Super Talk!™BARBIE™Sun Jammer™

4x4

Owner’s Manual with Assembly Instructions

Please read this manual and save it with your original sales receipt.

For Model 76960

Tools needed for assembly: Phillips Screwdriver, Slotted Screwdriver, Hammer, Safety Scissors.

Use only with Power Wheels®Type H (9.5 Amp/hr.) Batteries, Power Wheels®30 Amp Fuses and

Power Wheels®Type H 12 Volt Charger (all included).

Requires three “AAA” (LR03) alkaline batteries (not included) for the phone.

CAUTION

ELECTRIC TOY: Not recommended for children under 3 years of age.

As with all electric products, precautions should be observed during

handling and use to prevent electric shock.

Product features may vary from the picture above.

WARNING

• Children can be harmed by small parts, sharp edges and sharp points in the vehicle’s

unassembled state, or by electrical items. Care should be taken in unpacking and assembly of

the vehicle. Children should not handle parts, batteries or help in assembly of the vehicle.

• Keep small parts such as the “AAA” batteries and plastic bags out of children’s reach. Dispose

of plastic bags properly.

• Adult supervision is required. Children do not have the judgement necessary to avoid many

accidents. Be sure that children operating this vehicle can do so safely and that they are

supervised at all times.

• Improper use of this vehicle could lead to a serious or fatal accident. Allow children to play

with this vehicle only when you have determined that they can do so safely. Follow all instruc-

tions to help your child enjoy this vehicle as safely as possible.

• Never use near steps, driveways, steep inclines, roadways, alleys, swimming pool areas or

other bodies of water.

• Always wear shoes or sneakers when operating or riding in this vehicle.

• Never allow more than two riders; one driver and one passenger.

• Riders should sit on the seat when the vehicle is in operation.

•Hot motor covers. Handle carefully.

• Never alter this vehicle or its electrical system in any way. Alterations could cause a fire

resulting in injury and could also ruin the electrical system.

• Use of the wrong type battery, fuse or charger could cause a fire or explosion, resulting in

serious injury.

• Never add unauthorized parts to the vehicle or use substitute parts. Use only specified

Power Wheels®replacement parts.

• Batteries must be handled by adults only.

• Never lift or carry the 6 volt batteries by the wires or connectors. This can damage the 6 volt

batteries and possibly cause a fire resulting in injury. Lift and carry the 6 volt batteries by the

cases only.

• Never permit a child to handle batteries. The 6 volt batteries are heavy and contain sulfuric acid

(electrolyte), and if dropped, could result in serious injury. Read the cautions on the back panel

of the 6 volt battery.

• Never allow children to charge the 6 volt batteries. Battery charging must be done by adults

only. A child could be injured by the electricity involved in charging batteries.

• Examine the 6 volt batteries, charger and their connectors for excessive wear or damage each

time you charge the 6 volt batteries. If damage or excessive wear is detected, do not use the

vehicle until you have replaced the worn or damaged part as it could possibly cause a fire

resulting in injury.

• Placing the “AAA” (LR03) batteries in the phone with the positive (+) and negative (-) markings

the wrong way could cause damage or over-heating resulting in injury. The “AAA” (LR03)

batteries must be positioned as shown on the battery compartment door.

Throughout this manual you will find important messages in the

form of WARNINGS, CAUTIONS, and NOTES. WARNING

WARNING – SIGNALS SOMETHING THAT

COULD HURT YOUR CHILD OR YOU.

The message explains the hazard and

how you can avoid it.

CAUTION

• Do not operate your vehicle for the first time until you have inserted the 30 amp fuses into the

6 volt batteries and charged the 6 volt batteries for at least 18 hours. Never charge the 6 volt

batteries longer than 30 hours.

• After first-time use, charge the 6 volt batteries for at least 14 hours after each use. You do not

have to let the 6 volt batteries run down completely before recharging. Never charge the 6 volt

batteries longer than 30 hours.

• Use the charger indoors only.

• Read and follow the Battery Care instructions on page 33. Failure to follow the Battery Care

instructions may permanently damage your 6 volt batteries and will void your warranty.

• When you purchase replacement 6 volt batteries, you should buy a set. Using an older 6 volt

battery with a new 6 volt battery may cause permanent damage to both 6 volt batteries.

• To avoid damaging motors and gears, do not overload the vehicle.

- Never allow more than two children in the vehicle at one time; one driver and one passenger.

- Do not exceed the maximum weight capacity of 130 lbs.

- Do not tow anything behind the vehicle. The extra weight may overload it.

• Avoid operating the vehicle in wet or snowy conditions, and do not spray the vehicle with a

hose. Do not wash the vehicle with soap and water. Water or moisture in the motors or

electrical switches can cause them to corrode, and could cause switch failure.

• Avoid operating the vehicle on sand, loose dirt or gravel. Sand, loose dirt and gravel in the

electrical switches or motors can cause them to jam, and could cause switch failure. Use

this vehicle on grass, asphalt or other hard surfaces.

CAUTION

CAUTION – SIGNALS SOMETHING THAT

COULD DAMAGE THE VEHICLE.

The message explains the risk and

how you can avoid it.

NOTE – Is used to highlight

useful information.

Table of Contents

AMessage to Parents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

BImportant Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

CParts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

DParts Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

EFirst-Time 6 Volt Battery Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

FAssembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

G6 Volt Battery Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

HCharging the 6 Volt Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31

IBattery Handling/Care/Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

JRules for Safe Driving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34

KHow to Operate Your Vehicle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36

LFrequently Asked Questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

MProblems and Solutions Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

NStatement of Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

OAuthorized Service Centers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

Message to Parents

Thank you for purchasing the Power Wheels®

Super Talk™BARBIE™Sun Jammer™4x4! For over

30 years, Power Wheels®has manufactured high-

quality, battery-powered vehicles for children. Our

goal is to provide your child with an enjoyable and

safe driving experience. To help achieve this goal, it is

extremely important that you read this entire manual

and share the appropriate information with your child.

Your vehicle requires adult assembly. Please set aside

at least 60 minutes for assembly. Read the assembly

instructions carefully and identify all parts before

assembly. Refer to the Parts Section beginning on

page 6 for parts identification. Save all packaging

material until assembly is complete to ensure that no

parts are discarded.

In the unlikely event that parts are missing or

damaged or if you have any questions about your

Power Wheels®vehicle, please call our Consumer

Affairs toll-free service lines, open from 8 AM to 6 PM

(EST) Monday through Friday.

Please call us at 1-800-348-0751.

Trained customer service representatives are available

to take your call in English or French.

¿Habla Español? Si usted tiene alguna pregunta ó

necesita asistencia llame gratis 1-800-348-0755 para

los Estados Unidos. Tenemos representantes que

hablan español para atender su llamada.

We also have a nationwide Authorized Service Center

network – with over 300 Authorized Service Centers.

Our Authorized Service Centers will repair or replace

parts under warranty at no charge. For vehicles

beyond warranty, our Authorized Service Centers

will perform repairs for a minimal charge. For the

Authorized Service Center nearest you, please see

the Authorized Service Center listing beginning on

page 43.

Important Information

• Carefully read this manual for important safety

information and operating instructions before using

your vehicle.

• Please complete and return the enclosed

Registration Card, or call 1-800-348-0751 to register

your vehicle by phone.

• This vehicle is designed for use by children 3-7 years.

• Adult assembly is required.

• This vehicle has adjustable play seat belts. Please

note that the adjustable seat belts are designed

to be a play feature only and do not function as

protective safety restraints.

• This vehicle uses two Power Wheels®Type H 6 volt

(9.5 Amp/hr.) batteries with Power Wheels®30 amp

fuses and a Power Wheels®Type H 12 volt charger

(120 VAC 60 HZ 28W with an output of 12 VDC

1200 mA). Do not substitute any other batteries,

fuses or charger.

•Before first-time use, charge the 6 volt batteries for

at least 18 hours. Never charge the 6 volt batteries

longer than 30 hours.

• After the first charge, charge the 6 volt batteries a

minimum of 14 hours after each use. Never charge

the 6 volt batteries longer than 30 hours.

• Do not run down the 6 volt batteries completely

before charging.

• Leaving the 6 volt batteries in a discharged

condition will ruin them.

• Charge the 6 volt batteries before storing your

vehicle.

• Charge the 6 volt batteries at least once per month,

even if the vehicle has not been used.

• Do not store the 6 volt batteries in temperatures

above 75˚ F or below -10˚ F.

• Even with proper care, the 6 volt batteries will not

last forever. The life of the 6 volt batteries depends

on how well you follow the Battery Care instructions

and the total number of hours the 6 volt batteries

are used. Please refer to the BatteryHandling/

Care/Disposal instructions on page 33 for detailed

information about battery care.

• When you purchase replacement Power Wheels®

Type H (9.5 Amp/hr.) batteries, you should buy them

as a set. Using an older 6 volt battery with a new 6

volt battery may result in poor performance and

may cause permanent damage to both 6 volt

batteries. Remember to charge new 6 volt batteries

for at least 18 hours before first use.

• To purchase Power Wheels®Type H 6 volt batteries,

Power Wheels®30 amp fuses or a Power Wheels®

Type H 12 volt charger, please contact:

- the store where your vehicle was purchased.

- an Authorized Service Center (see Authorized

Service Center list beginning on page 43).

- Power Wheels®Consumer Affairs at 1-800-348-0751.

• While the 6 volt batteries are charging, the charger

may become warm to the touch. This is a normal

condition and does not indicate a problem.

• This vehicle is suitable for use on grass, asphalt or

other hard surfaces. To prevent damage to the

motors and switches, do not operate the vehicle

on loose dirt, gravel or sand.

• To prevent damage to electrical components, store

the vehicle inside or under a protective cover during

snowy or rainy weather. Do not leave the vehicle out

in the rain or let your child wash it with soap and

water.

• This vehicle has a special circuit-breaker in the wiring

to protect the motors and electrical system. If the

vehicle is put under extreme load (driving on rough

surfaces, too much weight, climbing too steep an

incline), the circuit-breaker will shut the electrical

system down for up to 20 seconds. If the system

repeatedly shuts down, the driving conditions may

be too demanding (ie: too steep or too much

weight).

• Metal parts have been coated with a lubricant to

protect them during shipment. Wipe all metal parts

with a paper towel to remove any excess lubricant.

Parts

Sport Bar Support – 2

123

4 5 6

12-VOLT

CHARGER

12 Volt Charger

Sport Bar Swivel – 2

Lens Guard – 2

Battery Retainer

If you experience a problem with this product, or are missing a part, please call us

at 1-800-348-0751, rather than return this product to the store.

Please save all packaging material until assembly is complete to ensure that no parts are discarded.

Dashboard Plate

Phone Holder Clip

Headlight Lens – 2

Turn Signal Lens – 2

Taillight Housing Set

Taillight Lens Set

Gas Cap Assembly

Steering Wheel Cap

Phone

Sport Bar Bracket – 2

Short Seat Belt Strap – 2

Long Seat Belt Strap

Phone Holder

Canopy

Key Chain

Knob Plate

#8 x 1" Screw – 10

#8 x 3/4" Screw – 8

Hood Latch – 2

#10 x 1" Screw – 2

#6 x 1" Screw – 1

30 Amp Fuse – 3*

Dashboard Knob – 2

Windshield

Front Bumper

Rear Bumper

Sport Bar

Not Shown: Label Sheets 6 Volt Battery – 2

Steering Column

Parts

Cap Nut – 3* All Screws Shown

Actual Size

Vehicle Body

Dash

Hood

Seat

* For your convenience, an extra 30 amp fuse

and cap nut have been included.

**#3 x 3/8" screws found in phone.

Steering Wheel

Key Assembly

#8 x1/2" Screw – 2

Light Cover – 2

Light Rack, Rear Light Rack, Front

#10 x 1/2" Screw – 2

#6 x 11/2" Screw – 4

1/4" x 11/2" Machine Screw – 2

#3 x 3/8" Screw – 2**

12-VOLT

CHARGER

Parts Diagram

1 Dash

2 Dashboard Plate

3 Steering Wheel

4 Steering Wheel Cap

5 Phone

6 Phone Holder

7 Phone Holder Clip

8 Key Chain

9 Dashboard Knob – 2

10 Knob Plate

11 Key Assembly

12 Windshield

13 Headlight Lens – 2

14 Lens Guard – 2

15 Turn Signal Lens – 2

16 Sport Bar

17 Sport Bar Swivel – 2

18 Sport Bar Support – 2

19 Light Cover – 2

20 Canopy

21 Sport Bar Bracket – 2

22 Light Rack – Rear

23 Light Rack – Front

24 Hood Latch – 2

25 Gas Cap Assembly

26 Taillight Lens – 2

27 Taillight Housing – 2

28 Rear Bumper

29 Vehicle Body

30 Seat

31 Short Seat Belt Strap – 2

32 Long Seat Belt Strap

33 Hood

34 6 Volt Battery – 2

35 Battery Retainer

36 Steering Column

37 Front Bumper

38 12 Volt Charger

Not Shown: Label Sheet – 2

Parts

10 11

13 14

36 37

First-Time 6 Volt Battery Charging

WARNING

• Batteries must be handled by adults only.

