First Computer AQUAPAD02 Aquapad Wireless Tablet Computer User Manual AquaPAD UM 0530
First International Computer Inc Aquapad Wireless Tablet Computer AquaPAD UM 0530
Revised Manual
Web Pad
USERS MANUAL
Model
AquaPAD+
First International Computer, Inc.
ii
Copyright
Copyright © FIC (First International Computer). Corporation 2005. All rights reserved.
Disclaimer: FIC Corporation shall not be liable for technical or editorial errors or omissions contained herein; nor for
incidental or consequential damages resulting from furnishing this material, or the performance or use this product.
FIC Corporation reserves the right to change product specification without notice. Information in/of this document
may change without notice.
No part of this document may be copied, reproduced, or transmitted by any means, for any purpose without prior
written permission from FIC Corporation.
I
In
nf
fo
or
rm
ma
at
ti
io
on
n
t
to
o
U
Us
se
er
r
USA - Federal Communications Commission (FCC)
This device complies with Part 15 of FCC Rules. Operation of the devices in a Wireless LAN
System is subject to the following two conditions:
• This device may not cause harmful interference.
• This device must accept any interference that may cause undesired operation.
E
Ex
xp
po
os
su
ur
re
e
t
to
o
R
Ra
ad
di
io
o
F
Fr
re
eq
qu
ue
en
nc
cy
y
R
Ra
ad
di
ia
at
ti
io
on
n
The radiated output power of the Wireless module is far below the FCC radio frequency
exposure limits. Nevertheless, the Wireless module shall be used in such a manner that the
potential for human contact during normal operation is minimized.
The transmitter and the antenna are permanently installed inside the Web Pad, and are
specific for this model (not for generic device). For compliance with FCC radiation exposure
limits.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These.limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: To assure continued compliance, any changes or modifications not expressly
approved by the party responsible for compliance could void the user's authority to operate
this equipment (example - use only shielded interface cables when connecting to computer or
peripheral devices).
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
IMPORTANT NOTE:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment.
End users must follow the specific operation instruction for satisfying RF exposure compliance.
Canada - Industry Canada (IC)
• This device complies with RSS 210 of Industry Canada.
iv
Safety Instructions
The AQUAPAD+ has been tested for conformance to international safety regulations. Like any electronic device,
however, the AQUAPAD+ should be used with care. To protect yourself from possible injury and to minimize the
risk of damage to the AQUAPAD+, read and follow the safety instructions in this preface.
General Guidelines
? ? Read all of these instructions.
? ? Save these instructions for future use.
? ? Follow all warnings and instructions marked on the AQUAPAD+.
? ? Except as explained elsewhere in this manual, do not attempt to service the AQUAPAD+ yourself. Opening or
removing covers that are marked “Do Not Remove” might expose you to dangerous voltage points or other risks.
Refer all servicing of marked components to qualified personnel.
Installation Restrictions
1. Follow all warnings and instructions marked on the product.
2. Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning.
3. Do not use this product near water, for example, near a bathtub, washbowl, kitchen sink or laundry tub, in a wet
basement or near a swimming pool.
4. Do not place this product on an unstable cart, stand, or table. The product may fall, causing serious damage to
the product or harm to individuals.
5. Avoid using a telephone (other than a cordless type) during an electrical storm. There may be remote risk of
electric shock from lightning.
6. Do not use the telephone to report a gas leak in the vicinity of the leak.
7. Slots and openings in the cabinet and the back or bottom are provided for ventilation; to ensure reliable
operation of the product and to protect it from overheating, these openings must not be blocked or covered. The
product should never be placed near or over a radiator or heat register, or in a built-in installation unless proper
ventilation is provided.
8. This product should be operated from the type of power indicated on the marking label. If you are not sure of
the type of power available, consult your dealer or local power company.
9. Do not allow anything to rest on the power cord. Do not locate this product where persons will tread on the cord.
10. If an extension cord is used with this product, make sure that the total ampere rating of the equipment plugged
into the extension cord does not exceed the extension cord ampere rating. Also, make sure that the total rating
of all products plugged into the wall outlet does not exceed the fuse rating.
11. Never push objects of any kind into this product through cabinet slots as they may touch dangerous voltage
points or short out parts that could resulting a fire or electronic shocks. Never spill liquid of any kind on the
product.
