GUITAR AMPLIFIERS

MUSTANG BY FENDER ®

™

ADVANCED OWNER'S MANUAL

MUSTANG™ III/IV/V

Advanced Manual

Introduction

This manual is your step-by-step guide to the advanced

features found on your Mustang™ III / IV / V amplifier. Turn to

page 8 for the Mustang I / II advanced manual. For information

on using Fender® FUSE™, Ableton® Live or Amplitube®, please

see the separate manuals for each product available at www.

fender.com/support.

Navigation

There are just a few basics of Mustang navigation that you

should know before you explore any further...

Selecting Presets

Turn the DATA WHEEL to select one of 100 presets.

You will find some presets you like and others that you want

to change...

Each preset stores the settings for:

• Amplifier type — 12 selections

• Effects — 4 categories, 37 selections total

• Knob levels — GAIN through REVERB (not MASTER)

♫ You can select and edit presets from your computer

using Fender® FUSE™ software, available free at www.

fender.com/support

Master Volume

The MASTER volume knob is always "active." That means the

position of the MASTER knob always shows the true master

volume setting, unlike the programmable knobs.

(Always turn the MASTER volume knob first to adjust the

overall volume output of your Mustang amplifier.)

Programmable Knobs

Because the setting of every knob (except MASTER) is part of

each preset, the "programmable" knobs are not active and

the knob positions will NOT show their actual settings when a

preset is first selected.

     

How do I activate a programmable knob? The moment you

turn any programmable knob it instantly becomes active and

it will remain active until you select a different preset, at which

time all the programmable knobs become inactive again.



   

Press the DATA WHEEL to see what the preset settings are for

all the programmable knobs before you turn them. Press EXIT

to return to Play mode.

Press the DATA WHEEL a second time to see where your

effects are located in the Guitar Signal Processing Path. Press

EXIT to return to Play mode.

♫ You can change the order of effects in the Signal Path

using Fender® FUSE™ software.

Preset contents are displayed

on screen for each preset

DATA

WHEEL

MASTER volume is

always

active

PROGRAMMABLE knobs are not active unless turned

Turn any PROGRAMMABLE knob to activate it

To view preset knob settings, push the DATA WHEEL

To view the Signal Path, push the DATA WHEEL twice.

x2

2fender.com

MUSTANG™ III/IV/V

Amplifier Menus

Select amplifier models and adjust amplifier settings using

the Amp menus.

Amplifier Models

To select Amplifier Models:

1. Press the AMP button.

2. Turn the DATA WHEEL to select one of 12 amplifier models:

AMP MODELS

'57 Deluxe

'59 Bassman

'57 Champ

'65 Deluxe Reverb

'65 Princeton

'65 Twin Reverb

Super-Sonic (Burn)

British '60s

British '70s

British '80s

American '90s

Metal 2000

3. Press EXIT to return to Play mode.

Amplifier Settings

To adjust Amplifier Settings:

1. Press the AMP button.

2. Press the DATA WHEEL one or more times until the setting

that you want to adjust is highlighted, then turn the DATA

WHEEL to adjust the setting.

3. Press the AMP button a second time to access "Page 2" with

more amplifier settings. The settings that appear on "Page2"

depend on the amp model that is currently selected.

♫ You can de-select the highlighted amp setting and

return to Amp Model selection mode, as a shortcut, by

pressing and holding the AMP button.

4. Press EXIT to return to Play mode.

Effect Menus

Bypassing Effects

You can turn on–off effects that have been selected for the

current preset by pressing the corresponding effect button.

♫ Effects can also be bypassed (turned on-off) from the

footswitch included with your Mustang amplifier.

Effects that are shown on screen as "–EMPTY–" can not be

activated until an effect has been selected in that slot.