• Never allow children to charge the 6 volt batteries. Battery charging must be done by adults

only. A child could be injured by the electricity involved in charging batteries.

• Use of the wrong type battery, fuse or charger could cause a fire or explosion, resulting in

serious injury.

• Never permit a child to handle batteries. The 6 volt batteries are heavy and contain sulfuric

acid (electrolyte), and if dropped, could result in a serious injury. Read the cautions on the

back panel of the 6 volt battery.

• Never lift or carry the 6 volt batteries by the wires or connectors. This can damage the 6 volt

batteries and possibly cause a fire. Lift and carry the 6 volt batteries by the cases only.

• Examine the 6 volt batteries, charger and their connectors for excessive wear or damage

each time you charge the 6 volt batteries. If damage or excessive wear is detected, do not

use the charger or the vehicle until you have replaced the worn or damaged part.

• Never alter this vehicle or its electrical system in any way. Alterations could cause a fire

resulting in injury and could also ruin the electrical system.

CAUTION

• Do not operate the vehicle for the first time until you have inserted 30 amp fuses into the

6 volt batteries and charged them for at least 18 hours. Never charge the 6 volt batteries

longer than 30 hours.

• Carefully read the Battery Care instructions to obtain the best battery life. Failure to follow

the Battery Care instructions may permanently damage your 6 volt batteries and may void

your warranty.

• Use the charger indoors only.

We recommend that you start charging the 6 volt batteries before beginning assembly of

your vehicle. Your new 6 volt batteries must be charged for at least 18 hours before you use

your vehicle for the first time.

• Squeeze the Lock-InTM connector

tabs on the charger connector

and plug it into the battery

connector.

• Plug the charger into a standard

120 volt wall outlet.

Note: If power flow to the wall

outlet is controlled by a switch,

make sure the switch is “ON”.

• Before first time use, charge the

6 volt batteries for at least 18

hours. Never charge the 6 volt

batteries longer than 30 hours.

Note: The 6 volt batteries must be

upright while charging.

Battery

Connector

Charger

Connector

Lock-InTM

Connector

Tabs

First-Time 6 Volt Battery Charging

• Insert a 30 amp fuse into each

6 volt battery.

Note: The top of the fuse will

not be flush with the top of the

6 volt battery when properly

installed.

• Stack one battery connector

on top of the other and snap

them together.

IMPORTANT

A 25 AMP FUSE MUST

BE INSTALLED IN TOP

OF BATTERY BEFORE

TOY WILL RECHARGE

OR OPERATE

IMPORTANT

A 25 AMP FUSE MUST

BE INSTALLED IN TOP

OF BATTERY BEFORE

TOY WILL RECHARGE

OR OPERATE

30 Amp Fuse Battery

Connectors

Charger

Assembly

Do Not Omit Any Steps. Please set aside at least 60 minutes for assembly.

• Apply labels to the dashboard

plate, knob plate, and both sides

of the key chain as shown. Make

sure the areas where the labels

will be applied are clean and

dry. For best adhesion, avoid

applying labels more than once.

Dashboard Plate

Knob Plate

COOL

HEAT

Key Assembly

Knobs

• Snap the key assembly into the

dashboard plate.

• Insert the key chain end through

the key and then into the square

opening in the key chain.

• Snap the knobs into the knob

plate.

Note: Gently squeeze the tabs on

the knobs together before insert-

ing the knobs into the knob plate.

• Set the dashboard plate and

knob plate aside.

• Fit the phone holder into the

pocket in the dash, as shown.

• Slide the tab on the front of the

phone holder clip into the slot in

the bottom of the phone holder

to secure the phone holder to

the dash.

• Insert a #6 x 1'' screw through the

top of the phone holder and the

dash, and into the screw peg on

the back of the phone holder

clip, as shown.

Helpful Hint: Press on the screw

peg to align it with the screw

holes in the phone holder and

dash.

• Tighten the screw with a Phillips

screwdriver. Do not over-tighten.

Square

Opening

Key

Key Chain

#6 x 1" Screw

Shown Actual Size

Dash

Phone Holder

Phone Clip Holder

Tab

COOL

HEAT

Key Chain

Assembly

• Open the phone’s battery

compartment door and remove

the packet of #3 x 3/8" screws.

• Insert three “AAA” (LR03) alkaline

batteries as indicated in the

battery compartment.

• Close the battery compartment

door.

• Insert the #3 x 3/8" screws into the

holes in the battery compartment

door and tighten the screws with

a Phillips screwdriver. Do not

over-tighten.

–

“AAA” (LR03) x 3

Shown Actual Size

WARNING

Placing the “AAA” (LR03) batteries in the phone with the

positive (+) and negative (-) markings the wrong way could

cause damage or over-heating resulting in injury. The “AAA”

(LR03) batteries must be positioned as shown on the battery

compartment door.

Phone

Battery Compartment Door

Please Note:

• Do not mix old and new batteries.

• Do not mix different types of batteries; alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium).

• Remove batteries during long periods of non-use. Always remove exhausted batteries from this product.

Battery leakage and corrosion can damage this product.

• Never short circuit the battery terminals.

• Non-rechargeable batteries are not to be recharged.

• Only batteries of the same or equivalent type, as recommended above, are to be recharged.

• If removable rechargeable batteries are used, they are only to be charged under adult supervision.

• Rechargeable batteries are to be removed from this product before they are charged.

• If you use a battery charger, it should be examined regularly for damage to the cord, plug, enclosure and

other parts. Do not use a damaged battery charger until it has been properly repaired.

#3 x 3/8" Screw – 2

Shown Actual Size

Assembly

• Bend the end of the telephone

cord so that it forms a “T”.

• Insert the end of the telephone

cord through the hole in the

dash, as shown.

• Pull up on the end of the

telephone cord to be sure it is

secure.

• Place the telephone in the

telephone holder with the

number pad facing out.

• Position the bottom edge of the

knob plate in the opening in the

dash.

• Snap the top of the knob plate

into the dash.

123

456

Dash

Knob Plate

Telephone Cord

• Fit the tabs on the dash into

the slots in the front of the

vehicle body.

• Insert two #10 x 1" screws through

the holes closest to the front of

the vehicle body and into the

vehicle body .

• Insert two #10 x 1/2'' screws through

the holes closest to the seating

area and into the holes in the

vehicle body .

• Tighten each screw with a Phillips

screwdriver. Do not over-tighten.

123

456

Dash

Tab

Slots

Tab

#10 x 1" Screw – 2

Body

#10 x 1/2" Screw – 2

Both Shown Actual Size

• Fit the dashboard plate on the

dash. The notch in the large hole

should be at the top.

• Insert four #8 x 3/4" screws as shown.

• Tighten each screw with a Phillips

screwdriver. Do not over-tighten.

Steering Column

• Wipe the steering column with

a paper towel to remove any

excess lubricant.

• Turn the vehicle body on its side.

• Insert the straight end of the

steering column up through the

hole in the vehicle body wall

and out through the hole in the

dashboard plate.

Dash

Dashboard

Plate

Assembly

#8 x 3/4" Screw – 4

Shown Actual Size

Hole

Large Hole

Bottom View

Notch

• Turn the vehicle body upright.

• Position the steering wheel so that

the spokes form a “Y” as shown.

The tab on the steering wheel

stem should face up.

• Fit the steering wheel onto the

steering column.

• Fit a cap nut onto the end of the

steering column.

• Tap the cap nut with a hammer

to secure it on the steering

column.

Helpful Hint! You may want the help

of another person to support the

steering column while you tap the

cap nut with the hammer.

Steering Wheel

Cap Nut

Assembly

Steering

Column

• Insert the end of the steering

column through the hole in the

steering rod.

• Fit a cap nut onto the end of the

steering column.

• While supporting the steering

column, tap the cap nut with a

hammer to secure it on the

steering column.

Helpful Hint! You may want the

help of another person to support

the steering column while you tap

the cap nut with the hammer.

Steering Rod

Cap Nut

End of Steering Column

Bottom View

“UP”

Tab

Assembly

• Fit the wide notch in the side of a

headlight lens under the wide

tab on a lens guard.

• Press firmly on the inside of the

headlight lens to snap it into the

lens guard.

• Repeat this procedure to

assemble the other headlight

lens to the remaining lens guard.

Headlight

Lens

Wide Notch

Wide Tab

Lens Guard

Steering Wheel

• Align the tab on the steering

wheel cap with the slot in the

center of the steering wheel.

• Fit the steering wheel cap into

the center of the steering wheel.

• Insert two #8 x 1" screws into the

steering wheel cap as shown.

• Tighten the screws with a Phillips

screwdriver. Do not over-tighten.

#8 x 1" Screw – 2

Shown Actual Size

Steering Wheel

Cap

• Face the front of the vehicle.

• Apply labels to the vehicle body

grille as shown. Make sure the

areas where the labels will be

applied are clean and dry. For

best adhesion, avoid applying

the labels more than once.

• Fit the lens tabs on the back of a

headlight lens assembly (assem-

bled in step 12) into the headlight

slots in the grille.

• Press firmly to snap the headlight

lens assembly into the grille.

• Repeat this procedure to snap

the other headlight lens assembly

into the grille.

Grille

Tabs

Assembly

Slots

Front Bumper

Tabs

• With the front bumper angled as

shown, insert the tabs on the

front bumper into the slots in the

bumper support.

• Push down on the bumper so it

lays flat on the bumper support.

Slots Bumper Support

Assembly

• Insert the long tabs on the top of

a turn signal lens into the slots in

the front of the vehicle body. The

long tabs are at the top of the

turn signal lens.

• Push firmly on the bottom of

the turn signal lens to snap the

bottom tabs into the vehicle

body.

• Repeat this procedure to attach

the other turn signal lens to the

vehicle body.

Turn Signal

Lens

• Insert two #8 x 3/4" screws into the

front bumper as shown.

• Tighten the screws with a Phillips

screwdriver. Do not over-tighten.

#8 x 3/4" Screw – 2

Shown Actual Size

• Insert a hood latch into one of

the holes in the vehicle body,

near the hood area.

• Twist the base of the hood latch

1/4turn to secure it in the vehicle

body.

• Repeat this procedure on the

other side of the hood area to

attach the other hood latch to

the vehicle body.

Hood Latch

Hole

Long

Tabs Long

Tabs

Assembly

• Rotate the windshield forward so

that the base of the windshield

lies flat against the dash.

• Insert two #8 x 1/2" screws into the

holes in the rear of the windshield

as shown .

• Tighten the screws with a Phillips

screwdriver. Make sure there is no

gap between the windshield and

the dash. Do not over-tighten the

screws.

• Insert four #8 x 1" screws into the

holes in the front of the wind-

shield .

• Tighten the screws with a Phillips

screwdriver. Do not over-tighten.

#8 x 1/2" Screw – 2

Slots

• Insert the tabs on the windshield

into the slots in the vehicle body.

Tabs

Hood

Tabs

• Position the hood over the front

of the vehicle body as shown.

• Insert the tabs on the hood into

the slots in the vehicle body.

• Close the hood.

Slot Slot

Windshield

#8 x 1" Screw – 4

Both Shown Actual Size

Assembly

• Turn the seat upside down.

• Insert the fastener end of a short

seat belt strap through the slot

near the outer edge of the seat.

Make sure the side of the seat

belt with the fastener faces the

outer edge of the seat.

• Pull the short seat belt strap com-

pletely through the slot until the

last T-loop at the opposite end of

the belt catches against the slot.

(You will pull one T-loop through

the slot.)

• Repeat this procedure to

assemble the other short seat

belt strap.

• Insert each fastener end of the

long seat belt strap through a slot

in the center of the seat. Make

sure the fasteners face the outer

edge of the seat.

• Pull each side of the long seat

belt strap evenly through the

slots. Make sure to pull each

T-loop through a slot.

• Turn the seat upright.

Short Seat Belt Strap

Fastener End

Seat

Slot

End

T-Loops

T-Loop

Fastener End

Long Seat Belt Strap

Slot

T-Loop (Pull through slot)

Assembly

• Position the sport bar on its side

so that the sport bar ends curve

away from you.

• Position the canopy opposite the

sport bar with the netting facing

away from you.

• Slide the four canopy sleeves

onto the sport bar, as shown.

Canopy Sleeves

Seat

Tabs

Seat

Back Tabs

Slot

2Tab

Notch in Body

Lock Fastener

BACK OF SEAT

PUSH

HERE

• With the seat at an angle, insert

the tabs on the front edge of the

seat into the slots in the foot-well

wall .

• Push down firmly on the edge of

the seat above each tab to snap

the tabs into the slots .

• Rotate the back of the seat

down to snap the seat back

tabs into the slots in the vehicle

body. Push down firmly on the

seat back.

Important Note: Make sure that the

tab on the lock fastener is aligned

with the notch in the vehicle body.

Canopy

Sleeves

Canopy

Sport Bar

Assembly

Sport Bar

• Extend the canopy completely

around the sport bar, as shown.

Sport Bar

Canopy

Light Rack - Back Half

Tabs

Light Rack - Front Half

• Position the sport bar upright, as

shown.

• Fit and hold the front and back

halves of the light rack against

the sport bar. Make sure the two

light rack halves are aligned, and

that the screw holes in the light

rack are aligned with the screw

holes in the canopy and the

sport bar.

