Effective April 4, 2020 • Rev. 04/20
Price book 8
Click next for quick tips on
how to navigate Allegion
Price Books quicker!
Price Book 8
Effective April 4, 2020 • Rev. 04/20
2
Placing orders
You can place orders with Allegion via the fax numbers or emails listed below:
Locks, Exits (panic devices), Closers
Fax#: 1-800-452-0665
Email: Order_Entry_Schlage_Commercial@allegion.com
This price list supersedes and cancels all previous price lists. Prices shown are subject to change without notice.
Administrative Offices
Allegion Administrative Office
11819 N. Pennsylvania St.
Carmel, IN 46032
allegion.com/us
Customer Care
Our Customer Care Representatives are available for questions or assistance.
You can reach them at 877-671-7011 (Press 1 for Sales Support | Press 2 for Product Support | Press 3 for RSO) or
through the email addresses listed below:
Sales Support
support@allegion.com
Request for Quote
Carolinas
(North Carolina, South Carolina, Virginia)
Carolinas.Quotes@allegion.com
Central
(Arkansas, Illinois, Iowa, Kansas, Missouri,
Nebraska, Oklahoma)
Central.Quotes@allegion.com
Chicago
(Illinois-Northern, Wisconsin)
Chicago.Quotes@allegion.com
Florida
Florida.Quotes@allegion.com
Great Lakes
(New York, Pennsylvania)
GreatLakes.Quotes@allegion.com
Metro New York
Metro.Quotes@allegion.com
Technical Product Support
Mechanical Locks/Keying Systems
Mechanical_Locks_TechProdSupport@allegion.com
Exit Devices
Exits_TechProdSupport@allegion.com
Closers
Closers_TechProdSupport@allegion.com
Michigan
Michigan.Quotes@allegion.com
Mid Atlantic North
(New York, Pennsylvania)
Mid.Atlantics.north.quotes@allegion.com
Mid Atlantic South
(Delware, Maryland, New Jersey)
Mid.Atlantics.south.quotes@allegion.com
Midwest
(Indiana, Kentucky, Ohio, West Virginia)
Midwest.Quotes@allegion.com
Mountain States
(Colorado, Idaho, Montana, Nevada, Utah, Wyoming)
Mtn.States.Quotes@allegion.com
New England
(Connecticut, Main, Massachusetts, New Hampshire,
Rhode Island, Vermont)
NewEngland.Quotes@allegion.com
North Central
(Minnesota, North Dakota, South Dakota)
NorthCentral.Quotes@allegion.com
Northern California
NoCal.Quotes@allegion.com
Northwest
(Alaska, Oregon, Washington)
Northwest.Quotes@allegion.com
South
(Alabama, Georgia, Louisiana,
Mississippi, Tennessee)
South.Quotes@allegion.com
Southern California
(California-Southern, Hawaii)
SoCal.Quotes@allegion.com
Southwest
(Arizona, New Mexico)
Southwest.Quotes@allegion.com
Texas
Texas.Quotes@allegion.com
Electronic Products
Fax#: 1-800-452-0665
Email: Order_Entry_Schlage_Commercial@allegion.com
ProExpress
Fax#: 800-924-3551
Email: Order.Pro.Express@Allegion.com
Online: www.Allegion.com/us/proexpress
FastTrack
Fax#: 1-800-288-4242
Email: Order_Fasttrack@allegion.com
3
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Table of Contents
Contact Information ............................................2
General Terms ................................................4-7
Exits
Finishes......................................................168
Factors Affecting Exit Devices ................................169
New Nomenclature Conversion Chart......................... 170
How to Order .............................................171-172
25 Series ................................................. 174-183
25 Series Options/Trims/Accessories/Parts ...............184-194
25 Series Exploded View ................................196-209
24 Series................................................. 210-217
24 Series Options/Trims/Strikes/Accessories/Parts .......218-227
24 Series Exploded View ................................228-239
19 Series ................................................240-243
19 Series Options/Trims/Strikes/Accessories/Parts ......244-250
19 Series Exploded View..................................252-257
20 Series ....................................................258
1490 Series .............................................259-260
1590 Series ..............................................261-262
1490-1590 Series Exploded View ........................263-270
1690 Series ..............................................271-272
1690 Series Exploded View...............................273-275
1790 Series...............................................276-277
1790 Series Exploded View .............................. 278-279
1990 Series ............................................. 280-281
1990 Series Exploded View..............................282-285
2090 Series.............................................286-287
2090 Series Exploded View ............................. 288-291
2390 Series ..................................................292
2390 Series Exploded View .............................294-297
Exit Accessories .........................................298-299
Mullions/Mullion Options ....................................298
Numerical Index.........................................300-302
Closers
Available Finishes ............................................303
Common Applications .......................................304
SC Series Options ............................................305
SC60/SC60A Series Surface Mount ..........................306
SC70/SC70A Series Surface Mount ...........................307
SC80/SC80A Series Surface Mount ..........................308
SC90 Series Surface Mount ..................................309
OHC Series Concealed........................................310
8200 Series Auto Operator....................................311
8300 Series Actuators & Accessories ..........................312
Electronics
Power Supplies ..........................................313-314
Warranty..................................................... 315
Locks
Miscellaneous Information ..................................... 8
Finishes........................................................ 9
Forms & Examples ......................................... 14-27
Product Index ............................................163-166
MA Series ..................................................29-42
RU Series ..................................................43-56
T Series ....................................................57-70
X Series .....................................................71-78
K Series ....................................................79-84
D100 Series ............................................... 85-94
B Series ...................................................95-102
W Series ..................................................103-112
D200 Series...............................................113-124
H2 Series.................................................125-134
Cylinders .................................................135-152
Auxillary Products........................................153-162
Price Book 8
Effective April 4, 2020 • Rev. 04/20
4
General Terms and Conditions of Sale and Service
Allegion General Terms and Conditions of Sale and Service
1. GENERAL/ACCEPTANCE. (a) This Agreement contains the only terms and conditions by
which Company will quote and sell Deliverables to Customer; (b) The terms “purchase order”
or “order” for the purposes of this Agreement include the term “request for quotation,” as
appropriate; (c) This Agreement supersedes all pre-printed or boilerplate terms and conditions
set forth in any purchase order issued by Customer; (d) No reference herein to Customer’s
purchase order will in any way incorporate different or additional terms and conditions, all
of which Company hereby expressly objects to; (e) ANY ACCEPTANCE BY COMPANY OF
CUSTOMER’S PURCHASE ORDER IS EXPRESSLY CONDITIONED ON THE CUSTOMER’S
ASSENT TO AND ACCEPTANCE OF THE TERMS AND CONDITIONS CONTAINED IN THIS
AGREEMENT; (f) Company reserves the right to decline any order, in whole or in part, for any
reason.
2. ORDERS.
a. Order Processing. When Customer wishes to place an order for Deliverables, it will deliver to
Company a purchase order. All such purchase orders must (i) be in a written format acceptable
to Company, (ii) be legible, (iii) include a purchase order number, (iv) include Customer’s account
number, invoice address, ship to address, shipping method, shipper’s letter of instruction for
international shipments, part number, pricing, and designated contact information, (v) include,
if applicable, any special configuration ID numbers, necessary programming information, special
factory instructions, and requested specifications regarding a particular finish, handing, design,
backset, or strike, (vi) reference any applicable pricing discounts under an ongoing buying
program or based on a written quote from Company, along with the applicable buying program
number or quotation number, and (vii) not combine buying program and quoted product on the
same order.
b. Minimum Orders. In the event the order value does not meet any required minimum
net Deliverable value, Company may, at its sole discretion, (i) increase the quantity of items
in the order to meet the minimum net Deliverable value requirement; (ii) apply a minimum
order charge; (iii) reject the order, or (iv) waive the requirement, provided that the waiver of a
requirement for one order shall not constitute a waiver of the requirement for any future orders.
c. Acceptance of Purchase Orders. Company will endeavor to (i) acknowledge receipt of
each purchase order issued in accordance with this Agreement, and (ii) notify Customer whether
Company accepts or rejects the purchase order. If Company fails to accept or reject a purchase
order within a reasonable time period, such failure to respond will be deemed a rejection of the
entire order. Orders that combine buying program and quoted product on the same order will be
routed back to your local RSO office in order to review subject purchase order.
d. Changes to Order/ Cancellation of Orders. Additional terms and conditions regarding order
changes and cancellations are available on the Allegion customer website, WHICH TERMS
ARE EXPRESSLY INCORPORATED HEREIN BY REFERENCE. Unless otherwise provided
herein, Customer acknowledges that (i) requesting a Change Order may cause a delay in the
scheduled shipment date, a longer lead time or result in a new scheduled shipment date; (ii)
Orders may not be changed after 48 hours of Company’s order acknowledgment; (iii) After 48
hours of Company’s order acknowledgment, all changes to an accepted purchase order will be
subject to a Change Order charge of 25% of the net Deliverable value, plus the cost of labor and
fabrication or raw material that Company incurred prior to the receipt of the Change Order from
Customer, or that may be required due to the Change Order; (iv) the requested change may
result in additional charges for labor, fabrication, and raw material, and (v) if Customer cancels
an order or portion of an order that includes Deliverables that have been manufactured and
prepped for shipping, a 45% restocking fee will apply. Notwithstanding the foregoing, Customer
cannot change or cancel credential orders, reader orders, biometrics orders or any non-cataloged,
special, Custom or nonstandard items once they have been placed. All cancelled orders for a
Non Recurring Expense (NRE), credential orders, reader orders, biometrics orders, and/or Custom
orders will be subject to a cancellation charge of 100% of the acknowledged price.
e. Add-ons. Add-on orders will not be accepted. Additions to orders will be entered as
separate stand-alone orders and must qualify for all terms of sale, including discounts, on an
individual basis.
f. Fast-Track Orders. No changes or cancellations will be accepted on the 24-Hour Fast
Track Program. For 3-day Fast Track orders, changes and cancellations may only be requested
by Customer within 24 hours of Company’s order acknowledgment if the order has not shipped.
For 5-Day Fast Track orders, changes and cancellations may only be requested by Customer if
the order has not shipped and if the request is made to Company within 48 hours of Company’s
order acknowledgment. Return Material Authorization (RMA) for Deliverables must be processed
through Fast Track Customer Service.
g. Steelcraft Orders. For all Steelcraft orders, changes or cancellations are allowed without
penalty only if made within 48 hours of Company’s order acknowledgment, and provided that
the order has not shipped. Some exceptions do apply – please consult the factory. Changes
are not allowed on Rapid Program orders after the order has been entered and acknowledged.
After 48 hours of Company’s order acknowledgment, all changes or cancellations are subject to
a charge of 25% of the order. Unless otherwise specified by Company in writing, any changes
to orders acknowledged by Company that affect the delivery date will be deemed a new
order and will require acknowledgement by Company as provided in this Section. Additional
products, features, terms and conditions regarding the Rapid Program are available on the
Allegion customer website, WHICH TERMS ARE EXPRESSLY INCORPORATED HEREIN BY
REFERENCE.
3. PRICES, INVOICES AND PAYMENT.
a. Prices. The prices in Company’s Price Book are subject to change at any time, without
notice to Customer. Company may charge Customer additional amounts if Customer requests
special packing, marking, shipment, product modification, or engineering services. Oral prices
specified by Company are null and void. Quote numbers must be referenced on Customer’s
purchase order in order for the Company’s quoted pricing to apply. Orders that do not reference
a quote number will receive buy program pricing or book net pricing. Quoted prices are for those
specific products quoted for a specified job, and are subject to the Price Book in effect at the time
Company receives the order.
b. Taxes. Prices do not include any present or future federal, state or local property, license,
privilege, sales, use, excise, gross receipts or other like taxes or assessments which may result
from transactions or any services performed in connection therewith. Any taxes, charges,
or duties imposed by any governmental authority on the sale of Deliverables will be paid by
Customer, in addition to the selling price specified by Company. Credits for U.S. sales tax applied
to invoices will only be granted if valid exemption documentation is provided within 30-days
of the invoice date and a case is initiated by customer service. Exemption documentation
may be emailed to sales.tax.certificates@allegion.com, this e-mail address cannot be used to
request a credit for sales tax charged all such requests must be made with customer service.
All certificates sent to the e-mail address must include the following information: (1) Customer
account number(s); (2) Customer name; and (3) Allegion brand(s) the certificate should be
applied to.
c. Payment Terms. Company will deliver to Customer an invoice with each shipment of
Deliverables hereunder. Customer will pay all invoiced amounts within 35 days of the invoice
date (subject to any early pay discounts that may be offered to Customer by Company in its
sole discretion). Customer will make all payments in United States dollars. Past due invoices
will be subject to a late payment service charge of 1.5% per month on any overdue unpaid
balance, equivalent to 18% per annum, or the maximum rate permitted by law, whichever is
less. Customer shall reimburse Company for all costs of collection, including, without limitation,
reasonable attorneys' fees, for any overdue amount owed by Customer to Company, and such
collection costs shall also be subject to interest charges.
4. QUOTATIONS.
a. Project Quotations. Project or new construction quotes are restricted to the specific project
quoted for the quantities, finishes, and series of Deliverables referenced on the quote. Company
reserves the right to require proof of sale of Company products for any quoted project.
b. Stock Quotations. Deliverables fulfilling stock quotations may only be used for the
following: i) Stocking of the Customer’s shelves for small, quick-turn, discretionary projects, or
ii) Sale to a general contractor or installer for new construction. Stock quotations may not be
used for any project containing any Company no-substitution, specified products. Deliverables
purchased under Stock Quotations cannot be redistributed to other Customer branch locations
or re-sold to other resellers or used for aftermarket sales, end-user annual contracts or sold over
the counter to any walk in trade.
c. General. All quotes are subject to this Agreement, unless otherwise specified by Company,
and are subject to change at any time prior to Company’s acceptance of a purchase order
referencing the applicable quote number. Company, its representatives and employees reserve
the right, in their sole discretion and for any reason, to refuse a Customer’s request to quote a
price other than the standard list price, regardless of whether Company or its representatives
or employees have previously quoted discounted prices to the Customer on some or all of its
orders. Customer’s failure to comply with this Section 4 will be considered a material breach of
this Agreement, and will entitle Company to immediately terminate any purchase orders and/or
Customer’s ability to distribute Company’s products.
5. SECURITY INTEREST. Customer grants Company, and Company retains, a purchase
money security interest and lien on any and all of Customer’s rights, title and interest in each
Deliverable sold by Company to Customer, wherever located, until the invoice for the applicable
Deliverable(s) is paid in full, including any late charges and costs of collection. Customer
authorizes Company to, and will assist Company in, taking all necessary steps to perfect and
maintain Company’s interest in such Deliverables.
6. CREDIT TERMS. . Unless Customer pre-pays all of its purchase orders in advance, its
purchase orders will be subject to the credit limit and other terms of credit (“Credit Terms”) set
forth in Company’s credit application, which Credit Terms Customer acknowledges are subject
to change by Company at any time. Company reserves the right to request payment in advance
of shipment or any order or to request adequate assurances for Customer’s payment of an order
and may withhold or stop shipment, without any liability to Company, until Customer submits
payment or adequate assurance of payment.
7. RESALE OF DELIVERABLES. Customer agrees and warrants that it will offer Company
products in support of Company-written specifications and will maintain sufficient inventory
to adequately support End Users, installers, and/or general contractors’ needs. Company may
implement an MSRP or a resale pricing programs at any time in its sole discretion. Failure to
comply with such program(s) will be considered a material breach of this Agreement, and will
entitle Company to immediately terminate any purchase order and/or Customer’s ability to
distribute Company’s products. Customer shall, at its own expense, gain and maintain sufficient
knowledge of the industry and products competitive with Deliverables so as to be able to (a)
explain in detail to End Users, installers, and/or general contractors the differences between the
Deliverables and competing products, (b) ensure that an adequate number of trained, capable
and qualified technical personnel with sufficient knowledge of the Deliverables and who have
obtained all necessary licenses and permits are available to assist End Users, installers, and/or
general contractors, and (c) respond to such End Users, installers, and/or general contractors
with respect to the general operation and use of the Deliverables including, but not limited to,
(1) acting as a liaison between the End Users, installers and/or general contractors and Company
in matters requiring Company participation, (2) providing general product information and
configuration support on standard protocols and features, (3) collecting relevant technical
problem identification information, and (4) posting and distributing any warranty information
concerning the Products in accordance with Company’s instructions. Customer is responsible for
all service and support resulting from the re-sale of any Deliverable to End-Users, installers and/
or general contractors, examples of which may include, but are not limited to, support activities
such as installation, initialization, software set-up, training, trouble-shooting, technical support
and field service. In the event Customer is unwilling or unable to perform said support activities,
Company reserves the right to recover from Customer any and all expenses incurred by Company
to resolve the afore-mentioned End-User, installer and/or general contractor issues. Technical
product training is recommended for Customer in order to fully service and support Deliverables
purchased from Company that are resold to End-Users, installers and/or general contractors.
8. DEFAULT. If Customer is in default of payment or otherwise with respect to any purchase
order or other contract with Company, Company shall have the right, in addition to all other legal
remedies and without prejudice to any of its right hereunder, to defer further shipments under
that or any other purchase order until such default is corrected and to declare all outstanding
bills of Customer to be immediately due and payable.
9. INSPECTION AND DELIVERY.
a. Inspection. Customer will inspect all Deliverables immediately after receiving them.
Customer will be deemed to have accepted the Deliverables unless Customer notifies Company
in writing of any nonconformance within 10 days of delivery and provides Company written
evidence reasonably documenting that nonconformance. Inspection of Deliverables at
Company’s facility is not permitted.
b. Delivery. Delivery schedules for Deliverables are based upon current production capacities,
material or component availability, and inventory, and may be changed by Company as
conditions require. Delivery schedules for services are based upon Company’s prompt receipt
of, and prompt access to, Customer’s equipment and all information necessary to complete the
services. In no event will any delivery date be construed as falling within the meaning of “time is
of the essence.” Partial delivery shall be accepted by Customer and paid for at the price and on
the terms stated herein. Any partial delivery shall constitute a separate sale, and payment shall
be separately made when due. If any part of a delivery hereunder is not delivered by Company in
accordance with Customer’s purchase order, this Agreement shall not be affected thereby.
5
Price Book 8
Effective April 4, 2020 • Rev. 04/20
General Terms and Conditions of Sale and Service
10. TITLE & RISK OF LOSS. Unless otherwise specified by Company, (i) where the Customer is
located in the United States, all Deliverables will be sold “Uniform Commercial Code, FOB Origin,
Company’s factory”; and (ii) where the Customer is located outside of the United
States, all Products will be sold “Ex-works, Company’s factory (Incoterms 2010).” In either
instance, title and risk of loss will pass to Customer upon delivery to the carrier at Company’s
factory, provided, however, as set forth herein, Company shall retain a security interest in the
Deliverables until full payment has been made therefore, and Customer agrees, upon request,
to do all things and acts necessary to protect Company’s interest by adequately insuring
the Deliverables against loss or damage from any cause and to have Company named as
an additional insured. Customer will promptly provide Company with a copy of the relevant
certificate of insurance upon Company’s request.
11. SHIPPING.
a. Freight Charges. Company will ship all Deliverables in accordance with Company’s
freight shipment guidelines, which are set forth on the My Allegion Portal (“Freight Shipping
Guidelines”), WHICH TERMS ARE EXPRESSLY INCORPORATED HEREIN.
b. Rush Charges. Expedited order options are available as set forth in Company’s Freight
Shipping Guidelines.
c. Packing and Marking. Company will pack, mark, and ship Deliverables according to its
standard procedures for shipment, unless the parties agree, in writing, that Company will
comply with any special instructions provided by Customer. Special instructions may result in an
increased price.
d. International Shipments. For all international orders, a Shipper’s letter of instruction must
be submitted in writing with the order. Failure to do so will result in the order being rejected.
Complete adherence to this order requirement will be strictly enforced. Company will not be held
liable for any charges resulting from delays due to lack of complete required information being
supplied.
e. Once received by the Company, a purchase order cannot be combined with any other order
to increase average order size as it relates to Company’s Freight Shipping Guidelines. However,
for orders placed under Company’s FastTrack 24 Hour/5 Day Program (available for Schlage, Von
Duprin, LCN and Glynn-Johnson products); ii) FastTrack 24 Hour/3 Day Program (available for
Ives products); or ProExpress (available for specific product lines stated in the ProExpress price
book for Falcon, Ives, Glynn Johnson, LCN, Schlage and Von Duprin products), the applicable
brands or product categories may, subject to certain order requirements identified by Company,
be combined on a single order to increase average order size used in Company’s Freight Shipping
Guidelines.
12. CLAIMS. All claims must be submitted in writing to Company as follows: (i) All claims for
prices must be submitted within thirty (30) days from the date of invoice; (ii) All claims regarding
Deliverable quantity or incorrect orders must be submitted within ten (10) days from the date
of delivery; (iii) All claims for damage to Deliverables (while in the care, custody, and control of
Company) must be submitted within thirty (30) days from the date of invoice; (iv) All claims for
loss or damage to Deliverables while in the care, custody, and/or control of a carrier will be the
responsibility of Customer, unless otherwise agreed by the parties.
13. PRODUCT CHANGES. Company’s product policy is one of ongoing update and revision, and
accordingly, Company reserves the right to change, without notice, the design of, or the process
of manufacturing, the Deliverables covered by this Agreement.
14. PRODUCT USAGE LIMITATION. Customer agrees: (i) not to sell or use a Deliverable in any
manner contrary to the manner in which the Deliverable is intended to be used; and/or (ii) not
to modify the design of any Deliverable for use with another product without the prior written
consent of Company.
15. PRODUCT RETURNS. Unless otherwise agreed by the parties in writing, Deliverables
that are correctly furnished by Company per the purchase order may not be returned unless
Customer receives written authorization from Company. If returns are authorized by Company, a
return merchandise authorization (“RMA”) number must be provided by Company. Deliverables
identified under such RMA must be returned to Company within 90 days of issuance of the RMA.
Such RMA number and any accompanying RMA documents, the original invoice number, and
a written explanation for the return must be included with the returned Deliverables in order
for Company to inspect and approve a credit for the return. For warranty returns, a credit in
the amount of the original purchase price will only be issued if, after Company’s receipt and
inspection of the returned Deliverables, Company confirms, in its sole discretion, the defect is
valid and approves the return. For non-warranty returns/convenience returns, in the event
Company approves such a return, in its sole discretion, the following shall apply: (a) the total
amount of Deliverables requested to be returned shall be a minimum of $250.00; (b) a credit
will be made to Customer’s account in the amount of the original purchase price less freight and
a handling charge of 45% of the net material on the original invoice; and (c) only Deliverables
that are new, current, standard, non-obsolete, non-specially manufactured, unused, in their
original condition as at the time of sale by Company to Customer, in their original packaging and
in Customer’s inventory less than 180 days from the date of shipment by the Company, and not
ordered as part of a master key solution may be considered by Company for return. Such credit
will only be issued if, after Company’s receipt and inspection of Deliverables, Company approves
the return. The amount of final credit will be determined upon receipt at the factory and
following Company’s inspection and analysis of the condition of the returned material. Company
retains the right to deny credit to anyone for any reason.
16. CONFIDENTIAL INFORMATION.
a. Non-Use And Non-Disclosure. Customer shall not use the Confidential Information of the
Company except for the purpose of performing its obligations under this Agreement or exercising
the rights granted herein (the “Purpose”). Customer shall protect Confidential Information of
the Company from disclosure and unauthorized use in the same manner that it protects its own
Confidential Information, but in no event shall such standard of care be less than reasonable
care. Customer may disclose Confidential Information of the Company only to its employees who
require such information for the Purpose and who are subject to confidentiality obligations at
least as protective as those set forth herein.
b. Proprietary Information and Advice. (a) All designs, data, and specifications provided by
Company are proprietary and may not be disclosed or reused by Customer without the prior
written consent of Company; (b) Company assumes no obligation or liability for any advice given
by Company, the results obtained, or damages incurred as a result of such advice, and all such
advice is given and accepted at Customer’s risk.
c. Return. Upon the termination or expiration of a purchase order or this Agreement or upon
the request of the Company, the Customer agrees to end all further use of, to immediately
return to the Company the original version of, and to delete or destroy all copies of, any and all
Confidential Information of the Company.
17. TRADEMARKS. Except as agreed to by Company in writing, Customer agrees not to (a)
use Company’s name in any form of publicity; or (b) use, create, register or market, directly or
indirectly, in whole or in part, Company’s names, logos, brands, or any other trademarks, or
names that are now or may hereafter be owned by Company, as part of Customer’s corporate
or business name, as part of an internet domain name, uniform resource locator (URL), or in any
way connected with Customer’s business, trade address or other designations. Upon termination
of this Agreement or upon the request of company for any reason, any use of Company’s
trademarks or names will be immediately discontinued.
18. LIMITED WARRANTY.
COMPANY MAKES NO OTHER WARRANTIES EXCEPT THOSE STATED IN COMPANY’S
LIMITED WARRANTY IN EFFECT ON THE DATE COMPANY ACCEPTS EACH APPLICABLE
PURCHASE ORDER (“LIMITED WARRANTY”). THE LIMITED WARRANTY MAY BE
FOUND IN THE APPLICABLE PRICE BOOK AND ON THE ALLEGION CUSTOMER WEBSITE,
WHICH TERMS ARE EXPRESSLY INCORPORATED HEREIN BY REFERENCE. COMPANY
WILL MAIL CUSTOMER A HARD COPY OF THIS WARRANTY UPON CUSTOMER’S
WRITTEN REQUEST. IN THE EVENT THAT CERTAIN DELIVERABLE WARRANTIES ARE
NOT FURNISHED BY THE COMPANY TO CUSTOMER, COMPANY WARRANTS ONLY TO
CUSTOMER THAT THE DELIVERABLES WILL BE FREE FROM DEFECTS IN MATERIAL
AND WORKMANSHIP FOR A PERIOD OF 12 MONTHS FROM THE DATE OF SHIPMENT
OF THE DELIVERABLES. COMPANY’S SOLE OBLIGATION UNDER THIS WARRANTY
IS LIMITED TO REPAIRING OR REPLACING, AT COMPANY’S OPTION, THE DEFECTIVE
DELIVERABLE, PROVIDED WRITTEN NOTICE OF THE DEFECT OR NONCONFORMANCE
IS PROVIDED BY CUSTOMER WITHIN 30 DAYS OF DISCOVERY OF THE DEFECT OR
NONCONFORMANCE. COMPANY DISCLAIMS ALL OTHER WARRANTIES, EXPRESS OR
IMPLIED, WITH RESPECT TO THE DELIVERABLES, INCLUDING BUT NOT LIMITED TO,
ANY IMPLIED WARRANTIES OF NON-INFRINGEMENT, MERCHANTABILITY, OR FITNESS
FOR A PARTICULAR PURPOSE.
a. Exclusions. The provisions of this Limited Warranty do not apply to Deliverables that: (A)
are not the proper size for the application; (B) are not installed in accordance with Company’s
published installation instructions; (C) are installed with improper or incorrect parts and/or
are used for purposes for which they are not designed or intended; (D) have been repaired or
altered without the Company’s prior written consent; (E) have been subjected to misuse, abuse,
negligence or accident; (F) have been improperly stored, installed, maintained or operated;
(G) have been used in violation of written instructions provided by Company to Customer; (H)
have been subjected to improper temperature, humidity, or other environmental conditions,
or (I) have been affected by normal wear and tear. In addition, the provisions of this Limited
Warranty do not apply to any defects or issues with the design or performance of equipment
or products not manufactured by Company, nor does it apply to any code compliance or permit
requirements for the assembly, installation, erection or construction of any goods. Company is
not responsible for loss or damage resulting from use of Deliverables in conjunction with parts or
systems not manufactured by Company. Accessories or products furnished by the Company, but
manufactured by others, shall carry whatever warranty the manufacturers have conveyed to the
Company and which can be passed to Customer.
b. Services. Company warrants that its services will be free from defects in material
and workmanship for a period of 12 months from the date of completion of the particular
items of service. Company’s sole obligation under this service warranty is limited to repair or
reperformance, at its option of the service, provided however, if repair or reperformance is either
impractical or impossible, the Company will refund to Customer that portion of the price paid to
Company for any defective service, provided written notice of the defect or nonconformance is
provided by Customer within 30 days of discovery of the nonconformance.
c. Notification. Customer agrees to immediately notify Company in writing if any claim is
made against Customer for any damages caused by any modules, parts, products, service or
other Deliverables which may be the direct result of any defect in the manufacture of such
aforementioned products. Customer agrees to cooperate with Company and its counsel in the
defense of such claim and Customer agrees not to settle such claim without Company’s written
consent. If Customer fails to notify Company of such claim or fails to cooperate in such defense
as aforesaid, then Company shall be discharged from any obligations under this Section and shall
have no further liability to Customer.
d. Exceptions. The following costs and expenses are not covered by the provisions of these
limited warranties: (i) labor costs for the removal and reinstallation of Deliverables or other
manufacturer’s products; (ii) shipping and freight expenses required to return Deliverables to
Company; (iii) normal maintenance; and (iv) economic losses. In addition, the provisions of this
warranty are not applicable to anything other than defects in Company’s material (products
only) or workmanship.
