BUILT RUGGED
FOR DEMANDING ENVIRONMENTS.
COMMERCIAL WATER SOFTENING PRODUCT PORTFOLIO
Everpure Japan LLC
Hashimoto MN Bldg. 7F
3-25-1 Hashimoto Sagamihara-Shi
Kanagawa 229-1103
JAPAN
TEL: 81.(0)42.775.3011
FAX: 81.(0)42.775.3015
Everpure Europe B.V./B.A.
Industriepark Wolfstee
Toekomstlaan 30
B-2200 Herentals
BELGIUM
TEL: +32.(0).14.283.500
FAX: +32.(0).14.283.505
Everpure, LLC
1040 Muirfield Dr.
Hanover Park, Illinois 60133
U.S.A.
TEL: 800.323.7873 (US only)
TEL: 630.307.3000
FAX: 630.307.3030
E-MAIL: info@everpure.com
Worldwide Headquarters
In Europe
In Japan
www.everpure.com
www.pentair.com
EV701346-0507
Commercial
Water Softening Commercial Water Softening
3
What a water softener does not do. Water softeners are cation exchangers
meaning they will exchange positive ions such as calcium, magnesium, iron,
copper, zinc, manganese, and other metals.Water softeners to not filter
water,they merely exchange hardness ions for sodium ions. Sediment,
chemicals and organics that can affect the appearance, taste and odor of
your water are not affected by softening your water. For these, you should
consider an Everpure filtration system, or an Everpure reverse osmosis system.
WHY SOFTEN YOUR WATER?
WHY CHOOSE AN EVERPURE COMMERCIAL SOFTENER?
Water Grains/Gallon mg/L or ppm
Soft <1.0 0 - 17.1
Slightly Hard 1.0 to 3.5 17.1 - 60
Moderately Hard 3.5 to 7.0 60 - 120
Hard 7.0 to 10.5 120 - 180
Very Hard>10.5 180+
Everpure, a division of Pentair Water, is the
worldwide leader in foodservice water
treatment solutions.
Everpure is the worldwide leader in foodservice water treatment
solutions and water management. Since 1933, our total focus has
been water.We've dedicated ourselves to understanding water
and how it affects your business.We've applied ourselves to
developing innovative and effective treatment solutions to ensure
the best quality water anywhere.And we've committed ourselves
to providing the absolute best service.
Quality
Our water softeners feature components from other Pentair Water
divisions representing some of the most well-known brands in their
respective industries, including:
Fleck Control Valves are world-renowned for superior quality
and extra-long service life. For over 50 years, they've led the
way in advancing technology for commercial and industrial
water treatment markets, and today they are the leader in water
treatment controls.
Structural leads the industry with highly advanced manufacturing
facilities and over 40 years of experience.They invented composite
pressure vessels, and were among the first to use fiberglass-
reinforced plastic in their patented manufacturing process.
Selection
We offer a full line of commercial water softeners, from small under
counter systems for point-of-use espresso applications, to large
softeners with flow rates of 165 gallons per minute and more than
750,000 grains of hardness removal capacity, ideally suited for retail
superstores and other whole facility applications.
Installation and Support
Our service network is made up of
companies who will ensure that
your softener system is installed
professionally and efficiently. Product failures are very limited,
due to the smart design and superior quality of our products.
However, when issues do arise, our Technical Support Team and
our Everpure Water Auth2ority Dealer Network will provide a
quick resolution.
Warranty
Everpure water softener systems are warranted to be free from defects in material and/or workmanship under normal use and
service for a period of five (5) years from the date of shipment from our plant. When issues arise, you can simply call Everpure’s
Service Hotline at 800.323.7873.
Features and Benefits
lBacked by Everpure's customer service,
installation and service teams
lHardness removal from 7,500 to
750,000 grains
lMeter initiated regeneration minimizes
salt, water and electrical costs
lAdvanced user-friendly controls that are
simple to service
lFiberglass reinforced resin vessels with
NSF approved polyethylene liners
eliminate worries about corrosion
Applications
lEspresso
lWarewashing
lReverse Osmosis
Pre-treatment
lC-stores
lLaundry
lWater Heater Scale
Prevention/Reduction
lFood Service
lGrocery
lBoiler Scale Control
lRetail
Everpure filtration system,
WATER CONDITIONER
CES SERIES
750,000 grains of
hardness removal
Flow rate up to 165 GPM
WATER CONDITIONER
CES SERIES
100,000 grains of
hardness removal
Flow rate up to 20 GPM
7,500 grains of
hardness removal
Flow rate up to 3 GPM
WATER CONDITIONER
WS SERIES
2
Quality water is vital to your operation.
There are contaminants in nearly all water that over time affect
the efficiency of your plumbing and your water-using equipment.
Water is a natural solvent, and as it passes through soil and
limestone it picks up minerals.These minerals make water “hard”,
and hard water can wreak havoc on water heaters, pipes, faucets,
toilets, laundry, dishwashers, coffee brewers and other equipment
that use water. Common culprits for causing hard water are
calcium and magnesium.
