FENDA TECHNOLOGY ESI-A610 premium Bluetooth wireless speaker User Manual
SHENZHEN FENDA TECHNOLOGY CO., LTD. premium Bluetooth wireless speaker
User Manual
Instruction Manual and
Warranty Information ESI-A610
ambience
premium Bluetooth® wireless speaker
THE SHARPER IMAGE ® name and logo are registered trademarks.
Marketed and distributed by SI Products under license. ©The Sharper Image.
All rights reserved.
IB-ESIA610
ONE YEAR LIMITED WARRANTY
SI PRODUCTS sells its products with the intent that they are free of defects in manufacture and
workmanship for a period of one year from the date of original purchase, except as noted below.
SI PRODUCTS warrants that its products will be free of defects in material and workmanship under
normal use and service. This warranty extends only to consumers and does not extend to Retailers.
To obtain warranty service on your Sharper Image product, contact a consumer relations
representative by telephone at 1-888-856-6781 for assistance. Please make sure to have the model
number of the product available.
SI PRODUCTS does not authorize anyone, including, but not limited to, Retailers, the subsequent
consumer purchaser of the product from a Retailer or remote purchasers, to obligate SI PRODUCTS
in any way beyond the terms set forth herein. This warranty does not cover damage caused by
misuse or abuse; accident; the attachment of any unauthorized accessory; alteration to the product;
improper installation; unauthorized repairs or modifications; improper use of electrical/power supply;
loss of power; dropped product; malfunction or damage of an operating part from failure to provide
manufacturer’s recommended maintenance; transportation damage; theft; neglect; vandalism; or
environmental conditions; loss of use during the period the product is at a repair facility or otherwise
awaiting parts or repair; or any other conditions whatsoever that are beyond the control of SI
PRODUCTS.
This warranty is effective only if the product is purchased and operated in the country in which the
product is purchased. A product that requires modifications or adoption to enable it to operate in any
other country than the country for which it was designed, manufactured, approved and/or authorized,
or repair of products damaged by these modifications is not covered under this warranty.
THE WARRANTY PROVIDED HEREIN SHALL BE THE SOLE AND EXCLUSIVE WARRANTY. THERE
SHALL BE NO OTHER WARRANTIES EXPRESS OR IMPLIED INCLUDING ANY IMPLIED WARRANTY
OF MERCHANTABILITY OR FITNESS OR ANY OTHER OBLIGATION ON THE PART OF THE COMPANY
WITH RESPECT TO PRODUCTS COVERED BY THIS WARRANTY. SI PRODUCTS SHALL HAVE NO
LIABILITY FOR ANY INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES. IN NO EVENT SHALL
THIS WARRANTY REQUIRE MORE THAN THE REPAIR OR REPLACEMENT OF ANY PART OR PARTS
WHICH ARE FOUND TO BE DEFECTIVE WITHIN THE EFFECTIVE PERIOD OF THE WARRANTY.
NO REFUNDS WILL BE GIVEN. IF REPLACEMENT PARTS FOR DEFECTIVE MATERIALS ARE NOT
AVAILABLE, SI PRODUCTS RESERVES THE RIGHT TO MAKE PRODUCT SUBSTITUTIONS IN LIEU
OF REPAIR OR REPLACEMENT.
This warranty does not extend to the purchase of opened, used, repaired, repackaged and/or resealed
products, including but not limited to sale of such products on Internet auction sites and/or sales of
such products by surplus or bulk resellers. Any and all warranties or guarantees shall immediately
cease and terminate as to any products or parts thereof which are repaired, replaced, altered, or
modified, without the prior express and written consent of SI PRODUCTS.
This warranty provides you with specific legal rights. You may have additional rights which may vary
from state to state. Because of individual regulations, some of the above limitations and exclusions
may not apply to you. For more information regarding our product line in the USA,
please visit: www.siproducts.com
SI Products
Service Center
1.888.856.6781
8:30a.m. – 7:00p.m. (EST)
M – F
e-mail:
cservice@siproducts.com
P
l
e
a
s
e
T
a
k
e
A
M
o
m
e
n
t
N
o
w
Register
Your Product At:
www.siproducts.com/register
Your valuable input regarding this
product will help us create
the products you will
want in the future.
