 GHz WLAN Radio Module
July 2007 Page 14 of 14
PM-B2CC033AA Version 2
BelAir Networks Inc.
603 March Road
Kanata, Ontario
Canada
K2K 2M5
613-254-7070
Sales
sales@belairnetworks.com
Support
support@belairnetworks.com
General Information
Info@belairnetworks.com

Navigation menu
