FORM ELECTRONICS FM0184 Bluetooth Speaker User Manual LACOSTE FW18 Speaker Notice 180502 rev 01
FORM ELECTRONICS CO.,Ltd Bluetooth Speaker LACOSTE FW18 Speaker Notice 180502 rev 01
Users Manual
SPECIFICATION
1 .Bluetooth version : V4.0
2 .Power : 6W
3 .Impedance : 4 Ω
4 .Signal-to-noise ratio : ≥ 85±2dB
5 .Frequency response : 100 Hz-18KHz
6 .Working distance : 10m
7 .Battery capacity : 2000mAh
8 .Charging voltage : DC 5V
USER’S MANUAL AUX Cable
SPEAKER
USB Cable
COMPONENTS & FUNCTION
PLS KINDLY CHECK THE FUNCTION INDICATOR BEFORE USE THE SPEAKER SYSTEM
1
3
5
7
2
4
6
8
Press for last song
Press for next song
Press for volume down
Audio input port
Press for volume up
Press to power on and off
Charging port-DC 5V
Press for pause/play,
answer or hang up the
phone
BASIC FEATURES
• Bluetooth play.
• Bluetooth telephone function.
• Support PC iPod/iPhone/iPad/MP3/MP4 and any other smartphones
and tablet by connecting with 3.5mm jack.
TROUBLE SHOOTING
• Cannot turn on the speaker: check if the speaker does not have power.
If no power, charge it first.
• Cannot connect with Bluetooth devices: check if the speaker is
connected to a third Bluetooth device. If yes, disconnect it first. If
it still
does not connect, reboot it and try again.
CHARGING VIA USB CABLE
• Switch ON and connect it to PC via USB cable. It can play songs
during charge.
• Switch OFF and connect it to PC to only charge it.
• USB cable is not made to transfer datas.
INTERFACES
• Micro USB Port: Use charging cable to connect the speaker with USB
power adaptor or PC for charging.
• AUX Port: 3.5mm connector to connect the speaker and playback
equipment. The speaker switch to wired connection playback mode
when plugged in.
• LED indicator:
°White: Bluetooth connected or playing music
°Red: Charging status (red indicator of when fully charged)
CAUTIONS
• Keep out of reach of children.
• Never knock the speaker.
• Keep it away from fire, water, high and low temperature.
• Never obstruct speaker nets.
• Never open it by yourself.
• Do not charge it for too long, it could damage the battery. 3 hours is
the best charging time.
i^`lpqb=J=ctNU=J=péÉ~âÉê=J=kçíáÅÉ=NUMRMOKéÇÑ===N===MOLMRLOMNU===NRWNU
FCC Warning Statement
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures: ‐‐Reorient or relocate the receiving antenna.
‐‐Increase the separation between the equipment and receiver.
‐‐Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
‐‐Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC rules. Operation is subject to
the following two conditions (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
