litl Easel Quick Start Guide

Read Me First

litl LLC

33 Exeter St

Boston, MA.

USA

Welcome to the litl Easel

Congratulations on purchasing the lilt Easel.

Your litl Easel is different. More than ever, the web is why people use computers. That's why

the litl Easel is a web computer, built on and for the Internet. Web computers use the web

instead of locally stored data and software. And of course, they’re specifically designed for

accessing websites and their content.

Getting started with your litl Easel

To turn on your litl Easel, briefly push the power button on the right side of the hinge of the

device. The litl uses so little power and runs so cool you can leave it on all the time, but if you

do want to turn it off, push the same button and hold it in for a moment.

You'll be prompted to choose a wireless network. Make sure you know the name of your

network and the password. If you enable MAC filtering, use the hardware address on the

bottom left to configure your router.

When you reach the Do You Own a litl screen, click "No."

You've reached litl Card View, the litl's home. Rearrange your set of cards by dragging them;

delete them with the "X" in their top right corner. The blue litl key on the keyboard always

returns you to this view.

Blue cards are permanent litl cards: the Card Catalog, Family and Friends card, Mediawall

and Settings cards.

White cards are web cards. These are live web sites, displayed in a familiar Mozilla-powered

web browser. Click on the gray New Web Card card to create a new one and navigate to a

new site, e.g. yahoo.com, ebay.com, etc. Or, type a search term or URL in the Google-

powered Search the web box.

Black cards are what we call channel cards. Think of a TV or radio channel. Some good

ones, including a specially designed litl alarm clock, a New York Times headline ticker, and an

exclusive weather channel, are one click away in the Card Catalog.

Family and Friends! Click the Family and Friends card. Click on the litl family icon and you'll

activate the camera. Take a picture. Then go to Find Friends and type in Annie at litl. Click

on her smiling picture and share the card with her. This puts you in touch with her for

customer support of all kinds. (You can email support anytime at asklitl@litl.com or call

617-329-1416.) Commercial litl users will be able to select their own friends and family.

Visit the card catalog! We've preloaded a mix of familiar sites and some exclusive offerings.

To configure location for the clock or weather channel, click on "TimeZone/Location" in the

Settings card. (You can also edit the location directly in the weather channel card.)

Create your own channel! You can create a litl channel from any web page that has an RSS

feed. Navigate to your favorite news site, blog, or flickr photostream and click "add channel" in

your Web Card toolbar (picture). This will create a black channel card.

Once you have a channel open, pick up your litl Easel and flip it over. (Picture) Now you're

in easel view. Depending on the site you've chosen to create as a channel, you will probably

see streaming headlines. To view your photos or fun sites such as icanhascheezburger.com,

go into Options and switch to slideshow mode.

You can see more in easel mode by clicking the blue button on the hinge (now on your right

side) and use the "rolodex" to view the other stories. Or just go directly to the scroll wheel to

see all of your channels.

The litl remote control functions the same as the scroll wheel and the blue litl button. To read

further on certain stories, flip back into laptop mode.

Have fun with photos through the Mediawall! Connect to flickr or Shutterfly under the

Mediawall "options" button. You'll see your photos after a short time. Flip into easel mode.

Your slideshow will appear in full-screen mode. Click the blue button on the hinge to open a

menu of photos.

Enjoy the big picture. Hook the litl up to your HDTV using an HDMI cable and enjoy all the

features of your litl with the visual and auditory experience of your television and sound

system. Photos look great in the larger-than-large mode!

Have fun!

Contact litl with any questions by emailing asklitl@litl.com or by calling +1 617.329.1416.

Product Specification

Product litl Easel

Category Webbook

Processor: Intel® AtomTM Z540 Processor (1.86 GHz, 512KB L2 Cache, 533MHz FSB)

Operating System Litl OS

Memory 1GB 533MHz DDR2 SDRAM

Chipset Intel® US15W chipset

Graphics Intel® Integrated Graphics Media Accelerator 500

LCD Display Matte 12.1 inch WXGA display (1280x800) wide view

Audio and speakers Two internal speakers (0.5 W per channel)

Built in microphone

Compact Flash 2 GB SLC

Ports HDMI (Type A), USB 2.0 (1), Audio jack (1 line out), AC adaptor connector

Battery 3 cell 28WHr Lithium Ion Battery 

Camera Built in 300kP webcam 

Wireless 802.11 b/g, 2 Internal IR receivers compatible with litl remote

AC Adaptor 120 240V AC; DC 20V @ 2A 

Dimensions & Weight Width: 12.6” (320mm)

Height: 1.06” (27mm)

Depth: 9.25” (235mm)

Weight: 3.38 lbs

Safety and Care Information

Usage Warnings

CAUTION: For use with information Technology Equipment.

PRECAUCION: Para uso con equipos de tecnologia de la information.

ATTENTION: Utiliser avec du matériel informatique seulement.

Safety Instructions

This document contains important information on how to use your litl safely. Please read

these instructions carefully and take careful note of all warnings and cautions here, on the

device or in any other litl documentation. Please note the location of these instructions for

later reference.