Selecting Effects

• — Stompbox effects

• — Modulation effects

• — Delay effects

• — Reverb effects

To select Effects:

1. Press and hold one of the four effects buttons.

2. Turn the DATA WHEEL to select one of the following

effects:

STOMPBOX MODULATION

Overdrive Sine Chorus

Fixed Wah Triangle Chorus

Touch Wah Sine Flanger

Fuzz Triangle Flanger

Fuzz Touch Wah Vibratone

Simple Compressor Vintage Tremolo

Compressor Sine Tremolo

Ring Modulator

Step Filter

Phaser

Pitch Shifter

"PAGE 2" of the Amp menus

The Effect name is highlighted

and the Effect button lights up

when an effect is active

Press the DATA WHEEL repeatedly

to select the next Amp setting

3

fender.com

MUSTANG™ III/IV/V

Effects tables continued from previous page...

DELAY REVERB

Mono Delay Small Hall

Mono Echo Filter Large Hall

Stereo Echo Filter Small Room

Multitap Delay Large Room

Ping Pong Delay Small Plate

Ducking Delay Large Plate

Reverse Delay Ambient

Tape Delay Arena

Stereo Tape Delay Fender '63 Spring

Fender '65 Spring

3. Press EXIT to return to Play mode.

♫ You can switch to a different effect category at any time,

even while you are in the effect selection menus, by

pressing and holding a different Effects button.

Effect Settings

Use the Effects Settings menus to adjust a dazzling array of

effect settings.

To adjust Effect Settings:

1. Press and hold any Effect button (STOMP, MOD, DELAY,

REVERB).

2. Turn the DATA WHEEL to select the effect you want to

work with.

3. Press the DATA WHEEL one or more times until the setting

that you want to adjust is highlighted, then turn the DATA

WHEEL to adjust the setting.

4. Press EXIT to return to Play mode.

♫ You can bypass an effect at any time, even while you

are in the effect settings menus, by pressing the Effect

buttons or corresponding footswitch buttons.

Tap Button

The TAP button can be used to "tap in" delay time and

modulation rate settings, by rhythmically pressing the TAP

button.

When you select a delay effect, the TAP button will blink

in time with the delay time setting. When you select a

modulation effect, the TAP button will blink in time with

the modulation rate setting (note that modulation rates can

have up to 12 second intervals and the TAP button will flash

infrequently).

When both delay and modulation effects are selected

simultaneously, the TAP button will blink in time with the

delay effect and will only control the delay time setting.

♫ You can use the Effects menus or Fender FUSE to set

delay time and modulation rates more precisely.

To set the TAP interval of effects:

1. Select a Delay or Modulation effect that causes the TAP

button to blink, using the Effects menus (see Selecting

Effects, page 3).

2. Press the TAP button rhythmically (twice minimum) in time

with the desired interval. If you press the TAP button only

once, the interval will be set to the maximum.

♫ If you open the Effect settings menu (see Effect Settings,

above), you can watch the actual TAP values you are

setting while you are tapping them in!

Saving Presets

Your Mustang™ amplifier gives you the powerful ability to

save every setting on the amplifier as part of a preset. When

you select a preset, the level of each knob, every effect

setting, and the amp model selection, are instantly recalled to

your pre-programmed settings.

The SAVE button will light up red when you turn

any programmable knob or edit any other setting

on the amp. This indicates that you have temporarily modified

the preset. You can undo your modifications by turning the

DATA WHEEL to a different preset and then back again.

♫ The EXIT button will not cancel changes to the current

preset. Only by selecting a different preset using the

DATA WHEEL, Footswitch, or Fender FUSE, will your

temporary changes be erased.

To save a preset:

1. To save a preset you should first modify an existing preset,

for example, by turning any of the programmable knobs,

such as GAIN.

Press the DATA WHEEL repeatedly

to select the next Effect setting

4fender.com

MUSTANG™ III/IV/V

2. Press the SAVE button. The SAVE and EXIT buttons should

be illuminated. You can press EXIT at this point to cancel

the save process.

3. Turn the DATA WHEEL select a preset destination to

overwrite.

4. Press the DATA WHEEL if you want to edit the name of

your new preset. Use the buttons to perform the functions

listed along the bottom of the screen; turn the DATA

WHEEL to select characters.