• Snap the tabs on the front half of

the light rack into the slots below

the lights on the rear half of the

light rack.

• Insert two #6 x 11/2" screws

through the holes in the back of

the light rack, through the sport

bar, and into the front half of

the light rack.

• Tighten the screws with a Phillips

screwdriver. Do not over-tighten.

• Set the sport bar assembly aside

for assembly step 29.

#6 x 11/2" Screw – 2

Shown Actual Size

Assembly

• Fit the sport bar into the holes

in the vehicle body, as shown.

• Using safety scissors, remove

the sport bar brackets and sport

bar swivels from the plastic

connector. Dispose of the plastic

connector.

• Fit a swivel onto the long leg of a

sport bar support.

• Press the sport bar support firmly

into the swivel.

• Repeat this procedure to

assemble the other sport bar

support.

Swivel

Sport Bar Support

Long Leg

• Insert a sport bar support with

swivel (assembled in step 28)

through the tunnel in the rear

corner of the canopy and into

the hole in the vehicle body,

as shown.

• Repeat this procedure to attach

the other sport bar support and

the canopy to the vehicle body.

Swivel

Sport Bar

Support

Tunnel

Hole

Assembly

• Insert a #6 x 11/2" screw into the

sport bar bracket as shown.

• Tighten the screw with a Phillips

screwdriver. Do not over-tighten.

• Repeat step 31 on the other side

of the sport bar to attach the

other sport bar support tube.

#6 x 11/2" Screw – 2

Shown Actual Size

Sport Bar

Bracket

• Position a sport bar bracket

above the swivel on one of the

sport bar support tubes as shown.

• Insert the tab on the inside of the

sport bar bracket into the hole in

the sport bar.

• Fit the ball on the end of the swiv-

el against the end of the sport

bar bracket.

• Fold the sport bar bracket over

the sport bar to close it around

the sport bar and swivel ball.

Swivel

Tab

Assembly

PUSH HERE

Sport Bar

Support

PULL HERE

Side

Fender

• Push down firmly on one side of

the sport bar while pulling up on

the vehicle body side fender to fit

the sport bar completely into the

vehicle body.

• Repeat this procedure on the

other side of the sport bar.

• Insert a 1/4" x 11/2" machine screw

into the hole closest to the front

ot the vehicle in the underside of

the rear wheel well, through the

vehicle body and into the end of

the sport bar.

• Tighten the screw with a Phillips

screwdriver. Do not over-tighten.

• Repeat this procedure on the

other side of the vehicle.

1/4" x11/2" Screw – 2

Shown Actual Size

• Align the four tabs on the inside

of a light cover with the four slots

in one of the light housings on the

back half of the light rack.

• Push firmly on the light cover

to snap it to the light housing.

• Repeat this procedure on the

other side of the light rack to

assemble the other light.

Light Cover

Light Housing

Assembly

• Fit the tabs on the rear bumper

into the slots in the vehicle body.

• Push down on the rear bumper

to fit the holes in the rear bumper

onto the pegs on the vehicle

body.

Slots

Rear Bumper Tabs

Gas Cap Assembly

• Position the gas cap assembly so

that its tether points down.

• Snap the gas cap assembly

into the opening under the right

taillight.

Right Taillight

Gas Cap

Tether

• Using safety scissors, remove the

taillight lenses and the taillight

housings from the plastic connec-

tors. Dispose of the plastic con-

nectors.

• Face the rear of the vehicle.

• Fit a taillight lens inside a

taillight housing.

• Position the taillight housing with

lens against the vehicle body

with the screw holes aligned, as

shown.

• Insert two #8 x 1" screws through

the taillight lens and housing and

into the vehicle body as shown.

• Tighten the screws with a Phillips

screwdriver. Do not over-tighten.

• Repeat this procedure to attach

the other taillight.

#8 x 1" Screw – 4

Shown Actual Size

Taillight

Housing

Taillight

Lens

Assembly

Proper label application will help

to keep the labels looking their

best! Follow these helpful guidelines

when applying labels to your

vehicle.

– Wash your hands before applying

the labels.

– Make sure the areas where the

labels will be applied are clean

and dry. Wipe your vehicle with a

clean, soft, dry cloth to remove

any dust or oils.

– For best results, avoid applying a

label more than once.

– After applying a label, rub the

label firmly with a cloth to make

sure the label is adhered to your

vehicle.

Right Side View

Left Side View

456

Interior View Back View

24 26

Assembly

One-time assembly is now

complete.

IMPORTANT NOTES:

• Please carefully read the owner’s

information in this manual and

teach your child about proper

vehicle operation and rules for

safe driving before allowing

operation of this vehicle.

• For safety reasons, your vehicle

has been pre-assembled so that

it will only operate at low speed.

Make sure that your child can

safely operate this vehicle at

low speed before adjusting the

vehicle to run at high speed.

To disconnect high speed

lock-out, please see page 36.

• Apply labels to your vehicle as

shown in illustrations 1, 2, 3 and 4.

• After applying the labels as

shown in illustrations 1, 2, 3 and 4,

apply labels as shown in illustra-

tions 5, 6 and 7 to add sparkle to

your vehicle.

Right Side View

Left Side View

Back View

• Lift the seat back to access the

battery compartment.

6 Volt Battery Installation

Battery

Compartment

Power Wheels®

Type H Batteries • Place both Power Wheels®6 volt

batteries upright in the battery

compartment directly on top of

the molded-in battery informa-

tion. Make sure the battery

connectors extend toward the

rear of the vehicle.

• Make sure a Power Wheels®

30 amp fuse in good condition

is installed in each of the 6 volt

batteries and that the battery

connectors are snapped

together.

Important Note: Use only Power Wheels®Type H (9.5 Amp/hr.) batteries with Power Wheels®30

amp fuses installed. Use of any other 6 volt batteries or fuses may damage your vehicle. Make

sure that you charge the 6 volt batteries for at least 18 hours before operating your vehicle for

the first time. After first-time use, charge the 6 volt batteries for at least 14 hours after each use.

Never charge the 6 volt batteries longer than 30 hours. Failure to follow these instructions may

damage your 6 volt batteries and will void your warranty.

Seat Back

Power Wheels®

30 Amp Fuses

Battery Connectors

• Position the battery retainer over

the batteries with the ends of the

battery retainer aligned with the

screw holes in the bottom of the

battery compartment.

• Insert two #8 x 3/4" screws through

the battery retainer and into the

battery compartment.

• Tighten the screws with a Phillips

screwdriver. Do not over-tighten.

Battery Retainer

#8 x 3/4" Screw – 2

Shown Actual Size

Batteries

Rear of Vehicle

Canopy Not Shown

6 Volt Battery Installation

• Lower the seat back. Make sure

the tabs on the front of the seat

are inserted into the slots in the

vehicle body.

Note: Make sure that the tabs on

the lock fastener are aligned with

the notches in the lock fastener

opening.

• Push down firmly on the seat

back to snap the seat into the

vehicle body.

• Rotate the lock fastener 1/4turn

using a slotted screwdriver to lock

the battery compartment.

• Lift the seat back to make sure

the lock fastener is in the locked

position. Keep the lock fastener in

the locked position at all times to

prevent children from accessing

the batteries.

• Squeeze the tabs on each side

of the motor harness connector.

• Plug the battery connector into

the motor harness connector.

Note: If the battery connector will

not plug into the motor harness

connector, turn it over and try

again! Do not force the battery

connector into the motor harness

connector.

Motor Harness

Connector

Battery Connector

Lock Fastener

Opening

Top of Seat

Top View

Canopy Not Shown

Charging the 6 Volt Batteries

WARNING

• Batteries must be handled by adults only.

• Never allow children to charge the 6 volt batteries. Battery

charging must be done by adults only. A child could be

injured by the electricity involved in charging batteries.

• Use of the wrong type of battery, fuse or charger could

cause a fire or explosion, resulting in serious injury.

• Never permit a child to handle batteries. The 6 volt

batteries are heavy and contain sulfuric acid (electrolyte),

and if dropped could result in serious injury. Read the

cautions on the back panel of the 6 volt battery.

• Never lift or carry the 6 volt batteries by the wires or

connectors. This can damage the 6 volt batteries and

possibly cause a fire. Lift and carry the 6 volt batteries by

the cases only.

• Examine the 6 volt batteries, charger and their connectors

for excessive wear or damage each time you charge the

6 volt batteries. If damage or excessive wear is detected,

do not use the vehicle until you have replaced the worn or

damaged parts, as it could possibly cause a fire resulting

in injury.

• Never alter this vehicle or its electrical system in any way.

Alterations could cause a fire resulting in injury and could

also ruin the electrical system.

CAUTION

• Carefully read the Battery Care instructions to obtain the best

battery life. Failure to follow the Battery Care instructions may

permanently damage your 6 volt batteries and will void your

warranty.

• Use the charger indoors only.

• Squeeze the tabs on the motor

harness connector to unplug it

from the battery connector.

• Squeeze the tabs on the charger

connector to plug it into the

battery connector .

• Plug the charger into a standard

120 volt wall outlet .

Note: If power to the outlet is

controlled by a wall switch, make

sure the switch is “ON”.

• Charge the 6 volt batteries a

minimum of 14 hours after each

use. Never charge the 6 volt

batteries longer than 30 hours.

Overcharging or undercharging

the 6 volt batteries may shorten

battery life and decrease vehicle

running time.

• Once the 6 volt batteries are

charged, reconnect the battery

connector and motor harness

connector and lower the seat

back.

Note: Remember to lock the lock

fastener to prevent children from

accessing the 6 volt batteries.

Charging the 6 Volt Batteries

IMPORTANT

A 25 AMP FUSE MUST

BE INSTALLED IN TOP

OF BATTERY BEFORE

TOY WILL RECHARGE

OR OPERATE

IMPORTANT

A 25 AMP FUSE MUST

BE INSTALLED IN TOP

OF BATTERY BEFORE

TOY WILL RECHARGE

OR OPERATE

• Rotate the lock fastener on the

seat back 1/4turn using a slotted

screwdriver to unlock the battery

compartment.

• Lift the seat to access the 6 volt

batteries.

• Use pliers to remove the fuses

from the 6 volt batteries.

• Look at each fuse to make sure

it is not blown. If a fuse has

blown, replace it with a new

Power Wheels®30 amp fuse.

• Re-insert the fuses into the 6 volt

batteries before charging. The

6 volt batteries will not charge if

a 30 amp fuse in good condition

is not inserted into each 6 volt

battery.

GOOD FUSE "BLOWN" FUSE

Motor Harness Connector

Battery Connector

Important Note: The 6 volt batteries must be upright while charging. You do not have to

remove the 6 volt batteries from the vehicle to charge them.

Canopy Not Shown

Battery Handling/Care/Disposal

WARNING

•

Batteries must be handled by adults only.

• Never permit a child to handle batteries.

The 6 volt batteries are heavy and contain

sulfuric acid (electrolyte), and if dropped,

could result in a serious injury. Read the

cautions on the back panel of the 6 volt

battery.

• Never lift or carry the 6 volt batteries by

the wires or connectors. This can damage

the 6 volt batteries and possibly cause a

fire. Lift and carry the 6 volt batteries by

the case only.

Handling

If a battery leak develops:

• Avoid contact with the leaking acid.

• Place the damaged battery in a plastic bag. See

information below for proper disposal.

If acid comes in contact with skin or eyes:

• Flush with cool water for at least 15 minutes.

• Call a physician.

If acid is internally ingested:

• Give water, milk of magnesia or egg whites

immediately.

• Never give emetics or induce vomiting.

• Call a physician.

Disposal

• Sealed lead-acid batteries must be collected,

recycled or disposed of in an environmentally sound

manner.

• Do not dispose of lead-acid batteries in your regular,

household trash. The incineration, landfilling or mixing

of sealed lead-acid batteries with household trash is

prohibited by law in most areas.

• Return the batteries to a federal or state approved

lead-acid battery recycler, such as a Power Wheels®

Authorized Service Center or a local seller of

automotive batteries. In Minnesota, call

1-800-348-0751 if further disposal information is

required. Contact your local waste management

officials for other information regarding the

environmentally sound collection, recycling and

disposal of lead-acid batteries.

CAUTION

• Carefully read the Battery Care instructions

to obtain the best battery life. Failure to

follow the Battery Care instructions may

damage your 6 volt batteries and will void

your warranty.

Care

•Charge new 6 volt batteries for at least 18 hours

before first use. Never charge the 6 volt batteries

longer than 30 hours. Overcharging or undercharg-

ing the 6 volt batteries may shorten battery life and

decrease vehicle running time.

• After the first charge, charge the 6 volt batteries

for at least 14 hours after each use. Never charge

the 6 volt batteries longer than 30 hours.

•Charge the 6 volt batteries after each use, regard-

less of how long the vehicle was used.

• The 6 volt batteries must be upright while charging.

•Do not allow the 6 volt batteries to run down

completely before charging.

• Charge the 6 volt batteries before storing the

vehicle.

• Charge the 6 volt batteries at least once per month,

even if the vehicle has not been used.

• Leaving the 6 volt batteries in a discharged

condition will ruin them.

•Do not store 6 volt batteries in temperatures above

75° F or below -10° F.