Calcium and magnesium, when evaporated from water or
combined with heat, can form hard, chalky deposits known as
limescale.These deposits can clog pipes, reducing flow, and coat
heating elements, requiring more energy to heat water.Your
operation loses efficiency, and your maintenance and energy costs rise.
The Ion Exchange Process
Water softeners can remove dissolved calcium and magnesium through a process known as “ion exchange”. Systems consist of
two tanks: a resin tank and a brine tank.The resin tank contains a bed of negatively charged cation resin (small plastic beads), that
are coated with sodium ions (Na+).As hard water passes through this bed, the positively charged calcium (Ca++) and magnesium
(Mg++) ions exchange with sodium ions and are captured by the beads,
causing the sodium to release into the water. Since the sodium in the
water is harmless to plumbing and equipment, this “soft” water is now
ready for use by your operation.
During the exchange process, the sodium charge eventually depletes.
When near depletion, the softener is regenerated to recover the
exchange capacity. High concentration sodium chloride solution is drawn
from the brine tank and passed through the resin bed.The positively
charged sodium ions in the solution displace the calcium and magnesium
ions, releasing them back into the solution.These hardness ions are then
flushed down the drain. .
Measuring Grains of Hardness
Hardness of water is measured in grains per gallon (GPG) or sometimes
in parts per million (PPM). One GPG equals 17.1 ppm (Mg/l). Generally
water with GPG of 7 or more is considered hard. In certain foodservice
applications this level of hardness can be less than seven (7).To determine
the hardness of your water, it can be tested using simple test strips or a
titration drop test. Everpure can provide an analysis of your water to
determine the correct water treatment solution for your operation.
CALCIUM
SODIUM CHLORIDE
IRON
MAGNESIUM
RESIN
BEADS
RESIN BED
Mg 2
+
Mg 2
+
Fe 2
+
Fe 2
+
Ca 2
+
Ca 2
+
Na
+
Na
+
Na
+
Na
+
Na
+
Na
+
Na
+
Na
+
Na
+
HARD WATER
SODIUM CHLORIDE
TO DRAIN
HARD MINERALS
DISPLACE SODIUM
CHLORIDE ON
RESIN BEADS
EXHAUSTED RESIN
BEADS READY FOR
REGENERATION
Mg 2
+
Mg 2
+
Fe 2
+
Fe 2
+
Ca 2
+
Ca 2
+
Na
+
Na
+
Na
+
Na
+
Na
+
Na
+
Na
+
Na
+
Na
+
Mg 2
+
Mg 2
+
Fe 2
+
Fe 2
+
Ca 2
+
Ca 2
+
Na
+
Na
+
Na
+
Na
+
Na
+
Na
+
Commercial Water Softening
5
WE HAVE A SOFTENER FOR YOUR APPLICATION.
Flow rates of 3 GPM or less.
If space is an issue, or your situation requires a point-of-use (POU) softener system, we can
provide a system to meet your needs.
Space Saving Softeners
Need an under counter softener for your espresso machine? Or a small footprint softening system
for your warewashing machine? We can help.We can provide softening systems that are designed
especially for operations with space restrictions, or specialty applications requiring hardness
removal as low as 7,500 grains.
Cabinet Softeners
WS Series
Single Tank Water Conditioner
l1”porting
lHardness removal of 30,000 to 45,000 grains
lFlow rates of up to 12 gallons per minute continuous
lMeter initiated regeneration
lEasily adjustable 5-cycle control
Designed for operations with low volume
soft water usage and limited space:
lPoint of use applications including warewashing and espresso
lBoiler scale control
lSpecialty coffee
High Performance Fleck Control Valves
We offer Fleck valves. Fleck is the worldwide
leader in water softening controls, and is renowned
for reliability and performance.
lMachined with state-of-the-art tools.
lTime-tested technology.
lAdvanced user-friendly controls incorporate two
time-tested hydraulically balanced pistons to
independently pilot service flow and regeneration
(available on some models).
lDesigned to withstand rigorous fatigue testing,
passing 250,000 pressure cycles at up to 190 psi,
as well as 10,000 complete regeneration
cycles. That's the equivalent of 27 years of
uninterrupted daily use.
Easy to Service, With
Low Maintenance
lEasy, friendly programming.
lA single moving part in contact
with the water, the piston,
lowers maintenance.
lSelf cleaning. Teflon coating
prevents stickiness that results
from precipitated calcium,
magnesium and other dissolved
minerals. With each regeneration,
a full stroke against the seals
wipes the piston clean.
Efficient Operation
lMeter initiated regeneration
minimizes salt, water and
electrical costs.
lMeters are made of lead-free
brass or tough, corrosion
resistant plastic.
The Ideal Pressure Tanks
Our pressure vessels offer
tremendous strength and durability,
for maximum reliability.
lFiberglass reinforced resin vessels
with polyethylene liners eliminate
worries about corrosion.
lEndured 250,000 cycle testing
without leakage.
lMeets NSF design parameters
(minimum burst at 600 psi).
