Users Manual

UserManual



BluetoothReceiver‐UNIFY

Brandname:ETEKCITY

FCCID:2AB22UNIFY



ProductPresentation

Thankyouverymuchforpurchasingourproduct.Thisproductisonemodelcontainingfaddishdesign,supportsBluetooth

wirelessreceivingandstereooutputfunction,canbringBluetoothfunctiontosimplespeakersorhometheaterandotherdevices,let

youenjoywirelessmusic.

Pleasereadthefollowinginstructionscarefullybeforeoperating.Keepthemsafeforfuturereference.





1. MFB multi-function button 2. Working station indicator

3. Audio output 3.5 mm jack plug 4. MICRO USB DC In port

ProductFeatures

●BluetoothStandard4.0,StrongCompatibility

●StereoSoundOutput

●Built‐inLithiumBattery,ConvenientforUse

●3.5mmAudioOutputInterface,WidelyUse

●Exquisite&FashionableFacade



TechnicalParameters

● StereoOutput,2.0ChannelSound

● BluetoothStandard:V4.0

● SupportFunction:A2DP,AVRCP,etc.

●WorkingRange:8‐10M

●FrequencyResponse:30Hz‐20KHz

●ExternalPower:DC5V200mA

●Built‐inLithiumBattery:3.7V200mAH

●Playtime:10hours

●Dimensions:48x48x24mm

Specification

Charge

Under off state, connected external power 5V by micro USB cable, lamp of indicator lights in red. When finish,

lamp turns off.

*It has built-in rechargeable lithium battery. Before use, please charge up firstly.

Before operating, please connect receiver and speaker by 3.5mm audio cable.

On/Off

Long press MFB button when off, lamp of working indication light, it’s on.

Long press MFB button when on, lamp of working indication extinguish, it’s off.

How to Operate

·Pair： It is necessary for external equipments to pair this product in the first operation. Operate as below：

Off state, long press MFB button for 3-4 seconds until lamp in red and blue flicker slowly, enter pairing status.

Please search for Bluetooth device until find out “UNIFY”, select it, lamp in blue will flash once at intervals.

It means pairing successfully.（Note：if the pass code is required, enter "0000".）

*Under on state, you can short press MFB twice to re-enter pairing mode to connect other Bluetooth devices.

·Connect automatically: It will pair Bluetooth devices which have paired last time. If devices out of range,

please follow above instructions to re-enter pairing status.

*If it doesn’t connect any external devices for a long time, it will shut off automatically. Please restart.

·Operate: After paired, you can play/pause music through mobile phone, or receiver by short pressing MFB button.

Low Power Warning

The indicator light will flash at intervals in red twice when power is too low to alarm user to charge up.

InstructiononProductSafetyMaintenance

●Donotplacethisproductunderthehigh‐temperatureanddamp

environment,evenmakeitbecaughtintherainorimpactedbystrongforce.

●Ifthisproductsmokesorencounters

otherexceptions,plugofftheDC‐USBpowercablepluginstantly.

Toavoidaccidents,pleasecontactthelocalfranchiserordialtheservicecallofCOOXforrepair.

●Theaudiosignalcableandpowercablecannotbepulled,tied,extruded,trampledorsuspendedwithheavyobjects,toavoid

damagingtheinsulationlayeroftheaudiosignalcableandUSBpowercable,whichwillleadtoshortcircuitorbadcontact.

●Pleasedisconnectpoweradapter,ifnonuseforalongtime.

●Bluetoothfunctioncanbecompatiblewithcommonsmartphonesandtablets,buttheremaybesomedifferencesoncemake

useofsomespecialdevicesorapplicationprogram.Somefunctionsmaybenotsupported.



Thisproductismadewithhigh‐qualitymaterialsandcomponentswhichcanberecycledforreuse.Iftheproductpackageincludesa

crossandtherecyclingboxsymbol,thentheyshouldbeprocessedaccordingtoyourlocalregulations,donotdiscardthisproductsas

commonhouseholdrubbish.





PackageList

● UNIFYBluetoothreceiver……………………………………………1unit

● Usermanual………………………………………………………1copy

● 3.5mmStereoAudioCable…………………………………………1piece

● CableofstandardUSBtomicroUSB………………………………1piece



*Ifthematerialsinsidethepackagearenotconsistentwiththeaccompaniedlist,pleasecontactthemanufacturerorretailseller

whoyoupurchasedtheunitfrom.



This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference

that may cause undesired operation.

Changes or modifications to this unit not expressly approved by the party responsible for compliance

could void the user's authority to operate the equipment.