•Prevent the 6 volt batteries from moving freely inside

the battery compartment. Always use the battery

retainer to secure the 6 volt batteries in the battery

compartment.

•Examine the 6 volt batteries, charger and their

connectors for excessive wear or damage each

time you charge the 6 volt batteries. If damage is

detected, do not use the charger or the 6 volt

batteries until you have replaced the worn or

damaged part.

• Attempting to charge the 6 volt batteries without

fuses or with blown fuses will not damage the 6 volt

batteries, but they will not charge. Check the fuses

to make sure they are in good condition each time

you charge the 6 volt batteries.

• Adult supervision is required. Children

do not have the judgement necessary to

avoid many accidents. Be sure that

children operating this vehicle can do so

safely and that they are supervised at all

times.

• Never use near steps, driveways, steep

inclines, roadways, alleys, swimming pool

areas or other bodies of water.

• Always wear shoes or sneakers when

operating or riding in this vehicle.

• Never allow more than two riders; one

driver and one passenger.

• Riders should sit on the seat when the

vehicle is in operation.

• Improper use of this vehicle could lead to

a serious or fatal accident. Allow children

to play with this vehicle only when you have

determined that they can do so safely.

Follow all instructions to help your child

enjoy this vehicle as safely as possible.

Teach Safety Rules to Children

While children can quickly develop the skill necessary

to drive this vehicle, it is important to remember

that their judgment skills are still very immature.

Unsupervised driving by children can lead to serious

injury. Before children use the vehicle, an adult should

carefully evaluate the driving area as well as the chil-

dren’s skill level and ability to drive this vehicle

safely.Children are not always able to recognize or

anticipate hazards, even when they have been

taught about them. There is no acceptable

substitute for adult supervision.

Teach appropriate safety rules to your child before

you allow operation of this vehicle. These rules should

also be reviewed with neighborhood children or other

playmates who want to drive or ride in this vehicle.

• To avoid damaging motors and gears, do

not overload the vehicle.

- Never allow more than two children in the

vehicle at one time; one driver and one

passenger.

- Do not exceed the maximum weight

capacity of 130 lbs.

- Do not tow anything behind this vehicle.

The extra weight may overload the

vehicle.

• Avoid operating the vehicle in wet or snowy

conditions, and do not spray the vehicle

with a hose. Do not wash the vehicle with

soap and water. Water or moisture in the

motors or electrical switches can cause

them to corrode, and could cause switch

failure.

• Avoid operating the vehicle on sand, loose

dirt or gravel. Sand, loose dirt and gravel in

the electrical switches or motors can cause

them to jam, and could cause switch fail-

ure. Use this vehicle on grass, asphalt or

other hard surfaces.

1. Do not allow any child to drive the vehicle in the

street or near moving (motorized) vehicles.

2. Do not allow any child to drive near bodies of

water (such as pools or creeks), obstructions (such

as furniture, low tree limbs or play equipment), or

drop-offs (such as stairs or decks).

3. Do not allow any child to drive the vehicle in

the dark. A child could encounter unexpected

obstacles and have an accident. Operate the

vehicle only in the daytime or in a well-lit area.

4. Teach your child to avoid driving on steep inclines

or slopes. Restrict your child’s driving to areas that

are fairly level with gentle inclines or slopes of no

more than 10°.

• While driving down a steep slope, the vehicle

may gain unsafe speed, even if the foot pedal is

released to stop.

WARNING CAUTION

Rules for Safe Driving

10°

Incline should never be

more than 10°

• While driving across a steep slope, the vehicle

may tilt and tip over. The wheels could lose

traction, causing the vehicle to slip.

•While driving up a steep incline, the motor may

stop and the vehicle could roll backwards at an

unsafe speed.

8. Do not operate the vehicle near flammable vapors

(gasoline, paint thinner, acetone, liquid wax, etc.).

The vehicle’s electrical switches, like most electrical

switches, emit an internal spark when first turned on

and when turned off. The presence of flammable

liquids or vapors could cause an explosion or a fire.

Keep all flammable products in tightly sealed

containers and away from the vehicle.

9. Do not allow a child to operate the vehicle

without proper adult supervision. To prevent

unsupervised use of the vehicle, disconnect the

motor harness from the batteries.

• Rotate the lock fastener 1

4turn with a slotted

screwdriver to unlock the battery compartment.

• Raise the seat to access the batteries.

• Squeeze the tabs on the motor harness

connector to unplug the battery connector from

the motor harness connector.

• Lower the seat and rotate the lock fastener

4turn with a slotted screwdriver to lock the

battery compartment.

5. Operate this vehicle with no more than two

riders; one driver and one passenger in the seating

area. Children who are not sitting on the seat or

who are standing on the vehicle could fall off,

cause a tip-over or block the driver’s view. A child

could be seriously injured.

6. Always wear shoes or sneakers when operating or

riding in this vehicle.

7. Never put anything near any moving parts.

Rotating parts such as motors, gear boxes and

wheels can snag fingers, hair, etc., causing serious

injury. Do not allow operation of the vehicle when it

is on its side or in an upside-down position.

Motor Harness

Connector

Battery Connector

Canopy Not Shown

How to Operate your Vehicle

Beginner Drivers:

Low Speed Forward

To Drive

• Make sure the shifter is in the

LOW ( ) position .

• Press down on the foot pedal .

The vehicle goes forward at a

maximum of 21/2mph .

• Help your child practice steering

to learn how far and how quickly

to turn the steering wheel when

driving forward in low speed.

To Stop

• You vehicle has a patented,

electronic braking system that

automatically stops the vehicle

when your child’s foot is lifted

from the pedal.

• Have your child practice to

become familiar with low speed

forward and automatically know

how to stop.

To help your child develop the skill necessary to drive this vehicle safely, your Power Wheels® vehicle

has been pre-assembled so that it will only operate in low speed (21/2mph, maximum). After your

child has mastered the basic skills of driving and understands the rules for safe driving, it’s time to

disconnect the high-speed lock-out to allow the vehicle to operate at low (21/2mph, maximum) or

high speed (5 mph, maximum). See the instructions below to disconnect the high-speed lock-out.

Experienced Drivers:

High Speed Forward

To disconnect the

High-Speed Lock-Out

• Before you disconnect the high

speed lock-out, make sure your

child:

• Knows how to start and stop

the vehicle easily in low speed.

• Knows how to steer.

• Knows the safety rules well.

• Rotate the lock fastener 1/4turn

with a slotted screwdriver to

unlock the battery compartment.

• Raise the seat to access the

lock-out pin.

• Pull the lock-out pin out of the

shifter box.

• Re-install the seat. Remember to

lock the lock fastener to prevent

children from accessing the 6 volt

batteries.

• You can re-insert the lock-out pin

into the shifter box if you want to

lock out high speed and allow

operation of the vehicle in low

speed only.

Lock-out Pin

Shifter Box

Seat

Rear of Vehicle

How to Operate your Vehicle

To Drive:

Note: To prevent damage to the

motors, stop the vehicle before

shifting speeds.

• Make sure the shifter is in the

HIGH ( ) position .

• Press down on the foot pedal .

The vehicle goes forward at a

maximum of 5 mph .

• Help your child practice steering

to learn how far and how quickly

to turn the steering wheel when

driving forward in high speed.

To Stop:

• Stopping in high speed is the

same as stopping in low speed.

The vehicle automatically stops

when your child’s foot is lifted

from the pedal.

Reverse

Note: To prevent damage to the

motors, stop the vehicle before

shifting from forward (LOW or

HIGH ) to reverse.

• Once your child is completely

comfortable with operating the

vehicle in the forward mode

(LOW or HIGH speed),

introduce reverse ( ).

To Back Up

• Make sure the shifter is in the

reverse ( ) position .

• Press down on the foot pedal .

The vehicle will go in reverse at a

maximum of 21/2 mph .

• Help your child practice steering

to learn how far and how quickly

to turn the steering wheel when

backing up.

Frequently Asked Questions

Q. How often do I need to charge the 6 volt batteries?

Charge the 6 volt batteries for a minimum of 14 hours after each use of the vehicle or whenever the vehicle

begins to slow down. When the vehicle is not in regular use, charge the 6 volt batteries at least once a

month until normal use is resumed.

Q. How much riding time should I get after charging the 6 volt batteries?

You should get from one to three hours of riding time per charge. The riding time is affected by:

•the driving surface,

•passenger weight,

•the charge of the 6 volt batteries,

•whether the vehicle is used intermittently or continuously,

• condition of the electrical switches and connectors,

• whether the vehicle is used in low or high speed,

• the temperature.

Q. What is the life expectancy of the 6 volt batteries?

The life of the batteries will vary depending on how well you follow the Charging and Battery Care

instructions. It’s also affected by the total number of hours the 6 volt batteries are used. Average battery life

is one to three years.

Q. Do the fuses have to be inserted into the 6 volt batteries when I’m charging?

Yes! The 6 volt batteries must have good fuses installed when charging and during use. If the fuses are

missing, blown or if you are using the wrong type of fuse, the 6 volt batteries will not charge.

Q. How can I tell if the fuses are blown?

Use pliers to remove the fuses from the 6 volt batteries and compare the fuses to the illustration on page 32.

Q. How can I tell if the charger is working?

There is no sure way to tell if your charger is working unless you have a volt meter. If you suspect there is a

problem with your charger, contact your local Power Wheels®Authorized Service Center. They can test your

charger for you.

Q. How and when should I store my vehicle?

During snowy or rainy weather, the vehicle should be stored inside or under a protective cover. Remember

to charge the 6 volt batteries at least once per month while your vehicle is not in regular use.

Q. How should I care for my vehicle?

The vehicle can be wiped down with a soft, dry cloth. For a shiny finish, you can wipe plastic parts with a

non-wax furniture polish applied to a soft-cloth. Do not use automotive wax. Do not use soap and water or

spray the vehicle with a hose. Check all nuts, bolts, and their protective coverings regularly and tighten as

required. Check plastic parts on a regular basis for cracks or broken pieces.

To ensure that your vehicle stays in good operating order, we recommend that you periodically have your

vehicle checked by a Power Wheels®Authorized Service Center. See page 43 for the list of Authorized

Service Centers or call 1-800-348-0751 for the location of the Authorized Service Center nearest you.

Q. If I have a problem that I can’t solve myself, what should I do?

Power Wheels®has over 300 Authorized Service Center locations. They can repair vehicles under warranty,

or out of warranty, or sell you the proper parts for you to do the repair work. These service centers have

factory-trained personnel, and use only genuine Power Wheels®replacement parts. If there is not an

Authorized Service Center in your area, please call Power Wheels®Consumer Affairs toll-free at:

1-800-348-0751.

Problems and Solutions Guide

Problem Possible Cause Solution

Vehicle does not run Undercharged 6 volt batteries Charge the 6 volt batteries. New 6 volt batteries should

have been charged for at least 18 hours before using the

vehicle for the first time. After first-time use, recharge 6 volt

batteries for at least 14 hours after each use. Never charge

the 6 volt batteries longer than 30 hours.

Check all connectors. Make sure the battery connector is

tightly plugged into the charger connector, and that the

charger is plugged into the wall.

Make sure power flow to the wall outlet is “ON”.

Wrong type or improperly installed fuse Make sure that each 6 volt battery has a properly installed

Power Wheels®30 amp fuse before charging. For best

performance, do not use substitute parts.

Blown fuses Make sure that the fuses in the 6 volt batteries are in good

condition. Replace blown fuses with Power Wheels®

30 amp fuses. For best performance, do not use

substitute parts.

Loose wire or loose connectors Check all wires and connectors. Make sure the battery

connector is tightly plugged into the motor harness

connector, and that there are no loose wires around the

motors.

Dead 6 volt batteries If your 6 volt batteries are old or if you have not followed

Battery Care instructions, your 6 volt batteries may be dead.

If you are unsure whether or not the 6 volt batteries are

dead, you can have them tested at your local Power

Wheels®Authorized Service Center.

If one or both 6 volt batteries are dead, replace BOTH 6 volt

batteries with new Power Wheels®Type H 6 volt batteries.

(Use of a new 6 volt battery with an older 6 volt battery may

cause permanent damage to both 6 volt batteries.) For best

performance, do not use substitute parts.

Electrical switch damage The electrical switches can become corroded due to

exposure to water or moisture, or can jam due to loose dirt,

sand or gravel. Contact your local Power Wheels®

Authorized Service Center for diagnosis and repair.

Motor damage Contact you local Power Wheels®Authorized Service Center

for diagnosis and repair.

IMPORTANT! If you experience a problem with your vehicle, first check the Problems and

Solutions Guide below. If you still experience a problem, please contact Power Wheels ®

Consumer Affairs, toll-free at 1-800-348-0751 between 8 AM and 6 PM (EST) Monday through

Friday. Or, contact your local Power Wheels®Authorized Service Center. For the location

nearest you, please refer to the Authorized Service Center list beginning on page 43.

Vehicle was running but Loose wire or loose connectors Check all wires and connectors. Make sure the battery

suddenly stopped connector is tightly plugged into the motor harness

connector, and that there are no loose wires around the

motors.

Wrong type or improperly installed fuse Make sure that each 6 volt battery has a properly installed

Power Wheels®30 amp fuse installed before charging.