Available as Duplex
Alternating System
Alternating tank configurations
provide continuous soft water
supply and reduced salt usage.
Heavy Duty Brine Tanks
Constructed from quality FDA
approved materials,our tanks are
built to withstand the rigors of
commercial environments.
lRigid, high-impact, non-toxic
polyethylene provides exceptional
resistance to stress cracks.
lQuality production technology
for years of trouble free
performance.
5-year Limited Warranty
on Complete System
Our water softening systems are
warranted to be free from defects
in material and/or workmanship
under normal use and service for
a period of five (5) years from the
date of shipment from our plant.
See warranty for complete details.
Backed by Everpure,
the Leading Brand in
Commercial Water
Treatment
Since 1933, Everpure has been
providing water treatment solutions
for foodservice and other commercial
industries. Our water softening line
of products is another example of
our commitment to providing the
highest quality products to solve your
water problem.
Exceptional Service
and Support
We provide the complete package
of professional services, from
sizing, installation, servicing and
technical support.
Wide Range of Sizes and
Configurations
Models available from point-of-use under
counter softeners to large systems for
high volume operations.
QUICK REFERENCE
Model Part
Number Tank
Rated
Capacity
(grains)
Service Flow Rate Pipe
Size
(in)
Resin
Volume
(ft3)
Per
Tank
System
Dimensions* Brine Tank
Salt Capacity
(lbs)
Ship
Wt
(lbs)
Continuous
@ 15 PSI DP
(gpm)
Intermittent
@ 15 PSI DP
(gpm)
WXDXH
(inches)
WS-7.5 EV9980-17 Single 7,500 3 5 .75 .25 11x11x28 25 25
WS-30 EV9980-10 Single 30,000 10.0 14 1 1 13x22x45 300 90
WS-45 EV9980-11 Single 45,000 12.0 16 1 1.5 37x22x68 335 125
Need a point of use softening solution for a specialty coffee application?
Consider our unique It features ion
exchange softening, pH buffering and carbon filtered water. The benefits include
reduced hardness, chlorine and off tastes and odors.The pH buffering prevents
water from becoming too acidic. Available in systems from 4,100 up to 21,200
grains of capacity.
3-stage blending quick change cartridge system.
4
Specifications
*When determining system space requirements, refer to spec sheet for physical arrangement. Installations
requiring re-arrangement of tanks, or separation of tanks, may need additional clearance.
Model Part
Number Tank
Rated
Capacity
(grains)
Service Flow Rate
Pipe
Size
(in)
Resin
Volume
(ft3)
Per
T
ank
System
Dimensions* Brine
T
ank
Salt Capacity
(lbs)
Ship
Wt
(lbs)
Continuous
@ 15 PSI DP
(gpm)
Intermittent
@ 25 PSI DP
(gpm)
W X D X H
(inches)
CES-2850M-68 EV9983-21 Single 68,000 27 35 1.5 2 37x23x63 425 200
CES-2850M-102 EV9983-22 Single 102,000 32 42 1.5 3 45x28x74 750 290
CES-2850M-136 EV9983-23 Single 136,000 34 44 1.5 4 46x28x74 750 360
CES-2850M-171 EV9983-24 Single 171,000 37 48 1.5 5 49x28x77 750 450
CES-9500M-68 EV9986-00 Twin 68,000 25 32 1.5 2 56x23x63 425 360
CES-9500M-101 EV9986-01 Twin 101,000 28 36 1.5 3 64x28x74 750 520
CES-9500M-135 EV9986-02 T
win 135,000 30 39 1.5 4 66x28x74 750 660
CES-9500M-169 EV9986-03 Twin 169,000 31 40 1.5 5 73x28x77 750 840
Commercial
Water Softening Commercial Water Softening
7
WE HAVE A SOFTENER FOR YOUR APPLICATION.
WE HAVE A SOFTENER FOR YOUR APPLICATION.
6
Flow rates up to 37 GPM.
Flow rates up to 20 GPM.