12. To reduce the risk of fire, use at least No. 26 AWG wire for the telecommunication line cord.
13. Always disconnect all telephone lines & all power cords from the wall outlet before servicing or disassembling
this product. And, refer it for servicing to qualified service personal under the following conditions:
a. When the power cord or plug is damaged or frayed.
b. If liquid has been spilled into the product.
c. If the product has been exposed to rain or water.
d. If the product does not operate normally when the operating instructions are followed. Adjust only those
controls that are covered by the operating instructions, since improper adjustment of other controls may
result in damage and will often require extensive work by a qualified technician to restore the product to
normal condition.
e. If the product has been dropped or the cabinet has been damaged.
f. If the product exhibits a distinct change in performance, indicating a need for service.
Electrical Restrictions
WARNING: This equipment is designed for connection to a grounded (earthed) outlet. The grounding type plug is
an important safety feature. To reduce the risk of electrical shock, damage to your equipment, or
loss of data, do not disable this feature.
Power Cord Set Requirements
The power cord set (appliance coupler, flexible cord, and wall plug) you received with the AQUAPAD+ meets the
requirements for use in the country where you purchased the equipment.
Power cord sets for use in other counties must meet the requirements of the country where you use the AQUAPAD+.
For more information on power cord set requirement, contact your local authorized dealer, reseller, or service
provider.
General Requirements
The requirements listed below are applicable to all countries:
1. The length of the power cord set must be at least 6.0 feet (1.8 m) and a maximum of 14.76 feet (4.5 m).
2. All power cord sets must be approved by an acceptable accredited agency responsible for evaluation in the
country where the power cord set will be used.
3. The power cord set must have a minimum current capacity of 10A and a normal voltage rating of 125 or 250
volts AC, as required by each country’s power system.
4. The appliance coupler must meet the mechanical configuration of an EN 60320. / IEC 320 Standard Sheet C13
connector, for mating the appliance inlet on the AQUAPAD+.
Country-Specific Requirements
Power Cord Set Requirement
Country Accredited Agency Applicable Note Numbers
Australia EANSW 1
Austria OVE 1
Belgium CEBC 1
Canada CSA 2
Denmark DEMKO 1
Finland FIMKO 1
France UTE 1
Germany VDE 1
Italy IMQ 1
Japan JIS 3
The Netherlands KEMA 1
Norway NEMKO 1
Sweden SEMKO 1
Switzerland SEV 1
United Kingdom BSI 1
United States UL 2
Note:
1. Flexible cord must be <HAR> Type HO5VV-F, 3-conductor. 1.0 mm2 conductor size. Power cord set fittings
(appliance coupler and wall plug) must bear the certification mark of the agency responsible for evaluation in the
country where it will be used.
2. Flexible cord must be Type SVT or equivalent. No. 18 AWG, 3-conductor. Wall plug must be a two-pole
grounding type with a NEMA 5-15P (10A. 125V) or NEMA 6-15P (15A 250V) configuration.
3. Appliance coupler, flexible cord, and wall plug must bear a “T” mark and registration number in accordance with
the Japanese Dentori Law. Flexible cord must be Type VCT or VCTF, 3-conductor, 0.75mm2 conductor size.
Wall plug must be a two-pole grounding type with a Japanese Industrial Standard C8303 (15A, 125V)
configuration.
vi
Battery (Lithium)
NOTE: The following caution statement is located in the service and operating manual or on the label
adjacent to the battery.
1. English
CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY
WITH SAME OR EQUIVALENT TYPE RECOMMENDED BY THE MANUFACTURER. DISPOSE OF
USED BATTERIES ACCORDING TO THE MANUFACTURER'S INSTRUCTIONS.
2. French
IL Y A DANGER D'EXPLOSION S'IL Y A REMPLACEMENT INCORRECT DE LA BATTERIE.
REMPLACER UNIQUEMENT AVEC UNE BATTERIE DU MÊME TYPE OU D'UN TYPE RECOMMANDÉ
PAR LE CONSTRUCTEUR. METTER AU RÉBUT LES BATTERIES USAGÉES CONFORMÉMENT AUX
INSTRUCTIONS DU FABRICANT.
3. German
VORSICHT ! Explisionsgefahr bei unsachgemäßen Austausch der Batterie.
Ersatz nur durch denselben oder einem vom Hersteller empfohlenem ähnlichen Typ.
Entsorgung gebrauchter Batterien nach Angaben des Herstellers.
4. Swedish
Explosionsfara vid felaktigt batteribyte.
Använd samma batterityp eller en ekvivalent typ som rekommenderas av apparattillverkaren. Kassera
använt batteri enligt fabrikantens instruktion.