5. Press the SAVE button a second time to confirm the save.

♫ Memory Lock must be OFF to save presets (see Utility

Menus, page 6)

Guitar Tuner

Your Mustang™ amplifier has a built-in Tuner mode that turns

the screen into a guitar tuner.

To use the Tuner:

1. Press and hold the TAP button. The TAP and EXIT buttons

will illuminate.

2. Strike any single string on your guitar and watch the

screen. The the note of the string being tuned is displayed

along with a fine tuning needle

3. Turn the tuning peg on your guitar until the fine tuning

needle indicates the string is in tune, as shown above.

4. Standard guitar tuning is as follows:

5. Press EXIT or TAP to exit from the Tuner.

Footswitches

Four-Button Footswitch (0080996000)

Connect a 4-button footswitch to your Mustang amplifier

(included with the Mustang IV & V, optional equipment for

the Mustang III) to enable remote multi-function foot con-

trol. The footswitch display and LEDs show you some of the

same information as the amplifier screen, so you can, for

example, tune your guitar and select presets by watching the

footswitch without ever looking at the screen onboard the

Mustang!

• Select Quick Access presets (QA1/QA2/QA3)

• Select presets (up/down/bank)

• Bypass effects

• Activate the Tuner

The footswitch has three modes that are identified by the

three LEDs labeled MODE 1, MODE 2 and MODE 3. The

footswitch also has a Tuner mode which is indicated when all

of the mode LEDs are off.

To switch between modes, press the MODE button. To acti-

vate Tuner mode, press and hold the MODE button.

Mode 1—In Mode 1 the footswitch is used to select one of

three Quick Access presets, using the buttons labeled: QA1 /

QA2 / QA3 (in line with the MODE 1 LED). When you select a

Quick Access preset, the number of the preset will appear in

the display of the footswitch.

♫ You can any assign any preset to be a Quick Access

preset in the Utility menus. (see Utility Menus, page 6).

Mode 2—In Mode 2 the footswitch is used to select presets

down/up, or in banks of 10, using the buttons labeled: DOWN

/ UP / BANK (in line with the MODE2 LED). When you select a

preset, the number of the preset will appear in the display of

the footswitch.

Mode 3—In Mode 3 the footswitch is used to bypass the

Stompbox, Modulation or Delay effects, using the buttons

labeled: STOMP / MOD / DELAY (in line with the MODE 3

LED). The footswitch button LEDs indicate the effects that are

active, just like the buttons on the amplifier.

Mode indicators

"In tune"

5

fender.com

MUSTANG™ III/IV/V

♫ You can also have a footswitch button assigned to

bypass the Reverb effect by adding on the 2-button

Mustang footswitch (see Six-Button Footswitching

options, below).

Tuner Mode—Press and hold the MODE button to activate

the Tuner. The screen and the footswitch both will display the

same tuner information so that you can look in either place to

tune your guitar. The footswitch will display the nearest note;

the button LEDs will indicate sharp and flat and "in tune" is

indicated when the green LED below the footswitch display

lights up.

Press any footswitch button to exit Tuner mode.

Two-Button Footswitch (0080997000)

Connect a 2-button footswitch to your Mustang amplifier

(included with the Mustang III, optional equipment for the

Mustang IV & V) to enable remote multi-function foot control.

Use the Utility menus to assign one of the following functions

to the 2-button footswitch:

• Select presets (up/down)

• Select Quick Access presets (QA1/QA2)

• Bypass effects (various combinations)

• Set TAP interval

Six-Button Footswitching options

Plug both a 4-button and a 2-button footswitch into your

Mustang amplifier to expand your remote control options.

By assigning different functions to each footswitch you can

create more than a dozen different foot control combinations.

For example, you could assign Quick Access presets to the

4-button footswitch and Up/Down presets to the 2-button

footswitch. Or you could bypass effects with the 4-button

footswitch and select presets with the 2-button footswitch.

The choice is up to you.