CES 2750 Series
Single Tank Water Conditioner
l1”porting
lHardness removal of 34,000 to 101,000 grains
lFlow rates of up to 20 gallons per minute continuous
lMeter initiated regeneration
lEasily adjustable 5-cycle control
Designed for operations with low volume soft water usage:
lPoint of use applications including warewashing and espresso
lBoiler scale control
lC-Stores
lSpecialty coffee
Model Part
Number Tank
Rated
Capacity
(grains)
Service Flow Rate
Pipe
Size
(in)
Resin
Volume
(ft3)
Per
Tank
System
Dimensions* Brine Tank
Salt Capacity
(lbs)
Ship
Wt
(lbs)
Continuous
@ 15 PSI DP
(gpm)
Intermittent
@ 25 PSI DP
(gpm)
W X D X H
(inches)
CES-2750M-34 EV9982-21 Single 34,000 16 20 1 1 34x23x65 425 120
CES-2750M-51 EV9982-22 Single 51,000 17 22 1 1.5 35x23x71 425 150
CES-2750M-68 EV9982-23 Single 68,000 19 25 1 2 37x23x69 425 190
CES-2750M-101 EV9982-24 Single 101,00020 26 1 3 45x28x82 750 280
CES-9000M-34 EV9985-00 Twin 34,000 14 18 1 1 48x23x57 425 200
CES-9000M-51 EV9985-01 T
win 51,00014 18 1 1.5 49x23x64 425 260
CES-9000M-68 EV9985-02 Twin 68,000 15 20 1 2 51x23x62 425 330
CES-9000M-101 EV9985-03 T
win 101,00016 20 1 3 63x28x74 750 500
CES 2850 Series
Single Tank Water Conditioner
l1.5”porting
lHardness removal of 68,000 to 171,000 grains
lFlow rates of up to 37 gallons per minute continuous
lMeter initiated regeneration
lEasily adjustable 5-cycle control
Designed for operations with low to medium volume soft water usage:
lFull service restaurants
lC-stores
CES 9000 Series
Twin Tank Water Conditioner
l1”porting
lAlternating twin tank design for continuous soft water supply
and reduced salt usage
lHardness removal of 34,000 to 101,000 grains
lFlow rates of up to 16 gallons per minute continuous
lMeter initiated regeneration
lEasily adjustable 5-cycle control
Designed for operations with low volume soft water
usage, and requiring continuous flow with no
regeneration interruption:
lAll night C-stores
lBoiler feed
lContinuous operation-type equipment
CES 9500 Series
Twin Tank Water Conditioner
l1.5”porting
lAlternating twin tank design for continuous soft water supply
and reduced salt usage
lHardness removal of 68,000 to 169,000 grains
lFlow rates of up to 31 gallons per minute continuous
lMeter initiated regeneration
lEasily adjustable 5-cycle control
Designed for operations with low to medium volume
soft water usage,and requiring continuous flow with
no regeneration interruption:
l24-hour restaurants lVehicle wash
lBoiler feed lLinen care
High levels of dissolved (ferrous) iron and manganese (>5 ppm)
can damage your softening resin.To prolong the lifespan of
your water softener when these minerals are excessive, we
recommend a prefilter. Also, use a salt that contains an iron
“fighting”additive, or use a resin cleaner on a regular basis.
Salt Recommendation. Use a high quality salt,
labeled for use in water softeners. Solar salt is
recommended. Pellet can also be used if solar
salt is not available. Rock salt is not recommended,
due to the higher level of impurities it may contain.
*When determining system space requirements,refer to spec sheet for physical arrangement. Installations
requiring re-arrangement of tanks, or separation of tanks, may need additional clearance.
*When determining system space requirements, refer to spec sheet for physical arrangement. Installations
requiring re-arrangement of tanks, or separation of tanks, may need additional clearance.
Commercial
Water Softening Commercial Water Softening
9
WE HAVE A SOFTENER FOR YOUR APPLICATION.
WE HAVE A SOFTENER FOR YOUR APPLICATION.
8
Flow rates up to 145 GPM.
Flow rates up to 73 GPM.
CES 2900 Series
Single Tank Water Conditioner
l2”porting
lHardness removal of 136,000 to 512,000 grains
lFlow rates of up to 73 gallons per minute continuous
lMeter initiated regeneration
lEasily adjustable 5-cycle control
Designed for operations with high volume soft water usage:
lFull service restaurants
lRetail superstores - hot side only
CES 2900DA Series
Duplex Alternating Twin Tank Water Conditioner
l2”porting
lDuplex Alternating twin tank configuration for continuous soft
water supply and reduced salt usage
lHardness removal of 136,000 to 512,000 grains
lFlow rates of up to 73 gallons per minute continuous
lMeter initiated regeneration
lEasily adjustable 5-cycle control
Designed for operations with high volume soft water
usage,and requiring continuous flow with no
regeneration interruption:
lFull service 24-hour restaurants l Linen care
lV
ehicle wash
The salt in the brine tank should not fall below 30%. After the water softener
has been in service for a period of time, a salt usage pattern should develop,
and a schedule for replenishment of salt can be determined. When adding
salt, the brine tank can be filled completely.
Flow rates up to 165 GPM.
CES 3900 Series
Single Tank Water Conditioner
l3”porting
lHardness removal of 750.000 grains
lFlow rates of up to 165 gallons per minute continuous
lMeter initiated regeneration
lEasily adjustable 5-cycle control
Designed for operations with high volume soft
water usage:
lRetail superstores
lWhole facility applications
CES 2900DP Series
Duplex Parallel Twin Tank Water Conditioner
l2”porting
lDuplex Parallel twin tank configuration for continuous soft
water supply and reduced salt usage
lHardness removal of 136,000 to 512,000 grains per tank
lFlow rates of up to 145 gallons per minute continuous
lMeter initiated regeneration
lEasily adjustable 5-cycle control
Designed for operations with low to medium volume
soft water usage:
lWhole stores lC-store vehicle wash
lHotel/Motel
Do you know what's in your water? Determining
the quality of your water is the first step to
applying the correct water treatment.