5. Danish
Lithiumbatteri- Eksplosionsfare ved fejlagtig håndtering.
Udskiftning må kum ske med batteri af samme fabrikat og type.
Lever det brugte batteri tilbage til leverandoren.
6. Norwegian
Ekspolsjonsafe ved feilaktig skifte av batteri.
Benytt samme batteritype eller en tilsvarende type anbefalt av apparatfabriknten.
Brukte batterier kasseres i henhold til fabrikantens instruksjoner.
7. Finnish
Paristo voi räjähtää, jos se on virheellisesti asennettu.
Vaihda paristo ainostaan laitevalmistajan suosittelemaan tyyppiin.
Hävitä käyteet paristo valmistajan ohjeiden mukaisesti.
0
Table of Contents
Chapter 1 1
Welcome to AQUAPAD+! 1
Safe use of your AQUAPAD+........................................................................2
Chapter 2 5
Getting Started 5
Unpacking System .........................................................................................5
Package Contents...........................................................................................5
AQUAPAD+ Internet Connection..................................................................6
Powering Up....................................................................................................7
Chapter 3 9
Identifying the Parts 9
Front View........................................................................................................9
Right Side View.............................................................................................12
Top View ........................................................................................................13
Rear View.......................................................................................................14
Rapid Charging Cradle (Optional)..............................................................14
Setting up the charging cradle ...................................................................16
Appendix I 17
Specifications 17
Hardware Specifications..............................................................................17
Software Specifications...............................................................................18
Appendix II 21
AC-DC Adapter Guidelines 21
Appendix III 22
Troubleshooting 22
Welcome to AQUAPAD+!
1
C
Ch
ha
ap
pt
te
er
r
1
1
W
We
el
lc
co
om
me
e
t
to
o
A
AQ
QU
UA
AP
PA
AD
D+
+!
!
Congratulations on your purchase of AQUAPAD+!
You have purchased a high quality, highly scalable basis for your computing needs.
The AQUAPAD+ has the following advantages:
?? Sleek Design and Smart Organization: The design of the AQUAPAD+
encompasses both functionality and elegance. The touch panel and stylus
replace a mouse and keyboard, allowing effortless input and Internet access.
?? Compact Size: Ultra-slim and light, the AQUAPAD+ weighs less than 1.2
Kg and is smaller than B5 paper. The wide 8.4’’ TFT LCD with sharp 800 ×
600 resolution makes the AQUAPAD+ ideal for Internet browsing on the go.
?? Well-rounded Performance: The Transmeta Crusoe TM5900 (800 MHz)
low power consumption CPU and Code Morphing Software (CMS)
technology minimize power consumption, giving a battery life of 3~3.5 hours.
?? All-in-one Solution: The all-in-one design of the AQUAPAD+ lets you get
connected anywhere, any time, with efficiency superior to ordinary PDAs.
Besides using an embedded Windows CE.net OS, it can also come loaded
with Windows®XPe which is compatible with many devices and has a full
suite of utilities.
?? Wireless Internet Access: The support for the 802.11g wireless standard
allows you to browse, email, download multimedia, play games, shop, and
chat online. Via its access point, the AQUAPAD+ can expand wireless
networks to spaces such as meeting rooms, offices, hotel rooms, hospitals,
or kiosks (from 160 feet (50m) indoors up to 1000 feet (300m) outdoors).
Mobility and wireless Internet access are now at your fingertips.
?? Flexible Expansion: The AQUAPAD+ is upgradable and includes one built-
in type II PCMCIA/ CardBus slot and two USB ports. The optional charging
cradle station comes with four additional USB ports and one battery
connector for a second battery backup. With compact flash or hard drive
module flexibility on the main system, users can run various applications
with the most cost-effective storage solution.
Read this User’s Manual carefully before unpacking and setting up your AQUAPAD+.
Refer to this User’s Manual first if you encounter any problems. Keep this manual on
hand for future reference.
AQUAPAD+ System User’s Manual
2
Safe use of your AQUAPAD+
Your AQUAPAD+ is designed to be as safe as possible. The guidelines that follow
ensure correct usage.
Routine Care
To keep your AQUAPAD+ working properly:
?? Do not attempt to disassemble or modify your AQUAPAD+.
?? Do not place anything on the display.
?? Avoid using or storing the AQUAPAD+ in places where static electricity or
electrical interference is likely to occur.
?? Avoid using or storing the AQUAPAD+ in places where there are sudden
temperature variations or condensation.
