Ericsson Wi Fi 20100520 2.3 GHz WCS WLAN Radio User Manual RAR20100520 WCS Manual revised
Ericsson Wi-Fi 2.3 GHz WCS WLAN Radio RAR20100520 WCS Manual revised
User Manual
Page 1 of 12
BCG001912
BCG001912 Product Manual
WCS 2.3 GHz WLAN Radio Module
Document Date: 26 June, 2009
Document Number : PM-BCG001912
Document Version Number : 2
Document Status: Release
© Copyright 2009 by BelAir Networks.
All rights reserved.
BCG001912 Product Manual
Page 2 of 12
BCG001912 Product Manual
Page 3 of 12
Contents
About this Document ............................................................................3
Introduction...........................................................................................4
Conditions of Use...................................................................................5
Module Installation and Service...........................................................7
Final Product Requirements.................................................................8
Regulatory Statements........................................................................10
About this Document
This document is a product manual for the BCG001912 WCS 2.3 GHz WLAN Radio
Module, including its limitations on use in any product marketed or offered for sale.
It is intended as a supplement to training and documentation by BelAir Networks Inc.
or its authorized agents.
BCG001912 Product Manual
Page 4 of 12
Introduction
The BCG001912 (hereafter referred to as “the module”) is a 2.3 GHz radio module
compatible with the IEEE 802.11g standard for Wireless LAN operation. It is
designed to be interoperable with WLAN products which are based on OFDM radio
technology.
The module contains a complete 802.11g radio and Medium Access Control (MAC)
protocol engine which allows implementation of an 802.11g module.
The module is not intended for stand-alone operation. It will only be marketed as a
complete product, in conjunction with a package, DC power supply and antenna
(hereafter referred to as “the product” or the “final product”). It will only be used
with final products designed and authorized specifically for that purpose by BelAir
Networks.
BCG001912 Product Manual
Page 5 of 12
Conditions of Use
General Conditions of Use
This manual is intended to supplement training provided by BelAir Networks or
authorized parties. The module BCG001912 is only intended for use in BelAir
Networks products and is not for sale to the general public as a stand-alone module.
Please read this entire document, including the Regulatory Statements section before
attempting to install or operate the module.
Warning: Any use of BCG001912 in any manner which is not expressly
specified within this manual or specifically approved by BelAir Networks or its
authorized agents will void the user’s right to operate this module, and is expressly
forbidden by BelAir Networks. This includes any modification of the module,
installation of the module in a configuration or used with an antenna which is not
expressly listed in this document or approved by BelAir Networks.
List of Approved Final Products
The BCG001912 module is only approved for use in the following BelAir Networks
products:
• BelAir100. See BelAir100 documentation for complete manufacturing instructions.
• BelAir20. See BelAir20 documentation for complete manufacturing instructions.
Operation of the module within the products expressly listed above is required to
ensure compliance to all FCC regulations. Any modification of the module, or its use
in any configuration not expressly listed above may void the user’s right to operate
this module.
Country of Use
BCG001912 is certified with limited modular approval for use as an Intentional
Radiator in the United States as device: FCC ID: RAR20100520. Please read all
regulatory statements at the end of this document before any attempt to install or
operate this module.
BCG001912 Product Manual
Page 6 of 12
The module is only certified for operation in the United States. Before attempting to
install and operate this module in any other country, contact BelAir Networks for
approval.
Module Labeling
One or more labels are applied to the module during manufacture, including a label
which identifies the FCC identification numbers. Do not attempt to remove any
labels from the module.
BCG001912 Product Manual
Page 7 of 12
Module Installation and Service
Installation into a Product
The module shall only be installed by a technician trained by BelAir Networks or its
authorized agents. It should only be installed into an approved product (see above)
following all manufacturing and service procedures for that product. The module
should only be installed into a final product in a manufacturing or service depot site.
Caution: BCG001912 is an electro-static discharge (ESD) sensitive device. All
appropriate ESD measures must be taken when handling the module. Failure to
employ appropriate ESD protection may damage the module.
Module Service
The module is not intended as a field-serviceable unit. It contains no field-
replaceable or field-serviceable parts, or any external adjustable mechanisms. The
module should only be serviced in a manufacturing or service depot site approved by
BelAir Networks or its authorized agents.
BCG001912 Product Manual
Page 8 of 12
Final Product Requirements
The requirements below apply to any final product in which the BCG001912 module is installed.
Antenna Usage and Module Transmit Power
BCG001912 module shall only be operated on the following frequencies in
conjunction with the following antenna types as outlined in the tables that follow:
2.3 GHz – Part 27
For operation in the 2.3 GHz band, the BCG001912 may be set to operate on 2.5 or 5
MHz channel bandwidths as follows:
Channel
Bandwidth
[MHz]
Sub-band ID Channel Center
Frequency [MHz] Maximum Avg.
