Fleetwood Group KG3EI Low Power Wireless Response Keypad User Manual CERTIFICATE OF COMPLIANCE
Fleetwood Group Inc Low Power Wireless Response Keypad CERTIFICATE OF COMPLIANCE
User Manual
Rhein Tech Laboratories, Inc. Client: Fleetwood Group, Inc.
360 Herndon Parkway Model: KG3EI
Suite 1400 Standards: FCC 15.247/IC RSS-210
FCC/IC ID: FBRKG3EI/1859A-KG3EI Herndon, VA 20170
http://www.rheintech.com Report #: 2009149
Page 38 of 48
Appendix K : Manual
Please refer to the following pages.
USER MANUAL
KG3EI Wireless
Response Keypad
ii
©Copyright 2007 Fleetwood Group, Inc., Electronics Division. All rights reserved. Licensed software products are
owned by Fleetwood Group, Inc. or its suppliers and are protected by United States copyright laws and international
treaty provisions.
Fleetwood Group, Inc. products are covered by U.S. and foreign patents, issued and pending. Information in this
publication supersedes that in all previously published material. Specifications and pricing are subject to change
without notice.
Printed in the U.S.A.
Fleetwood Group, Inc.
Electronics Division
11832 James St.
Holland, Michigan 49424
www.fleetwoodgroup.com
www.replysystems.com
Sales: 1-800-257-6390
Technical Service: 1-888-GO-REPLY (467-3759)
Reply® is a registered trademark of Fleetwood Group, Inc.
Other trademarks contained herein are the property of their respective holders.
Revision History:
Rev Date Description
A 3/16/2009 Original
iii
Table of Contents
1.0 KG3EI.........................................................................................................................................................................4
1.1 DESCRIPTION............................................................................................................................................................4
1.2 FCC, IC, AND EU COMPLIANCE INFORMATION ......................................................................................................4
1.3 STANDARDS AND GUIDELINES.................................................................................................................................4
1.4 FCC/IC COMPLIANCE ..............................................................................................................................................4
1.5 EU COMPLIANCE......................................................................................................................................................5
1.6 TECHNICAL SPECIFICATIONS ...................................................................................................................................5
4
1.0 KG3EI
1.1 Description
The KG3EI is a low power wireless response keypad. The KG3EI is used to interact with an audience so they can
provide real time feed back to questions. It communicates at 2.4GHz, GFSK to a base station. The base unit polls
keypads, and displays result.
The overall operation of the KG3EI is controlled by a microcontroller. This microcontroller is powered from
approximately 3V and uses a 16 MHz reference. The microcontroller handles control of the RF communications,
keypad inputs, EEPROM, and LCD.
RF communications use the Nordic 24L01+ 2.4 GHz transceiver. The Nordic chip uses a 16 MHz reference
oscillator that is shared with the microcontroller for TX/RX and is also powered by 3V. The Nordic transceiver uses
an integral PCB antenna.
1.2 FCC, IC, and EU Compliance Information
KG3EI Low Power Wireless Response Keypad
Responsible Party Pertaining to the Declaration of Conformity
Fleetwood Group, Inc.
11832 James Street
Holland, MI 49424
Attn: Product Service Coordinator
Phone: 888-467-3759
1.3 Standards and Guidelines
This device complies with the following European Directives and USA/Canada Regulations:
¾ Directive 1999/5/EC on radio equipment and telecommunication terminal equipment and the mutual
recognition of their conformity
¾ Directive 2006/95/EC on the harmonization of laws of member states related to electrical equipment
designed for use within certain voltage limits
¾ The USA Federal Communications Commission (FCC) Rules and Regulations
¾ Industry Canada Rules and Regulations
This device complies with the following national and international standards:
¾ EN 301 489-1 V1.8.1
¾ EN 301 489-17 V1.3.2
¾ EN 300 328 V1.7.1
¾ EN 60950-1: 2006
¾ FCC 15B, 15.247: 10-01-08
¾ IC RSS-210 Issue 7
1.4 FCC/IC Compliance
This device complies with Part 15 of the FCC Rules and RSS-210 of the Industry Canada Rules. Operation is
subject to the following two conditions: (1) this device may not cause interference and (2) this device must accept
any interference, including interference that may cause undesired operation of the device. The user is cautioned that
changes or modifications to the device that are not approved by the manufacturer could void the user’s authority to
operate the device.
5
1.5 EU Compliance
This device is a 2.4 GHz low power response system controller intended for residential and commercial use in all EU and
EFTA member states .
Notice
The base and keypad units may be susceptible to Electrostatic Discharge (ESD) and other similar fast transient events causing system interruption.
Should system interruption occur, reboot computer, reset base unit by disconnecting and reconnecting USB cable and push any key on keypads which
have powered down.
1.6 Technical Specifications
Min Typ Max
VDD Supply Voltage
Battery, 2AA
2.2
3.0
3.4 V
To Operating Temperature 15 40 Deg C