Utility Menus

Press the UTIL button to activate the Utility menus.

Press the UTIL button repeatedly to step through

each of the seven menus.

Quick Access #1 / #2 / #3 — Use the first three Utility menus

to choose Quick Access presets. You can then access those

presets quickly from the footswitches (see Footswitches,

above).

Two-Button Footswitch Mode — Use this menu to assign

functions to the two-button footswitch.

Memory Lock — Use the Memory Lock menu to prevent

accidental preset modifications. You will still be able to make

temporary changes to presets with Memory Lock ON, but you

won't be able to save those changes until Memory Lock is

switched OFF.

LCD Contrast — Use this menu to adjust the contrast of the

Mustang display.

About This Amp — This menu displays the Firmware version

currently running on the amplifier. Use this information to

determine if an update is available for your amplifier.

Speaker Outputs

Mustang V, only

The Mustang V head amplifier provides stereo speaker

outputs that must both be connected to a stereo speaker

cabinet such as the Mustang V 412, with four 12" Celestion®

G12P Rocket 50 speakers (recommended), or two 8Ω speaker

cabinets capable of handling 75W each.

Aux / Phones Jacks

Auxiliary Input

You can use the Auxiliary jack to input audio into your

Mustang amplifier for accompaniment. Connect the

headphone output on your CD player or MP3 player to the

AUX jack using a mini-stereo cable. Use the volume control

6fender.com

MUSTANG™ III/IV/V

on your player, together with the MASTER volume knob, to

adjust the auxiliary volume level.

Phones Jack

Plug in your headphones, ear buds, or powered

speakers to enjoy the Mustang's stereo features. This

jack may also be used as a stereo recording output. The amp's

speaker is muted when the PHONES jack is used.

Effects Loop

Connect external effects devices to your Mustang amplifier

using the effects loop jacks.

The Mustang IV & V amplifiers can accept stereo or mono

effects devices. Note that a mono-in, mono-out effect unit

will use one send and one return, and only effect one side

of the stereo image. The Mustang III amplifier only accepts

mono effects devices.

Connect the FX SEND jack(s) to the input(s) on your external

effects device and connect the FX RETURN jack(s) to the

output(s) on your effects device.

USB Port

Use the USB port to connect the Mustang™ amplifier to

your computer and take your music to the next level:

• Use Fender® FUSE™ software to control your Mustang

from your computer and access bonus amp features not

available from the Mustang alone.

♫ Please see the Fender FUSE manual at www.fender.

com/support for details.

• Record and edit Mustang audio using Ableton® Live Lite 8

Fender® Edition software.

♫ Please see the Ableton® Live Lite 8 Fender edition at

www.fender.com/support for details.

• Stream live audio and play with people around the

world using Fender® BAND JAM, powered by eJamming®

AUDiiO.

♫ For a 30-day trial subscription, log on to: www.fender.

com/ejamming

Factory Restore &

Firmware Update

Factory Restore

You can restore your Mustang amplifier to the original factory

settings if desired. All user presets will be erased!

To restore the Mustang amplifier to factory settings:

1. Turn the amplifier OFF.

2. Press and hold the EXIT button while turning the amplifier

ON. Continue holding the EXIT button until it is no longer

illuminated.

! The FACTORY RESTORE function will erase all user

modified presets. It will also restore any effect selections

that have been modified using Fender FUSE software.

Firmware Update

From time to time, Fender may make available firmware

updates for your Mustang amplifier to improve operation

or to add new features. To update the firmware on your

amplifier you will need to connect it through the USB port

to a computer with Fender FUSE software and an internet

connection.

♫ Please see the Fender FUSE manual at www.fender.

com/support for details.