19. LIMITATION OF REMEDIES.
CUSTOMER’S EXCLUSIVE AND SOLE REMEDY ON ACCOUNT OF, OR IN RESPECT
OF, THE FURNISHING OF NON-CONFORMING DELIVERABLES, SHALL BE TO (A)
SECURE REPAIR OR REPLACEMENT OF THE PRODUCTS; OR (B) SECURE REPAIR
OR RE-PERFORMANCE OF THE SERVICES OR TO OBTAIN A REFUND OF THE PRICE
PAID FOR THE DEFECTIVE SERVICE, ALL AT COMPANY’S OPTION. IN NO EVENT
WILL THE COMPANY’S MAXIMUM LIABILITY EXCEED THE SELLING PRICE FOR THE
DELIVERABLE. THE WARRANTY, OBLIGATIONS AND LIABILITIES OF COMPANY
(INCLUDING ITS SUPPLIERS) AND THE RIGHTS AND REMEDIES OF CUSTOMER ARE
EXCLUSIVE AND ARE IN LIEU OF AND CUSTOMER HEREBY WAIVES AND RELEASES ALL
OTHER WARRANTIES, OBLIGATIONS, REPRESENTATIONS OR LIABILITIES EXPRESS
OR IMPLIED ARISING BY LAW, IN CONTRACT, TORT (INCLUDING NEGLIGENCE OR
STRICT LIABILITY) OR OTHERWISE, INCLUDING BUT NOT LIMITED TO (I) ANY IMPLIED
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE
OR ANY WARRANTY IMPLIED THROUGH COURSE OF PERFORMANCE, COURSE OF
DEALING, OR USAGE OF TRADE OR (II) CLAIMS ARISING OUT OF THE NEGLIGENCE OF
COMPANY OR COMPANY’S SUPPLIERS OR (III) ANY OTHER CLAIM ARISING OUT OF,
CONNECTED WITH, OR RESULTING FROM THE PERFORMANCE OF COMPANY OR FROM
THE DESIGN, MANUFACTURE, SALE, REPAIR, LEASE OR USE OF THE DELIVERABLE, OR
ANY COMPONENT THEREOF, DELIVERED OR RENDERED HEREUNDER OR OTHERWISE.
20. INDEMNIFICATION AND LIMITATION OF LIABILITY. a. Customer shall indemnify,
defend and hold Company, and its officers, directors, employees, customers, Affiliates,
suppliers, users and agents, (collectively the “Indemnitees”) harmless from and against any
and all damages, claims, losses, expenses, costs, obligations, liabilities, including without
limiting the generality of the foregoing, liabilities for court costs and attorneys’ fees, suffered
directly or indirectly by an Indemnitee by reason of, or arising out of any injury, death or loss
to any person, or injury to any property (collectively, “Damages”), received or sustained by any
person(s) or property, arising out of, occasioned by, attributable or related to i) any breach of
any representation or warranty made by Customer, its officers, directors, employees, affiliates,
users, agents, representatives or customers to Company or any third party, (ii) any failure by
Price Book 8
Effective April 4, 2020 • Rev. 04/20
6
General Terms and Conditions of Sale and Service
Customer to perform or fulfill any of its covenants, acts and/or omissions to Company or to
any third party, or (iii) any litigation, proceeding or claim by any third party relating in any
way to the obligations of Customer and/or the Deliverables sold by Company to Customer
hereunder. Customer shall not consummate any settlement of any indemnified claim without
the Indemnitees’ prior written consent. Customer’s obligation to indemnify Indemnitees will
continue in full force and effect notwithstanding the termination or expiration of any order
under this Agreement. In any claim against an Indemnitee by an employee of Customer or any
subcontractor or anyone directly or indirectly employed by any of them or anyone for whose
acts they may be liable, the indemnification obligations set forth in this Section shall not be
limited in any way by or for Customer or any subcontractor under any applicable worker’s
compensation act, disability or other employee benefit act, or insurance coverage. This provision
shall survive termination of any order or Agreement. IN NO EVENT WILL COMPANY, ITS
OFFICERS, DIRECTORS, EMPLOYEES, CUSTOMERS, AFFILIATES, USERS AND AGENTS,
(NOR COMPANY’S SUPPLIERS) BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL,
INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OF ANY KIND OR NATURE UNDER ANY
CIRCUMSTANCES INCLUDING, BUT NOT LIMITED TO, LOSS OF USE OF THE PRODUCTS,
SERVICE INTERRUPTION, LOSS OF PROFITS, LOSS OF REVENUE, LOSS OF INTEREST,
LOST GOODWILL, LOSS OF DATA, WORK STOPPAGE, IMPAIRMENT OF OTHER GOODS,
LOSS BY REASON OF SHUTDOWN OR NON-OPERATION, INCREASED EXPENSES OF
OPERATION, OR CLAIMS OF CUSTOMER’S CUSTOMERS, OR ANY OTHER LOSSES
OR DAMAGES ARISING OUT OF ANY LACK OR LOSS OF USE OF THE DELIVERABLES
WHETHER BASED ON CONTRACT, WARRANTY, TORT (INCLUDING, BUT NOT LIMITED
TO, STRICT LIABILITY OR NEGLIGENCE), PATENT INFRINGEMENT, OR OTHERWISE,
EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
b) INTELLECTUAL PROPERTY INDEMNITY. Company makes no representation or warranty
to the Customer that the Deliverables shall not infringe any intellectual property rights including,
without limitations, claims arising from patent, copyright, trademark, trade secret, or other
intellectual property infringement. Customer agrees to hold Company harmless from and
defend the Company against any such claim of intellectual property infringement, including any
Damages resulting from that claim, the cost of complying with any preliminary or permanent
injunction, and all other costs of defense (including the attorneys’ fees and costs), in connection
with the foregoing.
c) To the extent that applicable law does not permit any limitations set out in this Agreement,
such limitation shall not be applied or invoked. Nothing in this Agreement will be interpreted
to disclaim liability of Company or the Indemnitees for gross negligence or willful misconduct.
The limitations of remedy and liability herein shall not be interpreted to affect Company’s
obligations, if any, for claims for (i) property damage, (ii) personal injury, or (iii) wrongful
death asserted by persons who are not parties to or beneficiaries of this Agreement. Further,
the limitations of remedy and liability herein shall not be interpreted to limit Company’s or
Customer’s right, if permitted by applicable law, to assert a claim for contribution among joint
tortfeasors in connection with a claim by a person who is not a party to this Agreement.
21. CERTIFICATIONS. Certification of Deliverables for compliance with UL and ANSI standards
are tested and performed by third-party independent laboratories. Any field modification or
alteration of certified Deliverables will void certification and Company is not liable to Customer
to certify any modified or altered Deliverable.
22. TERM FOR CLAIMS. NO ACTION ARISING OUT OF ANY CLAIMED BREACH OF THIS
AGREEMENT BY COMPANY MAY BE BROUGHT BY CUSTOMER MORE THAN ONE (1)
YEAR AFTER THE CAUSE OF ACTION HAS ARISEN.
23. CONSUMER PRODUCTS
WITH RESPECT TO “CONSUMER PRODUCTS” AS DEFINED UNDER THE MAGNUSON-
MOSS WARRANTY ACT (“MMWA”), THE FOLLOWING STATEMENTS ARE MADE.
(A) SOME STATES OR LOCAL LAWS DO NOT ALLOW LIMITATIONS ON HOW LONG
AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY
TO YOU; (B) IF ANY IMPLIED WARRANTY IS PROVIDED UNDER THE MMWA, IT IS
LIMITED TO THE DURATION OF THE WARRANTY PROVIDED IN SECTION 18 ABOVE.
(C) SOME STATES OR LOCAL LAWS DO NOT ALLOW THE EXCLUSION OR LIMITATION
OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR
EXCLUSION MAY NOT APPLY TO YOU; AND (D) THIS WARRANTY GIVES YOU SPECIFIC
LEGAL RIGHTS AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE
TO STATE OR LOCATION TO LOCATION.
24. FORCE MAJEURE/EXCUSABLE DELAY. Any delay or failure of Company to perform its
obligations hereunder will be excused to the extent that it is caused by an event or occurrence
beyond Company’s control such as, by way of example and not by way of limitation, acts of
God, acts by any governmental authority (whether valid or invalid), governmental laws and
regulations not presently in effect, fires, floods, windstorms, explosions, riots, natural disasters,
wars, sabotage, accidents, labor problems (including, without limitation, lockouts, strikes, and
slowdowns) at Company’s facility, its source plant or their suppliers, inability to obtain power,
material, labor equipment, or transportation, or court injunction or order. The delivery date will
be extended for a time equal to that of the delay and the schedule for Company’s performance
will be deemed adjusted to that effect.
25. ENTIRE AGREEMENT AND AMENDMENT. This Agreement, together with the
attachments, exhibits, webpages, or supplements specifically referenced and incorporated
herein, constitute the entire agreement between Company and Customer with respect to
the matters contained herein and supersede all previous communications, representations,
or agreements, either oral or written between Company and Customer. No agreement or
understanding varying or expanding this Agreement will be binding upon either party unless it is
in writing and signed by a duly authorized representative of each party hereto.
26. CONFLICTS. In the event of any conflict or inconsistency between the terms of any
agreement, or any part of an agreement or the various documents (including, but not limited to,
electronic documents) between Company and Customer, unless the parties agree otherwise in
writing, the various components of the agreements shall be given the following precedence (in
descending order of precedence): a) any master agreement or long term agreement between
Company and Customer; b) any specific terms, conditions and/or warranties of the individual
products or Deliverables; c) the terms and conditions of this Agreement, and d) any purchase
order.
27. UNSATISFACTORY CREDIT/TERMINATION FOR INSOLVENCY OR DEFAULT.
Customer shall furnish Company with statements evidencing Customer’s financial condition as
Company may, from time to time, reasonably request, and shall notify Company immediately of
any and all events that may have a material adverse effect on Customer’s business or financial
condition. If Company determines, in its sole discretion, that Customer’s financial condition or
creditworthiness is inadequate or unsatisfactory, then in addition to Company’s other rights,
Company may without liability or penalty, take any of the following actions: (i) modify the
payment terms for any outstanding and/or future purchases; (ii) cancel any previously accepted
orders; (iii) delay any further shipment of Deliverables to Customer; or (iv) any combination of
the above.
Company may immediately terminate an order from Customer by giving written notice to
Customer in the event of the happening of any of the following or any other comparable event:
(i) insolvency of the Customer; (ii) filing of a petition in bankruptcy by or against the Customer;
(iii) appointment of a receiver or trustee for the Customer; (iv) execution of an assignment for
the benefit of creditors by the Customer, all of which will allow Company to demand reclamation
of all affected orders; (v) Customer ceases or threatens to cease to trade; (vi) Company
determines that Customer does not meet or no longer meets the credit requirements of
Company or Customer’s credit account is closed; (vii) any Customer violation of law, specifically
including, without limitation, those laws set forth in this Agreement.
In the event of termination in accordance with this section, Company will not be obligated to
accept any existing or additional orders from Customer and Company will be released from
its obligation to deliver under orders accepted prior to such termination. The rejection or
termination of any order by Company will not entitle Customer to any termination or severance
compensation, or to any payment in respect to any goodwill established by Customer, or render
Company liable for damages on account of the loss of prospective profits, or on account of any
loss, expenditure, investment or obligation incurred or made by Customer.
No action taken under this Section 27 by Company (nor any failure of Company to act under
this Section 27) will constitute a waiver by Company of any of its rights to enforce Customer’s
obligations, including the obligation of Customer to make payments as required under this
Agreement. Upon termination of any order, all amounts owed by Customer to Company will
become immediately due and payable, whether or not otherwise then due or payable.
28. CREDIT RISK ON RESALE OF DELIVERABLES. Customer is responsible for all credit risks
with respect to, and for collecting payment for, all Deliverables sold to third parties (including
End Users, installers, and/or general contractors) whether or not Customer has made full
payment to Company for such Deliverables. The inability of Customer to collect payment for any
Deliverable shall not affect Customer’s obligation to pay Company for any Deliverable.
29. GOVERNING LAW; VENUE; AND EXPENSES. Any dispute or claim relating to this
Agreement shall be governed by and construed according to the laws of the State of Indiana
(excluding its conflict of laws principles); and not by the provisions of the 1980 United Nations
Convention on the International Sale of Goods. Any disputes or claims shall be instituted
and maintained in the courts of the State of Indiana. Customer consents to the exercise of
jurisdiction over it by such courts and agrees that Indiana is not an inconvenient forum for any
action arising from or relating to this Agreement. Customer agrees to pay for all expenses
(including, but not limited to, collection costs, court costs and attorneys’ fees) incurred by
Company in enforcing the obligations of Customer under this Agreement.
30. RELATIONSHIP OF THE PARTIES. Nothing in this Agreement or any other document
creates an employment, partnership, joint venture, or agency relationship between Company and
Customer, including that of franchisee/franchisor. No party will have any power or authority to
enter into any commitment on behalf of or otherwise bind the any other party on any matter.
No employee of Customer will be deemed to be an employee of Company. If any provision of
this Agreement is deemed to create a franchise relationship or business opportunity between
the Parties, then Company may terminate any purchase order or this Agreement or the Parties
shall negotiate in good faith to modify this Agreement so as to effect the original intent of the
Parties as closely as possible in a mutually acceptable manner in order that the transactions
contemplated hereby are consummated as a reseller agreement and not a franchise or business
opportunity agreement.
31. SETOFF. Customer does not have the right to setoff or to back charge against any amounts
which become payable to Company under this Agreement or otherwise. Company will not
accept responsibility for backcharges for the cost of material or labor by Customer or any third
party.
32. ELECTRONIC COMMUNICATIONS AND ELECTRONIC SIGNATURES. Both parties
expressly agree to electronic transactions and acknowledge that documents they sign
electronically will bind them to the same extent as a paper signature. Customer represents
and warrants to Company that only employees authorized to bind Customer legally shall
electronically sign any document under this Agreement. Customer shall comply with any
method of electronic communication/payment processing specified by Company, including
electronic funds transfer, pay-on-receipt processes/systems, order transmission, releases,
electronic signature, and electronic communication systems, including, without limitation, the
use of electronic data interchange (“EDI”) portals. Notwithstanding the foregoing, e-mails, even
those containing a signature block of one of Company’s representatives, shall not constitute a
signed writing.
33. COMPLIANCE WITH APPLICABLE LAWS.
a. General. Company and Customer will comply with all applicable federal, state and
municipal laws, regulations, codes, ordinances and orders that pertain to the Deliverables,
including but not limited to full compliance with any applicable provisions of The Health
Insurance Portability and Accountability Act. Where the Customer is located outside the
United States, or where the customer intends to ship the product outside the United States,
the Customer shall be responsible for compliance with all U.S. export laws, and for filing all U.S.
Electronic Export Information, as applicable.
b. The Customer acknowledges and agrees that: (i) it shall not violate applicable laws and
regulations in performing its duties under this Agreement; (ii) it does not and shall not engage in
any conduct that shall violate any applicable anti-bribery or anti-corruption laws or regulations;
(iii) it (and its owners, officers, directors, employees and agents) shall not pay, offer, promise or
authorize the payment of, either directly or indirectly, anything of value (including but not limited
to cash, gifts and entertainment) to (a) any government official or employee of any government;
(b) any official or employee of any department, agency, or instrumentality of a government;
(c) any employee of any corporation or entity owned or controlled by a government; (d) any
family member of such officials or employees; (e) any political party, party official, or political
candidate; or (f) any other persons, owners, officers, directors, employees and agents of any
corporation or entity; to improperly or illegally assist in obtaining or retaining business (including
but not limited to any contracts, avoidance of duties or reduction of tariffs, reduction of taxes or
7
Price Book 8
Effective April 4, 2020 • Rev. 04/20
General Terms and Conditions of Sale and Service
to obtain money owed, or to obtain regulatory approval) or for the purpose of causing, soliciting
or inducing the sale and purchase of the Deliverables by any party, and (iv) it has full knowledge
of and will comply with the Company’s Code of Conduct for Business Partners as set forth on the
Allegion customer website, WHICH IS HEREBY INCORPORATED BY REFERENCE.
c. The Customer shall indemnify and hold the Company harmless from any claim, demand,
expense or cost arising from any breach of this Article.
d. The Customer shall permit the Company to conduct an audit or review of the Customer’s
financial books and records and business operations at such other times that the Company
considers it necessary to confirm compliance with this provision. Such audit may be conducted
by representatives of the Company or, at the Company’s sole discretion, by a certified public
accounting firm selected by the Company. The Customer shall cooperate with any inquiries from
the Company’s Ethics & Compliance Group.
e. A violation of this provision constitutes a material breach of this Agreement and the
Company may terminate any purchase order or this Agreement immediately, with no opportunity
to cure, in accordance with Section 27 of this Agreement.
f. Notwithstanding the foregoing provisions of this Section 33, (i) Company is not responsible
for obtaining or maintaining any permits for the performance of services or the verification
or compliance with any code requirements relative to the performance of services, (ii) to the
extent any sale of Deliverables pursuant to this Agreement may require approval of the U.S.
Government, Company’s obligations under this Agreement are conditioned upon the grant of
such approval and upon compliance by Customer with any restrictions imposed by the U.S.
Government in connection with such approval, and (iii) in the event the Deliverables are to
be used in a nuclear facility, the Customer shall, prior to such use, arrange for insurance or
governmental indemnity protecting Company against liability. The Customer hereby releases and
agrees to indemnify Company and its suppliers for any nuclear damage including, but not limited
to, loss of use, in any manner arising out of the nuclear incident, whether alleged to be due, in
whole or in part by Company or its suppliers.
g. No Inducements. Each party represents to each other that neither it nor any person
acting on its behalf has, in contravention of any applicable law, given or offered to give or will
give or offer to give, any sum of money or other material consideration to any person, directly
or indirectly, as an inducement to obtain business hereunder or to influence the granting of
licenses or other governmental permissions to enter into this Agreement or perform obligations
hereunder.
h. Equal Employment Opportunity. Company is a U.S. federal contractor that complies with
Executive Order 11246, as amended, and applicable regulations in 41 CFR Parts 60-1 through
60-60, 29 U.S.C. § 793 and applicable regulations in 41 CFR § 60-741; and 38 U.S.C. § 4212 and
applicable regulations in 41 CFR Part 60-250 and 60-300. THE FOLLOWING PROVISIONS
ARE INCORPORATED HEREIN BY REFERENCE: Executive Order 11246, as amended by
Executive Order 13672, and 41 CFR § 60-4.3(a); Executive Order 11701 and 41 CFR §§ 60-250.5(a),
60-300.5; Executive Order 11758 and 41 CFR § 60-741.5(a); U.S. immigration laws, including the
L-1 Visa Reform Act of 2004 and the H-1B Visa Reform Act of 2004; and Executive Order 13496.
i. Ethical Business Conduct. Customer shall adopt and comply with Company’s Business
Partner Code of Conduct which is EXPRESSLY INCORPORATED HEREIN BY REFERENCE.
34. REPRESENTATIONS AND WARRANTIES. Customer represents, warrants and covenants
to Company that: (a) it has the right, power, and authority to enter into this Agreement and fully
perform its obligations hereunder; (b) it has all necessary rights in and to its respective Content
and Marks for use within the scope of this Agreement, including the licenses granted herein; and
(c) it complies, and at all times shall comply, with all laws, rules, and regulations in effect that
are applicable to its performance under this Agreement, including obtaining all such approvals
and/or permits as may be required hereunder.
35. NO THIRD-PARTY BENEFICIARY. Each party is entering into this Agreement solely based
on the representations contained herein for its own purposes and not for the benefit of any third
party.
36. NOTICES AND CHANGE OF ADDRESS. All notices or other communications under this
Agreement shall be in writing and delivered in person, or sent by receipted courier, express mail,
e-mail, or postage prepaid certified or registered mail, addressed to the party for whom it is
intended, at the addresses set forth in this Agreement. Either party may change its address for
notice by giving written notice to the other party. Any notice or other communication shall be
deemed given no later than the date actually received. Notice by courier, express mail, certified
mail, or registered mail shall be deemed given on the date it is officially recorded as delivered
and, in the absence of such record of delivery, it shall be rebuttably presumed to have been
delivered on the third Business Day after it was deposited. Notices sent by e-mail require tangible
confirmation of receipt from addressee.
37. ASSIGNMENT. Customer may not assign this Agreement without the prior written consent
of Company. Company may assign its rights and delegate its duties under this Agreement,
without the prior consent of Customer, to an Affiliate, or to a third party in the event of a spin-
off, merger, business combination, consolidation or sale of all, or substantially all, of its assets or
business that are related to this Agreement. The rights and duties in this Agreement shall bind
and inure to the benefit of any such assignee.
38. SEVERABILITY. If any provision of this Agreement is held to be invalid, illegal, or
unenforceable under any statute, regulation, ordinance, executive order, or other rule of law,
that provision will be deemed severed to the extent necessary to comply with such statute,
regulation, ordinance, order, or rule. In the event such provision is deemed severed, the parties
will negotiate in good faith to arrive at an alternative arrangement approximating the original
business objective of the parties. The remaining terms and conditions of this Agreement will
remain in effect.
39. NO IMPLIED WAIVER. The failure of either party at any time to require performance by
the other party of any provision of this Agreement will in no way affect the right to require
such performance at any time thereafter, nor will the waiver of either party of a breach of any
provision of this Agreement constitute a waiver of any succeeding breach of the same or any
other provision.
40. MISCELLANEOUS. (a) This Agreement does not make either party the agent or legal
representative of the other party. Neither party is authorized to create any obligation on behalf
of the other party including, but not limited to, the obligation for payment of any service or
warranty obligation hereunder; (b) The rights and remedies herein reserved to Company are
cumulative and additional to any other rights and remedies provided at law or equity; (c) The
official text of this Agreement is in the English language. If this Agreement is translated into
another language, the English text will govern any question with respect to interpretation;
(d) The headings in this Agreement are for convenience of reference only and do not affect the
meaning of this Agreement in any manner.
DEFINITIONS.
Capitalized terms have the meanings set forth in this Section, or in the Section in which they first
appear in this Agreement.
“Agreement” means these Allegion Terms and Conditions of Sale and Service, together with
any applicable Country Supplement or Region Supplement provided by Company, and all of the
documents referenced herein or therein.
“Affiliate” means any Person that directly or indirectly, through one or more intermediaries,
controls, is controlled by, or is under common control with, the Company. The term “control”
(including the terms “controlled by” and “under common control with”) means the possession,
directly or indirectly, of the power to direct or cause the direction of the management and
policies of a Person, whether through the ownership of voting securities, by contract or otherwise.
“Business Day” means any day except Saturday, Sunday or any other day on which commercial
banks located in the United States are authorized or required by Law to be closed for business.
“Company” means Schlage Lock Company, LLC or any subsidiary or affiliate thereof selling
products that are part of the Allegion product portfolio. Schlage Lock Company and/or its
subsidiary or affiliates will be severally but not jointly liable under the Agreement.
“Company Marks” refers to the Marks of Company.
“Confidential Information” shall mean any and all information provided by either party to
the other party pertaining to the disclosing party’s business. Confidential Information shall
include, but not be limited to, any bitting lists, formulae for products, manufacturing processes,
production techniques, packaging processes, methods, research materials, ideas, marketing
plans and related materials, quality standards, test results and data, apparatus, engineering
drawings, contract documents, computer software, hardware, or firmware, business activities
information such as financial information, reports, projections, books and records, customer and
supplier information, and operations, customer and supplier lists and data, specifications, know
how, and other Proprietary Information or Trade Secrets (as defined herein) that either party
may furnish to the other party. Confidential Information shall not include information that:
(a) is or becomes publicly known if such public knowledge or disclosure is not the result of any
act or failure to act on the part of the receiving party; (b) is, at the time of disclosure, already
known to the Receiving Party without utilizing the Confidential Information; (c) is information
disclosed to the Receiving Party by a third party which is not to the Receiving Party’s knowledge,
after inquiry of the third party, under a duty of confidentiality to the Disclosing Party; or (d) is
independently developed by the Receiving Party without the use of Confidential Information.
The Receiving Party shall have the burden of proof as to prior knowledge and absence of breach.
Confidential Information may be furnished in any tangible or intangible form including, but not
limited to, writings, drawings, computer and other electronic media, logic diagrams, component
specifications, graphs, prototypes, samples, or verbal communications and regardless of
whether such information is marked or designated as “confidential.” For the avoidance of
doubt, all information, knowledge or data disclosed by Company to Customer, regardless of
whether disclosed in written, tangible, oral, visual or other form, including, without limitation,
sample products, equipment, software, or other objects or material, provided by Company to
Customer, and all information, knowledge or data which was obtained by Customer from visits
to Company’s facilities, shall be considered “Confidential Information” under this Agreement.
“Content” means all information (including without limitation any text, music, sound,
photographs, video, graphics, data or software), in any medium, on a particular Company Web
page or Website or in Marketing Materials.
“Customer” means the purchaser of Deliverables from Company.
“Deliverables” means any good or service or both purchased by Customer from Company under
these General Terms and Conditions of Sale and Service.
“End Users” means the purchaser that (a) has acquired a Deliverable from Customer for (i) its
own and its Affiliate’s/Affiliates’ internal use and not for resale, remarketing or distribution or
(ii) incorporation into its own products and (b) is an individual or entity, other than any federal,
state or local agency, office or division.
“IP” means all intellectual property and industrial property rights comprising or relating to/
of the following: (a) Patents; (b) Trademarks; (c) internet domain names, whether or not
Trademarks, registered by any authorized private registrar or Governmental Authority, web
addresses, web pages, website and URLs; (d) works of authorship, expressions, designs and
design registrations, whether or not copyrightable, including copyrights and copyrightable
works, software and firmware, application programming interfaces, architecture, files, records,
schematics, data, data files, and databases and other specifications and documentation; (e)
Trade Secrets; and (f) all other intellectual property and industrial property rights, and all rights,
interests and protections that are associated with, equivalent or similar to, or required for the
exercise of, any of the foregoing, however arising, in each case whether registered or unregistered
and including all registrations and applications for, and renewals or extensions of, such rights or
forms of protection pursuant to the Laws of any jurisdiction throughout in any part of the world.
“Marketing Materials” means all marketing brochures, buckslips, pamphlets, emails, text, call
scripts or other material, whether in printed format, audio or audiovisual format, or in any other
format, that contain any (i) Content relating to the Company Deliverables or (ii) Company Marks.
“Marks” means collectively the domain names, trademarks, trade names, service marks,
trade dress, logos, and the like used or provided by either party for use in connection with this
Agreement.
“Patents” means all patents (including all reissues, divisionals, provisionals, continuations and
continuations-in-part, re-examinations, renewals, substitutions and extensions thereof), patent
applications, and other patent rights and any other Governmental Authority-issued indicia of
invention ownership (including inventor’s certificates, petty patents and patent utility models).
“Person” means a person or entity.
