Ericsson Wi Fi 20021002 TRM1 – Transport Radio Module 1 User Manual RAR20021002 TRM Manual
Ericsson Wi-Fi TRM1 – Transport Radio Module 1 RAR20021002 TRM Manual
User Manual
Page 1 of 13
B2CH100AA
B2CH100AA Product Manual
TRM 5.9 GHz WLAN Radio Module
Document Date: 19 Sept, 2008
Document Number : PM-B2CH100AA
Document Version Number : 4
Document Status: Release
© Copyright 2008 by BelAir Networks.
All rights reserved.
B2CH100AA Product Manual
Page 2 of 13
B2CH100AA Product Manual
Page 3 of 13
Contents
About this Document .................................................................... 3
Introduction .................................................................................... 4
Conditions of Use ........................................................................... 5
Module Installation and Service.................................................... 7
Final Product Requirements ......................................................... 8
Regulatory Statements................................................................ 11
About this Document
This document is a product manual for the B2CH100AA 5 GHz WLAN Radio
Module, including its limitations on use in any product marketed or offered for sale.
It is intended as a supplement to training and documentation by BelAir Networks
Inc. or its authorized agents.
B2CH100AA Product Manual
Page 4 of 13
Introduction
The B2CH100AA (hereafter referred to as “the module”) is a 5.9 GHz radio
module compatible with the IEEE 802.11p standard for Wireless LAN operation. It
is designed to be interoperable with WLAN products which are based on Direct
Sequence Spread Spectrum (DSSS) radio technology.
The module contains a complete 802.11p radio and Medium Access Control (MAC)
protocol engine which allows implementation of an 802.11p module.
The module is not intended for stand-alone operation. It will only be marketed as a
complete product, in conjunction with a package, DC power supply and antenna
(hereafter referred to as “the product” or the “final product”).
Since the module has a BelAir networks proprietary digital interface, it cannot be
directly connected to any standard telecommunications or computer devices. It can
only be used with final products designed and authorized specifically for that
purpose.
B2CH100AA Product Manual
Page 5 of 13
Conditions of Use
General Conditions of Use
This manual is intended to supplement training provided by BelAir Networks or
authorized parties. The module B2CH100AA is only intended for use in BelAir
Networks products and is not for sale to the general public as a stand-alone module.
Please read this entire document, including the Regulatory Statements section
before attempting to install or operate the module.
Warning: Any use of B2CH100AA in any manner which is not expressly
specified within this manual or specifically approved by BelAir Networks or its
authorized agents will void the user’s right to operate this module, and is expressly
forbidden by BelAir Networks. This includes any modification of the module,
installation of the module in a configuration or used with an antenna which is not
expressly listed in this document or approved by BelAir Networks.
List of Approved Final Products
The B2CH100AA module is only approved for use in the following BelAir Networks
products:
• BelAir200. See BelAir200 documentation for complete manufacturing instructions.
• BelAir100. See BelAir100 documentation for complete manufacturing instructions.
• BelAir50c. See BelAir50c documentation for complete manufacturing instructions.
Operation of the module within the products expressly listed above is required to
ensure compliance to all FCC and Industry Canada regulations. Any modification of
the module, or its use in any configuration not expressly listed above may void the
user’s right to operate this module.
Country of Use
B2CH100AA is certified with limited modular approval for use as an Intentional
Radiator in the United States as device: FCC ID: RAR20021002 and in Canada as
B2CH100AA Product Manual
Page 6 of 13
IC: 4674A-20021002. Please read all regulatory statements at the end of this
document before any attempt to install or operate this module.
The module is only certified for operation in the United States and Canada. Before
attempting to install and operate this module in any other country, contact BelAir
Networks for approval.
Module Labeling
One or more labels are applied to the module during manufacture, including a label
which identifies the FCC and Industry Canada identification numbers. Do not
attempt to remove any labels from the module.
B2CH100AA Product Manual
Page 7 of 13
Module Installation and Service
Installation into a Product
The module shall only be installed by a technician trained by BelAir Networks or its
authorized agents. It should only be installed into an approved product (see above)
following all manufacturing and service procedures for that product. The module
should only be installed into a final product in a manufacturing or service depot site.
