Esel C348610-H 2.4G WIRELESS CONTROLLER User Manual note1
Esel International Co., Ltd. 2.4G WIRELESS CONTROLLER note1
Esel >
USERS MANUAL
How to use:
Step 1: Turn off your console and insert the controller’s receiver into the Player
1 slot
Note:
-Do not insert the controller’s receiver into a memory card slot.
-Make sure to switch off the console before inserting the controller’s receiver.
Once the receiver is inserted you may turn on your console.
Step 2: When the receiver is first plugged into the console, the LED is OFF.
Once the controller has detected the receiver, the LED on the receiver
will turn ON. The controller is now ready to use. Please note that the
controller MAY take up to 3 minutes to connect to the receiver.
Note:
When using more than one wireless controller, plug one receiver in at a time.
When the LED lights up on the first receiver you can then plug in the second
wireless receiver into the next available controller port.
Force Connection to a designated Controller and Receiver:
Forcing the connection to a designated controller and receiver can be achieved
by following the steps listed below:
a)Press the “FC” button on the receiver - the LED on the receiver starts to blink.
c) Controller's receiver
Battery Replacement:
- Open the battery compartment door.
- Insert the batteries as marked on the bottom of the battery compartment.
Make sure that the polarity matches the illustration on the battery compartment.
-Close the battery compartment door. You are now ready to use your wireless
controller.
Note:
-For increased playing time, use Alkaline batteries.
-Do not mix fresh and used batteries. This will reduce the controller’s
transmitting and receiving distance and may cause the product to malfunction.
-Rechargeable NiMH or NiCad batteries can safely be used with this product
(rechargeable batteries are not included).
Dispose of used batteries according to the battery manufacturer’s instructions.
Thank you for purchasing Hip Gear 2.4GHz Wireless Controller for GameCube.
Please read this manual carefully before use.
Features:
-Fully compatible with GameCube
-Dual rumble motors
-Power on/off switch
-Rumble on/off switch
-6 Digital Action Buttons and 2 Analog Triggers
-Rubberized grips
-Auto channel selection
-50’ (15 meter) range
-Turbo fire setting
-Macro setting
-Low power Indicator
Button Name for Hip Gear’s 2.4GHz GameCube Wireless Controller:
a) Controller (front view)
b) Controller (top view)
GameCube 2.4GHz Wireless Controller
Instruction Manual
Y
X
A
B
Turbo
Start,Pause
Macro
C StickD Pad
Directional Stick
M
a
c
r
o
T
U
R
B
O
ON
S
T
A
R
T
OFF
Vibration
Power ON
Power OFF
Left Analog Trigger
Z
Right Analog Trigger
LED
FORCE CONNECTION
BUTTON
b) Press and hold the Macro, Turbo and Start button simultaneously on the
controller. The LED of the receiver will stop blinking and light up. The forced
connection is complete and you are ready to play.
Note:
If the controller is left idle for more than 3 minutes the designated connection
may be lost. If this happens, simply repeat the steps above.
Turbo Fire Setting:
Each button of the wireless controller has a built-in Turbo Fire function, simply
follow the steps listed below to achieve a Turbo Fire gaming experience:
-Press and hold the Turbo Fire button, the Function LED lights up.
-Press any button on the controller and the LED will turn off. The Turbo
setting is complete.
-The Function LED will blink when you press a button that has been set to
Turbo Fire.
-Repeat the procedure to assign more than one button at a time to a Turbo
Fire function.
Note:
The controller and the receiver must be connected before assigning any Turbo
Fire function.
To Clear Turbo Fire:
-Press and hold the Turbo Fire button, the Function LED will light up.
-Press the button that has been set to Turbo Fire, the LED will turn off.
-The Turbo Fire is clear, repeat this procedure for any other Turbo Fire
cancellations.
Macro Setting:
On your controller the Z button has built in Macro capabilities. This Macro
function allows you to program complicated moves and button combinations
into the Z button.
Note:
The regular function of the Z button is suspended when the button has a Macro
function designated to it. Only when the Macro designated button is cleared
will the button resume its regular operation. Clearing the Macro function is
explained further in this manual.
How to Program a Macro Function:
-Press Macro button, the Function LED turns ON.
-Press then Z button.
-Input the button combination you wish to designate to the Macro button (Z).
The button combination must be completed within 10 seconds and a
maximum of 15 button presses are allowed.
-Press the Macro button again when the input has been completed, the LED
is now OFF.
-The Function LED will blink when the Macro function button is activated.
To Clear a Macro Setting:
-Press the Macro button, the Function LED is now ON.
-Press the Z button
-Press the Macro button again, the Macro setting is now clear, and the LED
is OFF.
OFF
M
A
C
R
O
S
T
A
R
T
ON
T
U
R
B
O
OFF
M
A
C
R
O
S
T
A
R
T
ON
RTB LTB
Low Power Indication:
The Turbo LED and Macro LED will blink simultaneously when the power is
low, replace with new batteries.
Rumble On/Off
The Rumble motors will be turned on when the main power switch is set to
Rumble (wavy lines). The Rumble motors will not operate when the power
switch is in the “on” position.
User Information
This device complies with part 15 of FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference
that may cause undesired operation.
The FCC require the user to be notified that any changes or modification made
to this device that are not expressly approved by Esel International Co., Ltd.
may avoid the user's authority to operate the equipment.
To comply with FCC RF exposure requirement, this device and its antenna
must no be co-located or operating in conjunction with any other antenna or
transmitter.
M
a
c
r
o
T
U
R
B
O
ON
S
T
A
R
T
OFF
FORCE CONNECTION
BUTTON
LED
OFF
M
a
c
r
o
T
U
R
B
O
S
T
A
R
T
ON
OFF
M
A
C
R
O
S
T
A
R
T
ON
T
U
R
B
O
OFF
M
A
C
R
O
S
T
A
R
T
ON
LED light-up
LED light-up
OFF
M
A
C
R
O
T
U
R
B
O
S
T
A
R
T
ON
OFF
M
A
C
R
O
T
U
R
B
O
S
T
A
R
T
ON
Warning:
FEDERAL COMMUNICATIONS COMMISSION
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:(1) this
device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
NOTE
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiated
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for
help.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user‘s authority to
operate the equipment.
The antenna(s) used for this transmitter must not be
co-located or operating in conjunction with any other antenna
or transmitter.