“Price Books” mean Company’s current Price Book in effect for the applicable Deliverable being
purchased by Customer.
“Trade Secrets” means and includes business or technical information of either party, including
processes, formulas, devices, techniques, compilations and other material that a party attempts
to maintain in secret and that derive commercial value for such party from not being generally
known to the public or readily ascertainable through independent development or reverse
engineering.
Price Book 8
Effective April 4, 2020 • Rev. 04/20
8
LOCKS
Prices subject to change without notice
Miscellaneous Information
LOCKS FOR THICK DOORS
Many Series of Falcon locks are available for doors over 1-3/4" thick. Consult the options section for each series for available door
thicknesses and charges.
LEAD-LINING OR LEAD-WRAPPING
T and RU Series locksets and latchsets are available lead-lined. MA Series locksets are available lead-wrapped. Consult the options
section for each series for availability and charges.
ABRASIVE COATING AND KNURLING
Abrasive coated or knurled knobs or levers are available for most Falcon locksets and latchsets. Consult the options section for each
series for availability and charges.
MOUNTED LOCK SAMPLES
Individual mounted samples are available for all lock series. The samples are mounted on a mount block and are fully operative thus
allowing demonstration of each functions’ individual features. There is a nominal charge for the mount block. There is no charge for
mounting of the hardware. See page 168 for mount selection.
SET OF FINISH SAMPLES
One (1) of each finish on 1-1/4" diameter disks attached together with a bead chain.
Finishes Included: 605, 606, 612, 613, 619, 622, 625, 630, & 643e. Contact your RSO representative for availability.
COMPETITORS’ KEYWAYS
A selection of standard keyways of other lock manufacturers is available as listed below (6-pin only). Consult options sections of each
series for availability. (Not available in any mortise and rim cylinders, except Schlage C, or factory master keyed.)
Furnished 0-Bitted unless otherwise specified. KD option is not available for locks containing 2 cylinders.
INTERCHANGEABLE CORES
The “A” keyway is standard for IC products and will be supplied unless otherwise specified. A, B, C, D, DD, E, F, G, H, J, K, L, M, N, Q, R,
TB, TD are equivalent to Best and Arrow IC keyways of the same names. Consult Allegion Customer Service for restricted keyways not
listed here. Conventional cylinders are not compatible with interchangeable core.
COMPETITORS’ CORES
Falcon standard IC preps accept Arrow (including Flex-Core), Best (including PKS, Peaks and Cormax®), InstaKey, Kaba Peaks,
Keymark and KSP cores. Other brands of interchangeable cores are compatible with T and RU Series locksets. See those sections for
details.
CONVENTIONAL CYLINDERS
The “G” keyway is standard for conventional cylinder products and will be supplied unless otherwise specified. E, H, K, L, N and P are
also available. Consult Allegion Safety Customer Service for restricted keyways and other keyways not listed here.
* Interchangeable core not compatible with conventional cylinders
RESTRICTED KEYWAY POLICY
All keyways not listed in the above statements defined as standard keyways are considered RESTRICTED. Falcon requires a minimum
cylinder order size to qualify for a defined geographic area restricted key system. A letter of authorization is required for the purchase
of keys, locks or cylinders (to include plugs) for a restricted keyway. Contact 877-671-7011 for availability.
Manufacturer Keyway Keying Options
Corbin Russwin 60 O Bitted, KD
L4 O Bitted, KA4
Russwin D1 O Bitted, KD
Sargent LA O Bitted, KD
Schlage CO Bitted, KD, KA4
EO Bitted
Yale 8 (Para) O Bitted, KD
9
Price Book 8
Effective April 4, 2020 • Rev. 04/20
LOCKS
Prices subject to change without notice
Miscellaneous Information
FINISHES
Although we apply the finest available protective plating and/or enamel coating to the surface of our products, these finishes have
limitations and in time may deteriorate either from exposure to weather, pollution, perspiration, extremes of climate, frequency of use
or other factors. Deterioration of these finishes is, therefore, not a defect, but a normal process which is unavoidable. Our Company
cannot accept responsibility for finish deterioration in these circumstances and therefore the finishes cannot be guaranteed. These
products will not be refinished or replaced under our warranty should deterioration of finishes occur.
Some finishes are not suggested for areas that are subject to corrosive climate or chemical conditions. We recommend chrome plated
or stainless steel finishes for these areas.
* 605 Finish is not recommended for corrosive climates.
** Oil rubbed bronze (613) is considered a category “B” finish by ANSI/BHMA and will vary in color when applied to different alloys and forms of base material. 613 will
also vary from production lot and additionally from one manufacturer to another. Oil rubbed bronze will wear off over time due to the “rubbed” finishing method
that has no protective coating or plating.
Please refer to price columns for each lock series for finish availability.
HOW TO SPECIFY FINISHES
STRAIGHT FINISHES: When the finish is to be the same for both sides of the door.
EXAMPLE: 40 EA. 511HG 626
SPLIT FINISHES: Split finishes are available on all models except for Padlocks. Finish may vary from one side of the door to the other
and will be priced at the highest list price of the design/finish chosen.
EXAMPLE: 40 EA. X301TG 606 x 625 (Outside finish is always specified first)
MARKING CARTONS
Markings (e.g., door number, stock reference numbers) on individual product cartons will be provided with no charge.
ANSI/BHMA
Finish
Code
U.S. Standard
Code Description
605* 3Bright Brass - Clear Coated
606 4 Satin Brass - Clear Coated
612 US10 Satin Bronze
613** 10B Satin Bronze; Dark Oxidized and Oil Rubbed
619 US15 Satin Nickel
622 Matte Black
625 26 Bright Chromium
626 26D Satin Chromium
630 32D Satin Stainless Steel
643E US11 Aged Bronze
Price Book 8
Effective April 4, 2020 • Rev. 04/20
10
LOCKS
Prices subject to change without notice
Notes
11
Price Book 8
Effective April 4, 2020 • Rev. 04/20
LOCKS
Prices subject to change without notice
* X Series chassis only.
** SFIC = Small format interchangeable core
Note 1) Failure to use the above fax numbers or mailing address will delay processing of your order.
WHERE TO SEND ORDERS
Type of Order Fax No. Mailing Address
Factory 888-840-7732 (West)
888-840-7735 (East)
Falcon Lock
3899 Hancock Expressway
Security, CO 80911
877-671-7011
PRODUCT IDENTIFICATION CODING
Latch Suffix
D Deadlatch
S Springlatch
Cylinder Suffix
P 6 pin cylinder, keyed to 5 chambers
L Less cylinder
B Less SFIC
BDC Disposable construction core, plastic (SFIC**)
J FSIC core prep (competitor’s full-size IC, designate competitor in
“Additional Details” of Order Form)
G SFIC (Old Falcon designation = WIC)
H Construction Core SFIC (brass, keyed)
BB Best Syle Capped Core (SFIC)
CP6 Schlage C Keyway
Trim and Chassis Prefix
6 Abrasive Lever (6DA = Dane Lever x abrasive strip)
8 Knurled (8TG = Troy-Gala knob trim x knurled lever or knob)
9 Lead-Lined (9AV = Avalon lever x lead-lining of levers (and/or chassis)
XC Corrosion resistant chassis (XC561 = X corrosion resistant chassis,
classroom function)*
Price Book 8
Effective April 4, 2020 • Rev. 04/20
12
LOCKS
Prices subject to change without notice
To order Falcon products, descriptive data should be in the same sequence as shown:
Line
Item Qty Product
Outside Inside
Hand Latch Strike Dr. Thk Ext DIM Additional DetailsDES FIN DES FIN
1 2 3 4 5 6 7 8 9 10 11 12 13 14
1. LINE ITEM: Line item number
2. QTY: Quantity
3. PRODUCT: Complete lock product or part number
4. OUTSIDE DES: Outside design code
5. OUTSIDE FIN: Outside finish code
6. INSIDE DES: Inside design code. Leave blank if same as outside design code.
7. INSIDE FIN: Inside finish code. Leave blank if same as outside finish code.
8. HAND: Hand of door. Only one hand allowed per line item.
Example: RH = Right Hand, LH = Left Hand, RHR = Right Reverse, LHR = Left Reverse.
9. LATCH: Latch. Leave blank for standard or specify part number if non-standard latch is
required. LLL = Less Latch.
10. STRIKE: Strike. Leave blank for standard or specify part number if non-standard strike is required. LLL =
Less Strike.
11. DR THK: Door Thickness. Enter door thickness if non-standard. Example: 138 = 1-3/8",
214 = 2 1/4", 212 = 2 1/2".
12. EXT: Extension. Enter one of the following when doors 2" thick or greater are specified:
EE = Extended Equally
EI = Extended Inside
EO = Extended Outside
ED = Extended Differently
EI or EO assumes the latch will be centered on a 1-3/4" door, to which material has been added.
13. DIM: Enter dimension for non-standard strike lip length and mortise cylinder or blocking ring length.
012 = 1/8" 118 = 1-1/8"
018 = 3/16" 114 = 1-1/4"
025 = 1/4" 138 = 1-3/8"
031 = 5/16" 112 = 1-1/2"
037 = 3/8" 158 = 1-5/8"
050 = 1/2" 134 = 1-3/4"
078 = 7/8" 200 = 2"
100 = 1" 400 = 4"
14. ADDITIONAL DETAILS: Enter detail for keying information and for special requirements.
How to Determine Hand of Door
RHR
LHR
13
Price Book 8
Effective April 4, 2020 • Rev. 04/20
LOCKS
Prices subject to change without notice
Line
Item Qty Product
Outside Inside
Hand Latch Strike Dr. Thk Ext DIM
Additional
Details/KeyingDES FIN DES FIN
Ten B-Series storeroom locks with a Dane outside lever in 605 and Dane inside lever in 626, with a 2-3/8 radius face
latch and full lip radius strike, 6-pin standard cylinder, G keyway.
2 10 B581PD6 DAN 605 DAN 626 57421 5104-1
Four T-Series entry office locks with an Avalon lever in 613, standard latch and strike, 5-pin standard cylinder, G keyway
3 4 T511PD AVA 613 98535 5164 134
Three T-Series entry office locks with a Quantum lever in 605, abrasive outside lever, standard latch and strike,
for 2-1/4" thick doors, 6-pin standard cylinder, G keyway, masterkeyed to new system, with 3 keys each.
Provide 2 masterkeys.*
Note: Masterkeying charges and extra cut key charges will be added to the applicable lock/cylinder order line and list price of lock will be adjusted.
Charges will not be shown separately on acknowledgements or invoices.
4 3 T511PD6 6QU 605 QUA 98535 5164 214 G Keyway, w/3 keys ea.
5 2 KB578 G Section, master key
6 3 50-215 Extra cut keys charges
7 3 50-210 Master keying charges
Two X-Series dormitory locks with a Troy knob and Gala rose in 606, 7-pin SFIC, A keyway, 0-bitted, one
control key, less strike.
8 2 X571BD7 TG 606 98535 LLL A-000000
9 1 KB609-2 A Section
control key 0-bit
Two MA-Series dormitory locks with a Hana knob and Gala rose in 625, right hand, lead-lined, 6-pin SFIC, A keyway, construction
core, one control key, two change keys.
10 2 MA571HDG 9HG 625 RH
11 2 KB632-1 CCA A Section
const. change key
12 1 KB609-1CCA A Section
const. ctrl. key
One MA-Series dormitory locks with a Hana knob and Gala rose in 625, left hand reverse, knurled outside knob,
6-pin SFIC, disposable construction core.
13 1 MA571BDC 9HG 625 LR
Five W-Series classroom locks with a Dane lever in 626. Standard latch and strike. 6-pin Schlage C keyway,
Keyed Different.
14 5 W5619D6 DAN 626 30-197 30-148 Sch C KD
*Use Master Keying Schedule form and appropriate Master Key Specification Sheet when ordering.
Price Book 8
Effective April 4, 2020 • Rev. 04/20
14
LOCKS
Prices subject to change without notice
FORMS & EXAMPLES •
May 1, 2003
To: Falcon Dealer
100 East Avenue
Dealer City, State 11111
RE: District 10, Jones Elementary School
Please consider this authorization to ship product for the above-referenced project.
Jones Elementary School is to be keyed using a new Falcon Restricted Key System. For security reasons, we would like to
have all keys for this facility shipped to a location other than the job site. Master keyed products, however, can be shipped
directly to the site. This letter authorizes Falcon to ship our restricted products to the following addresses:
Master Keyed Products, Construction Keys, Locks Less
Cylinders, and Locks with Construction Cores
Attn: Building Project Manager
District 10 Schools
555 Main Street
End User City, State 55555
Master Keys, Change Keys, Control Keys, and Key Blanks
Attn: Locksmith
District 10 Lockshop
1201 Fifth Avenue
End User City, State 55555
These two addresses above serve as our only authorized shipment addresses for all orders placed for our facility. We
understand that this letter will be kept on file and referenced for our future orders and that a new letter is only required to
add, remove, or change authorized shipping locations.
Sincerely,
End User Representative
Facilities Manager
Date - REQUIRED
Facility Name - REQUIRED
Dealer Name -
RECOMMENDED
Authorized Ship -
To Addresses -
REQUIRED
End User
Representative
Signature -
REQUIRED
Letter may be mailed or faxed to Falcon
Falcon Restricted Order Processing
3899 Hancock Expressway
Security, CO 80911
Fax: (888) 840-7735
District 10 Schools
555 Main Street
End User City, State 55555
(555) 555-5555
End User
Letterhead - REQUIRED
DISTRICT 10
Sample Letter of Authorization
For Falcon® Restricted Products
Non-Master Keyed
ORDER
MARK CARTONS: ACCOUNT NO. P.O. NO DATE
CUSTOMER NAME AND ADDRESS: SHIP TO:
Page 1 of _______ © 2013 Allegion
ADDITIONAL DETAILS
LINE OUTSIDE INSIDE Use for Key Section and Bitting
ITEM QTY PRODUCT DES FIN DES FIN HAND LATCH STRIKE EXT DIM Information, KA Groups, etc.
QUOTE# PRICE BOOK:
SHIPPING INSTRUCTIONS
REQUESTED SHIPDATE
ORDER WRITTEN BY
FOR FURTHER INFORMATION, CONTACT
Name:
Phone:
Fax.
Account No. _______ _____________ P.O. No. ______________________ Page _______ of _______ © 2013 Allegion
ADDITIONAL DETAILS
LINE
OUTSIDE INSIDE Use for Key Section and Bitting
ITEM QTY PRODUCT DES FIN DES FIN HAND LATCH STRIKE EXT DIM Information, KA Groups, etc.
FALCON
MASTER KEYED ORDER
This form must be attached to the
MASTER KEY SYSTEM SUMMARY FORM
Please provide as complete and accurate as possible
so we can provide what you need for your Key System
Excel Soft copy - Print Instructions:
To avoid printing more sheets than
needed, Select <Print>, from the print
screen select <Print range>, then select
<Pages> from ___to___& click OK.
Quote #: Account No.: P.O. #:
Shipping Instructions: Mark Cartons: Date:
Order Written By: Customer Name and Address: Ship to:
For Further Information Contact:
Name:
Phone:
Fax:
Page 1 of ___
Items Ordered OUTSIDE
HAND
(Only one
hand per
line item)
INSIDE LATCH STRIKE Enter door
thickness
if not
standard
Enter
when door
thickness
is greater/
equal to 2˝
Dimension
for mortise
cylinder,
blocking
ring, etc.
ADDITIONAL DETAILS
Lock Details DESIGN FINISH DESIGN FINISH
Key/Label Instructions
QTY Heading DOOR #
KEY
Symbol(s)
MK
Symbol(s)LINE ITEM QTY PRODUCT DR THK EXT DIM
© 2013 Allegion
Page 2 of ___
Items Ordered OUTSIDE
HAND
(Only one
hand per
line item)
INSIDE LATCH STRIKE Enter door
thickness
if not
standard
Enter
when door
thickness
is greater/
equal to 2˝
Dimension
for mortise
cylinder,
blocking
ring, etc.
ADDITIONAL DETAILS
Lock Details DESIGN FINISH DESIGN FINISH
Key/Label Instructions
QTY Heading DOOR #
KEY
Symbol(s)
MK
Symbol(s)LINE ITEM QTY PRODUCT DR THK EXT DIM
© 2013 Allegion
1 of 5 MS-I200
MASTER KEY
SYSTEM SUMMARY
This form must be attached to the
Master Key Order form and P.O.
Please provide as complete and accurate as
possible so we can provide what you need for
your Key Syste m.
o New
o Attached Dealer Specified Combinations
Construction Keyed o Yes o No
Full Size Construction Cores o ICA o ICB o ICC
(Schlage Only)
Small Format Construction Cores o Brown o Green
Construction Keyed Type
oFalcon o CK (BOK) o Lost Ball
oSchlage o CK (Split) o RCK ( 5-Pin C only )
Type
o 5-pin o 6-pin o 7-pin
See compatibility chart on page 5
Keyway
Specified **:
Schlage
oClassic
oClassic Primus *
Everest ®
oB (Small Format IC, Restricted *)
oC (Open)
oPrimus® *
oD (Restricted *)
oPrimus® *
Everest 29™
oR (Small Format IC, Restricted *)
oS (Open)
oPrimus® *
oT (Restricted *)
oPrimus® *
Job Name
Address
City / State
Country
Account
No.
P.O.#
For detailed instructions on how to complete this form please refer to pages 4 & 5
System Overview
1. Select System
o Existing (provide info below)
Registry # __________________________________________
Structure or
Factory Order # _____________________________________
Falcon
oStandard
oSchlage C
oRestricted *
oInterchangeable Core A2
oInterchangeable Core A4
** = The Commercial Master Key Department makes the final
decision in the selection of key sections
Everest 29 key sections are backwards compatible to Everest key-
ways and have the following relationships:
R family sections > B family keyways
S family sections > C family keyways
T family sections > D family keyways
2 of 5 MS-I200
2. Select Keys & Key Stamping
3. Select Cylinder Stamping
Change Keys
No. Of Keys per Symbol
No. Of Keys per Cylinder
Type
oStandard Bow oStandard Bow oAccess Bow oLarge Bow
(Unembossed) (Schlage Only)
Key Stamp Details
oKeyset Symbol oDo Not Duplicate oWith Custom Die
(DND) (Specify)
oNon-standard Code (Specify)
Change Key Packaging and Shipping Instructions
Pack Keys Independently (PKI) of Lock or Cylinder ***
oYes oNo
If PKI, ship change keys to:
oDealer oOther
oSee Primus Facesheet
*** = Furnished standard at no charge with
Split-Key construction keying
Cylinder Stamp Details
oWith Industry Standard Key Symbol oNon-Standard Code (Specify)
Cylinder Stamping Location
oPlug Face (N/A in Primus) - VKC oConcealed (N/A in Falcon STD) - CKC
3 of 5 MS-I200
6. Operating Instructions
(Unless otherwise specified, all hierarchical master keys will operate cross-keyed cylinders)
Cross Keyed is operated by
Cylinder these change keys
X
X
X
X
Cross Keyed is operated by
Cylinder these change keys
X
X
X
X
GGM o
GM o
MK o
MK o
MK o
MK o
Others o
5. Master Key Future Expansion
List Future MK Symbols
Example:
MK………o BJ, BK 40 each
Approx. # of Change Key Symbols Under Each Future MK
3
Level Qty. Per Master Key Symbol (s) Total Quantity
GGM
GM
MK or RMK
Control
Emergency
Others
Ship Master Keys To:
oDealer oSee Primus Facesheet oOther
Special Function Qty. Per Qty. Per
RCK (Lost Ball) **** Full Size Construction Core Keys (Schlage Only)
CK (Split Key) **** Full Size Construction Core Control Keys (Schlage Only)
Extractor Tools **** Small Format Construction Core Keys
Small Format Construction Core Control Keys
4. Select Key Quantities
**** = Use with Construction Keying
4 of 5 MS-I200
7. Instructions and Compatibility
General Information
If you do not know the registry number (R#), structure number or the original factory order number for an existing system, contact Customer
Service prior to placing the order:
Tel. 1-877-671-7011
Fax 1-800-452-0663
• Only one structure may be ordered on the same purchase order
• Classic refers to Obverse, Numbered (Paracentric), Quad, and Reverse key section families
• Classic Primus refers to Primus Obverse and Primus Quad key section families
Section 1: System a System
Full Size Construction Cores
• Schlage only
Small Format Construction Cores
• 7-pin only for Schlage
• 6- and 7-pin for Falcon
CK (Split)
• 6-pin for Schlage and Falcon
• Split key construction keying is not available for Classic Primus or Everest 29 Primus
RCK (Lost Ball)
• 5-pin (C keyway) only for Schlage
• 5-, 6-, and 7-pin for Falcon
System Selection
• Refer to the compatibility chart
Section 2: Select Kys and Key Stamping
Stamp Details
• Unless otherwise specified, industry standard key symbols are stamped on Everest 29™ and Primus® keys
• For custom die, attach RFQ approval for Schlage
Section 3: Select Cylinder Stamping
Type
• For cylinder type refer to the compatibility chart
Keyway (specify)
• Schlage Commercial’s default key section for new Master Key Systems is Everest™ S145
5 of 5 MS-I200
Section 4: Key Quantities
Level
• Unless otherwise specified, the control key has the same cut as the highest-level key in the system
(Except SFIC systems)
Special Function
• Construction keys are not furnished unless specified
Change Keys
• Unless otherwise specified 2 change keys are furnished per lock or cylinder
Section 5: Master Key Future Expansion
• Do not use the letters “I”, “O”, “CK”, “KA, or “KD” for any master key symbols
Section 6: Operating Instructions
• Cross keying reduces the security and expansion of key systems
• Unless otherwise specified, all hierarchical master keys will operate cross-keyed cylinders
5 Pin 6 Pin 7 Pin Split
Key
Block
O-Key
Lost
Ball
Tempe
Core A2 A4 0.025 0.018
Schlage
Classic X X X X X
Everest 29 S X X X
Everest 29 T X X X
Everest 29 R X X X
Classic Primus (XP) X X
Everest 29 Primus (XP) X X
Falcon
Open X X X X X X
Restricted X X X X X
Schlage C X X
SFIC Open X X X X X
SFIC Restricted X X X X X
Compatibility Chart
29
Price Book 8
Effective April 4, 2020 • Rev. 04/20
MA SeriesMortiseGrade 1LOCKS
Prices subject to change without notice
MA-Series
Introduction
Finish Codes and Descriptions
Code Description
605 (US3) Bright Brass
606 (US4) Satin Brass
613 (US10B) Oil Rubbed Bronze
619 (US15) Satin Nickel
622 (US19) Matte Black
625 (US26) Bright Chrome
626 (US26D) Satin Chrome
630 (US32D) Satin Stainless Steel
643E (US11) Aged Bronze
Standard Features - Furnished unless otherwise specified
Certification ANSI A156.13, Series 1000, Grade 1 Operation and Security, UL Listed for 3-Hour fire door
with SFIC Interchangeable Core Cylinders: Grade 3 Security
Latch 2 piece stainless steel anti-friction bolt 3/4" projection.
Strike 1-1/4" x 4-7/8", ANSI, Square corner, with dust box
Cylinder 6-Pin, Solid brass, Keyed 5-Pin, Falcon G keyway, Keyed different (KD)
Door Range 1-3/4" - 1-7/8" standard
Keys Two, Nickel silver cut keys per lock, Falcon G keyway
MA Series
Function Chart 31
MA Complete Lock Pricing 33
Option
Conventional Cylinder Options ...............................................37
SFIC Cylinder Options ................................................................37
Small Format Interchangeable Core.....................................37
Small Format Constructoin Core ...........................................37
Strikes ...........................................................................................38
Armor Fronts (Scalps) .............................................................38
Lock Less Components ............................................................. 41
Non-Standard Door Thickness ............................................... 41
Abrasive Coating and Knurling ...............................................41
Lead Wrap.....................................................................................41
Allegion Connect .........................................................................41
Indicators ......................................................................................41
MA Series Parts
Full Body Mortise Deadlocks .................................................. 36
Lock Cases ...................................................................................39
Knobs & Levers ...........................................................................39
Roses .............................................................................................39
Escutcheons ................................................................................40
Screws and Screw Packs .........................................................40
Misc. Parts ....................................................................................40
Allegion Connect .........................................................................41
Indicators ......................................................................................41
Trim Packs ....................................................................................42
Product Identification
MA 501 P D
Latch Suffix
D = Deadlatch
Cylinder Suffix
B = Less SFIC
BB = SFIC - 6 Pin BEST capping
BDC = SFIC Construction Core
(disposable)
G = SFIC (Falcon)
H = SFIC Construction Core
(refundable)
L = Less Conventional, 6 Pin
P = Conventional, 6 Pin/Keyed 5
P6 = Conventional, 6 Pin
P7 = Conventional, 7 Pin
Function
See 31
Lock Series
SFIC = Small Format (Best® Style) Interchangeable Core
30
Price Book 8
Effective April 4, 2020 • Rev. 04/20
MA Series Mortise Grade 1 LOCKS
Prices subject to change without notice
Outside escutcheon
Outside rose
Mounting posts
Lock case
mounting screws
Mounting screws
Inside
escutcheon
Outside lever
Spindle
Spindle Inside lever
Inside rose
Inside thumbturn
Lock assembly
Strike screws
Armor screw
Armor front Mounting screws
Strike
MA Series
GRADE 1 MORTISE LOCK
31
Price Book 8
Effective April 4, 2020 • Rev. 04/20
MA SeriesMortiseGrade 1LOCKS
Prices subject to change without notice
Functions • MA-Series
ANSI A156.13 Series 1000 Grade 1 Operation
Mortise Mortise
FALCON ANSI FALCON ANSI
MA101 F01 Passage/Closet Latchset
Latchbolt retracted by knob/lever from
either side at all times. Inside knob/
lever is always free for immediate
egress.
MA411* F30 Asylum Lock
Latch bolt operated by key from either side.
Both knobs/levers always inoperative. Auxiliary
dead latch.
MA161 F31 Connecting Room/Exit Latch
Latch bolt operated by knob/lever from
inside. No trim outside. Auxiliary dead
latch.
MA431 F34 Classroom Security Lock with Deadbolt
Latch bolt operated by knob/lever from
either side except when outside knob/lever
is locked from inside or outside by key. Dead
bolt retracted by key from inside or outside.
Operating inside knob/lever retracts both bolts
and unlocks outside. Latch bolt dead locked
when dead bolt is thrown. Inside knob/lever
is always free for immediate egress. Available
with messaging indicator. Please specify.
MA301 F02 Privacy Lock
Latch bolt operated by knobs/levers
either side, dead bolt operated by turn
from inside or by emergency release
outside. Available with messaging
indicator. Please specify.
MA441 F32 Classroom Security Lock
Latch bolt operated by knob/lever from either
side except when outside knob/lever is locked
from inside or outside by key. When outside
knob/lever is locked, latch bolt is retracted
by key from inside or outside or by operating
inside knob/lever. Auxiliary dead latch. Inside
knob/lever is always free for immediate egress.
Available with messaging indicator. Please
specify.
MA311 F19 Privacy, Bedroom or Bath Lock
Latch bolt operated by knobs/levers.
Dead bolt operated by turn from
inside and emergency release outside.
Rotating inside knob/lever retracts both
bolts. Inside knob/lever is always free
for immediate egress. Available with
messaging indicator. Please specify.
MA451 F15 Hotel Guest Lock
Latch bolt operated by key from outside or by
operating inside knob/lever. Outside knob/lever
is always inoperative. Dead bolt projected by
turn from inside and all keys except emergency
key are shut out. Operating inside knob/lever
retracts both bolts. Auxiliary dead latch. Inside
knob/lever is always free for immediate egress.
Using MA451 in conjunction with SFIC must
use Falcon SFIC mortise housing and Falcon
SFIC core. Available with messaging indicator.
Please specify.
MA321 F22 Privacy Lock
Latch bolt operated by knob/lever
from either side except when outside
knob/lever is locked by inside T-turn.
Operating inside knob/lever, closing
door or operating outside emergency
release unlocks outside knob/lever.