• Keep this equipment away from humidity. Do not use your litl near water, for example,

near a bathtub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a

swimming pool.

• Place your litl on a stable flat surface during use. Breakage or injury to the user could

occur if the device slips or is dropped during use. Make sure that the air vents on the

base of your litl are not blocked by another object or any soft material such as carpet or

blankets. Do not cover your litl during operation with any material that could reduce air

circulation.

• Your litl may be used in surrounding temperatures of 32º-104ºF (0º-40ºC) only. Do not

place your litl near heat sources such as radiators, heat registers, stoves, or any

apparatus that produces heat, including amplifiers.

• Use your litl in a clean, non-dusty environment. Dust may cause an electrical short

circuit inside the device causing a malfunction. The screen could be damaged if a short

circuit is caused by metal particles. Do not operate your litl during a gas leak.

• The base of the device may become quite warm during use and it is advisable not to

place your litl in contact with bare skin or flammable materials.

• Never put heavy objects on top of your litl or on the screen.

• Do not operate your litl with any part of its casing opened. For safety reasons your litl's

casing should only be opened by authorized service personnel. Never disassemble or

reassemble the screen under any circumstances.

• Always refer your litl for servicing to an authorized service center under the following

conditions:

• If the power cord or plug gets damaged or frayed.

• If liquid has been spilled into your litl.

• If your litl has been exposed to rain or water.

• If your litl does not operate normally when the operating instructions are followed.

Adjust only those controls that are covered in litl's documentation or instructions,

since improper adjustment of other controls may result in damage and will often

require extensive work by an authorized technician to restore the product to

normal condition.

• If you drop your litl or its casing has been damaged.

• If your litl's performance noticeably changes - this indicates a need for service.

• If your litl shows any obvious sign of breakage.

• Always disconnect all cables and the power cord before servicing or disassembling

your litl. To reduce the risk of injury from electrical shock or hot surfaces disconnect the

power cord from the wall outlet and allow the internal system components to cool

before touching.

• Your litl contains an internal battery pack that is not user serviceable. Do not attempt to

remove or disassemble the battery pack - it may release toxic materials, create an

electrical or fire hazard or cause burns. Send your litl to an authorized service center

when the battery needs to be checked or replaced. There is a risk of explosion if the

battery is replaced incorrectly. Do not short circuit the battery. The replacement battery

pack must be of the exact type as specified by litl.

• The battery is easily damaged. Only charge the battery using a power adapter

approved by litl specifically for use with this device. Using a different power adapter

may cause a fire or explosion.

• This product should be operated using the type of AC mains power specified on the

power adapter label (100-240 Vac, 50-60 Hz). If you are unsure of the type of mains

power available, consult your power company.

• If your litl is not going to be used for a long time, disconnect it from mains power to

avoid possible damage from voltage spikes.

• Do not carry your litl in a bag containing small metallic or sharp objects, such as loose

paper clips or staples, which could penetrate or enter the casing and cause short

circuits.

• Do not press on or touch the screen.

• Never incinerate your litl or dump your litl in the municipal waste. Check regulations in

your area concerning how to dispose of electronic products.

• If the screen is broken and liquid crystal material spills out, do not ingest or inhale this

material, and be careful not to allow this material to come into contact with your skin. If

this liquid crystal material does come into contact with the skin or clothing, wash

immediately with alcohol and then rinse thoroughly with water. If this liquid crystal

material enters the mouth or eyes, rinse with copious amounts of water and seek

medical attention. The screen contains a small amount of mercury gas. If the screen is

damaged this gas may be released. Be careful not to inhale this gas and seek medical

attention if this gas is inhaled.

Installation Restrictions

If an extension cord is used with this product, make sure that the total ampere rating of the

equipment plugged into the extension cord does not exceed the ampere rating of the

extension cord. Also make sure that the total rating of all products plugged into the wall outlet

does not exceed the rating of the mains fuse.

Never force connectors into jacks on your litl's casing. Do not push objects of any kind into

your litl through openings in the device casing. Inserted objects may come into contact with

components running at a dangerous voltage or short out parts that could result in a fire or

electrical shock. Never spill liquid of any kind on your litl.

Unplug this product from the ac wall outlet before cleaning. Normally only use a soft clean dry

cloth without chemicals or detergents for cleaning your litl. Do not use liquid chemical or

aerosol cleaners. You may use soft absorbent cotton with a little water (or isopropyl alcohol

when necessary) for cleaning your litl's screen or any external surfaces of your litl. Ensure

that no liquid enters your litl.

Note that the surface of the remote control scratches easily. Do not handle the remote control

with suntan lotion on your hands - it will fade the surface finish.

CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED.

REPLACE ONLY WITH SAME OR EQUIVALENT TYPE RECOMMENDED BY THE

MANUFACTURER. DISCARD USED BATTERIES ACCORDING TO THE

MANUFACTURER'S INSTRUCTIONS.

IL Y A DANGER D'EXPLOSION S'IL Y A REMPLACEMENT INCORRECT DE LA BATTERIE.

