Falcom MAMBO56 Mobile Phone User Manual Mambo operational description
Falcom GmbH Mobile Phone Mambo operational description
Falcom >
Manual
This document is available at http://www.falcom.de/
MAMBO56
GSM / GPRS / GPS / Bluetooth device
Operational description
Version 1.00, 24/04/2006
Mambo Operational Description Version 1.00
This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission.
Page 1
OPERATIONAL DESCRIPTION
Based on the GSM/GPRS and state-of-art GPS technology for satellite
navigation, FALCOM introduces a new powerful pocket size device with a stand-
alone software system for personal safety and security as well as asset monitoring.
FALCOM MAMBO consists of the GSM/GPRS engine, 20-channel GPS receiver,
Bluetooth™ class 2.0 and a 3-D motion detector (in the state of inactivity it can be
set into the low power mode) as an all-in-one solution.
FALCOM MAMBO is a Tri-band GSM/GPRS engine that works on the three
frequencies either GSM 900/1800/1900 MHz or GSM 850/1800/1900 MHz. The
integrated GPS receiver architecture based on the SiRFstarIII chipset, provides more
than enough precise location information using satellite signals to enable it to track
people wherever they are in the world. With its integral housing, compact design,
ultra-low power consumption, easy-to-carry and easy-to-use, it is an outstanding
quality, high-performance, operating as a stand-alone device ideally suited for
personal security, asset management and automotive applications as well. The
configurable internal firmware is a fundamental component, which in combination
with the excellent hardware performance makes the FALCOM MAMBO device to be
the best application where the fleet management and personal security today are
required. Operating as a stand-alone personal security device, manufactured in a
form factor 85 mm x 59 mm x 25 mm and weighing less than 120 grams with battery,
it can be easily fit in a jacket pocket (e.g. into a child's pocket). Ease-of-use is
ensured with just three touch-buttons and three LEDs. Each LED includes three-
different lighting colors. Each Button and LED is free-configurable. Based on the
internal firmware all Buttons and LEDs can be adjusted to the user requirements.
Depending on the user-defined configuration, each touch-button can execute
more than one action (voice call, TCP packets, SMS generation etc.). In the event of
emergency, the person carrying the device can contact a range of services by
pressing just a button. Upon button activation, the equipment uses the GPS signals to
define its accurate position, and it sends a SMS message with its location information
or it performs a voice call to one of the predefined numbers via the GSM network.
With the help of the implemented TCP/IP protocol, FALCOM MAMBO (person who
carrying it) can be continually tracked and monitored live from any Internet
connection point around the world.
FALCOM MAMBO provides Geofence features, which can be used for territory
management, route verification, prohibited locations, and more. Once a Geofence
area is manually set-up, the device automatically notifies the destination number via
SMS, Voice or Data calls or TCP, if the person carrying it enters into and/or leaves the
pre-defined area(s).
The FALCOM MAMBO contains a History function which enables it to archive unique
locations in sequence for up to 45 days long (for example, archive interval up to 20
sec.) and at a later time the history data can be downloaded either locally via
Bluetooth or over-air GSM network or TCP-connection for further evaluation.
Additionally, the FALCOM MAMBO is also a high-capacity navigation system, an
intelligent and dynamic destination guidance that allows you to navigate freely
without the hassle of messy wire connections. The integrated Class 2 Bluetooth™
transceiver in the FALCOM MAMBO is capable to communicate with any Serial Port
Profile Bluetooth™ device and to transmit its data within a 10m radius. The FALCOM
MAMBO in communication with your installed GPS Mapping software on the
Bluetooth™-enabled device points you the way comfortably and reliably from the
current location A to your desired destination B.
Mambo Operational Description Version 1.00
This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission.
Page 2
FALCOM MAMBO is equipment that can be used in a variety of applications such as:
♦ Personal safety and security
♦ Fleet tracking and management
♦ Remote tracking (Locating people)
♦ Real-time Navigation and Positioning
♦ Finding streets and routes
♦ Travel planning and many others …
BUTTON-ASSIGNMENTS & LED-BEHAVOIRS
Figure 1: MAMBO & Headset
Button assignments
Actions Button number & Duration of depressing
1 2 3 4
Turns power on long (>5s) - - -
Turns power off - - double -
Sends actual position to server short - - -
Sends alarm as SMS long (>2) - - -
Establishes voice calls* double - - double
Hanges up an established call* short short short short
Accepts an incoming call* short short short short
Hanges up an outgoing call* short short short short
* alternative button allocation
LED behavoirs
LED name LED color Short blinking Permanent
Red network search in progress
GSM Blue data transfer
Yellow TCP search in progress
Off GSM/TCP is connected
Green battery state 65-100% *battery charging state 90-100%
Mambo Operational Description Version 1.00
This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission.
Page 3
Yellow battery state 30-65% *battery charging state 10-90%
STAT Red battery state 0-35% *battery charging state 0-10%
Blue Bluetooth is connected
Off device OFF
GPS Red GPS invalid
Off GPS valid
* only in charge mode
CIRCUIT CONCEPT
The MAMBO architecture includes the following major functional components:
ARCHITECTURE INTEGRATES:
high-performance Tri Band GSM/GPRS core (operating at 26MHz)
20 parallel channel low-power GPS core (operating at L1 1575.42
MHz and C/A code 1,023 MHz chip rate)
ARM7TDMI Processor (at speed 25MHz) that controls all functions of
the system
BluetoothTM technology
3D detector system (MSENS module)
Power Control for Li-Ion Batteries
high capacity (3.7V/ 850 mA/h) Li-Ion battery
FLASH-Memory (2MB - 512KB).
Internal SIM card reader
Internal GSM/GPRS antenna
Internal GPS antenna
Internal Bluetooth antenna
Internal Speaker and Microphone
PHYSICAL INTERFACES:
Audio interface (for headset)
Mambo Operational Description Version 1.00
This confidential document is a property of FALCOM GmbH and may not be copied or circulated without previous permission.
Page 4
RF EXPOSURES
This device contains 850/1800/1900 MHz GSM/GPRS functions that is operational in
these frequencies.
The following statements according to the FCCs are only applied for the MAMBO56.
However, the MAMBO56 unit contains 1800 MHz GSM functions that are not
operational (must not be used) in U.S. Territories. This filing is only applicable for
850MHz GSM/1900 MHz PCS operations, whereby only these frequencies (850MHz
GSM/1900 MHz PCS) are possible to be used in U.S. Territories.
The external antennas used for this mobile transmitter must provide a separation
distance of at least 20 cm from all persons and must not be co-located or operating
in conjunction with any other antenna or transmitter.
Statement according to FCC part 15.19:
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
this device may not cause harmful interference, and
this device must accept any interference received, including interference that may
cause undesired operation.
Statement according to FCC part 15.21:
Modifications not expressly approved by this company could void the user's
authority to operate the equipment.
Statement according to FCC part 15.105:
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help