Inside knob/lever is always free for
immediate egress. Available with
messaging indicator. Please specify.
MA521 F04 Entry/Office Lock
Latch bolt operated by knob/lever from either
side except when outside knob/lever is made
inoperative by buttons in face. When outside
knob/lever is locked, latch bolt is retracted by
key from outside or by operating inside knob/
lever. Auxiliary dead latch. Inside knob/lever is
always free for immediate egress.
MA371* F14 Store Door Lock
Latch bolt operated by knobs/levers
either side. Dead bolt by key from either
side. Available with messaging indicator.
Please specify.
MA531 F20 Apartment Corridor Door Lock
Latch bolt operated by knob/lever from either
side, except when outside knob/lever is made
inoperative by buttons in face. Dead bolt
operated by key outside or turn inside. Key
outside operates both bolts. Operating inside
knob/lever retracts both bolts and outside
remains locked. Latch bolt is deadlocked when
outside knob/lever is made inoperative or
when the dead bolt is projected. When dead
bolt is retracted, knob/lever is unlocked by
buttons in face. Inside knob/lever is always free
for immediate egress.
MA381 F09 Apartment, Exit Lock
Latch bolt operated by knob/lever from
either side, except when outside knob/
lever is locked by key from inside. When
outside knob/lever is locked, latch bolt
is retracted by key from outside or by
operating inside lever. Auxiliary dead
latch. Inside knob/lever is always free
for immediate egress.
* Caution: Double cylinder locks on residences and any door, in any structure, which is used for egress are a life safety hazard in times of emergency and
their use is not recommended. Installation should be in accordance with existing codes only.
32
Price Book 8
Effective April 4, 2020 • Rev. 04/20
MA Series Mortise Grade 1 LOCKS
Prices subject to change without notice
Mortise
FALCON ANSI
MA851-12
MA851-24
Storeroom-Fail Safe EL
Latch bolt operated by knob/lever from either
side except when outside knob/lever is electrically
locked. When outside knob/lever is locked, latch
bolt retracted by key in outside cylinder. Deadlocking
latch. Specify 12 or 24V DC. Inside knob/lever is
always free for immediate egress.
MA851-12RX
MA851-24RX
Storeroom-Fail Safe EL w/ MA851-24RX
Request to Exit (RX)
Latch bolt operated by knob/lever from either
side except when outside knob/lever is electrically
locked. When outside knob/lever is locked, latch
bolt retracted by key in outside cylinder. RX monitors
lever rotation from both sides. Compatible with
normally open systems. Deadlocking latch. Specify
12 or 24V DC. Inside knob/lever is always free for
immediate egress.
MA881-12
MA881-24
Storeroom-Fail Secure EU
Latchbolt operated by knob/lever from inside
except when outside knob/lever is electrically
unlocked, then knob/lever from either side. When
locked, key in outside cylinder retracts latch bolt.
Specify 12 or 24V DC. Deadlocking latch. Inside
knob/lever is always free for immediate egress.
MA881-12RX
MA881-24RX
F15 Storeroom-Fail Secure EU
Latchbolt operated by knob/lever from inside
except when outside knob/lever is electrically
unlocked, then knob/lever from either side. When
locked, key in outside cylinder retracts latch bolt. RX
monitors lever rotation from both sides. Compatible
with normally open systems. Deadlocking latch.
Specify 12 or 24V DC Inside knob/lever is always free
for immediate egress.
MA911 F29 Classroom Dead Lock
Key from outside operates dead bolt. Turn from
inside retracts but does not project dead bolt.
MA921 F18 Outside Only Deadlock
Dead bolt by key outside only. Available with
messaging indicator. Please specify.
MA931* F16 Two-sided Deadlock
Dead bolt by key from either side. Available with
messaging indicator. Please specify.
MA941 F17 Deadlock w/ inside turn
Dead bolt by key outside or turn inside. Available
with messaging indicator. Please specify.
MA12/MA18 Dummy Trim
Single or double available.
Single (MA12)
Double (MA18)
ANSI A156.13 Series 1000 Grade 1 Operation
Mortise
FALCON ANSI
MA541* F21 Entry or Office Lock
Latchbolt retractedby knob/lever from either
side. Deadbolt thrown or retracted by key
outside or thumbturn inside. Available with
messaging indicator. Please specify.
MA551 F06 Holdback Lock
Latch bolt operated by lever from either side
except when outside lever is locked from
outside by key. Latch bolt can be locked in a
retracted position by key. When outside lever
is locked, latch bolt is retracted by key from
outside or by operating inside lever unless
latch bolt has been locked in a retracted
position.Auxiliary dead latch. Inside knob/
lever is always free for immediate egress.
Note: Chassis is handed
MA561 F05 Classroom Lock
Latchbolt operated by knob/lever from
either side except when outside knob/lever
is locked by key. When outside knob/lever
is locked, latchbolt is retracted by key from
outside or by operating inside knob/lever.
Auxiliary latch deadlocks latchbolt when door
is closed. Inside knob/lever is always free for
immediate egress.
MA571 F13 Dormitory or Exit Lock
Latch bolt operated by knob/lever from
either side. Dead bolt projected by key from
outside and turn from inside. Operating inside
knob/lever retracts both bolts and unlocks
outside. Inside knob/lever is always free for
immediate egress. Available with messaging
indicator. Please specify.
MA581 F07 Storeroom Lock
Latch bolt operated by key from outside or
by operating inside knob/lever. Outside knob/
lever is always inoperative. Auxiliary dead
latch. Inside knob/lever is always free for
immediate egress.
MA621 F08/F10 Apartment Corridor Lock
Latch bolt is operated by knob/lever from
either side, except when outside knob/lever
is made inoperative by buttons in face. Dead
bolt is operated by turn inside. Key outside
operates both bolts. Inside knob/lever is
always free for immediate egress.
MA641 Dormitory Lock
Latch bolt by knob/lever inside and key
outside. Inside knob/lever free. Outside knob/
lever rigid. Dead bolt by key outside or T-turn
inside. Rotating inside knob/lever retracts
both bolts. Deadlocking latch. Inside knob/
lever is always free for immediate egress.
Available with messaging indicator. Please
specify.
MA-Series • Functions
* Caution: Double cylinder locks on residences and any door, in any structure, which is used for egress are a life safety hazard in times of emergency and their use
is not recommended. Installation should be in accordance with existing codes only. No Immediate Egress.
33
Price Book 8
Effective April 4, 2020 • Rev. 04/20
MA SeriesMortiseGrade 1LOCKS
Prices subject to change without notice
Grade 1 Mortise Locks with Cast/Forged or Heavy Wrought
Trim ANSI-A156.13, SERIES 1000, GRADE 1 Complete Locks • MA-Series
AG (Avalon-Gala) DG (Dane-Gala) LTG (Latitude-Gala*)
QG (Quantum-Gala) SG (Sutro-Gala)
Cast Lever BOG (Boardwalk-Gala*)
BRG (Broadway-Gala*)
Note: 1) Specify 12 or 24VDC. Default is 12V.
Power supply PS902 will be sufficient to operate an individual lock for multiple lock installation - see Power Supply section.
* Latitude, Longitude, Broadway and Boardwalk levers not available in 630 finish.
** Sutro-Gala trim not available in 619, 622 or 643e finishes.
MA Lever/Rose Styles
Function Description
Designs and Finishes
AG DG QG SG** LTG* LGG* BRG* BOG*
626 643E 605 606 613 619 622 625 630
*
Single Cylinder Functions
MA521P Entry/Office
$612.00 $624.00
MA541P Entry/Office
MA551P Holdback
MA561P Classroom
MA571P Dormitory Exit
MA581P Storeroom
MA531P Apartment Corridor
627.00 639.00 MA621P Front Door
MA641P Dormitory
MA451P Hotel 792.00 804.00
MA851P-12 or -24 1 Elect. Storeroom (Fail Safe) 1,127.00 1,139.00
MA881P-12 or -24 1 Elect. Storeroom (Fail Secure)
MA851P-12RX or -24RX 1 Elect. Storeroom (Fail Safe) w/ RX 1,232.00 1,244.00
MA881P-12RX or -24RX 1 Elect. Storeroom (Fail Secure) w/ RX
Double Cylinder Functions
MA371P Store Door
$672.00 $684.00
MA381P Apartment /Exit
MA411P Asylum
MA431P Classroom Security with deadbolt
MA441P Classroom Security
CAUTION: Double cylinder locks on residences and any door in any structure which is used for egress are a life safety hazard in times of emergency and their use is
not recommended. Installation should be in accordance with existing codes only.
Non-Keyed Functions
MA101 Passage $472.00 $484.00
MA161 Exit/Connecting 452.00 464.00
MA301 Privacy
552.00 564.00 MA311 Privacy
MA321 Privacy
MA12 Half Dummy 253.00 259.00
MA18 Full Dummy 388.00 400.00
LGG (Longitude-Gala*)
34
Price Book 8
Effective April 4, 2020 • Rev. 04/20
MA Series Mortise Grade 1 LOCKS
Prices subject to change without notice
Grade 1 Mortise Locks with Cast/Forged or Heavy
Wrought Trim ANSI-A156.13, SERIES 1000, GRADE 1
MA-Series • Complete Locks
AN (Avalon-Napa) DN (Dane-Napa)
QN (Quantum-Napa) SN (Sutro-Napa)
Cast Lever
Note: 1) Specify 12 or 24 VDC.
Power supply PS902 will be sufficient to operate an individual lock for multiple lock installation - see Power Supply section.
* Latitude, Longitude, Broadway and Boardwalk levers not available in 630 finish.
** Sutro-Napa trim not available in 619, 622 or 643e finishes.
MA Lever Escutcheon Styles
Function Description
Designs and Finishes
AN DN QN SN** LTN* LGN* BRN* BON*
626 643E 605 606 613 619 622 625 630
Single Cylinder Functions
MA521P Entry/Office
$657.00 $669.00
MA541P Entry/Office
MA551P Holdback
MA561P Classroom
MA571P Dormitory Exit
MA581P Storeroom
MA531P Apartment Corridor
672.00 684.00 MA621P Front Door
MA641P Dormitory
MA451P Hotel 837.00 849.00
MA851P-12 or -241 Elect. Storeroom (Fail Safe) 1,172.00 1,184.00
MA881P-12 or -241 Elect. Storeroom (Fail Secure)
MA851P-12RX or -24RX1 Elect. Storeroom (Fail Safe) w/ RX 1,277.00 1,289.00
MA881P-12RX or -24RX1 Elect. Storeroom (Fail Secure) w/ RX
Double Cylinder Functions
MA371P Store Door
$717.00 $729.00
MA381P Apartment/Exit
MA411P Asylum
MA431P Classroom Security with deadbolt
MA441P Classroom Security
CAUTION: Double cylinder locks on residences and any door in any structure which is used for egress are a life safety hazard in times of emergency and their use is
not recommended. Installation should be in accordance with existing codes only.
Non-Keyed Functions
MA101 Passage $517.00 $529.00
MA161 Exit/Connecting 497.00 509.00
MA301 Privacy
597.00 609.00 MA311 Privacy
MA321 Privacy
MA12 Half Dummy 298.00 304.00
MA18 Full Dummy 433.00 445.00
LTN (Latitude-Napa*)
BON (Boardwalk-Napa*)
BRN (Broadway-Napa*)
LGN (Longitude-Napa*)
35
Price Book 8
Effective April 4, 2020 • Rev. 04/20
MA SeriesMortiseGrade 1LOCKS
Prices subject to change without notice
Complete Locks • MA-Series
HG (Hana-Gala) HN (Hana-Napa)
Note: 1) Specify 12 or 24VDC. Default is 12V.
Power supply PS902 will be sufficient to operate an individual lock for multiple lock installation - see Power Supply section.
MA Knob Styles – Hana
Function Description
Designs and Finishes
HANA – GALA HANA – NAPA
626
605 606 613
625 630 626
605 606 613
625 630
Single Cylinder Functions
MA521P Entry/Office
$512.00 $524.00 $557.00 $569.00
MA541P Entry/Office
MA551P Holdback
MA561P Classroom
MA571P Dormitory Exit
MA581P Storeroom
MA531P Apartment Corridor
527.00 539.00 572.00 584.00 MA621P Front Door
MA641P Dormitory
MA451P Hotel 692.00 704.00 737.00 749.00
MA851P-12 or -241 Elect. Storeroom (Fail Safe) 1,027.00 1,039.00 1,072.00 1,084.00
MA881P-12 or -241 Elect. Storeroom (Fail Secure)
MA851P-12RX or -24RX1 Elect. Storeroom (Fail Safe) w/ RX 1,132.00 1,144.00 1,177.00 1,189.00
MA881P-12RX or -24RX1 Elect. Storeroom (Fail Secure)w/ RX
Double Cylinder Functions
MA371P Store Door
$572.00 $584.00 $617.00 $629.00
MA381P Apartment/Exit
MA411P Asylum
MA431P Classroom Security with deadbolt
MA441P Classroom Security
CAUTION: Double cylinder locks on residences and any door in any structure which is used for egress are a life safety hazard in times of emergency and their use is
not recommended. Installation should be in accordance with existing codes only.
Non-Keyed Functions
MA101 Passage $372.00 $384.00 $417.00 $429.00
MA161 Exit/ Connecting 352.00 364.00 397.00 409.00
MA301 Privacy
452.00 464.00 497.00 509.00 MA311 Privacy
MA321 Privacy
MA12 Half Dummy 153.00 159.00 198.00 204.00
MA18 Full Dummy 288.00 300.00 333.00 345.00
36
Price Book 8
Effective April 4, 2020 • Rev. 04/20
MA Series Mortise Grade 1 LOCKS
Prices subject to change without notice
MA-Series • Deadlocks and Cylinders
* Hotel mortise cylinder are only offered as Master keyed or 6-pin 0-bitted and must be specified. If not specified, 0-bitted furnished.
** Important: When using 985T or 986T Falcon mortise thumbturn cylinder, if the turn is left in the 180 position it could interfere with cylinder retraction on the outside.
Notes: 1) Cylinders are furnished 5-pin G keyway, keyed differently unless otherwise specified.
2) Restricted sections see page 141. See Keys & Keying for standard keyways. Contact 877-671-7011 for availability.
3) MA cam (5622-STD) provided unless otherwise specified.
4) For 7-pin conventional add $11.90.
5) All mortise cylinders will be furnished with cam 5622-STD, except for MA381 function which will be supplied with 5620-STD and 5621-STD. See page 152 for
additional available cams.
6) Mortise and rim cylinders are not available in any competitor keyway, except Schlage C.
7) 984D, 985D not available in 629 and 630.
8) Conventional mortise cylinder with Schlage C keyway are available with the following cams only, 5622-STD & B502-191. Specify XQ11-949 when ordering with
cylinder dogging
9) Add $11.10 (list) for Falcon restricted keyways. See page 8 for standard keyways. All others are restricted. Falcon conventional cylinder restricted keyways use a
unique pin kit (P/N 1417) and cutter wheel for keys.
10) 985T is not available in 619, 622, 625 and 643e.
Notes: 1) All mortise cylinders will be furnished with cam 5622-IC, except for MA381 function which will be supplied
with 5620-IC and 5621-IC. See page 154 for additional available cams.
2) C977 is only furnished with 012667-001 Adams Rite Cam.
Conventional Mortise Cylinders
Pins Length Description Number 626 643e 605 606 613 619
622 625 630
5 or 6 1-1/8 Mortise 985 $63.00 $65.00
1-1/4 986
5, 6, or 7
1-3/8
Mortise
987 63.00 65.00
1-1/2 988 78.00 80.00
1-3/4 990 100.00 102.00
2992 105.00 107.00
61-1/8
Mortise, hotel function*
250
82.00 84.00
1-1/4 251
6 1-3/8 252
7 1-3/8 253
- 1-1/8 Mortise thumbturn cylinder ** 985T 98.00 100.00
1-1/4 986T
- 1 Dummy 984D 38.00 40.00
1-1/8 985D
SFIC MA Series housings only
Cat. Number Length Pins Description 626, 643E 605 606 613, 619
622 625 630
C987-xx 1 3/8" 6 or 7 Mortise $39.00 $41.00
C988-xx 1 1/2" 6 or 7 Mortise
C990-xx 1 3/4" 6 or 7 Mortise 50.00 52.00
C992-xx 2" 6 or 7 Mortise 53.00 55.00
C997-xx 1 3/8" 6 or 7 Mortise, unassembled, less cam 25.00 27.00
C262-xx 1 5/8" 6 or 7 Mortise, hotel function RH 70.00 72.00
C265-xx 1 5/8" 6 or 7 Mortise, hotel function LH
Notes: 1) If ordered with Napa Escutcheon Trim - add $140 (both sides will be included)
2) Deadlock case comes with appropriate scalp (front).
MA Series Mortise Deadlocks (No Knob or Lever Trim)
Function Description
List Price
626, 643E
605 606 613 619
622 625 630
MA911P Classroom Deadlock $371.00 $377.00
MA921P Deadlock by key outside 334.00 340.00
MA931P** Deadlock by key from either side, Double Cylinder lock 364.00 370.00
MA941P Single Cylinder, Thumbturn inside 456.00 462.00
**CAUTION: Double cylinder locks on residences and any door in any structure which is used for egress are a life safety hazard in
times of emergency and their use is not recommended. Installation should be in accordance with existing codes only.
37
Price Book 8
Effective April 4, 2020 • Rev. 04/20
MA SeriesMortiseGrade 1LOCKS
Prices subject to change without notice
Cylinder Options • MA-Series
* Competitor keyways are furnished 0 bitted, unless otherwise specified. Not available Master keyed, except Schlage C
Notes: 1) Finishes: 606, 622, & 626 only
2) Specify keyway
3) Cylinders are furnished G keyway, keyed differently unless otherwise specified.
4) Restricted sections add $11.10 to list price. See page 8 for list of standard keyways.
All other keyways are considered restricted. Contact 877-671-7011 for availability.
5) 622 Finish is available only on Allegion cylinders (P, P6, & P7) in C & G Keyways.
* Keying must be specified
** Locks are assessed one non-refundable handling charge (50-231F) per core.
Note: 6) Control keys are not furnished with locks and must be ordered separately. See page 151 for details.
7) 622 Finish is available only on SFIC (G) in C & G Keyways.
8) Using MA451 in conjunction with SFIC must use Falcon SFIC mortise housing and Falcon SFIC core.
Conventional Cylinder options
Description Specify Add to Lock Price
5 pinned cylinder P Suffix
Example: MA581P STD
6 pinned cylinder P6 Suffix
Example: MA581P6 N/C
7 pinned cylinder P7 Suffix
Example: MA581P7 $11.90
6 pinned Competitor keyway cylinders* P6 Suffix
Example: MA581P6 (0 Bitted, KD, KA4 only) N/C
Small Format Interchangeable Core and Small Format Construction Core
Description Specify Add to Lock Price
(per core)
Small format core * G Suffix
Example: MA581GD $46.00
Small format core (Best Style) * BB Suffix
Example: MA581BB
Small format construction core ** H Suffix
Example: MA581HD 46.00
Less Small format core B Suffix
Example: MA581BD N/C
Small format disposable core BDC Suffix
Example: MA581BDC N/C
38
Price Book 8
Effective April 4, 2020 • Rev. 04/20
MA Series Mortise Grade 1 LOCKS
Prices subject to change without notice
MA-Series • Strikes and Armor Fronts
MA-Series Strikes with Locks
Descriptions Lip Length Specify
Add to Lock Price
605, 606, 613, 619
622, 625, 626, 643E
Standard - 1-3/4" Door Thickness 1-1/4" A8737-1
N/C
Optional - 2" Door Thickness 1-7/16" A8737-2
Optional - 2-1/4" Door Thickness 1-9/16" A8737-3
Optional - 2-1/2" Door Thickness 1-11/16" A8737-4
Optional - 1-3/4" Door Thickness 7/8" A8737-5
MA-Series Strikes Sold Separately
Descriptions Lip Length Specify
Price
605, 606, 613, 619
622, 625, 626, 643E
Standard - 1-3/4" Door Thickness 1-1/4" A8737-1 $24.10
Optional - 2" Door Thickness 1-7/16" A8737-2
31.60
Optional - 2-1/4" Door Thickness 1-9/16" A8737-3
Optional - 2-1/2" Door Thickness 1-11/16" A8737-4
Optional - 1-3/4" Door Thickness 7/8" A8737-5
Note: Strikes for MA locks with finishes 629 and 630 are supplied in 625 and 626.
MA-Series Armor Fronts (Scalps) Sold Separately
Descriptions Part Number
Price
605, 606, 613, 619
622, 629, 630, 643E
MA101, 321 S77801-LL
$44.40
MA521 S77804-LL
MA161, 381, 411, 441, 561, 581, 851, 881, 551 S77805-LL
MA621 S77811-LL
MA451, 641 S77815-LL
MA911, 921, 931, 941 S77816-LL
MA301, 311, 371, 541, 571, 431 S77819-LL
MA531 S77820-LL
Notes: 1) Armor front is included in complete MA lock
2) Screws not provided with armors or strikes when ordered separately.
Please order S76300 if additional screws are required.
39
Price Book 8
Effective April 4, 2020 • Rev. 04/20
MA SeriesMortiseGrade 1LOCKS
Prices subject to change without notice
Cases and Trim • MA-Series
MA-Series Lock Case
Part Number Description List Price
A7801-xx MA101 $273.00
A7831-xx MA161 252.00
A7802-xx MA301 351.00
A7819-xx MA311 350.00
A7822-xx MA321 284.00
A7814-xx MA371 318.00
A7809-xx MA381 317.00
A7830-xx MA411 316.00
A7815-xx MA451 508.00
A7804-xx MA521 287.00
A7820-xx MA531 350.00
A7821-xx MA541 343.00
A7805-xx MA561, 441 342.00
A7813-xx MA571, 431 341.00
A7807-xx MA581 340.00
A7808-xx MA621 352.00
A7815-xx MA641 351.00
A7806-xx MA551 338.00
A7851-12-xx MA851 12V 842.00
A7851-24-xx MA851 24V 841.00
A7881-12-xx MA881 12V 840.00
A7881-24-xx MA881 24V 839.00
A7851-12RX-xx MA851 12V RX 943.00
A7851-24RX-xx MA851 24V RX 942.00
A7881-12RX-xx MA881 12V RX 941.00
A7881-24RX-xx MA881 24V RX 940.00
A7829-xx MA911 208.00
A7816-xx MA921, 931, 941
Notes: 1) xx Specify handing: RH= Right hand. LH= Left hand. RR = Right hand reverse. LR = Left hand reverse.
2) Does not include armor front
MA-Series Lever & Knob Assemblies
Part Number Description
List Price
626 643E*
605 606 613 619*
622* 625 630
AS76029-L/RH Avalon, sectional trim
$130.00 $133.00
AS76140-L/RH Quantum, sectional trim
AS76526-L/RH Sutro, sectional trim
AS76280-L/RH Dane, sectional trim
AS76100-L/RH Hana, sectional trim
AS76321-L/RH Broadway, sectional trim (Not available in 630 finish)
AS76310-L/RH Boardwalk, sectional trim (Not available in 630 finish)
AS76360-L/RH Latitude, sectional trim (Not available in 630 finish)
AS76760-L/RH Longitude, sectional trim (Not available in 630 finish)
AE77321-L/RH Broadway, escutcheon trim (Not available in 630 finish)
AE77310-L/RH Boardwalk, escutcheon trim (Not available in 630 finish)
AE77360-L/RH Latitude, escutcheon trim (Not available in 630 finish)
AE77760-L/RH Longitude, escutcheon trim (Not available in 630 finish)
AE77029-L/RH Avalon, escutcheon trim
AE77140-L/RH Quantum, escutcheon trim
AE77526-L/RH Sutro, escutcheon trim
AE77280-L/RH Dane, escutcheon trim
AE77100-L/RH Hana, escutcheon trim
Notes: 3) Specify finish and handing
4) Lever assemblies include one lever assemblies with spring cage.
* Not available on Hana knobs.
MA-Series Rose
Part Number Description
List Price
626 643E
605 606 613 619
622 625 630
S76012 Rose, Gala $33.50 $36.50
AS76853 Emergency Coin Turn Rose Turn for MA 301/311/321 34.60 37.60
AS75319 Thumbturn assembly for sectional trim for MA 301/311/321 when door thickness is
less than 2" 34.60 37.60
AS76319 Thumbturn Assembly for sectional trim for all functions except MA 301/311/321
when door thickness is less than 2"
Notes: 5) Specify finish
MA-Series ROSE with INDICATOR
Part Number Description
List Price
626 630
AE55012-OT Outside indicator, sectional trim, MA301/311/321. $102.00 $105.00
AE55012-OC Outside Indicator, sectional trim, All functions except MA 301/311/321/441.
Notes: 6) Specify finish
40
Price Book 8
Effective April 4, 2020 • Rev. 04/20
MA Series Mortise Grade 1 LOCKS
Prices subject to change without notice
MA-Series • Trim, Screws and Parts
MA-Series Screw Packs
Part Number Description
List Price
606 613 622 630
S76300 1-3/4" - 1-7/8" door thickness, sectional trim with levers
$25.90
S76301 Over 1-7/8" - 2-1/2" door thickness, sectional trim with levers
E77301 Over 1-7/8" - 2-1/2" door thickness, escutcheon trim with levers
E77303 Over 1-7/8" - 2-1/2" door thickness, escutcheon trim with knobs
S76306 Torx screw pack, sectional trim, no turn
S76307 Torx screw pack, sectional trim, with turn
E77306 Torx screw pack, escutcheon trim, standard
E77307 Torx screw pack, escutcheon trim, over 1-7/8" – 2-1/2" door thickness
S76302 1-3/4" - 1-7/8" door thickness, sectional trim with knobs
S76303 Over 1-7/8" - 2-1/2" door thickness, sectional trim with knobs
E77300 1-3/4" - 1-7/8" door thickness, escutcheon trim with levers
E77302 1-3/4" - 1-7/8" door thickness, escutcheon trim with knobs
Notes: 3) Specify finish (Screw packs not available in 622 finish)
4) Non torx screw packs contains armor front screws, strike screws, trim screws, mortise screws, spindle, mounting posts
5) Torx screw packs contain armor front, strike and trim screws only
MA/M-Series Miscellaneous Parts
Part Number Description List Price
PE1396 Dust Box, standard with lock $5.50
005099-000-30 Metal Dust Box 10.70
S76806 Spindles (2) for lever on standard door thickness or knob on
door thickness 1-7/8" - 2-1/2" 7.00
S76816 Spindles (2) for lever on door thickness 1-7/8" - 2-1/2" 7.00
S76206 Spindles (2) for knob on standard door thickness 7.00
S76802 Spindles (2) for connecting door, MA161 7.00
AS5813 Mounting plate for use with no outside trim 18.60
030057-002 Replacement M lock lever return spring* 10.00
Note 6): *Return spring is for the old Falcon M mortise lock not the current Falcon MA mortise lock.
MA-Series Escutcheons
Part Number Description
List Price
626 643E
605 606 613 619
622 625 630
AE77012-OP Napa, Outside lever opening
$79.40 $82.40
AE77012-OC Napa, Outside Cylinder and lever openings
AE77012-OK Napa, Outside Cylinder only opening
AE77012-OT Napa, Outside Emergency key and lever opening
E77012-IP Napa, Inside lever opening
E77012-IB Napa, inside Blank, no lever opening
AE77012-IT Napa, Inside lever opening with thumbturn attached 95.30 98.30
AE77012-IE Napa, Inside no lever opening with thumbturn attached
E77012-IC Napa, Inside Cylinder and lever opening 98.10 101.10
E77012-IK Napa, Inside Cylinder only opening
Note: 1) Specify finish
MA-Series ESCUTCHEONS with INDICATOR
Part Number Description
List Price
626 630
AE87012-0T Napa, outside indicator escutcheon trim, MA301/311/321. Vacant/Occupied.
$118.00 $121.00
AE87012-0K Napa, outside indicator escutcheon trim, MA911/921/931/941. Vacant/Occupied.