REMPLACER UNIQUEMENT AVEC UNE BATTERIE DU MÊME TYPE OU D'UN TYPE

RECOMMANDÉ PAR LE CONSTRUCTEUR. METTER AU RÉBUT LES BATTERIES

USAGÉES CONFORMÉMENT AUX INSTRUCTIONS DU FABRICANT.

Important notices

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation.

This equipment generates uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is encouraged to try to

correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

FCC Caution

Any changes or modifications not expressly approved by the party responsible for compliance

could void the user's authority to operate this equipment.

FCC Declaration of Conformity

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may

cause undesired operation.

Any changes or modifications (including the antennas) made to this device that are not

expressly approved by the manufacturer may void the user’s authority to operate the

equipment.

FCC RF Radiated Exposure Statement

This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled

environment. This device and its antenna must not be co-located or operating conjunction

with any other antenna or transmitter.

IC EMC

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conformer à la norme NMB-003 du Canada.

Industry Canada Statement

This device complies with RSS-210 of the Industry Canada Rules. Operation is subject to the

following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may

cause undesired operation.

Radiation Exposure Statement

This equipment complies with IC radiation exposure limits set forth for an uncontrolled

environment.

Codecs

Windows Media Plugins

This product includes technology developed and owned by Microsoft and protected by certain

intellectual property rights of Microsoft. Use or distribution of such technology outside of the

plug-ins is prohibited without a license of Microsoft. Microsoft is the sole owner of any

trademark related with such technology (i.e. Windows Media, Microsoft, etc.).

Microsoft technology is subject to U.S. export jurisdiction. In complying with U.S. export

regulations and its amendments distribution limitations to the plug-ins may be placed in

Fluendo’s website from time to time.

MP3 Audio Decoding Technology

MPEG Layer-3 audio decoding technology licensed from Fraunhofer IIS and Thomson.

This product cannot be installed in product other than Personal Computers sold for general

purpose usage, and not for set-top boxes, embedded PC, PC which are sold and customized

for mainly audio or multimedia playback and/or registration, unless the seller has received a

license by Fraunhofer IIS and Thomson and pays the relevant royalties to them.

AVC Patent Portfolio (h.264)

THIS PRODUCT IS LICENSED UNDER THE AVC PATENT PORTFOLIO LICENSE FOR

THE PERSONAL AND NON-COMMERCIAL USE OF A CONSUMER TO (i) ENCODE VIDEO

IN COMPLIANCE WITH THE AVC STANDARD ("AVC VIDEO") AND/OR (ii) DECODE AVC

VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND NON-

COMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER

LICENSED TO PROVIDE AVC VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED

FOR ANY OTHER USE. ADDITIONAL INFORMATION MAY BE OBTAINED FROM MPEG LA,

L.L.C. SEE HTTP://WWW.MPEGLA.COM

MPEG-4 Visual Patent Portfolio

THIS PRODUCT IS LICENSED UNDER THE MPEG-4 VISUAL PATENT PORTFOLIO

LICENSE FOR THE PERSONAL AND NON-COMMERCIAL USE OF A CONSUMER FOR (i)

ENCODING VIDEO IN COMPLIANCE WITH THE MPEG-4 VISUAL STANDARD ("MPEG-4

VIDEO") AND/OR (ii) DECODING MPEG-4 VIDEO THAT WAS ENCODED BY A

CONSUMER ENGAGED IN A PERSONAL AND NONCOMMERCIAL ACTIVITY AND/OR

WAS OBTAINED FROM A VIDEO PROVIDER LICENSED BY MPEG LA TO PROVIDE

MPEG-4 VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY OTHER

USE. ADDITIONAL INFORMATION INCLUDING THAT RELATING TO PROMOTIONAL,

INTERNAL AND COMMERCIAL USES AND LICENSING MAY BE OBTAINED FROM

MPEG LA, LLC. SEE HTTP://WWW.MPEGLA.COM.

Adobe Flash Copyright Notice

Contains Adobe® FlashTM technology by Adobe, Inc

Adobe, Flash, Adobe Flash, and Adobe Flash Lite are trademarks or registered

trademarks of Adobe, Inc. in the United States and other countries.

How To Obtain Source Code

Your litl Easel includes certain free/open source software. litl will provide the source code to

this free/open source software as may be required by applicable licenses. To obtain a DVD

containing the source code for the open source components of our operating system, please

write to:

Sources DVD

litl LLC

33 Exeter St.

Boston, MA 02116

Please state your name, address and telephone number and enclose a check or money order

for US$10 (inside US only) to cover postage and handling. Also clearly state the version of the

sources that you are requesting. You can see the version details of litl's software at the bottom

right corner of this screen. Write down the characters that follow "litlOS version:" and be sure

to include these in your letter.

If you are outside the US, please email asklitl@litl.com and we will make arrangements to

send you the sources.

Note that the DVD does not contain source code to our proprietary interface which is not open

source.

More legal information

You can view additional detailed license and copyright documentation in the About section of

the Settings card on your litl. You

can also find links to our warranty, privacy and security

policies, and other important information online at litl.com/legal.

First Computer EASEL Notebook User Manual

First International Computer Inc Notebook

user manual

Navigation menu

Namespaces

Views

Navigation
