Etiger Digital Technology A0-CL01 Lamp Speaker System User Manual Introduction
SHANGHAI ETIGER DIGITAL TECHNOLOGY CO., LTD. Lamp Speaker System Introduction
Instruction manual
FCC user guide information:
Radio Frequency Interference Requirements-FCC
Note: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However there is no
guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected
• Consult the dealer or an experienced radio/TV technician for help.
Radio Transmitters (Part 15)
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
FCC RF Exposure Guidelines
Safety Information
Reducing RF Exposure - Use Properly
Only operate the device in accordance with the instructions supplied.
This device complies with FCC radiation exposure limits set forth for an uncontrolled
environment. In order to avoid the possibility of exceeding the FCC radio frequency exposure
limits, human proximity to the antenna shall not be less than 20cm
(8 inches) during normal operation.
Introduction
Thanks for purchasing Cosmic LED Bluetooth Speaker. It’s a Bluetooth speaker with LED light
with 2.4G RF remote control for multidirectional control. Enjoy it!
Caution
1. Please read, follow and keep these instructions.
2. Heed all warnings on the product and in the operation instructions.
3. Do not use accessories that are not recommended by the product manufacturer.
4. Keep the device out of extreme heat and humidity. Don’t use the product near a heater,
stove, or any other source of heat
5. Do not use the device near water, such as sinks, bathtubs, swimming pools, washing
machines, tubs of water, etc.
6. If cleaning is required, use a soft dry cloth, before clean, unplug the product from the
electrical source.
7. Do not use the device during lighting storm, turn the power off to prevent damage to the
product due to lighting and power-line surges. For best protection against lightning, unplug
the product from its power source in the event of storm.
8. Don’t open the device to avoid electronic shock.
9. The speaker has a wireless range of up to 10M, but wireless performance may be affected
in different operating environment.
10. Place the product stable, as any fall may damage the product or cause bodily harm
11. Don’t block any opening on the product. Never push any objects into the openings or
slots on the product. Doing so may create electric shock or fire hazard. Maintain sufficient
distance around your product for sufficient ventilation.
12. Avoid stepping on the power cord or pinching it.
13. Repair must be performed by a qualified technician
14. For lamps with a weight significantly higher than that of the lamps for which they are
replacement, attention should be drawn to the fact that the increased weight may reduce the
mechanical stability of certain luminaires and lamp holders and may impair contact making
and lamp retention.
15. CAUTION: danger of explosion if battery is incorrectly replaced. Replace only with the
same or equivalent type.
Risk of swallowing batteries! The remote control contains a button type battery, which can be
swallowed. Keep the battery out of reach of children at all times! If swallowed, the battery
can cause serious injury or death. Severe internal burns can occur within two hours of
ingestion
Indicates that the marked item can be hot and should not be touched without taking
care
What’s in the box?
1x Cosmic LED Bluetooth Speaker - 1x Remote control - 2x Adapters (1x B22, 1x E14) –
Instruction Manual in different languages
Structure of speaker
Standard E27 + 2 adapters
Speaker and LEDs
Speaker connection
1. Take the speaker, remote control, instruction manual out of your package.
2. Before installing Cosmic speaker in your lamp system, turn the power off (don’t use an
external dimmer switch).
3. Screw Cosmic speaker into the socket, turn the power on, the light will be lit. There are 3
levels of light intensity: On(100%), 50%, Off, you can change it by remote control.
4. Activate Bluetooth on your music player (smartphone, tablet, etc.), search for new
Bluetooth devices.
5. Select “A0-CL01 Cosmic” in the Bluetooth devices list (make sure the speaker is in pairing
mode), when the devices status is paired, your device is ready for use.
6. Play music on your audio source and make sure the volume output is activated.
7. Adjust the audio volume up/down to your desired level.
Note:
1. If you want to connect to another audio player when the speaker is working, press and hold
Bluetooth pairing button on remote control for 5 seconds until blue LED starts its fast
blinking (pairing mode). And follow up from step 5 above.
2. There is Bi-color LED for Bluetooth, volume control and mute indication: Fast blinking
blue for pairing; red for mute; Blue and red will flash alternately when you adjust volume,
and it will become solid blue when the volume is at Max or Min.
Specification
Input power: 100-240V
Audio output: 11W mono, 10% THD
Light intensity: 7.6W LED
Light bulb socket: E27 + Adapters (B22, E14)
Color temp: warm white 3200k
LED beam angle: 120 degrees
Speaker: 2inch
Product dimensions: 85 x 85 x 150mm
Lamp Speaker System FCC ID:2AAUHA0-CL01
Remote control FCC ID: 2AAUHA0-RC01REMOTE