Hardness, chemicals, total dissolved
solids and sediment can all impact
your operation. We can analyze your
water, and your unique situation, and
recommend the right mix of products
to ensure your water is exactly as it should be.
Model Part
Number T
ank
Rated
Capacity
(grains)
Service Flow Rate Pipe
Size
(in)
Resin
Volume
(ft3)
Per
Tank
System
Dimensions* Brine
T
ank
Salt Capacity
(lbs)
Ship
Wt
(lbs)
Continuous
@ 15 PSI DP
(gpm)
Intermittent
@ 25 PSI DP
(gpm)
W X D X H
(inches)
CES-2900E-136-DP EV9984-42 Twin 136,000 94 121 2 4 64x28x79 750 460
CES-2900E-171-DP EV9984-43 Twin 171,000 106 137 2 5 70x28x82 750 880
CES-2900E-239-DP EV9984-44 T
win 239,000 114 148 2 7 81x34x82 1,200 1,210
CES-2900E-341-DP EV9984-45 Twin 341,000 123 159 2 10 87x34x89 1,200 1,750
CES-2900E-512-DP EV9984-46 Twin 512,000 145 188 2 15 99x34x97 1,500 2,750
CES-3900E-341 EV9980-32 Single 341,000 74 96 3 10 61x34x93 1,200 960
CES-3900E-512 EV9980-33 Single 512,000 100 129 3 15 66x34x97 1,500 1,470
CES-3900E-682 EV9980-34 Single 682,000 105 136 3 20 82x43x99 2,200 2,010
CES-3900E-853 EV9980-35 Single 853,000 165 213 3 25 87x43x89 2,600 2,970
*When determining system space requirements, refer to spec sheet for physical arrangement. Installations
requiring re-arrangement of tanks, or separation of tanks, may need additional clearance.
*When determining system space requirements, refer to spec sheet for physical arrangement. Installations
requiring re-arrangement of tanks, or separation of tanks, may need additional clearance.
Model
Part
Number T
ank
Rated
Capacity
(grains)
Service Flow Rate
Pipe
Size
(in)
Resin
Volume
(ft3)
Per
Tank
System
Dimensions* Brine Tank
Salt Capacity
(lbs)
Ship
Wt
(lbs)
Continuous
@ 15 PSI DP
(gpm)
Intermittent
@ 25 PSI DP
(gpm)
W X D X H
(inches)
CES-2900M-136 EV9984-22 Single 136,00047 60 2 4 46x28x79 750 360
CES-2900M-171 EV9984-23 Single 171,000 53 69 2 5 49x28x82 750 460
CES-2900M-239 EV9984-24 Single 239,000 57 74 2 7 57x34x82 1,200 630
CES-2900M-341 EV9984-25 Single 341,00062 80 2 10 61x34x89 1,200 920
CES-2900M-512 EV9984-26 Single 512,000 73 94 2 15 66x34x97 1,500 1,420
CES-2900E-136-DA EV9984-32 Twin 136,000 47 60 2 4 64x28x79 750 460
CES-2900E-171-DAEV9984-33 T
win 171,00053 69 2 5 70x28x82 750 870
CES-2900E-239-DAEV9984-34 T
win 239,000 57 74 2 7 81x34x82 1,200 1,200
CES-2900E-341-DA EV9984-35 Twin 341,000 62 80 2 10 87x34x89 1,200 1,740
CES-2900E-512-DAEV9984-36 T
win 512,00073 94 2 15 99x34x97 1,500 2,750
7 - 10
Hardness
Range
26-30
21-25
30 45 34 51 68 101 34 51 68 101 68 102 136 171 68 101 135 169 136 171 239 341 512 136 171 239 341 512 341 512 682 853
