Feitian Technologies FTEPASSFIDOK13 ePass FIDO User Manual ePass FIDO K13 PRODUCT MANUAL
Feitian Technologies Co., Ltd. ePass FIDO ePass FIDO K13 PRODUCT MANUAL
Users Manual
ePass FIDO K13 PRODUCT MANUAL
© 1998-2015, FEITIAN Technologies Co., Ltd. All Rights Reserved.
Website: www.FTsafe.com
ii
Content
1. Overview............................................................................................................................................................. 1
2. Product Views..................................................................................................................................................... 2
a) Casing Views...................................................................................................................................................2
b) Casing Introduction........................................................................................................................................2
3. Specification........................................................................................................................................................3
ePass FIDO K13 PRODUCT MANUAL
© 1998-2015, FEITIAN Technologies Co., Ltd. All Rights Reserved.
Website: www.FTsafe.com
1
1. Overview
Feitian FIDO K13 is a FIDO alliance certified U2F security key. Feitian FIDO K13 is a Top Gear in the Feitian FIDO
U2F Security Key family. NFC, BLE and USB, K13 employees three interfaces for conducting communications with
authenticating devices. Users are allowed to use any of these interfaces to complete the FIDO U2F registration and
verification. FIDO K13 brings the most stable and compatible experiences to the users.
ePass FIDO K13 PRODUCT MANUAL
© 1998-2015, FEITIAN Technologies Co., Ltd. All Rights Reserved.
Website: www.FTsafe.com
2
2. Product Views
a) Casing Views
b) Casing Introduction
1BLE indicator. This LED indicator lights up while the key is in pairing mode.
2
Authentication indicator. Any authentication request received will be passed while this LED is
on.
3
Control button. Short press to power on. Long press for 5 seconds for entering pairing mode.
4Battery indicator.
1
2
3
4
440620
ePass FIDO K13 PRODUCT MANUAL
© 1998-2015, FEITIAN Technologies Co., Ltd. All Rights Reserved.
Website: www.FTsafe.com
4
2. Request authentication from the client device.
3. Attach the key to the NFC sensor.
* Using FIDO U2F with NFC mode on mobile devices requires middle ware. Using Chrome browser and Google
authenticator is a good example.
3.2.3 USB mode
1. Connect the authenticator with your client PC by using the attached USB cable.
2. The authentication indicator will blink when an authentication request is received.
3. Press the button to confirm this authentication.
e P a s s FIDOK13P R O D U C T MANUAL
©1998-2015, FEITIAN Technologies C o . , Ltd. All Rights Reserved.
We b s i t e :w w w . F T s a f e . c o m
5
4.Specification
ePass FIDOK 1 3
Specification
V a l u e
O S
Windows, Linux, O S X
Certifications
FIDOU 2 F
Embedded security algorithm
ECDSA, SHA256
Size
47.29mm*29.32mm*8.34mm
M a x number ofkeys
N o limit
Interface type
USB, N F C (Receiving),Bluetooth
D a t a storage life
At least10years
Erasing times
100,000 times
Communication protocol
H I D
Workingvoltage
5.0V (USB)
Workingcurrent
22mA (USB)
Power
0.11W(USB)
Workingtemperature
-10℃－+50
℃
Storage temperature
-20℃－+70℃
Button Physical type; Green, red and blue LEDlights
C a s e Material ABS
