Bounce ’n Play Activity Dome

Please save these instructions for future reference.

Adult assembly is required.

Tool needed for assembly: Phillips Screwdriver.

Use only for a child who is unable to push up on hands and knees, pull up or sit unassisted.

Model Number: 79534

Instructions

Occasionally a consumer may experience a problem with one of our products. If this should happen, please call us

toll-free, rather than return this product to the store. Usually we can solve the problem on the telephone or by sending

you replacement parts. Please call Fisher-Price®Consumer Affairs, toll-free at 1-800-432-KIDS, 8 AM - 6 PM EST Monday

through Friday. Hearing-impaired consumers using TTY/TDD equipment, please call 1-800-382-7470. Or, write to:

Fisher-Price®Consumer Affairs, 636 Girard Avenue, East Aurora, New York 14052.

Consumer Information

2

• Never leave child unattended.

• To prevent suffocation from entrapment, use only the Fisher-Price®pad

provided. Never use additional padding or mattress.

• To prevent falls, use only for a child who is unable to push up on hands

and knees, pull up or sit unassisted.

• To prevent strangulation:

_Never place items with a string, such as hood strings or pacifier cords,

around a child's neck.

_Never place this product near a window where cords from blinds or

drapes can strangle a child.

• Never place product on an elevated surface.

• Never move or carry this product with a child in it. This product is not

designed to be used as a carrier and will become unstable.

• The Bounce ’n Play Activity Dome must be fully erected prior to each use.

• Never use plastic shipping bags or other plastic film as mattress covers.

They can cause suffocation.

WARNING

3

SHOWN ACTUAL SIZE

M5 x 113/16" Screw - 2 M5 Lock Nut - 2 M6 x 13/8" Screw - 8 M6 Lock Nut - 8

Base

Pad

Metal Canopy Stay

3 Toys

2 Base Wires

®

®

2 Covers

Plastic Mesh Cover Stay

Parts

4

Assembly

• Insert an M6 x 13/8" screw through each frame tube

and into the frame.

• Fit an M6 lock nut into each corresponding hexagonal

opening on the back of the frame.

Metal

Canopy

Stay

• Insert the metal canopy stay through the canopy tunnel.

• Position the base upright on a flat surface.

• Locate the end of the base with the mesh cover. Insert

the entire plastic mesh cover stay into one of the

button holes in the mesh cover.

• Be sure to tuck the plastic mesh cover stay away from

the button holes in both sides of the mesh cover.

Frame Tube Frame Tube

• Position the ends of the frame tubes against the

middle holes in a frame.

2

3

IMPORTANT! Before each use or assembly, inspect this product for damaged hardware, loose joints, missing parts or

sharp edges. DO NOT use if any parts are missing or broken. Contact Fisher-Price®for replacement parts and

instructions if needed. Never substitute parts.

M6 Lock Nut

Hexagonal

Opening

Base

Canopy Tunnel

Middle Hole Middle Hole

Frame

Frame

Frame Tube

Frame

Tube

M6 x 13/8" Screw - 4 M6 Lock Nut - 4

4

Base

Mesh Cover

Button Hole

1Plastic Mesh

Cover Stay

• Tighten the screws with a Phillips screwdriver. Do not

over-tighten.

• Repeat this procedure to attach the other ends of the

frame tubes to the frame on the other side of the base.

5

• Position the base wires around the base so that the

ends point upward and are in front of the lower holes

in a frame.

• Insert an M6 x 13/8" screw through each base wire and

into the frame.

• Fit an M6 lock nut into each corresponding hexagonal

opening on the back of the frame.

• Tighten the screws with a Phillips screwdriver. Do not

over-tighten.

• Repeat this procedure to attach the other ends of the

base wires to the frame on the other side of the base.

6

Base Wire

Lower Hole

Base Wire

Frame

5

• Position one end of the metal canopy stay against the

upper hole in a frame.

• Insert an M5 x 113/16" screw through the hole in

the cover.

• Fit the end of the screw through the hole in the metal

canopy stay and into the hole in the frame.

• Push on the cover to insert and “snap” the tab on

the cover into the slot in the frame. Make sure you

hear a “snap”.

• Fit an M5 lock nut into the corresponding hexagonal

opening on the back of the frame.

• Tighten the screw with a Phillips screwdriver. Do not

over-tighten.

• Repeat this procedure to attach the other end of the

metal canopy stay and the remaining cover to the

frame on the other side of the base.

Assembly

Upper

Hole

Cover

Slot Tab

Lower Hole

M6 Lock Nut - 4

M5 x 113/16" Screw - 2 M5 Lock Nut - 2

Metal Canopy Stay

7

M6 x 13/8" Screw - 4

®

• Lift the canopy.

• Fasten the pad fasteners to the base fasteners.

• Attach the toys to the canopy fasteners.

Assembly is now complete, but Bounce ‘n Play

Activity Dome is not ready for use. Please refer to

the Use instructions, page 7, steps 3 and 4.

Pad

Fastener

Base Fastener

Toys Canopy

Fasteners

Sides of Base Wire

• Grasp both sides of a base wire.

• Pull both sides of the base wire outward and then let

the base wire rotate down.

Note: If the base wire does not freely rotate down, pull

the sides of the base wire further outward.

6

Assembly

®

Carry Straps

• Position the product on a flat surface.

• Unfasten the carry straps.

1

2

Use

8

To Unfold

Using the Canopy

7

Base Wire

Frame

Groove Groove

3

• Lift the product up slightly so that the base wire

“snaps” into the groove in each frame. Make sure

you hear a “snap”.

• Repeat Use Steps 2 and 3 to unfold the other base wire.

• Push down on the product to

be sure the base wires are in

the correct position.The base

wires should rest in the groove

in each frame.

Use

Base Wire

Groove

Frame

Correct

®

• Adjust the canopy and mesh cover up.

• While holding the mesh cover up, fasten the

zipper closed.

Canopy Up

Mesh

Cover Up

Zipper

®

• Adjust the canopy up or down.

Canopy Down

Canopy Up

Using the Mesh Cover

6

5

4

If you have any questions about this product:

In CANADA: Mattel Canada Inc., 6155 Freemont Blvd., Mississauga, Ontario L5R 3W2.

Questions? 1-800-567-7724.

In GREAT BRITAIN: Mattel U.K., Ltd., Helpline: 01628 500302.

In AUSTRALIA: Mattel Australia Pty. Ltd., 658 Church Street, Locked Bag #870, Richmond,

Victoria 3121 Australia. Consumer Advisory Service 1-800-800-812 (valid only in Australia).

The pad is machine washable.Wash the pad separately

in cold water on the gentle cycle. Do not use bleach.

Tumble dry separately on low heat and remove promptly.

The fabric, frame and toys may be wiped clean using a

mild cleaning solution and a damp cloth.

Care

• Grasp both sides of a base wire.

• While lifting the product up slightly, pull both sides of

the base wire outward to remove the base wire from

the groove in each frame.

Frame

Groove

Base Wire

Groove

7

Base Wire

• Rotate the base wire up.

• Repeat this procedure to fold the other base wire.

8

Correct

®

• Fasten the carry straps.

Carry Straps

9

Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, NY 14052 U.S.A. 79534 B 79534-0920

©1998 Mattel, Inc. All Rights Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc. Printed in Hong Kong

To Fold for Portability

Use Use