For best performance, do not use substitute parts.

Blown fuses Make sure that the fuses in the 6 volt batteries are in good

condition. Replace blown fuses with Power Wheels®

30 amp fuses. For best performance, do not use

substitute parts.

Vehicle is overloaded Make sure you do not overload the vehicle by allowing

more than 2 riders at one time, by exceeding the 130 lbs.

maximum weight capacity, or by towing objects behind the

vehicle. If the vehicle is overloaded, it will automatically

shut down. The vehicle will reset itself after approximately

20 seconds. Reduce the load on the vehicle to prevent

additional automatic shut-downs.

Driving conditions are too stressful Use only on gentle inclines or slopes of 10˚ or less. Extreme

temperatures can also affect run time. If the driving

conditions are too stressful, the vehicle will automatically

shut down. The vehicle will reset itself after approximately

20 seconds. Adjust the driving conditions to prevent

additional automatic shut-downs.

Short run time (Less than 1 hour Undercharged 6 volt batteries Charge the 6 volt batteries. New 6 volt batteries should have

in high speed; less than been charged for at least 18 hours before using the vehicle

3 hours in low speed) for the first time. After first-time use, recharge 6 volt

batteries for at least 14 hours after each use. Never charge

the 6 volt batteries longer than 30 hours.

Check all wires and connectors. Make sure the battery

connector is tightly plugged into the charger connector,

and that the charger is plugged into the wall.

Make sure power flow to the wall outlet is “ON”.

Overcharged 6 volt batteries Do not charge the 6 volt batteries longer than 30 hours. If

you suspect that your 6 volt batteries are damaged as a

result of overcharging, contact your local Power Wheels®

Authorized Service Center. They can test your 6 volt

batteries for you.

6 volt batteries are old and will not Even with proper care, rechargeable batteries do not

accept full charge last forever. Average 6 volt battery life is 1 to 3 years

depending on vehicle use and use conditions. Always

replace 6 volt batteries as a set; use of an older 6 volt

battery with a new 6 volt battery may cause permanent

damage to both 6 volt batteries. Replace BOTH 6 volt

batteries with Power Wheels®Type H 6 volt batteries.

For best performance, do not use substitute parts.

Wrong type or improperly installed fuse Make sure that each 6 volt battery has a properly installed

Power Wheels®30 amp fuse installed before charging.

For best performance, do not use substitute parts.

Driving conditions are too stressful Use only on gentle inclines or slopes of 10˚ or less. Extreme

temperatures can also affect run time. If the driving

conditions are too stressful, the vehicle will automatically

shut down. The vehicle will reset itself after approximately

20 seconds. Adjust the driving conditions to prevent

additional automatic shut-downs.

Problems and Solutions Guide

Problem Possible Cause Solution

Vehicle runs sluggishly Undercharged 6 volt batteries Charge the 6 volt batteries. New 6 volt batteries should have

been charged for at least 18 hours before using the vehicle

for the first time. After first-time use, recharge 6 volt batteries

for at least 14 hours after each use. Never charge the 6 volt

batteries longer than 30 hours.

Check all connectors. Make sure the battery connector is

tightly plugged into the charger connector, and that the

charger is plugged into the wall.

Make sure power flow to the wall outlet is “ON”.

6 volt batteries need charging After approximately 1 hour of constant use in high speed

or 3 hours of constant use in low speed, the 6 volt batteries

need charging.

Wrong type or improperly installed fuse Make sure that each battery has a properly installed

Power Wheels®30 amp fuse installed before charging. For

best performance, do not use substitute parts.

6 volt batteries are old and will not accept Even with proper care, rechargeable batteries do not last

full charge forever. Average battery life is 1 to 3 years depending on

the vehicle use and use conditions. Always replace 6 volt

batteries as a set; use of an older 6 volt battery with a

new 6 volt battery may cause permanent damage to both

6 volt batteries. Replace BOTH 6 volt batteries with

Power Wheels®Type H 6 volt batteries. For best

performance, do not use substitute parts.

Vehicle is overloaded Make sure you do not overload the vehicle by allowing

more than 2 riders at one time, exceeding the 130 lbs.

maximum weight capacity, or by towing objects behind the

vehicle. If the vehicle is overloaded, it will automatically

shut down. The vehicle will reset itself after approximately

20 seconds. Reduce the load on the vehicle to prevent

additional automatic shut-downs.

Driving conditions are too stressful Use only on gentle inclines or slopes of 10˚ or less. Extreme

temperatures can also affect run time. If the driving

conditions are too stressful, the vehicle will automatically

shut down. The vehicle will reset itself after approximately

20 seconds. Adjust the driving conditions to prevent

additional automatic shut-downs.

Vehicle runs in low speed, but High speed lock-out not disconnected The vehicle was pre-assembled to run only in low speed.

does not run in high speed To allow the vehicle to run in low and high speed, you

must disconnect the High Speed Lock-Out. Follow the

(Please Note: The vehicle is instructions on page 36 to disconnect the High Speed

designed to operate in low Lock-Out.

speed only in reverse (REV).)

When the foot pedal is pressed, Operation of vehicle in low speed It is possible that only one rear wheel may spin when both-

only one rear wheel turns with both rear wheels off the ground rear wheels are raised off the ground and the vehicle is in

low speed. This does not necessarily indicate a problem.

Check for proper operation of the drive system by raising

the rear wheels off the ground and pressing the foot pedal.

If only one rear wheel spins, carefully press your hand on

the spinning wheel to slow it down. The other rear wheel

should begin to spin. If the other rear wheel does not begin

to spin, there may be a problem with the vehicle. Contact

your local Power Wheels® Authorized Service Center for

diagnosis and repair.

Problems and Solutions Guide

Problem Possible Cause Solution

Sometimes the vehicle doesn’t Loose wire or connector Check all wires around the motors and all connectors to

run, but other times it does make sure they are tight.

Motor or electrical switch damage Contact your local Power Wheels®Authorized Service

Center for diagnosis and repair.

When the foot pedal is pressed, Loose wire or connector Check all wires around the motors and all connectors

the vehicle won’t run without to make sure they are tight.

a push

“Dead Spot” on motor Contact your local Power Wheels®Authorized Service

Center for diagnosis and repair.

Vehicle constantly blows fuses Wrong type of fuse used This vehicle requires two Power Wheels®30 amp

fuses, one in each 6 volt battery. Make sure Power Wheels®

30 amp fuses are properly installed in the 6 volt batteries.

For best performance, do not use substitute parts.

Child is switching speeds or switching Teach your child to stop the vehicle before switching

from forward (LOW or HIGH ) speeds and before switching from forward to reverse.

to reverse ( ) without stopping

Replace blown fuses with Power Wheels®30 amp fuses.

For best performance, do not use substitute parts.

Loud clacking or grinding Broken gears Contact your local Power Wheels®Authorized Service

noise from a motor-gearbox Center for diagnosis and repair.

Charger gets warm during use It is normal for some chargers to get No action required.

warm during use and is not reason

for concern. Some chargers do not If your charger does not get warm during

get warm during use. use, it does not mean that it is not

working properly.

6 volt batteries make a sizzling It is normal for some 6 volt batteries to No action required.

or gurgling noise when charging make noise and swell slightly while

charging and is not reason for If your 6 volt batteries do not make noise or swell slightly

concern. Some 6 volt batteries do not during charging, it does not mean that they are not

make noise or swell while charging. accepting the charge.

Problems and Solutions Guide

If, after reviewing the Problems and Solutions Guide, the vehicle still fails to operate, please contact your nearest

Authorized Service Center (see page 43) or contact Power Wheels Consumer Affairs toll-free at 1-800-348-0751.

Helpful Hint: For faster service when calling Consumer Affairs, completely charge the batteries before calling and

have the following available by the phone:

• vehicle,

• vehicle model number (see sticker in battery compartment),

• vehicle production run number (see sticker in battery compartment),

• Phillips screwdriver, slotted screwdriver and needle-nose pliers with plastic or rubber handles,

• extra Power Wheels®30 amp fuses are helpful.

Statement of Limited Warranty

90-day limited warranty for the Power

Wheels®Ride-On Toy Vehicle

A 6-month battery warranty applying only to

those 6 volt batteries which were included

by Power Wheels®, with the Power Wheels®

vehicle when originally purchased.

This limited warranty covers the Power Wheels®

ride-on vehicle and the 6 volt batteries, purchased

from Power Wheels®by the original purchaser, against

defects in materials and workmanship.

This warranty covers normal use and does not cover

the Power Wheels®vehicle or batteries if damaged by

unreasonable use, neglect, accident, abuse, misuse,

improper service or other causes not arising out of

defects in materials or workmanship. Evidence of any

attempt at consumer repair will void this warranty. This

warranty does not cover, and is intended to exclude,

any liability on the part of Power Wheels®, whether

under this warranty or implied by law or any indirect or

consequential damages for breach of warranty.

Some states do not allow the exclusion or limitation so

this limitation may not apply to you.

Should you need service or assistance with your

vehicle during the warranty period, DO NOT RETURN

THE VEHICLE TO THE STORE. Power Wheels®has

provided a nationwide network of Authorized Service

Centers. Please refer to the list in this manual. Power

Wheels®is continually expanding our Authorized

Service Center network. If there is not an Authorized

Service Center in your area, please call Consumer

Affairs for information, 1-800-348-0751.

This warranty gives you specific legal rights, and you

may also have other rights which may vary from state

to state.

PLEASE SAVE YOUR ORIGINAL SALES RECEIPT.

Authorized Service Centers

We are continually expanding our Authorized Service Center Network. Please check this listing

for the Authorized Service Center nearest you. If there is not one in your area, please call Power

Wheels®Consumer Affairs at 1-800-348-0751.