AE87012-0C Napa, outside indicator escutcheon trim, all other functions. Vacant/Occupied.
AE87012-IC Napa, inside indicator escutcheon trim, MA441. Vacant/Occupied.
AE87112-0T Napa, outside indicator escutcheon trim, MA301/311/321. Locked/Unlocked.
AE87112-0K Napa, outside indicator escutcheon trim, MA911/921/931/941. Locked/Unlocked.
AE87112-0C Napa, outside indicator escutcheon trim, all other functions. Locked/Unlocked.
AE87212-IC Napa, inside indicator escutcheon trim, MA441. Locked/Unlocked.
Note: 2) Specify finish
41
Price Book 8
Effective April 4, 2020 • Rev. 04/20
MA SeriesMortiseGrade 1LOCKS
Prices subject to change without notice
Options • MA-Series
Notes: 1) MA-series locks ordered less all components will be furnished as lock cases. See page 39 for part numbers.
2) Sum of applicable deducts, use DG (Dane Gala) and specified finish for base price.
Notes: 3) Must indicate how lock will be extended: Extended Inside (EI) on non-thumb turn functions only
Extended Outside (EO) on all functions
Extended Equally (EE) on all functions
4) MA451 has maximum 1-3/4" door thickness
Note: 8) Optional Vacant available on the following functions: MA301, MA311, MA321, MA371, MA431, MA451, MA541, MA571, MA641, MA921, MA931, MA941 on the
outside of door.
Optional Vacant available on the following functions: MA441 on the inside of door.
Available in 626 (Satin Chrome) or 630 (Satin Stainless) finish only.
LOCKED/UNLOCKED message indicator only available on the following functions: MA441 on the inside of the door.
Locks Less Components
Description Specify Deduct from Lock Price
Less each knob or lever LLL for knob/lever design
Example: MA581P LLL/DG x DG $29.00
Less each escutcheon LLL for escutcheon design
Example: MA581P DN x DN/LLL 29.40
Less each rose LLL for rose design
Example: MA581P DG x DG/LLL 7.50
Less standard cylinder L suffix
Example: MA581L DG 63.00
Less standard hotel cylinder L suffix
Example: MA451L DG 63.00
Less armor front LLL for latch
Example: MA581P DG 626 LLL 21315R 24.90
Less strike LLL for strike
Example: MA581P DG 626 20099 LLL 12.90
Non-Standard Door Thickness
Description Specify Add to Lock Price
Over 1 7/8" – 2 1/2" thick doors Door thickness and how door is extended
Example: 2", EE $90.40
Abrasive (Available on Avalon, Dane, Quantum and Sutro)
Description Specify Add to Lock Price
6 Prefix Example: 6 DG for Dane Gala*
* G Prefix not available in 613 $62.70
Knurling (Available on Avalon, Dane, Hana, Quantum and Sutro)
Description Specify Add to Lock Price
8 Prefix Example: 8 DG for Dane Gala**
**Only available in 626 finish and levers only $93.60
Lead Wrap
Description Specify Add to Lock Price
9 Prefix Example: 9 DG for Dane Gala $201.00
Allegion Connect
Suffix List Add
CON Cross-category solution using common interconnect components for electrified options.
Available on the MA851 and MA881 functions including all voltage (12 or 24) and RX options.
For wire harness options refer to Electronic Power Supplies section.
N/C
Indicators
Description Specify Add to Lock Price
OCCUPIED/VACANT message indicator.
For Sectional and Escutcheon Trim
Add M Suffix to trim.
Example: DGM for Dane Gala $102.00
LOCKED/UNLOCKED message indicator.
For Sectional and Escutcheon Trim
Add SI Suffix to trim.
Example: DGSI for Dane Gala 102.00
Note: 5) Abrasive option not available on Latitude, Longitude, Broadway, & Boardwark levers.
Note: 6) Knurling option not available on Latitude, Longitude, Broadway, & Boardwark levers.
Note: 7) Lead Wrap option not available on Latitude, Longitude, Broadway, & Boardwark levers.
42
Price Book 8
Effective April 4, 2020 • Rev. 04/20
MA Series Mortise Grade 1 LOCKS
Prices subject to change without notice
MA-Series • Trim Packages
Notes:
S = Sectional, No Thumbturn, up to 2 cylinders
C = Sectional, Thumbturn, no cylinder
T = Sectional, Thumbturn & cylinder
E = Escutcheon Trim
1) Specify Lever/Knob style and finish
2) Contains inside and outside trim, screw pack with mounting hardware
3) If Abrasive option is required on trim package, add additional $62.70 to list price. Not available on Latitude, Longitude, Boardwalk and Broadway levers.
4) If Knurling option is required on trim package, add additional $93.60 to list price. Not available on Latitude, Longitude, Boardwalk and Broadway levers.
* Hana Knob, Sutro-Gala and Sutro-Napa Levers not available in 619m 622 or 643e finishes.
**Latitude, Longitude, Broadway and Boardwalk levers not available in 630 finish.
MA-Series Trim Packages
List Price
Cat. Number Function Specify Style 626
643E*
605 606 613
619* 622*
625 630**
TP 50 S 101, 371, 381, 411, 431, 441, 521, 551, 561, 581, 851, 881 Dane, Sutro, Avalon, Quantum, Hana, Latitude,
Longitude, Broadway, Boardwalk $335.00 $347.00
TP 60 C 301, 311, 321 Dane, Sutro, Avalon, Quantum, Hana, Latitude,
Longitude, Broadway, Boardwalk 365.00 377.00
TP 70 T 451, 531, 541, 571, 621, 641 Dane, Sutro, Avalon, Quantum, Hana, Latitude,
Longitude, Broadway, Boardwalk 390.00 402.00
TP 55 E 101 Dane, Sutro, Avalon, Quantum, Hana, Latitude,
Longitude, Broadway, Boardwalk 404.00 416.00
TP 65 E 311, 321, 301 Dane, Sutro, Avalon, Quantum, Hana, Latitude,
Longitude, Broadway, Boardwalk
423.00 435.00
TP 75 E 431, 441, 411, 371, 381 Dane, Sutro, Avalon, Quantum, Hana, Latitude,
Longitude, Broadway, Boardwalk
TP 85 E 551, 881, 851, 581, 561, 521 Dane, Sutro, Avalon, Quantum, Hana, Latitude,
Longitude, Broadway, Boardwalk
TP 95 E 641, 541, 531, 571, 621, 451 Dane, Sutro, Avalon, Quantum, Hana, Latitude,
Longitude, Broadway, Boardwalk
43
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
RU-Series
Introduction
Finish Codes and Descriptions
Code Description
613 (US10B) Oil Rubbed Bronze
626 (US26D) Satin Chrome
Standard Features - Furnished unless otherwise specified
Certification ANSI A156.2, Series 2000, Grade 1, UL Listed for 3-Hour fire door
Latch 1-1/8" x 2-1/4", Square corner faceplate, 1" housing diameter, 1/2" throw, 2-3/4" backset
Strike 1-1/4" x 4-7/8", ANSI, Square corner, with dust box
Cylinder 6-Pin, Solid brass, Keyed 5-Pin, Falcon G keyway, Keyed different (KD)
Door Range 1-3/4" - 2-1/8" standard
Keys Two, Nickel silver cut keys per lock, Falcon G keyway
Product Identification
RU 501 P D
Latch Suffix
D = Deadlatch
S = Springlatch
Cylinder Suffix
B = Less SFIC
BB = With SFIC Core (Best)
BDC = Disp. Const. Core
G = With SFIC Core (Falcon)
H = With SFIC Keyed Const.
Core
J = Full Size IC
(Specify Manufacturer)
L = Less 6-Pin Cylinder
P = 6-Pin Cylinder pinned
to 5 chambers
P6 = 6-Pin Cylinder pinned
to 6 chambers
P7 = 7-Pin Cylinder
to 7 chambers
CP6 = 6-Pin Cylinder
Schlage C
Function
See 45
Lock Series
SFIC = Small Format (Best® Style) Interchangeable Core
Options
Latches ......................................................................................... 47
Strikes ........................................................................................... 47
Cylinder Requirements .............................................................49
Competitor Cylinders ................................................................50
Parts
Complete Cylinders ....................................................................51
Conventional Cylinder Options ...............................................51
Lock Less Components ............................................................ 52
Tactile Warning ..........................................................................52
Lead Lining .................................................................................. 52
Levers ............................................................................................ 53
Roses ............................................................................................. 53
Misc. Parts .................................................................................... 54
Screws ........................................................................................... 54
Tailpieces ......................................................................................55
Table of Contents
Function Chart 45
Complete Lock Pricing 46
Order Detail 48
RU SeriesPreassembledGrade 1LOCKS
44
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
Mounting screws
Inside lever
Inside rose
Inner mounting plate
Flange nut
Inside spring cage
Mounting plate screws
Outside lever/chassis
RU Series
GRADE 1 PREASSEMBLED LOCK
RU Series Preassembled Grade 1 LOCKS
45
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
Functions • RU-Series
Retrofit Locks
FALCON ANSI
RU521 F40 Office Lock
Turn button locking. Turning button locks outside
lever requiring use of key until button is manually
unlocked. Inside lever always free. Deadlocking latch
bolt.
RU561 F42 Classroom Lock
Deadlocking latch bolt by levers. Outside lever is
locked by key in outside lever. Inside lever is always
free.
RU571 F48 Dormitory/Corridor Lock
Deadlocking latch bolt by levers except when locked
by push button in inside lever. Key in outside lever
locks or unlocks lever and releases button. Closing
door releases push button. Inside lever always free.
RU581 F44 Storeroom Lock
Deadlocking latch bolt by lever inside or key outside.
Outside lever is inoperable. Inside lever always free.
RU851 Storeroom (Electrified-Fail Safe)
Latch bolt operated by lever from either side except
when outer lever is electrically locked. When outer
lever is locked (inoperable), latch bolt retracted
by key in cylinder outside. 24 volt DC .185 Amps,
continuous duty.
RU881 Storeroom (Electrified-Fail Secure)
Deadlocking latch bolt operated by lever inside at
all times. Outside lever inoperable until electrically
unlocked, then latch bolt from either side. When
outside lever is inoperable, latch bolt retracted by
key in cylinder outside.
24 volt DC .185 Amps, continuous duty.
ANSI A156.2, Series 2000 Grade 1
Retrofit Locks
FALCON ANSI
RU101 F36 Passage/Closet Latchset
Latch bolt by levers at all times.
RU301 F37 Privacy/Bedroom/Bath Lock
Latch bolt by levers. Outside lever locked by
push button in inside lever. Rotating inside
lever or closing door releases push button.
Emergency release in outside lever unlocks
door.
RU381 F45 Classroom Security Lock
Latchbolt operated by lever from either
side except when key from inside lever locks
outside lever. When outside lever is locked,
latchbolt retracted by key in outside lever or
by turning inside lever.
RU411 Asylum Lock*
Deadlocking latch bolt by key from either side
at all times. Both levers inoperable.
RU501 F41 Entry Lock
Push button locking. Button on inside locks
outside lever until unlocked by key or by
rotating inside lever.
Inside lever always free.
Deadlocking latch bolt.
RU511 F40/F41 Entry/Office Lock
Turn/push button locking. Pushing and
turning button locks outside lever requiring
use of key until button is manually unlocked.
Push button locking. Pushing button locks
outside lever until unlocked by key or by
rotating inside lever. Inside lever always free.
Deadlocking latch bolt.
* Caution: Double cylinder locks on residences and any door, in any structure, which is used for egress are a life safety hazard in times of emergency and their use
is not recommended. Installation should be in accordance with existing codes only.
RU SeriesPreassembledGrade 1LOCKS
46
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
Grade 1 Heavy Duty Unit Lock Retrofit
Key-In-Lever Lockset ANSI- A156.2, GRADE 1
RU-Series • Complete Locks
D (Dane)
Q (Quantum)
Key-In-Lever
Function Description
Designs and Finishes
D Q D
626 613
Single Cylinder Functions
RU501PD Entry
$834.00 $846.00
RU511PD Entry/Office
RU521PD Entry/Office
RU561PD Classroom
RU571PD Dormitory/Corridor
RU581PD Storeroom
Single Cylinder Functions - Electrified
RU8511PD Elec. Storeroom – Fail Safe 1,262.00 1,274.00
RU8811PD Elec. Storeroom – Fail Secure
Double Cylinder Functions
RU381PD Classroom Security 921.00 933.00
RU411PD Asylum
CAUTION: Double cylinder locks on residences and any door in any structure which is used for egress are a life safety hazard in times of emergency
and their use is not recommended. Installation should be in accordance with existing codes only.
Non-Keyed Functions
RU101S Passage $693.00 $705.00
RU301S Privacy 776.00 788.00
RU Series Preassembled Grade 1 LOCKS
47
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
Latches, Strikes • RU-Series
Latches with Locks
Latch Description
Door Thickness
Add to Lock Price
1-3/4" 2" 2-1/4"
314691 2-3/4" Latch height 1-3/4" x 1/2 Proj. Std. Default N/C
314692 2-3/4" Latch height 2-1/16" x 1/2 Proj. lN/C
314693 2-3/4" Latch height 2-5/8" x 1/2 Proj. lN/C
314694 2-3/4" Latch height 2-11/16" x 1/2 Proj. lN/C
315491 2-3/4" Latch height 1-3/4" x 3/4 Proj. l$164.00
315492 2-3/4" Latch height 2-1/16" x 3/4 Proj. l164.00
315493 2-3/4" Latch height 2-5/8" x 3/4 Proj. l164.00
315494 2-3/4" Latch height 2-11/16" x 3/4 Proj. l164.00
316231 2-3/4" Latch height 1-3/4" x 1/2 Proj. Default N/C
316232 2-3/4" Latch height 2 1/16" x 1/2 Proj. lN/C
316233 2-3/4" Latch height 2 5/8" x 1/2 Proj. lN/C
316234 2-3/4" Latch height 2 11/16" x 1/2 Proj. lN/C
316241 2-3/4" Latch height 1-3/4" x 1/2 Proj. Default N/C
316242 2-3/4" Latch height 2 1/16" x 1/2 Proj. lN/C
316243 2-3/4" Latch height 2 5/8" x 1/2 Proj. lN/C
316244 2-3/4" Latch height 2 11/16" x 1/2 Proj. lN/C
Strikes with Locks
Description Specify Add to Lock Price
ANSI, 1-1/4" x 4-7/8" standard 5164
N/CEarly Corbin Russwin single door 31471
Early Corbin Russwin single door 31471S
Early Corbin Russwin pair doors 31472
$98.10
Yale Mono Pair of Doors 31473
Early Corbin 31474
Early Russwin Unit Lock 31477
ANSI Dust Box 1" deep steel 005099-000 30 N/C
3/4 deep for 3-1/4" high strike, dust box 031453-000 30 2.40
Strikes sold separate
Finishes: 613, 626, 630
Description Lip Length Specify List Price
ANSI, 1-1/4" x 4-7/8" standard
1-3/16"
005164-000 $14.20
Early Corbin Russwin single door
(center line same as early Corbin Russwin)
031471-000 17.10
Early Corbin Russwin single door
(center line is different than early Corbin Russwin)
031471-001
Early Corbin Russwin pair doors 031472-000
91.80
Yale Mono Pair of Doors 031473-000
Early Corbin 031474-000
Early Russwin Unit Lock 031477-000
ANSI Dust Box 1" deep steel 005099-000 30 3.30
3/4 deep for 3-1/4" high strike, dust box - 031453-000 30 2.30
Latches sold separate
Finishes: 613, 626
Backset Description Spring Latch Dead Latch List Price
2-3/4"
Latch height 1-3/4" x 1/2 Proj. A31469-001 A31469-01D $104.00
Latch height 2-1/16" x 1/2 Proj. A31469-002 A31469-02D 137.00
Latch height 2-5/8" x 1/2 Proj. A31469-003 A31469-03D 143.00
Latch height 2-11/16" x 1/2 Proj. A31469-004 A31469-04D
Latch height 1-3/4" x 3/4 Proj. - A31549-01D
205.00
Latch height 2-1/16" x 3/4 Proj. - A31549-02D
Latch height 2-5/8" x 3/4 Proj. - A31549-03D
Latch height 2-11/16" x 3/4 Proj. - A31549-04D
RU SeriesPreassembledGrade 1LOCKS
48
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
RU-Series • Order Detail
When evaluating the retrofit requirements for an RU Series lockset, the following ques tions need to be answered.
o Which manufacturer’s unit lock is currently installed?
oRusswin oCorbin oCorbin Russwin oYale oFalcon
o What is the existing latch height? To determine latch height measure existing latch height as shown here:
Latch heights currently identified and the manufacturer:
1. 1 3/4" Most Corbin & Russwin sold 1949 thru current; Yale 6200
2. 2 1/16" Corbin, Falcon
3. 2 5/8" Certain Corbin (0)2400 Series sold 1913-1953
4. 2 11/16" Russwin 2100 & 2800 Series sold 1904-1968
o What is the existing strike condition?
o What is the existing door thickness?
Locks are for 1 3/4" thick doors only.
0005164-000 031477-000
Early Russwin
Unit Lock
031474-000
Early Corbin
031471-000
Note: Strike, Door and Lock
Same Center Line Early
Corbin Russwin Single Door
031471-001
Note: Strike Center Line is not the
Same as Door and Lock Early
Corbin Russwin Single Door
031472-000
Early Corbin Russwin
Pair of Doors
031473-000
Yale Mono
Pair of Doors
DOOR LATCH
CUT OUT HEIGHT
1-1/4"
3-3/8"
4-1/8"
4-7/8"
1-5/6"
1-15/6"
2-5/8"
1-3/8"
1-15/16"
4-13/16 "
4 "
1-1/8"
9/16"
3-
11/32"
1-1/2"
2-1/8"
5/8"
4-5/32 "
1-1/4"
1- 3/4"
1-1/8" 9/16"
1-9/16"
2-
1/4"
2-1/8"
2-5/8"
3-
1/4"
2-
1/4"
1-1/8"
9/16"
1-9/16"
2-1/8"
2
-5/8"
3-1/4"
1- 7/8"
1-1/8"
2-
1/4"
2-5/8"
3-1/4 "
1- 3/8" 11/16"
1- 7/8"
1-1/8"
2-
1/4"
2-5/8"
3-1/4 "
1- 3/8" 11/16"
Ordering Format
Qty. Catalog
Number
Trim
Design
Finish Latch
Height
Strike
Part No.
Hand Cylinder Other
Requirements
8 RU521 D 626 13/4"031471-000 RH Less IC-CR Cylinder
RU Series Preassembled Grade 1 LOCKS
49
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
Order Detail Cont. • RU-Series
Specify cylinder requirements.
Note: Locks furnished with Falcon’s standard “G” keyway cylinder or prepared for Falcon interchangeable core unless otherwise specified.
With Cylinder
Falcon IC
o6-pin
o 7-pin
Falcon Standard
o 6-pin
specify keyway
o 7-pin
specify keyway
Competitors’ Keyways -
6-pin Standard Cylinder*
o Corbin - 60, 0 Bitted, KD
o Russwin - D1, 0 Bitted, KD
o Sargent - LA, 0 Bitted, KD (Also accepts LB, LC keys)
o Schlage - C, 0 Bitted, KD, KA4
o Schlage - E, 0 Bitted
o Yale - 8 (Para), 0 Bitted, KD
Less Cylinder - Prepared to Accept**
oFalcon IC
Falcon Standard
o 6-pin
o 7-pin
Unit / Mono Lock Cylinders
o Falcon Standard (R Series old small plug) 6-pin
o Corbin Russwin Unit Lock
(2000-052) - Master Ring not available
o Medeco Unit Lock Retrofit Cylinder
(20W5005) - Corbin Russwin Unit Lock
o Medeco Unit Lock Retrofit Cylinder
(20W0500) - Yale 6200 Mono Lock
o Yale Mono Lock (1801) and later models
Competitors’ Standard Cylinders
o Assa (65611 or 65661) 6-pin
o Corbin Russwin (2000-034 / CL3400) 6-pin-
Master Ring not available
o Medeco (20W200V3) 6-pin
- tailpiece supplied by Medeco
- Falcon / Schlage style
o Peaks (Kaba) 6-pin
o Primus (Schlage) 6-pin
o Sargent (6, 7 & 10 Line) 6-pin - Keso not available
o Schlage 6-pin
o Yale (1801) 6-pin - Bicentric not available
Competitors’ IC
o Arrow 6, 7-pin
o Assa (70600IC & V70600IC) 6-pin
o Best 6, 7-pin
o Corbin Russwin (8000) 6-pin
o Corbin Russwin (8000-7) 7-pin
o InstaKey
o Medeco 31 Series 6-pin
o Medeco 32 Series 6-pin
o Medeco Keymark 6, 7-pin
o Peaks (Kaba) 6, 7-pin
o Primus (Schlage) 6-pin
o Sargent (6300) 6-pin
o Schlage 6-pin
o Yale (1210) 6-pin
* Generic replacement cylinders with competitors’ keyways. ** Proper tailpiece supplied unless otherwise noted.
RU SeriesPreassembledGrade 1LOCKS
50
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
RU-Series • Competitors’ I-Cores & Competitors’ Standard Cylinder
Compatibility with Competitors’ I-Cores
Compatibility with Competitors’ Standard Cylinders
The RU Series is furnished with Falcon’s standard “G” keyway cylinder unless otherwise specified.
The RU Series accepts the following competitors’ standard 6-pin cylinders.
o Assa (65611 or 65661) 6-pin
o Corbin Russwin (2000-034 / CL3400) 6-pin -
Master Ring not available
o Medeco (20W200V3) 6-pin
- tailpiece supplied by Medeco
- Falcon / Schlage style
o Peaks (Kaba) 6-pin
o Primus (Schlage) 6-pin
o Sargent (6, 7 & 10 Line) 6-pin - Keso not available
o Schlage 6-pin
o Yale (1801) 6-pin - Bicentric not available
Falcon’s standard interchangeable core option. Specify 6 or 7-pin.
Locksets with this option also accept Schlage SFIC, Arrow (in clud ing Flex Core),
Best (including PKS & Peaks), InstaKey, Kaba Peaks, Keymark and KSP cores.
The following larger format interchangeable cores will work with the T Series locksets when lockset is so specified:
Assa
old and new style
Specify IC-AS
Corbin Russwin
8000 or 8000-7
Specify IC-CR6
or IC-CR7
Medeco
32 Series 6-pin
Specify IC-ME
Medeco
31 Series 6-pin
Specify IC-YA6
Sargent
6300
Specify IC-SA
Schlage 6-pin
including Primus
Specify IC-SC
Yale 6-pin
Specify IC-YA6
Falcon
Assa Corbin
Russwin Medeco
32 Medeco
31 Sargent
6300 Schlage Yale
RU Series Preassembled Grade 1 LOCKS
51
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
Cylinder Options • RU-Series
Notes: 1) Finishes: 606 and 626 only
2) Specify keyway
3) Cylinders are furnished G keyway, keyed differently unless otherwise specified.
4) Restricted sections add $10.80 to list price. See page 8 for list of standard keyways.
All other keyways are considered restricted. Contact 877-671-7011 for availability.
* Competitor keyways are furnished 0 bitted, unless otherwise specified. Not available Master keyed, except Schlage C.
KD option is not available for locks containing 2 cylinders.
Note: 5) Control keys are not furnished with locks and must be ordered separately. See page 151 for details policy
on use of restricted keyway cylinders. Contact 877-671-7011 for availability.
* Keying must be specified
** Locks are assessed one non-refundable handling charge (50-231F) per core.
RU Series • Complete Cylinders
Cylinder Mechanism Part Number Price Each
5 pin cylinder RU series (except 381 IS, 571) A23151-05
$56.00
5 pin cylinder RU series 381 IS A23151-06
5 pin cylinder RU series 571 A23151-07
6 pin cylinder RU series (except 381 IS, 571) A23161-05
6 pin cylinder RU series 381 IS A23161-06
6 pin cylinder RU series 571 A23161-07
7 pin cylinder RU series (except 381 IS, 571) A23171-05
71.007 pin cylinder RU series 381 IS A23171-06
7 pin cylinder RU series 571 A23171-07
Conventional Cylinder Options
Description Specify
Add to Lock
Price (per core)
5 pinned cylinder P Suffix
Example: RU581P STD
6 pinned cylinder P6 Suffix
Example: RU581P6 N/C
7 pinned cylinder P7 Suffix
Example: RU581P7 $11.90
6 pinned Competitor keyway cylinders* P6 Suffix
Example: RU581P6 (0 Bitted, KD, KA4 only) N/C
Schlage C (6 pin only) CP6 Suffix
Example: RU581CP6 (All other keying, not listed above)
Interchangeable Core and Small Format Construction Core
Description Specify
Add to Lock
Price (per core)
Small format core * G Suffix
Example: RU581GD $46.00
Small format core (Best Style) * BB Suffix
Example: RU581BB
Small format construction core ** H Suffix
Example: RU581HD 46.00
Less Small format core B Suffix
Example: RU581BD N/C
Less Full Size core J Suffix
Example: RU581JD SCH x DAN
Small format disposable core BDC Suffix
Example: RU581BDC N/C
RU SeriesPreassembledGrade 1LOCKS
52
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
RU-Series • Less Components, Thick Door, Tactile Warning, Lead Lining
Locks Less Components
Description Specify
Deduct from
Price (per core)
Less standard cylinder L suffix
Example: RU581LD DAN $56.00
Less latch LLL suffix
Example: RU581PD DAN 626 LLL/5164 7.40
Less strike LLL suffix
Example: RU581PD DAN 626 314691 LLL 9.10
Tactile Warning (Abrasive coat)
Description Specify
Add to
Lock Price
Abrasive Preface the design code with 6
Example: 6DA for DAN $68.30
Lead Lining
Description Specify
Add to
Lock Price
Lead lining Preface the design code with 9
Example: 9DA for DAN $302.00
RU Series Preassembled Grade 1 LOCKS
53
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
Trim • RU-Series
* Specify design prefix D (Dane), Q (Quantum)
Note: 1) Dane available in 626 and 613 Quantum available in 626.
