Z-Wave® Controller
ES800ZWD (V3)
Incorporating Z-Wave® Devices into
the We.R™ System
With millions of systems and security peripherals installed
internationally, Essence Security is a technological and
market leader in the field of advanced security solutions for
homes, offices and full-service central monitoring stations
The ES800ZWD Z-Wave controller
integrates with the
EverGuard and EverGuard Express
control panels and with 3rd party
Z-Wave compatible devices
part of the Essence Group
Single element – A lightweight Z-Wave® controller
Powered by the We.R™ Central Control Unit
Simple and fast pairing process
Supported Z-wave® devices – binary switch (on/off)
and dimmer, thermostat and door lock
ES800ZWD Z-Wave Controller
DESCRIPTION:
•The Z-Wave® controller allows
incorporation of 3rd party Z-Wave®
compatible devices into the We.R™
system thus integrating Smart
Home applications with Essence
security system
•To incorporate a 3rd party device in
the Essence system, the Z-Wave®
controller connects on one side to
the Essence Control Panel and on
the other to the 3rd party device.
COMMUNICATION:
•Maximum RF range 500m (1640 ft)
open air
•Z-Wave® bi-directional radio
protocol (onboard)
Essence Security International (E.S.I.) Ltd.
www.essence-grp.com +972-73-244-7777 info@essence-grp.com
© 2013 Essence Security International (E.S.I.) Ltd. Information contained within this document may change without notice.
Certifications and approvals:
This device complies with FCC Rules Part 15 and with Industry Canada license-exempt
RSS standard(s). Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause undesired operation
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions
suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si
le brouillage est susceptible d'en compromettre le fonctionnement.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications to this equipment not expressly approved by the party responsible for
compliance (Essence Ltd.) could void the user’s authority to operate the equipment.
•Frequency: 868.4/908.4/921.4 MHz
•Bit Rate: 9.6/40 kbps
SECURITY:
•Data Security – 128bit AES encryption
•Unique electronic serial number
POWER CONSUMPTION:
•Efficient power consumption to extend
the operation period
SIZE and WEIGHT:
•Z-Wave® controller = H: 5mm (0.2 in.),
L: 58mm (2.28 in.), W: 24mm 0. 94 in.)
•Cable length = 15cm (5.9 in.)
•Z-Wave® controller = 10 grams (0.03 lb)
ENVIRONMENT:
•Storage Temperature: -20oC – +50oC
(-4oF–+122oF)
•Operating Ambient Temperature range:
0oC – +50oC (+32oF – +122oF)
•Humidity: Up to 95% non-condensing
