PCE3200AH Confidential Page 1
Product Specification
PCE3200AH
V. 0.3
Revision History
Version Date Revision Description
0.1 2012/2/4 Preliminary
0.2 2012/6/27 1. connector change to MMCX
2. Revised the operating temperature support range
3. Revised on the radio transmit power and sensitivity
specification
0.3 2012/10/09 1. Improved TX power.
Extreme Networks, Inc.
PCE3200AH Confidential Page 2
PRODUCT DESCRIPTION
The PCE3200AH is a adapting up-to-date Qualcom chip,
AR9590B (i-temp support), and targeting for enterprise-class
platform. It is acting at 2.4GHz frequency band.
P
RODUCT
S
PECIFICATION
General information
Chipset Atheros AR9590B
PA SE2576L
Interface PCIe
Operating voltage
Need both 3.3V and 5V voltage input
PCIe Slot : DC 3.3 V ± 5% with Advanced DC Power management support
PA: Extended DC power supply 5V
Antenna connectors 3 MMCX connectors
Temperature range -40°C to + 70 °C (Operating temperature)
-45°C to + 85°C (Storage temperature)
PCB Dimension L x W 58 x 31 mm
Security WPA, WPA2, 64/128 bit WEP, TKIP, and AES. hardware-based IEEE 802.11i
encryption engine
Data rates
802.11b:1, 2, 5.5, 11Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54Mbps
802.11n: 20MHz bandwidth:
1Nss: 65Mbps @ 800ns GI; 72.2Mbps @ 400ns GI (Max);
2Nss: 130Mbps @ 800ns GI; 144.44Mbps @ 400ns GI (Max);
3Nss: 195Mbps @ 800ns GI; 216.7Mbps @ 400ns GI (Max);
802.11n: 40MHz bandwidth:
1Nss: 135Mbps @ 800ns GI; 150Mbps @ 400ns GI (Max.);
2Nss: 270Mbps @ 800ns GI; 300Mbps @ 400ns GI (Max.);
3Nss: 405Mbps @ 800ns GI; 450Mbps @ 400ns GI (Max.);
Tx channel width support 20MHz / 40MHz
Standard/Compliance WECA (Wi-Fi & Wi-Fi5 compliance), IEEE802.11,b/g/n, RoHS and WEEE
Extreme Networks, Inc.
PCE3200AH Confidential Page 3
Regulation Certifications FCC Part 15
Preliminary Radio Specification
Channel Data rate
Typical AVG. Power
@combined
(dBm)
Tolerance
Typical RX Sensitivity
@ combined
(dBm)
802.11b (2.412~2.472GHz) 1 Mbps(no compliance with
spectrum mask) 29 +1/-2 dB ≦-95 dBm
1 ~ 2 Mbps 29 +1/-2 dB
5.5 ~ 11 Mbps 29 +1/-2 dB ≦-88 dBm
802.11g (2.412~2.472GHz) 6 ~ 24 Mbps 28 +1/-2 dB ≦-91 dBm
36 Mbps 27 +1/-2 dB
48 Mbps 25 +1/-2 dB
54 Mbps 24 +1/-2 dB ≦-74 dBm
802.11n_HT20
(2.412~2.472GHz) MCS 0/8/16 28 +1/-2 dB ≦-89 dBm
MCS 1/9/17 27 +1/-2 dB
MCS 2/10/18 27 +1/-2 dB
MCS 3/11/19 27 +1/-2 dB
MCS 4/12/20 27 +1/-2 dB
MCS 5/13/21 26 +1/-2 dB
MCS 6/14/22 25 +1/-2 dB
MCS 7/15/23 23 +1/-2 dB ≦-72 dBm
802.11n_HT40(2.422~2.462GHz)
MCS 0/8/16 28 +1/-2 dB ≦-89 dBm
MCS 1/9/17 26 +1/-2 dB
MCS 2/10/18 26 +1/-2 dB
MCS 3/11/19 26 +1/-2 dB
MCS 4/12/20 26 +1/-2 dB
MCS 5/13/21 25 +1/-2 dB
MCS 6/14/22 25 +1/-2 dB
MCS 7/15/23 23 +1/-2 dB ≦-69 dBm
Current consumption information
Tx current consumption
(without Jump wire) Continuous TX (99% duty) 8 W
Sleep Current Sleep mode ≦ 100 mA
OS support Windows 2000/XP/Vista, Linux
Extreme Networks, Inc.
