Ezurio Ltd Bluetooth module PC Card II Users Manual

Contents

Users Manual

innovative Bluetooth solutions
The blu2i range allows:
•Reduction in time to market
•Flexibility in wireless interconnection
•Competitive differentiation
•Reduction of development costs
•Integration of new technology without specialist knowledge
•Access to the experience of a recognised leading technology partner
blu2i from TDK Systems allows virtually any product, existing or in
development, to be enhanced with wireless connectivity – adding
flexibility and increasing value to customers.
blu2i – simply integrated intelligence.
integrated an
ready and relevant
d intelligent
•Innovative – the only range if its kind
•Bluetooth 1.1 pre-qualified – eliminates approval timescales and costs
•Common industrial interfaces make for easy integration
•Requires no host Bluetooth software stack
•No Bluetooth knowledge required
•Hayes AT-style command protocol
•Data-transfer rates of 200Kpbs (typical)
•Range includes serial profile and can be upgraded to support
DUN or headset profiles*
•Robust design
*DUN and headset profiles must be separately approved in conjunction with the manufacturer’s hardware
Module
A Bluetooth module for integration in host systems
•2 analogue lines – configurable as input
or output
•69x24mm in size
•Development kit available
form and function
RS232 Adaptor
An external Bluetooth RS232 interface adaptor
•Enables any device with an RS232 serial
interface to communicate over Bluetooth
•Attaches to DTE or DCE interfaces
•Standard DB-9 serial connector
the blu2i range
USB Adaptor
An external Bluetooth USB interface adaptor
•Enables any device with a USB interface
to communicate over Bluetooth
•Powered by USB interface
•Supplied with self-adhesive mounting pad
RS232-Powered Adaptor
An external RS232-powered interface adaptor
•Burst transfer duration of 5 minutes
•Ten years life expectancy
•Rated at IP65
PCMCIA Adaptor
An internal Bluetooth PCMCIA interface adaptor
•Enables any device with a PCMCIA interface to
communicate over Bluetooth
•Type II format
•Integrated antenna avoids external pods
blu2i
blu2i
blu2i
Data sent via
Bluetooth
from sensor
Air flow sensor
Pipe
blu2i
A
Transmitted data to
central control and
stock change etc
Transmitted data to
central control and
stock change etc
Phone point
blu2i
blu2i
blu2i
Bluetooth entry phone system Bluetooth remote monitoring
Vending machine control and replenishment B
These application notes are engineering concepts designed to educate users about the potential of Bluetooth and are provided
in good faith. Users wishing to implement them should check that no third party patents are infringed before commercialisation.
Feature Implementation
Status indication by LED Power on
Data transfer
Device is discoverable
NB – varies between devices
Fully Bluetooth pre-qualified Bluetooth 1.1 product listing
Current consumption Less than 36mA during data transfer
Configurable low power mode
Temperature range Normal operation: -20oC to +75oC
Interface levels 3.3V
Audio Audio can be transferred over SCO channels
through the PCM interface at 64Kbps
All information correct at time of going to press. Specifications are subject to change.
facts and figures
Feature Implementation
Bluetooth transmission Class 1
Frequency 2.400 – 2.485 Ghz
Max transmit power +6dBm
Min transmit power +0dBm
Receive sensitivity Better than -85dB
Antenna gain +2dBi
Range 200m
Data transfer rate 200Kbps (typical)
Interfaces RS232
USB
PCMCIA
Baud rate Configurable from 9600bps
Signalling DTR, DSR, DCD, RI, RTS, CTS
www.tdksystems.com
Simply integrated intelligence. Visit www.blu2i.com
e-mail blu2i@tdksys.com or call +44 (0)20 8938 1000 for more details.
pioneers in mobile connectivity
TDK Systems Europe Ltd
126 Colindale Avenue
London
NW9 5HD
United Kingdom
Tel: +44 (0)20 8938 1000
Fax: +44 (0)20 8905 8608
TDK Corporation
1-13-1 Nihonbashi
Chuo-Ku
Tokyo 103-8272
Japan
Tel: +81 (0)3 3278 5111
TDK Singapore
460 Alexandra Road
PSA Building
Singapore
119963
Tel: +65 6270 5861
Fax: +65 6278 3858
TDK Pty. (Australia) Ltd
Level 22
8-20 Napier Street
North Sydney NSW 2060
Australia
Tel: +61 2 8908 8600
Fax: +61 2 8904 1570
TDK USA Ltd
144 Hughes Road
Suite “C”
Grass Valley
CA 95945
USA
E-mail: usa@tdksys.com
The Bluetooth trademarks are owned by their proprietor and used by TDK Systems Europe Ltd under licence.
Other product or company names mentioned herein may be trademarks or trade names of their respective owners.
06/03