Levers, Conventional Cylinder
Part Number Description List Price
030742-000 Dane lever, closed
$50.60
030742-001 Dane lever, open
030744-000 Quantum lever, closed
030744-001 Quantum lever, open
030929-002 Lever, Dane open (Corbin Russwin, Medeco, Yale unit) 60.30
030929-003 Lever, Quantum open (Corbin Russwin, Medeco, Yale unit)
030996-002 Lever, Dane open (Sargent 6, 7 & 10 line, Yale) 67.70
030996-003 Lever, Quantum open (Sargent 6, 7 & 10 line, Yale)
A30753-00* Inside lever w/set screw, closed 41.30
A30753-01* Inside lever w/set screw, open
A31544-00* Inside lever w/set screw, closed 851/881 104.00
Levers and related parts, Small Format and Large Format Interchangeable Core
Part Number Description List Price
030742-002 Lever, Dane SFIC $50.60
030744-002 Lever, Quantum SFIC
030926-002 Lever, Dane IC, ASSA, Medeco, Yale 108.00
030926-003 Lever, Quantum IC, ASSA, Medeco, Yale
030927-002 Lever, Dane IC, Schlage 108.00
030927-003 Lever, Quantum IC, Schlage
030928-002 Lever, Dane IC, Corbin Russwin 105.00
030928-003 Lever, Quantum IC, Corbin Russwin
030930-002 Lever, Dane IC, Sargent 112.00
030930-003 Lever, Quantum IC, Sargent
Roses
Part Number Description List Price
031452-000 Rose, square $34.60
RU SeriesPreassembledGrade 1LOCKS
54
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
RU-Series • Miscellaneous Parts
Miscellaneous Parts
Part Number Description List Price
022104-000-30 Short Slide Catch $0.92
022105-000-30 Slide Catch 2.60
022106-002-55 Retractor 3.20
022108-000-60 Retractor Spring 2.00
022112-000-30 Retainer, Retractor Spring 2.00
022986-001-50 Retractor Insert 0.64
030703-000-30 Inner Spindle, Passage and Button Functions 26.80
030704-002-30 Lever Stop Plate 3.80
030709-000-60 Clutch Spring 0.44
030712-000-30 Mounting Plate, Inner 3.70
030712-001-30 Mounting Plate, Outer 3.30
030718-000-30 Key Spindle, std 4.70
030718-001-30 Key Spindle, IC
030722-000-30 Dogging Bar 3.20
030724-000-30 Lever Retaining Ring 0.64
030726-000-30 Flanged Nut 7.50
030726-007-30 Flanged Nut, Inner Electrified 10.50
030728-000 Push Button Cap 9.90
030733-000-55 Spindle Inner 3.40
031511-000-30 Hex Nut, 1/-28 Special 8.30
031514-000-30 Solenoid Mount 10.70
031519-000-30 Inner Spindle, RU851/881 42.20
1387 Hex Key – 1/8" with Looped Handle 15.90
A30746-000-00 Hub & Housing Assembly 15.70
A30747-000-00 Hub & Plate Assembly 14.40
A30749-060-00 Insert & Spindle Assembly, Outer, 6 Pin 102.00
A30749-070-00 Insert & Spindle Assembly, Outer, 7 Pin 61.20
A30905-001-00 Spindle & Driver Assembly, IC
57.50A30905-060-00 Spindle & Driver Assembly, 6 Pin
A30906-070-00 Spindle & Driver Assembly, 7 Pin
A30913-000-00 Key Spindle Assembly, Inner Std. 168.00
A30913-001-00 Key Spindle Assembly, Inner IC
Q330-272 RU Lock Spring Cage Kit (for all functions except RU101 and RU301) 40.10
Q330-273 RU Lock Spring Cage Kit (RU101 and RU301)
Screws
Part Number Description Finishes Size List Price
002762-000 RU latch screw 606, 613, 626 8-32 x3/8 $0.36
002770-016-30 Insert screws –10-32 x 1 0.50
021164-016 ANSI strike screws 606, 613, 626, 630 12-24 x 1" combo 0.58
024416-012 Latch and strike screws 606, 613, 626, 630 8-32 x 3/4"combo 0.34
030755-005-30 Type D screw – 8-32 x 5/16" 0.44
030831-004-30 Set screw – 1/4-20 x 1/4" 0.62
031533-006-30 Self tap screw – 8-32 x 3/8" 0.46
031541-006-30 Mounting plate screws – 8-32 x 1/2" 0.48
RU Series Preassembled Grade 1 LOCKS
55
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
Cylinder & IC Parts • RU-Series
* Arrow, Best, InstaKey. Kaba Peaks, Keymark, KSP and Schlage small format cores all use the Falcon configuration.
Tailpieces for Conventional Cylinders
Cylinder Std. Functions RU381 Inside RU571 Price
Falcon 6-pin* (10/pack) A30730-001-00 A30730-003-00 A30730-002-00 $23.80 pkg. of 10
Falcon 7-pin (10/pack) A30730-002-00 A30730-004-00 A30730-006-00 $23.80 pkg. of 10
Sargent 6 & 10 Line 030997-001-30 030997-003-30 030997-005-30 12.60
Yale1801, 5801 030917-001-30 030917-003-30 030917-005-30 36.00 each
Corbin Russwin 030994-001-30 030994-003-30 030994-005-30 67.80
IC Throw Members (Tailpieces)
Core Type Std. Functions RU381 Inside RU571 Price
Falcon 6-pin* 030739-000-30 030739-000-30 $3.00
Falcon 6-pin* 030739-002-30 10.20
Falcon 7-pin* 030739-001-30 030739-001-30 3.00
Falcon 7-pin * 030739-003-30 3.00
Corbin Russwin 8000 and Sargent 6300 031468-000-30 031468-002-30 031468-004-30 7.70
Corbin Russwin 8000-7 (7-pin) 031468-001-30 031468-003-30 031468-005-30 7.70
Medeco 32 Series & ASSA A30988-000-00 A30988-002-00 A30988-000-00 6.60
Schlage full size, including Primus 031467-000-30 031467-002-30 031467-004-30 15.80
Yale and Medeco 31 Series 6-pin 030917-001-30 030917-003-30 030917-005-30 36.00
RU SeriesPreassembledGrade 1LOCKS
56
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
RU-Series Notes
RU Series Preassembled Grade 1 LOCKS
57
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
T-Series
Introduction
Standard Features - Furnished unless otherwise specified
Certification ANSI A156.2, Series 4000, Grade 1, UL Listed for 3-Hour fire door
Latch 1-1/8" x 2-1/4", Square corner faceplate, 1" housing diameter, 1/2" throw, 2-3/4" backset
Strike 1-1/4" x 4-7/8", ANSI, Square corner, no box
Cylinder 6-Pin, Solid brass, Keyed 5-Pin, Falcon G keyway, Keyed different (KD)
Door Range 1-3/4" - 2-1/8" standard
Keys Two, Nickel silver cut keys per lock, Falcon G keyway
Finish Codes and Descriptions
Code Description
605 (US3) Bright Brass
606 (US4) Satin Brass
613 (US10B) Oil Rubbed Bronze
619 (US15) Satin Nickel
622 Matte Black
625 (US26) Bright Chrome
626 (US26D) Satin Chrome
643E (US11) Aged Bronze
Product Identification
T 501 P D
Latch Suffix
D = Deadlatch
S = Springlatch
Cylinder Suffix
B = Less SFIC
BB = With SFIC Core (Best)
BDC = Disp. Const. Core
G = With SFIC Core (Falcon)
H = With SFIC Keyed Const.
Core
J = Full Size IC
(Specify Manufacturer)
L6 = Less 6-Pin Cylinder
L7 = Less 7-Pin Cylinder
P = 6-Pin Cylinder pinned
to 5 chambers
P6 = 6-Pin Cylinder pinned
to 6 chambers
P7 = 7-Pin Cylinder
to 7 chambers
CP6 = 6-Pin Cylinder
Schlage C
Function
See 59
Lock Series
SFIC = Small Format (Best® Style) Interchangeable Core
Table of Contents
Function Chart 59
Complete Lock Pricing 60
Options & Parts
Cylinders ........................................................................................61
Tailpieces ......................................................................................62
Order Detail .................................................................................63
Competitor Cylinders ................................................................64
Lock Less Components ............................................................65
Non-Standard Door Thickness .............................................. 65
Tactile Warning ..........................................................................65
Lead Lining ..................................................................................65
Allegion Connect ........................................................................65
Latches with Locks ....................................................................65
Strikes ...........................................................................................66
Levers ............................................................................................ 67
Roses ............................................................................................. 67
Misc. Parts ....................................................................................68
Chassis Assemblies ...................................................................68
Screws ........................................................................................... 69
T SeriesCylindricalGrade 1LOCKS
58
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
Mounting screws
Inside lever
Inside rose
Inner mounting plate
Flange nut
Inside spring case
Reversible deadlatch
Outside lever/chassis
T Series
GRADE 1 CYLINDRICAL LOCK
T Series Cylindrical Grade 1 LOCKS
59
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
Key-In-Lever Locks
FALCON ANSI
T521 F81 Office Lock
Turn button locking. Turning button locks outside
lever requiring use of key until button is manually
unlocked. Inside lever always free. Deadlocking latch
bolt.
T561 F84 Classroom Lock
Deadlocking latch bolt by levers. Outside lever is
locked by key in outside lever. Inside lever is always
free.
T571 F90 Dormitory/Corridor Lock
Deadlocking latch bolt by levers except when locked
by push button in inside lever. Key in outside lever
locks or unlocks outside lever and releases button.
Closing door releases push button. Inside lever
always free.
T581 F86 Storeroom Lock
Deadlocking latch bolt by lever inside or key outside.
Outside lever is inoperable. Inside lever always free.
T851 Storeroom (Electrified – Fail Safe)
Latch bolt operated by lever from either side except
when outer lever is electrically locked. When outer
lever is locked (inoperable), latch bolt retracted
by key in cylinder outside. Available in both 12 (.65
Amps) or 24 (.32 Amps) volt DC, continuous duty.
T881 Storeroom (Electrified – Fail Secure)
Deadlocking latch bolt operated by lever inside at
all times. Outside lever inoperable until electrically
unlocked, then latch bolt from either side. When
outside lever is inoperable latch bolt retracted by
key in cylinder outside. Available in both 12 (.65
Amps) or 24 (.32 Amps) volt DC, continuous duty.
T12 Dummy Trim
Single Trim-surface mounted rigid lever.
ANSI A156.2 Series 4000 Grade 1
Key-In-Lever Locks
FALCON ANSI
T101 F75 Passage/Closet Latchset
Latch bolt by levers at all times.
T291 Privacy Hospital Lock
Latch bolt by levers. Outside lever locked by
push button in inside lever. Rotating inside
lever, closing door, or turning emergency
release turn button on outside, release push
button. Inside is always free for egress.
T301 F76 Privacy Lock
Latch bolt by levers. Outside lever locked by
push button in inside lever. Rotating inside
lever or closing door releases push button.
Emergency release in outside lever unlocks
door.
T351 Closet Lock
Deadlocking latch bolt by turn knob inside
or lever outside except when outside lever is
locked by key.
T381 F88 Classroom Security Lock
Latchbolt operated by lever from either
side except when key from inside lever locks
outside lever. When outside lever is locked,
latchbolt retracted by key in outside lever or
by turning inside lever.
T411 F87 Asylum Lock*
Deadlocking latch bolt operated by key in
lever from either side. Both levers always
inoperable.
T501 F82 Entry Lock
Push button locking. Button on inside locks
outside lever until unlocked by key or by
rotating inside lever. Inside lever always free.
Deadlocking latch bolt.
T511 F109 Entry/Office Lock
Turn/push button locking. Pushing and
turning button locks outside lever requiring
use of key until button is manually unlocked.
Push button locking. Pushing button locks
outside lever until unlocked by key or by
rotating inside lever. Inside lever always free.
Deadlocking latch bolt.
Functions • T-Series
* Caution: Double cylinder locks on residences and any door, in any
structure, which is used for egress are a life safety hazard in times of
emergency and their use is not recommended. Installation should be
in accordance with existing codes only.
T SeriesCylindricalGrade 1LOCKS
60
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
T-Series • Complete Locks Grade 1 Extra Heavy Duty Cylindrical Locksets
ANSI-A156.2, SERIES 4000, GRADE 1
A (Avalon)
LON (Longitude)*
LAT (Latitude) D (Dane)
BRW (Broadway)
Q (Quantum)
BRK (Boardwalk)
Key-In-Lever
Function Description
Designs and Finishes
A D Q LAT LON BRW BRK
626 643E 605 606 613 619 622 625
Single Cylinder Functions
T351PD Closet
$443.00 $455.00
T501PD Entry
T511PD Entry/Office
T521PD Office
T561PD Classroom
T571PD Dormitory/Corridor
T581PD Storeroom
T851PD1Elec. Storeroom – Fail Safe 808.00 820.00
T881PD1Elec. Storeroom – Fail Secure
Double Cylinder Functions
T381PD Exit Security $519.00 $531.00
T411PD Asylum
CAUTION: Double cylinder locks on residences and any door in any structure which is used for egress are a life safety hazard in times of emergency
and their use is not recommended. Installation should be in accordance with existing codes only.
Non-Keyed Functions
T101S Passage $317.00 $329.00
T291S Hospital/Grade School Privacy 398.00 410.00
T301S Privacy
Dummy Trim
T12 Half Dummy 141.00 147.00
Notes: 1) 24V is standard. Power supply PS902 will be sufficient to operate an individual lock for multiple lock installation -
see Power Supply section.
T Series Cylindrical Grade 1 LOCKS
61
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
Cylinder Options • T-Series
Notes: 1)Finishes: 606, 622*, & 626 only
2) Specify keyway
3) Cylinders are furnished G keyway, keyed differently unless otherwise specified.
4) Restricted sections add $10.80 to list price. See page 8 for list of standard keyways.
All other keyways are considered restricted. Contact 877-671-7011 for availability.
5) 622 Finish is available only on Allegion cylinders (P, P6, & P7) in C & G Keyways.
* Competitor keyways are furnished 0 bitted, unless otherwise specified. Not available Master keyed, except Schlage C.
KD option is not available for locks containing 2 cylinders.
Note: 6) Control keys are not furnished with locks and must be ordered separately. See page 151 for details.
7) 622 Finish is available only on SFIC (G) in C & G Keyways.
* Keying must be specified
** Locks are assessed one non-refundable handling charge (50-231F) per core.
T Series • Complete Cylinders
Cylinder Mechanism Part Number Price Each
5 pin cylinder T series (except 381 IS, 571) A23151-05
$56.00
5 pin cylinder T series 381 IS A23151-06
5 pin cylinder T series 571 A23151-07
6 pin cylinder T series (except 381 IS, 571) A23161-05
6 pin cylinder T series 381 IS A23161-06
6 pin cylinder T series 571 A23161-07
7 pin cylinder T series (except 381 IS, 571) A23171-05
71.007 pin cylinder T series 381 IS A23171-06
7 pin cylinder T series 571 A23171-07
Conventional Cylinder Options
Description Specify
Add to Lock
Price (per core)
5 pinned cylinder P Suffix
Example: T581P STD
6 pinned cylinder P6 Suffix
Example: T581P6 N/C
7 pinned cylinder P7 Suffix
Example: T581P7 $11.90
6 pinned Competitor keyway cylinders* P6 Suffix
Example: T581P6 (0 Bitted, KD, KA4 only)
Schlage C (6 pin only) CP6 Suffix
Example: T581CP6 (All other keying, not listed above) N/C
Small Format Interchangeable Core and Small Format Construction Core
Description Specify
Add to Lock
Price (per core)
Small format core * G Suffix
Example: T581GD $46.00
Small format core (Best Style) * BB Suffix
Example: T581BB
Small format construction core ** H Suffix
Example: T581HD 46.00
Less Small format core B Suffix
Example: T581BD N/C
Less Full Size core J Suffix
Example: T581JD SCH x DAN
Small format disposable core BDC Suffix
Example: T581BDC N/C
T SeriesCylindricalGrade 1LOCKS
62
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
T-Series • Cylinder Parts
* Assa 65611 and 65661, Corbin Russwin 2000-034 and Schlage, including Primus, all use the Falcon 6-pin tailpiece.
* Arrow, Best, InstaKey, Kaba Peaks, Keymark, KSP and Schlage small format cores all use the Falcon configuration.
Tailpieces for Conventional Cylinders
Cylinder Std. Functions T381 Inside T571 Price
Falcon 6-pin* (10/pack) A30730-001-00 A30730-003-00 A30730-002-00 $23.80 pkg. of 10
Falcon 7-pin (10/pack) A30730-002-00 A30730-004-00 A30730-006-00 $23.80 pkg. of 10
Sargent 6 & 10 Line 030997-001-30 030997-003-30 030997-005-30 12.60
Yale1801, 5801 030917-001-30 030917-003-30 030917-005-30 36.00 each
Corbin Russwin 030994-001-30 030994-003-30 030994-005-30 67.80
IC Throw Members (Tailpieces)
Cylinder Std. Functions T381 Inside T571 Price
Falcon 6-pin* 030739-000-30 030739-000-30 $3.00
Falcon 6-pin* 030739-002-30 10.20
Falcon 7-pin* 030739-001-30 030739-001-30 3.00
Falcon 7-pin* 030739-003-30 3.00
Corbin Russwin 8000 and Sargent 6300 031468-000-30 031468-002-30 031468-004-30 7.70
Corbin Russwin 8000-7 (7-pin) 031468-001-00 031468-003-30 031468-005-30 7.70
Medeco 32 Series & ASSA A30988-000-00 A30988-002-00 A30988-000-00 6.70
Schlage Full Size, Including Primus 031467-000-30 031467-002-30 031467-004-30 15.80
Yale and Medeco 31 Series, 6-pin 030917-001-30 030917-003-30 030917-005-30 36.00
T Series Cylindrical Grade 1 LOCKS
63
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
Order Detail • T-Series
Specify cylinder requirements.
Note: Locks furnished with Falcon’s standard “G” keyway cylinder or prepared for Falcon interchangeable core unless otherwise specified.
With Cylinder
Falcon IC
o6-pin
o 7-pin
Falcon Conventional
o 6-pin
specify keyway
o 7-pin
specify keyway
Competitors’ Keyways -
6-pin Conventional Cylinder*
o Corbin - 60, 0 Bitted, KD
o Russwin - D1, 0 Bitted, KD
o Sargent - LA, 0 Bitted, KD (Also accepts LB, LC keys)
o Schlage - C, 0 Bitted, KD, KA4
o Schlage - E, 0 Bitted
o Yale - 8 (Para), 0 Bitted, KD
Less Cylinder - Prepared to Accept**
oFalcon IC
Falcon Conventional
o 6-pin
o 7-pin
Unit / Mono Lock Cylinders
o Falcon Standard (R Series old small plug) 6-pin
o Corbin Russwin Unit Lock
(2000-052) - Master Ring not available
o Medeco Unit Lock Retrofit Cylinder
(20W5005) - Corbin Russwin Unit Lock
o Medeco Unit Lock Retrofit Cylinder
(20W0500) - Yale 6200 Mono Lock
o Yale Mono Lock (1801) and later models
Competitors’ Conventional Cylinders
o Assa (65611 or 65661) 6-pin
o Corbin Russwin (2000-034 / CL3400) 6-pin-
Master Ring not available
o Medeco (20W200V3) 6-pin
- tailpiece supplied by Medeco
- Falcon / Schlage style
o Peaks (Kaba) 6-pin
o Primus (Schlage) 6-pin
o Sargent (6, 7 & 10 Line) 6-pin - Keso not available
o Schlage 6-pin
o Yale (1801) 6-pin - Bicentric not available
Competitors’ IC
o Arrow 6, 7-pin
o Assa (70600IC & V70600IC) 6-pin
o Best 6, 7-pin
o Corbin Russwin (8000) 6-pin
o Corbin Russwin (8000-7) 7-pin
o InstaKey
o Medeco 31 Series 6-pin
o Medeco 32 Series 6-pin
o Medeco Keymark 6, 7-pin
o Peaks (Kaba) 6, 7-pin
o Primus (Schlage) 6-pin
o Sargent (6300) 6-pin
o Schlage 6-pin
o Yale (1210) 6-pin
* Generic replacement cylinders with competitors’ keyways. ** Proper tailpiece supplied unless otherwise noted.
T SeriesCylindricalGrade 1LOCKS
64
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
T-Series • Competitors’ I-Cores & Competitors’ Standard Cylinder
Compatibility with Competitors’ I-Cores
Falcon’s standard interchangeable core option. Specify 6 or 7-pin.
Locksets with this option also accept Schlage SFIC, Arrow (in clud ing Flex Core),
Best (including PKS & Peaks), InstaKey, Kaba Peaks, Keymark and KSP cores.
The following larger format interchangeable cores will work with the T Series locksets when lockset is so specified:
Assa
old and new style
Specify IC-AS
Corbin Russwin
8000 or 8000-7
Specify IC-CR6
or IC-CR7
Medeco
32 Series 6-pin
Specify IC-ME
Medeco 31
31 Series 6-pin
Specify IC-YA6
Sargent
6300
Specify IC-SA
Schlage 6-pin
including Primus
Specify IC-SC
Yale 6-pin
Medeco 31 Series
Specify IC-YA6
Falcon
Assa Corbin
Russwin Medeco
32 Medeco
31 Sargent
6300 Schlage Yale
Compatibility with Competitors’ Standard Cylinders
The T Series is furnished with Falcon’s standard “G” keyway cylinder unless otherwise specified, and accepts the following competitors’
standard 6-pin cylinders.
o Assa (65611 or 65661) 6-pin
o Corbin Russwin (2000-034 / CL3400) 6-pin -
Master Ring not available
o Medeco (20W200V3) 6-pin
- tailpiece supplied by Medeco
- Falcon / Schlage style
o Peaks (Kaba) 6-pin
o Primus (Schlage) 6-pin
o Sargent (6, 7 & 10 Line) 6-pin - Keso not available
o Schlage 6-pin
o Yale (1801) 6-pin - Bicentric not available
T Series Cylindrical Grade 1 LOCKS
65
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
Special Options • T-Series
Locks Less Components
Description Specify Deduct from
Lock Price
Less each lever LLL
Example: T581PD LLL/DAN $24.60
Less standard cylinder L suffix
Example: T581LD DAN 56.00
Less latch LLL
Example: T581PD DAN 626 LLL/5164 38.40
Less strike LLL
Example: T581PD DAN 626 98535 LLL 9.20
Non-Standard Door Thickness
Description Specify Add to
Lock Price
Door thickness 1-3/8" to 1-3/4" A30775-000-00 for thin door shims $12.80
Tactile Warning (abrasive coat)
Description Specify Add to
Lock Price
Abrasive Strip* Preface the design code with 6
Example: 6DA for DAN $60.20
Lead Lining
Description Specify Add to
Lock Price
Lead lining Preface the design code with 9
Example: 9DA for DAN $276.00
Part Number Description Price
24483760 latch spacer for hollow door applications $5.30
Note: 1) T Series lockset will accommodate up to a 2-1/4" thick door prep standard.
Note: 2) Outside lever only is coated unless otherwise specified.
* Not available in 613, Latitude, Longitude, Broadway, & Boardwalk Levers.
Note: 3) Lead Lining is not available on Latitude, Longitude, Broadway, & Boardwalk levers.
Latches with Locks
Backset Description
HSG
Dia
Specify Add to
Lock PriceSpringlatch Deadlatch
2-3/8" Square corner, 1" x 2-1/4"
1"
23981111 23981160 N/C
2-3/4" Square corner, 1-1/8" x 2-1/4", std. 23981137 23981145
2-3/4" Anti-friction fire door latch
Square corner, 1-1/8" x 2-1/4", 3/4" throw – 23981152 $187.00
3-3/4" Square corner, 1-1/8" x 2-1/4" 24074387 23981129 N/C
5" Backset extension Link 43-005 34.10
Allegion Connect
Suffix List Add
CON Cross-category solution using common interconnect components for electrified options. Available on the
T851 and T881 functions. For wire harness options refer to Electronic Power Supplies Section. N/C
T SeriesCylindricalGrade 1LOCKS
66
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
T-Series • Latches and Strikes
Shaded items are standard components and are furnished with locks unless otherwise specified.
Latches sold separate
Finishes: 606, 613, 630
Specify
Backset Description
HSG
Dia List PriceSpringlatch Deadlatch
23981111 23981160 2-3/8" Square corner, 1" x 2-1/4"
1"
$95.60
23981137 23981145 2-3/4" Square corner, 1-1/8" x 2-1/4", std. 73.70
– 23981152 2-3/4" Anti-friction fire door latch
Square corner, 1-1/8" x 2-1/4", 3/4" throw 282.00
24074387 23981129 3-3/4" Square corner, 1-1/8" x 2-1/4" 88.40
43-005 5" Backset extension Link 34.10
Strikes with Locks
Description Lip Length Specify Add to Lock Price
ANSI, 1-1/4" x 4-7/8" standard 1-3/16" 5164 N/C
Square corner, full lip 1-5/8" x 2-1/4" 1" 01-049 N/C
1/4" Radius round corner, full lip 1-5/8" x 2-1/4" 1" 01-048 N/C
Square Corner, T-strike, 1-1/8" x 2-3/4" 1-5/16" 5185 N/C
ANSI dust box 1" deep, steel - 005099-000-30 N/C
ANSI 1-1/4" x 4-7/8" 7/8" 5161 N/C
Radius T Strike, 1-1/8" x 2-3/4" 9/16" 5185-4 N/C
Strikes sold separate
Description Lip Length Specify List Price
ANSI, 1-1/4" x 4-7/8" standard 1-3/16" 005164-000 $14.20
Square Corner, T-strike, 1-1/8" x 2-3/4" 1-1/8" A05185-000 4.40
1/4" Radius round corner, full lip 1-5/8" x 2-1/4" 1" Q001-048 4.40
Square corner, full lip 1-5/8" x 2-1/4" Q001-049
ANSI dust box 1" deep, steel - 005099-000-30 3.30
ANSI 1-1/4" x 4-7/8" 7/8" 005161-000 23.90
Radius T Strike, 1-1/8" x 2-3/4" 9/16" A05185-004 29.90
T Series Cylindrical Grade 1 LOCKS
67
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
Levers and Parts • T-Series
Note: 1) When ordering levers or roses, specify finish.
Note: 2) Competitor prepped levers are not available in 622, 619, & 643e Finish except Schlage options.