PCE3200AH Confidential Page 4
Federal Communication Commission Interference Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate this equipment.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 30cm between the radiator & your body.
Extreme Networks, Inc.
PCE3200AH Confidential Page 5
This device is intended only for OEM integrators under the following conditions:
1) The antenna must be installed such that 30 cm is maintained between the antenna and users,
and
2) The transmitter module may not be co-located with any other transmitter or antenna.
As long as 2 conditions above are met, further transmitter test will not be required. However, the OEM
integrator is still responsible for testing their end-product for any additional compliance requirements required
with this module installed
IMPORTANT NOTE: In the event that these conditions can not be met (for example certain laptop
configurations or co-location with another transmitter), then the FCC authorization is no longer considered
valid and the FCC ID can not be used on the final product. In these circumstances, the OEM integrator will be
responsible for re-evaluating the end product (including the transmitter) and obtaining a separate FCC
authorization.
End Product Labeling
This transmitter module is authorized only for use in device where the antenna may be installed such that 30
cm may be maintained between the antenna and users. The final end product must be labeled in a visible
area with the following: “Contains FCC ID: QXO-24G32”. The grantee's FCC ID can be used only when all
FCC compliance requirements are met.
Manual Information To the End User
The OEM integrator has to be aware not to provide information to the end user regarding how to install or
remove this RF module in the user’s manual of the end product which integrates this module.
The end user manual shall include all required regulatory information/warning as show in this manual.
Industry Canada statement:
This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Ce dispositif est conforme à la norme CNR-210 d'Industrie Canada applicable aux appareils radio exempts de
licence. Son fonctionnement est sujet aux deux conditions suivantes: (1) le dispositif ne doit pas produire de
brouillage préjudiciable, et (2) ce dispositif doit accepter tout brouillage reçu, y compris un brouillage
susceptible de provoquer un fonctionnement indésirable.
Extreme Networks, Inc.
PCE3200AH Confidential Page 6
Radiation Exposure Statement:
This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment. This
equipment should be installed and operated with minimum distance 30cm between the radiator & your body.
Déclaration d'exposition aux radiations:
Cet équipement est conforme aux limites d'exposition aux rayonnements IC établies pour un environnement
non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 30cm de distance entre la source
de rayonnement et votre corps.
This device is intended only for OEM integrators under the following conditions: (For module device use)
1) The antenna must be installed such that 30 cm is maintained between the antenna and users, and
2) The transmitter module may not be co-located with any other transmitter or antenna.
As long as 2 conditions above are met, further transmitter test will not be required. However, the OEM
integrator is still responsible for testing their end-product for any additional compliance requirements required
with this module installed.
Cet appareil est conçu uniquement pour les intégrateurs OEM dans les conditions suivantes: (Pour
utilisation de dispositif module)
1) L'antenne doit être installée de telle sorte qu'une distance de 30 cm est respectée entre l'antenne et
les utilisateurs, et 2) Le module émetteur peut ne pas être coïmplanté avec un autre émetteur ou
antenne.
Tant que les 2 conditions ci-dessus sont remplies, des essais supplémentaires sur l'émetteur ne seront pas
nécessaires. Toutefois, l'intégrateur OEM est toujours responsable des essais sur son produit final pour
toutes exigences de conformité supplémentaires requis pour ce module installé.