FAQ

There are several great places you can go to learn more about

your Mustang and music in general:

• www.fender.com/support

• Join a Fender Community forum where you can ask

questions and read threads. There's even a forum just for

the Mustang: www.fender.com/community/forums

• Log on to the Fender Knowledge Base to download and

read "Frequently Asked Questions" (FAQ): www.fender.

com/support/faqs.php

• Find music theory learning materials and sheet music at

Hal Leonard Publications: www.halleonard.com

Mustang IIIMustang IV & V

7

fender.com

Advanced Manual

Introduction

This manual is your step-by-step guide to all the advanced

features found on your Mustang™ I / II amplifier. For

information on using Fender® FUSE™, Ableton® Live or

Amplitube®, please see the separate manuals for each product

available at www.fender.com/support.

Navigation

There are just a few basics of Mustang navigation that you

should know before you explore any further...

Selecting Presets

The most powerful feature of your Mustang amplifier is its

ability to store every amplifier setting and effect selection as a

preset that you can instantly recall using the PRESET knob, or

remotely from your computer or footswitch.

Use the PRESET knob to select one of 24 presets. Presets are

stored in three banks, colored AMBER, GREEN and RED.

Turn the PRESET knob to scroll through each bank of presets

in the following order:

Each preset is based on one of the eight amplifier types

labeled next to each of the preset LEDs. That gives you a total

of three presets for each amplifier type.

♫

The

RED

and

GREEN

banks are for creating your

own presets. The

AMBER

bank of presets can only be

modified using Fender FUSE software available free at

www.fender.com/support

.

Each preset includes the settings of all the programmable

knobs on the Mustang, which includes every knob except the

MASTER volume and PRESET knobs.

Programmable Knobs

Because the setting of every knob on the Mustang amplifier

(except MASTER) is part of each preset, all programmable

knobs are normally inactive and knob positions will NOT

show their actual settings when a preset is first selected.

     

How do I activate a programmable knob? The moment you

turn any programmable knob it instantly becomes active

and it will remain active until you select a different preset, at

which time it becomes inactive again.

    

You may hear a big change in volume or tone when you

first turn a programmable knob if there happened to be a

large difference between the knob's starting position and

the stored preset setting. For example, if the VOLUME knob

is pointing to "8" but the stored preset VOLUME setting is

"2," the volume level will jump from "2" to "8" when you start

turning the VOLUME knob because the VOLUME knob is now

instantly active at "8."

♫ The only way to know what the preset setting of a knob

is before you turn it, is by using Fender FUSE software

and connecting the Mustang to your computer.

Effects

There are two effect selection knobs on the Mustang:

• MOD — selects Modulation type effects

• DLY / REV — selects Delay and Reverb type effects

♫ You can also select effects from a STOMPBOX category

using Fender FUSE software.

The MOD and DLY / REV knobs share the same three selection

indicator LEDs. The knob turned last has control of these LEDs:

Programmable knob positions are inactive unless turned

Rotate knobs to activate their positions

AMBER Bank

( Factory presets )

GREEN Bank

( User presets )

RED Bank

( User presets )

8

MUSTANG™ I / II

fender.com

These LEDs are numbered 1, 2, 3 and correspond to the three

positions within each of the selection ranges A, B, C, D on

each knob. Use the LEDs to determine exactly which position

the knob is pointing to, for example, A 1 is shown below:

Effect Selections

The tables below list the effect selections for each knob.

MODULATION EFFECTS

A1 Chorus

A2 Chorus Deep

A3 Flanger

B1 Bias/Sine Tremolo

B2 Optical/Vintage Tremolo

B3 Optical/Vintage Tremolo Fast

C1 Vibratone Slow

C2 Vibratone Fast

C3 Octaver

D1 Phaser Slow Deep

D2 Phaser Medium

D3 Step Filter

DELAY EFFECTS REVERB EFFECTS

A1 Tape Delay 150ms / 1 Repeat

A2

Stereo Tape Delay 300ms / 3 Repeats

A3

Mono Delay 700ms / 4 Repeats

B1 Small Room Reverb

B2 Plate Reverb

B3 Large Hall Reverb

C1 Fender '65 Spring Reverb

C2 Fender '63 Spring Reverb

C3 Tape Delay Room

D1 Tape Delay Large Hall

D2 Ducking Delay Small Hall

D3 Echo Filter

♫ You can completely change the effects list on your

Mustang™ amplifier using Fender® FUSE™ software

available at www.fender.com/support.