10000 0.1 0.2 0.1 0.2 0.2 0.4 0.1 0.2 0.2 0.4 0.2 0.4 0.5 0.6 0.2 0.4 0.5 0.6 0.5 0.6 0.9 1.2 1.8 0.5 0.6 0.9 1.2 1.8 1.2 1.8 2.4 3.0
5000 0.2 0.3 0.2 0.4 0.5 0.7 0.2 0.4 0.5 0.7 0.5 0.7 1.0 1.2 0.5 0.7 1.0 1.2 1.0 1.2 1.7 2.4 3.7 1.0 1.2 1.7 2.4 3.7 2.4 3.7 4.9 6.1
4000 0.3 0.4 0.3 0.5 0.6 0.9 0.3 0.5 0.6 0.9 0.6 0.9 1.2 1.5 0.6 0.9 1.2 1.5 1.2 1.5 2.1 3.0 4.6 1.2 1.5 2.1 3.0 4.6 3.0 4.6 6.1 7.6
3000 0.4 0.5 0.4 0.6 0.8 1.2 0.4 0.6 0.8 1.2 0.8 1.2 1.6 2.0 0.8 1.2 1.6 2.0 1.6 2.0 2.8 4.1 6.1 1.6 2.0 2.8 4.1 6.1 4.1 6.1 8.1 10.2
2000 0.5 0.8 0.6 0.9 1.2 1.8 0.6 0.9 1.2 1.8 1.2 1.8 2.4 3.1 1.2 1.8 2.4 3.0 2.4 3.1 4.3 6.1 9.1 2.4 3.1 4.3 6.1 9.1 6.1 9.1 12.2 15.2
1500 0.7 1.1 0.8 1.2 1.6 2.4 0.8 1.2 1.6 2.4 1.6 2.4 3.2 4.1 1.6 2.4 3.2 4.0 3.2 4.1 5.7 8.1 12.2 3.2 4.1 5.7 8.1 12.2 8.1 12.2 16.2 20.3
1000 1.1 1.6 1.2 1.8 2.4 3.6 1.2 1.8 2.4 3.6 2.4 3.6 4.9 6.1 2.4 3.6 4.8 6.0 4.9 6.1 8.5 12.2 18.3 4.9 6.1 8.5 12.2 18.3 12.2 18.3 24.4 30.5
800 1.3 2.0 1.5 2.3 3.0 4.5 1.5 2.3 3.0 4.5 3.0 4.6 6.1 7.6 3.0 4.5 6.0 7.5 6.1 7.6 10.7 15.2 22.9 6.1 7.6 10.7 15.2 22.9 15.2 22.9 30.4 38.1
600 1.8 2.7 2.0 3.0 4.0 6.0 2.0 3.0 4.0 6.0 4.0 6.1 8.1 10.2 4.0 6.0 8.0 10.1 8.1 10.2 14.2 20.3 30.5 8.1 10.2 14.2 20.3 30.5 20.3 30.5 40.6 50.8
400 2.7 4.0 3.0 4.6 6.1 9.0 3.0 4.6 6.1 9.0 6.1 9.1 12.1 15.3 6.1 9.0 12.1 15.1 12.1 15.3 21.3 30.4 45.7 12.1 15.3 21.3 30.4 45.7 30.4 45.7 60.9 76.2
10000 0.1 0.2 0.1 0.2 0.3 0.4 0.1 0.2 0.3 0.4 0.3 0.4 0.6 0.7 0.3 0.4 0.6 0.7 0.6 0.7 1.0 1.5 2.2 0.6 0.7 1.0 1.5 2.2 1.5 2.2 3.0 3.7
5000 0.3 0.4 0.3 0.4 0.6 0.9 0.3 0.4 0.6 0.9 0.6 0.9 1.2 1.5 0.6 0.9 1.2 1.5 1.2 1.5 2.1 3.0 4.5 1.2 1.5 2.1 3.0 4.5 3.0 4.5 5.9 7.4
4000 0.3 0.5 0.4 0.6 0.7 1.1 0.4 0.6 0.7 1.1 0.7 1.1 1.5 1.9 0.7 1.1 1.5 1.8 1.5 1.9 2.6 3.7 5.6 1.5 1.9 2.6 3.7 5.6 3.7 5.6 7.4 9.3
3000 0.4 0.7 0.5 0.7 1.0 1.5 0.5 0.7 1.0 1.5 1.0 1.5 2.0 2.5 1.0 1.5 2.0 2.4 2.0 2.5 3.5 4.9 7.4 2.0 2.5 3.5 4.9 7.4 4.9 7.4 9.9 12.4
2000 0.7 1.0 0.7 1.1 1.5 2.2 0.7 1.1 1.5 2.2 1.5 2.2 3.0 3.7 1.5 2.2 2.9 3.7 3.0 3.7 5.2 7.4 11.1 3.0 3.7 5.2 7.4 11 .1 7.4 11 .1 14.8 18.5
1500 0.9 1.3 1.0 1.5 2.0 2.9 1.0 1.5 2.0 2.9 2.0 3.0 3.9 5.0 2.0 2.9 3.9 4.9 3.9 5.0 6.9 9.9 14.8 3.9 5.0 6.9 9.9 14.8 9.9 14.8 19.8 24.7
1000 1.3 2.0 1.5 2.2 3.0 4.4 1.5 2.2 3.0 4.4 3.0 4.4 5.9 7.4 3.0 4.4 5.9 7.3 5.9 7.4 10.4 14.8 22.3 5.9 7.4 10.4 14.8 22.3 14.8 22.3 29.7 37.1
800 1.6 2.4 1.8 2.8 3.7 5.5 1.8 2.8 3.7 5.5 3.7 5.5 7.4 9.3 3.7 5.5 7.3 9.2 7.4 9.3 13.0 18.5 27.8 7.4 9.3 13.0 18.5 27.8 18.5 27.8 37.1 46.4
600 2.2 3.3 2.5 3.7 4.9 7.3 2.5 3.7 4.9 7.3 4.9 7.4 9.9 12.4 4.9 7.3 9.8 12.2 9.9 12.4 17.3 24.7 37.1 9.9 12.4 17.3 24.7 37.1 24.7 37.1 49.4 61.8
400 3.3 4.9 3.7 5.5 7.4 11 .0 3.7 5.5 7.4 11 .0 7.4 11.1 14.8 18.6 7.4 11.0 14.7 18.4 14.8 18.6 26.0 37.1 55.7 14.8 18.6 26.0 37.1 55.7 37.1 55.7 74.1 92.7