ALABAMA

BIRMINGHAM - Frigid Service & Sales,

701 Graymont Ave. North, 35203, (205) 323-5831

BIRMINGHAM - Frigid Service & Sales,

1861 Centerpoint Rd., 35215, (205) 853-3952

BIRMINGHAM (HOMEWOOD) - D & R Appliance

Company, 154 West Valley Ave., 35209, (205) 942-3959

CULLMAN - Robert G. Werner Company,

1115 4th Street S.W., 35055, (205) 734-5673

DECATUR - Peddler II, 1000 B Beltline Road, 35603,

(205) 350-1044

DOTHAN - Bill’s Appliance Service, 208 Bic Road,

P.O. Box 1192, 36303, (334) 792-7746

DOUGLAS - Brown Hardware, Highway 75, 35964,

(205) 593-6086

HUNTSVILLE - C & G Appliance, 307 Jordan Lane, 35805,

(205) 837-4551

MOBILE - Foster’s Appliance Repair, 1660 South Beltline

Highway, 36693, (334) 666-2670

MONTGOMERY - Acme Service Co., 2603 Highland Ave.,

36107, (205) 264-2456, (800) 285-2160

TUSCALOOSA (NORTHPORT) - Frigid Service & Sales,

2813 Lurleen B. Wallace Blvd., 35476, (205) 339-3624

ALASKA

ANCHORAGE - Ken’s Electronics Service, 360 E. Inter-

national, Ste. 8, 99518, (907) 562-3443

ARIZONA

GLENDALE - Elliott Electric Appliance Service,

6242 N. 43rd Avenue, 85301, (602) 937-2613

SCOTTSDALE - Elliott Electric, 7515 E. McDowell Road,

85257, (602) 946-7487

ARKANSAS

FT. SMITH - Bromley Appliance Service, 614 North 10th

Street, 72901, (501) 782-9646

HOT SPRINGS, The Battery Center, 400 Airport Road,

71913, (501) 624-7144

JONESBORO - Best Sewing & Vacuum & Repair, 2235

S. Caraway Road, 72401, (501) 935-4739, (800) 844-4739

LITTLE ROCK - C & W Tool Repair, 1303 W. Markham,

72201, (501) 374-1911

MENA - Bearcat Starter & Alt., 801 Petros,71953,

(501) 394-0320

ROGERS - Kressel’s Vacuum & Repair, 115 North 5th

Street, 72756, (501) 636-7894

STUTTGART - Davis Lumber Company, 301 East

Michigan, 72160, (501) 673-3601

CALIFORNIA

ANDERSON - Hardware Express/ Do It Best, 2681 Balls

Ferry Road, 96007, (916) 365-3783

BAKERSFIELD - Southwest TV, 6300 White Lane,

Suite B, 93309, (805) 397-4940

CONCORD - California Electric Service Center, 1170-G

Burnett Avenue, 94520, (510) 827-1011

COVINA - California Electric Service Center, 612 Shoppers

Lane, 91723, (818) 915-4935

DUBLIN - California Electric Service, 8947 San Ramon

Road, 94568, (510) 551-3390

FONTANA - California Electric Service Center, 9794 Sierra

Avenue, 92335, (909) 355-2500

FORT JONES - Ft. Jones Frontier Hardware,11911 Main

Street, 96032, (916) 468-2266

FRESNO - Valley Small Appliance, 4005 E. Ashlan Avenue,

93726, (209) 224-5530

FULLERTON - California Electric Service Center, 1208

E. Ash Avenue, 92631-5020, (714) 870-0900

LOS ALAMITOS - California Electric Service Center,

11284 Los Alamitos Blvd., 90720, (310) 430-2668

MERCED - Moosehead Electronics, 920 W. 18th Street,

95340, (209) 723-4712

MISSION VIEJO - California Electric Service Center, 23725

Via Fabricante, Unit B, 92691, (714) 586-9440

OAKLAND - California Electric Service Center, 1139

E. 12th Street, 94606, (510) 834-1050

OXNARD - Terry’s Inc., The Clean-up Store, 1237 Saviers

Road, 93033, (805) 487-9401, (800) 845-3223

PASADENA - California Electric Service Center, 2594

E. Colorado Blvd., 91107, (818) 792-3194

SACRAMENTO - California Electric Service Center,

1821 “Q” Street, 95814, (916) 443-5711

SAN CARLOS - California Electric Service Center, 990

Industrial Road, Suite 102, 94070, (415) 593-6696

SAN DIEGO - California Electric Service Center, 3430

El Cajon Blvd., 92104, (619) 283-6488

SAN FRANCISCO - California Electric Service Center,

1090 Bryant Street, 94103, (415) 431-8494

SAN JOSE - California Electric Service Center, 783

The Alameda, 95126, (408) 295-1723

SANTA ANA - California Electric Service Center, 2025

South Main Street, 92707, (714) 641-0529

SANTA ROSA - Hardisty’s Inc., 710 Farmers Lane, 95405,

(707) 545-0535

STOCKTON - California Electronics, 929 North Yosemite

Street, 95203, (209) 466-5432

Authorized Service Centers

TEMECULA - California Electric Service Center, 41715

Enterprise Circle North, Suite 101, 92590, (909) 695-5445

VAN NUYS - California Electric Service Center, 14753

Oxnard Blvd., 91411, (818) 997-8855

WEST LOS ANGELES - California Electric Service Center,

2314 S. Westwood Blvd., 90064, (310) 475-2532

YUCAIPA - Aire-Rite Heating & A/C, 34724 Yucaipa Blvd.,

92399, (909) 797-2788

COLORADO

AURORA - Appliance Service, 2295 So. Chambers Road,

Unit F, 80014, (303) 369-6651

COLORADO SPRINGS - Nelson Appliance Repair, Inc.,

1220 E. Fillmore, 80907, (719) 635-1928, (800) 291-8010

DENVER - Appliance Service, 4262 Lowell Blvd., 80211,

(303) 458-1109, (800) 631-0941 (CO, WY only)

DENVER (ENGLEWOOD) - Appliance Service, 3932

S. Broadway, 80110, (303) 781-1227, (800) 553-1864

GRAND JUNCTION - V & L Appliance Service, 809

North Avenue, 81501, (970) 243-3360

CONNECTICUT

HARTFORD - Hartford Element & Appliance Service, 1500

Albany Avenue, 06112, (860) 246-7424, (800) 787-7977

NEW HAVEN (HAMDEN) - New Haven Appliance Service

Center, 1627 Dixwell Avenue, 06514, (203) 288-6229

SHELTON - Jeff’s Appliance, Inc., 500A Howe Avenue,

06484, (203) 924-8997

STAMFORD - Appliance Servicenter of Stamford,

15 Cedar Heights Road, 06905, (203) 322-7656

WATERBURY - P.J. Appliance Repair, 935 South Main

Street, 06706, (203) 757-1014

DELAWARE

DOVER - Del-Mar Appliance of Delaware, 230 South

Governors Avenue, 19904, (302) 674-2414, (800) 858-3424

WILMINGTON - Lyons Hardware, Inc., 2021 Kirkwood

Highway, 19805, (302) 995-1260

FLORIDA

ATLANTIC BEACH - First Coast Repair, 25 Seminole

Road, 32233, (904) 246-4616

CAPE CORAL - Family Hardware/Do-It Express, 622 SE

47th Terrace, 33904, (941) 542-6365

DELRAY - Mister Fix It, 209 S.E. 2nd Avenue, 33483,

(407) 243-9999

GAINESVILLE - Authorized Appliance Service Co.,

2614 S.W. 34th Street, 32608, (904) 375-3886

HIALEAH - S-O Service Co., 925 Hialeah Drive, 33010,

(305) 887-6275

HOLLY HILL - Ormond Element,1668 Ridgewood Avenue,

32117, (904) 677-3497

JACKSONVILLE - Authorized Appliance Service Co.,

6120-5 Powers Avenue, 32217, (904) 737-5312

LAKE CITY - S&S Mowers Sales & Service, Route 10,

Box 9161, Hwy 47 South & MacFarland Ave., 32055,

(904) 755-9375

LAKELAND - Electric Shaver & Small Appliance, 4243

S. Florida Avenue, 33813, (941) 644-4690

MIAMI - Goodman’s Sales & Service, 13081 SW 133 Court,

33186, (305) 278-8822

NORTH FORT MYERS - Family Hardware,13817 N.

Cleveland Ave., 33903, (941) 995-6161

NORTH PALM BEACH - Appliance Doctors, 450 Northlake

Blvd., 33408, (407) 845-0377, FAX (407) 845-0378

OCALA, Vacuums, Inc., 3535 S.E. Maricamp Road, #103,

34471, (904) 694-2247

ORLANDO - Philips Consumer Electronics, 2452 Sand

Lake Road, 32809, (407) 857-8998, (800) 942-6128

ORLANDO - Pine Hills Appliance Svc. Co., 6100-4

W. Colonial Drive, 32808, (407) 299-1271

ORLANDO - Southern Electric Co., 510 N. Parramore

Avenue, 32801, (407) 841-8824, (800) 940-8824

PANAMA CITY, Callaway Vacuum & Sewing, 221 N.Tyndall

Prkwy., 32404, (904) 763-6333

PENSACOLA - Foster’s Appliance Repair, 3836 N. Davis

Highway, 32503, (904) 432-8853

POMPANO BEACH - Authorized Appliance Service Co.,

2171 N. Dixie Highway, 33060, (954) 941-2038

POMPANO BEACH - Philips Consumer Electronics, 2099

W. Atlantic Blvd., 33069, (954) 978-0467

PORT ST. LUCIE - Hoppe’s Authorized Vac & Appliance,

6735 S. Federal Way, 34592, (561) 464-0102

ROCKLEDGE - Neelco Do-It Center, 400 Barton Blvd.,

32955, (407) 639-1400

SARASOTA - Sunray Small Appliances,8371 N.Tamiami,

34243, (941) 358-9999, (800) 895-5655

SEBRING - Sebring Do-It Center, 305 U.S. 27 North,

33870, (813) 385-2785

SPRING HILL - Crowder Bros Hardware, 5350 Spring Hill

Dr., 34606, (904) 686-4743

ST. PETERSBURG - Keystone Electric, 4604 Central

Avenue, 33711, (813) 321-1124

STUART - Appliance Doctors, 3166 S.E. Dixie Highway,

34997, (407) 287-6437

SUNRISE - Muller Appliance Service, 2620 N. University

Drive, 33322, (954) 749-5460

TAMPA - Authorized Appliance Service Co., Dibbs Plaza,

4119 Gunn Hwy., Unit 8, 33624, (813) 968-6638

VERO BEACH - Hoppe’s Authorized Vac & Appliance, 1872

Commerce Avenue, 32960, (561) 562-4466

WEST PALM BEACH - Satisfaction TV Video Service, Inc.,

1980 S. Congress Avenue, 33406, (561) 439-3733

GEORGIA

ATLANTA - Georgia Service Center, 5366 Buford Hwy.,

30340, (770) 455-1716, (800) 455-1715

ATLANTA (MARIETTA) - Philips Consumer Electronics,

200 N. Cobb Parkway, Bldg. #100, Suite 120, 30062,

(770) 795-0085

AUGUSTA - A & A Appliance Parts & Service, 1708 Walton

Way, 30904, (706) 733-5163

BRUNSWICK - Arco Hardware & Supply, 3711 Community

Road, 31520, (912) 267-0771

COLUMBUS - Burrell’s National Appliance Service,

1728 Warm Springs Road, 31904, (706) 327-0523

LOGANVILLE - Mtn. Mower Sales and Service, 6099C

Hwy. 20, 30249, (770) 466-9111

MACON - Capitol Cycle Company, 1090 Washington

Avenue, 31201, (912) 745-3946

SAVANNAH - Hagins Appliance Service, 3 West Victory

Drive, 31405, (912) 233-8372

TIFTON - Western Auto, 354 S. Main St., 31794,

(912) 382-5767

VALDOSTA - Harry B. Anderson, Inc. Western Auto, 204

Central Avenue, 31601, (912) 242-5945

HAWAII

HONOLULU - McCully Bicycle & Sporting Goods,

932 Hausten Street, 96826, (808) 946-1192

WAILUKU (MAUI) - Tom’s Appliance Sales & Service,

891 Eha Street, 96793, (808) 244-6278

WAIPAHU - Waipahu Bicycle, 94-320 Depot Street, 96797,

(808) 671-4091 IDAHO

BOISE - Boise Appliance, 1503 Main Street, 83702,

(208) 343-0102

ILLINOIS

CHAMPAIGN - Appliance Parts & Service Center, 905

Francois, 61821, (217) 355-0220

CHICAGO (BERWYN) - Brand Service Center,

6739 West Cermak, 60402, (708) 749-4315

CHICAGO (DOWNER’S GROVE) - Authorized Appliance

Service Co., 1644 W. Ogden Avenue, 60515,

(630) 852-1550

CHICAGO (MORTON GROVE) - Brand Service Center,

Inc., 5618 Dempster Street, 60053, (847) 965-5900

JACKSONVILLE- Rexx Battery Specialists, 847 South

Main Street, 62650, (217) 245-2713

NASHVILLE - Kesel Hardware,173 West St. Louis, 62263,

(618) 327-8957

NILES - Household Appliance Sales & Serv., 7411

N. Milwaukee Ave., 60714, (847) 647-8250

PEORIA - Brand Service Center, 6926-I North University

Street, Tanglewood Center, 61614, (309) 691-7588

ROCKFORD - Sun Appliance Sales & Service,

3112 N. Rockton Avenue, 61103, (815) 964-3866

SPRINGFIELD - Bannon Electronics,1224 N. Franklin,

62702, (217) 523-0313

WAUKEGAN - Brand Service Center, 2850 Belvidere

Road, 60085, (847) 244-5800

INDIANA

EVANSVILLE - Electro Hygiene Co., 1614 South Kentucky,

47714, (812) 425-2671

FT. WAYNE - Don’s Harware, 5701 Coventry Lane, in the

Village of Coventry, 46804, (219) 436-2278

FT.WAYNE - Sun Appliance Service & Sales, 3523

N. Anthony Blvd., 46805, (219) 482-1702

INDIANAPOLIS - Brand Service Center, 1827 N. Meridian

Street, 46202, (317) 924-1386

INDIANAPOLIS - Sullivan Hardware Do-It Center,

7021 N. Keystone, 46220, (317) 255-9230

MUNCIE - Joel’s Appliance Service, 4405 N. Old State

Road 3, 47303, (317) 286-2896

NEW ALBANY - Wells Hardware, Inc., 1011 Vincennes

Street, 47150, (812) 944-4523

SOUTH BEND - Ray’s TV and Appliance, 60717 US 31

South, 46614, (219) 291-1630

SOUTH BEND (OSCEOLA) - AAA Appliance Service Co.,

11868 Lincoln Way West, 46561, (219) 679-4981

TERRE HAUTE - Corey Electronics, 924 S. 8th Street,

47802, (812) 232-8786, (888) 758-4746

IOWA

BETTENDORF - K & K True Value Hardware, 1818 Grant

Street, 52722, (319) 359-4473

CEDAR RAPIDS - Stalker Electric, Inc.,110 3rd Ave. SW,

52404, (319) 364-5646

DES MOINES - Quality Appliance Repair Center, 1417

Walnut Street, 50309, (515) 288-0108

DUBUQUE - Shaver’s Plus, 11 Bluff Street, 52001,

(319) 556-4442

SIOUX CITY - Millard Television Inc., 1419 Hamilton Blvd.,

51103, (712) 258-3435

KANSAS

COLBY - Gavon’s Electronics, 1870 South Range, 67701,

(913) 462-6601

JUNCTION CITY - R/C Hobbies, 115 W. 7th Street, 66441,

(913) 238-1877

KANSAS CITY (OVERLAND PARK) - Mar-Beck Appliance

Service Co., 8471 West 95th Street, 66212, (913) 642-1557

WICHITA - Alan Appliance Service, Inc., 1300 E. Central,

67214, (316) 262-7228, (800) 290-7228

KENTUCKY

GREENVILLE – Malone Lumber Do-It Center, 204

W. Depot Street, 42345, (502) 338-3252

LEXINGTON - Factory Electronics, 2422 Palumbo Drive,

40509, (606) 269-7341

LEXINGTON (VERSAILLES) - Deaver’s Hardware,

221 N. Main St., 40383, (606) 873-7396

LOUISVILLE - Maury’s Fluorescent & Appliance Service,

1521 Bardstown Road, 40205, (502) 456-1671

MADISONVILLE - Kuester’s Hardware, N. Main St., Martin

Mall, 42431, (502) 825-2818

OWENSBORO - Kuester’s Hardware, 1210 Carter Road,

42301, (502) 685-4916

PADUCAH - Hank Brothers True Value, 3101 Lone

Oak Rd., 42003, (502) 554-4001

LOUISIANA

BATON ROUGE - Home Appliance Service, Inc., 10781

Florida Blvd., 70815, (504) 272-7727

LAFAYETTE - Cullen’s Playland,

4498 Johnston Street, 70503, (318) 981-2929

LAKE CHARLES - Capitol Schwinn Cyclery, 722 E. Prien

Lake Road, 70605, (318) 474-9090

NEW ORLEANS (METAIRIE) - Le Jouet, Inc., 1700 Airline

Hwy., 70001, (504) 837-0533

SHREVEPORT - Shreveport Shaver and Appliance, 9750

St. Vincent, Burt Kouns Ind. Loop, 71106, (318) 865-5088,

(800) 349-7722

WEST MONROE - West Monroe Small Appliance Repair,

1300 N. 7th Street, Suite F., 71291, (318) 323-5088

MAINE

BANGOR - Adco Surgical Supply Co., 1292 Hammond St.,

04401, (207) 942-5273

PORTLAND - Colonial Electronics, Inc.,

259 St. John Street, 04102, (207) 774-6666

MARYLAND

BALTIMORE (ELLICOTT CITY) - Clark Do-It Center,

10325 Baltimore National Pk., 21042, (410) 313-8100

BALTIMORE (TOWSON) - Duran Service Company,

8741 Mylander Lane, 21286, (410) 321-9033

Authorized Service Centers

GAITHERSBURG - Waters Appliance Service, 216 E.