Levers, Conventional Cylinder
Part Number Description List Price
030740-000 Avalon lever, closed
$50.60
030740-001 Avalon lever, open
Q330-430 BRK Boardwalk lever, closed
Q330-431 BRK Boardwalk lever, open
Q330-430 BRW Broadway lever, closed
Q330-431 BRW Broadway lever, open
030742-000 Dane lever, closed
030742-001 Dane lever, open
Q330-430 LAT Latitude lever, closed
Q330-431 LAT Latitude lever, open
Q330-430 LON Longitude lever, closed
Q330-431 LON Longitude lever, open
030744-000 Quantum lever, closed
030744-001 Quantum lever, open
030929-001 Lever, Avalon open (Corbin Russwin, Medeco, Yale unit)
60.30030929-002 Lever, Dane open (Corbin Russwin, Medeco, Yale unit)
030929-003 Lever, Quantum open (Corbin Russwin, Medeco, Yale unit)
030996-001 Lever, Avalon open (Sargent 6, 7 & 10 line, Yale)
67.70030996-002 Lever, Dane open (Sargent 6, 7 & 10 line, Yale)
030996-003 Lever, Quantum open (Sargent 6, 7 & 10 line, Yale)
A30753-00* Inside lever w/set screw, closed 41.30
A30753-01* Inside lever w/set screw, open
A31544-00* Inside lever w/set screw, closed 851/881 104.00
Levers, Small and Large Format Interchangeable Core
Part Number Description List Price
030740-002 Lever, Avalon SFIC
$50.60
Q330-432 BRK Lever, Boardwalk SFIC
Q330-432 BRW Lever, Broadway SFIC
030742-002 Lever, Dane SFIC
Q330-432 LAT Lever, Latitude SFIC
Q330-432 LON Lever, Longitude SFIC
030744-002 Lever, Quantum SFIC
030926-001 Lever, Avalon IC, ASSA, Medeco, Yale
108.00030926-002 Lever, Dane IC, ASSA, Medeco, Yale
030926-003 Lever, Quantum IC, ASSA, Medeco, Yale
030927-001 Lever, Avalon IC, Schlage
108.00
Q330-433 BRK Lever, Boardwalk FSIC
Q330-433 BRW Lever, Broadway FSIC
030927-002 Lever, Dane IC, Schlage
Q330-433 LAT Lever, Latitude FSIC
Q330-433 LON Lever, Longitude FSIC
030927-003 Lever, Quantum IC, Schlage
030928-001 Lever, Avalon IC, Corbin Russwin
105.00030928-002 Lever, Dane IC, Corbin Russwin
030928-003 Lever, Quantum IC, Corbin Russwin
030930-001 Lever, Avalon IC, Sargent
112.00030930-002 Lever, Dane IC, Sargent
030930-003 Lever, Quantum IC, Sargent
Roses
Part Number Description List Price
626 643E 605 606 613 619 622
030706-002 Rose cover $24.40 $27.40
T SeriesCylindricalGrade 1LOCKS
68
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
T-Series • Levers and Parts
Miscellaneous Parts
Part Number Description List Price
022104-000-30 Short Slide Catch 0.92
022105-000-30 Slide Catch 2.60
022106-002-55 Retractor 3.20
022108-000-60 Retractor Spring 2.00
022112-000-30 Retainer, Retractor Spring 2.00
022986-001-50 Retractor Insert 0.64
030654-000-625 Emergency Release Cap 2.40
030654-000-626 Emergency Release Cap 2.90
030703-000-30 Inner Spindle, Passage and Button Functions 26.80
030704-002-30 Lever Stop Plate 3.80
030709-000-60 Clutch Spring 0.44
030712-000-30 Mounting Plate, Inner 3.70
030712-001-30 Mounting Plate, Outer 3.30
030722-000-30 Dogging Bar 3.20
030724-000-30 Lever Retaining Ring 0.64
030726-000-30 Flanged Nut 7.50
030726-007-30 Flanged Nut, Inner Electrified 10.50
030728-000 Push Button Cap 9.90
030729-000-70 Outer Button Mount 1.30
030733-000-55 Spindle Inner 3.40
030787-000-70 Button Spacer 2.50
M204-198 Drill guide for locating 5/16" thru-bolt holes 15.70
031516-000-70 Solenoid, Fail secure T881 388.00
031511-000-30 Hex Nut, 1/-28 Special 8.30
031514-000-30 Solenoid Mount 10.70
031519-000-30 Inner Spindle, T851/881 42.20
1387 Hex Key – 1/8" with Looped Handle 15.80
1388 Hex Wrench 36.60
A30746-000-00 Hub & Housing Assembly 15.70
A30747-000-00 Hub & Plate Assembly 14.40
A30749-060-00 Insert & Spindle Assembly, Outer, 6 Pin 102.00
A30749-070-00 Insert & Spindle Assembly, Outer, 7 Pin 61.20
A30906-001-00 Spindle & Driver Assembly, IC 57.50
A30775-000-00 Door thickness 1-3/8" to 1-3/4" Door Shims 12.80
A30906-060-00 Spindle & Driver Assembly, 6 Pin 57.50
A30906-070-00 Spindle & Driver Assembly, 7 Pin
Q330-270 T Lock Spring Cage Kit (Inside for T411 and outside for all functions except T101, T291, T301) 41.30
Q330-271 T Lock Spring Cage Kit (Inside- all functions except T411 and inside & outside for T101, T291, T301)
030718-000-30 Key Spindle Assembly T501, T511 T521, T851, T881 STD and T381 Outside STD 4.80
030718-001-30 Key Spindle Assembly T501, T511 T521, T851, T881 IC and T381 Outside IC 4.80
A30913-000-00 Key Spindle Assembly T381 Inside STD 173.00
A30913-001-00 Key Spindle Assembly T381 Inside IC
A30780-000-00 Key Spindle Assembly T351, T561 STD 173.00
A30780-001-00 Key Spindle Assembly T351, T561 IC 173.00
A30915-000-00 Key Spindle Assembly T571 STD 83.50
A30915-001-00 Key Spindle Assembly T571 IC 81.90
030732-000-30 Key Spindle Assembly T581 STD 5.10
030732-001-30 Key Spindle Assembly T581 IC 5.10
T Series Cylindrical Grade 1 LOCKS
69
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
Chassis and Parts • T-Series
Screws
Part Number Description Finishes Size List Price
021164-016 ANSI strike screws 606, 613, 622, 626, 630 12-24 x 1" combo $0.58
024416-012 Latch and strike screws 606, 613, 622, 626, 630 8-32 x 3/4" combo 0.34
030755-005-30 Type D screw - 8-32 x 5/16" 0.44
030831-004-30 Set screw for standard lever - 1/4 x 20 x 1/4" 0.60
031515-004-30 Fillister Head Screw - 4-40 x 1/4" 2.30
031531-006-30 Set Screw for electrified screw - 1/4-20 x 3/8" 0.52
031533-006-30 Self Tap Screw - 8-32 x 3/8" 0.46
002770-016-30 Mounting Screws -10-32 x 1" 0.50
Chassis Assemblies
Part Number
Conventional
Cylinder IC Core Description List Price
A30761-000-00 T101 Chassis $87.00
A30765-000-00 T301 Chassis, T291 Chassis
150.00
A30758-000-00 A30758-001-00 T351/561 Chassis
A30769-000-00 A30769-001-00 T411 Chassis
A30773-000-00 A30773-001-00 T501 Chassis
A30756-000-00 A30756-001-00 T511 Chassis
A30748-000-00 A30748-001-00 T521 Chassis
A30760-000-00 A30760-001-00 T581 Chassis
A30767-000-00 A30767-001-00 T381 Chassis 284.00
A30759-000-00 A30759-001-00 T571 Chassis
A31517-000-00 A31517-001-00 T851 Chassis 811.00
A31518-000-00 A31518-001-00 T881 Chassis
T SeriesCylindricalGrade 1LOCKS
70
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
T-Series Notes
T Series Cylindrical Grade 1 LOCKS
71
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
Introduction X-Series
Finish Codes and Descriptions
Code Description
605 (US3) Bright Brass
606 (US4) Satin Brass
613 (US10B) Oil Rubbed Bronze
625 (US26) Bright Chrome
626 (US26D) Satin Chrome
630 (US32D) Satin Stainless
Standard Features - Furnished unless otherwise specified
Certification ANSI A156.2, Series 4000, Grade 1, UL Listed for 3-Hour fire door
Latch 1-1/8" x 2-1/4", Square corner faceplate, 1" housing diameter, 1/2" throw, 2-3/4" backset
Strike 1-1/4" x 4-7/8", ANSI, Square corner, no box
Cylinder 6-Pin, Solid brass, Keyed 5-Pin, Falcon G keyway, Keyed different (KD)
Door Range 1-3/8" - 2-1/8" standard
Keys Two, Nickel silver cut keys per lock, Falcon G keyway
Backset 2-3/4"
X SeriesCylindricalGrade 1LOCKS
Product Identification
X 501 P D
Latch Suffix
D = Deadlatch
S = Springlatch
Cylinder Suffix
B = Less SFIC
BB = With SFIC Core (Best)
BDC = Disp. Const. Core
G = With SFIC Core (Falcon)
H = With SFIC Keyed Const.
Core
L = Less 6-Pin Cylinder
P = 6-Pin Cylinder pinned
to 5 chambers
P6 = 6-Pin Cylinder pinned
to 6 chambers
P7 = 7-Pin Cylinder
to 7 chambers
CP6 = 6-Pin Cylinder
Schlage C
Function
See 72
Lock Series
SFIC = Small Format (Best® Style) Interchangeable Core
Table of Contents
Function Chart 72
Complete Lock Pricing 73
Options & Parts
Latches ................................................................................... 74-75
Strikes ..................................................................................... 74-75
Cylinders ....................................................................................... 76
Knobs .............................................................................................77
Roses ..............................................................................................77
Misc. Parts ..................................................................................... 77
Screws ............................................................................................ 77
Screw Packs .................................................................................77
Lock Less Components ............................................................ 78
Tactile Warning ..........................................................................78
Stainless Steel/Corros. Resist. Chassis ................................78
Non-Standard Door Thickness .............................................. 78
72
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
Key-In-Knob Locks
FALCON ANSI
X521 F81 Office Lock
Turn button locking. Turning button locks outside
knob requiring use of key until button is manually
unlocked. Inside knob always free.
X561 F84 Classroom Lock
Deadlocking latch bolt by knobs. Outside knob is
locked by key in outside knob. Inside knob is always
free.
X571 F90 Dormitory Lock
Deadlocking latch bolt by knobs except when locked
by push button in inside knob. Key in outside knob
locks or unlocks outside knob and releases button.
Closing door releases push button. Inside knob
always free.
X581 F86 Storeroom Lock
Deadlocking latch bolt by inside knob or key outside.
Outside knob rigid.
X12 Single Dummy Trim
Single Trim–Surface mounted.
ANSI A156.2 Series 4000 Grade 2
Key-In-Knob Locks
FALCON ANSI
X101 F75 Passage/Closet Latchset
Latch bolt by knobs at all times.
X301 F76 Privacy Lock
Latch bolt by knobs. Outside locked by push
button in inside knob. Rotating inside knob or
closing door releases push button. Emergency
release in outside knob. Emergency Release
Tool M504-271.
X411 F87 Asylum Lock*
Deadlocking latch bolt by key from either side.
Both knobs rigid.
X501 F82 Entry Lock
Push button locking. Button on inside locks
outside knob until unlocked by key or by
rotating inside knob.
X511 F109 Entry/Office Lock
Turn/push button locking. Pushing and
turning button locks outside knob requiring
use of key until button is manually unlocked.
Push button locking. Pushing button locks
outside knob until unlocked by key or by
turning inside knob.
X-Series • Functions
* Caution: Double cylinder locks on residences and any door, in any structure, which is used for egress are a life safety hazard
in times of emergency and their use is not recommended. Installation should be in accordance with existing codes only.
X Series Cylindrical Grade 1 LOCKS
73
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
Key-In-Knob • X -Series
Grade 1 Heavy Duty Cylindrical Locksets
ANSI-A156.2, SERIES 4000, GRADE 1
EG (Elite-Gala) HG (Hana-Gala)** TG (Troy-Gala)
EY (Elite-York) HY (Hana-York)** TY (Troy-York)
** Hana Knob not available in IC
Key-In-Knob
Function Description
Designs and Finishes
EG EY HG HY TG TY TG TY
626 605 606 613 625 630
Single Cylinder Functions
X501PD Entry
$660.00 $672.00 $672.00
X511PD Entry/Office
X521PD Entry/Office
X561PD Classroom
X571PD Dormitory
X581PD Storeroom
Double Cylinder Functions
X411PD Asylum 764.00 776.00 776.00
CAUTION: Double cylinder locks on residences and any door in any structure which is used for egress are a life safety hazard in times of emergency and their use is
not recommended. Installation should be in accordance with existing codes only.
Non-Keyed Functions
X101S Passage $474.00 $486.00 $486.00
X301S Privacy 584.00 596.00 596.00
X12 Single Dummy Trim 212.00 218.00 218.00
X SeriesCylindricalGrade 1LOCKS
74
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
X-Series • Latches and Strikes
Shaded items are standard components and are furnished with locks unless otherwise specified.
Note: 1) Marine non-ferrous mechanism latches can be ordered by adding "OSD" for Deadlatch or "OOS" for Springlatch
2) These latches conform to the standards set forth within ANSI/BHMA 156.2, 156.5, & 156.15 and are suitable for marine applications.
3) Marine latches have a $24.80 add to list price
Note: 1) Stainless steel applications can be substituted for the 2-3/4" backsets. Specify as "S" after part number (ex: 98535S)
* 2-3/8" backset is furnished as a 1" faceplate standard.
** Only available as a deadlatch.
Latches with Locks
Finishes 606, 613, 630
Backset Description Specify Add to Lock Price
2-3/4"
Square corner, 1 1/8" x 2-1/4", std. 98535 N/C
9/16" radius corner, 1-1/8" x 2-1/4" 98538
3/4" proj. square corner, 1-1/8" x 2-1/4" 98835S** $206.00
9/16" radius x 3/4" proj., 1-1/8" x 2-1/4" 98838S**
Square corner, 1" x 2 1/4" 92330 19.30
1/4" Radius round corner, 1" x 2-1/4" 92331
2-3/8"* Square corner, 1" x 2-1/4" 92320 19.30
1/4" Radius round corner, 1" x 2-1/4" 92321
5" Backset Link for 2-3/4" Backset Latch A22161-005-00 156.00
Strikes with Locks
Description Lip Length Specify Add to Lock Price
ANSI, 1-1/4" x 4-7/8" standard 1-3/16" 5164
N/C
Square corner, full lip 1-5/8" x 2-1/4" 1" 01-049
1/4" Radius round corner, full lip 1-5/8" x 2-1/4" 1" 01-048
Square Corner, T-strike, 1-1/8" x 2-3/4" 1-5/16" 5185
Vermin proof strike for ships, 9/16" radius 5133-4 $114.00
2 3/4" high T strike, ANSI A115.3 1 5183
N/C
2 3/4" high T strike, ANSI A115.3 9/16" 5185-4
2 3/4" high T strike, ANSI A115.3 1-9/16" 5186
2 3/4" high T strike, ANSI A115.3 1-13/16" 5187
2 3/4" high T strike, ANSI A115.3 2-1/16" 5188
2 3/4" high T strike, ANSI A115.3 2-5/16" 5189
ANSI dust box 1" deep, steel - 005099-000-30
Dust box, 1/2" deep, use with 2-3/4" strike - 012191-003-70
Dust box, 1/2" deep, stainless steel - 012191-000-60 N/C
ANSI, 1-1/4" x 4-7/8" 7/8" 5161 N/C
Latches sold separate
Finishes: 606, 613, 630
Backset
Latch Face 2-3/8" 2-3/4" List Price
1" Spring Latch A92320-000 A92330-000
$63.00
1" Deadlatch A92320-00D A92330-00D
1" Spring Latch – 1/4" Radius A92321-000 A92331-000
1" Deadlatch – 1/4" Radius A92321-00D A92331-00D
1-1/8" Spring Latch *
-
A98535-000
1-1/8" Deadlatch * A98535-00D
1-1/8" Spring Latch – 9/16" Radius * A98538-000
1-1/8" Deadlatch – 9/16" Radius * A98538-00D
1-1/8" Deadlatch – 3/4" Projection * A98835-0SD 237.00
1-1/8" Deadlatch – 9/16" Rad. X 3/4" Proj. * A98838-0SD
5" Backset Link for 2-3/4" Backset Latch A22161-005-00 106.00
X Series Cylindrical Grade 1 LOCKS
75
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
Latches and Strikes • X-Series
Strikes sold separate Finishes: 605, 606, 613, 625, 626, 629, 630
Description Lip Length Specify List Price
ANSI, 1-1/4" x 4-7/8" 1-3/16" 005164-000 $14.20
1/4" Radius round corner, full lip 1-5/8" x 2-1/4" 1" Q001-048
4.40Square corner, full lip 1-5/8" x 2-1/4" Q001-049
Square Corner, T-strike, 1-1/8" x 2-3/4" 1-1/8" A05185-000
2-3/4" high T strike, ANSI A115.3 9/16" A05185-004 29.90
2-3/4" high T strike, ANSI A115.3 1" A05183-000
2-3/4" high T strike, ANSI A115.3 1-9/16" A05183-004 50.10
A05186-000
2-3/4" high T strike, ANSI A115.3 1-13/16" A05187-000
55.902-3/4" high T strike, ANSI A115.3 2-1/16" A05188-000
2-3/4" high T strike, ANSI A115.3 2-5/16" A05189-000
Vermin proof strike for ships, 9/16" radius A05133-004-630 77.10
ANSI dust box 1" deep, steel - 005099-000-30 82.10
ANSI dust box 1" deep, stainless steel - 005099-000-60 3.30
Dust box, 1/2" deep, stainless steel 012191-000-60 10.40
Dust box, 1/2" deep, use with 2-3/4" strike 012191-003-70 6.30
ANSI, 1-1/4" x 4-7/8" 7/8" 005161-000 2.40
X SeriesCylindricalGrade 1LOCKS
76
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
X-Series • Cylinder Options
Notes: 1) Cylinders are furnished G keyway, keyed differently unless otherwise specified.
2) Finishes: 606 and 626 only.
3) Specify keyway
4) Restricted sections add $10.80 to list price. See page 8 for list of standard keyways.
All other keyways are considered restricted. Contact 877-671-7011 for availability.
* Keying must be specified
** Locks are assessed one non-refundable handling charge (50-231F) per core.
* Competitor keyways are furnished 0 bitted, unless otherwise specified. Not available Master keyed, except Schlage C.
KD option is not available for locks containing 2 cylinders.
Note: 5) Control keys are not furnished with locks and must be ordered separately. See page 151 for details
X-Series Complete Cylinders
Cylinder Mechanism Part Number Price Each
5 pin cylinder X411, 501, 511, 521, 581 E & T A23152
$56.00
5 pin cylinder X411, 501, 511, 521, 581 H A23152-02
5 pin cylinder X561 – E and T designs A23151
5 pin cylinder X561 – H designs, 571 – E & T A23151-02
5 pin cylinder X571 – H designs A23151-03
6 pin cylinder X411, 501, 511, 521, 581 E & T A23162
6 pin cylinder X411, 501, 511, 521, 581 H A23162-02
6 pin cylinder X561 – E and T designs A23161
6 pin cylinder X561 – H designs, 571 – E & T A23161-02
6 pin cylinder X571 – H designs A23161-03
7 pin cylinder X411, 501, 511, 521, 581 H A23172-02
71.007 pin cylinder X561 – H designs A23171-01
7 pin cylinder X571 – H designs A23171-02
Conventional Cylinder Options
Description Specify
Add to Lock
Price (per core)
5 pinned cylinder P Suffix
Example: X581P STD
6 pinned cylinder P6 Suffix
Example: X581P6 N/C
7 pinned cylinder P7 Suffix
Example: X581P7 $11.90
6 pinned Competitor keyway cylinders* P6 Suffix
Example: X581P6 (0 Bitted, KD, KA4 only)
Schlage C (6 pin only) CP6 Suffix
Example: X581CP6 (All other keying, not listed above) N/C
Small Format Interchangeable Core and Small Format Construction Core
Description Specify
Add to Lock
Price (per core)
Small format core * G Suffix
Example: X581GD $46.00
Small format core (Best Style) * BB Suffix
Example: X581BB
Small format construction core ** H Suffix
Example: X581HD 46.00
Less Small format core B Suffix
Example: X581BD N/C
Small format disposable core BDC Suffix
Example: X581BDC N/C
X Series Cylindrical Grade 1 LOCKS
77
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
Parts • X-Series
Note: 1) Hana and Elite not available in 630
Miscellaneous Parts
Part Number Description List Price
012138-000 Push button cap (X301/X501/X571) $2.80
012137-000 Turn button cap (X511/X521) 2.80
012136-000 Button mount For Elite & Troy knobs (X501/X521/X301/X511) 14.80
012236-000 Button mount For Elite & Troy knobs (X571) 14.80
012966-000 Button mount For Hana knobs (X501/X521/X301/X511) 14.80
012967-000 Button mount For Hana knobs (X571) 14.80
012172-000-30 X Lock Spanner Wrench 2.60
Note: Need to specify finish
Screws
Part Number Description Finishes Size List Price
024416-012 Latch and strike screws 606, 613, 626, 630 8-32 x 3/4" combo $0.34
021164-016 ANSI strike screws 606, 613, 626, 630 12-24 x 1" combo 0.58
Screws packs
Part Number Description Specify Finish Contents List price
A03519-000 Screw pack 605, 613, 626 024416-012 (2 ea) $3.60
Knobs
Part Number Description List Price
626 605 606 613 625 630
022258-007 Knob, Troy – Closed
$83.30 $86.30
022258-008 Knob, Troy – Emergency
022258-009 Knob, Troy – SFIC
022290-007 Knob, Troy – Button/Cylinder
022950-007 Knob, Hana – Closed
79.20 82.20022950-008 Knob, Hana – Emergency
022953-007 Knob, Hana – Button/Cylinder
022980-007 Knob, Elite – Closed
71.70 74.70
022980-008 Knob, Elite – Emergency
022980-009 Knob, Elite – SFIC
022981-007 Knob, Elite – Button/Cylinder
Roses
Part Number Description List Price
626 605 606 613 625 630
022920-000 Rose, Gala $31.50 $34.50
024030-000 Rose, York
X SeriesCylindricalGrade 1LOCKS
78
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
X-Series • Options
Note: 1) Outside lever only is coated unless otherwise specified
Locks Less Components
Description Specify Deduct from
Lock Price
Less each knob LLL for knob design
Example: X581PD LLL/EG $13.00
Less standard cylinder L suffix
Example: X581LD EG 56.00
Less latch LLL for latch
Example: X581PD EG 626 LLL/5164 55.70
Less strike LLL for strike
Example: X581PD EG 626 98535 LLL 13.30
Tactile Warning
Description Specify Add to
Lock Price
Abrasive - 6 Prefix (not available in 613) Preface the design code with 6
Example: 6EG for ELITE GALA $79.40
Knurled - 8 Prefix (not available in 630) Preface the design code with 8
Example: 8EG for ELITE GALA 144.00
Stainless Steel / Corrosion Resistant Chassis
Description Specify Add to
Lock Price
SS – Stainless steel/non-ferrous mechanism After the function code as “SS”
Example: X581 SS PD TG 630 $251.00
Non-Standard Door Thickness
Description Specify Add to
Lock Price
Door thickness over 2-1/8" - 2-1/4" Door thickness and how door is extended
Example: 2-1/4", EE $16.20
Note: 1) When ordering SS you will get the A98538 OSD Deadlatch standard.
X Series Cylindrical Grade 1 LOCKS
79
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
K-Series
Introduction
Finish Codes and Descriptions
Code Description
613 (US10B) Oil Rubbed Bronze
626 (US26D) Satin Chrome
Standard Features - Furnished unless otherwise specied
Certication ANSI A156.2, Series 4000, Grade 1, UL Listed for 3-Hour re door
Latch 1-1/8" x 2-1/4", Square corner faceplate, 1" housing diameter, 1/2" throw, 2-3/4" backset
Strike 1-1/4" x 4-7/8", ANSI, Square curved lip corner, no box
Cylinder 6-Pin, Solid brass, keyed 5-pin, Falcon G keyway, Keyed different (KD)
Door Range 1-3/8" - 2-1/4" standard, come set for a 1-3/4" thick door standard
Keys Two, Nickel silver cut keys per lock, Falcon G keyway
Product Identification
K 501 P D
Latch Suffix
D = Deadlatch
S = Springlatch
Cylinder Suffix
B = Less SFIC
BB = With SFIC Core (Best)
BDC = Disp. Const. Core
G = With SFIC Core (Falcon)
H = With SFIC Keyed Const.
Core
L = Less 6-Pin Cylinder
P = 6-Pin Cylinder pinned
to 5 chambers
P6 = 6-Pin Cylinder pinned
to 6 chambers
CP6 = 6-Pin Cylinder
Schlage C
Function
See 99
Lock Series
SFIC = Small Format (Best® Style) Interchangeable Core
Table of Contents
Function Charts 80
Levers ........................................................................................... 80
Complete Lock Pricing 81
Levers .............................................................................................81
Options 82
Conventional Cylinder Options .............................................. 82
Latches .........................................................................................83
Strikes ...........................................................................................83
Miscellaneous Parts ..................................................................84
K SeriesCylindricalGrade 1LOCKS
80
Price Book 8
Effective April 4, 2020 • Rev. 04/20
K Series Cylindrical Grade 1 LOCKS
K-Series • Lever Functions
Key-In-Lever Locks
FALCON ANSI &
Function
K561 F84 Classroom Lock
Deadlocking latch bolt by levers. Outside lever is
locked by key in outside lever. Inside lever is always
free.
K571 Corridor Lock
Deadlocking latch bolt. Push Button Locking. Button
on the inside locks outside lever until unlocked
by key or by rotating inside lever. Closing the door
releases button. Inside lever always free. Key will
lock and unlock from the outside.
K581 F86 Storeroom Lock
Deadlocking latch bolt by lever inside or key outside.
Outside lever is always locked. Inside lever is always
free.
K12 Dummy Trim
Single trim - surface mounted right lever
ANSI A156.2, Series 4000 Grade 1
Key-In-Lever Locks
FALCON ANSI &
Function
K101 F75 Passage Latchset
Latch bolt by levers at all times.
K301 F76 Privacy Lock
Latch bolt by levers. Outside lever is locked
by push button in inside lever. Rotating inside
lever or closing door release push button and
frees outside lever. Inside lever is always free.
Emergency release in outside lever unlocks
door.
K501 F82 Entry Lock
Push Button Locking. Button on the inside
locks outside lever until unlocked by key or by
rotating inside lever. Inside lever always free.
Deadlocking latch bolt.
K511 F109 Entry/Office Lock
Deadlocking latch bolt by levers. Turn/push
button locking. Pushing and turning button
locks outside lever, requiring use of a key for
unlocking the door until button is manually
unlocked. Pushing button locks outside lever
until unlocked by key or by rotating inside
lever. Inside lever is always free.
81
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
Levers Complete Locks • K-Series
Grade 1 Medium Duty Cylindrical Locksets
ANSI-A156.2, SERIES 4000, Grade1
D (Dane) Q (Quantum)
Key-In-Lever
Function Description
Designs and Finishes
A D Q
626 613
Single Cylinder Functions
K501PD Entry
$274.00 $286.00
K511PD Entry/Office
K561PD Classroom
K571PD Dormitory/Corridor
K581PD Storeroom
Non-Keyed Functions
K101S Passage $225.00 $237.00
K301S Privacy 252.00 264.00
Dummy Trim
K12 Half Dummy $115.00 $121.00
A (Avalon)
K SeriesCylindricalGrade 1LOCKS
82
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
K-Series Levers • Cylinder Options
* Competitor keyways are furnished 0 bitted.
Not available Master keyed, except Schlage C. KD option is not available for locks containing 2 cylinders.
Notes: 5) Finishes for Falcon keyway cylinders are 613 and 626 only.
6) Falcon cylinders are furnished G keyway unless otherwise specified.
7) Restricted sections See page 141. See Restricted Keyway Policy for standard keyway and policy on use
of restricted keyway cylinders. Contact 877-671-7011 for availability.
Note: 8) Control keys are not furnished with locks and must be ordered separately. See page 151 for details
Notes: 1) Finishes: 613 and 626 only
2) Specify keyway
3) Cylinders are furnished G keyway, keyed differently unless otherwise specified.
4) Restricted sections add $10.80 to list price. See page 8 for list of standard keyways.
All other keyways are considered restricted. Contact 877-671-7011 for availability.
* Keying must be specified
** Locks are assessed one non-refundable handling charge (50-231F) per core.
Conventional Cylinder Options
Description Specify
Add to Lock Price
(per core)
5 pinned cylinder P Suffix
Example: K581P STD
6 pinned cylinder P6 Suffix
Example: K581P6 N/C
6 pinned Competitor keyway cylinders* P6 Suffix
Example: K581P6 (0 Bitted, KD, KA4 only) $11.80
Schlage C (6 pin only) CP6 Suffix
Example: K581CP6 (All other keying, not listed above) N/C
Small Format Interchangeable Core and Small Format Construction Core
Description Specify
Add to Lock Price
(per core)
Small format core * G Suffix
Example: K581GD
$46.00
Small format core (Best Style) * BB Suffix
Example: K581BB
Small format construction core ** H Suffix
Example: K581HD
Less Small format core B Suffix
Example: K581BD N/C
Small format disposable core BDC Suffix
Example: K581BDC N/C
K-Series Complete Conventional Cylinders
Part Number
Cylinder Mechanism For All Other Functions For K571 Price Each
6 Pin Falcon keyway cylinder Q330-396 Q330-310
$56.00 6 Pin Schlage C keyway cylinder Q330-391 Q330-306
6 Pin to 5 Pin Falcon G keyway cylinder Q330-397 Q330-311
For other cylinders, see pages 141-146.
K Series Cylindrical Grade 1 LOCKS
83
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
Latch & Strike Options • K-Series
Note: 1) Specify finish when ordering.