Effects Level

You can adjust the effects level by holding down the EXIT

button while rotating either the MOD or DLY/REV knob,

depending on which effect type you want to adjust.

Tap Button

The TAP button can be used to "tap in" delay time and

modulation rate settings:

• Delay time — TAP button blinks green:

• Modulation rate — TAP button blinks red:

When you select a delay effect, the TAP button will blink

green in time with the delay time setting. When you select a

modulation effect, the TAP button will blink red in time with

the modulation rate setting.

When both delay and modulation effects are selected

simultaneously, the TAP button will blink green and only

control the delay time setting.

♫ You can use TAP to set both delay time and modulation

rate by tapping in the modulation rate first, with NO

delay effect selected, then adding a delay effect and

tapping in the delay time last.

To set the TAP interval of effects:

1. Select an effect that causes the TAP button to blink, using

the DLY/REV or MOD knob.

2. Press the TAP button rhythmically (twice minimum) in time

with the desired interval.

These LEDs are linked to the

knob that is being turned

9

MUSTANG™ I / II

fender.com

Tuner Button

Your Mustang™ amplifier has a built-in Tuner mode that turns

the control panel LEDs into a chromatic guitar tuner.

To use the tuner:

1. Press and hold the TAP button for 2 seconds. The TAP and

EXIT buttons will illuminate.

2. Strike any single string on your guitar and watch the panel

LEDs. The Preset LEDs are used to indicate the note of the

string being tuned (the top LED "#" indicates if the note is

sharp).

3. Turn the tuning peg on your guitar until the fine tuning

LEDs above the MOD knob indicate the string is in tune, as

shown above.

4. Standard guitar tuning is as follows:

5. Press EXIT or TAP to exit from the Tuner.

Save Button

Your Mustang amplifier gives you the powerful

ability to save every setting on the amplifier as

part of a preset. When you select a preset, the level of each

knob, including effect selections, is instantly recalled to your

pre-programmed settings!

The SAVE button will light up red when you turn any

programmable knob on the amplifier. This indicates that you

have temporarily modified the preset. You can reset your

modifications simply by selecting a different preset and then

back again.

♫ The EXIT button will not cancel changes to the current

preset. Only by selecting a different preset using the

PRESET knob will your temporary changes be erased.

To save a preset:

1. To save a preset you must first modify an existing preset

by turning any of the programmable knobs, such as GAIN

or MOD. (once the SAVE button is illuminated, you can

proceed to step 2).

2. Press the SAVE button. The SAVE and EXIT buttons should

be flashing rapidly. You can press EXIT at this point to

cancel the save process.

3. Turn the PRESET knob to select a preset to overwrite.

You can only overwrite the red and green banks of the

amplifier type that you started from (if you started by

modifying the amber bank, you must select either the red

or green bank to overwrite).

♫ You can modify the AMBER bank of presets by using

your computer and Fender® FUSE™ software available

at www.fender.com/support.

Aux / Phones Jacks

Auxiliary Input

You can use the Auxiliary jack to input audio into your

Mustang amplifier for accompaniment. Connect the

headphone output on your CD player or MP3 player to the

AUX jack using a mini-stereo cable. Use the volume control

on your player, together with the MASTER volume knob, to

adjust the auxiliary volume level.

Phones Jack

Plug in your headphones, ear buds, or powered speakers to

enjoy the Mustang's stereo features. This jack may also be

used as a stereo recording output. The amp's internal speaker

is muted when the PHONES jack is used.

Letters next to LEDs indicate the note being tuned

3 LEDs indicate fine tuning. GREEN means "in tune"

10

MUSTANG™ I / II

fender.com

Footswitch

Connect a (optional) 1-button footswitch (P/N 0994049000)

into the FTSW jack to enable remote selection of your two

favorite presets. The LED (next to the FTSW jack) will turn red

or green to indicate which footswitch preset is active.