IMPORTANT NOTE:
In the event that these conditions can not be met (for example certain laptop configurations or co-location with
another transmitter), then the Canada authorization is no longer considered valid and the IC ID can not be
used on the final product. In these circumstances, the OEM integrator will be responsible for re-evaluating the
end product (including the transmitter) and obtaining a separate Canada authorization.
NOTE IMPORTANTE:
Dans le cas où ces conditions ne peuvent être satisfaites (par exemple pour certaines configurations
d'ordinateur portable ou de certaines co-localisation avec un autre émetteur), l'autorisation du Canada n'est
plus considéré comme valide et l'ID IC ne peut pas être utilisé sur le produit final. Dans ces circonstances,
Extreme Networks, Inc.
PCE3200AH Confidential Page 7
l'intégrateur OEM sera chargé de réévaluer le produit final (y compris l'émetteur) et l'obtention d'une
autorisation distincte au Canada.
End Product Labeling
This transmitter module is authorized only for use in device where the antenna may be installed such that 30
cm may be maintained between the antenna and users. The final end product must be labeled in a visible
area with the following: “Contains IC: 4141B-24G32”.
Plaque signalétique du produit final
Ce module émetteur est autorisé uniquement pour une utilisation dans un dispositif où l'antenne peut être
installée de telle sorte qu'une distance de 30cm peut être maintenue entre l'antenne et les utilisateurs. Le
produit final doit être étiqueté dans un endroit visible avec l'inscription suivante: "Contient des IC:
4141B-24G32".
Manual Information To the End User
The OEM integrator has to be aware not to provide information to the end user regarding how to install or
remove this RF module in the user’s manual of the end product which integrates this module.
The end user manual shall include all required regulatory information/warning as show in this manual.
Manuel d'information à l'utilisateur final
L'intégrateur OEM doit être conscient de ne pas fournir des informations à l'utilisateur final quant à la façon
d'installer ou de supprimer ce module RF dans le manuel de l'utilisateur du produit final qui intègre ce module.
Le manuel de l'utilisateur final doit inclure toutes les informations réglementaires requises et avertissements
comme indiqué dans ce manuel.
Professional installation instruction
1. Installation personal
This product is designed for specific application and needs to be installed by a qualified personal who has RF
and related rule knowledge. The general user shall not attempt to install or change the setting.
2. Installation location
The product shall be installed at a location where the radiating antenna can be kept 30cm from nearby person
in normal operation condition to meet regulatory RF exposure requirement.
3. External antenna
Extreme Networks, Inc.
PCE3200AH Confidential Page 8
Use only the antennas which have been approved by the applicant. The non-approved antenna(s) may
produce unwanted spurious or excessive RF transmitting power which may lead to the violation of FCC/IC
limit and is prohibited.
4. Installation procedure
Please refer to user’s manual for the detail.
5. Warning
Please carefully select the installation position and make sure that the final output power does not exceed the
limit set force in relevant rules. The violation of the rule could lead to serious federal penalty.
Instructions d'installation professionnelle
1. Installation
Ce produit est destine a un usage specifique et doit etre installe par un personnel qualifie maitrisant les
radiofrequences et les regles s'y rapportant. L'installation et les reglages ne doivent pas etre modifies par
l'utilisateur final.
2. Emplacement d'installation
En usage normal, afin de respecter les exigences reglementaires concernant l'exposition aux
radiofrequences, ce produit doit etre installe de facon a respecter une distance de 30 cm entre l'antenne
emettrice et les personnes.
3. Antenn externe.
Utiliser uniiquement les antennes approuvees par le fabricant. L'utilisation d'autres antennes peut conduire
a un niveau de rayonnement essentiel ou non essentiel depassant les niveaux limites definis par FCC/IC,
ce qui est interdit.
4. Procedure d'installation
Consulter le manuel d'utilisation.
5. Avertissement
Choisir avec soin la position d'installation et s'assurer que la puissance de sortie ne depasse pas les limites
en vigueur. La violation de cette regle peut conduire a de serieuses penalites federales.
