FALCON EYES LPS-LIGHT Remote Control for Professional LED Light User Manual
FALCON EYES LTD. Remote Control for Professional LED Light
user manual
D) Warning
FM1412_LPS-2100CTR_ENG
3
Thank you for purchasing FalconEyes’ products.
For further details of our related products, please contact your
local distributor or visit our webpage at www.falconeyes.com.hk
Thank you.
Please read this manual carefully before using this product.
E-mail: info@falconeyes.com.hk
Website: www.falconeyes.com.hk
LPS-2100CTR
Wireless Remote Control
Instruction Manual
1. Read the Instruction Manual carefully before usage.
2. To prolong lifespan of the device, avoid violent crashing or vibrations to
the device.
3. Repair the device only by professionals and do not open the unit your-
self.
4. Use the device in clean and dry environments. Do not use it in humid or
dusty environments. Keep the device away from explosive or corrosive
gases.
5. Switch off the remote after use. As setting up of the remote is com-
pleted, it can be switched off until settings need to be changed.
6. Store the remote in a place where children cannot reach to prevent any
damages of the remote.
B) Control Panel
A) Features
C) Instruction
12
LCD display
Menu
Power Socket
Enter
LED backlight
Hot Shoe
MENU
Channel
Yellow LED display
ID code
White LED display
Menu
RC-3L Remote LCD display
Each LED light has 10 channels, each channel has 100 IDs,
channel and ID are the identification of the flash unit.
Channel: Set C0-C9 (each channel has ID: 00 to 99)
ID: set 00-99 (Lights in same channel and ID can be adjusted
together with remote control)
K
YELLOW WHITE
CHANNEL I.D
Power Switch
●“Menu” button is to switch between digits and “Enter” button is to
adjust reading of digits. For example:
1、When pressing the “Menu” button, the first digit of “Yellow LED
display” blinks, press “Enter” now to adjust the reading.
2、Press the “Menu” button again to switch to the second digit of
“Yellow LED display”, press “Enter” to adjust the reading.
3、The light reacts instantly to give final effect
4、Same setting for “White LED display”, “Channel” and “ID”
● LED Backlight
1、LED Backlight lights up when users press the button. It is for
better remote adjustment in dim environment.
Color Temperature
Display
LPS-2100CTR remote control is equipped with LCD digital
display and 2.4GHz anti-interference wireless function. Trans-
mission range is far up to 15 meters, it allows you to freely
adjust the settling of the LED light. Once you have the remote
control in your hand, everything will become a lot easier and
efficient. Channel and ID settings
FCC Statement:
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