Caution: B2CH100AA is an electro-static discharge (ESD) sensitive device. All
appropriate ESD measures must be taken when handling the module. Failure to
employ appropriate ESD protection may damage the module.
Module Service
The module is not intended as a field-serviceable unit. It contains no field-
replaceable or field-serviceable parts, or any external adjustable mechanisms. The
module should only be serviced in a manufacturing or service depot site approved
by BelAir Networks or its authorized agents.
B2CH100AA Product Manual
Page 8 of 13
Final Product Requirements
The requirements below apply to any final product in which the B2CH100AA module is installed.
Antenna Usage and Module Transmit Power
B2CH100AA module shall only be used at the following output power levels in
conjunction with the following antenna types as outlined in the tables that follow:
5.85-5.925 GHz
For operation in the 5.85 – 5.925 GHz bands:
Channel
No.
Frequency
(GHz)
Channel
BW
(MHz)
DSRC Radio Rated
Output power (dBm)
10 dBi antenna
DSRC Radio Rated
Output power (dBm)
15 dBi antenna
DSRC Radio Rated
Output power (dBm)
19 dBi antenna
172
5.860
10
23 dBm conducted/
33 dBm EIRP
18 dBm conducted/
33 dBm EIRP
14 dBm conducted/
33 dBm EIRP
174
5.870
10
23 dBm conducted/
33 dBm EIRP
18 dBm conducted/
33 dBm EIRP
14 dBm conducted/
33 dBm EIRP
175
5.875
20
13 dBm conducted/
23 dBm EIRP
8dBm conducted/
23dBm EIRP
4dBm conducted/
23dBm EIRP
176
5.880
10
23 dBm conducted/
33 dBm EIRP
18 dBm conducted/
33 dBm EIRP
14 dBm conducted/
33 dBm EIRP
178
5.890
10
23 dBm conducted/
33 dBm EIRP
18 dBm conducted/
33 dBm EIRP
14 dBm conducted/
33 dBm EIRP
180
5.900
10
13 dBm conducted/
23 dBm EIRP
181
5.905
20
13 dBm conducted/
23 dBm EIRP
182
5.910
10
13 dBm conducted/
23 dBm EIRP
184
5.920
10
23 dBm conducted/
33 dBm EIRP
As per FCC 90.377(b), the maximum EIRP shown above are permitted only for a
unit which is mounted at an antenna height not exceeding 8m above the roadway
surface. A unit may employ an antenna height more than 8m but not exceeding 15m
above the roadway surface, providing the EIRP in the table above is reduced by a
B2CH100AA Product Manual
Page 9 of 13
factor of 20 log(H/8) in dB, where H is the height of the radiation center of the
antenna in meters above the roadway surface.
The list of certified antennas is given below:
Manufacturer Part # Gain Type
MAXRAD MHO5158010NM 10 Omni, vertical polarization
MTI MT-462008 10 Omni, vertical polarization
MAXRAD MMO58010NF 10 Omni, vertical polarization
BelAir BX2A00002 15 Directional, vertical polarization
MAXRAD WISP4959018MBV 15 90 deg. Sector, vertical polarization
MTI MT-485001 19 Directional, vertical polarization
In order to comply with the FCC and Industry Canada rules in the USA and Canada,
respectively, it is required to respect the maximum transmit power limits as shown
above for each of the antenna types.
Warning: Use of this module in conjunction with any antenna not expressly
listed above will void authority to install or operate this equipment.
Warning: Setting of module transmit power above the limits specified in the
above table for a particular combination of antenna type, frequency of operation,
and type of usage, will exceed FCC or Industry Canada limits and void authority to
install or operate this equipment.
