User Manual

$VVHW7UDQVSRQGHU (9$7
OPERATION OF THE TRANSPONDER
1. Remove the baery cap by turning counter-
clockwise;
2. Insert baery to the baery compartment
with posive terminal toward inside;
3. Replace the baery cap and secure it by
turning clockwise;
4. The transponder will beep once when it is
powered up.
5. Now the transponder is ready to be
deployed.
MOUNTING OF THE TRANSPONDER
A matching bracket may be provided for the
transponder.
1. Securely Aach the bracket to a desired
locaon using appropriate methods, such as
magnet, Velcro strips, screws or other
means;
2. Slide the powered transponder into the
bracket unl it is firmly inserted;
3. To remove the transponder from the
bracket, push down the tab at the end of
the bracket, slide the transponder out of
the bracket.
SPECIFICATIONS
RFID Protocol ISO 18000-7:2008
Frequency 433.92MHz
Power A’ Size 3.6V primary
lithium (Li-SOCl2), user
replaceable
Baery Life >6 years at 2 collecons
per day
Range 350 feet unobstructed
Dimensions 6.38 L x 2.17 W x 1.42 H
Weight 4.5 oz (127g)
Operang
Temperature -30⁰C to +70⁰C
Dust / Moist IP 64
Beeper Audible beeper for tag
locaon and status
indicaon
Memory 2 Kbytes
Compliance FCC, HERO
This asset transponder enjoys reduced power
consumption and allows great exibility, as
member of EV3 family products, which is
designed to provide dramatically improved func-
tionality at a much more attractive price point
than was attainable by previous conventional
Active RFID design approaches. This device oper-
ates in a master/slave conguration with an inter-
rogator. In all cases, the interrogator acts as the
master unit initiating commands from the tran-
sponder. Once, the device has been successfully
woken up, it will respond to data transmission
from the interrogator by sending packets of data.
This device complies with part 15 of the FCC Rules and with
RSS-210 of Industry Canada. Operation is subject to the following
two conditions: (1) this device must not cause harmful interfer-
ence, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equip-
ment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at
his own expense.
WARNING: Changes or modications not expressively approved by
the party responsible for compliance could void the user's author-
ity to operate the equipment.
Data Rich Transponder EV3-DRT
OPERATION OF THE TRANSPONDER
1. Remove the baery cap by turning counter-
clockwise;
2. Insert baery to the baery compartment
with posive terminal toward inside;
3. Replace the baery cap and secure it by
turning clockwise;
4. The transponder will beep once when it is
powered up.
5. Now the transponder is ready to be
deployed.
MOUNTING OF THE TRANSPONDER
A matching bracket may be provided for the
transponder.
1. Securely Aach the bracket to a desired
locaon using appropriate methods, such as
magnet, Velcro strips, screws or other
means;
2. Slide the powered transponder into the
bracket unl it is firmly inserted;
3. To remove the transponder from the
bracket, push down the tab at the end of
the bracket, slide the transponder out of
the bracket.
SPECIFICATIONS
RFID Protocol ISO 18000-7:2008
Frequency 433.92MHz
Power A’ Size 3.6V primary
lithium (Li-SOCl2), user
replaceable
Baery Life >5 years at 2 collecons
per day
Range 350 feet unobstructed
Dimensions 6.5 L x 2.37 W x 1.42 H
Weight 5.6 oz (158.8g)
Operang
Temperature -30C to +70C
Dust / Moist IP 64
Beeper Audible beeper for tag
locaon and status
indicaon
Memory 256 Kbytes
Compliance FCC, HERO
This data rich transponder enjoys many of the
characteristics intrinsic to EV3 family products,
which is designed to provide dramatically
improved functionality at a much more attractive
price point than was attainable by previous con-
ventional Active RFID design approaches. Addi-
tionally, the increased memory size available
locally at the asset site can allow for increased
monitoring and visibility. This device operates in a
master/slave con guration with an interrogator.
In all cases, the interrogator acts as the master
unit initiating commands from the transponder.
Once, the device has been successfully woken up,
it will respond to data transmission from the inter-
rogator by sending packets of data.
This device complies with part 15 of the FCC Rules and with
RSS-210 of Industry Canada. Operation is subject to the following
two conditions: (1) this device must not cause harmful interfer-
ence, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equip-
ment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at
his own expense.
WARNING: Changes or modi cations not expressively approved by
the party responsible for compliance could void the user's author-
ity to operate the equipment.