Conducted
Transmit Power
[dBm]
5 A1 2307.5 13.0
5 B1 2312.5 13.5
5 A2 2352.5 14.5
5 B2 2357.5 16.5
Channel
Bandwidth
[MHz]
Sub-band ID Channel Center
Frequency [MHz] Maximum Avg.
Conducted
Transmit Power
[dBm]
2.5 A1L 2306.25 12.5
2.5 A1U 2308.75 12.5
2.5 B1L 2311.25 13.5
2.5 B1U 2313.75 13.5
2.5 CL 2316.25 11.0
2.5 DU 2348.75 13.5
2.5 A2L 2351.25 15.0
BCG001912 Product Manual
Page 9 of 12
2.5 A2U 2353.75 15.0
2.5 B2L 2356.25 15.5
2.5 B2U 2358.75 15.5
Antenna List
BMHG50002-A BelAir Networks, 8 dBi directional antenna
MT-344026/N, MTi, 15.5 dBi directional antenna
MFBW23008, Maxrad, 8 dBi omni-directional antenna
BNCKG0071, BelAir Networks, 3 dBi omni-directional antenna
Warning: Use of this module in conjunction with any antenna not expressly
listed above will void authority to install or operate this equipment.
Product Installation
Products which contain BCG001912 shall only be installed by professional installers trained
by BelAir Networks or its authorized agents. This product is to be installed on fixed
permanent structures. In addition to normal installation procedures and good installation
practice, professional installers are responsible to ensure that:
1. Only an approved antenna (see above) is connected to the module, and,
2. The antenna is mounted in such a manner and in such a location that access to the
antenna by the general population is minimized. Access to the antenna by the general
population should be limited to more than the minimum safety distance. These distances
are outlined according to product type and whether high gain antennas are used. See “RF
Exposure” section below for details.
Adherence to these rules by the professional installer is mandatory. See full installation
procedures for the particular product for details.
Product Labeling
The following permanent label, or one containing equivalent information, must be
affixed in a conspicuous location on the exterior of every product containing this module:
FCC ID: RAR20100520
BCG001912 Product Manual
Page 10 of 12
Regulatory Statements
The following regulatory notes apply to the product which contains module
BCG001912. The following sections or equivalent information shall appear in the
user-manual of the final product.
Regulatory Information and Disclaimers
Installation and use of this device must be in strict accordance with the instructions
included in the user documentation provided with the product. Any changes or
modifications to this product not expressly approved by the party responsible for
compliance could void the user’s authority to operate this equipment.
The manufacturer is not responsible for any interference to radio or television
equipment caused by unauthorized modification of this device, or attachment of any
antennas or equipment other than those specified by the manufacturer. The
manufacturer or its authorized resellers or distributors will assume no liability for any
damage or violation of government regulations arising from failing to comply with
these guidelines.
Manufacturer’s FCC Conformity Statement
This device complies with Part 27 of the FCC Rules.
FCC Interference Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 and Part 90 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
BCG001912 Product Manual
Page 11 of 12
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
BCG001912 Product Manual
Page 12 of 12
RF Exposure Statement
This Wireless LAN radio device has been evaluated under FCC Bulletin OET 65C and found to
be compliant to the requirements set forth in CFR 47 27.52 addressing RF exposure from radio
frequency devices.
This device complies with FCC RF radiation exposure limits for an uncontrolled environment.
The radiated output power of this Wireless LAN device is below the FCC radio frequency
exposure limits. However, this device should still be installed and used in such a manner that the
potential for human contact during normal operation is minimized. In order to comply with RF
exposure limits established in the ANSI C95.1 standard, this equipment should be installed and
operated at a minimum distance between the radiator and a human body. This minimum distance
is shown below, based on product and antenna configuration:
RAR20100520
(2.3 GHz)
RAR20180001
(2.4 GHz)
RAR20180002
(5.2, 5.6, 5.8
GHz)
RAR20000003
(2.4 GHz)
RAR20021001 /
RAR20031001
(5.8 GHz)
BelAir20
up to 15.5 dBi
n/a
n/a
n/a
n/a
Safety Distance
BelAir20
up to 15.5 dBi
4 dBi
5 dBi
n/a n/a
Safety Distance
BelAir100T
up to 15.5 dBi
n/a n/a
Any
n/a
Safety Distance
BelAir100T
up to 15.5 dBi
n/a n/a
Any
up to 15 dBi
Safety Distance
BelAir100T
up to 15.5 dBi
n/a n/a
Any
up to 19 dBi
Safety Distance
BelAir100T
up to 15.5 dBi
n/a n/a
Any
up to 23 dBi
Safety Distance
33 cm (13.0 inches)
45 cm (17.7 inches)
Radio and Antenna Combinations
16.5 cm (6.5 inches)
21 cm (8.3 inches)
26 cm (10.2 inches)
15 cm (6 inches)