To program the footswitch:

1. Select a preset that you want to assign to the footswitch.

The preset must not be modified (the SAVE button must

NOT be illuminated to proceed to step 2).

2. Press the SAVE button. The SAVE and EXIT buttons should

be flashing rapidly. You can press EXIT at this point to

cancel the footswitch assignment process.

3. Press the footswitch button to select either the red or

green LED next to the FTSW jack to associate with the

chosen preset.

4. Press the SAVE button to confirm the footswitch

assignment. Now when you press the footswitch, the

chosen preset will be activated with the assigned red or

green footswitch indicator.

USB Port

Use the USB port to connect the Mustang™ amplifier to your

computer and take your music to the next level:

• Use Fender® FUSE™ software to control your Mustang

from your computer and access bonus amp features not

available from the Mustang alone.

♫ Please see the Fender FUSE manual at www.fender.

com/support for details.

• Record and edit Mustang audio using Ableton® Live Lite 8

Fender® Edition software.

♫ Please see the Ableton® Live Lite 8 Fender edition at

www.fender.com/support for details.

• Stream live audio and play with people around the

world using Fender® BAND JAM, powered by eJamming®

AUDiiO.

♫ For a 30-day trial subscription, log on to: www.fender.

com/ejamming

Factory Restore &

Firmware Update

Factory Restore

You can restore your Mustang amplifier to the original factory

settings if desired. All user presets will be erased!

To restore the Mustang amplifier to factory settings:

1. Turn the amplifier OFF.

2. Press and hold the EXIT button while turning the amplifier

ON. Continue holding the EXIT button until it is no longer

illuminated.

! The FACTORY RESTORE function will erase all user

modified presets. It will also restore the AMBER bank

of presets and any effect selections that have been

modified using Fender FUSE software.

Firmware Update

From time to time, Fender may make available firmware

updates for your Mustang amplifier to improve operation

or to add new features. To update the firmware on your

amplifier you will need to connect it through the USB port

to a computer with Fender FUSE software and an internet

connection.

♫ Please see the Fender FUSE manual at www.fender.

com/support for details.

FAQ

There are several great places you can go to learn more about

the Mustang and music in general:

• www.fender.com/support

• Join a Fender Community forum where you can ask

questions and read threads. There's even a forum just for

the Mustang: www.fender.com/community/forums

• Log on to the Fender Knowledge Base to download and

read "Frequently Asked Questions" (FAQ): www.fender.

com/support/faqs.php

• Find music theory learning materials and sheet music at

Hal Leonard Publications: www.halleonard.com

11

MUSTANG™ I / II

fender.com

This product is covered by one or more of the following patents:

US Pat. 6,222,110

AMPLIFICADOR DE AUDIO

IMPORTADO POR: Instrumentos Musicales Fender S.A. de C.V., Calle Huerta # 132, Col. Carlos Pacheco, C.P. 228890, Ensenada, Baja California, Mexico.

RFC: IMF870506R5A Hecho en China. Servicio de Cliente: 001-8665045875

A PRODUCT OF:

FENDER MUSICAL INSTRUMENTS CORPORATION

CORONA, CALIFORNIA, USA

Fender®, Mustang™ and Fender® FUSE™ are trademarks of FMIC.

Other trademarks are property of their respective owners.

Copyright © 2010 FMIC. All rights reserved. P/N 824CGP006 (ENGLISH) rev a

有毒有害物质或元素

(Hazardous Substances’ Name)

部件部件名称

(Part Name) 铅

(PB)

汞

(Hg)

镉

(Cd)

六价铬

(Cr6+)

多溴联苯

(PBB)

多溴二苯醚

(PBDE)

部分电子元件 x o o o o o

部分机器加工金属部件 x o o o o o

部分其他附属部件 x o o o o o

O: 表示该有毒有害物质在该部件所有均质材料中的含量均在 SJ/T 11363-2006 规定的现量要求以下

X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T 11363-2006 规定的现量要求
