Essence Security ES700SPB Shop Panic Button User Manual 1
Essence Security International ltd. Shop Panic Button 1
User_manual
Panic Button
ES700SPB
S.O.S. Button for Retail Locations
and Small/Medium-sized Enterprises
Sends a panic message to the central
monitoring station for further action
Fully-supervised device
For shops, offices or private homes
With millions of systems and security peripherals installed
internationally, Essence Security is a technological and
market leader in the field of advanced security solutions for
homes, offices and full-service central monitoring stations
The ES700SPB Panic Button
seamlessly integrates with the
EverGuard and EverGuard Express
control panels and other products
from Essence Security
part of the Essence Group
ES700SPB Panic Button
DESCRIPTION
•When the panic button is pressed, a message is
immediately sent to the Central Monitoring
Station (CMS).
•Central Service response can be configured to
various parameters and rules and corresponding
actions
WIRELESS
•Bi-directional: End-to-End Bi-Directional ESI
protocol
•Advanced radio supervision algorithm
•Up to 700 meters RF range (open air)
•Modulation and Frequency: BFSK , 868.3 MHz
(Europe) or 916.5 MHz (US)
•Encoding: 32-bit ID, over 4 billion combinations
POWER CONSUMPTION
•Long operation period (over 36 months) without
external power source
•Uses one 3V CR123A Lithium Battery
SIZE & WEIGHT
•Size:
H-25mm/ L-55mm/ W-90mm
•Weight:
64 gr. + 17 gr. (battery)
ENVIRONMENTAL
•Operating Ambient Temperature range
-5° - 55° Celsius
•Humidity: Up to 95% non condensing
CERTIFICATIONS AND APPROVALS
•CE: CE mark, EMC/EMI according to
ETSI EN 301 489-4, ETSI EN 301 489-1,
EN 50130-4:1996,
EU Directive 1999/5/EC for R&TTE
•Radio: ETSI EN 300 220-3, ETSI EN 300 220-1,
CEPT/ERC Recommendation 70-03,
EN 50131-5-3:2005 + A1:2008
•Safety: EN/IEC 60950-1, TUV , NOM
•Security & Alarm systems: EN 50131-1:2006 +
A1:2009 Class-II Grade-2,
EN 50131-6:2008 Type-C
•Environmental Regulation: RoHS 2002/95/EC
•Reliability (Mechanical & Environmental
conditions):
EN 50130-5:1999 and IEC 60068
•Manufacturing and Materials Standards:
ISO 9001:2008 , ISO 14000
55mm
90mm
Essence Security International (E.S.I.) Ltd.
www.essence-grp.com +972-73-244-7777 info@essence-grp.com
© 2013 Essence Security International (E.S.I.) Ltd. Information contained within this document may change without notice.
Certifications and approvals:
This device complies with FCC Rules Part 15 and with Industry Canada license-exempt
RSS standard(s). Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions
suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si
le brouillage est susceptible d'en compromettre le fonctionnement.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications to this equipment not expressly approved by the party responsible for
compliance (Essence Ltd.) could void the user’s authority to operate the equipment.
