FENDA TECHNOLOGY UB450 6CH 2.4GHZ FHSS RADIO CONTROL SYSTEM User Manual UB450 2015 10 22
SHENZHEN FENDA TECHNOLOGY CO., LTD. 6CH 2.4GHZ FHSS RADIO CONTROL SYSTEM UB450 2015 10 22
User manual
Thank you for choosing the
Headset. Please read this manual carefully before
using and keep it for future reference.
Sports stereo headset
version 4.0
Charging means: power adapter output (DC5V 150mAh)
Battery:
high-capability rechargeable lithium polymer battery
RF power: class 2
Profiles: Headset, Handsfree, A2DP, AVRCP, APT-X
Talk time: up to 8 hours
Playing time: up to 8 hours
Standby time: up to 180 hours
Keep the unit away from high temperature and high
humidity.
Do not disassemble, modify or attempt to repair
the unit.
1× UB450 Sports Stereo Headset
1× USB charger Cable
4× Ear rubber
2× Ear hook
(Remark:UB450 is with middle size rubbers and ear hooks.)
1 2 3 4 5
Important Safety Instructions
UB450 User Manual
Sports Stereo Headset
Accessories List
Product Description
Please keep or use this product at normal temperature;
Do not expose this product in rain or moisture;
Do not throw this product to aviod any damage;
Do not disassemble, repair or reform this product;
Do not clean this product with any chemical solvents;
Please use USB power of DC5V for output when needed;
Do not throw away or put it in high temperature(higher
than 60℃) fire to avoid any danger.
This product can accept audio file from any
devices like mobile phones,
notebooks.
When being connected to DONGLE on PC,
it can play any audio files on the computer. You can
use it for voice chat to achieve wireless QQ.MSN.SKYPE.
Cautions
Warning
Changes or modifications to this unit not expressly
approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception,
which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
WARRANTY TERMS & CONDITIONS
********************************************
The warranty will be effective only if the warranty card is
completed and returned to the company within 14 days from the
date of purchase.We guarantee the provision of free services of the
product within the warranty period, from its date of purchase from
our Authorised Dealer. The period and conditions of our warranty
service are as follow:
1. The warranty covers services by our Authorised Dealer. This
warranty card together with the receipt must be presented when
servicing is required. This warranty card is irreplaceable in the event
of loss.
2. Repair services will be provided for defects arising from normal
usage for the following period, commencing from the date of
purchase from our Authorised Dealer. (Parts would be replaced
when necessary)
A. Parts:……………………………… 1 year
B. Technical service free…………… 1 year
3. Under the following circumstances, service and parts will be
chargeable even within the warranty period:
A. Failure to present the warranty card and receipt when
servicing is required.
Full particulars not clearly shown or alterations made against
the actual information.
For e.g.: Alteration of the date of purchase, serial
numbers-altered or removed.
B. This unit being tampered with, altered in any way by any
unauthorised technicians or which has been subjected to misuse,
negligence or accident. This guarantee does not cover damage
occuring in transit by or from the cumtomer.
C. The defect is caused by the attack of household pests, fire,
lighting, natural disasters, pollution,abnormal voltage or the usage of
generator.
NFC
L
FCC ID:HBOUB450
Bluetooth®
Bluetooth
®
Bluetooth
®
Bluetooth
®
Bluetooth
®
Bluetooth
®
Bluetooth®
Bluetooth
®
WARNING
• If water or other foreign objects enter the inside of the
device, fire or electric shock may result.
• Do not attempt to modify this product. Doing so could
result in personal injury and/or product failure.
CAUTION
• Never disassemble or modify the device, as failures
may result.
• Do not subject to extreme force and do not pull on the
cable or failures may result.
• Keep the product dry and avoid exposure to extreme
temperatures and humidity.
hotncold
Bluetooth Stereo Headset
SHENZHEN FENDA TECHNOLOGY CO., LTD.
FCC RF warning statement: the device has been evaluated to meet
general RF exposure requirement , The device can be used in
portable exposure condition without restriction.
DISTRIBUTOR’S COPY
WARRANTY REGISTRATION CERTIFICATE
****************************************************
Mr./Mrs/Ms First Name:
Last Name:
Address：
Contact No.:
Product Name:
Model No.:
Serial No.:
Date Purchased:
Invoice No.:
Retail Outlet Where Purchased:
(Please print the name & address)
76 8 9 10 11
Power On: Long press “MFB” for 2 seconds until the
blue indicator light flashes.