?? Avoid using or storing the AQUAPAD+ in direct sunlight.
?? Keep your AQUAPAD+ away from excessive moisture and temperature
extremes. Do not expose the device to liquids or precipitation.
?? Operate your AQUAPAD+ with the main battery pack installed, even when
using external power. This ensures the system has the necessary power to
operate when disconnected from external power.
?? Store your AQUAPAD+ in its cradle when not in use.
?? To clean the device, wipe the display and the exterior with a soft, damp cloth
moistened only with water. Do not use soap or other cleaning products, as they
will discolor the finish and damage the display.
Battery Care
?? Do not heat or attempt to disassemble the battery. Do not place the battery in
water or expose it to flames.
?? Do not subject the battery to strong impact, such as hitting it with a hammer,
stepping on it or dropping it.
?? Do not puncture the battery.
?? Do not attempt to service the battery.
?? Replace only with batteries designed for this product.
?? If the battery has not been used for three months, charge and discharge it for
two full cycles before recommencing normal use.
Welcome to AQUAPAD+!
3
AC-DC Adapter Care
?? Use only the supplied AC-DC adapter or as specified by the manufacturer.
Other adapters may cause damage to the AQUAPAD+; such damage is not
covered under the warranty.
?? Grasp the plug, not the cord, when unplugging the adapter from a wall socket.
?? If the power cord or adapter becomes damaged (has exposed or severed wires,
etc.), replace with a new AC-DC adapter. Use of damaged adapters may cause
fire or electrical shock.
?? Power off and disconnect the AQUAPAD+ from the AC-DC adapter before
unplugging the adapter from the wall socket.
TFT LCD Display Care
?? Do not spray liquid directly on the display or allow excess liquid to drip inside
the device.
?? Do not place anything on the display.
?? Do not scratch the surface of the display with hard objects.
?? Do not expose the display to direct sunlight or strong ultraviolet light for
extended periods of time.
Travel Care
?? Take the AQUAPAD+ AC-DC adapter with you.
?? Pack your AQUAPAD+ in the Carrying Bag or a protective case and carry it as
cabin baggage. Do not check it with your luggage.
?? Do not use your AQUAPAD+ on an airplane. The radio may function even
though you are working off-line, and interfere with aircraft navigation.
?? Be aware of the possible effect of airport security devices on your device. There
are three types of airport security devices: X-ray machines, magnetic detectors
(the device you walk through), and security magnetic wands. It is recommended
that you prevent exposure of your device to magnetic detectors and security
magnetic wands.
Shipping Care
?? Safeguard your data by making a backup copy.
?? Turn off your AQUAPAD+ and disconnect all external devices.
?? Pack your AQUAPAD+ and all external devices (e.g. power cords and AC-DC
adapter) in the original packing boxes or in similar packaging with sufficient
protective packing material.
AQUAPAD+ System User’s Manual
4
5
C
Ch
ha
ap
pt
te
er
r
2
2
G
Ge
et
tt
ti
in
ng
g
S
St
ta
ar
rt
te
ed
d
Unpacking System
Before unpacking your AQUAPAD+ System, prepare a suitable workspace for your
AQUAPAD+. You need a steady, level, and clean surface near a wall outlet.
When opening the box of the AQUAPAD+, make sure not to damage the box. Keep it
and all packing material for future shipping needs.
Check the following components are included in the box and are not damaged. If any
of these components are missing or appear damaged, contact your system dealer
immediately.
Package Contents
?
AQUAPAD+ System Unit (OS and Applications)
?
Stylus Pen
?
User's Manual
?
AC-DC Adapter
?
AC Power Cord
?
Battery (in Accessory Box)
?
Carrying Bag (Optional)
?
Rapid Charging Cradle (Optional)
?
Mini USB Conversion Cable (Optional)
?
Mini VGA Conversion Cable (Optional)
AQUAPAD+ System User’s Manual
6
AQUAPAD+ Internet Connection
AQUAPAD+ is designed to offer convenient Web browsing. The wireless local area
networking feature lets you experience real “anytime, anywhere” mobility. Information
that you or your business need is available wherever you are. With 802.11g wireless
LAN support, your AQUAPAD+ can connect to wireless networks, or wired networks
and modems using the Type II PCMCIA card slot or USB ports. The AQUAPAD+
wireless Internet connection diagram is shown in [Figure 2.1] below.
Internet
Networking and Internet
Access Configurations
(Broadband and POTS,
Gateways, Hub, Switch,
Workstation, etc.)