License Plate Transponder EV3-LPT
OPERATION OF THE TRANSPONDER
1. Remove the baery cap by turning counter-
clockwise;
2. Insert baery to the baery compartment
with posive terminal toward inside;
3. Replace the baery cap and secure it by
turning clockwise;
4. The transponder will beep once when it is
powered up.
5. Now the transponder is ready to be
deployed.
MOUNTING OF THE TRANSPONDER
A matching bracket may be provided for the
transponder.
1. Securely Aach the bracket to a desired
locaon using appropriate methods, such as
magnet, Velcro strips, screws or other
means;
2. Slide the powered transponder into the
bracket unl it is firmly inserted;
3. To remove the transponder from the
bracket, push down the tab at the end of
the bracket, slide the transponder out of
the bracket.
SPECIFICATIONS
RFID Protocol ISO 18000-7:2008
Frequency 433.92MHz
Power A’ Size 3.6V primary
lithium (Li-SOCl2), user
replaceable
Baery Life >6 years at 2 collecons
per day
Range 350 feet unobstructed
Dimensions 6.38 L x 2.17 W x 1.42 H
Weight 4.5 oz (127g)
Operang
Temperature -30C to +70C
Dust / Moist IP 64
Beeper Audible beeper for tag
locaon and status
indicaon
Memory 256 bytes
Compliance FCC, HERO
This license plate transponder is one of the more
cost sensitive devices in EV3 family products,
which is designed to provide dramatically
improved functionality at a much more attractive
price point than was attainable by previous con-
ventional Active RFID design approaches. This
device operates in a master/slave con guration
with an interrogator. In all cases, the interrogator
acts as the master unit initiating commands from
the transponder. Once, the device has been suc-
cessfully woken up, it will respond to data trans-
mission from the interrogator by sending packets
of data.
This device complies with part 15 of the FCC Rules and with
RSS-210 of Industry Canada. Operation is subject to the following
two conditions: (1) this device must not cause harmful interfer-
ence, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equip-
ment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at
his own expense.
WARNING: Changes or modi cations not expressively approved by
the party responsible for compliance could void the user's author-
ity to operate the equipment.
ensor Transponder EV3- T
OPERATION OF THE TRANSPONDER
1. Remove the baery cap by turning counter-
clockwise;
2. Insert baery to the baery compartment
with posive terminal toward inside;
3. Replace the baery cap and secure it by
turning clockwise;
4. The transponder will beep once when it is
powered up.
5. Now the transponder is ready to be
deployed.
MOUNTING OF THE TRANSPONDER
A matching bracket may be provided for the
transponder.
1. Securely Aach the bracket to a desired
locaon using appropriate methods, such as
magnet, Velcro strips, screws or other
means;
2. Slide the powered transponder into the
bracket unl it is firmly inserted;
3. To remove the transponder from the
bracket, push down the tab at the end of
the bracket, slide the transponder out of
the bracket.
SPECIFICATIONS
RFID Protocol ISO 18000-7:2008
Frequency 433.92MHz
Power A’ Size 3.6V primary
lithium (Li-SOCl2), user
replaceable
Baery Life >4.5 years at 2 collecons
per day
Range 350 feet unobstructed
Dimensions 6.5 L x 2.37 W x 1.42 H
Weight 5.6 oz (158.8g)
Operang
Temperature -30C to +70C
Dust / Moist IP 64
Beeper Audible beeper for tag
locaon and status
indicaon
Memory 512 bytes
Compliance FCC, HERO
This sensor transponder incorporates temperature,
humidity, shock and light sensing to our already pow-
erful transponder capabilities of EV3 family products,
which is designed to provide dramatically improved
functionality at a much more attractive price point
than was attainable by previous conventional Active
RFID design approaches. Additionally, the increased
memory size available locally at the asset site can
allow for increased monitoring and visibility. This
device operates in a master/slave con guration with
an interrogator. In all cases, the interrogator acts as
the master unit initiating commands from the tran-
sponder. Once, the device has been successfully
woken up, it will respond to data transmission from
the interrogator by sending packets of data.
This device complies with part 15 of the FCC Rules and with RSS-210 of
Industry Canada. Operation is subject to the following two conditions:
(1) this device must not cause harmful interference, and (2) this device
must accept any interference received, including interference that may
cause undesired operation.
NOTE: This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communi-
cations. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to
correct the interference at his own expense.
WARNING: Changes or modi cations not expressively approved by the
party responsible for compliance could void the user's authority to
operate the equipment.

Navigation menu