10000 0.2 0.3 0.2 0.3 0.4 0.6 0.2 0.3 0.4 0.6 0.4 0.6 0.8 1.0 0.4 0.6 0.8 0.9 0.8 1.0 1.3 1.9 2.8 0.8 1.0 1.3 1.9 2.8 1.9 2.8 3.8 4.7
5000 0.3 0.5 0.4 0.6 0.8 1.1 0.4 0.6 0.8 1.1 0.8 1.1 1.5 1.9 0.8 1.1 1.5 1.9 1.5 1.9 2.7 3.8 5.7 1.5 1.9 2.7 3.8 5.7 3.8 5.7 7.6 9.5
4000 0.4 0.6 0.5 0.7 0.9 1.4 0.5 0.7 0.9 1.4 0.9 1.4 1.9 2.4 0.9 1.4 1.9 2.3 1.9 2.4 3.3 4.7 7.1 1.9 2.4 3.3 4.7 7.1 4.7 7.1 9.5 11 .8
3000 0.6 0.8 0.6 0.9 1.3 1.9 0.6 0.9 1.3 1.9 1.3 1.9 2.5 3.2 1.3 1.9 2.5 3.1 2.5 3.2 4.4 6.3 9.5 2.5 3.2 4.4 6.3 9.5 6.3 9.5 12.6 15.8
2000 0.8 1.3 0.9 1.4 1.9 2.8 0.9 1.4 1.9 2.8 1.9 2.8 3.8 4.8 1.9 2.8 3.8 4.7 3.8 4.8 6.6 9.5 14.2 3.8 4.8 6.6 9.5 14.2 9.5 14.2 18.9 23.7
1500 1.1 1.7 1.3 1.9 2.5 3.7 1.3 1.9 2.5 3.7 2.5 3.8 5.0 6.3 2.5 3.7 5.0 6.3 5.0 6.3 8.9 12.6 19.0 5.0 6.3 8.9 12.6 19.0 12.6 19.0 25.3 31.6
1000 1.7 2.5 1.9 2.8 3.8 5.6 1.9 2.8 3.8 5.6 3.8 5.7 7.6 9.5 3.8 5.6 7.5 9.4 7.6 9.5 13.3 18.9 28.4 7.6 9.5 13.3 18.9 28.4 18.9 28.4 37.9 47.4
800 2.1 3.1 2.4 3.5 4.7 7.0 2.4 3.5 4.7 7.0 4.7 7.1 9.4 11 .9 4.7 7.0 9.4 11 .7 9.4 11.9 16.6 23.7 35.6 9.4 11.9 16.6 23.7 35.6 23.7 35.6 47.4 59.2
600 2.8 4.2 3.1 4.7 6.3 9.4 3.1 4.7 6.3 9.4 6.3 9.4 12.6 15.8 6.3 9.4 12.5 15.6 12.6 15.8 22.1 31.6 47.4 12.6 15.8 22.1 31.6 47.4 31.6 47.4 63.1 79.0
10000 0.2 0.3 0.3 0.4 0.5 0.8 0.3 0.4 0.5 0.8 0.5 0.8 1.0 1.3 0.5 0.8 1.0 1.3 1.0 1.3 1.8 2.6 3.9 1.0 1.3 1.8 2.6 3.9 2.6 3.9 5.2 6.6
5000 0.5 0.7 0.5 0.8 1.0 1.6 0.5 0.8 1.0 1.6 1.0 1.6 2.1 2.6 1.0 1.6 2.1 2.6 2.1 2.6 3.7 5.2 7.9 2.1 2.6 3.7 5.2 7.9 5.2 7.9 10.5 13.1
4000 0.6 0.9 0.7 1.0 1.3 1.9 0.7 1.0 1.3 1.9 1.3 2.0 2.6 3.3 1.3 1.9 2.6 3.3 2.6 3.3 4.6 6.6 9.8 2.6 3.3 4.6 6.6 9.8 6.6 9.8 13.1 16.4
3000 0.8 1.2 0.9 1.3 1.7 2.6 0.9 1.3 1.7 2.6 1.7 2.6 3.5 4.4 1.7 2.6 3.5 4.3 3.5 4.4 6.1 8.7 13.1 3.5 4.4 6.1 8.7 13.1 8.7 13.1 17.5 21.9
2000 1.2 1.7 1.3 2.0 2.6 3.9 1.3 2.0 2.6 3.9 2.6 3.9 5.2 6.6 2.6 3.9 5.2 6.5 5.2 6.6 9.2 13.1 19.7 5.2 6.6 9.2 13.1 19.7 13.1 19.7 26.2 32.8
1500 1.5 2.3 1.7 2.6 3.5 5.2 1.7 2.6 3.5 5.2 3.5 5.2 7.0 8.8 3.5 5.2 6.9 8.7 7.0 8.8 12.3 17.5 26.3 7.0 8.8 12.3 17.5 26.3 17.5 26.3 35.0 43.7
1000 2.3 3.5 2.6 3.9 5.2 7.8 2.6 3.9 5.2 7.8 5.2 7.8 10.5 13.2 5.2 7.8 10.4 13.0 10.5 13.2 18.4 26.2 39.4 10.5 13.2 18.4 26.2 39.4 26.2 39.4 52.5 65.6
800 2.9 4.3 3.3 4.9 6.5 9.7 3.3 4.9 6.5 9.7 6.5 9.8 13.1 16.4 6.5 9.7 13.0 16.3 13.1 16.4 23.0 32.8 49.2 13.1 16.4 23.0 32.8 49.2 32.8 49.2 65.6 82.0
600 3.8 5.8 4.4 6.5 8.7 12.9 4.4 6.5 8.7 12.9 8.7 13.1 17.4 21.9 8.7 12.9 17.3 21.7 17.4 21.9 30.6 43.7 65.6 17.4 21.9 30.6 43.7 65.6 43.7 65.6 87.4 109.4