AP (Access Point)
AquaPAD 1 AquaPAD 2 AquaPAD 3
USB Keyboard USB Mouse
Figure 2.1 AQUAPAD+ Internet Connection
Getting Started
7
Powering Up
AQUAPAD+ features a two-way power supply that lets you use either the battery or
household AC current.
Using the Battery
The primary source of power for the AQUAPAD+ is the battery. The 2400mAH, 14.8V,
35.5 W, 4-cell Lithium battery combined with the Code Morphing Software technology
of the Crusoe processor provides up to 3 hours of battery life at full operation (with
Internet access).
The battery is accessible from the rear of the AQUAPAD+. Recharging is possible
using the AC-DC adapter supplied with the AQUAPAD+. It is not necessary to remove
the battery pack except to replace it with a fresh battery pack.
To remove the battery pack:
1. Turn off the AQUAPAD+.
2. Open the battery cover.
3. Slide the latch in the direction of the arrow shown in [Figure. 2.2].
4. Remove the discharged battery and replace with a new battery.
5. Replace the battery cover.
6. Turn on the AQUAPAD+.
Figure 2.2 Removing the battery pack
!
CAUTION
Battery charging requirement:
To lengthen battery life and maximize performance, we recommend you completely
charge then discharge the battery at least three times before commencing normal use.
AQUAPAD+ System User’s Manual
8
To charge/discharge battery:
1. Use the battery as the main power supply. When the power meter icon on the toolbar
shows low power, or the Battery Life LED Indicator starts blinking, plug the AC-DC
adapter in and charge until the battery is full.
2. Repeat this cycle three times.
Using the AC-DC Adapter
1. If you prefer to operate the AQUAPAD+ on AC power, use the supplied AC-
DC adapter. Connect the power adapter into the DC-in jack on the
AQUAPAD+. Alternatively, you can plug the AC-DC adapter to the optional
charging cradle. Connect the AQUAPAD+ to the cradle.
2. Plug the power adapter to a wall socket.
Figure 2.3 The AC-DC adapter of the AQUAPAD+
9
C
Ch
ha
ap
pt
te
er
r
3
3
I
Id
de
en
nt
ti
if
fy
yi
in
ng
g
t
th
he
e
P
Pa
ar
rt
ts
s
Front View
Refer to [Figure 3.1] below to familiarize yourself with the features of the AQUAPAD+.
Figure 3.1 Front View of the AQUAPAD+
1. Power Button:
Press this button to turn power on; press this button for more than 4 seconds to
turn power off. Press the button for less than 4 seconds to enter the AQUAPAD+
into suspend mode.
2. Built-in Microphone
3. TFT LCD Display:
The wide 8.4’’ TFT LCD integrates a touch panel that provides 800 × 600
resolution in 16-bit high color and makes AQUAPAD+ ideal for Internet browsing
on the go. Data can be entered from the touch screen using the stylus and soft
keyboard. The soft keyboard is displayed by clicking the bottom right area on the
screen. You can also use a USB keyboard plugged into the USB ports of the
AQUAPAD+. The AQUAPAD+ supports most USB keyboards and pointing
devices.
AQUAPAD+ System User’s Manual
10
Figure 3.2 Enlarged picture of the Power Button and
Internal Microphone
4. Built-in Speaker:
The built-in speaker is located on the upper left front corner. You can set the
volume through the operating system or applications or by using the Volume
Control Buttons. Sound from the speaker is muted when headphones are used.
5. Volume Control Buttons:
To increase or decrease the sound volume, press the upper or lower volume
control button.
6. Brightness Control Buttons:
To adjust the brightness of the screen, press the upper or lower brightness
control button.
Identifying the Parts
11
Figure 3.3 Enlarged picture of the Volume/Brightness
Control Buttons
7. Suspend Indicator (Left):
The yellow LED blinks when the system is in suspend mode.
8. Power Indicator (Middle):
The green LED lights up when the system is powered on.
9. Battery charge/Low Indicator (Right):
The amber LED lights when the battery is charging. The LED is off when the
battery is fully charged. The LED blinks amber rapidly when battery level is low.
Figure 3.4 Enlarged picture of LED Indicators
AQUAPAD+ System User’s Manual
12
Right Side View
Features on the right side of the AQUAPAD+ are shown in [Figure 3.5].
