ZH143-0 Portable Multimedia
Tablet User Manual
1
Content
1. Product Overview………….…………………………………………………………………………………………………………….…………..2
1.1 Front View…………………………………………………………………………………………………………………………………………..2
1.2 Ba ck View ............................................................................................................................................... ...3
1.3 Botton Side........................................................................................................................................ ….....3
1.4 Top Side................................................................................................................................................... ..3
2. Product Features …..………………………………….………………………………………………………………………………….…….…….4
3. Product Speci fica tions.……….……………….……………………………………………………………………………………….…….…….5
4. Appendics ..……………………………………………………………………………………………………………………………………………6-7
2
1. Product Overview
1-1 Front View
Microphone
Front Camera
Status Indicator-Red、Blue、Green
Message Indicator-Orange
IR Sensor
Touch Screen Panel
1
2
3
4
5
6
1
2
3
5
6
4
3
1-2 Back View
Audio Speaker
1-3 Bottom Side
Dock Port
1-4 Top Side
Power Button
1
1
1
1
1
1
1
4
2. Product Features
Disconnecting to a network
Connecting to a network
S
lide
your finger up to
your
Home screen
5
3. Product Specification
Mode Name ZH143-0 (Portable Multimedia Tablet)
Operating System AndroidTM5.0
Display 8
”
(1280x800)
Panel OGS+Direct Bonding
CPU Intel® Atom Z3735D 1.33GHz Quad core
Memory DDR3L 2GB
Storage eMMC 16GB
Wireless Data Network WLAN 802.11 a/b/g/n (Dual Band)
Bluetooth Bluetooth v4.0
Front Camera 1.2M (FF)
Audio Audio speaker 1Wx2
Interface 1x Pogo connector
Button Power Key
Sensor Proximity Sensor
Battery (3.8V, 3070mAH)
Dimensions 224.35*138.20*10.8 (mm)
Weight 388g
Power -05V/3A
Operating environment -0°C to 35°C