Product Installation
Products which contain B2CH100AA-A shall only be installed by professional installers
trained by BelAir Networks or its authorized agents. This product is to be installed on
fixed permanent structures. In addition to normal installation procedures and good
installation practice, professional installers are responsible to ensure that:
1. Only an approved antenna (see above) is connected to the module, and,
2. The antenna is mounted in such a manner and in such a location that access to the
antenna by the general population is minimized. Access to the antenna by the general
population should be limited to more than the minimum safety distance. This distances
are outlined according to product type and whether high gain antennas are used:
B2CH100AA Product Manual
Page 10 of 13
Product
RF boards: All valid
combinations TRM1 ARM3C PSM1
PSM2 WRM1
WRM2 TRM1 ARM3C PSM1
PSM2 WRM1
WRM2
BelAir100, BelAir100C,
BelAir100T, BelAir100S,
BelAir100M, BelAir100D,
BelAir 200, BelAir200D
Any* Any 10 dBi 15 dBi Any* Any 25 dBi 25 dBi
Distance
* TRM1 with 10, 15, or 19 dBi antennas
High Gain Antennas (up to 30 dBi)
Minimum Safety Distances
Standard Antennas (up to 19 dBi)
33 cm (13 in) 83 cm (33 in)
Adherence to these rules by the professional installer is mandatory. See full installation
procedures for the particular product for details.
Product Labeling
The following permanent label, or one containing equivalent information, must be
affixed in a conspicuous location on the exterior of every product containing this
module:
FCC ID: RAR20021002
IC: 4674A-20021002
B2CH100AA Product Manual
Page 11 of 13
Regulatory Statements
The following regulatory notes apply to the product which contains module
B2CH100AA. The following sections or equivalent information shall appear in the
user-manual of the final product.
Regulatory Information and Disclaimers
Installation and use of this device must be in strict accordance with the instructions
included in the user documentation provided with the product. Any changes or
modifications to this product not expressly approved by the party responsible for
compliance could void the user’s authority to operate this equipment.
The manufacturer is not responsible for any interference to radio or television
equipment caused by unauthorized modification of this device, or attachment of any
antennas or equipment other than those specified by the manufacturer. The
manufacturer or its authorized resellers or distributors will assume no liability for
any damage or violation of government regulations arising from failing to comply
with these guidelines.
Manufacturer’s FCC Conformity Statement
This device complies with Part 90 of the FCC Rules.
FCC Interference Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
B2CH100AA Product Manual
Page 12 of 13
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Manufacturer’s Industry Canada Conformity Statement
This device has been designed to operate with an antenna having a maximum gain of
19 dBi. Antenna having a higher gain is strictly prohibited per regulations of Industry
Canada. The required antenna impedance is 50 ohms.
This device has been designed to ensured that radio frequency emissions are
maintained within the band of operation under all normal operating conditions listed
in this manual.
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including interference
that may cause undesired operation of the device.
To reduce potential radio interference to other users, the antenna type and its gain
should be so chosen that the equivalent isotropically radiated power (EIRP) is not
more than that required for successful communication.
This Class B Digital apparatus meets all the requirements of the Canadian
Interference-Causing Equipment Regulations.
B2CH100AA Product Manual
Page 13 of 13
RF Exposure Statement
This Wireless LAN radio device has been evaluated under FCC Bulletin OET 65C and found to
be compliant to the requirements set forth in CFR 47 90.1335 and Sections 2.1091, 2.1093,
addressing RF exposure from radio frequency devices.
This device complies with FCC RF radiation exposure limits for an uncontrolled environment.
The radiated output power of this Wireless LAN device is below the FCC radio frequency
exposure limits. However, this device should still be installed and used in such a manner that
the potential for human contact during normal operation is minimized. In order to comply with
RF exposure limits established in the ANSI C95.1 standard, this equipment should be installed
and operated at a minimum distance between the radiator and a human body. This minimum
distance is:
Product
RF boards: All valid
combinations TRM1 ARM3C PSM1
PSM2 WRM1
WRM2 TRM1 ARM3C PSM1
PSM2 WRM1
WRM2
BelAir100, BelAir100C,
BelAir100T, BelAir100S,
BelAir100M, BelAir100D,
BelAir 200, BelAir200D
Any* Any 10 dBi 15 dBi Any* Any 25 dBi 25 dBi
Distance
* TRM1 with 10, 15, or 19 dBi antennas
High Gain Antennas (up to 30 dBi)
Minimum Safety Distances
Standard Antennas (up to 19 dBi)
33 cm (13 in) 83 cm (33 in)
BelAir Networks Inc.
603 March Road
Kanata, Ontario
Canada
K2K 2M5
613-254-7070
Sales
sales@belairnetworks.com
Support
support@belairnetworks.com
General Information
Info@belairnetworks.com