2 3
Thank you for purchasing Sharper Image Ambience Premium
Bluetooth® Wireless Speaker for smartphones, tablets, notebook
computers and other Bluetooth enabled devices. This product,
along with the entire Sharper Image Electronics lineup, combines
high-tech innovation with design to provide you with years of
dependability and enjoyment.
Package Contents
Getting Started
Unpack the unit carefully. Remove all the accessories from the display carton. Do not
remove any labels or stickers on the rear of the unit and adapter. Before setting up the
unit, verify that the following accessories are present:
• Instruction manual x 1 • AC power adapter x 1
• Main unit x 1 • 3.5mm audio cable x 1
• Remote control x 1
Power Source
This unit is supplied with an AC adapter; take the following steps to connect the adapter.
1. Referring to rear panel image (page 4), connect the DC plug of the AC adapter to the
DC socket on the rear of the unit.
2. Plug the AC adapter to the AC outlet (100v – 240VAC 50/60 Hz). Connecting this
system to any other power source may cause damage to the system.
3. To switch the unit off completely, withdraw the AC adapter from the wall outlet.
Controls
User Manual
Remote Control
Sound System
AUX Audio Cable AC Adapter
Bluetooth Button
AUX Button
Volume Controls
Play/Pause Button
Power
3
3
4
4
5
5
2
2
1
1
4 5
BASS
AUX
Listening to your device through the Auxiliary AUX In Audio Jack
1. Referring to rear panel image, connect AUX cable to the headphone or line-out jack
of an audio device and plug the other end of the cable into the AUX In Audio jack on
the back of the unit.
2. Press the POWER button to turn on the unit.
3. Press the AUX button, AUX indicator will illuminate.
4. Press PLAY on the device and use controls on the unit or remote to adjust to desired
volume.
Adjusting Bass
While playing audio, press the BASS controls on the remote to adjust to desired bass
level.
Remote Control Battery:
The battery is already installed. Simply pull tab out to
activate battery power. To replace remote battery, open the
battery door by pressing the two tabs together. Remove
the old battery and replace with the same (CR-2025)
battery type.
Battery Precautions
• Use only the size and type of batteries specified.
• When installing batteries, observe proper +/- polarities.
Incorrect installation of battery may cause damage to
the unit.
• Do not mix different types of batteries together (e.g.,
alkaline with carbon-zinc or old batteries with new ones).
• If the unit is not going to be used for a long period of
time, remove batteries to prevent damage due to pos-
sible battery leakage.
• Do not dispose of batteries in fire. Batteries may explode
or leak.
This product contains small parts that may present a choking hazard for young
children. If swallowed, it could cause severe injury or death. Seek medical
attention immediately.
Listening to your device wirelessly over Bluetooth
To listen to your music over Bluetooth wireless connection, you need to pair your device
with Sharper Image Ambience:
1. Make sure your device has Bluetooth capability.
2. Press the POWER button to turn on the unit. The Bluetooth light will flash slowly
after 5 seconds.
3. Once the Bluetooth button beings to flash, press and HOLD the Bluetooth button for a
few seconds until the Bluetooth light begins to flash quickly.
4. Follow the instructions of your device to pair the unit.
5. Pair your device with the unit by selecting from your Bluetooth listings on your device
or selecting YES.
6. Press play on your device and use controls on the unit or remote to adjust to desired
volume.
7. The effective range of the Ambience is approximately 30-feet from the Bluetooth
device. Range can be affected by numerous factors including the Bluetooth device,
wall materials, etc. If you experience audio drop outs please move the Bluetooth
device closer to the Ambience
NOTE: Once you have successfully paired your device, you typically will not need to
repeat the above steps. Please ensure the unit source is set to Bluetooth and your
device has Bluetooth enabled.
21
1 9
2 8
3 7
4 6
5
3
DC In
Charging Port
AUX Audio Jack
3
2
1
Power
Bluetooth Button
Bass Controls
Skip/Search
Down Button
Play/Pause Button
Skip/Search
Up Button
Volume Controls
AUX Button
Mute Button
3
4
5
6
7
8
9
2
1
BASS
AUX
Remove
Rear Panel
6 7
FCC Disclaimer:
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause
undesired operation.
NOTE: The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications to this equipment. Such modifications could void the user
authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