Figure 3.5 Right Side View of the AQUAPAD+
1. DC-in Jack:
The AQUAPAD+ is a normally a battery-operated device. The battery operating
capacity is three hours at full power with Internet access, and up to 48 hours in
STR mode. When not in use, it is recommended that the AQUAPAD+ battery be
recharged. The recharging mechanism is built into the AQUAPAD+. Insert the
supplied AC-DC adapter into the DC-in jack. Recharging time may take up to two
hours for a fully discharged battery pack.
2. Mini USB Port and Standard USB Port:
AQUAPAD+ has two USB ports. The USB ports support most USB keyboard and
pointing devices. The mini USB can be connected to a standard USB port with
the USB convert cable (optional). It is recommended you store the AQUAPAD+ in
the cradle when using a USB keyboard or USB pointing device.
3. Audio Out Jack:
The Audio Out Jack is located next to the USB ports of the AQUAPAD+. You can
connect it to standard audio headsets to provide a private stereo audio
experience. When a headset is inserted, the speaker is muted.
4. Mini VGA-out port:
The mini VGA-out port allows you to use the AQUAPAD+ with a VGA monitor or
projector. Connect the AQUAPAD+ to the monitor or projector using a cable with
a mini-VGA plug (optional).
5. Stylus Pen:
The stylus included with the AQUAPAD+ is used to activate the touch screen. It is
partially visible on the top right front corner. Do not use anything other than the
tip of the stylus to interact with the display or you may damage the display
surface.
Identifying the Parts
13
Top View
Features at the top of the AQUAPAD+ are shown in [Figure 3.6].
Figure 3.6 Top View of the AQUAPAD+
1. Infrared Transceiver:
The FIR (IrDA) provides active synchronization and a wireless data transfer
interface.
2. Expansion PC Card Socket (PCMCIA Type II):
PCMCIA cards can be inserted in this slot for added functionality.
3. Expansion PC Card Eject Button.
To remove the inserted PC card, push this eject button.
AQUAPAD+ System User’s Manual
14
Rear View
Features at the back of the AQUAPAD+ are shown in [Figure 3.7].
Figure 3.7 Rear View of the AQUAPAD+
Battery Cover:
The 2400 mAH, 14.8 V, 35.5 W, 4-cell Lithium battery combined with the Code
Morphing Software advantage of the Crusoe processor provides up to three hours of
battery life at full power with Internet access.
Rapid Charging Cradle (Optional)
The AQUAPAD+ includes a cradle into which the AQUAPAD+ can be attached to keep
it upright and stable during use. The cradle has the following features:
?? Power charging function
?? Less than 2 hrs charging time
?? Battery charging set for additional battery charging at the same time
?? Auto priority circuit for system recharging
?? Smart identification of charge indicator
?? Four USB ports for additional device functionality
Identifying the Parts
15
Figure 3.8 Rapid Charging Cradle
Figure 3.9 The Rapid Charging Cradle with battery
AQUAPAD+ System User’s Manual
16
Setting up the charging cradle
To place the AQUAPAD+ in the cradle for charging:
?? Locate the connector on the bottom of the AQUAPAD+. A rubberized cover protects
this connector.
?? Remove the rubberized cover to display the connector as shown in [Figure. 3.10].
?? Place the AQUAPAD+ in the cradle with the connectors properly aligned as shown in
[Figure. 3.11].
Figure 3.10 Rubberized connector cover
Figure 3.11 AQUAPAD+ with the cradle
17
A
Ap
pp
pe
en
nd
di
ix
x
I
I
S
Sp
pe
ec
ci
if
fi
ic
ca
at
ti
io
on
ns
s
Hardware Specifications
Item Feature
Dimensions 268.5 mm (L) x 160.0 mm (W) x 26.0 mm (H)
Weight 1.20 kg (2.65lbs.)
Processor Transmeta Crusoe TM5900 (800 MHz)
Southbridge ALi M1535+
Memory ?? Default 128/256MB DDR SO-DIMM
?? Max system memory support: 512MB
Storage ?? Factory configurable 20GB HDD or 64 MB Compact Flash
?? Microdrive support (CF type, by customer request)
Display ?? TFT-LCD 8.4”, 800 x 600 color TFT LVDS.
?? Touch screen
Battery/Life ?? 2400 mAH, 14.8V, 35.5 W, 4-cell Lithium battery.
?? Battery Life: 3 hours at full power with Internet access.