Diamond Avenue, 20877, (301) 258-7500, (800) 225-5009

SALISBURY - Cycle and Sports Outlet,

2505 N. Salisbury Blvd., 21801, (410) 860-0400

TANEYTOWN - MacHenry Services, 68 Frederick Street,

21787, (410) 756-6659, (800) 276-1301

WASHINGTON D.C. (BELTSVILLE) - Philips Consumer

Electronics, 10800 Rhode Island Avenue, 20705,

(301) 595-5330, (800) 438-9647

MASSACHUSETTS

BOSTON (MEDFIELD) - Wills Hardware, 5 Janes Avenue,

02052, (508) 359-4381

BOSTON (WALTHAM) - Suburban Appliance Service

Center, Inc., 271 Moody Street, 02154, (617) 893-6694

LOWELL - Lowell Appliance Service Center, Inc., 564

Dutton Street, 01854, (508) 454-8731

MAYNARD - Gramp’s Garage, 16 Main Street, 01754,

(508) 461-0463

QUINCY - Appliance Service and Parts, Inc., 582 Wash-

ington Street, Route 3A, 02169, (617) 773-6656

SALEM - Fix Master, Inc., 190 North Street, 01970,

(508) 745-0004

SPRINGFIELD - Utility Electric Service, Inc., 810 Main

Street, 01101, (413) 781-1635

MICHIGAN

ALMONT - Almont Hardware, 4545 Van Dyke, P.O. Box

511, 48003, (810) 798-8922

BAY CITY - Bay Vac & Pedal, 805 Columbus Ave., 48708,

(517) 892-7516

BRIGHTON - Complete Battery Source, 8023 W. Grand

River, 48116, (810) 220-1050

DEARBORN - McNichols Electric Service, 1836 Grindley

Park, 48124, (313) 563-7550

DETROIT - McNichols Electric Service, 13725 W.

McNichols, 48235, (313) 342-6070, (800) 562-4226

DETROIT (ROYAL OAK) - McNichols Electric Service,

4115 West 13 Mile Road, 48072, (810) 288-5135

FLINT (DAVISON) - Gill-Roy’s Hardware, 8405 East

Davison, 48423, (810) 653-2288

FLINT (SWARTZ CREEK) - Gill-Roy’s Hardware, 9061

Miller Road, 48473, (810) 635-2020

GRAND RAPIDS - Superior Appliance Service Co., 1050

Scribner Avenue, NW, 49504, (616) 459-3271

JACKSON - Hammond Hardware, 1800 Francis St., P.O.

Box 7, 49204, (517) 782-0704

KALAMAZOO - Bill Coleman TV, 3938 S. Westnedge,

49008, (616) 344-1200

LANSING - Rapid Appliance Service, Inc., 1454

E. Michigan Avenue, 48912, (517) 485-1320

MIDLAND - Knopic’s Do-It Center, 3128 Jefferson Ave.,

48640, (517) 832-2774

PRUDENVILLE - Ford’s Do-It Center, 841 W. Houghton

Lake Drive, 48651, (517) 366-7622

TRAVERSE CITY - De Weese Hardware Inc., 1029 Carver

Street, 49685, (616) 947-7670

MINNESOTA

BRAINERD - Diggz Motor Sports, 4299 Hwy. 371 North,

56401, (218) 828-8088

DULUTH - All Brand Mr. Fixit, 16 West First Street, 55802,

(218)-722-1499

DULUTH - Mr. Fix it - Metro Appl. Service Center, Inc.,

2020 W. Superior St., 55806, (218) 722-9063

MINNEAPOLIS (ST. LOUIS PARK) - Barness, 4631

Excelsior Blvd., 55416, (612) 926-0521

ROCHESTER - Robert’s Electronics, 611 6th Ave. NW,

55901, (507) 282-2140

ST. PAUL - Barness, 1573 University Avenue, 55104,

(612) 646-3109

MISSISSIPPI

HATTIESBURG - Champion Cycle & Fitness, 2625 Lincoln

Road, 39402, (601) 264-8233, (800) 273-4158

IUKA - W. H. Fairless Hardware Co., Inc., 117 Fulton Street,

38852, (601) 423-2233, (800) 797-9457

JACKSON (RIDGELAND) - Propeller Service,

291 Hwy. 51, Suite D6, 39157, (601) 856-3191

MERIDIAN - Broadmoor Home Center, 2420 Old North

Hills Street, P.O. Box 3280, 39305, (601) 483-7373

NATCHEZ - Western Auto, 180 Seargent Prentiss Dr.,

39120, (601) 445-4186

STARKVILLE - East Mississippi Lumber Co.,

300 Russell Street, 39759, (601) 323-3554

MISSOURI

INDEPENDENCE - Mar-Beck Appliance Service Co.,

4476 South Noland Road, 64055, (816) 478-1889

KANSAS CITY - Mar-Beck Appliance Service Co.,

303 W. 79th Street, 64114, (816) 523-6931

KANSAS CITY (GLADSTONE) - Mar-Beck Appliance Serv.

Co., 6559 N. Oak Traffic Way, 64118, (816) 436-9191

POPLAR BLUFF - Mills Iron & Supply, 1919 S. Westwood

Blvd., 63901, (573) 785-2628

SPRINGFIELD - Mar-Beck Appliance Service Co.,

2704 S. Glenstone Avenue, 65804, (417) 882-3070

ST. LOUIS - Authorized Appliance, Inc., 2355 Hampton

Avenue, 63139, (314) 647-4250

ST. LOUIS - Brand Service Center, Inc., 1624 S. Broadway,

63104, (314) 231-0751

MONTANA

BILLINGS - Radio Equipment Company,

1120 16th Street West, 59104, (406) 256-9778

NEBRASKA

GRAND ISLAND - Mundt’s Small Appliance & Vacuum

Repair, 1822 W. Northfront Street, 68803, (308) 382-5084

LINCOLN - CB Small Appliance, 432 South 11th Street,

68508, (402) 475-2546

LINCOLN - Sperry TV, 1115 North 47th St., 68503,

(402) 464-9181

LINCOLN - Sperry TV, 2013 Highway 2, 68502,

(402) 464-9181

NORTH PLATTE - Sperry TV, 1855 West A Street,

Westfield Shopping Center, 69010, (308) 532-5200

OMAHA - Myers Electric Co., 7571 Dodge Street, 68114,

(402) 393-8388, (800) 234-1414

OMAHA - Myers Electric Co., Inc., 1458 South 16th Street,

68108, (402) 342-7710

NEVADA

LAS VEGAS - Burney’s Commercial Service, Inc., 4480

Aldebaran Avennue, 89103, (702) 736-0006

MINDEN - Valley Home & Sport Center, 1587 Highway 395,

89423, (702) 782-5111

NEW JERSEY

HAWTHORNE - Ter Kuile, Inc., 206 Diamond Bridge

Avenue, 07506, (201) 423-1142

HIGHLAND PARK - Dash Electronics, 10 N. 2nd Street,

08904, (908) 247-5124

HOWELL - South Jersey TV Service, Inc., 4232 Rt. 9

South, 07731, (908) 363-5550, (800) 244-3094

OCEAN - South Jersey TV Service, Inc., 1719 Route 35,

07712, (908) 531-3565

SICKLERVILLE - Sicklerville Hardware, 540 Williamstown

Road, 08081, (609) 728-3800

TOMS RIVER - South Jersey TV Service, Inc., Stella Towne

Center, 1258 Route 166, 08753, (908) 505-1771

TOTOWA - Philips Consumer Electronics, 140J Commerce

Way, 07512, (201) 890-0586

TRENTON - Tattersall, Inc., 309 N. Willow Street, 08618,

(609) 393-4293

NEW MEXICO

ALBUQUERQUE - Appliance Service Center, 5505 Silver

Avenue, SE, 87108, (505) 265-7774

CLOVIS - Burns Hardware, 1511 N. Prince, 88101,

(505) 769-2528

NEW YORK

BAYSHORE, L.I. - Turnpike Appliance of Suffolk, Inc.,

1253 Sunrise Highway, 11706, (516) 665-8311

BINGHAMTON - Hardware Fare DO-IT Center, 1139 Front

Street, Nimmonsburg Square, 13905, (607) 722-9202

BUFFALO - Buffalo Appliance Repair Center, Inc., 20

Pannell Street, 14214, (716) 833-4677

BUFFALO (WILLIAMSVILLE) - Hector’s Hardware,

876 Maple Road, 14221, (716) 688-4488

COMMACK, L.I. - Turnpike Appliance Service,

6181 Jericho Turnpike, 11725, (516) 499-3355

ELMIRA - Capabilities, Inc., 1149 Sullivan Street, 14901,

(607) 734-2006

GREAT NECK - Turnpike Appliance Service Center, 45

Northern Boulevard, 11021, (516) 466-0644

HUDSON - Sweeps Vacuum & Repair Center, Inc.,

705 Warren Street, 12534, (518) 828-5457

PEEKSKILL - Clark Appliance & Vacuum Service Corp.,

950 Main Street, 10566, (914) 737-1368, (800) 765-0649

POUGHKEEPSIE - S & S Appliance Sales & Service,

390 Violet Avenue, 12601, (914) 452-6122

RICHMOND HILL - Lockdoctor Locksmiths, 104-37 Atlantic

Ave., 11418 (718) 441-6242

ROCHESTER - Benfante Appliance Service, 1286

Mt. Hope Avenue, 14620, (716) 473-8765

SEA CLIFF, L.I. - Shabra Electronics, 400 Glen Cove

Avenue, 11579, (516) 671-2218

STATEN ISLAND - Springstead Lumber 6232, 4255 Amboy

Road, 10308, (718) 984-0300

SYRACUSE - County Wide Appliance, 1001 N. State

Street, 13208, (315) 479-5253, (800) 333-3243

TUCKAHOE - Authorized Appliance of Westchester,

26 Columbus Ave., 10707, (914) 961-8011

UTICA - Oneida Bicycle & Sports Center, 2107 Whitesboro

St., 13502, (315) 724-6084

WARWICK - Wadeson Home Center, 60 Forester Avenue,

10990, (914) 986-2215, (800) 982-2215 (NY only)