Power off: With the headset on, long press “MFB”
for 3 seconds, the red indicator light flashes
2 seconds and goes off.
Answering a call:
Press the answer key on your phone
or short press “MFB” on your headset.
Ending a call: Press the end key on your phone or
short press “MFB” on your headset.
Rejecting a call: Press the end key on your phone or
long press the “MFB” button for 2 seconds on your
headset.
Redialing the last called number: Double press the
“MFB” button when headset is in standby mode.
Play/Pause: When you are listening to the music from
the headset, you can short press “MFB” to play and
pause.
Previous/Nect Track: Previous Track when press the
“+” 2 seconds. Next Track when press the“-”
2 seconds.
Volume control: Volume will be up when short press
“+” and will be down when short press “-”.
Microphone Mute: During a call, press “-” for
about 2 seconds it will mute, press “-” for about
2 seconds it will work again.
Function and OperationProduct Overview
Previous Track
Volume +
Indicator Light
MFB
Charging port
Mic
Next Track
Volume -
Right Channel
Left Channel
Pair to your Phone
•
Pair the headset for the first time, the distance
between the headset and your
phone would be better within 1 meter when pairing.
•
With the headset power off, hold and press “MFB” until
the headset is pairing status, red light and blue light
flash alternately.
•
Start mobile phone function.
•
Search device, Choose “UB450”.
•
Depending on your device you may be prompted to enter
a pairing code. If prompted enter “0000” as the code.
•
Repeat above-mentioned steps if the pairing was
unsuccessful.
•
The green light will flash if paired successfully.
Voice Prompt
When your UB450 isn’t rocking out, it can tell you
sorts of things it’s doing: Power on; Power off; Your
headset is enter pairing mode; Your headset is
connected; Battery low.
Voice dialing: On the status of standby, long press
“MFB” .
Low power alarm: When the headset is power on, if
the battery volatge is lower than 3.3V, there will be a
prompt and the red indicator light flashes every 20
seconds.
Charging status: Red indicator light remains solid when
charging, the blue indicator light remains solid when
completed.
Low power shutdown: When the headset is power on,
if the battery voltage is lower than 3.0V, the headset
will shutdown automatically.
Call switching: Call switching between mobile phone
and headset: during a call, long press “MFB”, the audio
will be switched from the headset to mobile
phone; Long press “MFB”, the audio will be switched
from mobile phone back to the headset.
Connect two mobile phones at the same time:
•
After paired the first mobile phone, please turn off the
function of the first mobile phone, then pair
to the second mobile phone.
•
Open the first mobile phone function,
manual connection the first mobile phone.
•
During a call, short press “MFB”, hang up the current
call, then answer the incoming call.
•
Double press “MFB” to answer another incoming
call while you are on one phone call, and switch
between the two incoming calls.
•
Short press “MFB” to cut off the incoming calls one
by one.
Important: Different mobile phone brands or menu funtions,
the operation will be different. Please read your phone’s
manual carefully.
OFF
NFC Function
The mobile phone only need to get close to the headset
NFC detecting area when the headset is on.
* MFB:Multi-Function Button
Handling of the Waste Electrical
Note: While two mobile phones are connecting one
headset, some functions of the
headset will be restricted.
The Waste Electical
This marking shown on the product or its literature
indicates that is should not be disposed with other
household wastes at the end of its working life.
To prevent possible harm to the environment or human
health from uncontrolled waste disposal, please separate
this from other types of wastes and recycle it responsibly
to promote the sustainable reuse of material resources.
Household user should contact either the retailer where
they purchased this product or their local government
office, for details of where and how they can take this
item for environmentally safe recyling.
Business users should contact their supplier and check
the terms and conditions of the purchase contract.This
products should not be mixed with other
commercial wastes for disposal.
NFC NFC
Bluetooth
®
Bluetooth
®
Bluetooth
®
Bluetooth
®
Bluetooth
®
Bluetooth
®
Bluetooth
®
Bluetooth
®
Bluetooth
®
Bluetooth
®
Bluetooth
®
Bluetooth
®
Bluetooth
®
Bluetooth
®
hotncold