?? Battery charge time: 2 hours
Power Adapter ?? 65W Max. 100 ~ 240V
?? Output Voltage: 20 V, 3.25 A
?? Dimension: 107 mm (L) x 47 mm (W) x 30 mm (H)
Expansions One CardBus PCMCIA Type II Slot
Input/Output &
Connectors
?? One DC in power jack
?? Two USB 2.0 ports (one standard, one mini-type)
?? One mini-VGA out port
?? One audio out jack (3D Audio)
?? One built-in speaker (1 Watt)
?? One built-in microphone
?? One IrDA 1.1 FIR
?? One cradle connector
Switches ?? Power switch (slide) x 1
?? Brightness button x 2 (up and down)
?? Volume button x 2 (up and down)
LED ?? 1 (left) Suspend: blinking and off (yellow)
?? 1 (middle) for power: On and Off (green)
?? 1 (right) for charger: blinking for battery low. On for DC-in
charging, and Off for others (amber)
Case Material Magnesium alloy
AQUAPAD+ System User’s Manual
18
Item Feature
Wireless LAN Built-in 802.11g WLAN
Antenna
?? Chip antenna
Frequency Range
?? 2.400GHz ~ 2.4835GHz (subject to local regulations)
Number of Selectable Channels
?? USA, Canada: 11 channels
?? Europe: 13 channels
?? Japan: 14 channels
Modulation Technique
?? Direct Sequence Spread Spectrum (CCK, DQPSK, DBPSK)
?? Orthogonal frequency division multiplexing(OFDM)
Security
?? 64/128/256-bit WEP Encryption and Wi-Fi Protected Access
Media Access Protocol
?? CSMA/CA (Collision Avoidance) with ACK
Max. Transmit Power
?? 802.11b:19.45dBm
?? 802.11g:19.66dBm
Max. SAR (1g)
?? 802.11b:0.1090 W/kg
?? 802.11g:0.1350 W/kg
Supported Bit Rate
?? 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48 and 54Mbps
Operation Power
?? DC 5V
Throughput
?? 20.5Mbps @ 54Mbps
?? 5.7Mbps @ 11Mbps
Sensitivity
?? -68dBm@54Mbps
?? -80dBm@11Mbps
O/S options ?? Windows CE .NET
?? XP embedded
?? Midori (by request)
?? XP Home (by request)
Accessories ?? AC-DC adapter
Optional Items:
?? Mini USB cable
System Specifications
19
Item Feature
?? Mini VGA cable
?? Charging cradle
?? Carry bag
Software Specifications
Windows XP Embedded Platform Specification
Item Feature
Windows XPE ?? Media player 9.0 embedded
?? Office for XP
?? Internet Explorer 6.0
?? Outlook Express
Applications ?? Remote Desktop
?? Handwriting recognition (optional)
?? Screen keyboard
?? Windows Update
?? Gauge indicator (for battery)
?? Adobe Acrobat Reader
?? Image Viewer
?? Windows Messenger
?? Voice over IP Phone Application
?? FreeCell
?? Solitaire
?? GPS Navigator
Utilities ?? Pointer Calibration
?? Printing (Local and Remote) (optional)
?? File transfer via IrDA
Wireless Interface &
Communication
?? WLAN 802.11g
??
WAN solution compatible, supports PHS, GSM/GPRS, CDMA
module (optional)
?? Bluetooth, WCDMA in further development
WinCE Platform Specification
Item Feature
Microsoft Windows
CE .NET 4.2
?? Media player 7.0 embedded
?? Pocket word (embedded)
?? Office Viewer (Excel, Power Point)
?? Internet Explorer 6.0
?? Inbox
Applications ?? RDP 5.1
?? ICA 6.0 (optional)
?? Handwriting recognition (optional)
?? Virtual K/B
?? Remote update (optional)
?? Gauge indicator (for battery)
?? PDF Viewer
?? Image Viewer
?? Windows Messenger
?? Voice over IP Phone (optional)
AQUAPAD+ System User’s Manual
20
Item Feature
?? FreeCell
?? Solitaire
?? GPS Navigator (optional)
Utilities ?? Pointer Calibration
?? Printing (Local and Remote) (optional)
?? File transfer via IrDA
Wireless Interface &
Communication
?? WLAN 802.11g
??