W. HEMPSTEAD L.I. - Turnpike Appliance Service,

86 Hempstead Turnpike, 11552, (516) 486-5700,

(800) 628-3911

NORTH CAROLINA

ASHEVILLE - Skyland Hardware, 3179 Sweeten Creek

Road, 28803, (704) 684-0308

CHARLOTTE - Authorized Appliance Servicenter,

1020 Tuckaseegee Road, 28208, (704) 377-4501,

(800) 532-6127

CLINTON - Danny’s Service Center, 119 Vance Street,

28328, (910) 592-3200

ELIZABETH CITY - Coastal Office Equipment Co., 501

East Church Street, 27909, (919) 335-2927

GREENSBORO - Greensboro Shaver & Appliance,

430 North Eugene Street, 27401, (910) 273-1065

HICKORY - First Flight Bicycles, 2435 N. Center Street,

28601, (704) 324-9350

RALEIGH - Authorized Appliance Service Center,

800 North Person Street, 27604, (919) 834-3476

STATESVILLE - First Flight Bicycles, 216 S. Center St.,

28677, (704) 878-9683

WILMINGTON - American Tool & Tractor, 102 Eastwood

Road, Ste. D-9, 28403, (910) 392-5784

WINSTON-SALEM - Authorized Appliance Servicenter,

904 South Marshall Street, 27117, (910) 725-5396

NORTH DAKOTA

FARGO - General Parts & Supply Co., 10 S. 18th Street,

58103, (701) 235-4161, (800) 279-9987

OHIO

AKRON - Advanced Appliance Service Company,

73 W. Exchange Street, 44308, (216) 762-8968

CANTON - Appliance Parts Co., 1267 Dueber Avenue,

SW, 44706, (330) 453-8077

CINCINNATI - H&S Service, 458 Cincinnati Batavia Pike,

45244, (513) 528-0808 (800) 344-4210

CINCINNATI (SILVERTON) - Brand Service Center, Inc.,

6944 Plainfield Road, 45236, (513) 793-1170

CLEVELAND - Majors Appliance, 5845 Turney Road,

44125, (216) 663-4650

CLEVELAND (MENTOR) - Lake Erie Lawn & Garden, 7833

Munson Rd., 44060, (216) 257-9000

CLEVELAND (PARMA) - Majors Appliance, 5785 Ridge

Road, 44129, (216) 884-7200

CLEVELAND (WESTLAKE) - Philips Consumer

Electronics, 24090 Detroit Avenue, 44145, (216) 899-2040,

(800) 331-7037

COLUMBUS - Philips Consumer Electronics, 6333 Busch

Blvd., 43229, (614) 781-2605

DAYTON - Layer Electric, 603 South Ludlow Street, 45402,

(937) 224-9608

DAYTON (NEW CARLISLE) - Ballweg Do-It Center, 3300

South Dayton, Lakeview Rd., 45344, (937) 849-1306

LIMA - Crouse Lumber Do-It Center, 333 E. Market Street,

45801, (419) 229-9070, (800) 826-9663

NEW BOSTON - True Value Toy Town, Rt. 52 & 139, 45662,

(614) 456-5704

STRYKER - Short’s Hardware, 115 N. Depot Street, 43557,

(419) 682-4231

Authorized Service Centers

TOLEDO - Broadway Sales and Appliance Repair, 1621

Broadway, 43609, (419) 241-9731, (800) 436-5415

YOUNGSTOWN - O’Connor’s, 3224 Market Street, 44507,

(216) 782-4705

OKLAHOMA

OKLAHOMA CITY - Brand Service Center,

538 N. Pennsylvania Avenue, 73107, (405) 235-0583

TULSA - H.L. Moss, Inc., 1714 E. 15th Street, 74104,

(918) 744-1305, (800) 248-5948

OREGON

PORTLAND - Oregon Appliance Service, 2137 East

Burnside Street, 97214, (503) 235-6681

PENNSYLVANIA

ALTOONA - Frye’s Sweeper & Sewing Center, Inc.,

1400 Valley View Boulevard, 16602, (814) 943-5001,

(800) 640-1308

HARRISBURG - C.A. Juillard, Inc., 2301 North Seventh

Street, 17110, (717) 233-3488, (800) 633-3488

JOHNSTOWN - Cambria True Value Hardware,West Hills

Square, Goucher Street, 15905, (814) 255-4752

KINGSTON - Vac-Way Appliance & Service, 595 Market

Street, 18704, (717) 288-4508

MOSCOW - Vac-Way Appliance & Service,RR #6 Box

6237, 18444, (717) 842-4668

ORANGEVILLE - Hess Do-It Center & Market, Route 487,

Box 4 M, 17859, (717) 683-5162

PHILADELPHIA - Appliance Care/Service Corp., 6407

Rising Sun Ave., 19111, (215) 725-3112

PHILADELPHIA (COLLINGDALE) - J.F. Kenney Electric,

920 MacDade Boulevard, 19023, (610) 534-7373

PITTSBURGH - Ferry Electric Service Co., 7498 McKnight

Road, 15237, (412) 364-3403

PITTSBURGH - Ferry Electric Service Co., 140 Clairton

Blvd., 15236, (412) 653-6004

READING - Electric Repair Co., 502-504 North 9th Street,

19604, (610) 376-5444, (800) 422-8171 (PA only)

SCRANTON - Vac-Way Appliance and Service, 601 Cedar

Avenue, 18505, (717) 343-1121

SHAMOKIN DAM - Willard Battery Outlet, 138 S. Old Trail,

17876, (717) 743-5383

TROY - Hoover Hardware, 9 Canton, 16947,

(800) 251-2156, (717) 297-3445

WASHINGTON - Murphy Family Inc., 585 East National

Pike, 15301, (412) 225-0324

WILKES-BARRE - Walter Hardware DO-IT Center,

57 N. Welles Street, 18702, (717) 823-1406

YORK - Parcel Plus, 2549 E. Market Street, York Market

Place, 17402, (717) 757-1875

PUERTO RICO

HATILLO - Tropical Parts Service, P.O. Box 1335, Road 130

KM 8.5, 00659, (787) 898-6474

MAYAGUEZ - Cardona Appliance Service, 8 San Vicente

Sreet, 00680, (787) 832-8366

MAYAGUEZ - Melendez Home Appliance Repair, Calle

Post 319 Sur, 00680, (787) 832-5225

PONCE - Ferreteria Vivian, Centro Comercial, Los Caobos

#7, 00731, (787) 840-0677

PUERTO NUEVO - Buckeye Service, 1013 Jesus T. Pinero

Avenue, 00920, (787) 782-6175

RHODE ISLAND

PROVIDENCE - Marshall Electric Co., 200 Broad Street,

02903, (401) 331-4482

SOUTH CAROLINA

CHARLESTON HEIGHTS - Dorchester Electric Service,

3575 Dorchester Avenue, 29405, (803) 747-5221

COLUMBIA - Authorized Appliance Servicenter, 1811

Taylor Street, 29202, (803) 254-8414

DARLINGTON - Hobbies and More, 1570 South Main

Street, 29532, (803) 393-0355, FAX (803) 393-8171

GREENWOOD - Bikes & Boards & Mopeds, 203A

Montague Avenue, 29646, (864) 229-2453

SENECA - Seneca Micronics, 110 East North First, 29678,

(803) 882-6593

SPARTANBURG - Boiling Springs Hardware, 3124 Boiling

Springs Rd, 29303, (803) 578-1852

VARNVILLE - P&S Small Engine & Variety Shop,

105 Carolina Avenue, West, 29944, (803) 943-9141

TENNESSEE

CHATTANOOGA - Light Electric, 732 East 11th Street,

37403, (615) 267-9224

KNOXVILLE - Authorized Appliance Service Center,

1206 North Central Street, 37917, (615) 524-3376

MEMPHIS - Camp Electric Co., 647 Madison Avenue,

38103, (901) 527-7543, (800) 238-7345

NASHVILLE - Webb’s Appliance Service Center, Inc., 1519

Church Street, 37203, (615) 329-4079, (800) 899-4079

TEXAS

ABILENE - Metro Small Appliance Service Co., 141

S. Clyde, 79605, (915) 672-1853

AMARILLO - Reid’s Appliance Service, Inc., 906 Georgia,

79102, (806) 373-8812

ANTHONY - Villarreal & Sons Elec., 512 S.Third Street,

79821, (915) 886-3362

AUSTIN - Harrell Supply and Service, Inc., 5435 Burnet

Road, 78756, (512) 451-6464, (800) 332-7250 (TX only)

AUSTIN - Harrell Supply and Service, Inc., 1409 West

Oltorf, 78704, (512) 442-5966

AUSTIN (ROUND ROCK) - Harrell Supply, 907c Interstate

Highway 35, 78664, (512) 388-0866

CORPUS CHRISTI- Brand Appliance & Microwave, 2751

South Staples, 78404, (512) 854-1851

DALLAS - Pearsol Appliance Co., 3127 Main Street,

75226, (214) 939-0930

DALLAS - All Type Sales and Service Co., Inc.,

2835 Irving Blvd., 75207, (214) 638-1170, (800) 717-1170

FT.WORTH - Ft. Worth Shaver and Appliance Center,

1012 West 7th Street, 76102, (817) 335-9970

HOUSTON - Brand Service Center, 5727 Richmond

Avenue, 77057, (713) 782-8910

HOUSTON - Brand Service Center, 1970 FM 1960, 77090,

(713) 537-7795

LAREDO - Rubio Electric, 1719 San Bernardo, 78040,

(210) 722-3908

LONGVIEW - Toys and Things, 918 NW Loop 281,

75604, (903) 759-3939

LUBBOCK - Minter’s, 4409 50th Street, 79414,

(806) 799-3170

LUFKIN - STS Audio and Video, 1505 South First Street,

75901, (409) 639-4529

MC ALLEN - All-In-One Repair Shop, 2313 Lark Avenue,

78504, (210) 682-8858

MIDLAND - Midland Tool Specialty, 918 South Main, 79701,

(915) 682-4647, (800) 499-0755

PASADENA - Larry’s TV Service, 3520 Fairmont Parkway,

77504, (713) 998-0122, (800) 244-0281

ROMA - True Value Hardware, 1004 E. Highway 83,

(210) 849-1322

SAN ANTONIO - Brand Service Center, 7065 San Pedro

Avenue, 78216, (210) 344-8577

SEYMOUR - Western Auto, 211 N. Main Street, 76308,

(817) 888-3980

TEMPLE - Master Tech Repairs, 2819 West Avenue North,

76504, (817) 773-8991

VICTORIA - Tom’s Video Service, 211 East Anaqua, 77901,

(512) 576-0664, (800) 433-0664

WICHITA FALLS - Burke’s Appliance Service,

2410 10th Street, 76309, (817) 723-6211

UTAH

OREM - The Mending Shed, 1735 South State Street,

84058, (801) 225-8012, (800) 339-9297

SALT LAKE CITY - Appliance Service Center, Inc., 210

East 6th South, 84111, (801) 328-9703

VERMONT

RUTLAND - Appliance Service Center Ltd., 152 Woodstock

Avenue, 05701, (802) 773-8917

VIRGINIA

HARRISONBURG (PENN LAIRD) - J.L. Maintenance &

Repair, Inc., Route 2, Box 308, 22846, (540) 289-9844

NEWPORT NEWS - Commonwealth Electric Shaver Sales

& Service, Inc., 10105 Jefferson Ave., 23605,

(804) 595-6712

NORFOLK - Commonwealth Electric Shaver Sales &

Service, Inc., 6612 E. Virginia Beach Blvd., 23502,

(804) 461-4475

ROANOKE - Commonwealth Shaver & Appliance Service,

5524 Williamson Road, NW, 24012, (703) 366-6038

VIENNA - Appliance Fix-It, 8455 Tyco Road, 22182,

(703) 893-1234

WINCHESTER - Battery Mart of Winchester, Inc., 1 Battery

Dr., 22601, (703) 655-0065

WOODBRIDGE - Baker’s Appliance, 13314 Occoquan

Road, 22191, (703) 490-5605

WASHINGTON

SEATTLE - Ajax Electric, 2911 First Avenue South, 98134,

(206) 622-9945

SEATTLE (BELLEVUE) - Action Small Appliance Service,

1500 145th Place, SE, 98007, (206) 643-9806

SPOKANE - SPARCO, West 45 2nd Avenue, 99204,

(509) 624-8965

SPOKANE - SPARCO, N. 1119 Pines Rd., 99206,

(509) 922-9666

WEST VIRGINIA

BECKLEY - Jerry’s Detectors, Vacuum & Appl. Svc., 411

Second Street. 25801, (304) 253-3521

CHARLESTON - Sneed’s Vacuum & Sewing Center, 2614

7th Avenue, 25312, (304) 744-3670, (800) 245-8048

(WV only)

HARRISVILLE - Western Auto, 1107 E. Main St., 26362,

(304) 643-2226

HUNTINGTON - Mike’s Appliance and Service, 212 20th

Street, 25703, (304) 522-0737, (800) 244-9152

MARTINSBURG - Battery Mart, 1161-3 Winchester

Avenue, 25401, (304) 267-7033, (800) 464-7918

WHEELING - Fast Service Center, 1058 Main Street,

26003, (304) 232-5561 (800) 874-4090

WISCONSIN

APPLETON - G/Tech Electric Tool & Housewares Service,

600 W. College Ave., 54911, (414) 739-6064,

(800) 400-6064

GREENBAY - Kastle Carts, Inc., 2301 N.Irwin Ave., 54313,

(414) 465-6121

LACROSSE - Paul’s Shaver Service, 1224 Caledonia

Street, 54603, (608) 782-6291

MADISON (MONONA) - Kiefer’s Shaver and Appliance,

4511 Monona Drive, 53716, (608) 221-3322

MAUMETTE - Della Do-It Center, W 1536 Highway 41,

54143, (715) 732-1768

MILWAUKEE - Brand Service Center, 3707 North 92nd

Street, 53222, (414) 461-0440

MILWAUKEE - Brand Service Center, 6000 W. Oklahoma

Street, 53219, (414) 541-4340

FOR MODEL 76960

Questions? Please call Consumer Affairs toll-free at 1-800-348-0751.

BARBIE and associated trademarks are owned by and used under license from Mattel, Inc.

JEEP and the Jeep grille design are registered trademarks of Chrysler Corporation U.S.A. used under license.

76960 1 76960-0920

Printed in U.S.A.

Super Talk!™BARBIE™Sun Jammer™

4x4

Fisher Price 76960 Instruction Sheet PW SunJammer 1 8

SUPER TALK! 76960 76960-1-0920

Navigation menu

Versions of this User Manual:

Views

Navigation
