www.firstchoicebuildingproducts.com
Phone (800) 793-4544 • Fax (800) 867-5016
3600
GRADE 1 Listed –
ANSI/BHMA 156.3
UL File #SN2590 for UL305
Panic Hardware
Suitable for Narrow
Stile Doors
Standard Door Widths
36”, 42”, 48”
DIMENSIONS
• 21
/2” Push Bar Height
• 3” Projection
• 405
/8” Centerline Height Typical
• Center Case Cover -
6-5/8” Tall by 1-1/4” Wide
SPECIFICATIONS
• Exit device shall be 3600 series concealed vertical
rod device as manufactured by First Choice
Building Products, Inc.
• Exit device shall have Ul file #: SA12590 for
UL305 and be grade 1 listed under national
standard ANSI/BHMA 156.3.
• Exit device shall be a narrow style model utilizing
low profile touch bar projecting 3” from face of door.
• Exit device shall use 3/8” steel vertical rods with
steel latch bolts engaging stainless steel strike to
lock at two points in the opening.
• Exit device shall be non-handed.
• Exit device shall have the following
upgrades available:
3Electric latch retraction (rated for continuous all
day retraction.)
3Signal switch providing the ability to monitor of
the push bar position and to provide a n.o./n.c.
trigger to any new or existing system.
3 Alarm control providing audible notification of
unauthorized egress of the exit device.
3 Interior cylinder dogging providing interior 1/4
turn dogging of the device through the use of a
standard type rim cylinder.
3Exit device shall be field sizable.
S E R I E S
CONCEALED
VERTICAL ROD
EXIT DEVICE
3600 Series is available with
Motor Driven Electronic Latch Retraction
* Devices approved for Blast and Impact are part
of the complete entrance system as provided by the
door manufacturer. Consult your door supplier
for approved models.
1”
6 5/8”
2 ½”
1 7⁄8”
www.firstchoicebuildingproducts.com
Phone (800) 793-4544 • Fax (800) 867-5016 5/15
3600
S E R I E S
APPLICATIONS
• Schools
• Convention Centers
• Office Buildings
• Churches
• Retail Spaces, Etc.
DOOR/ or OTHER SIZES
• 30” to 48” Standard
• Custom Sizes Available
• Door Heights up to 9’
• Door Stiles Widths as Narrow as 2”
PRODUCT MATERIALS
• Anodized Aluminum Push Bar and Channel
• Die Cast Aluminum End Caps
• Stainless Steel Strikes
• Steel Latch Bolts
• 3/8” Steel Vertical Rods
PRODUCT WARRANTY
First Choice warrants that the products manufac-
tured by us will be free of defects in material and
workmanship for a period of two years from date
of invoice.
Motorized Electric Latch Retraction
MEL is available on First Choice model 3690 vertical rod devices.
These devices are equipped with a 4vDC motor suitable for high traffic
conditions and capable of extended periods of activation.
Your Answer for Exit Alarm Requirements
The AL36 Series alarm kits are designed to fit inside the push bars of the
Model 360 CVR exit device. The mechanism is designed for the rigorous
requirements of exit hardware.
A powerful alarm emits a piercing (105 db) notification of unauthorized
egress to protect persons and property. Automatic resetting means the
door will remain protected at all times.
The sophisticated circuitry of the AL36 provides up to 12 months of
standby power of 100 alarm cycles from a standard 9v battery. Battery
monitoring is constant and a low charge signal is provided to make it
easy to maintain.
Interior Cylinder Dogging
The CD36 cylinder dogging function is available for the model 3600 CVR
exit device and eliminates the need for special hex keys to put the device
into hold open mode.
The CD36 accepts standard Rim Type key cylinders which can be
changed in the field. Just a quarter turn by key and the exit device is
dogged open for unrestricted access.
ACCESSORIES
Series L3 Levers
Utilizing a unique gear system these levers will operate with the 3600 CVR device
and are available in anondized finishes.
Manual levers can be set for both Hold Back or a High Latch. All levers are designed
for most common mortise cylinders. A security collar is included.
The electric model levers are low voltage and can be operated by remote devices
such as card readers, code key devices and remote mounted switches.
Power requirements are 24v DC with easy hook up at the lever.
Thumb-turn
cylinders are
also available for
keyless dogging.