Note: 1) Standard faceplate size is 2-1/4" x 1-1/8"
Latches with Locks
Backset Description
Specify
Add to Lock Price
Springlatch
101
Restoring
Springlatch
301
Deadlatch
501, 511,
561, 581
Restoring
Deadlatch
571
2-3/8" Square corner 30-267 30-271 30-301 30-386
N/C
Radius corner 30-269 30-273 30-275 30-388
2-3/4" Square corner 30-266 30-270 30-302 30-385
Radius corner 30-268 30-272 30-274 30-387
Latches as Parts Finishes: 613, 626
Backset Description
Specify
List Price
Springlatch
101
Restoring
Springlatch
301
Deadlatch
501, 511,
561, 581
Restoring
Deadlatch
571
2-3/8" Square corner Q630-267 Q630-271 Q630-301 Q630-386
$55.80
Radius corner Q630-269 Q630-273 Q630-275 Q630-388
2-3/4" Square corner Q630-266 Q630-270 Q630-302 Q630-385
Radius corner Q630-268 Q630-272 Q630-274 Q630-387
Strikes with Locks
Description Lip Length Specify Add to Lock Price
ANSI, 1-1/4" x 4-7/8" standard 1-3/8" 30-148
N/C
Square Corner, T-Strike 1-1/8" x 2-3/4" 1-3/8" 30-149
Radius Corner, Full Lip Strike 1-5/8" x 2-1/4" 1" 30-150
Square Corner, Full Lip Strike 1-5/8" x 2-1/4" 1" 30-151
Strikes as Parts Finishes: 613, 626
Description Lip Length Specify List Price
ANSI, 1-1/4" x 4-7/8" standard 1-3/8" Q330-148
$11.00
Square Corner, T-strike, 1-1/8" x 2-3/4" 1-3/8" Q330-149
Radius Corner, Full Lip Strike 1-5/8" x 2-1/4" 1" Q330-150
Square Corner, Full Lip Strike 1-5/8" x 2-1/4" 1" Q330-151
K SeriesCylindricalGrade 1LOCKS
84
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
K-Series • Misc. Parts & Options
Locks Less Components
Description Specify
Deduct from
Lock Price
Less standard (conventional) cylinder L Suffix
Example: K581LD DAN $21.00
Less latch LLL Suffix
Example: K581PD6 DAN 626 LLL 30-148 16.50
Less strike LLL Suffix
Example: K581GD7 DAN 626 30-206 LLL 5.50
Screws
Part Number Description Finishes List Price
Q630-254 Screw Pack 613, 626 $5.80
Q330-399 Screw Pack — Dummy Trim – 4.10
Miscellaneous Parts
Part Number Description List Price
Q330-393 Conventional Falcon G Cylinder tailpiece (K501, 511, 581, 561)
$4.00
Q330-394 Conventional Falcon G Cylinder tailpiece (K571)
Q630-312 Conventional Schlage C cylinder tailpiece (K501, 511, 581, 561)
Q630-288 Conventional Schlage C cylinder tailpiece (K571)
Q630-289 SFIC Tailpiece (K501, 511, 581, 561)
Q330-392 SFIC Tailpiece (K571)
Q630-246 Inside Spring Cage Kit 57.00
Q630-279 2-1/4" x 1-1/8" Faceplate, deadlatch, round corner
6.30
Q630-278 2-1/4" x 1-1/8" Faceplate, deadlatch, square corner
Q630-277 2-1/4" x 1-1/8" Faceplate, springlatch, round corner
Q630-276 2-1/4" x 1-1/8" Faceplate, springlatch, square corner
K Series Cylindrical Grade 1 LOCKS
85
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
D100-Series
Finish Codes and Descriptions
Code Description
605 (US3) Bright Brass
606 (US4) Satin Brass
613 (US10B) Oil Rubbed Bronze
625 (US26) Bright Chrome
626 (US26D) Satin Chrome
Standard Features - Furnished unless otherwise specified
Certification BHMA - ANSI A156.5, 2001, Grade 1 auxiliary lock, Available UL Listed for 3-Hour fire door
Deadbolt 1-1/8" x 2-1/4", Square corner faceplate, 1" housing diameter, 1" throw
Strike 1-1/8" x 2-3/4", lipless, with box
Cylinder 6-Pin, Solid brass, Keyed 5-Pin, Falcon G keyway, Keyed different (KD)
Door Range 1-3/8" - 1 7/8" standard cylinder and thumbturn only; 1-5/8" - 2-1/4" interchangeable core cylinder
Keys Two, Nickel silver cut keys per lock, Falcon G keyway
Reinforcement Metal dust box reinforcer with three - 3" screws
Trim Ring 1" Wrought brass or bronze, reinforced with security insert
Backset 2-3/8" and 2-3/4" adjustable
Introduction
Product Identification
D 111 P F
Latch Suffix
F = UL Listed
Cylinder Suffix
B = Less SFIC
BDC = SFIC Construction Core
(refundable)
BB = SFIC- 6 Pin BEST capping
G = SFIC (Falcon)
H = SFIC Construction Core
(refundable)
L = Less Conventional, 6 Pin
P = Conventional, 6 Pin/Keyed 5
P6 = Conventional, 6 Pin
P7 = Conventional, 7 Pin
Function
See 81
Lock Series
SFIC = Small Format (Best® Style) Interchangeable Core
Table of Contents
Function Charts 87
Complete Lock Pricing 88
Options
Deadbolts ....................................................................................89
Strikes ...........................................................................................89
Small Format Interchangeable Cores ..................................90
Small Format Construction Cores ........................................90
Lock Less Components .............................................................91
Conventional Cylinder Options ............................................... 91
Parts
Trim ................................................................................................ 92
Deadbolts ....................................................................................92
Strikes ...........................................................................................93
Adapters .......................................................................................93
Screws ...........................................................................................94
Screw Packs ................................................................................94
D100 SeriesDeadboltGrade 1LOCKS
86
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
D141 / 241
D131 / 231
D111 / 211
D121 / 221
2 ³⁄₄
Mounting screws
Mounting screws
Faceplate
Anti-pry shield
UL rated
firecup
Mounting screws
Rose
Rose
Rose
Mounting screws
Mounting screws
Mounting
screws
Trim ring
Steel mounting plate
Dust box
Strike
Steel mounting
plate
Steel mounting
plate
Deadbolt
Trim ring
Cylinder
D100 Series
GRADE 1 DEADBOLT
D100 Series Deadbolt Grade 1 LOCKS
87
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
Functions • D100-Series
BHMA / ANSI A156.5, 2001, Grade 1
Bored Deadbolt Locks
FALCON ANSI
D111P E0171 Classroom Function
Deadbolt thrown or retracted by key from outside.
Inside turn will only retract bolt. Bolt automatically
deadlocks when fully thrown.
D121P E0161 Single Cylinder x Rose
Deadbolt thrown or retracted by key only. Blank
plate inside. Bolt automatically deadlocks when
fully thrown.
D131P E0141 Double Cylinder
Deadbolt thrown or retracted by key from either
side. Bolt automatically deadlocks when fully
thrown.
D141P E0151 Single Cylinder x Turn
Deadbolt thrown or retracted by key or by turn.
Bolt automatically deadlocks when fully thrown.
D151 Turn x Turn
Deadbolt thrown or retracted by turn unit from
either side. Application for shelters. Bolt
automatically deadlocks when fully thrown.
D100 SeriesDeadboltGrade 1LOCKS
88
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
D100 Series • Levers and Parts
Outside Cylinder Trim Inside Cylinder Trim Rose and Turn
Notes: 1) Split finishes are priced at the highest finish price.
2) Keying options: See page 8
3) ‘F’ suffix must be added for UL product.
D-100 Series
Function Description
Designs and Finishes
626 605 606 613 625
Single Cylinder Functions
D111P Classroom Function $147.00 $153.00
D121P Single Cylinder x Blank Rose 130.00 136.00
D141P Single Cylinder x Turn
Double Cylinder Functions
CAUTION: Double cylinder locks on residences and any door in any structure which is used for egress are a life safety hazard in
times of emergency and their use is not recommended. Installation should be in accordance with existing codes only.
D131P Cylinder x Cylinder $168.00 $174.00
Non-Keyed Functions
D151 Turn x Turn $108.00 $114.00
D100 Series Deadbolt Grade 1 LOCKS
89
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
Shaded items are standard components and are furnished with locks unless otherwise specified.
Square Corner 1/4" Radius Drive-In
10-094 10-087 10-095 10-092
Deadbolts with Locks
Backset Description HSG Dia Specify
Add to
Lock Price
2-3/8" or
2-3/4"
Square corner, 1-1/8" x 2-1/4", standard
1"
30-256
N/C
Square corner, 1" x 2-1/4" 30-176
1/4" Radius round corner, 1" x 2-1/4" 30-178
Circular, Drive-In bolt, 626 only 30-257
For UL Listed Locks
2-3/8" or
2-3/4" UL
Square corner, 1-1/8" x 2-1/4", standard
1"
30-174
N/CSquare corner, 1" x 2-1/4" 30-172
Circular, Drive-In bolt, 626 only 30-259
Strikes with Locks
Description Lip Length Specify Add to Lock Price
Drive-In thimble strike, 1-3/16" dia. 1" 10-064 N/C
ANSI, 1-1/4" x 4-7/8", with box 1-1/8" 10-087 $8.90
Full Lip, 1/4" radius corner, 1-5/8" x 2-1/4", no box 1-5/16" 10-092
N/C
Square Corner with metal dust box, 1-1/8" x 2-3/4", standard
–
10-094
Full Lip, square corner, 1-5/8" x 2-1/4", no box 10-095
1-1/8" square corner and strike 5075
Options • D100 Series
D100 SeriesDeadboltGrade 1LOCKS
90
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
Small Format
Interchangeable Core
* Keying must be specified
** Locks are assessed one non-refundable handling charge (50-231F) per core.
Notes: 1) Split finishes are priced at the highest finish price.
2) Key section must be specified and applicable charges for restricted sections will be applied. See page 141.
3) Control keys are not furnished with locks and must be ordered separately. See page 151 for details
Small Format Interchangeable Core and Small Format Construction Core
Description Specify
Add to Lock Price
(per core)
Small format core * G Suffix
Example: D111GD $46.00
Small format core (Best Style) * BB Suffix
Example: D111BB
Small format construction core ** H Suffix
Example: D111HD 46.00
Less Small format core B Suffix
Example: D111BD N/C
Small format disposable core BDC Suffix
Example: D111BDC N/C
D100 Series • Options
D100 Series Deadbolt Grade 1 LOCKS
91
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
Conventional Cylinders and Lock Less Components Options • D100 Series
* Specify specific competitor keyway on order. Competitor keyways are furnished 0 bitted, unless otherwise specified.
Not available Master keyed, except Schlage C. KD option is not available for locks containing 2 cylinders.
Notes: 1) Finishes: 606 and 626 only
2) Specify keyway
3) Cylinders are furnished G keyway, keyed differently unless otherwise specified.
4) Restricted sections add $10.80 to list price. See page 8 for list of standard keyways.
All other keyways are considered restricted. Contact 877-671-7011 for availability.
Lock Less Components
Description Specify
Deduct from
Lock Price
Less deadbolt LLL for latch
Example: D211P 605 30-171 LLL $11.30
Less strike LLL for strike
Example: D211L 3.60
Less conventional cylinder L suffix
Example: D211L 19.80
Less conventional cylinder D131 L suffix
Example: D131L 37.30
Conventional Cylinder Options
Description Specify
Add to Lock Price
(per core)
5 pinned cylinder P Suffix
Example: D111P STD
6 pinned cylinder P6 Suffix
Example: D111P6 N/C
7 pinned cylinder
(Not available on D131)
P7 Suffix
Example: D111P7 $11.90
6 pinned Competitor keyway cylinders* P6 Suffix
Example: D111P6 (0 Bitted, KD, KA4 only) N/C
D100-Series Complete Conventional Cylinders
Cylinder Mechanism Part Number Price Each
5 Pin Cylinder - D111, D141 Q500-064
$56.00
5 Pin Cylinder - D121 Q500-066
5 Pin Cylinder - D131 Q500-070
6 Pin Cylinder - D111, D141 Q500-021
6 Pin Cylinder - D121 Q500-058
6 Pin Cylinder - D131 Q500-054
7 Pin Cylinder - D111, D141 Q500-046 71.00
7 Pin Cylinder - D121 Q500-059
D100 SeriesDeadboltGrade 1LOCKS
92
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
D100 Series • Parts
Rose and Turn Mounting Plate Rose
Note: 1) For trim rings and inserts see Cylinders: D100
Square Corner 1/4" Radius Drive-In
Trim
Part Number Specify Finish Description Price Each
B302-041 • Rose and Turn $45.80
B302-045 • Rose and Turn (D111) 45.80
12-626 • Blank Rose (D121) 26.10
B600-018 • Mounting plate for rose and rose & turn 10.60
Deadbolts
Part Number Specify Finish Housing Diameter Description Price Each
Q330-256 •
2-3/8" or 2- 3/4"
Universal
Square corner, 1-1/8" x 2-1/4" faceplate
$16.70
Q330-176 • Square corner, 1" x 2-1/4" faceplate
Q330-178 • 1/4" radius corner, 1" x 2-1/4" faceplate
Q330-257 626 1" circular drive-in, 626 only
D100 Series Deadbolt Grade 1 LOCKS
93
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
Parts • D100 Series
38-031 B520-649 B520-650
10-064 10-087 10-092 10-094 10-095
Strikes
Part Number Specify
Finish Description Lip Length Price
Each
10-064 • Drive-In, thimble strike, 1-3/16" deep - $17.20
10-087 • ANSI, 1-1/4" x 4-7/8, with box 1-1/8" 23.60
10-094 • Square corner with metal dust box, 1-1/8" x 2-3/4" - 12.60
10-092 • Full lip, 1/4" radius corner, 1-5/8" x 2-1/4", no box
1-5/16" 7.10
10-095 • Full lip, square corner, 1-5/8" x 2-1/4", no box 8.10
J250-028 2" strike mounting screws 2.10
5075 • Security Strike -9.90
Adapters
Part Number Specify
Finish Description Price Each
(per finish)
605 606
613 625 626
38-031 • 2-1/2" diameter adapter ring for 2-1/8" door prep, for under cylinder $19.60
B520-649 • Trim ring w/shield for D131/D141 24.20
B520-650 • Trim ring w/shield for IC functions 24.20
36-071 • 1-3/8" IC Core thin door shim kit, contains 36-066 & 36-068 15.00
Strikes , Adapters
D100 SeriesDeadboltGrade 1LOCKS
94
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
D100 Series • Parts
Screw Packs
Part
Number
Specify
Finish Door Thickness Contents Price
Each
Keyed, Single Conventional Cylinder
61-500 • 1 3/8" – 1 3/4" (1) B600-018
(2) B600-100
(2) B600-066
(4) C603-897
$15.00
61-501 • over 1 3/4" – 2 1/4" (1) B600-018
(2) B600-101
(2) B600-066
(4) C603-897
15.00
Keyed, Single SFIC Cylinder
61-500 • 1 3/8" – 2" (1) B600-018
(2) B600-100
(2) B600-066
(4) C603-897
$15.00
Keyed, Double Conventional Cylinder
61-502 • 1 3/8" – 1 3/4" (2) B600-047
(4) C603-897 $11.40
61-503 • over 1 3/4" – 2 1/4" (2) B600-078
(4) C603-897 11.40
Keyed, Double SFIC Cylinder
61-507 • 1 3/8" – 2" (2) B600-053
(4) C603-897 $11.40
Screws
Part
Number
Specify
Finish
Description Application Price Each
(Order in
multiples
of 100)Size Type Use Door Thickness
Keyed, Single Conventional Cylinder
B600-100 1/4"-28 x 1-15/16" POH mach. Mounting 1-3/8" - 1-3/4"
$2.50 B600-101 1/4"-28 x 2.425" POH mach. Mounting over 1-3/4"
B600-066 • 6-32 x 1/4" PH mach. Turn -
B520-298 10-32 x 3/8" PH mach. Anti-pry shield - 0.80
Keyed, Single SFIC Cylinder
B600-100 1/4"-28 x 1-15/16" POH mach. Mounting 1-3/8" - 2-1/4" 2.50
B600-066 • 6-32 x 1/4" PH mach. Turn -
Keyed, Double Conventional Cylinder
B600-047 1/4"-28 x 3-13/16" PH mach. Mounting 1-3/8" - 1-3/4" 2.50
B600-078 1/4"-28 x 3-29/64" PH mach. Mounting over 1-3/4"
B520-298 10-32 x 3/8" PH mach. Anti-pry shield - 0.80
Keyed, Double SFIC Cylinder
B600-053 1/4"-28 x 3-61/64" PH mach. Mounting 1-3/4" - 2-1/4" 2.50
B520-298 10-32 x 3/8" PH mach. Anti-pry shield -0.80
All Functions
C603-897 • #8 x 3/4" PFH combo Deadbolt & strike - 0.92
J250-028 #8 x 2" PFH wood 2" strike screw -2.10
R525-256 #12 x 3" PFH wood 3" metal dust box -
Screws
D100 Series Deadbolt Grade 1 LOCKS
95
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
Introduction B-Series
Finish Codes and Descriptions
Code Description
605 (US3) Bright Brass
606 (US4) Satin Brass
613 (US10B) Oil Rubbed Bronze
625 (US26) Bright Chrome
626 (US26D) Satin Chrome
Standard Features - Furnished unless otherwise specified
Certification ANSI A156.2, Series 4000, Grade 2, UL Listed for 3-Hour fire door
Latch 1-1/8" x 2-1/4", Square corner faceplate, 1" housing diameter, 1/2" throw, 2-3/4" backset
Strike 1-1/4" x 4-7/8", ANSI, Square corner, no box
Cylinder 6-Pin, Solid brass, Keyed 5-Pin, Falcon G keyway, Keyed different (KD)
Door Range 1-3/8" - 2" standard (exceptions for communicating locks - see pg 98)
Keys Two, Nickel silver cut keys per lock, Falcon G keyway
Product Identification
B 501 P D
Latch Suffix
D = Deadlatch
S = Springlatch
Cylinder Suffix
B = Less SFIC
BDC = Disp. Const. Core
BB = With SFIC Core (Best)
G = With SFIC Core (Falcon)
H = With SFIC Keyed Const.
Core
L = Less 6-Pin Cylinder
P = 6-Pin Cylinder pinned
to 5 chambers
P6 = 6-Pin Cylinder pinned
to 6 chambers
CP6 = 6-Pin Cylinder
Schlage C
Function
See 97
Lock Series
SFIC = Small Format (Best® Style) Interchangeable Core
Table of Contents
Functions 97
Complete Lock Pricing 98
Options
Conventional Clyinder Options ..............................................99
Small Format Interchangeable Cores .................................. 99
Small Format Construction Cores ........................................99
Latches .......................................................................................100
Strikes .........................................................................................100
Lock Less Components ........................................................... 101
Tactile Warnging Strip (not available in 613)................... 101
Parts
Levers ........................................................................................... 101
Roses ............................................................................................ 101
Chassis Assemblies .................................................................. 101
Screws ......................................................................................... 102
Misc. Parts .................................................................................. 102
B SeriesCylindricalGrade 2LOCKS
96
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
B Series
GRADE 2 CYLINDRICAL LOCK
Outside lever
Cylinder
Plastic insert
Plastic insert
Spring cage
Lock chassis
Inner mounting plate
Inside lever
Outside rose
Inside rose
Deadlatch
Mounting screw
B Series Cylindrical Grade 2 LOCKS
97
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
ANSI A156.2 Series 4000 Grade 2
Key-In-Lever Locks Key-In-Lever Locks
FALCON ANSI FALCON ANSI
B101 F75 Passage/Closet Latchset
Latch bolt by levers at all times.
B561 F84 Classroom Lock
Deadlocking latch bolt by levers. Outside lever
is locked by key in outside lever. Inside lever is
always unlocked for immediate egress.
B161 F111 Communicating Passage Lock
Deadlocking latch bolt by inside lever.
Non-removable blank plate outside.
B581 F86 Store Room
Deadlocking latch bolt by lever inside or key
outside. Outside lever is always locked. Inside
lever is always unlocked for immediate egress.
B301 F76 Privacy/Bedroom/Bath Lock
Latch bolt by levers. Outside lever
locked by push button in inside lever.
Rotating inside lever or closing door
releases push button. Emergency
release in outside lever unlocks door.
B611 F90 Dormitory/Corridor Lock
Deadlocking latch bolt by levers except when
locked by push button on inside lever. Key in
outside lever locks or unlocks outside lever
and releases button. Closing door releases push
button. Inside lever is always free.
B341 F112 Communicating Store Room Lock
Deadlocking latch bolt by inside lever
except when locked by key.
Non-removable blank plate on opposite
side of lever (11/16" projection).
B12 Dummy Trim
Single Trim-surface mounted rigid lever.
B501 F82 Entry Lock
Push button locking. Button on inside
locks outside lever until unlocked by key
or by rotating inside lever. Inside lever
always free. Deadlocking latch bolt.
B511 F109 Entry/Office Lock
Turn/push button locking. Pushing and
turning button locks outside lever
requiring use of key until button is
manually unlocked. Push button
locking. Pushing button locks outside
lever until unlocked by key or by
rotating inside lever. Inside lever always
free. Deadlocking latch bolt.
Functions • B-Series
Grade 2 Standard Duty Cylindrical Locksets
ANSI-A156.2, SERIES 4000, GRADE 2
B SeriesCylindricalGrade 2LOCKS
98
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
Grade 2 Standard Duty Cylindrical Locksets
ANSI-A156.2, SERIES 4000, GRADE 2
B-Series • Complete Locks
D (Dane) Q (Quantum)
Key-In-Lever
Designs and Finishes
D Q
Function Description 626 605 606 613 625
Single Cylinder Functions
B341PD* Connecting/Exit
$215.00 $227.00
B501PD Entry
B511PD Entry/Office
B561PD Classroom
B581PD Storeroom
B611PD Dormitory/Corridor 243.00 255.00
Non-Keyed Functions
B101S Passage $155.00 $167.00
B161D* Communicating Latch
B301S Privacy 179.00 191.00
Dummy Trim
B12 Half Dummy $70.00 $76.00
* The B161 and B341 need to be specified as shown for correct door ranges: 138 for ( 1-3/8"- 1-5/8") or 134 for (>1-5/8"-2")
B Series Cylindrical Grade 2 LOCKS
99
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
Cylinder Options • B-Series
* Specify specific competitor keyway on order. Competitor keyways are furnished 0 bitted, unless otherwise specified.
Not available Master keyed, except Schlage C. KD option is not available for locks containing 2 cylinders.
Notes: 1) Finishes: 606 and 626 only.
2) Specify keyway.
3) Cylinders are furnished G keyway, keyed differently unless otherwise specified.
4) Restricted sections add $10.80 to list price. See page 8 for list of standard keyways.
All other keyways are considered restricted. Contact 877-671-7011 for availability.
*Keying must be specified.
** Locks are assessed one non-refundable handling charge (50-231F) per core.
Note: 5) Control keys are not furnished with locks and must be ordered separately. See page 151 for details
Conventional Cylinder Options
Description Specify Add to Lock Price
(per core)
5 pinned cylinder P Suffix
Example: B581P STD
6 pinned cylinder P6 Suffix
Example: B581P6
N/C6 pinned Competitor keyway cylinders* P6 Suffix
Example: B581P6 (0 Bitted, KD, KA4 only)
Schlage C (6 pin only) CP6 Suffix
Example: B581CP6 (All other keying, not listed above)
Small Format Interchangeable Core and Small Format Construction Core
Description Specify Add to Lock Price
(per core)
Small format core * G Suffix
Example: B581GD $46.00
Small format core (Best Style) * BB Suffix
Example: B581BB
Small format construction core ** H Suffix
Example: B581HD 46.00
Less Small format core B Suffix
Example: B581BD N/C
Small format disposable core BDC Suffix
Example: B581BDC N/C
B-Series Complete Conventional Cylinders
Cylinder Mechanism Part Number Price
Each
5 Pin Cylinder A23155-02
$56.00
5 Pin Cylinder - B611 A23151-06
6 Pin Cylinder A23165-02
6 Pin Cylinder - B611 A23161-06
B SeriesCylindricalGrade 2LOCKS
100
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
B-Series • Latch and Strike Options
Shaded items are standard components and are furnished with locks unless otherwise specified.
Latches with Locks
Backset Description
Specify
Add to Lock Price
Springlatch/Deadlatch
301/611
2-3/4"
Square corner, 1-1/8" x 2-1/4", standard 57435 57635
N/CSquare corner, 1" x 2-1/4" 57430 57630
1/4" Radius round corner, 1" x 2-1/4" 57431 57631
2-3/8" **
Square corner, 1" x 2-1/4" 57420 57620
N/CSquare corner, 1-1/8" 57425 57625
1/4" Radius round corner, 1" x 2-1/4" 57421 57621
5" Backset extension link A31727-005-00 * $39.80
Strikes with Locks
Description Lip Length Specify Add to Lock Price
ANSI, 1-1/4" x 4-7/8" standard 1-3/16" 5164 N/C
Square Corner, full lip 1-5/8" x 2-1/4" 1" 01-049 N/C
1/4" Radius round corner, full lip 1-5/8" x 2-1/4" 1" 01-048 N/C
Square Corner, T-strike, 1-1/8" x 2-3/4" 1-5/16" 01-046 N/C
ANSI dust box 1" deep, steel - 005099-000-30 N/C
ANSI, 1-1/4" x 4-7/8" 7/8" 5161 N/C
Strikes sold separate
Finishes: 605, 606, 613, 626, 630 (ANSI only)
Description Lip Length Specify List Price
Square Corner, T-strike, 1-1/8" x 2-3/4" 1-1/8" Q001-046
1/4" Radius round corner, full lip 1-5/8" x 2-1/4" 1" Q001-048 $4.40
Square corner, full lip 1-5/8" x 2-1/4" Q001-049
ANSI, 1-1/4" x 4-7/8" standard 1-3/16" 005164-000 14.20
ANSI dust box 1" deep, steel - 005099-000-30 3.30
ANSI, 1-1/4" x 4-7/8" 7/8" 005161-000 23.90
Latches sold separate
Finishes: 605, 613, 630
Latch Face Backset & Price
2-3/8" 2-3/4" Price
1" Spring Latch (101) A57420-000 A57430-000
$29.20
1" Spring Latch (301) A57620-000 A57630-000
1" Spring Latch - 1⁄4" Rad. (101) A57421-000 A57431-000
1" Spring Latch - 1⁄4" Rad. (301) A57621-000 A57631-000
1" Deadlatch A57420-00D A57430-00D
1" Deadlatch (611) A57620-00D A57630-00D
1" Deadlatch - 1⁄4" Rad. A57421-00D A57431-00D
1" Deadlatch - 1⁄4" Rad. (611) A57621-00D A57631-00D
1-1⁄8" Spring Latch (101) A57425-000 A57435-000
1-1⁄8" Spring Latch (301) A57625-000 A57635-000
1-1⁄8" Deadlatch A57425-00D A57435-00D
1-1⁄8" Deadlatch (611) A57625-00D A57635-00D
* Backset extension link A31727-005-00 must be used with 2-3/8" backset latches
** 2-3/8" backset is furnished as a 1" faceplate standard.
B Series Cylindrical Grade 2 LOCKS
101
Price Book 8
Effective April 4, 2020 • Rev. 04/20
Prices subject to change without notice
Trim and Chassis Options • B-Series
Notes: 1) Outside lever only has abrasive strip adhered to the back surface of the lever.
2) B581 Storeroom function locks should be used on doors requiring tactile warning of danger.
3) Abrasive strip not available in 613 finish.
Note: 4) Chassis provided with trim finish on B341 and B611.
Lock Less Components
Description Specify Deduct from
Lock Price
Less standard cylinder L suffix
Example: B581LD DAN $54.00
Less latch LLL for latch
Example: B581PD DAN 626 LLL 5164 13.70
Less strike LLL for strike
Example: B581PD DAN 626 57435 LLL 10.40
Tactile Warning (abrasive strip)
Description Specify Add to
Lock Price
Abrasive Strip Preface the design code with 6
Example: 6DA for DAN $50.20
Levers
Part Number Description
List Price
605, 606, 613,
625, 626
A31750-000 Lever, Dane closed
$43.10
A31751-000 Lever, Quantum closed
A31750-001 Lever, Dane open
A31751-001 Lever, Quantum open
031700-002 Lever, Dane IC
031701-002 Lever, Quantum IC
B Series Chassis Assemblies
Part Number
Description Price
Conventional
Cylinder IC Core
A31706-000-00 B101 Chassis $125.00
A31707-000-00 B161 Chassis – 1-5/8" – 2" Door Thickness
A31707-002-00 B161 Chassis – 1-3/8" – 1-5/8" Door Thickness 125.00
A31709-000-00 A31709-001-00 B301/501 Chassis 151.00
A31714-000-00 A31714-001-00 B511 Chassis
A31715-000-00 A31715-001-00 B561 Chassis 203.00
A31716-000-00 A31716-001-00 B581 Chassis
151.00A31708-000 A31708-001 B341 Chassis – >1-5/8" – 2" Door Thickness
A31708-002 A31708-003 B341 Chassis – 1-3/8" – 1-5/8" Door Thickness
A31739-000 A31739-001 B611 Chassis 227.00
Roses
Part Number Description
List Price
605, 606, 613,
625, 626
031702-000 Rose, Outer
$17.30 031703-000
