1 Introduction - Tork EasyCubeTM
Tork EasyCube delivers actionable washroom insights through a web
user interface.
The service consists of Tork dispensers equipped with sensors that
communicate the dispenser status and rell needs to a cloud based
system, made available for different roles such as a facility manager or
the cleaning staff.
The system as well includes visitor registration units that can count
people passing into a washroom area.
Figure 1. Each dispenser is wirelessly connected to an information system that can be utilized by both
a Facility Manager as well as cleaning staff, in order to facilitate more efcient work planning.
OK OK
bin full
2 Get an instant overview
At any point in time the system will provide a quick overview of the
status of the installed dispensers through a web based dashboard.
Instantly the user of the web application, for example a facility manager,
will be able to spot if dispensers are about to become empty.
2.1 Before you get started
To be able to get started with the Tork EasyCube System there are some
activities that need to be performed.
Initially the customer together with SCA will determine which washrooms
will be included and the required number of Data Collection Units (DCUs)
to support these locations. The number of DCUs required for a location
depends upon the distribution of washrooms within the building and also
the construction material of the building walls.
Installation of the system is done by an external professional
installation company.
3 Technical components used in Tork EasyCube
The different components used for the Tork EasyCube solution:
*
3.1 Sensors
A selected range of Tork dispensers is prepared to be equipped with
sensor technologies to optimize the function, depending on the eld
of use. There are three different sensor technologies used within Tork
EasyCube:
• SCU (Sensor Communication Unit) which is used to measure
rell levels in Tork dispensers
• Dispensers with embedded sensors. The dispenser contains
a sensor from factory.
All sensors communicate to the Data Collection Unit via the radio
frequency 2.4GHz.
3.2 Tork EasyCube Sensor Communication Unit (SCU)
The SCU unit is added to a special slot within the dispensers. The rell
levels reported by the SCU are visualized in the Tork EasyCube system
by using colors.
• Green: indicates that the dispenser still
have enough paper or soap remaining.
• Orange: indicates that it is possible to
rell the dispenser.
• Red: indicates that the dispenser is
almost empty.
Each sensor is operated by an embedded battery.
3.3 Dispensers with embedded sensors
Tork dispensers such as Tork Foam Soap
Dispenser with Intuition sensor™ do not
need an additional Tork EasyCube sensor.
Instead, they have an additional radio
component within the cassette which
forwards information to the DCU via
2.4 GHz radio.
The system runs on the same battery as the
dispenser, no additional battery is needed.
3.4 Tork EasyCube Visitor Registration Unit (VRU)
The VRU counts the number of people going in and out of a room.
The number of visitors can be used as a guideline for when
washrooms need to be cleaned.
The sensor has a exible measurement direction, just open the two
end pieces and rotate the center unit 90° to change direction. Place
one sender and one receiver at the door frame to the entry of the
room. The sensor has a range of up to 1.7 meters / 5.5 feet.
A congurable response time makes the sensor useful in many
different environments and applications.
Each sensor is operated by an embedded battery that will
last for 5 years.
3.5 Tork EasyCube Data Collection Unit (DCU)
The Data Collection Unit, DCU, collects the data
from the sensors (SCUs and VRUs) and sends
information to the Tork EasyCube system. The
DCU acts as a communication gateway for all
the sensors that have been paired with it.
The unit collects and processes incoming
sensor data.
The DCU has a DC adapter and it has battery
backup to ensure performance during power failure.
The DCU has a built-in GSM/GPRS modem used to connect to Internet.
No access to local physical networks is needed. Communication
between sensors and the DCU is based on SCA proprietary protocol.
3.6 Several DCUs
In order to cover larger areas, several DCUs may be needed. As each
DCU has communication capabilities with the back end server, they
can be installed over a large area with no requirements of in-between
communication.
Figure 2. Status red indicates very soon out-of-paper and Yellow indicates a half-full dispenser. Status
green needs no attention. Add a dashboard measurement of a critical location to track its usage.
Figure 3. The different components used for the Tork EasyCube solution
* Europe only End customer washroom SCA server
Real-time data
at customer
Figure 4. Sensor
card found inside
a dispenser
Figure 6. Visitor
registration unit
Figure 7. DCU gateway
Figure 5. The battery
operated, touch free Tork
Foam Soap Dispensers
4 Wireless Communication
There are different sensors in the Tork EasyCube system, but they all
communicate in the same manner.
Data
Collection
Unit
Server/Gateway
2.4Ghz Radio
2.4Ghz Radio
GSM
User Interface
Sensor
Communication
Unit
Internet
Connection
Visitor
Registration
Unit
The sensors send data to the DCU with a default dened time interval.
The DCU is congured for Tork dispensers with dened status levels,
e.g. Almost Empty, Time for Rell and Full . If a change in status
occurs, the DCU forwards the information to the back-end server. It is
in the back-end where all data is processed and aggregated to useful
information. The customer is provided access to the Tork EasyCube web
application for management and analysis of collected information.
All congurations and settings to the system are done during installation.
Warnings
• Only use the power supply provided with the Tork
EasyCubeTM.
• If any of the contents of the Tork EasyCubeTM appear
to be damaged or broken, contact SCA Customer
Service at 1 866 722 8675, for North America. For
Europe please contact your SCA representative
FCC:
Changes or modications to the equipment not expressly approved by
the party responsible for compliance could void the user’s authority to
operate the equipment.
Important:
Save this instruction manual for future reference.
If any changes to the installation are necessary, please contact SCA for
support. No modication of this equipment is allowed. Tork EasyCubeTM
must be returned to SCA after the end of its service life.
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may
cause undesired operation.
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against arm-
ful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interfer-
ence to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, the user is encouraged to contact SCA for support.
Le présent appareil est conforme aux CNR d’Industrie Canada appli-
cables aux appareils radio
exempts de licence. L’exploitation est autorisée aux deux conditions
suivantes :
1) l’appareil ne doit pas produire de brouillage;
2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est
susceptible d’en compromettre le fonctionnement.
Industrie Canada ICES-003 Étiquette de conformité:
CAN ICES-3 (A) / NMB-3 (A).
Computer, server device or smartphone not included.
The Tork EasyCube application can be accessed from
any available connected device.
Devices shown are not the actual size.
IC:
This device complies with Industry Canada’s licence-exempt RSSs.
Operation is subject to the following two conditions:
(1) This device may not cause interference; and
(2) This device must accept any interference, including interference
that may cause undesired operation of the device.
Industry Canada ICES-003 Compliance Label:
CAN ICES-3 (A)/NMB-3(A)
Manufactured by SCA
SE-405 03 Göteborg, Sweden
www.sca-tork.com
Made in Sweden (sensors, data collection units,
visitor registration units),
Made in Poland (foam soap in stainless)
Made in China (foam soap in plastic)
Manufactured for
SCA Tissue North America LLC
Philadelphia, PA 19104
www.torkusa.com
Version A 5.1 Radio
Frequenzy 2.405 GHz
Radio Standard IEEE 802.15.4
5.2 DCU
Power adapter Input: 90-264V AC,
Output: 5V DC, 1.2A
Battery 3.6V, 4.4Ah
Battery backup Up to 10 hours
Internet connection GPRS
Dimensions 188 x 188 x 33mm / 7.4 x 7.4 x 1.3 inches
5.3 VRU
Sensors Infrared (IR)
Battery 3.6V, 2.1Ah
Dimensions 158 x 23 x 23mm / 6.2 x 0.9 x 0.9 inches
5.2 SCU
Sensors Light
Battery 3V, 500mAh
Dimensions 62 x 50 x 6mm / 2.4 x 2.0 x 0.2 inches
