Fisher Price N596208 Toy Walkie Talkie User Manual N5962a 0920 indd
Fisher-Price Inc. Toy Walkie Talkie N5962a 0920 indd
User Manual
www.fisher-price.com
• Please keep this instruction sheet for future
reference, as it contains important information.
• Requires two 9V (6LR61) alkaline batteries (not
included) for operation.
• Adult assembly is required for
battery installation.
• Tool required for battery installation: Phillips
screwdriver (not included).
• Transmission carrier frequency is 27.145 MHz.
• Walkie talkie range is up to 200 feet (61 meters).
• Field strength: 74.8dBu V/m at 3m.
Troubleshooting Guide
Problem Cause Solution
Excessive static Interference from vehicles,
power lines, fl uorescent lights,
electric motors or dimmer
switches
Change your location.
Point the antenna in a different
direction.
Can hear other people talking Transmissions on the same
frequency as this product
This product operates on
a public frequency and
may occasionally pick up
transmissions from other
transmitting devices on the
same frequency.
Walkie talkie does not work Walkie talkie power is off Make sure both walkie
talkies’ power is on
Battery power is low Replace the exhausted battery
in each walkie talkie. See
Battery Installation section on
this sheet.
Walkie talkies are out of range The walkie talkies can transmit
up to 200 feet. Decrease the
distance between the units.
Walkie talkie range decreases Units do not transmit well
through large objects
Indoor range may be lower
because of walls or large
objects between the walkie
talkies. Make sure there is a
clear path between the units.
Battery power is low Replace the exhausted battery
in each walkie talkie. See
Battery Installation section on
this sheet.
Power L.E.D. is off Power is OFF Turn the power/volume dial to
the ON position.
Walkie talkie is in sleep mode The walkie talkie goes into
sleep mode after 5 minutes of
inactivity. Press the talk button
to “wake it up”.
Battery power is low Replace the exhausted battery
in the walkie talkie. See Bat-
tery Installation section on
this sheet.
6
Tough for Talking
5
• Turn the power/volume dial on the front of each walkie talkie to turn them on. The power L.E.D.
lights to indicate that power is ON.
• Press and hold the talk button on the side of the walkie talkie and talk into the microphone.
• Release the talk button to listen to a response from the other walkie talkie!
• Walkie talkie range is dependant on environmental conditions. The range of the walkie talkies will
be shorter when used indoors than it will when used outdoors.
• After fi ve minutes of inactivity, the walkie talkies will go into sleep mode. Press the talk button to turn
it back on.
IMPORTANT! Always remember that you are using public frequencies when using these walkie
talkies. You may fi nd that this product will occasionally pick up transmissions from other transmitting
devices using the same frequency.
FCC Statement (United States Only)
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Consult the dealer or an experienced radio/TV technician for help.
Note: Changes or modifi cations not expressly approved by the manufacturer responsible for
compliance could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference and (2) this device must accept any interference
received, including interference that may cause undesired operation.
N5962
Power/Volume Dial
Talk Button
Power L.E.D.
Battery Installation
9V x 2
(6LR61)
Features
• Locate the battery compartment on the back of each walkie talkie.
• Loosen the screw in each battery compartment door. Remove each battery compartment door.
• Snap one 9V (6LR61) alkaline battery into each walkie talkie.
Hint: We recommend using alkaline batteries for longer battery life.
• Replace each battery compartment door and tighten each screw.
• If the toy begins to operate erratically, you may need to reset the electronics. Turn the power/
volume dial off and then back on.
• When sounds from this toy become faint or stop, it’s time for an adult to change the batteries.
Battery Safety Information
In exceptional circumstances, batteries may leak fl uids that can cause a chemical burn injury
or ruin your product. To avoid battery leakage:
• Do not mix old and new batteries or batteries of different types: alkaline, standard (carbon-zinc) or
rechargeable (nickel-cadmium).
• Insert batteries as indicated inside the battery compartment.
• Remove batteries during long periods of non-use. Always remove exhausted batteries from the
product. Dispose of batteries safely. Do not dispose of product in a fi re. The batteries inside may
explode or leak.
• Never short-circuit the battery terminals.
• Use only batteries of the same or equivalent type as recommended.
• Do not charge non-rechargeable batteries.
• Remove rechargeable batteries from the product before charging.
• If removeable, rechargeable batteries are used, they are only to be charged under
adult supervision.
Protect the environment by not disposing of this product with household waste
(2002/96/EC). Check your local authority for recycling advice and facilities (Europe only).
2 3
• Power/Volume Dial – Turn the dial to turn power
ON and adjust the volume level.
• Power L.E.D. – Indicates that power is ON.
• Talk Button – Press and hold while talking into
the microphone. Fisher-Price, Inc., a subsidiary of Mattel, Inc.,
East Aurora, NY 14052 U.S.A.
©2008 Mattel, Inc. All Rights Reserved.
® and ™ designate U.S. trademarks of Mattel, Inc.
PRINTED IN CHINA N5962a-0920
Care
• Wipe the toy with a clean cloth dampened with a mild soap and water solution.
• Do not immerse the toy.
• This product has no consumer serviceable parts. Do not take this product apart.
Microphone/Speaker
ICES-003
This Class B digital apparatus complies with Canadian ICES-003. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference and (2) this device must accept any
interference received, including interference that may cause undesired operation.
This Category II radiocommunication device complies with Industry Canada Standard RSS-310.
NMB-003
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. L’utilisation de
ce dispositif est autorisée seulement aux conditions suivantes: (1) il ne doit pas produire de brouillage
et (2) l’utilisateur du dispositif doit être prêt à accepter tout brouillage radioélectrique reçu, même si
ce brouillage est susceptible de compromettre le fonctionnement du dispositif.
Ce dispositif de radiocommunication de catégorie II respecte la norme CNR-310 d’Industrie Canada.