WAN solution compatible, supports PHS, GSM/GPRS, CDMA
module (optional)
?? Bluetooth, WCDMA in further development
Midori Platform Specification
Item Feature
Linux Kernel 2.4.20 X window V 4.0.3
Applications ?? Office viewer (optional)
?? Ice Window manager v1.2.0
?? Mozllia 0.9
?? MPEG player—Real player v10.0
?? MP3 Player---xmms1.2.7
?? Virtual K/B (xkeyboard 0.2)
?? Games (optional)
?? GPS Navigator
PIM ?? Calculator
?? Calendar (support sync. via IrDA)
?? Address Book (support sync. via IrDA)
?? Note (support sync. via IrDA)
?? Alarm Clock
?? To Do List
Utilities ?? Xtouch0.2
?? Printing (Local and Remote) (optional)
?? File transfer via IrDA
?? System Configuration Program
Wireless Interface &
Communication
?? WLAN 802.11g
??
WAN solution compatible, supports PHS, GSM/GPRS, CDMA
module (optional)
?? Bluetooth, WCDMA in further development
The specification and appearance are subject to change without notice.
21
A
Ap
pp
pe
en
nd
di
ix
x
I
II
I
A
AC
C-
-D
DC
C
A
Ad
da
ap
pt
te
er
r
G
Gu
ui
id
de
el
li
in
ne
es
s
This AC-DC adaptor is a dedicated accessory to be used exclusively with the
AQUAPAD+. Read these guidelines before use.
!
WARNING
?? Do not use the product at voltages other than the specified voltage. Failure to
observe this may cause fire or electrical shock.
?? Do not use the AC-DC adapter if it emits smoke or a strange odor. Failure to
observe this may cause fire or electrical shock.
?? Do not attempt to disassemble or modify the product. Failure to observe this
may cause fire or electrical shock.
?? If water gets inside the product, immediately unplug the power cord. Continuing
to use the product may cause fire or electrical shock.
?? Wipe off the plug of the power cord if it becomes covered with dust. Failure to
do so can cause a fire or electrical shock.
!
CAUTION
?? Do not place heavy objects on the power cord, or allow heavy objects to drop
onto it. Do not allow the power cord to become damaged by excessive bending.
?? Do not short or touch the output terminals of the product while it is plugged in.
?? Do not touch the power cord with wet hands. This may cause an electrical
shock.
?? Do not subject the product to strong impact or allow it to drop onto hard
surfaces. This can cause a malfunction.
?? Use and appropriate AC-DC Adapter according to the country of use.
22
A
Ap
pp
pe
en
nd
di
ix
x
I
II
II
I
T
Tr
ro
ou
ub
bl
le
es
sh
ho
oo
ot
ti
in
ng
g
Problem: The AQUAPAD+ does not turn on when not connected to AC power.
Solution: If the battery charge is too low to run your AQUAPAD+, the Power LED Indicator
blinks.
Turn off the AQUAPAD+ and replace the battery with a fresh one or
connect to AC power.
Problem: Battery runs out of power quickly.
Solution: High loads on the CPU cause power to run out quickly. The
Power LED
Indicator starts blinking when power is low. Plug the AC-
DC adapter in and
recharge the battery until full.
Problem: The AQUAPAD+ turns off automatically.
Solution: Battery charge is too low or has run out. Tap the screen with the stylus pen
to
see if the display activates. Replace the battery with a fresh one or plug the AC-
DC adapter in
to charge the AQUAPAD+. You may lose unsaved data; so save
your data regularly.
Problem: The AQUAPAD+ locks up when running applications or runs slowly.
Solution: The
CPU may be overloaded or the AQUAPAD+ is locked up. Close
applications that are not in use. If this doesn’t work, restart the AQUAPAD+ by
turning the power off and on. Be sure to save your data before you restart the
system.
Problem: The AQUAPAD+ do
es not turn on or the TFT LCD display appears to be
off, even though the power is on.
Solutions:
??The display brightness and contrast are too low. Use the
Brightness Control
Button to adjust the brightness level of screen image.
??The AQUAPAD+ is in Suspend mode
. Press the power button to resume full
power mode.
??The AQUAPAD+ has run out of power. Plug the AC-DC adapter in
to charge
the AQUAPAD+.
System Specifications
23
Problem: The display is blank.
Solution: ??
Adjust the LCD display brightness and contrast by using the Brig
htness
Control Buttons.
??Restart the AQUAPAD+.
??
Plug the AC-DC adapter in to charge the AQUAPAD+.
Problem: Screen is dark.
Solution: Prolonged exposure to direct sunlight may cause your AQUAPAD+ LCD s
creen
to temporarily darken. This is normal for LCD SCREENS and
IS NOT
PERMANENT.
Problem: Display is difficult to see in sunlight or in dark rooms.
Solution: Use the Brightness Control Button to adjust contrast and brightness level
for
optimal viewing.