10000 0.4 0.5 0.4 0.6 0.8 1.2 0.4 0.6 0.8 1.2 0.8 1.2 1.6 2.0 0.8 1.2 1.6 2.0 1.6 2.0 2.8 4.0 6.0 1.6 2.0 2.8 4.0 6.0 4.0 6.0 8.0 10.0
5000 0.7 1.1 0.8 1.2 1.6 2.4 0.8 1.2 1.6 2.4 1.6 2.4 3.2 4.0 1.6 2.4 3.2 4.0 3.2 4.0 5.6 8.0 12.0 3.2 4.0 5.6 8.0 12.0 8.0 12.0 16.0 20.1
4000 0.9 1.3 1.0 1.5 2.0 3.0 1.0 1.5 2.0 3.0 2.0 3.0 4.0 5.0 2.0 3.0 4.0 5.0 4.0 5.0 7.0 10.0 15.1 4.0 5.0 7.0 10.0 15.1 10.0 15.1 20.1 25.1
3000 1.2 1.8 1.3 2.0 2.7 4.0 1.3 2.0 2.7 4.0 2.7 4.0 5.3 6.7 2.7 4.0 5.3 6.6 5.3 6.7 9.4 13.4 20.1 5.3 6.7 9.4 13.4 20.1 13.4 20.1 26.7 33.5
2000 1.8 2.6 2.0 3.0 4.0 5.9 2.0 3.0 4.0 5.9 4.0 6.0 8.0 10.1 4.0 5.9 7.9 9.9 8.0 10.1 14.1 20.1 30.1 8.0 10.1 14.1 20.1 30.1 20.1 30.1 40.1 50.2
1500 2.4 3.5 2.7 4.0 5.3 7.9 2.7 4.0 5.3 7.9 5.3 8.0 10.7 13.4 5.3 7.9 10.6 13.3 10.7 13.4 18.7 26.7 40.2 10.7 13.4 18.7 26.7 40.2 26.7 40.2 53.5 66.9
1000 3.5 5.3 4.0 6.0 8.0 11 .9 4.0 6.0 8.0 11 .9 8.0 12.0 16.0 20.1 8.0 11 .9 15.9 19.9 16.0 20.1 28.1 40.1 60.2 16.0 20.1 28.1 40.1 60.2 40.1 60.2 80.2 100.4
3" PIPE
SIZE MODELS
3900 - Single
2850M - Single
2900M - Single
2" PIPE SIZE MODELS
Gallons
Per Day
2750M - Single
WS
9000M - Twin
9500M - Twin
2900E - Twin
1" PIPE SIZE MODELS
1-1/2" PIPE SIZE MODELS
WE ARE WATER.
SELECTION/SIZING GUIDE
10
Whether you need softening, filtration or reverse osmosis, we have a solution.After all, our
entire existence revolves around providing the best, most consistent water anywhere.That's
why so many operations around the world depend on us to solve their water problems.
We don't just offer product, we manage water. Our Everpure Total Water Management™
Program can analyze your water, identify your needs, provide the perfect solution for your
operation, and support it with outstanding customer and technical support.
Contact us at 1-800-323-7873, or visit us at www.everpure.com.
Insurice Twin
Parallel 202 Prefilter Kit
MRS 225
High Flow CSR Triple
Inlines
Everpure Auth2ority®, Everpure Total Water Management™, Everpure®, Fleck® and Structural® are registered trademarks of Pentair, Inc.
Model Selection Guidelines:
1. Test water to determine
hardness and select
appropriate hardness range.
2. Determine gallons per
day usage and select
appropriate row.
3. Determine pipe size and
select models, shown in blue,
for recommended choices.
4. Narrow choices by
determining need for single
or twin tank system.
Single:
Twin:
Recommended choice;
Time between regeneration
is 2 days to 3.5 days
Acceptable choice;
Time between regeneration
is 1.8 days to 4 days
Model not recommended
Recommended choice;
Time between regeneration
is 1 day to 1.5 days
Acceptable choice;
Time between regeneration
is .7 days to 2 days
Model not recommended

Navigation menu
