Ewig Macao Commercial Offshore TLG002 Temperature Logger User Manual 1
Ewig Industries Macao Commercial Offshore Limited Temperature Logger 1
user manual
flashes while
broadcasting
press and hold to turn
on and start connection
after connected with
smart device
led indicator
steadily on 3's
times out when no device
connected after 10mins
after 3's
led indicator off and
work with smart
device
flashes while
broadcasting
press once to check
battery status after 5's
led indicator off and
work with smart
device
below 30%
31% - 70%
above 70%
UI - Bluetooth Temperature Logger Bluetooth Temperature Logger
FCC Statement:
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
Specifications
1.Voltage Supply: 1 x CR2032 3.0V Lithium battery
2.Temperature Range: -20 to +60 ℃
3.Recording cycle: up to 22 days (with 1min sampling time interval) up to 45 hours (with 5sec sampling time interval)
4.Battery life: 12 months * depends on data sampling rate setting
5.Protection class: IPX4
6.Indicator: 1 x LED (red) to show pairing and battery stauts
7.Dimensions: (W)49 x (H)49 x (D)11.5mm
8.Weight: Approx. 15g
